Freedom SW-RVC Inverter/Charger
Installation Guide
Product ModelNumber
815-3012-02

2 Freedom SW-RVC Installation Guide
Copyright © 2022 Xantrex LLC. All Rights Reserved. All trademarks are owned by Xantrex LLC and its affiliates.
Exclusion for Documentation
UNLESS SPECIFICALLY AGREED TO IN WRITING, SELLER
(A) MAKES NO WARRANTY AS TO THE ACCURACY, SUFFICIENCY OR SUITABILITY OF ANY TECHNICAL OR OTHER INFORMATION PROVIDED IN ITS MANUALS OR OTHER DOCUMENTATION;
(B) ASSUMES NO RESPONSIBILITY OR LIABILITY FOR LOSSES, DAMAGES, COSTS OR EXPENSES, WHETHER SPECIAL, DIRECT, INDIRECT, CONSEQUENTIAL OR INCIDENTAL, WHICH MIGHT ARISE OUT OF
THE USE OF SUCH INFORMATION. THE USE OF ANY SUCH INFORMATION WILL BE ENTIRELY AT THE USER’S RISK; AND
(C) REMINDS YOU THAT IF THIS MANUAL IS IN ANY LANGUAGE OTHER THAN ENGLISH, ALTHOUGH STEPS HAVE BEEN TAKEN TO MAINTAIN THE ACCURACY OF THE TRANSLATION, THE ACCURACY
CANNOT BE GUARANTEED. APPROVED CONTENT IS CONTAINED WITH THE ENGLISH LANGUAGE VERSION WHICH IS POSTED AT http://www.xantrex.com/.
NOTE:Visit http://www.xantrex.com/ , click Products, select a Product category, select a Product, and search the Product Documents panel for a translation of the English guide, if available.
Document Number:975-1057-01-01 Rev A Date: March 2022
Product Name and Part Number
Freedom SW-RVC (815-3012-02)
Contact Information
Telephone: (Toll Free USA/Canada) [phone] / (Outside USA/Canada) [phone]
Email: [e-mail],
http://www.xantrex.com/power-products-support/
Web: http://www.xantrex.com/
Information About Your System
As soon as you open your product, record the following information and be sure to keep your proof of purchase.
Serial Number ____________________________
Product Number ____________________________
Purchased From ____________________________
Purchase Date ____________________________
To view, download, or print the latest revision, visit the website shown under Contact Information.

ABOUT THIS GUIDE
Purpose
The purpose of this Installation Guide is to provide explanations
and procedures for installing and configuring a Freedom SW-RVC
Inverter/Charger for recreational vehicle and commercial
applications.
Scope
The guide provides safety guidelines as well as information about
troubleshooting the installation the inverter/charger. It does not
provide details about particular brands of batteries. You need to
consult individual battery manufacturers for this information.
Audience
The guide is intended for qualified personnel of the Freedom SW-
RVC Inverter/Charger.
This guide is intended for qualified personnel. Qualified personnel
have training, knowledge, and experience in:
lInstalling electrical equipment and power systems (up to
1000 volts).
lApplying all applicable installation codes.
lAnalyzing and reducing the hazards involved in performing
electrical work.
lSelecting and using Personal Protective Equipment (PPE)
and following safety work code practices. See NFPA 70E or
CSA Z462.
Related Information
You can find more information about Xantrex products and
services at http://www.xantrex.com/.
975-1057-01-01 3

4 975-1057-01-01
IMPORTANT SAFETY INSTRUCTIONS
READANDSAVETHISGUIDE FORFUTUREREFERENCE.
This chapter contains important safety instructions for the
Freedom SW Inverter/Charger (Freedom SW-RVC). Each time,
before using the Freedom SW-RVC, READ ALL instructions and
cautionary markings on or provided with the inverter/charger, the
batteries, and all appropriate sections of this guide.
NOTE: The Freedom SW-RVC contains no user-serviceable
parts.
The following special messages may appear throughout this
bulletin or on the equipment to warn of potential hazards or to call
attention to information that clarifies or simplifies a procedure.
The addition of either symbol to a “Danger” or
“Warning” safety label indicates that an electrical
hazard exists which will result in personal injury if the
instructions are not followed.
This is the safety alert symbol. It is used to alert you to
potential personal injury hazards. Obey all safety
messages that follow this symbol to avoid possible
injury or death.
DANGER
DANGER indicates a hazardous situation which, if not avoided, will result in
death or serious injury.
WARNING
WARNING indicates a hazardous situation which, if not avoided, could result
in death or serious injury.
CAUTION
CAUTION indicates a hazardous situation which, if not avoided, could result
in minor or moderate injury.
NOTICE
NOTICE is used to address practices not related to physical injury.
IMPORTANT:These notes describe things which are important for you to know,
however, they are not as serious as a caution or warning.
Please Note: No responsibility is assumed by Xantrex for any consequences
arising out of the use of this material.

