X-Vision XPD700W-2 User manual

Before you begin
• Please unpack the box carefully and idenfy that all the parts are present.
• Please bear in mind the following points when choosing a mounng posion.
> The camera must be posioned so that it will not point directly into the sun (sunrise
and sunset) or any bright light, as this may cause damage to the camera
> Avoid viewing areas where half the area is in bright sunlight and the other half is
dark, such as in the shadow of a building. All types of cameras have diculty in
‘seeing’ with such a large lux level variaon.
• Do not cut the camera cables, this will void the warranty.
• Make sure you use only the recommended power supply. Damage caused to the
camera by incorrect voltage or wiring is not covered by the warranty.
User Manual
Model: XPD700W-2
Professional 700 TVL Dome
with DNR and WDR

2
Contents
1. Safety Precautions ........................................................ 3
2. Product Description ...................................................... 4
3. Features ........................................................................ 4
4. Contents ....................................................................... 4
5. Installation .................................................................... 5
6. Camera OSD Control ..................................................... 7
7. OSD Menu Structure ..................................................... 7
8. SETUP Menu Functions ................................................. 9
8.1 Lens .......................................................................... 8
8.2 Shutter/AGC ............................................................. 8
8.3 White Balance .......................................................... 8
8.4 Backlight ................................................................. 10
8.5 Picture Adjust ......................................................... 10
8.6 ATR ......................................................................... 11
8.7 Motion Detection ................................................... 11
8.8 Day/Night ............................................................... 12
8.9 Noise Reduction ..................................................... 12
8.10 Camera ID ............................................................. 13
8.11 Sync ....................................................................... 13
8.12 Language ............................................................... 13
8.13 Camera Reset ........................................................ 13

3
Thank you for purchasing this Xvision camera. Before operating this product, please
read this instruction manual carefully.
zDo not disassemble or modify the camera. Please refer repairs or service to a
qualified service technician.
zTake care when installing the camera. Avoid scratching the front glass window.
zAvoid shock and vibration. Do not install the camera on an unstable surface. It
can be damaged by improper use or storage.
zDo not attempt to point the camera at the sun or other extremely bright objects.
It can cause image smearing whether the camera is powered on or not and can
lead to the damage of the CCD (Charge Coupled Device).
zWhen camera is installed next to equipment, such as wireless communication
device, that emits a strong electromagnetic field, some irregularity such as noise
on the monitor screen may occur.
zOperating temperature: -10° ~ +45°C
zProvide ample slack in the video and power cables once the camera is installed in
its final position.
zRequest the service of a qualified technician if the camera malfunctions or
generates excessive amounts of heat.
1. Safety Precautions

4
3. Features
2. Product Description
• XPD700WIR-2 Camera
• User Manual
• Screws & Wall Plugs
The XPD700W-2 is a professional CCTV dome camera that has excellent colour
balance and a high resolution 700 TVL image, resulting in natural colours and super
sharp images.
It features a powerful ARM based DSP, which processes the image in real time and
improves it by using Digital Noise Reduction and Wide Dynamic Range to produce
an even image, that does not suffer from bright or dark spots. Further enhancing
the picture is a megapixel lens, which is fully adjustable, allowing you to select the
perfect viewing angle for your application. The camera also features an On Screen
Display (OSD) that allows the user to fully customise the advanced features to its
environment.
The XPD700W-2 is designed for internal use only and can be wall or ceiling mounted.
z700 TVL high resolution colour image
zSony 1/3” Ultra High Resolution CCD Sensor with an Xvision X7 DSP.
z2.8 to 12mm Varifocal Auto Iris Lens for 23 to 92° viewing angle for super sharp
images and easy selection of the optimum viewing angle during installation.
zSmart DNR (Digital Noise Reduction) reduces the noise on the image when
viewing in low lux environments (like at night). This reduces the size of the image
when being recorded by a DVR, resulting in a saving of disk space.
zWDR (Wide Dynamic Range) feature allows the camera to display balanced
pictures even when the scene being watched has bright spots or various light
levels and back light conditions.
zOn Screen Display menu for complete customisation of advanced features.
zDesigned for wall/ceiling mounting and is suitable for internal use only.
4. Contents

