XEROX FreeFlow
AccXES Firmware
10.3.3 b 106
(for HFT, PUN, CNG
Controllers)
June, 2006

Table of Contents
1Introduction 4
1.1 FEATURE KEYS: 4
1.1.1 Feature Key Descriptions 4
2Release Deliverables 6
2.1 Xerox 6030/6050 Wide Format Solution 6
2.2 Xerox 8850, 510dp Print Systems 6
2.3 Xerox Print System 721p 6
2.4 Xerox 8825, 8830 Print Systems 6
2.5 Xerox Print System X2 TECH 7
3Recommended Configurations 8
4Release Installation 9
5New Features of 10.3.3 b 106 10
5.1 Additional Postscript functionality 10
5.2 Postscript Interpretation level for PDF 10
5.3 Support for new IOT firmware releases 10
5.4 880mm paper support for 6030 and 6050 10
6New Features of 10.3.2 b 201 11
6.1 Title-block setting removed from Scanner UI menu (10.3.1) 11
6.2 Remote Media Mismatch for 6030/6050 (10.3.1) 11
710.0-10.2 Feature Enhancements 12
7.1 Turbo III speeds supported for Scan-To-Net 12
7.2 Check Plot checkbox 12
7.3 Copier Margin range increased to +/- 8 inches 12
7.4 Disk Logging setting added to WebPMT 12
7.5 Added support for 440, 620 and 880mm rolls for 6030/6050 printers 12
7.6 Support for 30 inch roll on 6030/6050 printer 13
7.7 Disk Image Overwrite 13
7.8 Scan to FTP 13
7.9 Maximum Copy Length 13
8Release Notes 14
8.1 Controller 14
8.1.1 Disk Image Overwrite 14
8.1.2 Firmware Installation of a Device Failed 19
8.1.3 Blank Pages after Firmware Installation 19
8.1.4 Stamp does not appear 19
8.1.5 Scaling interaction with “ANY” 19
8.1.6 Margins may cause image clipping 19
8.1.7 CGM Files and folding 19
8.1.8 Image wrap on 721 printer 19
8.2 Xerox 6030/6050 Wide Format Solution 20
8.2.1 Long Plotting 20
8.2.2 Long Copying 20
8.2.3 Out of Toner reported as “printer needs attention” 20
8.3 Scanner 20
8.3.1 Clear Last Image 20
8.3.2 Invert Feature and Recall Last Job 20
8.3.3 Upgrade Test Print 21
8.3.4 Scan-to-Print and Margins 21
8.3.5 Width Detection Sensors and Finishing 21
Page 2

8.3.6 Background Suppression 21
8.3.7 Scaling shaded documents 21
8.3.8 50000015 errors while copying 21
8.3.9 Recalling sets 21
8.3.10 Washed out documents when scanning/copying 21
8.4 AccXES Client Tools 22
8.4.1 Manual feed media source 22
8.5 Web Print Manager Tool (WebPMT) 22
8.5.1 Printer Queue – Main WebPMT Screen 22
8.5.2 Netscape 6.1 users only 22
8.5.3 Netscape 7.0 users only 22
8.5.4 German users only 22
8.5.5 Large Scaling Factors 23
8.5.6 Pen Palettes 23
8.5.7 HPGL Page – End of File 23
8.5.8 Display of Media Usage 23
8.5.9 Saved Parameter Settings 23
8.5.10 Default PostScript Page Size 24
8.5.11 String value of “0” in Text Fields 24
8.5.12 “Printer has been updated” message 24
8.5.13 Pen Patterns 24
8.5.14 Printer Password 25
8.5.15 Print Job Priority 25
8.5.16 Date and time shift position after update 25
8.6 Netscape and Unix 25
9Customer Issues Resolved 26
9.1 The following Customer issues were resolved in 10.3.3. b 106 26
9.2 The following Customer issues were resolved in 10.3.3. b 106 26
9.3 The following Customer issues were resolved in 10.3.2 b 201 26
9.4 The following Customer issues were resolved in 10.3.1 b 220 27
9.5 The following Customer issues were resolved in 10.2 b 141 28
9.6 The following Customer issues were resolved in 10.1 b 118 29
9.7 The following Customer issues were resolved in 10.1 b 116 30
10 Appendix 31
10.1 Controller Installation for Xerox Wide Format Solution 31
10.1.1 AccXES Client Tools 31
10.1.2 WebPMT 31
10.1.3 Unix 31
Page 3

