X-Vision XHC1080S10IRN User manual

Professional Pan Tilt Zoom
IR Speed Dome Camera
Version 1
User Guide
Thank you purchasing the speed dome camera from Xvision.
Please ensure that you read and understand this User Guide before operating the camera.
Please store this Installation Guide in an easily accessible location.
MODELS: XHC1080S10IRN and XHC1080S27IRN
HD
1080P
PRO

X v i s i o n . c o m P a g e 2 | 30
Table of Contents
Brief introduction and application ...........................................................................................3
Safety Notice............................................................................................................................4
Installation ...............................................................................................................................6
Functional Descriptions and Features......................................................................................7
Cable connection ..............................................................................................................8
Address, Protocol, Baud rate setting .......................................................................................8
Address setting ....................................................................................................................8
Baud rate setting..................................................................................................................9
Protocol setting..................................................................................................................10
Main Menu OSD Tree.............................................................................................................11
Function settings....................................................................................................................12
Set/call preset ....................................................................................................................12
Set preset position.........................................................................................................12
Call preset ......................................................................................................................12
Calling Tours/Cruise ...........................................................................................................12
Calling auto tour line......................................................................................................13
Stay time ............................................................................................................................13
Clear cruise routes .............................................................................................................14
Limit scan ...........................................................................................................................14
Setting Limit scanning on left and right .........................................................................14
Calling Limit scan ...........................................................................................................14
360° horizontal scanning....................................................................................................15
Pattern scan .......................................................................................................................15

X v i s i o n . c o m P a g e 3 | 30
Main Functions Fast Call Up...................................................................................................17
FAQ’s ......................................................................................................................................25
Specification...........................................................................................................................27
Brief introduction and application
The XHC1080S10IRN and XHC1080S27IRN can be widely
used in the in an area with low light levels, or no light where
high-speed monitoring in large scope is required, such as rivers,
forests, roads, railways, airports, ports, square, parks, scenic
spots, streets, stations, large stadiums and external boundary of
living quarters, etc.
As a high-end monitoring product, the XHC1080S10IRN and
XHC1080S27IRN features strong, stable and reliable functions in
addition to easy operation and installation. This camera has many
functions, such as fast trace, 360° unlimited rotation, 180°
automatic overturn, area scan, preset location scan and pattern
scan.
This camera applies to watching a moving target in a big area, and
has the performance that several fixed cameras cannot achieve.
Therefore it is widely used in various areas such as airport, station,
superstore, political-legal organ, bank, enterprise, warehouse,
hospital, etc.

X v i s i o n . c o m P a g e 4 | 30
Safety Notice
Do not install the equipment in an environment with too much
moisture, dust or smoke dust as this may result in fire or
electric shock.
In the unlikely event that the equipment should malfunction and
emit an abnormal smell of smoke, please immediately stop it, shut
off the power and contact your supplier.
Please do not place this equipment near a heat source to avoid risk
of fire.
Please do not store, install and use this product in danger areas
with inflammable or explosive substances.
Please make sure the power is turned off when installing the product.
Please do not use the PTZ in an environment where temperatures
that exceed either -35°C to +60°C.

X v i s i o n . c o m P a g e 5 | 30
Package contents:
The contents for the XHC1080s20IRN and XHC1080S27IRN are
shown below:

X v i s i o n . c o m P a g e 6 | 30
Installation

X v i s i o n . c o m P a g e 7 | 30
Functional Descriptions and Features
XHC1080S10IRN
Camera:
HD AHD 1080P 2.0 Megapixels
1/3" CMOS Sensor, 10x, f= (5.0mm~50mm), D/N (ICR-Cut), DWDR, Color:
0.1lux, B/W:0.01lux.
Dome Features:
1. New 32 bit processor, with soft ID, more storage space, higher speed,
better performance, lower consumption
2. Imported array IR LED, auto adjust zoom according to different distance
3. IR range 70M
4. Highest ESD protection against lightning and power surges.
5. HD1080P AHD output
7. IP66 Protection grade: IP66
XHC1080S27IRN
Camera:
HD AHD 1080P 2.0Mpixes
1/3" CMOS Sensor, 27x, f=4.7mm～90.0mm, D/N (ICR-Cut), DWDR, Color:
0.1lux, B/W:0.01lux.
Dome Features:
1. New 32 bit processor, with soft ID, more storage space, higher speed,
better performance, lower consumption
2. Imported array IR LED, auto adjust zoom according to different distance
3. IR range 150M
4. Highest ESD protection against lightning and power surges.
5. 360 degree continued rotation, manual pan speed 0~240°/S, manual tilt

X v i s i o n . c o m P a g e 8 | 30
speed 0~120°/S, preset speed 400°/S.
6. HD1080P AHD output
7. IP66 Protection grade: IP66
Cable connection
Video, Power and RS485 cable guide
Address, Protocol, Baud rate setting
You can set the address, the Protocol and the baud rate manually.
There is a removable plate under the ball cover which you can open and
close at any time. Open the plate you will see an 8-bit dial switch; move
the dials 1-8 up to set address code of the dome.
Address setting
No.1~ No.8 are used to set the address codes, you can set address codes
within the range 1~255, factory default is 1. Use binary, in the table below,