5
5. Installation
1. Select a suitable posion on the wall or ceiling to install the camera.
2. Press the buon on the camera shell (g 1) to unlock the dome cover and
removing it to expose the camera’s internal structure. (g 2).
3. Remove the black dome base from the main camera shell (g 3) by unlocking it
with the lever (g 4), and then turning it an-clockwise.
4. Secure the black dome base in the desired posion with xing screws using the 3
designated screw holes (g 5).
5. Re-aach the main camera shell back onto the dome base and turning it
clockwise to lock it in place.
6. The camera’s viewing angle can then be adjusted by moving the lens to the
desired viewing posion.
7. The lens can then be adjusted by using the 2 screws for the focus and zoom (g
6).
8. Reaach the dome cover back onto the main camera shell (by lining it up with
the arrow on the dome cover) and push it in to secure it.
fig 1 fig 2
fig 3 fig 4
fig 5 fig 6
Push
Button
Screw
Holes
Focus/Zoom
Adjustment
Screws
Lever

6
5. Installation continued
CONNECT THE POWER & VIDEO CABLES
1. Connect the video output to the monitor or other video device through a 75 Ohms
type coaxial cable.
2. Connect the power source, insert the AC plug into the AC socket and the DC plug
into the DC Jack (+12V DC in jack centre).
12V DC Power Cable
Video Cable
6. Camera OSD Control
Various camera settings can be adjusted using the OSD button located on the
camera’s cable.
Press the SET buon to enter the OSD Menu.
Press these controls For this Action
UP, DOWN Select between items in a list
LEFT, RIGHT Select a menu item to change its settings
SET (MENU) Call up the OSD Menu/
Access a Sub Menu
OSD Button Control Actions
SET
UP
LEFT RIGHT
DOWN

7
7. OSD Menu Structure
Please Note:
• The arrow symbol on the OSD menu indicates that there is a sub-menu
available. You can enter the sub-menu by pressing the SET (Menu) buon.
• RETURN: allows the user to return back to the previous menu.
• NEXT: allows the user to move to page 2 of the main menu.
• BACK: allows the user to return to page 1 of the main menu.
• EXIT: allows the user to exit out of the main menu completely.
• SAVE ALL: allows the user to save all the current sengs.
> AUTO > MANUAL
> ATW > PUSH > USER1 WB > USER2 WB >ANTI CR
> MANUAL WB > PUSH LOCK
> OFF > BLC > HLC
LENS
SHUTTER/AGC
WHITE BALANCE
BACKLIGHT
PICTURE ADJUST
ATR
MOTION DETECTION
PRIVACY
DAY/NIGHT
> AUTO > MANUAL
NOISE REDUCTION
CAMERA ID
SYNC
LANGUAGE
CAMERA RESET
> ON > OFF
> ON > OFF

8
8.1. LENS <Option : AUTO / MANUAL>
Select the iris aperture control method between ‘AUTO’ and ‘MANUAL’ by pressing
LEFT or RIGHT buon. When ‘AUTO’ is selected, you can press the seng buon to
enter its submenu.
• ‘TYPE’ lets you select between DC iris and video iris. However, video iris mode
is not supported on this camera. For the item ‘MODE’, you can select ‘AUTO’ to
let the camera automacally adjust the diameter of aperture. You can also set
the camera to open the aperture to the maximum degree, or use the minimum
aperture. The ‘SPEED’ item allows you to set aperture adjustment speed.
8.2. SHUTTER/AGC <Option : AUTO / MANUAL>
Allows you to congure the shuer speed and the AGC.
• Selecng ‘AUTO’, which is recommended when using a DC-iris lens, will allow the
camera to adjust shuer speed automacally based on the lighng condions.
Congure the funcon under dierent lighng condions in the submenu of
‘AUTO’.
• Under ‘HIGH LUMINANCE’, you can choose ‘AUTO IRIS’ mode (default seng)
to use a xed shuer while making the camera adjust iris level according to the
brightness of the scene. Choose ‘SHUT+AUTO IRIS’ mode to have the camera
adjust iris level according to the brightness, and control the exposure with DC
iris.
8. SETUP Menu Functions
AUTO SETUP
MODE
BRIGHTNESS
RETURN
HIGH LUMINANCE
AUTO IRIS
LOW LUMINANCE
MODE
BRIGHTNESS
AGC
x0.75
SETUP MENU
MODE
SPEED
RETURN
TYPE
AUTO
DC