Safety Information
975-1057-01-01 5
Safety Information
1. Before using the inverter/charger, read all instructions and
cautionary markings on the unit, the batteries, and all
appropriate sections of this guide.
2. Use of accessories not recommended or sold by the
manufacturer may result in a risk of fire, electric shock, or injury
to persons.
3. The inverter/charger is designed to be connected to both DC
and AC electrical systems. The manufacturer recommends that
all wiring be done by a certified technician or electrician to
ensure adherence to the local and national electrical codes
applicable in your jurisdiction.
4. To avoid a risk of fire and electric shock, make sure that
existing wiring is in good condition and that wire is not
undersized. Do not operate the inverter/charger with damaged
or substandard wiring.
5. Do not operate the inverter/charger if it has been damaged in
any way.
6. This unit does not have any user -serviceable parts. Do not
disassemble the inverter/charger except where noted for
connecting wiring and cabling. See your warranty for
instructions on obtaining service. Attempting to service the unit
yourself may result in a risk of electrical shock or fire. Internal
capacitors remain charged after all power is disconnected.
7. To reduce the risk of electrical shock, disconnect both AC and
DC power to or from the inverter/charger before attempting any
maintenance or cleaning or working on any components
connected to the inverter/charger. Do not disconnect under
load. Turning the inverter/charger to Standby using the Power
button on the panel will not reduce an electrical shock hazard.
8. The inverter/charger must be provided with an equipment-
ground.
9. Do not expose this unit to rain, snow, or liquids of any type.
This product is designed for dry-locations-use only. Damp
environments will significantly shorten the life of this product
and corrosion caused by dampness will not be covered by the
product warranty.
10. To reduce the chance of short-circuits, always use insulated
tools when installing or working with this equipment.
11. Remove personal metal items such as rings, bracelets,
necklaces, and watches when working with electrical
equipment.

Safety Information
6 Freedom SW-RVC Installation Guide
DANGER
ELECTRIC SHOCK HAZARD
• Do not expose the Freedom SW-RVC to rain, snow, or spray water.
• Do not operate the inverter/charger if it has received a sharp blow, been
dropped, has cracks or openings in the enclosure including if the AC terminal
cover has been lost, damaged, or will not close, or otherwise damaged in any
other way.
• Do not disassemble the inverter/charger. Internal capacitors remain charged
after all power is disconnected.
• Disconnect both AC and DC power from the inverter/charger before
attempting any maintenance or cleaning or working on any circuits connected
to the inverter/charger. The INVERTER ENABLE button on the front panel
does not function like a power switch that energizes or de-energizes the unit
arbitrarily. When AC and DC power sources are connected and present, the
unit is always energized.
• Do not operate the inverter/charger with damaged or substandard wiring.
Make sure that all wiring is in good condition and is not undersized.
Failure to follow these instructions will result in death or serious
injury.
NOTE: Turning the inverter/charger to Standby mode using the
INVERTER ENABLE button on the front panel will not reduce an
electrical shock hazard.
DANGER
FIRE AND BURN HAZARD
•Do not cover or obstruct the air intake vent openings and/or install in a zero-
clearance compartment.
•Do not use transformerless battery chargers in conjunction with the
inverter/charger due to overheating.
Failure to follow these instructions will result in death or serious
injury.

