Xerox DocuPrint C621 User manual

Setup Guide
Please read this when setting
up the printer

TrueType fonts, AppleTalk, KanjiTalk, Macintosh, and EtherTalk are trademarks Apple Computer, Inc , registered in
the United States and other countries
NetWare is a registered trademark of Novell, Inc , in the United States and other countries
Microsoft, MS-DOS, Windows, and Windows NT are either registered trademarks or trademarks of
Microsoft Corporation in the United States and/or other countries
Permission has been obtained from Microsoft Corporation for use of software screen shots
This software is based in part on the work of the Independent JPEG Group
All product/brand names are trademarks or registered trademarks of the respective holders
Important
This manual is copyrighted with all rights reserved Under the copyright laws, this manual may not be copied,
in whole or part, without the written consent of the publisher
Parts of this manual are subject to change without prior notice
We welcome any comment on ambiguities, errors, omissions, or missing pages
Never attempt any procedure on the machine that is not specifically described in this manual Unauthorized
operation can cause faults or accidents Fuji Xerox is not liable for any problems resulting from unauthorized
operation of the equipment
Xerox is a registered trademark
The Document Company and Ethernet are trademarks and may be registered in certain jurisdictions

i
Preface
Thank you for choosing DocuPrint C621
This manual aims to provide all the information necessary for effectively operating the printer together
with notes on safety precautions To get the most out of your printer, read the manual carefully and
completely before using the machine Keep this manual handy for future reference This guide is written
with the assumption that you are familiar with the basics of your computer to be connected, the operating
system, and the respective application software You can also refer to their respective manuals for
information on basic knowledge and operation methods of the product
This equipment conforms to the guidelines of the Japan Business Machine Makers Association on the
harmonic effects by copiers and other reproduction devices These guidelines conform to the guides on
the harmonic suppressors of electronic appliances and general-purpose machines
In this manual, safety instructions are described with the symbol Always read and follow the
instructions before performing the required procedures
This equipment is certified as a Class 1 laser product under IEC825 (1984) This means that the machine
does not emit hazardous laser radiation Since radiation emitted inside the machine is completely confined
within the protective housings and external covers, the laser beam cannot escape from the machine
during any phase of user operation
This equipment is in the Class B category based on the standard of Voluntary Control Council for
Interference from Information Technology Equipment (VCCI)* If the machine is used near a radio or
television receiver in a domestic environment, it may cause radio interference Install and use the
machine according to the instructions
*This regulation applies only to Japan.
As a member of the International Energy Star Program, Fuji Xerox confirms that this
product satisfies the Japanese requirements for International Energy Star Program
standards

ii
Contents
Preface i
Contents ii
Types of Manuals iv
Using this Guide vi
Organisation of this Guide vi
Conventions vii
Printer Features viii
Operating Environment ix
Safety Notes xi
The Objective of the International Energy Star Program xx
Chapter 1 Setting up the Printer
1 1 Removing the Packing Tape and Spacers 2
1 1 1 Removing the Packing Tape from Various Locations 2
1 1 2 Removing the Spacers from Various Locations 4
1 2 Assembling the Optional Products (Part 1) 12
1 2 1 Connecting the Tray Module Connector 12
1 3 Assembling the Face-up Tray 14
1 4 Installing the Drum Cartridge 15
1 5 Installing the Toner Cartridges 18
1 6 Loading Paper 21
1 7 Assembling the Optional Products (Part 2) 24
1 7 1 Installing Additional Memory 24
1 8 Switching on the Power and Confirming the Operation 28
1 8 1 Connecting the Power Cord 28
1 8 2 Switching on the Power 29
1 8 3 Printing the Printer Settings List 30
1 8 4 Switching off the Power 33
Chapter 2 Connecting the Interface Cables
2 1 Connecting the Parallel Cable 36
2 2 Connecting the Ethernet Cable 38
Chapter 3 Network Settings (Quick Setup)
3 1 Network Environment and Printer Settings 42
3 2 Setting the IP Address (When Using TCP/IP Protocol) 43
3 3 Activating the Protocol 47
3 4 Checking the Settings 49

