XP Metal Detectors DEUS User manual

USER'S MANUAL
V 3.0
V 3.0

Page 02
Page 04
Page 05
Page 06
Page 07
Page 08
Page 09
Page 10
Page 10
Page 11
Page 12
Page 12
Page 13
Page 15
PAGE 15
Page 16
Page 17
Page 17
Page 18
Page 19
Page 20
Page 21
Page 22
Page 23
Page 23
Page 25
Page 25
Page 26
Page 26
Page 26
Page 26
Page 27
Page 27
01
WIRELESS HEADPHONES
Menu 
Discrimination-Sensitivity-Ground
Frequency-Tones-Volume-Coil
Pairing with a new coil 
Delete coil 
Factory Programs 
Save or delete a modied program 
Replacement of the backphone 
POWER SUPPLY  BATTERIES
Battery status 
Battery life 
Charging time and charging progress 
Charge 
Battery durability 
Replacement 
Precautions 
EXPERT
Multi-Tones 
Pitch 
Full Tones 
Multi-Tones, thresholds and tones 
TX Power 
Audio Overload 
Frequency shift 
Silencer 
Multi-Notch 
Notch Ground 
Page 29
Page 30
Page 31
Page 31
Page 31
Page 31
Page 32
Page 32
Page 32
Page 33
Page 34
Page 34
Page 35
Page 36
Page 36
Page 37
Page 37
Page 38
Page 38
Page 39
Page 39
Page 40
Page 40
Page 41
Page 43
Page 44
Page 46
Page 47
Page 48
Page 49
Page 50
Page 52
Page 54
Page 56
Page 58
TECHNICAL INTRODUCTION 
LIST OF PARTS 
ASSEMBLY 
USE
Remote control 
Factory programs, Description 
Starting up 
MENU
Discrimination 
Discrimination IAR (Gold Field) 
Sensitivity 
Frequency 
Iron Level 
Tone 
Reactivity 
Audio Response 
Notch 
GROUND
General 
Manual Mode 
Pumping Mode 
Prog.10 Gold Field 
Tracking Mode 
Beach Mode 
NONMOTION 
OPTION
Programs 
Coils 
Pairing with a new coil 
Delete coil 
Conguration 
Speakers 
Back light 
Contrast 
Clock setting 
Prole 
Update 
PRACTICAL INFORMATION 
PRECAUTIONS FOR USE 
TROUBLESHOOTING AND SOLUTIONS 
SPECIFICATIONS 
ACCESSORIES 
SPARE PARTS 
RECOMMENDATIONS / LAW 
FACTORY PROGRAMMES 
YOUR SETTINGS 
MENU STRUCTURE 
DECLARATION OF CONFORMITY 
WARRANTY 
TABLE OF CONTENTS

CONGRATULATIONS ON THE PURCHASE OF YOUR XP METAL DETECTOR
AND WELCOME TO THE WORLD OF RESEARCH AND EXPLORATION!
®, the rst fully wireless detector
You have invested in a high-tech detector capable of exceptional performance, which was
designed and developed in France. You are therefore helping our Company to further research
in the eld of metal detecting and we thank you for your contribution.
02
Dēus is innovative in terms of metal detector design as it oers an architecture based on three
elements communicating via a digital radio link. In this new design the coil, remote control
and audio headphones have each been made independent through the integration of very
compact, high-capacity lithium batteries.
An ultra-miniature electronic circuit, incorporated in the search coil, digitises and analyses
the signals. Data is then sent to the headphones and remote control in real time via a digital
radio link. With this method, the signal is processed at source and not conveyed via a wire link,
which greatly improves data quality.
Incorporating components from leading-edge technologies such as scientic instrumentation
has enabled us to produce a powerful, rapid, lightweight, compact and fully controllable digital
detector.
Whether you are an experienced user or a beginner, Dēus lets you decide whether or not to
modify any of its settings. Powerful pre-congured factory programmes enable all users to get
started immediately, while expert detectorists can choose more advanced parameters via the
intuitive interface.
What is described in this manual as the "Remote Control" is in fact the user interface, known as
the ‘control box’ on conventional detectors.
It enables the detector’s many functions to be precisely adjusted via a graphical interface.
It can also receive program updates (via internet) through its USB socket.

