XD COLLECTION XD P329.12X User manual

TWS earbuds in
wireless charging case
Copyright© XD P329.12X

Content
English p. 3
Deutsch p. 9
Español p. 15
Français p. 12
Italiano p. 21
Svenska p. 18
Nederlands p. 6
Polski p. 24

ENGLISH
PARING FOR DOUBLE EARBUD CONNECTION
Press the on/o button on both earbuds to turn them on. Once the indicator on the earphones start
flashing red and blue, they are ready to pair. Turn on Bluetooth on your device and select “TWS
earbuds in case’’ to connect the earbuds to your device. After the first connection, the earbuds will
connect automatically when they are removed from the case.
HOW TO CHARGE THE EARBUDS
• Put the earbuds in the charging case
• Press the power button on the charging case
• The light on the charging case will turn on and starts charging the earbuds.
It takes around 2 hours to fully charge the earbuds
To charge the charging chase, connect the with the USB cable to a power source.
It takes around 2 hours to fully charge the charging case.
Congratulations on your TWS earbuds in charging case.
These BT earbuds allows you to enjoy your music without wires and charge your case and mobile
device.
Please read this manual before use.
DEVICE LAYOUT:
1- Charging case
2- Micro USB
3- On/O button
4- Battery/ Charging indicator
5- Earbuds
4. 1.
2.
3. 5.

FUNCTIONS
• To pick up a phone call short press the power button on one of the earbuds. To redial the last
dialled number double press the power button on one of the earbuds.
• While playing music, you can pause the song with shirt pressing the power button on one of the
earbuds. To go to the next song, press the power button for 2 seconds.
• To turn o the earbuds, press the power button for 5 seconds. The LED light on the earbuds will
flash red light and then the earbud turns o.
SPECIFICATIONS:
Continuous playing time 2-3 hours
Charging time 2 hours
Battery capacity Earbuds : 50 mAh
Battery capacity Charging station 350 mAh
Mic function : yes
Pick up function : yes
BT version : 5.0
CHARGING CASE VIA MICRO USB
1. If the red LED is always on, that means the charging is unfinished
2. If the red LED is o, that means the charging is completed.
CHARGING CASE VIA WIRELESS CHARGING PAD
1. If the red LED is always on, that means the charging is unfinished
2. If the red LED is o, that means the charging is completed.

MAINTENANCE WIRELESS EARBUDS
1. Do not use abrasive cleaning solvents to clean the device
2. Do not allow the device to touch with any sharp objects, as this will cause scratching and damage.
3. Please keep the device away from high-temperature, dust and
humidity.
USING THE WIRELESS CHARGER:
• Connect the wireless charger the micro USB cable to the wireless
charging pad, connect the USB to the USB port of your PC/laptop
or charger.
• Make sure your phone is compatible for wireless charging
• Put your wireless charging enabled device on the wireless charging
surface.
NOTES:
• Some phone cases may block the wireless charging
• Do not place other materials, like metal objects, magnets, and
magnetic stripe cards, between the mobile device and the wireless charger pad.
• Check your mobile device’s battery percentage using the charging icon
displayed on the screen of your phone.
• When the mobile device is not placed on the charging surface
accurately, your mobile device may not charge properly.
• If you use the wireless charger in areas with weak network coverage,
you may lose your network reception.
• Please do not expose this device to moisture or heat sources
• This is not a toy, not suitable for children under the age of 7