X v i s i o n . c o m P a g e 9 | 30
the reference to binary means 0 = off and 1 = on.
Binary
Add
Binary
Add
Binary
Add
Binary
Add
000000
00
0
111100
00
15
011110
00
30
10110
100
45
100000
00
1
000010
00
16
111110
00
31
01110
100
46
010000
00
2
100010
00
17
000001
00
32
11110
100
47
110000
00
3
010010
00
18
100001
00
33
00001
100
48
001000
00
4
110010
00
19
010001
00
34
10001
100
49
101000
00
5
001010
00
20
110001
00
35
01001
100
50
011000
00
6
101010
00
21
001001
00
36
11001
100
51
111000
00
7
011010
00
22
101001
00
37
00101
100
52
000100
00
8
111010
00
23
011001
00
38
10101
100
53
100100
00
9
000110
00
24
111001
00
39
01101
100
54
010100
00
10
100110
00
25
000101
00
40
11101
100
55
110100
00
11
010110
00
26
100101
00
41
00011
100
56
001100
00
12
110110
00
27
010101
00
42
10011
100
57
101100
00
13
001110
00
28
110101
00
43
01011
100
58
011100
00
14
101110
00
29
001101
00
44
11011
100
59
Baud rate setting
(The baud rate is adaptive this means it can auto sense what your controller/DVR is set
to and will auto connect on the correct Baud rate).
You can also set this manually, set through the 4th ~5th dial codes，Set
up the baud rateto 2400BPS、4800BPS、9600BPS、19200BPS。Dial
every number to be "ON" = 1, dial to be "OFF" = 0，Baud rate and dial
codes table below.

X v i s i o n . c o m P a g e 10 | 30
Baud rate and dial codes switch matching sheet
Dial codes
2400 bps
4800 bps
9600 bps
19200 bps
No.4
OFF
ON
OFF
ON
No.5
OFF
OFF
ON
ON
Protocol setting
There is no need to set the Protocol to match your DVR/Controller as
this is Adaptive and will auto sense what your device is set to. You
don't need to set；PELCO_D、PELCO_P support PELCO_D and
PELCO_P

X v i s i o n . c o m P a g e 11 | 30
Main Menu OSD Tree
You can call preset 103 to bring up the PTZ OSD menu.

X v i s i o n . c o m P a g e 12 | 30
Function settings
Set/call preset
Presets are defined points you can set on the PTZ camera, These PTZ IR
dome camera supports 255 presets.
Set preset position
Move the PTZ IR dome to the required position you would like to set
(remember). You can use the Controller or the DVR for this. You can also
zoom in or out and this will be remembered.
Depending on your method of controlling the PTZ IR dome camera you will
find different buttons.
Press the key “set preset/Set”
Enter “1” or the required Preset number you wish.
Press the key “enter” to save the preset.
Call preset
Press the key “call preset position or Preset”
Then press the required preset number “1”
Click “Enter” This will move your PTZ camera to the stored preset
location.
Calling Tours/Cruise
Tours/Cruise enable you to set a defined group of presets and initialise
the tour of the group of presets. There are 8 auto tours/cruise routes for
the PTZ dome camera，Each tour line can storeup to 5 presets minimum
and a maximum of 30 presets.

X v i s i o n . c o m P a g e 13 | 30
Calling auto tour line
Use your controller or DVR to call preset “No.98” to initialise the 1st
cruise/auto tour.
Patrol line
Calling preset
Contains
preset
First cruise
call No.98 preset
1 ～ 5 preset
Second cruise
call No.97 preset
6 ～ 15 preset
Third cruise
call No.96 preset
16 ～ 35
preset
Stay time
You can set how long the Tour will stay on a preset, this can be set
between 5 to 60 Seconds Call the preset “No.123”, the stay time add 5
sec；“call No.124 preset position”，the stay time minus 5 sec；
stay time
operation
default 10
sec
Call No.106 clear all Settings to restore the
default
Add 5 sec
Call No.123 preset
Minus 5
sec
Call No.124 preset
Example: using the DVR or control we set the stay time to be 8 sec
Press the key “call preset position”, then enter “123”
Press “enter”

X v i s i o n . c o m P a g e 14 | 30
Clear cruise routes
Call No.106 clear all Settings to restore the default
Limit scan
(Limit scanning on left and right 360°horizontal scanning)
Setting Limit scanning on left and right
Move the PTZ camera to the Right limit position you require and
“set No.83 preset position”.
Move the PTZ camera to the Left limit position you require and
“set No.84 preset position”.
The Speed dome will run just between these two points only.
Example: Using the DVR or controller
Press the key “set preset”, Then move the camera to the Right
position
Enter “83”
Press the key “enter”
Move the PTZ Speed dome to the required Left position
Enter “84”
Press the key “ enter”
Calling Limit scan
Call No.91 preset position, the PTZ speed dome will start limit scanning.
You can set 3 Limit scans.