Dēus is also exceptional in being able to function without the remote control, with just the
coil and the wireless headphones, for an even more compact, lightweight conguration !
Like the remote control, the headphones contain all the components needed for detection,
they are a genuine control unit in themselves, but on an ultra-miniature scale and rain proof.
They take over in the absence of the remote control for adjusting the detector settings.
With the headphones you can turn Dēus on and o, change the main detection settings such
as sensitivity, discrimination, ground balance, tone, frequency (4 kHz, 8 kHz, 12 kHz, 18 kHz),
volume, etc. as well as selecting the factory programmes or those previously congured with
the remote control !
Performance is identical whether you are searching with or without the remote control !
Lastly, the new patented XP stem has the combined advantages of an S-shaped stem and a
straight telescopic stem.
It enables you to deploy or fold away the device in just a few seconds, and to change the coil
in an instant.
Its user-friendly design ensures comfort and convenience for the user: length adjustable by
millimetre increments, improved operating angle and shaped rubber handle for a rm, controlled
grip.
So now you’re ready for a new adventure!
03
TECHNICAL INTRODUCTION continued ...

One assembled fully telescopic stem
One set of wireless headphones with
storage case (
subject to version purchased )
One search coil with coil cover
One user interface (remote control)
with case
One connection cable: USB / one mini-B plug
(Only when purchased with remote control)
One connection cable: USB / three mini-B plugs
One mains power supply transformer-charger
One connection clamp for recharging the coil
One set of fastenings (2 screws, 2 wing nuts,
1 washer, 1 spacing washer)
04
LIST OF PARTS
The box for your Dēus metal detector (subject to version purchased) contains the following parts:

1
05
Fitting the coil on the stem
Insert the single rubber
washer in the lower shaft.
Line up the lower stem with
the coil t the two parts
together.
Install bolt and nut.
Arm rest assembly
Remote control assembly
3
2 3
Remove the Protection cover
Unlock the remote control
3

Access to
(Ground Balance)
Manual / Pumping / Beach /Tracking
ON/OFF
Access to menu
Conguration / Programs /Coil
Factory programs
Decrease values
Change program
USB connection for charging
the lithium battery or for updating
the software via internet
Increase values
Change program
Non-motion mode (Pinpoint)
3.5 plug: 3.5mm
audio output jack
MENU
MENU
G.B.
OPTION
OPTION
1 - BASIC 1
Battery level
of coil and remote control
(displayed alternately)
Name of active programme
Change programme with Time
Analog scale
of target conductivity
Digital scale of target conductivity,
from 0 to 99
Detection frequency used
4 - 8 - 12 - 18 kHz
The ground mineralisation index
(phase measured constantly
for information)
The actual level of ground eect
corrections (phase adjustment
underway)
Choose your own prol for this area with
OPTION>CONFIGURATION>PROFILE
G.B.
Reminds you of the target conductivity index to help you optimise your settings
The ground mineralisation index
Valid and return to main menu
To scroll through the menu
Access to expert menu
Access to
DISCRI - SENS - FREQ ...
/
Example of secondary page
06
Mineralisation strength
Value capture prog. 10
MENU
EXPERT
NOTCH
SENS.
FREQ.
DISC

1 - BASIC 1
2 - GM POWER
3 - DEUS FAST
4 - PITCH
5 - G-MAXX
6 - RELIC
7 - WET BEACH
8 - DRY BEACH
9 - BASIC 2
10 - GOLD FIELD
General use (12 kHz).
Similar settings to the XP Gold Maxx Power detector, powerful and fast.
More selective with small targets on iron-infested eld and deeper on
mineralised ground
Responsive pitch that varies in frequency and amplitude according to
the signal’s strength.
Medium speed, particularly eective for large masses and highly conductive
coins.
Slow, for large and deep masses in relatively uncontaminated ground
Wet beaches, although in situ adjustments are needed for the ground
eect, either by pumping or manually (pg 17).
Suitable for dry sand.
Ease of operation with settings that oer greater stability, perfect
for starting out while avoiding false signals (or bottle caps signal).
GOLD FIELD uses another detection method designed for detecting on
ground that is highly mineralised which is often found where gold
nuggets are deposited. In these conditions, targets can be seen as
ground mineralisation or ferrous objects, especially when they are deep.
To go deeper in these dicult conditions, the "Gold Field" program uses
a true All Metal mode that allows you to accept a zone of ground that is
usually not available. Instead of rejecting all the ground values below a
predened value (as on conventional detectors), it rejects only the
specic value of ground in which you are searching, which means you
have to adjust precisely. To facilitate the ground balance (essential in
this program), pressing will make an immediate acquisition of the
ground value within one or 2 pumps of the coil.
In this program a few settings are not active or are replaced by the
other specic setting such as:
- The IAR discrimination (Iron Amplitude Rejection): A range of
discrimination can be applied from 0 to 5. It applies only to targets
that produce strong signals – typically shallow ferrous items. It will
not reject deeper targets which may come across as ferrous when
they are buried in mineralised ground to ensure good targets are not
rejected by mistake.
- Immediate acquisition of the ground value (Grab) is performed simply
by pressing (while pumping the coil to & from the ground).
The display of conductivity is kept, this advantage allows to
work in All Metals mode with visual recognition (valid on shallow targets).
07

