X-Vision XIR501 User manual

CCTV
Model: XIR501
Colour Dome Camera
with 15m Nightvision
CCTV
Model:
XIR501
Colour Dome Camera
with 15m Nightvision
Manufactured exclusively for:
Xvision (Europe) Group,
Head Office: London, U.K.
Email: [email protected]
Web: www.x-vision.co.uk
TECHNICAL SUPPORT:
For Technical Support for any Xvision product please contact your local
distributor.
LIMITED WARRANTY:
This product is supplied with a 2 Year warranty.The Warranty excludes
products that have been misused, (including accidental damage) and
damage caused by normal wear and tear. In the unlikely event that you
encounter a problem with this product, it should be returned to the
place of purchase.
Before you begin
•Please unpack the box carefully and identify that all the parts are present.
•Do not cut the camera cables, this will void the warranty.
•Make sure you use only the recommended power supply. Damage caused to the camera by
incorrect voltage or wiring is not covered by the warranty.
The camera is suitable for indoor use only (unless used with an optional external housing).
Please bear in mind the following points when choosing a mounting position.
•The camera must be positioned so that it will not point directly into the sun (sunrise and
sunset) or any bright light, as this may cause damage to the camera.
•Avoid viewing areas where half the area is in bright sunlight and the other half is dark,
such as in the shadow of a building. All types of cameras have difficulty in ‘seeing’ with
such a large lux level variation.
Specification
Model: XIR501
Picture Type: Day/Night (B/W &Colour)
Image Sensor: Sony 1/3” Super HAD CCD
DSP: Xvision IXC1DN
Resolution: 480 TVL
Lens Viewing Angle: 78°
Infra Red Nightvision: 15 metres
Minimum Illumination: 0.1 Lux
Audio: No
Operating Voltage: 12V DC 750mA
Suggested Power Supply: 12V DC 1250mA Regulated
Mounting: Ceiling
Weatherproofing: No
Dimensions (ØxH): 133x84mm

STEP 4: Set the proper image by moving the camera body (some model
types limit the PCB board to 180° rotational adjustment) and set
the focus by turning the lens either to the left or to the right.
When the camera is correctly focused, rotate the dome housing
clockwise to secure it to the mounting base.
STEP 5: Lock the dome by using the countersunk head screw supplied.
1. Connect the video output to the monitor or other video device through
a75 Ohms type coaxial cable.
2. Connect the DC jack with the power source.
Description
Package Contents Installation
How to Operate
THANK YOU VERY MUCH FOR PURCHASING OUR PRODUCT
The XIR501 colour dome camera is designed for medium to high risk applications. It
offers very high resolution 480 TVL images from its Sony 1/3" Super HAD CCD
sensor and will provide images in complete darkness up to 15 metres and beyond
15 metres in light levels above 0.1 lux. The camera is designed for internal use and
ceiling mounting.
1. Instruction Manual
2. XIR501 Dome Camera 3. Plastic Bag- containing 4. 4x Bracket mounting screws
5. Countersunk Head Screw
STEP 1: Select a suitable position on the wall or ceiling to install the
camera.
STEP 2: Rotate the dome housing counterclockwise to remove it from
the mounting base (as shown in the figure below).
Note! The inner parts may differ depending on the camera model type.
STEP 3: Place the mounting base onto the ceiling and centre over the
mounting hole,using the four retaining screws for the bracket
(A) supplied in the accessories package (shown in the figure
below).
Main Features
•Dual mode High Resolution CCD sensor provides very good quality Colour images
in low light conditions of 0.1 lux or above and B/W images in low light conditions
below 0.1 lux and in complete darkness.
•Integrated Long Life Infra Red LEDs turn on automatically when the camera
switches to B/W mode and provide up to 15 metres night vision
•Tamper resistant and easy to clean as all moving parts are behind the dome cover
•Sony 1/3" Super HAD CCD image sensor for 480 TVL resolution images and 0.1
lux low light sensitivity
•Xvision IXC1DN Digital Signal Processing (DSP) chip which has been optimised
for internal viewing and features Automatic Gain Control, Automatic Electronic
Iris,Auto White Balance, Back Light Compensation, Low Smear, Edge
Enhancement, Zero Colour Rolling and Day/Night
•3.6mm focus free lens for a 78°viewing angle
