Installation Guide
Wyse®Rx0L Thin Client
Flash and RAM Upgrade Option Kit
Issue: 052209
PN: 883884-11L Rev. A

ii
Copyright Notice
© 2009, Wyse Technology Inc. All rights reserved.
This manual and the software and firmware described in it are copyrighted. You may not reproduce, transmit,
transcribe, store in a retrieval system, or translate into any language or computer language, in any form or by any
means, electronic, mechanical, magnetic, optical, chemical, manual or otherwise, any part of this publication
without express written permission.
End User License Agreement (“License”)
A copy of the Wyse Technology End User License Agreement is included in the software and provided for your
reference only. The License at http://www.wyse.com/license as of the purchase date is the controlling licensing
agreement. By copying, using, or installing the software or the product, you agree to be bound by those terms.
Trademarks
The Wyse logo and Wyse are trademarks of Wyse Technology Inc. Other product names mentioned herein are for
identification purposes only and may be trademarks and/or registered trademarks of their respective companies.
Specifications subject to change without notice.
Patents
This product and/or associated software are protected by copyright, international treaties, and various patents,
including the following U.S. patents: 6,836,885 and 5,918,039.
Restricted Rights Legend
You acknowledge that the Software is of U.S. origin. You agree to comply with all applicable international and
national laws that apply to the Software, including the U.S. Export Administration Regulations, as well as end-user,
end-use and country destination restrictions issued by U.S. and other governments. For additional information on
exporting the Software, see http://www.microsoft.com/exporting.
Ordering Information
For availability, pricing, and ordering information in the United States and Canada, call 1-800-GET-WYSE
(1-800-438-9973) or visit us at http://www.wyse.com. In all other countries, contact your sales representative.
FCC Statement
This equipment has been tested and found to comply with the limits for either Class A or Class B digital devices,
pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful
interference in a residential installation. This equipment generates, uses, and can radiate radio frequency energy
and, if not installed and used in accordance with the instructions, may cause harmful interference to radio
communications. However, there is no guarantee that interference will not occur in a particular installation. If this
equipment does cause harmful interference to radio or television reception, which can be determined by turning
the equipment off and on, the user is encouraged to try to correct the interference by one or more of the following
measures:
•Reorient or relocate the receiving antenna.
•Increase the separation between the equipment and the receiver.
•Connect the equipment into an outlet on a circuit different from that to which the receiver is connected.
•Consult the dealer or an experienced radio/TV technician for help.
Shielded interconnect cables and shielded AC power cable must be employed with this equipment to insure
compliance with the pertinent RF emission limits governing this device. Changes or modifications not expressly
approved by the system's manufacturer could void the user's authority to operate the equipment.
Caution
Modifications made to the product, unless expressly approved by Wyse Technology, could void
the user’s authority to operate the equipment.

iii
Regulatory Compliance for Wyse Products
Basic EMC and Safety Requirements
Wyse appliances are compliant with the regulatory requirements in the regions listed below.
U.S.A. - FCC Part 15 (class B)
Canada - CAN/CSA-C22 No. 60950
Europe - EN 55022 (class B), EN 61000-3-2 (class A), EN 61000-3-3, EN 90650-1:2000+ALL
Canadian DOC Notices
Class A
This digital apparatus does not exceed the Class A limits for radio noise emissions from digital apparatus set out in
the Radio Interference Regulations of the Canadian Department of Communications.
Le présent appareil numérique n’émet pas de bruits radioélectriques dépassant les limites applicables aux
appareils numériques de la classe A prescrites dans le Réglement sur le brouillage radioélectrique édicté par le
Ministère des Communications du Canada.
Class B
This digital apparatus does not exceed the Class B limits for radio noise emissions from digital apparatus set out in
the Radio Interference Regulations of the Canadian Department of Communications.
Le présent appareil numérique n’émet pas de bruits radioélectriques dépassant les limites applicables aux
appareils numériques de la classe B prescrites dans le Réglement sur le brouillage radioélectrique édicté par le
Ministère des Communications du Canada.
Device Power Supply
For use with external power supply included in the shipping carton.
Caution
Replace power adapter with the same or equivalent type as recommended by the manufacturer.
Model Rx0L Thin Client
For use with External Power Supply Model 0335A1965 or certified equivalent model supplied by the manufacturer,
output rated 19Vdc, 3.42A.
Battery Information
The Rx0L thin client contains an internal button cell battery replaceable by Wyse or one of our Authorized Service
Centers. For service, visit http://www.wyse.com/serviceandsupport/service/service.asp.
Warning
There is a risk of explosion if the battery is replaced by an incorrect type. Always dispose of used
batteries according to the instructions accompanying the battery.
Warning
Perchlorate Materials - Special Handling May Be Required under California Code of Regulations,
title 22. (Only required within the U.S.A.)