iii
Chapter 4 Configuring the Computer
4 1 After Setting up the Printer 52
4 1 1 Printer Drivers 52
4 1 2 Using TCP/IP Direct Print Utility 53
4 2 Installing the Printer Driver (Windows 95 or Windows 98) 54
4 3 Configuring the TCP/IP Direct Print Utility 61
4 3 1 Installing TCP/IP Direct Print Utility 61
4 3 2 Setting the Port 64
4 4 Installing the Printer Driver (Windows NT) 67
4 5 Installing the Printer Driver (Macintosh) 75
Appendix
A Control Panel Menu (Abstract) 80
B About the Software Pack CD-ROM 82
C When Using the Printer 84
D Glossary 85
Index 90

iv
Types of Manuals
The following manuals are bundled with DocuPrint C621 Please read the relevant manual to suit your
needs
Some of these manuals are in PDF file formats You will require Adobe® Acrobat® Reader to view or
print these manuals A copy of the Adobe Acrobat Reader can be found in the Software Pack CD-ROM
bundled with the printer You can use this CD-ROM to install the Acrobat Reader software on your
computer if necessary
Before Using the Printer
This booklet provides an overview of the items that come
with the printer It also provides a general description of
the procedures that guide you from opening the printer box
to getting your printer ready for printing
Firstly, use this manual to check the items bundled with the
printer Then, refer to the Setup Guide to set up the
printer
Setting up
Setup Guide (this manual)
This guide explains how to set up the printer and install the necessary
software There are also examples to illustrate how to use the printer as
a network printer
Software Pack Operation Guide
This guide explains how to use the DocuPrint C621 Software Pack CD-
ROM (referred to as Software Pack CD-ROM hereafter) on
Windows® 95, Windows® 98 and Windows NT®, and how to install the
various software available in the Software Pack Once you insert the
Software Pack CD-ROM in CD-ROM drive of your computer, the Fuji
Xerox Setup Menu will appear automatically Click on the desired button
to display this manual on the screen
Network Print Environment User Guide
This guide explains in detail the procedures to set up and use the printer
as a network printer in various networking environments This manual is
a PDF file and can be found in the Manual folder in the Software Pack
CD-ROM The name of this file is net pdf

v
User Guide
This guide describes the capabilities of DocuPrint C621 and
explains what to do when you encountered a problem It
explains the methods of operation as well as the solutions to
troubleshoot problems
After Setup

vi
Using this Guide
Organisation of this Guide
This manual consists of five chapters A brief introduction of each chapter is provided
below
Chapter 1 Setting up the Printer
This chapter explains how to look for a suitable installation environment, what to check for
the bundled products, and how to check that the printer has been properly set up
Chapter 2 Connecting the Interface Cables
This chapter explains how to connect the printer to the computer (when using it as a local
printer) and how to connect the printer to a network (when using it as a network printer)
Chapter 3 Network Settings (Quick Setup)
This chapter describes the procedures to define the network settings so that the printer can
be used in the TCP/IP, SMB (Windows network) or AppleTalk environment
Chapter 4 Configuring the Computer
This chapter explains how to install the necessary software to the computer so that the
printer can be used
Appendix
This section contains the following information:
•Control Panel Menu (Abstract)
Explains the the control panel schematically
•About the Software Pack CD-ROM
Explains the folder structure of the Software Pack CD-ROM bundled with the printer
•When Using the Printer
Explains information that you can refer to after the printer is installed
•Glossary

vii
Conventions
This manual uses the following conventions:
Notation
Explains points to pay attention to. Be sure to read it.
Gives supplementary information for reference.
Indicates where to find related information.
" " indicates that the source of reference is in this manual.
Italics indicates that the source of reference is in another manual.
Symbol
Symbol
Bold
" "
Initial caps
+
Meaning
Indicates selections or all kinds of buttons
Example: Click Next
Indicates input contents
Example: Enter "DocuPrint C621" in the text box
Indicates the names of the window, menu, dialog box, list box, combo
box
Example: The Add Port dialog box is displayed
Indicates that the key on the keyboard and the button on the control
panel should be pressed simultaneously
Example: Press the + buttons

