Xilinx Zynq ZC702-G User manual

Zynq-7000 All Programmable SoC ZC702
Evaluation Kit
Quick Start Guide
The Zynq®-7000 All Programmable (AP) SoC ZC702 Evaluation Kit provides a platform for evaluating Xilinx
Zynq-7000 AP SoC devices. The ZC702 kit contains the necessary hardware, tools, and IP to quickly evaluate and
start the development of your embedded system.
This guide provides a kit overview and step-by-step instructions to set up and configure the board, run the built-in
self-test (BIST), install Xilinx tools, and redeem the license voucher.
ZC702 Evaluation Kit
For more information, visit www.xilinx.com/zc702.
X-Ref Target - Figure 1-1
(WKHUQHW
&URVVRYHU
&DEOH
3RZHU
6XSSO\
=&
%DVH
%RDUG
86%
+XE
86%
7\SH$WR0LQL%
$GDSWRU
6'&DUGZLWK
5HIHUHQFH
'HVLJQ
86%&DEOHV
7\SH$WR0LQL%DQG
7\SH$WR0LFUR%
+'0,
&DEOH

2
Built-In Self-Test (BIST) Instructions
ZC702 Evaluation Kit
STEP 1: Install Driver and Terminal Emulator
Install the Silicon Labs CP210x USB-to-UART drivers
and a terminal emulator for the USB-to-UART on your
PC.
Install the CP210x USB to UART drivers as described in
www.xilinx.com/kits/cp210x.
Xilinx recommends using Tera Term for terminal
emulation as described in www.xilinx.com/kits/
teraterm.
Note: If switches, jumpers, or flash memory images
have been changed, refer to www.wiki.xilinx.com/
Kits+ZC702+Getting+Started.
X-RefTarget-Figure1-2
STEP 2: Set Switches
Set DIP switch SW16 to this configuration (00010):
STEP 3: Connect Computer to ZC702 Board
Connect your computer to J17 on the ZC702 board
using the Type-A to Mini-B USB cable.
X-RefTarget-Fi gure1-3
STEP 4: Connect Power
Connect the 6-pin power supply plug to J60 and turn
the board on with SW11.
STEP 5: Set Up Terminal Emulator: Select COM Port
Open Tera Term, select Serial, and choose the COM
port that correlates with the Silicon Labs CP210x
USB-to-UART bridge. Click OK. Note the assigned COM
port for Step 7.
X-RefTarget-Figure1-4
STEP 6: Set Up Terminal Emulator: Select Serial Port
Go to Setup and click Serial port to configure the
terminal serial port setting.

3
STEP 7: Set Up Terminal Emulator: Serial Setup
Select the same COM port assigned in Step 5 and set
the Baud rate to 115200, the Data to 8 bit, the Parity
to none, Stop to 1 bit, and Flow control to none. Click
OK to save the settings.
X-RefTarget-Fi gure1-5
STEP 8: Initialize Configuration
Press SW1 (POR_B) to reinitialize the configuration for
the ZC702 board.
STEP 9: Terminal Display
After the ZC702 board is configured
in Step 8, text appears in the
terminal emulator window. Type the
number or letter associated with a
listed option to run a test
application. For example, type 2 to
run the LED Test application.
Note: DIP switches SW15-1 and
SW15-2 are tied in parallel to
pushbuttons SW13 and SW14,
respectively. For SWITCH Test 5,
either use DIP switches SW15-1
and SW15-2, or keep SW15-1 and
SW15-2 OFF and use pushbuttons
13 and 14.
ON OFF

4
XTP310 (v1.4) December 22, 2017
Install Xilinx Tools and Redeem the License Voucher
A Vivado® Design Suite: Design Edition, node-locked, device-locked license voucher code is included with this
ZC702 Evaluation Kit and shown in Step 10.
STEP 10: Redeem the Vivado Tools License Voucher
To redeem the voucher code, go to www.xilinx.com/getlicense and enter the voucher code shown below. After it is
redeemed, the licenses will appear in your entitlement account, and you can generate a license file, which will be
emailed to you. For additional assistance redeeming your voucher, go to www.xilinx.com/kits/voucher.
Note: This code can only be used once and must be redeemed within one year of purchase.
STEP 11: Install the Vivado Design Suite
a. For the latest version, go to www.xilinx.com/download. Click Archive. Select and download the latest Vivado
version for your operating system. The final release for ZC702 was 2015.4.
b. The Vivado installation flow will open the Vivado License Manager. Under the Acquire a License tab, select
Locate Existing License. Click Next. In the Manage Xilinx License tab, click the Load License button and
navigate to where you saved the license emailed to you in Step 10. Select the file. Click Open.
c. If you need assistance, review the Vivado installation guide at www.xilinx.com/kits/vivadoinstall.
Next Steps
Learn More
To learn more, please go to the next steps page (www.xilinx.com/zc702-nextsteps) which provides an extensive
collection of resources, including tutorial and instructional videos, a detailed reference design guide, schematics, a
hardware user guide, and other reference designs to move you from the evaluation and learning phase to
developing your own product.
Support
For support options related to this product, see the Xilinx support website at www.xilinx.com/support.
Warranty
For the product warranty, go to www.xilinx.com/kits/warranty.
