Xmart HL-BASE-07 User manual

USER MANUAL
Parts Identication Operation Instructions Installation Instructions
Power On/Off: Press switch for 1.5 Sec, approx.
Mode Change: Press switch shortly to choose Mode
1 or Mode 2.
Battery Power Indication:
> 70%Green:
Orange: Between 30% and 70%
Red: < 30%
Solar Panel
Led Panel
Screw
Switch
Indicator Light
3
2
1
4
5
Special Features:
Polycrystalline Solar Panel
Li-ion Rechargeable Battery
Congurable Operation Modes
Material: Aluminum Alloy & PC
100
lumens
www.xmart-ups.com
4
2
1
3
Note: Indicator LED regularly shows Battery Capacity. When
changing Operation Mode it shows selected mode for 5 Sec,
then it returns to show Battery Capacity
Screw the lamp base to the ground, making sure to
have proper stability.
Solar Panel must be oriented toward sun for battery
charging efciency
HL-BASE-07
Solar Lamp
5
Available Modes:
Mode 1: Red Indicator 1 Flash
100 LMx2H + 80LMx1H + 60LMx1H + 40x1H + 20 LM
Mode 2: Red Indicator 2 Flashes
50 LM Until dawn
Select Operation Mode according to your own
requirements
IMPORTANT
1. Use standard installation accessories
2. If stored, charge the lamp every 3 months, to avoid
battery damage
3. If stored for more than 1 year without charging, make a
charge & discharge process to assure battery is in good
condition, otherwise it is not allowed to use.
WARNING
1. Keep the device away from re and re risk
2. There are no replaceable parts inside the lamp. If disassembled warranty will be void.
3. Do not remove battery for other use. If backup time is too short, lamp’s battery needs to be recharged under bright sunlight
4. Clean solar panel regularly for more efcient operation and longer backup (Suggestion: At least every 6 months)
5. Long term storage might cause battery damage and leakage, Leakage might cause battery spontaneous combustion
6. Operation temperature for this lamp must comply with Technical Specications
Luminosity / Luminosidad (LM) 100
SOLAR PANEL / PANEL SOLAR
Type & Capacity / Tipo y Capacidad Polycrystalline / Policristalino, 0.6W
Li-Ion BATTERY / BATERIA Li-Ion
Capacity / Capacidad 3.7 Vdc / 2.96 WH / 800 mAH
Charge & Discharge Temperature /
Temperatura de Carga y Descarga
Charge / Carga: 0 to/a 45 °C
Discharge / Descarga: -20 to/a 60 °C
Recharge Time / Tiempo de Recarga 6 H
ILLUMINATION / ILUMINACION
LED (OSRAM) 2835 - 04pcs
Light Color Temperature / Temperatura de Color de la Luz 3000K, Ra 80+
Efciency / Eciencia 190 lm/W
OPERATION / OPERACION
Backup (During cloudy days) / Autonomía (con Poca Luz Solar) Up to 10 nights / Hasta 10 noches
Operation Modes / Modos de Operación Mode 1: 50 LM / Mode 2: 20 LM
Mode Indication / Indicación de Modo Mode 1: 1 Flash - Mode 2: 2 Flashes
Modo 1: 1 Destello - Modo 2: 2 Destellos
Capacity Indication / Indicador de Capacidad
Green / Verde: >70%
Orange / Naranja: 70% to / a 30%
Red / Rojo: <30%
PIR N/A
IP/IK Codes / Códigos IP/IK IP65 / IK10
Directives / Normativas CE (IEC60598-1 / IEC60598-2-3 / EN55015 / EN61547)
Installation Height / Altura de Instalación Ground level / A nivel del suelo
HL-BASE-07 - TECHNICAL SPECIFICATIONS / ESPECIFICACIONES TECNICAS

HL-BASE-07
Top View / Vista Superior Right Side View /
Vista lateral Derecha
Fron View / Vista Frontal
530 mm
70
107
Packing Information / Información de Empacado:
Dimensions / Dimensiones
Dimensions / Dimensiones
Carton / Cartón (mm) Net/Neto Gros/Bruto
Inner Box / Caja Interna 2 134 x 98 x 620 1.26 1.44
Carton / Cartón 24 420 x 413 x 640 17.4 18.6
Net and Gross weight information is for reference purposes only / La información de pesos Neto y Bruto, es solo referencial
Model
Modelo
Packing Type
Tipo de Empaque
Packed Units
Unidades Empacadas
Carton Weight / Peso Cartón (Kg)
HL-BASE-07