To switch o Dēus
Hold down Power for two seconds on the remote control.
Press left- and right-hand buttons on the headphones.
-
YES
NO
After charging your device. (pg 33)
Switch on
the remote control
(after extending stems and holding the coil
away from the ground and any metal)
Switch on
the headphones
Validate or not the use
of the loudspeaker
-
Do not switch on Dēus when the coil is near metal, inside a car, or when the stem is collapsed,
as this may interfere with calibration and lead to abnormal performance. If this should occur, switch Dēus
o and move away from any metal masses before switching it on again. Nevertheless, this does not
represent any risk to the equipment or its electronics. But may give abnormal results !
By default you begin by using the 1 - BASIC 1 factory program which is suitable for general use.
If you wish to test one of the 10 other factory programs,
simply scroll through them with
08
The LED on the coil gives 20 long, successive ashes to indicate that it is waking
up and recalibrating.
Once recalibration is complete, the coil becomes operational and its LED ashes
every second.
When the coil is on standby, its LED ashes every 4 seconds, whereas when it is on it ashes every second.
DISC
SENS
GND
FREQ
TONE
VOL
COIL

Conguring the main detection settings.
Press
Scroll through the menu by pressing
MENU
09
MENU
Adjust the Discrimination level (from 0 to 99) with
Exit with to return to the main menu.
Discrimination enables undesirable targets to be rejected by raising or
lowering a threshold below which certain metals are dierentiated.
The conductivity scale (0 to 99) for metal targets shown below will help
you better understand the discrimination range and its limits, and see
how it corresponds to the digital display of target conductivity on the
remote control main menu.
Increasing the discrimination value enables you to gradually reject any
target whose conductivity is lower than the setting. For example, if you
tune the discrimination level to 10, you will reject iron with a value of
between 0 and 10. If you tune it to 40 you will also eliminate small
pieces of aluminium foil whose conductivity is less than 40.
If you wish to reject other rubbish with higher conductivity, such as pull
tabs from aluminium drinks cans, lead shot or copper hunting cartridges
(whose conductivity is 60-75), you must also be prepared to accept the
elimination of certain good metals with similar conductivity.
If you are particularly bothered by contamination registering as highly
conductive on the digital screen, and you still wish to reject it, it is better
to do so using the NOTCH rejection setting.
Two alternatives involve selecting a low level of discrimination, between
5 and 10, then using either:
1/ The digital target display to more or less visually discriminate a target
category.
2/ The Multi-tone mode to discriminate undesirable targets using a selected
audio tone.
In both cases the decision then lies with you on whether or not to dig.
MENU
EXPERT
NOTCH
SENS.
FREQ.
DISC
MENU G.B.
OPTION
1 - BASIC 1
Coke Foil Bronze coins
(medium size)
Large silver and
copper coins
Iron
Nails
Small targets
Small jewellery
Fine coins
Poor alloys Small pure silver coins
0 10 20 30 40 50 60 70 80 90 99