Contents
About this Guide 1
Wyse Technical Support 1
Related Online Resources Available at Wyse 1
Getting Started 2
Kit Warranty 2
Kit Contents 2
Required Tools and Materials 2
Removing the Thin Client Cover 3
Installing the Flash Module 4
Removing the Existing Flash Module 4
Installing the New Flash Module 4
Installing the RAM Module 5
Removing the Existing RAM Module 5
Installing the New RAM Module 5
Reassembling the Thin Client 6
List of Figures
1 Kit contents (both kits are shown) 2
2 Removing top and bottom screws 3
3 Left side cover removed to expose main board 3
4 Removing the existing Flash module 4
5 Removing the existing RAM module 5

Installing the Wyse Rx0L Thin Client
Flash and RAM Upgrade Option Kits
About this Guide
This guide enables users of Wyse Rx0L thin clients to install flash and RAM upgrades.
The information in this document is intended for the following Rx0L thin client products:
•R50L
•R90L
Wyse Technical Support
To access Wyse technical resources, visit http://www.wyse.com/support. If you still have
questions, you can submit your questions using the Wyse Self-Service Center (from the
Wyse Web site, navigate to Support, then Overview, and click “Wyse Self-Service and
Knowledge Base Center”) or call Customer Support at 1-800-800-WYSE (toll free in U.S.
and Canada). Hours of operation are from 6:00 A.M. to 5:00 P.M. Pacific Time, Monday
through Friday.
To access international support, visit http://www.wyse.com/global.
Related Online Resources Available at Wyse
Wyse thin client features can found in the Datasheet for your specific thin client model.
Datasheets are available on the Wyse Web site at: http://www.wyse.com/products.
Administrator, User, and ReadMe documentation for your thin client model are available
at: http://www.wyse.com/manuals.
Wyse Thin Computing Software is available on the Wyse Web site at:
http://www.wyse.com/products/software.

2Chapter
Getting Started
This chapter provides information about your flash and/or RAM kit warranty, kit contents,
required tools, and removing the thin client’s cover.
Kit Warranty
The warranty on this kit assumes the remaining months of warranty of the thin client in
which it is installed, or for 90 days, whichever is greater. Installation of this kit will not void
the factory warranty, however the user will be responsible for damage due to improper
installation.
Kit Contents
Included in the kit is the flash or RAM module as shown in Figure 1.
Figure 1 Kit contents (both kits are shown)
Note
Your flash or RAM module may look different
Required Tools and Materials
You will need the following tools to install the kit:
• #2 Phillips screwdriver
• Needle-nose pliers
• Container for holding screws, optional
Warning
Flash and RAM modules may be susceptible to damage by Electro-Static
Discharge (ESD). All industry-standard cautions should be followed to avoid
ESD. Before you remove or install a modules, touch any metal part of the
chassis and keep that contact with the chassis during the installation
process.

3
Removing the Thin Client Cover
To remove the cover of your thin client:
Caution
Follow all precautions listed in the Quick-Start Guide that came with your thin
client for disconnecting and reconnecting the thin client.
1. Perform a proper shutdown of the thin client by closing all files and ending your
session, and then press the power button to turn off the thin client.
2. Unplug the power cord and power adapter, remove all of the cables from the rear of the
thin client, and detach the vertical foot.
3. Position the thin client horizontally, and then remove the screws from the top and
bottom of the thin client using a #2 Phillips Screwdriver as shown in Figure 2.
Figure 2 Removing top and bottom screws
4. Open the thin client by sliding the left side cover toward the rear of the device and lift
off to expose the main board as shown in Figure 3. Notice that the rear of the thin client
is positioned at the bottom of the photo.
Figure 3 Left side cover removed to expose main board

4Chapter
Installing the Flash Module
This section provides information on how to install the flash kit in a Wyse Rx0L thin client.
Warning
Flash and RAM modules may be susceptible to damage by Electro-Static
Discharge (ESD). All industry-standard cautions should be followed to avoid
ESD. Before you remove or install a modules, touch any metal part of the
chassis and keep that contact with the chassis during the installation
process.
Removing the Existing Flash Module
To remove:
1. Note where the connector of the flash module is located in Figure 4. Use Needle-nose
pliers to squeeze the plastic standoff lock as you rock the module back and forth to
remove module from the socket.
Figure 4 Removing the existing Flash module
Installing the New Flash Module
To install:
1. Install the new module in the reverse order of removing the old flash module. Carefully
press the module onto the standoff lock and connector, making sure to lock it into
place.

5
Installing the RAM Module
This section provides information on how to install the RAM kit in a Wyse Rx0L thin client.
Warning
Flash and RAM modules may be susceptible to damage by Electro-Static
Discharge (ESD). All industry-standard cautions should be followed to avoid
ESD. Before you remove or install a modules, touch any metal part of the
chassis and keep that contact with the chassis during the installation
process.
Removing the Existing RAM Module
To remove:
1. Unlock the two module locking clamps at either side of the module by pushing in the
direction of the arrows as shown in Figure 5.
2. Remove the RAM module.
Figure 5 Removing the existing RAM module
Installing the New RAM Module
To install:
1. Insert the new RAM module into the connector of the original module.
2. Press down on the module so that the two locks with snap in place, securing the
module.

6Chapter
Reassembling the Thin Client
To reassemble the thin client:
1. Replace the top cover in the reverse order as described in "Removing the Thin Client
Cover."
2. Attach the vertical foot.
3. Reconnect the video display, keyboard, mouse, network cable, and power adapter to
the thin client before connecting to your electrical outlet.
4. The thin client is ready to re-image since the flash module does not contain an
operating system. Turning on power to your thin client without software will display the
error message “NO OPERATING SYSTEM FOUND.”