1 Introduction
The AccXES Controller Firmware Release 10.3.3 b 106 provides multinational software for the
Xerox 6030/6050 Wide Format Solution, Xerox Wide Format Print Systems 8825, 8830, 8850,
510dp, 721p, and for the Xerox Wide Format Scan System. The languages supported are
English, Deutsch, Espanol, Francais, Italiano, Portugues, and Russian.
This document presents the following information about the AccXES Controller Release 10.3.3
build 106.
•
•
•
•
•
Release deliverables
Recommended configurations
Installation procedures
Present supplemental information and known issues that are not mentioned in the published
customer user documentation.
New features
1.1 FEATURE KEYS:
Feature keys from before version 9.0 B180 are no longer useable with version 10.3.3 b 106
firmware. New keys must be acquired from the Xerox website to use your system.
Downgrading below 9.0 B 180 will also require you to re-download your feature keys. This
applies to AccXES controller resident feature keys only: Postscript, Job Accounting, Scan to
Net, and Scan to Print.
1.1.1 Feature Key Descriptions
Print and Copy Feature Keys are standard with AccXES 10.3.3 build 106 firmware for all printers
except the Xerox 6030/6050 Wide Format.
Additionally, the following functions will be unavailable until the appropriate feature key is
loaded.
•Job Accounting Enables tracking media usage data for print, scan and copy jobs.
Account Management Tool, or some other external accounting tool, is used to assign
User Id, Account Id, Printer Id associations, then collects and tallies the stored data from
the printers)
•PostScript – Enables the interpretation of Adobe Postscript 3 and PDF 1.3 files.
•Disk Image Overwrite – Enables the security options for overwriting image data on the
hard drive.
•Xerox Wide Format Scanner Features:
Scan to Net - To create an electronic file from a scanned image.
Page 4

Scan to Print - To scan, create a preview, and send the scanned image to the printer.
Must also have Scan-to-Net is present.
Color Enablement – AccXES - Allows color scanning when scan to net license is present.
Speed Enhancement Turbo II – AccXES - Enables 4 IPS scan speed for 36” wide.
Speed Enhancement Turbo III – AccXES – Enables 7.33 IPS Scanning on HFT/PUN model
controllers only
•Xerox 6030/6050 Wide Format Printer
Print Server Enablement – Enables print and copy mode for remote printer.
For more information on Feature Keys, see the Feature Key Instructions and Coupon Exchange
screens on the www.xes.com/keys website.
Page 5

2 Release Deliverables
2.1 Xerox 6030/6050 Wide Format Solution
The following executable is provided for the Xerox 6030/6050 Wide Format Solution and
supports the Xerox Wide Format Scan System.
HFT Controller – HFT_6030_10_3_3b106.disk.bin (file size = 7,736,382 bytes)
PUN Controller – PUN_6030_10_3_3b106.disk.bin (file size = 7,736,382 bytes)
2.2 Xerox 8850, 510dp Print Systems
The following executables are provided for the Xerox Wide Format Print System 8850 and
510dp and support the Xerox Wide Format Scan System scanner.
HFT Controller – HFT_8850_10_3_3b106.disk.bin (file size = 7,639,614 bytes)
HFT Controller – HFT_510dp_10_3_3b106.disk.bin (file size = 7,639.614 bytes)
PUN Controller – PUN_8850_10_3_3b106.disk.bin (file size = 7,639,614 bytes)
PUN Controller – PUN_510dp_10_3_3b106.disk.bin (file size = 7,639,614bytes)
CNG Controller – CNG_8850_10_3_3b106.disk.bin (file size = 10,319,876 bytes)
.
2.3 Xerox Print System 721p
The following executables are provided for the Xerox Wide Format Print System 721p and
support the Xerox Wide Format Scan System scanner.
HFT Controller – HFT_721p_10_3_3b106.disk.bin (file size =7,599,959 bytes)
PUN Controller – PUN_721p_10_3_3b106.disk.bin (file size = 7,599,959 bytes)
2.4 Xerox 8825, 8830 Print Systems
The following executables are provided for the Xerox Wide Format Print System 8825, 8830
and support the Xerox Wide Format Scan System scanner.
NOTE: You must load version 9.0 before loading this Firmware
Page 6