9
8. SETUP Menu Functions continued
8.3. WHITE BALANCE (WHITE BALANCE MENU)
<Option : ATW / PUSH / USER1 WB / USER2 WB / ANTI CR / MANUAL WB / PUSH LOCK>
White Balance (WB) adjusts the colour temperature of the camera image to match
the type of light available, so that colours appear as natural as possible.
• ATW: Adjusts the cameras automacally to the colour temperature range. ‘SPEED’
controls the speed of ATW. Changing the ‘ATW FRAME’ and ‘ENVIRONMENT’
seng will aect the color temperature range. Smaller value for ‘ATW FRAME’
leads to a smaller range of color temperature. The color temperature ranges
from 2500K to 9500K for indoor environment, and 1800K to 10500K for outdoor
environment.
• Selecng ‘USER1/2’ mode will allow you to adjust the blue gain and red gain
individually. ‘MANUAL’ mode will let you adjust the blue gain and red gain
simultaneously. The ‘ANTI CR’ (an color rolling suppression) mode uses a smaller
range of color temperature than ATW mode does.
8.2. SHUTTER/AGC Continued
• If you have previously selected ‘MANUAL’ for the ‘LENS’ item, the mode will be
forced as ‘SHUT’. The ‘BRIGHTNESS’ item let you adjust the aperture to tailor the
brightness to your preference.
• Under ‘LOW LUMINANCE’, you can choose ‘AGC’ mode (default seng) to have
the camera automacally increase the gain when in low light condions to
produce a brighter image. The ‘BRIGHTNESS’ item allows you to tailor brightness
level to your needs.
• The MANUAL shuer opon provides a submenu that contains Mode, Shuer
and AGC seng. ‘SHUTTER’ item lets you specify the shuer me (between 1/50
sec and 1/10000 sec). Adjust ‘AGC’ level according to your lighng condions.
ATW
DELAY CNT
ATW FRAME
RETURN
SPEED
ENVIRONMENT
x0.75
INDOOR

10
8. SETUP Menu Functions continued
8.5. PICTURE ADJUST
Adjust various settings to sharpen the camera image.
• MIRROR: Provides a mirror reecon (horizontal) of the image.
• BRIGHTNESS: Adjust the brightness of the image (0-255)
• CONTRAST: Adjust the contrast of the image (0-255)
• SHARPNESS: Adjust the shaprness of the image (0-255)
• HUE: Adjust the hue of the image (0-255)
• GAIN: Adjust the gain of the image (0-255)
PICT ADJUST
MIRROR
BRIGHTNESS
CONTRAST
SHARPNESS
HUE
GAIN
RETURN
OFF
8.4. BACKLIGHT <Option : OFF / BLC / HLC>
This funcon allows the user to adjust advanced backlight sengs, giving the
following opons:
• OFF: Turns the BLC funcon o
• BLC: The BLC funcon makes objects in front of a bright scene (such as a
window on a bright sunny day) clearer to see by increasing their brightness and
making the background darker.
• HLC: Select this feature to select masking of bright areas in the image, such as
when viewing number plates when car headlights are on.
SETUP MENU
LENS
SHUTTER/AGC
WHITE BAL
BACKLIGHT
MANUAL
AUTO
OFF
OFF
ON
ATR
MOTION DET
NEXT
EXIT SAVE ALL
PICT ADJUST

11
8. SETUP Menu Functions continued
8.7. MOTION DETECTION <Option : OFF / ON>
This funcon alerts the user if moon has been detected within a user dened area:
• Switch to ‘ON’ and then press the seng buon to enter its submenu. You
can create up to 4 moon detecon areas by enabling ‘MONITOR AREA’ and
adjusng the ‘TOP/BOTTOM/LEFT/RIGHT’ slider separately. You can also adjust
the detecon sensivity. ‘BLOCK DISP’, when switched on, will highlight moving
objects in the scene with color blocks; when switched to ‘ENABLE ‘, it allows
you to enter a grid screen in which you will use the operaon buons to move
the translucent square and, by pressing the seng buon, specify areas in the
scene that will not be detected (which then will become transparent). To exit the
grid screen, press and hold the seng buon for 2 seconds before releasing it.
8.6. ATR <Option : ON / OFF>
Similar to Wide Dynamic Range, ATR can compensate for gradaon of the subjects
to the opmal level and thereby improve contrast in both bright and dark areas in
the picture. Switch on ATR and then press the seng buon to enter its submenu.
Use the operaon buons to select ‘LUMINANCE’ or ‘CONTRAST’ and then adjust
the level to your preference.
MOTION DET
DETECT SENSE
BLOCK DISP
MONITOR AREA
AREA SEL
TOP
BOTTON
LEFT
RIGHT
RETURN
OFF
ON
ATR
CONTRAST
RETURN
LUMINANCE
MID
MID