Precautions When Working With Batteries
975-1057-01-01 7
DANGER
EXPLOSION HAZARD
•Charge only properly rated (such as 12 V) lead-acid (GEL, AGM, Flooded, or
lead-calcium) rechargeable batteries because other battery types may
explode.
•Do not work in the vicinity of lead-acid batteries. Batteries generate explosive
gases during normal operation. See note #1.
•Do not install and/or operate in compartments containing flammable materials
or in locations that require ignition-protected equipment. See notes #2 and #3.
•When using Lithium-Ion batteries, ensure that the battery pack being used
includes a certified Battery Management System (BMS) with safety controls.
Failure to follow these instructions will result in death or serious
injury.
NOTES:
1. Follow these instructions and those published by the battery
manufacturer and the manufacturer of any equipment you
intend to use in the vicinity of the battery. Review cautionary
markings on these products and on the engine.
2. This inverter/charger contains components which tend to
produce arcs or sparks.
3. Locations include any space containing gasoline-powered
machinery, fuel tanks, as well as joints, fittings, or other
connections between components of the fuel system.
Precautions When Working With
Batteries
IMPORTANT: Battery work and maintenance must be done by
qualified personnel knowledgeable about batteries to ensure
compliance with battery handling and maintenance safety
precautions.
WARNING
BURN FROM HIGH SHORT-CIRCUIT CURRENT, FIRE
AND EXPLOSION FROM VENTED GASES HAZARDS
•Always wear proper, non-absorbent gloves, complete eye protection, and
clothing protection. Avoid touching your eyes and wiping your forehead while
working near batteries. See note #4.
•Remove all personal metal items, like rings, bracelets, and watches when
working with batteries. See notes #5 and #6 below.
•Never smoke or allow a spark or flame near the engine or batteries.
•Never charge a frozen battery.
Failure to follow these instructions can result in death, serious
injury, or equipment damage.

Precautions When Preparing to Charge
8 Freedom SW-RVC Installation Guide
NOTES:
1. Mount and place the Freedom SW-RVC Inverter/Charger unit
away from batteries in a well ventilated compartment.
2. Always have someone within range of your voice or close
enough to come to your aid when you work near a lead-acid
battery.
3. Always have plenty of fresh water and soap nearby in case
battery acid contacts skin, clothing, or eyes.
4. Keep battery terminals clean from corrosion. If battery acid or
corrosion deposit contacts skin or clothing, wash immediately
with soap and water. If battery acid or corrosion deposit enters
your eye, immediately flood it with running cold water for at
least twenty minutes and have someone within range of your
voice or close enough to get medical attention immediately.
5. Use extra caution to reduce the risk of dropping a metal tool on
the battery. It could spark or short circuit the battery or other
electrical parts and could cause an explosion. Use tools with
insulated handles only.
6. Batteries can produce a short circuit current high enough to
weld a ring or metal bracelet or the like to the battery terminal,
causing a severe burn.
7. When removing a battery, always remove the negative
terminal from the battery first for systems with grounded
negative. If it is grounded positive, remove the positive terminal
first. Make sure all loads connected to the battery and all
accessories are off so you don’t cause an arc.
Precautions When Preparing to
Charge
WARNING
EXPOSURE TO CHEMICALS AND GASES HAZARD
•Make sure the area around the battery is well ventilated.
•Make sure the voltage of the batteries matches the output voltage of the
inverter/charger.
•Be careful to keep corrosion from coming into contact with your eyes and skin
when cleaning battery terminals.
Failure to follow these instructions can result in death or serious
injury.
NOTES:
nStudy and follow all of the battery manufacturer's specific
precautions, such as removing or not removing cell caps while
charging, whether equalization is acceptable for your battery,
and recommended rates of charge.
nFor flooded non-sealed batteries, add distilled water in each
cell until battery acid reaches the level specified by the battery
manufacturer. This helps to purge excessive gas from cells. Do
not overfill. For a battery without removable cell caps, carefully
follow manufacturer's instructions.