MENU
EXPERT
DISC
FREQ.
IRON VOL.
SENS
Adjust the Sensitivity level (from 0 to 99) with
Exit with
Sensitivity is often simplistically described as the setting which adjusts
the device’s power level. However this is incorrect. As its name indicates,
it actually determines the device’s sensitivity level. It reacts after receiving
a signal via the receiver coil. Nevertheless, the results are somewhat similar
in practice, as increasing a device’s sensitivity enables it to detect the
presence of more distant targets. However it must be noted that this
setting has no eect on the power emitted.
The most commonly used sensitivity levels range from 70 to 90. It may be
necessary to reduce the level if there is too much interference, as is often
the case near overhead or buried power lines, fences, radio-relay stations,
mobile telephones, computers, televisions, etc.
Do not test your device in your home as there is considerable electromagnetic
and metal interference in urban environments.
10
DISCRIMINATION continued...
MENU
EXPERT
NOTCH
SENS.
FREQ.
DISC
Depending on the frequency setting used, a target’s conductivity
is perceived dierently by the detector. The digital conductivity display
may therefore vary depending on the frequency.
The 0 to 10 range relates to the rejection of iron. To achieve greater
precision in this range there is a digit after the decimal point (from 2.1 to 9.9).
In several menus, particularly at the top left of the Discrimination
screen, a reminder of the target conductivity index is displayed, which helps
you when adjusting the discrimination level.
DISCRIMINATION IAR (Prog.10 GOLD FIELD)
MENU
SENS.
DISC IAR
The program N°10 GOLD FIELD uses another discrimination method,
called
IAR (Iron Amplitude Rejection): the range of discrimination
can be applied from 0 to 5. It applies only to targets that produce strong
signals – typically shallow ferrous items. It will not reject deeper targets
which may come across as ferrous when they are buried in mineralised
ground, to ensure good targets are not rejected by mistake.
Higher discrimination values, enable the detector to reject deeper ferrous.
The gold nuggets (buried deeper in mineralised ground) generate a similar
signal than a ferrous, so in this case it is better to reduce the level of discrimination.

Scroll through the frequencies with
Exit with
Dēus gives you the choice of four detection frequencies (4 kHz, 8 kHz,
12 kHz and 18 kHz) which cover most detection needs.
They enable you to adapt your research more closely to the characteristics
of the ground and the targets to be detected.
MENU
EXPERT
SENS.
IRON VOL.
REACTIVITY
FREQ.
KHZ
Here is a non-exhaustive list of the most likely targets that may be detected according to
the frequency:
11
If you are just starting out, the 8 kHz frequency is a good compromise
for general use. On a wet beach the 18 kHz frequency will be better at
nding small gold jewellery such as chain necklaces and bracelets that are
usually so dicult to detect.
4 kHz
8 kHz
12 kHz
18 kHz
Large, mainly ferrous and non-ferrous masses.
Coins of sucient conductivity and size.
All other medium or relatively small targets in non-mineralised ground relatively
uncontaminated by iron.
Good for ferrous masses and militaria.
Small coins made from any alloy (gold, silver, copper, etc.) and bigger but very ne coins,
low conductivity gold coins, lead, rings, sheet metal, aluminium foil.
Small objects can be found even on mineralised ground contaminated with iron.
Discriminates (distinguishes) coke more easily.
More unstable on non-mineralised and moist ground.
General use.
Coins and large masses, militaria.
Medium and small targets in low-mineralised ground.
General use, small coins.
Coins of all sizes in medium to highly mineralised ground.

MENU
FREQ.
REACTIVITY
AUDIO RESP.
IRON VO.
Adjust the Iron Volume (from 0 to 5) with
Exit with
- At 0 the low-pitched tone is cut o.
- At 5 the low-pitched tone will have a sound level equivalent to other medium
- or high-pitched tones.
12
You have the option of controlling the sound volume of the low-pitched
tone which generally corresponds to iron. Depending on the circumstances,
this enables more attention to be paid to other sounds, by reducing those
generated by iron.
On the other hand, some users prefer that the low-pitched signals from
iron are more audible, as they know that good targets at the detector’s
range limit in mineralised ground sometimes generate low amplitude,
low-pitched sounds.
If the discrimination threshold is too low, 0 or 2 for example,
most iron will generate not low- but medium-pitched tones, as you will
practically be in the All Metals mode. In this case, the iron level setting
will not be of much use.
TONE ( prog. 10 only )
Adjust the tone from 150 to 603 Hz with
Exit with
The TONE function is available only in the program 10 "GOLD
FIELD". It allows to set the fundamental frequency of the audio
pitch signal.
MENU
DISC IAR
SENS
FREQUENCE
TONE
HZ