12
8. SETUP Menu Functions continued
8.9. Day/Night <Option : AUTO / COLOR / BLACK/WHITE >
Congure the day/night funcon by selecng between ‘AUTO’, ‘COLOR’ and ‘B/W’.
When ‘AUTO’ is selected, press the seng buon to enter its submenu as shown
below. The ‘DELAY CNT’ species the delay before a switchover. ‘DAYNIGHT’ and
‘NIGHTDAY’ determines the lux level at the switching point.
When ‘COLOR’ is selected, color image is always displayed. When ‘B/W’ is selected,
the picture is always displayed in black/white (the burst seng in its submenu is
synchronized with the burst seng in the submenu of ‘AUTO’).
8.8. PRIVACY ZONE <Option : OFF / ON>
Privacy funcon can create up to 4 masks to protect sensive areas in the scene.
Switch to ‘ON’ to enter its submenu as shown below. Select an area and adjust the
‘TOP/BOTTOM/LEFT/RIGHT’ slider separately to create a mask on screen. You can
also specify the color, transparency (1 being opaque) and mosaic seng (not eec-
ve on opaque masks).
PRIVACY
TOP
BOTTON
LEFT
RIGHT
COLOR
RETURN
OFF
TRANSP
MOSAIC
AREA SEL 1/4
1
1.00
DAY/NIGHT
BURST
DELAY CNT
DAY NIGHT
NIGHT DAY
RETURN
OFF

13
8.10. Noise Reduction
Here you can congure the 2D digital noise reducon funcon (default: o). Its
submenu includes 3 noise reducon mode: ‘Y’, ‘C’, and ‘Y/C’. Select any of the three
NR modes, highlight the Y or C level, and then press the LEFT/RIGHT buon to adjust
the slider for Y level (brightness signal) or C level (color signal return).
8. SETUP Menu Functions continued
8.11. CAMERA ID
You can create a camera tle to be displayed on the screen. Switch to ‘ON’ and
press the seng buon to input a custom tle. The camera tle can be named with
up to 52 characters in two lines. Highlight and select ‘POS’ to move the tle to the
preferred posion on screen.
8.11. SYNCHRONOUS MODE
This funcon is not used.
8.12 LANGUAGE
Press the LEFT/RIGHT buon to change the language of the OSD menu. Available
languages include English, Japanese, German, French, Russian, Portuguese, Spanish,
and Chinese.
8.13. CAMERA RESET
Resets all settings to the factory default.
NR
NR MODE
Y LEVEL
C LEVEL
RETURN
Y/C

14
Specifications
Head Office
Xvision Group (UK)
Unit 2, Valley Point, Beddington Farm Road,
Croydon, Surrey CR0 4WP
E: [email protected]
Far East Office
Kyoung Am Building,
157-27 Samsung-dong
Kangnam-ku, 135 090 Seoul, Korea
E: [email protected]
Manufactured exclusively for Xvision - www.xvision.com
TECHNICAL SUPPORT:
For Technical Support for any Xvision product please contact your local distributor.
LIMITED WARRANTY:
This product is supplied with a 1 Year warranty.
The Warranty excludes:
Products that have been misused, (including accidental damage) and damage caused
by normal wear and tear. In the unlikely event that you encounter a problem with this
product, it should be returned to the place of purchase.
Model: XPD700W-2
Picture Type: Day/Night (B/W & Colour)
Image Sensor: Sony 1/3” Ultra High Resoluon CCD
DSP: Xvision X7 DSP
Resoluon: 700 TVL
Lens Viewing Angle: 23 to 92°
Infra Red Night Vision: No
Minimum Illuminaon: 0.0003 Lux
Audio: No
Operang Voltage: 12V DC 120mA
Suggested Power Supply: 12V DC 300mA
Mounng: Wall/Ceiling
Weatherproofing: No
Dimensions (WxH): 127 x 95 mm
Weight: 0.24 Kg