Precautions When Placing the Unit
975-1057-01-01 9
Precautions When Placing the
Unit
NOTICE
RISK OF INVERTER/CHARGER DAMAGE
•Never allow battery acid to drip on the inverter/charger when reading specific
gravity, or filling battery.
•Never place the Freedom SW-RVC unit directly above batteries; gases from a
battery will corrode and damage the inverter/charger.
•Do not place a battery on top of the inverter/charger.
Failure to follow these instructions can result in equipment
damage.
Regulatory
The Freedom SW-RVC is certified to appropriate US and Canadian
standards. For more information see Specifications on page 72.
The Freedom SW-RVC is intended to be used for recreational
vehicle and commercial applications.
It is not intended for other applications as it may not comply with the
additional safety code requirements needed for those other
applications. See “Limitations On Use” below.
WARNING
LIMITATIONS ON USE
Do not use in connection with life support or vital systems.
Failure to follow these instructions can result in death or serious
injury.

EMI Information to the User
10 Freedom SW-RVC Installation Guide
EMI Information to the User
This equipment has been tested and found to comply with the limits
for a Class B digital device, pursuant to part 15 of the FCC and ISED
CAN ICES-003 Rules. These limits are designed to provide
reasonable protection against harmful interference in a residential
environment. This equipment generates, uses, and can radiate radio
frequency energy and, if not installed and used in accordance with
the instructions, may cause harmful interference to radio
communications.
However, there is no guarantee that interference will not occur in a
particular environment. If this equipment does cause harmful
interference to radio or television reception, which can be
determined by turning the equipment off and on, the user is
encouraged to try to correct the interference by one or more of the
following measures:
nReorient or relocate the receiving antenna.
nIncrease the separation between the equipment and receiver.
nConnect the equipment into an outlet on a circuit different from
that to which the receiver is connected.
nConsult the dealer or an experienced radio/TV technician for
help.
CAUTION
Unauthorized changes or modifications to the equipment could void the user’s
authority to operate the equipment.
End of Life Disposal
The Freedom SW-RVC Inverter/Charger is designed with
environmental awareness and sustainability in mind. At the end of its
useful life, the Freedom SW-RVC can be decommissioned and
disassembled. Components which can be recycled must be recycled
and those that cannot be recycled must be disposed of according to
local, regional, or national environmental regulations.
Many of the electrical components used in the Freedom SW-RVC
Inverter/Charger are made of recyclable material like steel, copper,
aluminum, and other alloys. These materials can be auctioned off to
traditional scrap metal recycling companies who resell reusable
scraps.
Electronic equipment such as the circuit boards, connectors, and
fuses can be broken down and recycled by specialized recycling
companies whose goal is to avoid having these components end up
in the landfill.
For more information on disposal, contact Xantrex.

CONTENTS
Important Safety Instructions 4
Safety Information 5
Precautions When Working With Batteries 7
Precautions When Preparing to Charge 8
Precautions When Placing the Unit 9
Regulatory 9
EMI Information to the User 10
End of Life Disposal 10
Introduction 14
Materials List 14
Installation 16
Before You Begin the Installation 17
Installation Codes 17
Basic Installation Procedures 18
Planning the Installation 19
Step 1: Choosing a Location for the Unit 30
Step 2: Mounting the Unit 32
Step 3: Connecting the AC Input and AC Output Wires 36
Step 4: Connecting the DC Cables 40
Step 5: Connecting the Battery Temperature Sensor
(BTS) 45
Step 6: Connecting to the Network 49
Step 7: Performing Checks Prior to Initial Start-Up 50
Step 8: Testing Your Installation 51
Stacking Features 53
Parallel Stacking 53
Series Stacking 55
Stacking Cable 56
Series Stacking Operation 57
DC Connections for Stacked Inverters 57
Neutral Wiring for Stacked Inverters 58
Configuring System for Stacked Operation 59
Load Sense in Series Stacking 60
Load Sense Operation in Parallel Stacking 60
Disabling Load Sense on the Primary Unit 61
975-1057-01-01 xi

xii Freedom SW-RVC Installation Guide
Setting Load Sense on the Secondary Unit 61
Wiring Schematic 62
Charger Settings in Stacked Configuration 62
Calculations 63
Examples 64
Battery Information 66
Battery Capacity 66
About Amp-hours 66
Estimating Battery Requirements 67
Calculating Battery Size 67
Battery Banks 68
Battery Bank Sizing Worksheet 69
Restrictions on Motor Size 69
Battery Cabling and Connections 70
Battery Parallel Connection 70
Battery Series Connection 71
Battery Series-Parallel Connections 71
Specifications 72