X v i s i o n . c o m P a g e 15 | 30
Limit
scanning
setting
calling
First scan
Left limit：set No.83 preset
Right limit：set No.84
preset
Call No.91
preset
Second scan
Left limit：set No.85preset
Right limit：set
No.86preset
Call No.92
preset
Third scan
Left limit：set No.87 preset
Right limit：set No.88
preset
Call No.93
preset
360° horizontal scanning
Call No.99 preset position, the PTZ speed dome will start to Scan
360°horizontal scanning.
Pattern scan
This product has 4 groups of pattern scan.
Pattern scanning is used when you have an irregular pattern that you
want patrolled, this does not use preset positions but recorded moves
using the Controller or DVR controls.
Move to the target location, then call No.113 preset position to start
recording scanning track.
Move the controller or DVR joystick around your required pattern.
When you are happy with your movements, move to where you want
the pattern to end, then call No.114 preset position to end of
recording scanning track.

X v i s i o n . c o m P a g e 16 | 30
Now the pattern scan is complete
Call No.108 preset position will start the first pattern scan.
pattern
scan
Set command
Call command
first
The start point：call No.113
preset
The end point：call No.114
preset
call No.108
preset
second
The start point：call No.115
preset
The end point：call
No.116preset
call No.109
preset
third
The start point：call No.117
preset
The end point：call No.118
preset
call No.110
preset
fourth
The start point：call No.121
preset
The end point：call No.122
preset
call No.111
preset
Call No.106 preset to clear all Settings to restore the default to clear
Limit scanning、360°horizontal scanning and pattern scan.

X v i s i o n . c o m P a g e 17 | 30
Main Functions Fast Call Up
Fast
Call Up
Function
Fast
Call Up
Function
Call 81
Auto IR
Call 95
Open OSD Menu
Call 82
Turn on IR
Call 99
360°Horizontal scanning
Call 83
Turn off IR
Call 105
RATIO SPEED :
ON and OFF
Call 106
Clear all settings to
restore the default
Call 107
Horizontal start position
fix
Set 125
Set home position
Call 125
Clear Home position
Call 126
Increase 1 minute for
home position
( Max 10 minutes )
Call 127
Decrease 1 minute for
Home position
( Min. 1 minute )
Tour
Fast Call Up
Function
Call 96
Run tour 3 ( 16 ～ 30 preset )
Call 97
Run tour 2 ( 6 ～ 15 preset )
Call 98
Run tour 1 ( 1 ～ 5 preset )

X v i s i o n . c o m P a g e 18 | 30
A-B scan
Fast Call Up
Function
Fast Call Up
Function
Call 91
A-B scan 1
Set 83
Left limit 1
Set 84
Right limit 1
Call 92
A-B scan 2
Set 85
Left limit 2
Set 86
Right limit 2
Call 93
A-B scan 3
Set 87
Left limit 3
Set 88
Right limit 3
Pattern scan
Fast Call
Up
Function
Fast Call
Up
Function
Call 108
Run pattern
scan 1
Call 113
start recording scanning
track 1
Call 114
end of recording scanning
track 1
Call 109
Run pattern
scan 2
Call 115
start recording scanning
track 2
Call 116
end of recording scanning
track 2
Call 110
Run pattern
scan 3
Call 117
start recording scanning
track 3
Call 118
end of recording scanning
track 3
Call 111
Run pattern
scan 4
Call 121
start recording scanning
track 4
Call 122
end of recording scanning
track 4

X v i s i o n . c o m P a g e 19 | 30
Former control status
Fast Call Up
Function
Call 130
Release PTZ
camera
movement lock
Before calling cruise, limiting
the scan, 360 degree
panorama, call 131 preset point
could lock PTZ camera
movement. After lock PTZ
camera movement, PTZ
camera will back to the former
controlled status when user
stop control PTZ camera. Call
130 preset point could release
the lock.
Call 131
Lock PTZ
camera
movement
Call 132
Park mode
increase time
You can set the PTZ speed
dome to go back to a command
i.e. tour, cruise, pattern mode
after a set time or no
interaction. The default time is 5
minutes. User can increase the
time by calling 132 preset point.
Each calling operation increase
1 minute. Calling 133 preset
point to decrease the recovery
time. Each calling operation
decrease 1 minute. Max 10
minutes, and minimum 1
minute.
Call 133
Park mode
decrease time

X v i s i o n . c o m P a g e 20 | 30
Special function
Fast Call Up
Function
Call 103
Open
Camera Menu
ZOOM + : UP
ZOOM - : DOWN
FOUCS Near: Left
FOUCS Far: Right
Iris: Enter
Fast Call Up
Function
Fast Call Up
Function
Set 254
preset, call 1
ZOOM OSD ON
Set 254 preset,
call 17
HLC OFF
Set 254
preset, call 2
ZOOM OSD OFF
Set 254 preset,
call 18
HLC level 1
Set 254
preset, call 3
Through fog OFF
Set 254 preset,
call 19
HLC level 2
Set 254
preset, call 4
Through fog level 1
Set 254 preset,
call 20
HLC level 3
Set 254
preset, call 5
Through fog level 2
Set 254 preset,
call 21
Indoor
Set 254
preset, call 6
Through fog level 3
Set 254 preset,
call 22
Outdoor