viii
Printer Features
DocuPrint C621 has the following special features to satisfy a wide variety of printing requirements:
•High-quality, high-resolution and full-colour laser printing at 600 dpi
•As the wax toner is used, the uneven gloss normally found on colour prints are suppresed
Characters on printed copies are easy to read and uniform gloss can be achieved
•High speed printing at 26 sheets (A4 size) per minute for black and white jobs and 6 sheets (A4
size) per minute for colour jobs (when printing from the same document continously with A4 size
paper in portrait orientation)
•Printing on a range of sizes from postcard, A5-A3 size to paper measuring 328 x 453 mm in size
Moreover, normal paper, heavy weight paper, transparencies, labels and others can also be used
with the printer
•If the optional 2-tray module is installed, you can increase printing efficiency by using multiple
paper trays You can load up to 1400 sheets if the 2-tray module is installed
•If the optional hard disk is installed, you can use the electronic collation feature It is a feature that
allows you to import data into the hard disk so that any print job with more than one set can read
and print directly from the hard disk from the second set onwards You can output numerous sets
of documents such as reports or presentation materials at high speed
•If the optional duplex print module is installed, you can carry out duplex printing Even if the duplex
print module is not available, you can still print on side 2 (back) of the a sheet of paper as long as
side 1 (front) was pre-printed by DocuPrint C621 Printing on both sides will help to save paper

ix
Operating Environment
DocuPrint C621 can be used in a variety of office environments
Using As a Local Printer
In this manual, a local printer is one that is directly connected to the computer by using a
parallel cable
DocuPrint C621 can be connected to a computer with the following specifications:
Item
CPU
Model
Memory
Interface
Target Operating System
(OS)
Feature
i486SX or above
IBM PC-AT and compatible machine (DOS/V)
NEC company PC-98 series (on sale after Nov 1993)
16 MB or more
Parallel interface
Windows95
Windows 98
Windows NT 4 0

x
Using As a Network Printer
In this manual, a network printer is one that is connected to the network with an interface
cable
DocuPrint C621 can be connected to the following kinds of environment As a network
printer, print jobs can be sent from a client computer on the network
In addition, as the network card attached to the printer is loaded with HTTP server
feature, you can use the WWW browser on the network computer to check your network
settings or printer status
Item
Physical interface
Target OS
Network
Feature
10BASE-T
100BASE-TX
Windows 95
Windows 98
Windows NT 4 0
Macintosh Mac OS 7 6 1 or later (OpenTransport J1-1 1 2
or later)
TCP/IP (lpd)
In SMB (Windows network), TCP/IP is used in transport
protocol
In SMB (Windows network), NetBEUI is used in transport
protocol
IPX/SPX (NetWare 3 12J/3 2J/4 1J/4 11J/4 2J/5J)
AppleTalk (EtherTalk phase 2)

xi
Read the safety notes in this section carefully before you begin to use this machine to ensure that you
operate the copier properly
Do not place the machine in a hot, humid, dusty or poorly ventilated environment Prolonged
exposure can cause a fire or shock
Do not place the machine near heaters or volatile, flammable, or combustible materials such as
curtains that may catch fire
Place the machine on a level and sturdy surface If tilted, the machine can fall over and cause
injuries
Safety Notes
is used to alert operators to an operating procedure, practice, or condition
that, if not strictly observed, may result in severe injury or loss of life
is used to alert operator to an operating procedure, practice, or condition that,
if not strictly observed, might result in safety hazards to personnel or damage
to the equipment
This symbol is used to alert operators to a specific
operating procedure that requires close attention Read
and follow instructions carefully to ensure the task is
accomplished safely
This symbol is used to alert operators to a specific
operating procedure that must not be performed Read
and follow the instructions carefully
This symbol is used to alert operators to a specific
operating procedure that should be emphasised for
operating safety Read the instructions carefully before
performing the required procedure
This section describes the graphic symbols used throughout this guide
Heated Flammable Electric Pinched
surface shock fingers
Prohibited No fire Do not Do not
tear down touch
Instructions Unplug Ground/Earth
Precautions for Installation and Relocation