Adjust the Reactivity from 0 to 5 with
Exit with
EXPERT
MENU
IRON VOL.
AUDIO RESP.
NOTCH
REACTIV.
Large masses and coins, in ground uncontaminated by iron.
Large masses and coins, in ground with little iron contamination,
and general use.
General use, and mineralised soils contaminated with iron.
Dicult soils contaminated with iron, hot rocks, etc.
Very dicult soils, highly contaminated with iron and hot rocks.
0
1
2
3
4/5
Most likely nds with the recommended settings are as follows:
13
The Reactivity is a vital setting that determines the detector’s performance
in terms of how quickly it analyses the signal from detected objects
and its ability to separate the signals from two targets located close
together. This is also known as Recovery Time.
If a soil contains a great deal of iron, hot rocks or other mineralised
debris, soil penetration is generally reduced.
In these conditions, Dēus enables you to select a high degree of reactivity
which will help you speed up the analysis of signals.
On the other hand, if the ground is "clean", it is better to reduce the
Reactivity and sweep more slowly, in order to be more sensitive to deep
masses and obtain more thorough penetration.
Users familiar with the Gold Maxx Power have already had a foretaste
of the Reactivity (recovery speed) of XP’s detectors. And even though Dēus is
a particularly fast and selective detector, you now have the option of
adjusting the reactivity setting to make it even more selective!
By way of example, and to help you better understand the reactivity
levels available, you should note that the reactivity of most detectors
on the market is generally only equivalent to level 1 of the Dēus.
The Gold Maxx Power has a reactivity equivalent to level 2 of the Dēus.

Example
Passing the coil over an iron object close to
the surface then over a good metal target
(ring).
With a low Reactivity level, the iron is detected
for a longer duration, to the extent that it
completely hides the ring.
A high Reactivity level enables you to
distinguish the ring completely from the iron.
The audio signal fully indicates the target.
Full sound
Short sound
No sound
0
1
2
3
4
5
REACTIVITY
14
In terms of pure performance, the greatest detection ranges are obtained with low reactivity
levels. However, you will nd more targets and will be deeper on mineralised ground with
medium or high reactivity levels.
So do not just rely on performance in optimal conditions.
Depending on the reactivity level, you will notice that the length of the audio signal varies
when it passes over a target:
Low reactivity (0, 1) = long sound High reactivity (3, 4, 5) = short sound
Evidently the length of any false signals (the crackling of iron for example) will vary proportionately
as well.
You are therefore advised not to constantly change the reactivity level, as this may interfere
with your ability to distinguish good and bad sounds.
With a medium Reactivity level, you begin
detecting the ring.
The audio signal partially indicates the target.

7
6
5
4
3
2
1
0
The Audio Response enables you to amplify the sound volume of
distant targets and therefore to be more alert to them.
It gives the sensation of greater power, however it does not provide
any additional depth as this setting only aects the sound curve (the
dynamic range of sounds).
By amplifying small signals you will also be amplifying small
spurious false signals.
By increasing the sound response you will compress the
dynamic range and thus reduce the appreciation of a target’s distance.
The Notch complements the discrimination: it enables a "window" of
targets to be rejected whereas discrimination rejects all targets
below a selected threshold.
For example, if you detect a redundant, undesirable target in the
ground, you can decide just to reject the corresponding conductivity
group and continue to detect targets whose conductivity is higher and
lower than those in this group.
If the reference target has a conductivity of 37, adjust the Notch value
to 34-40 using
All targets whose conductivity is between 34 and 40 will then be silenced.
Exit with
By default, the width of the rejection window is 6 points.
EXPERT
MENU
AUDIO RESP.
DISC
SENS
NOTCH
Adjust the Audio Response from 0 to 7 with
Exit with
MENU
REACTIVITY
NOTCH
DISC
AUDIO R.
Audio Level
15
AUDIO RESPONSE
Distance to target