1 INTRODUCTION
Congratulations on your purchase of the Freedom SW-RVC
Inverter/Charger (Freedom SW-RVC). The Freedom SW-RVC
has been designed to give you premium power, ease of use, and
outstanding reliability.
Please read this chapter to familiarize yourself with the
components of the Freedom SW-RVC.
Materials List
The Freedom SW-RVC ships with the following items:
1 2
3 4
5
6
FREEDOM SW 3012
FREEDOMSW 3012
Inverter
Reset Enable Inverter AC/
On Charge Fault
Figure 1 What’s In The Box
1 one Freedom SW-RVC unit
2 Installation Guide
3 two RV-C network terminators
4 one Battery Temperature Sensor (BTS)
5two sets of 5/16”-18 nuts and washers for
the DC terminals
6
DC terminal covers (one red, one black)
with
two sets of #6-32 screws
NOTE: If any of the items are missing, contact customer service
or any authorized Xantrex dealer for replacement. See ABOUT
THIS GUIDE on page 3.
IMPORTANT: Keep the carton and packing material in case you
need to return the Freedom SW-RVC for servicing.
975-1057-01-01 14

This page is intentionally left blank. [2]

2 INSTALLATION
This section provides sample installation information as a guide
for your installation. For your convenience, the overall procedure
is divided into these main steps:
Before You Begin the Installation 17
Installation Codes 17
Basic Installation Procedures 18
975-1057-01-01 16

Before You Begin the Installation
17 Freedom SW-RVC Installation Guide
Before You Begin the
Installation
Before beginning your installation:
nRead this entire Installation guide so you can plan the
installation from beginning to end.
nAssemble all the tools and materials you require for the
installation.
nReview the Safety Information on page 1.
nBe aware of all safety and electrical codes which must be
met.
WARNING
ELECTRICAL SHOCK AND FIRE HAZARD
nAll wiring shall be done by qualified personnel to ensure
compliance with all applicable installation codes and
regulations.
nDo not connect to AC and DC power sources during
installation. Disconnect from all power sources when
servicing.
nDisable and secure all AC and DC disconnect devices and
automatic generator starting devices.
Failure to follow these instructions can result in death, serious
injury, or equipment damage
Installation Codes
Governing installation codes vary depending on the specific
location and application of the installation. Some examples
include the following:
nThe U.S. National Electrical Code (NEC)
nThe U.S. Code of Federal Regulations (CFR)
nThe Canadian Electrical Code (CEC)
nCanadian Standards Association/CSA Group (CSA) and the
RV Industry Association (RVIA) standards and codes for
installations in RVs
NOTE:It is the installer’s responsibility to ensure that all
applicable installation requirements are met.

Basic Installation Procedures
975-1057-01-01 18
Basic Installation Procedures
This section provides sample installation information as a guide
for your installation. For your convenience, the overall procedure
is divided into these main steps:
Planning the Installation 19
Step 1: Choosing a Location for the Unit 30
Step 2: Mounting the Unit 32
Step 3: Connecting the AC Input and AC Output Wires 36
Step 4: Connecting the DC Cables 40
Step 5: Connecting the Battery Temperature Sensor (BTS) 45
Step 6: Connecting to the Network 49
Step 7: Performing Checks Prior to Initial Start-Up 50
Step 8: Testing Your Installation 51