xii
The machine weighs 71 2 kg when the consumables and paper trays are fully assembled
When moving the printer, contact the transportation company and make sure that there are four or
more persons carrying it
When lifting the machine, face the front panel and firmly grip the recessed areas provided under
the front, rear and left sides of the machine Lfiting the machine by gripping any other areas can
cause to machine to fall and result in injuries
When lifting the machine, get a firm footing and bend your knees to avoid possible injuries to your
back
The machine has ventilation holes on the rear and side panels Ensure that the machine is installed
with a minimum clearance of 150 mm from the rear vent to the wall A poorly ventilated machine
can cause excessive internal heat and fire The accompanying diagram shows the minimum
clearances required for normal operation, consumable replacement, and maintenance to ensure
your machine operates at peak performance
When moving the machine, be sure to unplug the power cord from the outlet If the machine is
moved with the power cord connected, it can cause damage to the cord which could result in fire
or electric shocks
Lifting here may
damage the
machine
730 mm 780 mm
150mm
835 mm

xiii
When moving the machine, do not tilt it more than 10o (as indicated below) If tilted excessively, the
machine may fall over and cause injuries
After you have installed the optional 2-tray module, be sure to lock the caster stoppers at the base
of the tray module An unlocked machine may fall over or slide and cause injuries
•Operate the printer in a location that meets the following conditions:
Temperature range 5-32oC, relative humidity 15-85% (no condensation)
If operating the printer with a temperature of 32oC, the relative humidity should not exceed 48% If
the relative humidity reaches 85%, the temperature should not exceed 28oC
Do not place the printer in a room where there are sudden fluctuations in temperature
as condensation may occur within the printer and print quality will deteriorate.
•Do not place the printer in direct sunlight, as this may damage the machine
•Do not tilt the printer more than 5 mm front to back or more than 10 mm left to right, as the
consumables inside the printer may fall out and be damaged
•Before moving the printer, remove the drum cartridge and waste toner cartridge, as spilt toner
could damage the interior of the printer
•Do not place the printer directly next to an air conditioner or heater, as this affects the temperature
inside the machine, and could cause damage to the printer
The power specifications are listed below The specifications that apply to your machine depend on
your machine configuration Connect the power plug only to a properly rated power outlet
Otherwise, it can cause fire or electric shocks If in doubt, contact your Xerox Customer Support
Centre
•Rated voltage (100 V) • Rated voltage (110 V) • Rated voltage (220-240 V)
Rated frequency (50/60 Hz) Rated frequency (60 Hz) Rated frequency (50/60 Hz)
Never use multi-plug adaptors to plug multiple power plugs in the same outlet Be sure to operate
the machine on a sole-use receptable Multiple connectors can cause the outlet to overheat and
cause fire
Precautions for Power and Earth Connections
Other Precautions

xiv
Ensure that the plug connection is free of dust In a damp environment, a contaminated connector
can draw a non-negligible amount of current that can generate heat and eventually cause fire over
an extended period of time
Always use the power cord provided with your machine When an extension cord is required,
always use a properly rated cord
• In Japan: "125 V/15 A"
• In other countries: Contact your Xerox Customer Support Centre
If you use a cord with an unspecified current rating, the machine or plug may emit smoke or
become hot to the touch
Do not attempt to rework, pull, bend, chafe, or otherwise damage the power cord Do not place a
heavy object on the cord A damaged cord can cause fire or electric shocks
Never touch a power cord with wet hands Danger of electric shock exists
Stop operation immediately if your machine produces smoke, excessive heat, unusual noise, or
smell, or if water is spilt onto the machine Theses conditions can cause fire Immediately switch
off and unplug the machine, and contact your Xerox Customer Support Centre
To prevent fire or electric shocks, follow the instruction below based on your machine
configuration If in doubt, contact your Xerox Customer Support Centre
•If you machine is a 220-240 V model, there is no need to attach a separate earth line since the
earth connection is incorporated in the power line Plug it inot a properly rated outlet
•If your machine is a 100 V or 110 V model, use the green earth wire bundled with the power
cord, located at the rear of the machine
The earth wire must be connected to one of the following conductors:
- Earth terminal of the specified power outlet
- A piece of copper buried in the earth 650 mm or deeper
- Earth terminal with Class D* earthing
* Class D is the regulation for Japan only
Never connect the earth wire to any of the following:
•Gas pipe, which can be ignited and explode
•Telephone line earth wire or lightning rod, which can draw an excessive electric current if hit by
lightning
•Water faucet or pipe whose electrical conductivity is broken by a non-metal part
If the power cord is broken or insulated wires are exposed, ask your Xerox Customer Support
Centre for a replacement Using a damaged cord can cause fire or electric shocks

xv
Do not unplug or replug the machine while it is on Unplugging a live connector can deform the plug
and cause fire
When unplugging the machine, grasp the plug instead of the cord Forcibly pulling on a cord can
damage it and cause fire or electric shocks
Be sure to switch off and unplug the machine before accessing the interior of the machine for
cleaning, maintenance, or fault clearance Access to a live machine's interior can cause electric
shocks
Once a month, unplug the machine and check the power cord for the following:
•The power cord is plugged firmly into a receptacle
•The plug is not excessively heated, rusted, or bent
•The plug and receptacle are free of dust
•The cord is not cracked or frayed
If you notice any unusual conidtions, contact your Xerox Customer Support Centre
When the machine is not used over an extended period of time, switch it off and unplug it If an
unused machine is left connected to a power source for a long period, degraded insulation can
cause electric shocks, current leakages, or fire
Switch off the machine before connecting the interface cable and any optional product Connecting
the cable or optional product with a live machine can cause electric shocks
•Reception interference
When installed at a certain location, the machine may cause interference with radio and television
reception If you notice flickering, or distorted images or noises on your audio-visual units, your
machine may be causing radio interference Switch it off, and if the interference disappears, the
machine is the cause of radio interference Perform the following procedures until the interference
is corrected
•Move the machine and the TV and/or radio away from each other
•Reposition or re-orientate the machine and/or the TV and radio
•Unplug the machine, TV, and radio, and replug them into outlets that operate on different
circuits
•Re-orientate the TV and/or radio antennas and cables until the interference stops For an
outdoor antenna, you should ask your local electrician for support
•Use coaxial cable antennas
Other Precautions

xvi
Do not place any liquid container such as a vase or coffee cup on the machine Spilt water can
cause a fire or shock hazard
Do not place any metal parts such as staples or clips on the machine If metal and flammable parts
get into the machine, they can short-circuit internal components, and cause fire or electric shocks
If debris (metal or liquid) gets into the machine, switch off and unplug the machine Contact your
Xerox Customer Support Centre Operating a debris-contaminated machine can cause fire or
electric shocks
Never open or remove machine covers that are secured with screws unless specifically instructed
in this manual A high voltage component can cause electric shocks
Do not try to alter the machine configuration, or modify any parts An unauthorized modification
can cause smoke or fire
Never touch a labelled area found on or near the heat roller You can get burnt
If a sheet of paper is wrapped around the heat roller, do not try to remove it by yourself to avoid
injuries or burns Switch off the machine immediately, and contact your Xerox Customer Support
Centre
Operating Precautions

xvii
This equipment is certifed as a Class 1 laser product under IEC825 (1984) This means that the
machine does not emit hazardous laser radiation Since radiation emitted inside the machine is
completely confined within the protective housings and external covers, the laser beam cannot
escape from the machine during any phase of user operation Do not remove any covers except
those that have been specifically instructed in the manual This may result in unnecesary laser
radiation
Do not place any heavy object on the machine An off-balance machine can fall over or the heavy
object can fall, causing injuries
Do not use a highly flammable spray or solvent near the machine It can cause fire
When removing jammed paper, make sure that no pieces of torn paper are left in the machine A
piece of paper remaining in the machine can cause fire
If a sheet of paper is wrapped around the heat roller, or when clearing a jammed paper that is
difficult or impossible to see, do not try to remove it by yourself Doing so can cause injuries or
burns Switch off the machine immediately, and contact your Xerox Customer Support Centre
•Refer to this manual for procedures on clearing paper jams, and how to resolve other troubles that
may occur
Never throw a toner cartridge into an open flame Toner remaining in the cartridge can cause an
explosion and you can get burnt
Other Precautions
Notes on Handling Consumables

xviii
Never throw a waste toner cartridge into an open flame Toner in the cartridge can cause an
explosion and you can get burnt
Never throw a drum cartridge into an open flame Toner in the cartridge can cause an explosion
and you can get burnt