The dierent levels of soil mineralisation you encounter when prospecting
can sometimes aect the performance of your detector.
For example, this may be due to natural magnetic mineralisation such as
iron oxide, hot rocks and magnetite, or sporadic mineralisation from sites of
former human settlement (also magnetic): hearths, pottery, hot rocks, slag,
etc. At the seashore this may also involve mineralisation ranging from
magnetic grade (black sand) to electrical conductor grade (salt water)
depending on the beach or region.
If you are an experienced detectorist you may wish to optimise your
searches to achieve better penetration in some of these mineralised soils.
In magnetic ground with relatively uniform mineralisation, a setting
which is adjusted according to the ground eect will improve penetration by
reducing the amplitude of the ground signals sent back by the receiver
circuits. This ‘adapted setting’ involves adjusting your ground balance
value to the average value of the ground being detected, while adding
1 so as not to hear the ground signals as much. The tracking and pumping
modes do this automatically if the ground conditions allow it. With the
Prog.10 Gold Field it is vital to set exactly the value of the ground.
Attention: As the ground balance setting is the one requiring the most
experience, we recommend that you read this chapter and use the
dierent ground balance modes carefully, while acquiring your own
experience of the ground.
By default, remain in manual mode at level 90 on inland ground and on
dry beach sand. On wet beach reduce the level from 25 to 27.
If the ground is not mineralised (see below the bargraph : Minerali-
sation strength) there is no need to adjust your ground balance to a level
other than 90: since the ground does not send back any signicant
spurious echo, the performance will be optimal even at level 90 and you
will reduce interference resulting from knocks to the coil.
On the main menu, two values are permanently displayed:
16
The ground mineralisation index (phase measured constantly
for information).
The actual level of ground eect corrections
(phase adjustment underway).
General features
MENU G.B.
OPTION
1 - BASIC 1
Mineralisation strength. The higher this value is, the
more mineralized the ground is. Pump the coil up and down
several times to evaluate the mineralisation strength. If the level
is low, there is less of a need to make any adjustments.

You can manually adjust the ground rejection levels from 60 to 95 (Beach
O mode) or from 0 to 30 (Beach On mode)
Each ground rejection level from 60 to 95 receives additional units of ne
adjustment to allow better ground tracking.
90 is the default level, it is the most common level which enables you to
reject all magnetic minerals found in the ground.
By reducing G.B towards 87 you will begin detecting hot rocks, and knocks
to the coil may result in false signals. Even lower, between 75/85, pottery
and the ground itself will begin interfering with your device.
If you are inexperienced in working with ground eects, we strongly
suggest that you limit yourself to a Ground Balance level of 90, which is
the default setting, and is the most stable reference level recommended
for inland ground. Levels lower than 90 will result in increasing instability.
Go to Pumping with
Press and pump the coil on the ground several times until
you obtain the display G.B OK
Exit with
G.B.
TRACKING
PUMPING
BEACH
MANUAL
START
Go to Manual with
Adjust with
Exit with
G.B.
MANUAL
BEACH
TRACKING
PUMPING
START
G.B.
MANUAL
BEACH
TRACKING
IN PROGRESS
G.B OK
Press Ground
4 modes are available:
MANUAL - PUMPING - TRACKING - BEACH (ON / OFF)
G.B.
17
EXPERT

Pumping is a semi-automatic process which allows you to adjust the ground
balance in a zone that you have determined as being representative of the
mean level of the ground being prospected.
Henceforth, the measured value of the ground is entered in memory and
used as the new active ground balance value.
If this value is unsuitable, or if it generates too much instability, you can
repeat the process in a dierent zone or switch to manual mode adding
several extra rejection points.
If a metal target is detected while you are pumping, Dēus will recognise
this and display the message
It will then retain the previous ground balance value.
This problem is generally caused by iron being present. If this is the case
then move to another location and restart the pumping mode.
In low- or non-mineralised ground, there is no need to adjust the
ground balance and you are advised to remain on 90 for greater stability.
The program 10 GOLD FIELD is adapted specically to search for gold
nuggets on mineralised elds or likely gold areas. These areas are dicult
to prospect with conventional detectors. The reason for this being the
presence of ferromagnetic metals, they hide gold nuggets. The program
n°10 GOLD FIELD uses another technique dierent from conventional
detectors who need an accurate ground balancing.
You have the possibility to ground balance using the remote control or
the headphone.
Controlling via the remote control:
Press to grab the ground value while pumping the coil on the ground
to calibrate and stabilise DEUS. The number at the lower right of the
screen shows you the new ground value.
Restart the operation if the ground changes or it becomes unstable.
G.B FAIL
15 cm (6")
~
IN PROGRESS
G.B.
MANUAL
BEACH
TRACKING
G.B FAIL
18
15 cm
~
MENU G.B.
OPTION
10 - GOLD FIELD
PUMPING Mode PROG. 10 GOLD FIELD
6 inches