Basic Installation Procedures
19 Freedom SW-RVC Installation Guide
Planning the Installation
This section provides information to help you plan for a basic
installation of the Freedom SW-RVC.
As your system configuration is determined, record the details in
Information About Your System on page 2 in this guide.
Two Key Performance Factors
Two key factors in particular will have a major impact on system
performance.
Size and Length of DC Cables
To select the appropriate size and length of DC cables, see DC
Components on page 26.
The DC cables should be as short as possible and large enough to
handle the required current, in accordance with the electrical
codes or regulations applicable to your installation. If there are
long battery cables which are in excess of 10 feet (3.1m) each
and not of sufficient size, the voltage drop across the cables will
have a negative impact on overall system performance.
Mounting Location of the Freedom SW-RVC
To choose an appropriate location for mounting the
inverter/charger, see Step 1: Choosing a Location for the Unit on
page 30.
Planning Preparations
AC, DC, and Network Components
For a successful installation, you need to plan for AC, DC, and
network components of the power system. The AC and DC
components are described in this section.
AC components include:
nAC Input for Dual AC Line
nAC Input for Single AC Line
nAC Loads
nAC Disconnect and Over-Current Protection Device
nDistribution Panels
nAC Wiring
nAC Output Neutral Bonding
DC components include:
nBatteries
nDC Cabling
nDC Disconnects and Over-Current Devices
nDC Grounding
Network considerations include:
Detailed information on planning and installing your network is
available in the installation guide. Refer to the guide to determine
the type of network layout to install, as well as guidelines for
installing the network. This guide is available for download at
www.xantrex.com.

Basic Installation Procedures
975-1057-01-01 20
Figure 2 Typical Network
network terminator
network terminator
Freedom SW Inverter/Charger
FREEDOM SW 3012
FREEDOMSW 3012
Inverter
Reset Enable Inverter AC/
On ChargeFault
Shore
Power
AC Panel
BATTERY
Inverter
Load Panel
RV-C Device
AC Components
The Freedom SW-RVC has the capability of supporting several
AC shore power configurations. Single-line input and dual-line
input configurations. They are described as follows:
AC Input
for Single
AC Line
AC input to a single AC line can be supplied from a
single-phase 120 volt 60 Hz AC source such as the
utility grid (power company), a generator, or the
output of a transfer switch.
AC Input
for Dual AC
Lines
AC inputs to a dual AC lines can be supplied from a
split-phase or dual-input AC source such as the
utility grid (power company), a generator, or the
output of a transfer switch. The Freedom SW-RVC
can be operated from the following types of 120
volt 60 Hz AC sources:
nSplit
phase: This source type has two lines, one neutral, and
one ground. The two 120 volts AC lines are 180
degrees out of phase with each other, so that the
two voltages total to 240 volts AC line to line. The
voltage between each line and neutral is still 120
volts AC, and the voltage between the neutral and
ground is approximately zero.
Because the two lines are out of phase, the
currents from each line subtract in the neutral, and
the neutral current will be approximately zero if the
loads are equal. For example, if Line 1 is supplying
20 amps and Line 2 is supplying 15 amps, the
current in the neutral will be 5 amps.

Basic Installation Procedures
21 Freedom SW-RVC Installation Guide
nDual
input: This source type has two line inputs, one neutral,
and one ground. Unlike the split-phase type, the
two lines are in phase (not out of phase), and must
come from the same source. The voltage between
the two lines is zero. The voltage between each
line and the neutral is 120 volts AC, and the voltage
between the neutral and ground is approximately
zero.
Because the two lines are in phase, the currents
from each line add together in the neutral. For
example, if Line 1 is supplying 20 amps and Line 2
is supplying 15 amps, the current in the neutral will
be 35 amps.
AC Output The output voltage on Freedom SW-RVC
inverter/chargers is 120Vac. Both configurations
are supported - Single Input and Single Output line
(SI-SO) configuration and Dual Input and Dual
Output lines (DI-DO) configuration.
AC Loads The Freedom SW-RVC is intended to power loads
consisting of 120 volts AC appliances.
In Invert mode, the Freedom SW-RVC connects
L1 and L2 output lines together to provide 120 volts
AC to loads on either line. In AC Bypass mode, the
source connected to the AC input is passed
through to the load. Because of the way invert
mode operates, only 120 volts AC appliances can
be connected to the Freedom SW-RVC output.
AC
Disconnect
and Over-
Current
Protection
Device
To meet CSA, UL, and electrical code
requirements, and to protect system wiring, the AC
inputs and outputs of the inverter/charger must be
provided with overcurrent protection on both the
AC input and output. This protection may be a
circuit breaker or a fuse with a disconnect device
(for simplicity the following refers to breakers).
Refer to your applicable installation codes and the
following requirements:
AC Input
Protection
The breakers protecting the AC input of the
Freedom SW-RVC must be approved for use on
120 volts AC branch circuits, and must be located
in each Line. The breakers must be rated as shown
below:
