AccXES Version 10.2 Installation Instructions
Warning: If you have an HFT controller with AccXES 8.0 or 8.5, upgrading to AccXES 9.0 will
cause you to lose the following Data Format Interpreters (DFI):
• VCGL
• Versatec Raster (VRF & VDS)
• CGM
These DFIs are no longer part of the standard system. A feature key is necessary to enable them.
The DFI Feature Keys can be purchased through Xerox Sales or an Authorized Reseller. See Step
1 to determine if you have the appropriate controller.
Note: For the Xerox 6050 and 6030 Wide Format products, one must activate the AccXES print server by
downloading the appropriate print server feature key.
Warning: If the current AccXES Version is 8.0 or lower, upgrading to AccXES 9.0 will eliminate all existing
feature keys. Once installation is complete, you will need to reinstall your feature keys. If you are currently
at AccXES 9.0 or greater, your feature keys will be retained.
Step 1 Determine your Hardware Configuration
There are distinct versions of firmware for each controller hardware platform. Firmware is available for the
hardware platforms as indicated below. Your hardware platform can be determined by examining the
printer configuration test print or serial number (found on the AccXES controller unit). Note your hardware
version. Note: Use the HFT firmware as this will be the correct downloadable binary for PUN controllers.
Controller CPU from Test Print Serial Number
PUN RTT-MPC 7410 PUN-XXXXX
HFT RTT-MPC 7410 HFT-XXXXX
CNG PPC740 – 200 CNG-XXXXX
KLF PPC740 – 200 KLF-XXXXX
N5T PPC740 – 200 N5T-XXXXX
EV4 MPC8240-250 EV4-XXXXX
Step 2 Release Notes
Download, print, and read the AccXES release notes (pdf format). The release notes can be found in the
documentation section or by using the ‘See Also’ link.
Step 3 Check Disk Size and RAM Requirements
Consult the Recommended Configurations Chart in the AccXES Release Notes to confirm that your
Controller has the required disk size and RAM needed for the AccXES upgrade. This chart can be found in
the documentation section or by using the ‘See Also’ link.
Step 4 Job Accounting Migration (if applicable)
Warning: As a precaution, save your Job Accounting Data prior to upgrading. If you have AccXES 7.5 or
greater and are using Job Accounting, use the Account Management Tool (AMT) to collect existing Job
Based Accounting Data from the AccXES Controller / Printer. If you have AccXES 6.1 or lower and are using
job accounting, please read the Job Accounting Migration document (found in the Documentation section)
which describes the migration process from the legacy accounting system to the new Job Based Accounting
system. Legacy Job Log files are deleted when upgrading to AccXES 7.5 or greater. Use the Web Printer
Manager Tool, Scanner UI or ACT to retrieve/store your legacy data prior to upgrading AccXES.

Step 5Ensure Proper Upgrade Paths
Current AccXES Version Necessary Upgrade Path
AccXES 1.0 to 3.0 Step 1: Upgrade to AccXES 4.0 B119
Step 2: Upgrade to AccXES 5.99 B107
Step 3: Upgrade to AccXES 9.0
Step 4: Upgrade to AccXES 10.2
AccXES 4.0 to 5.0 Step 1: Upgrade to AccXES 5.99 B107
Step 2: Upgrade to AccXES 9.0
Step 3: Upgrade to AccXES 10.2
AccXES 6.0, 6.1 or 6.2 Step 1: Upgrade to AccXES 9.0
Step 2: Upgrade to AccXES 10.2
AccXES 7.0, 8.0, or 8.5
Step 1: Upgrade to AccXES 9.0 Step 2: Upgrade to AccXES 10.2
AccXES 9.0 or higher Step 1: Upgrade to AccXES 10.2
Step 6Install or Upgrade to Version 10.2
Download the AccXES firmware file (XXX_XXXX_10_2b141.disk.bin). Follow the instructions in the AccXES
customer release notes to load the appropriate AccXES firmware for your controller hardware type. The
controller type is found in the first set of 3 letters of the controller firmware file name. The printer type
which the firmware file is designed can be found in the next set of letters and/or numbers. Upon successful
completion, a configuration sheet will automatically print from the controller's designated printer.
Warning: After you’ve successfully upgraded the AccXES version, do not power off or reboot until you have
completed the feature key installation. Retrieve the Configuration sheet from the printer. Note the KIK#
and the hardware address. You will need this information for Feature Key redemption.
Step 7 Obtain Feature Keys & download to AccXES controller (if necessary)
Go to the Feature Key web-site to “Replace all keys after a software Upgrade” or “Redeem a Coupon for a
Feature Key”. Be sure to enter the KIK from the current Configuration sheet. Once the key is created,
download it to AccXES, wait 60 seconds, and then reboot. This key will re-enable the Optional Features you
previously purchased (Job Accounting, Scan to Net, etc…)
Note: For the Xerox 6050 and 6030 Wide Format products, one must activate the AccXES print server by
downloading the appropriate print server feature key.
For further information on obtaining or installing Feature Keys, download, print, and read the Feature Key
instructions found in the documentation section or use the Help feature on the Feature Key web-site.
Step 8Download & Install PostScript Fonts (if necessary)
If you have an HFT controller, skip this step (the PS fonts are standard on the HFT platform) To install the
PostScript fonts file, simply send the downloaded ".fwd" file to the controller as if it were a plot file.
Note: Support for Adobe Postscript 3 and Adobe PDF is a configuration option. For your System to be able
to run the Adobe PostScript 3 version, you must have purchased the PostScript Option. The PostScript
license can be purchased through Xerox Sales or an Authorized Reseller.
Step 9Download & Install the Web PMT Help File