HFT Controller – HFT_8830_10_3_3b106.disk.bin (file size = 7,640,368 bytes)
PUN Controller – PUN_8830_10_3_3b106.disk.bin (file size = 7,640,368 bytes)
CNG Controller – CNG_8830_10_3_3b106.disk.bin (file size = 10,319,876 bytes)
N5T Controller – N5T_8830_10_3_3b106.disk.bin (file size = 10,319,876 bytes)
2.5 Xerox Print System X2 TECH
The X2 TECH is no longer supported.
Page 7

3 Recommended Configurations
Table 1: Minimum (Min.) and Recommended (Rec.) RAM Configurations (MB)
F5Y, EV4, KLF, and UP8 controllers are no longer supported.
CNG/N5T Controller HFT/PUN Controller
System Min. Rec. Min. Rec.
8825, 8830, 8850 128
192 128 256
510, 6030, 6050 N/A N/A 128
256
721 N/A N/A 512
512
Page 8

4 Release Installation
NOTES:
Feature keys from before version 9.0 B180 are no longer useable with version 10.3.3
firmware. New keys must be acquired from the Xerox website to use your system.
Downgrading below 9.0 B 180 will also require you to re-download your feature keys.
The AccXES Revision MUST be 9.0 or higher to upgrade to 10.3.3. If your current version is
lower than 9.0, you must install 9.0 or higher before upgrading to 10.3.3.
Regarding scanner firmware revisions: If you are upgrading the firmware of a system
containing a Xerox Wide Format Scanner, you must also ensure that the scanner firmware is
upgraded, prior to upgrading the controller, to the following version:
Xerox Wide Format Scanner – version 2.2.4 or greater. Version 3.2.6 or greater
needed for full functionality.
Xerox 7356 and 7346 Scanners are no longer supported.
Page 9

5 New Features of 10.3.3 b 106
Version 10.3.3 build 106 is intended to be a SPAR release for the HFT, and PUN controllers.
The following features were added as part of those SPAR fixes.
5.1 Additional Postscript functionality
Versions of FreeFlow Accxes prior to 11.3 did not apply the Accxes contrast/lightness settings to
PDF or PostScript prints. These settings may now be used to adjust contrast and lightness on
PDF and PostScript prints.
The internal selection of tone curves and halftone screens for PostScript/PDF files has been
improved for certain document types
5.2 Postscript Interpretation level for PDF
This allows users to control technical details of how PDF files are printed. All PDF files are
internally converted to PostScript for printing. This new selection (on the Postscript emulations
tab in WebPMT) allows a choice between conversion to PostScript Level 2 or PostScript 3. Prior
versions of Accxes had always converted to PostScript 3. Setting this selection to "2" may allow
certain files to print. However, it may also prevent other PDF files from printing; the default
setting of 3 should always be chosen unless specific PDF printing problems arise.
5.3 Support for new IOT firmware releases
Support was added for the new releases of the following IOT firmware versions:
721: 01.05.00
6030/6050: 4.1.06
5.4 880mm paper support for 6030 and 6050
If 880mm paper is loaded and configured on the 6030/6050 it will be recognized by the FreeFlow
Accxes controller. The 880mm media will be displayed and used for printing and copying.
Page 10

6 New Features of 10.3.2 b 201
Version 10.3.2 build 201 is intended to be a SPAR release for the HFT, and PUN controllers,
there are no new features beyond 10.3.1.
The following is a list of new features since version 10.2 of the Accxes Controller.
6.1 Title-block setting removed from Scanner UI
menu (10.3.1)
The menu entry for setting the title-block location has been removed from the scanner UI menu in
favor of the ICON on the main copy screen. When a fold program is selected, the Accxes system
will display an ICON on the main copy screen to indicate the location of the title-block. The NEXT
and PREVious keys can be used to change the location and it is immediately reflected by a
change to the ICON.
6.2 Remote Media Mismatch for 6030/6050 (10.3.1)
Accxes version 10.3.1 now supports remote media mismatch for the 6030 / 6050 printers. The
feature can be found in WebPMT:
PRINTER DEFAULTS>PROCESSING DEFAULTS>Media
When this feature is enabled, Accxes will submit the page to the remote printer regardless of
installed media. If the required media is not installed, the 60X0 will mismatch for the appropriate
media and WebPMT will display “Printer Needs Attention” until the mismatch is resolved. Accxes
will never mismatch block.
When this feature is disabled, Accxes media mismatch will work the same as it does for all other
supported IOTs.
The Mismatch Queuing feature is mutually exclusive of this new setting. It will work as it always
has regardless of this setting.
Page 11

7 10.0-10.2 Feature Enhancements
The following features were added in releases between 10.0 and 10.2 and are listed here as a
convenience for users.
7.1 Turbo III speeds supported for Scan-To-Net
The 7.33 ips scanning mode which is enabled by turbo III feature key is now supported for scan
to net scans in normal mode.
7.2 Check Plot checkbox
A new checkbox is now available to specify if check-plots should be printed during the scanning
of a copy set or not. The checkbox is on the “Sets Build” screen.
When scanning in a copy set, the system would often print each page as it was scanned in to
show the copy quality of the page. There was a complex algorithm that decided if a check-plot
should be printed based on the collation order and the stacking order of the tray or folder.
Version 10.2 replaces the algorithm with a checkbox on the set build screen to allow the user to
specify if a check-plot should be printed or not regardless of collation.
7.3 Copier Margin range increased to +/- 8 inches
The margin settings for copies can now be specified up to +/- 8 inches. This menu can be
reached by selecting the “Transform” key on the scanner UI and selecting “Margins”
7.4 Disk Logging setting added to WebPMT
On the “Printer Setup” page there is a new checkbox for “Disk Logging” which is used for
enabling and disabling the log of system messages to the hard drive. These messages are
especially useful to trained Xerox personnel when diagnosing problems. Turning disk logging off
does not erase the log file, it simply closes it and does not write any more records to it. Turning
disk logging on begins to append new information to the bottom of the log file.
The default setting is “ON”
7.5 Added support for 440, 620 and 880mm rolls
for 6030/6050 printers
Support for these special ISO sizes has been added for the 6030/6050 printers.
To use these sizes, the roll must be configured for the “Spa2” series.
There is a known issue with using 880mm media causing YKE systems to lock-up.
Page 12

7.6 Support for 30 inch roll on 6030/6050 printer
Support of 30 inch rolls on the 6030/6050 printer changed for version 3.2.00. Version 10.1 of
AccXES supports 3.2.00 version of 6030/6050 printer and later. See you local Service
Representative for proper installation and configuration of the 3.2.00 printer firmware.
7.7 Disk Image Overwrite
The main feature for this release is the security feature, disk image overwrite. This feature
provides a means to securely overwrite the entire hard drive, or setup the system to securely
overwrite image data when it is no longer needed, i.e. the job has printed. Details of this feature
can be found in the “Release Notes” section of this document.
7.8 Scan to FTP
This feature allows users to scan documents to one of four FTP destinations. The destinations
MUST be setup by the system administrator. See the “Release Notes” section of this document
for more details.
7.9 Maximum Copy Length
This feature allows the user to specify the maximum output length of a copy. The maximum
length can be changed via the scanner UI in the following location:
MENU>CONFIGURATION>COPY OPTIONS>IMAGING>MAXIMUM COPY LENGTH
NOTE: The maximum copy length defaults to the maximum length that the attached printer
can print. For the 8825, 8830, 8850, and 510 Series this value is 1200 inches. For the 721P
this is either 6 meters or 16 meters based on the configuration of the printer. For the 6030
and 6050 this value defaults to 3 meters.
Page 13

8 Release Notes
The following information supplements the 10.X customer user guides.
8.1 Controller
8.1.1 Disk Image Overwrite
8.1.1.1 OVERVIEW
The Disk Image Overwrite feature has two operations: Immediate and On Demand. The
immediate operation overwrites image data on the hard drive immediately after it is no longer
needed (i.e. When the page has printed). The On Demand operation cleans the entire disk.
Both On Demand Image Overwrite and Immediate Image overwrite feature are configured by the
system administrator, assuming that the system administrator password is set to a non-zero
value.
8.1.1.2 ALGORITHM
The overwrite algorithm for both IIO and ODIO conforms to the U.S. Department of Defense
Directive 5200.28-M (Section 7, Part 2, paragraph 7-202), and is common to all
WorkCentre/WorkCentre Pros and AccXES controllers.
The algorithm for the Image Overwrite feature is:
Step 1: Pattern #1 is written to the sectors containing temporary files (IIO) or to the entire
spooling area of the disk (ODIO). (hex value 0x35 (ASCII “5”)).
Step 2: Pattern #2 is written to the sectors containing temporary files (IIO) or to the entire
spooling area of the disk (ODIO). (hex value 0xCA (ASCII compliment of 5)).
Step 3: Pattern #3 is written to the sectors containing temporary files (IIO) or to the entire
spooling area of the disk (ODIO). (hex value 0x97 (ASCII “ú”)).
Step 4: 10% of the overwritten area is sampled to ensure Pattern #3 was properly written. The
10% sampling is accomplished by sampling a random 10% of the overwritten area.
Page 14

8.1.1.3 USING ON DEMAND IMAGE OVERWRITE (ODIO)
The On Demand Image Overwrite (ODIO) feature is designed to clean the system after it has
been used by overwriting the entire HDD and is activated by pressing the “Start” button on the
Security Feature Web Pages shown below. After pressing the “Start” button, the AccXES
controller will post a message to the Printer UI display (if there is one) and then reboot. The HFT
and PUN controllers will indicate the progress of the operation via the LED’s on the front panel.
The printer UI on the 510, 8850, 8830, and 8825 will also display progress. The WebPMT and
scanner UI will NOT be active until the operation is complete.
When the ODIO operation is complete, the controller will print a status page and then resume
normal operation.
An ODIO is a lengthy operation. Approximates times for an ODIO are listed in the table below:
Controller TypeHDD
Size HFT/PUN
20GB 30 Minutes
40GB 45 Minutes
80GB 90 Minutes
NOTE: If you have done an ODIO, it is important that you do NOT refresh the Web page after the
system reboots because the refresh will resend the “ODIO Request” and cause the system to
perform another ODIO.
Page 15

8.1.1.4 USING IMMEDIATE IMAGE OVERWRITE (IIO)
The Immediate Image Overwrite (IIO) feature is designed to keep the system clean while it is
being used. The status of the feature is displayed on the “Security” page as shown below by the
solid circle. To enable or disable the feature simply press the button highlighted by the dashed
circle on the page below.
To ensure that the hard drive is clean and remains clean, it is recommended that IIO be enabled
and then an ODIO be performed. Certain configuration changes (enabling of scanner, postscript,
scan-to-net etc) result in repartitioning of the hard drive, which could result in non-image
partitions occupying sectors that were previously imaged, or verse visa. It is recommended that
the hard drive be clean (running IIO, or by performing an ODIO) prior to the configuration change
and then be cleaned by performing an ODIO after the configuration change. If the hard drive is
not clean prior to the configuration change it is possible that a section of the hard drive containing
image data could end up in a non-image partition and will not be cleaned by an ODIO. If an
ODIO is not performed after the configuration change, than any sectors from non-imaged
partitions which are now in image containing partitions will look dirty because they do not contain
the required pattern.
When IIO is enabled, each print or copy image is overwritten after it is printed and the scan-to-net
images are overwritten after they are deleted from the controller. This operation happens without
any significant delay in processing and printing of jobs. The one exception is that deleting large
scanned jobs may take a few minutes to free up the disk space so that it can be used again.
While IIO is enabled, the controller will keep the HDD clean. If the controller is rebooted during
the processing of a job, it will clean the partitions on which the job was stored before it completes
it boot-up sequence. This may take as long as an ODIO depending on what type of jobs were
being processed.
Additionally, two features (raster stamps, and image recall) are disabled when IIO is enabled.
When IIO is enabled raster stamps are rejected and an error page is printed with the message
Page 16

"RASTER STAMP REJECTED“. Scanned images are deleted after they are processed and are
not available for recall
In the event of a failure of either an IIO or an ODIO operation, a failure page will be generated.
This page has a customizable string that can be used to direct the operator to take a particular
action. The “Failure Action Requested” string is shown below:
Page 17

8.1.1.5 SCAN TO FTP
The Scan-To-FTP feature is enabled by the Scan-To-Net feature key and is configured by the
“Scan Destinations” web page as shown below. The “Scan Destinations” web page can only be
modified by the system administrator, assuming that the system administrator password is set to
a non-zero value.
Each of the four destinations can specify a different ftp server, account, password and destination
directory.
NOTE: It is important not to refresh this page because it will force the remote file indexes to be
reset to what they were on the original page.
On some occasions, the system administrator may want to restrict users to using only the four
destinations and NOT allow them to leave files on the hard drive of the controller. The “Allow
Local File” checkbox provides a means to allow or disallow the use of the local hard drive for file
storage.
Once a destination is setup, it may be selected from the “Sample” key menu on the scanner User
Interface while in scan mode. From this menu you can choose to keep a copy of the scanned
image on the hard drive of the controller (If the System Administrator has allowed this operation),
print a copy, and send it to one of the defined destinations.
Page 18

8.1.2 Firmware Installation of a Device Failed
If a firmware installation fails, repeat the installation procedure. Occasionally, other events may
interrupt the firmware installation on the AccXES controller.
8.1.3 Blank Pages after Firmware Installation
If, after a firmware installation, the system begins to print out blank pages the hardware needs to
be reset. Simply power down the controller and disconnect it from the printer. After waiting a
short time (30 seconds to 5 minutes) reconnect and reboot the controller, it should resume
normal operation.
8.1.4 Stamp does not appear
If the user tries to upload a stamp files that contains an invalid format, or if the Accounting Mode
is set to “Enabled”, no error message will be displayed. The WebPMT screen will display a
message that the file was uploaded successfully and the stamp’s filename will not appear in the
“Printer Resident Stamps” list.
To avoid this situation, set the Job Accounting mode to “Optional” before uploading stamps. The
WebPMT has no knowledge of the validity of any file that is sent to the printer. File validation and
error handling is done on the printer by the AccXES controller. The WebPMT only reports that the
file was sent to the printer successfully.
8.1.5 Scaling interaction with “ANY”
The media size “ANY” will select the best sheet size for an image to prevent clipping. If a user
specifies a media size of “ANY” and a scale factor that makes the image too large for any sheet
size and mismatch mode is set to scale, the controller will select the largest sheet size and scale
the image to fit on it.
If this is not the desired behavior, a specific sheet size can be selected, or the media mismatch
mode can be set to QUERY.
8.1.6 Margins may cause image clipping
If the margins (TOP, BOTTOM, RIGHT and LEFT) are set to a non-zero value (5mm is the
default) then that amount of whitespace will be added to the image before placing it on the media
and could cause part of the image to be shifted off the page, or clipped. To correct this problem
set the margins to 0.
8.1.7 CGM Files and folding
Certain CGM files contain rotation commands which can confuse the system when folding. If the
titleblock is not visible or the plot is bypassed and not folded, change the titleblock location to
obtain a correctly folded document.
8.1.8 Image wrap on 721 printer
Intermittant image wraps have been seen when very LARGE jobs (>256 Pages) are submitted to
the 721 printer. The best work around is to set the job to forward collation so all the pages are
rendered prior to printing.
Page 19

8.2 Xerox 6030/6050 Wide Format Solution
8.2.1 Long Plotting
Long plot limits are dependent on the amount of memory in the 6030/6050. Limits are as follows:
Amount of Memory
Installed Long Plot Limit
256 MB 3,000 mm
512 MB 7,500 mm
1 GB 15,000 mm
If the maximum plot length in AccXES (in WebPMT: PRINTER DEFAULTS>PROCESSING
DEFAULTS>MEDIA>MAXIMUM PLOT LENGTH) is set greater than the maximum length of the
6030/6050 the image will be truncated.
8.2.2 Long Copying
Copy documents should be limited to the maximum length printed by the 6030/6050 printer. If
longer documents are used the printer may not print them correctly and may hang. Canceling a
long copy job may require a very long time to complete or may hang the system requiring it to be
rebooted.
8.2.3 Out of Toner reported as “printer needs attention”
When the 6030/6050 printer runs out of toner the error message presented in WebPMT is simply
“printer needs attention”. The user needs to refer to the printer user interface to determine the
problem resolution required.
8.3 Scanner
8.3.1 Clear Last Image
When the “Clear Last Image” feature is selected on the Xerox Wide Format Scan System, it may
take a few minutes for a Photo or Color mode scanned document to clear out. After scanning a
document, this feature is accessed by selecting the “C” key on the scanner. It will bring up the
“CLEAR SCANNED IMAGE” screen. Use the “Next” button to select “CLEAR LAST IMAGE”, and
then press “ENTER”.
8.3.2 Invert Feature and Recall Last Job
Scan a document. Press the Transform key. Select “Recall Last Job”. If the Invert feature
(changes dark to light and vice versa) is selected before printing the recalled document, the
document will not be inverted. It will need to be rescanned to get the inverted image.
Page 20
