Xantrex GRIB and Ethernet interface User manual

GPIB and Ethernet
Interface for
XG Series
Programmable DC
Power Supplies
Operating Manual
GPIB
ENET
www.programmablepower.com

XG 850 Watt Series
Programmable DC Power
Supply
Operating Manual

M370078-01 ii
About Xantrex
Xantrex Technology Inc. is a world-leading supplier of advanced power electronics and controls with
products from small mobile units to utility-scale systems for wind, solar, batteries, fuel cells,
microturbines, and backup power applications in both grid-connected and stand-alone systems. Xantrex
products include inverters, battery chargers, programmable power supplies, and variable speed drives
that convert, supply, control, clean, and distribute electrical power.
Trademarks
XG 850 Watt Series Programmable DC Power Supply is a trademark of Xantrex International. Xantrex
is a registered trademark of Xantrex International.
Other trademarks, registered trademarks, and product names are the property of their respective owners
and are used herein for identification purposes only.
Notice of Copyright
XG 850 Watt Series Programmable DC Power Supply Operating Manual© November 2007 Xantrex
International. All rights reserved.
Exclusion for Documentation
UNLESS SPECIFICALLY AGREED TO IN WRITING, XANTREX TECHNOLOGY INC.
(“XANTREX”)
(A) MAKES NO WARRANTY AS TO THE ACCURACY, SUFFICIENCY OR SUITABILITY OF
ANY TECHNICAL OR OTHER INFORMATION PROVIDED IN ITS MANUALS OR OTHER
DOCUMENTATION.
(B) ASSUMES NO RESPONSIBILITY OR LIABILITY FOR LOSSES, DAMAGES, COSTS OR
EXPENSES, WHETHER SPECIAL, DIRECT, INDIRECT, CONSEQUENTIAL OR INCIDENTAL,
WHICH MIGHT ARISE OUT OF THE USE OF SUCH INFORMATION. THE USE OF ANY SUCH
INFORMATION WILL BE ENTIRELY AT THE USER’S RISK; AND
(C) REMINDS YOU THAT IF THIS MANUAL IS IN ANY LANGUAGE OTHER THAN
ENGLISH, ALTHOUGH STEPS HAVE BEEN TAKEN TO MAINTAIN THE ACCURACY OF THE
TRANSLATION, THE ACCURACY CANNOT BE GUARANTEED. APPROVED XANTREX
CONTENT IS CONTAINED WITH THE ENGLISH LANGUAGE VERSION WHICH IS POSTED
AT WWW.PROGRAMMABLEPOWER.COM.
Date and Revision
November 2007 Revision A
Part Number
M370078-01

M370078-01 iii
Product Numbers (FGAs)
Part Numbers for Rack Mount Kits
Contact Information
XG6-110 XG60-14
XG8-100 XG80-10.5
XG12-70 XG100-8.5
XG20-42 XG150-5.6
XG33-25 XG300-2.8
XG40-21 XG600-1.4
Rack Mount Kit Part Number
Dual XG 850 Watt RM-D-XG1
Single XG 850 Watt RM-S-XG1
Rack mount rails for
XG Series
RM-XG
Telephone: [phone] (toll free North America)
1 858 450 0085(direct)
Fax: [phone]
Email: [e-mail]
[e-mail]
Web: www.programmablepower.com

M370078-06 v
About This Manual
Purpose
This Operating Manual provides explanations and procedures for
programming the XG 850 Watt Series Programmable DC Power Supply
from the GPIB interface and connecting and configuring the power supply
to the Ethernet.
Scope
The Manual covers the GPIB and Ethernet interface options only. Refer to
the XG 850 Watt Series Programmable DC Power Supply Operating
Manual (Part number: M370078-01) for installation, operating procedures,
setup, calibration and troubleshooting for your power supply.
Audience
The Manual is intended for the user who is familiar with electronic power
supplies, Constant Current and Constant Voltage operating modes and the
control of output power. The user should be familiar with practicing safe
techniques while making supply or pin connections. The user should also
have experience with network-based communications software and
protocols.
Organization
This Manual is organized into two chapters, two appendices, and provides
Warranty and Product information.
Chapter 1, “GPIB” provides information and procedures on programming
the XG 850 Watt Series Programmable DC Power Supply from the GPIB
(General Purpose Interface Bus) interface.
Chapter 2, “Ethernet (ENET)” provides information and procedures to
connect and configure the power supply to the ENET.
Appendix A, “Troubleshooting” provides troubleshooting information for
the combined ENET and RS-485 communication and for ENET
communication.
Appendix B, “Links” provides the Web site links for relevant third party
vendors.

About This Manual
vi M370078-06
Conventions Used
The following conventions are used in this Manual.
Related Information
For related materials on this product, see also:
•XG 850 Watt Series Programmable DC Power Supply Operating
Manual (Part number: M370078-01).
•XG 850 Watt Series Programmable DC Power Supply Rack Mount
Kit Options (Part number: M370078-05).
•XG 850 Watt Series Programmable DC Power Supply: Quick
Reference Guide (Part number: M370078-04). This document is
included with your power supply and provides a quick start on using
the front panel interface.
More information about Xantrex Technology Inc. as well as its products
and services is available at www.programmablepower.com.
WARNING
Warnings identify conditions or practices that could result in personal injury or
loss of life.
CAUTION
Cautions identify conditions or practices that could result in damage to the unit or
other equipment.
Important: Important notes provide information that is important for you to
know. They are not as serious as Cautions or Warnings.

M370078-06 vii
Important Safety Instructions
WARNING: High Energy and High Voltage
Exercise caution when using a power supply. High energy levels can be stored at
the output voltage terminals on a power supply in normal operation. In addition,
potentially lethal voltages exist in the power circuit and on the output and sense
connectors of a power supply with a rated output greater than 40 V. Filter
capacitors store potentially dangerous energy for some time after power is
removed.
WARNING
Operate the power supply in an environment free of flammable gases or fumes.
To ensure that the power supply's safety features are not compromised, use the
power supply as specified in this manual and do not substitute parts or make any
unauthorized modifications. If service is necessary, please return the power
supply to the factory Authorized Service Center. See “Return Material
Authorization Policy” on page WA–3.
WARNING: Limitations on use
The XG 850W GPIB and Ethernet Interface Option is not intended for use in
connection with life support systems or other medical equipment or device.
