XPLORE TECHNOLOGIES Bobcat Instruction Manual

1-888-44-XPLORE (9-7567)
WWW.XPLORETECH.COM
[e-mail]
1
Bobcat User’s
Handbook

1-888-44-XPLORE (9-7567)
WWW.XPLORETECH.COM
[e-mail]
2
Table Of Contents
TABLE OF CONTENTS..................................................................2
DISCLAIMER............................................................................................................................................................. 4
TRADEMARKS .......................................................................................................................................................... 4
COPYRIGHT ............................................................................................................................................................. 4
PUBLICATION INFORMATION....................................................................................................................................... 4
DECLARATION OF CONFORMITY ................................................................................................................................... 4
WARRANTY INFORMATION ......................................................................................................................................... 5
IMPORTANT SAFETY INFORMATION ............................................................................................................................... 5
WELCOME......................................................................................8
ABOUT YOUR COMPUTER .......................................................................................................................................... 9
PACKAGE CONTENTS ............................................................................................................................................... 10
CONTACTING XPLORE:SERVICE &QUESTIONS.............................................................................................................. 11
GETTING STARTED.....................................................................12
FRONT VIEW ......................................................................................................................................................... 12
BACK VIEW ........................................................................................................................................................... 13
RIGHT SIDE VIEW ................................................................................................................................................... 14
LEFT SIDE VIEW...................................................................................................................................................... 15
BOTTOM VIEW....................................................................................................................................................... 16
LED STATUS INDICATOR ........................................................................................................................................... 17
QUICK START GUIDE................................................................................................................................................ 18
USING THE TABLET....................................................................19
SUSPEND OPERATION.............................................................................................................................................. 19
RESUME OPERATION............................................................................................................................................... 19
SCREEN INPUT OPERATION ....................................................................................................................................... 20
MAINTAINING THE TABLET .......................................................21
CARING FOR THE TABLET......................................................................................................................................... 21
TROUBLESHOOTING..................................................................23
HARDWARE SPECIFICATIONS..................................................24
AGENCY NOTES..........................................................................26
FCC NOTICES ........................................................................................................................................................ 26
HEALTH AND SAFETY INFORMATION............................................................................................................................ 28
DOC (INDUSTRY CANADA NOTICES)......................................................................................................................... 28

1-888-44-XPLORE (9-7567)
WWW.XPLORETECH.COM
[e-mail]
3
UL NOTICE............................................................................................................................................................ 30
SYSTEM DISPOSAL .................................................................................................................................................. 30
ENVIRONMENT............................................................................31
ENVIRONMENTAL POLICY.......................................................................................................................................... 31
TAKE BACK AND RECYCLING PROGRAM...................................................................................................................... 32
ENVIRONMENTAL AND SUSTAINABILITY CORPORATE REPORT.......................................................................................... 32

1-888-44-XPLORE (9-7567)
WWW.XPLORETECH.COM
[e-mail]
4
Disclaimer
Xplore Technologies® has made every effort to ensure the accuracy and completeness of this document;
however, because ongoing development efforts are made to continually improve the capabilities of our
products, we cannot guarantee the accuracy of the contents of this document. We disclaim liability for errors,
omissions, or future changes herein.
Trademarks
Xplore and the Xplore logo are registered trademarks of Xplore Technologies Corp. of America; iX104, iX104C5,
BOBCAT, iX104C5 Lite, and iX104C5 Dual Mode are trademarks of Xplore Technologies Corp. Kensington and
MicroSaver are registered trademarks of the Kensington Technology Group. Android is a registered trademark
of Google Corporation. MicroSD is registered trademark of the Personal Computer Memory Card International
Association. Wi-Fi is a trademark of the Wireless Ethernet Compatibility Alliance (WECA). HDMI is a trademark
of “” All other brands, product names, company names, trademarks and service marks used herein are property
of their respective companies.
Copyright
Copyright © 2003-2014 Xplore Technologies Corp. All rights reserved. No part of this publication may be
copied, reproduced, or translated, without the prior written consent of Xplore Technologies. No part of this
publication may be stored or transmitted in any electronic form without the prior consent of Xplore
Technologies. Any unauthorized use is a violation of copyright laws.
Publication Information
PN: 95-01211
February 2014
Declaration of Conformity
DECLARATION OF CONFORMITY according to FCC Part 15, IC ICES-003, and RTT&E directives Responsible Party
Name: Xplore Technologies Corp.
Address: 14000 Summit Drive, Suite 900, Austin, Texas 78728
Telephone: [phone]

1-888-44-XPLORE (9-7567)
WWW.XPLORETECH.COM
[e-mail]
5
Declares that product: Model Series: BOBCAT complies with Part 15 of the FCC Rules. This device complies with
Part 15 of the FCC rules. Operation is subject to the following two conditions: (1) This device may not cause
harmful interference, and, (2) This device must accept any interference received, including interference that
may cause undesired operation.
WARNING
Changes or modifications to this unit not expressly approved by the party responsible for compliance may void
the user’s authority to operate this equipment. For more information about FCC, IC, and EU rules and their
applicability to the BOBCAT, see, “Agency Notes”on page 24.
Warranty Information
The BOBCAT is backed by a standard 36-month International Limited Warranty. An extended International
Limited Warranty is available. Check the service kit included with your computer for warranty terms and
conditions.
Important Safety Information
Before you use the BOBCAT (referred to as the tablet), read these safety instructions and the operation
instructions in this handbook.
Failure to observe all these instructions voids the Limited Warranty and may lead to suspension or denial of
services to the offender, or legal action, or both.
Follow any special regulations governing the use of the tablet and, if radio-enabled, always switch it off in areas
where radio devices are forbidden or when the radio device can cause interference or danger.
Always follow any safety laws and regulations pertaining to the use of cell phones and two-way radios, because
these laws and regulations typically apply to the use of the wireless-enabled tablet.
Observe all restrictions on the use of radio equipment in fuel depots (fuel storage and distribution areas),
chemical plants, and wherever blasting operations are in progress or in any area in which restrictions on radio
transmissions are imposed. Switch off the tablet when in an aircraft. The tablet is not FAA-approved for use on
aircraft. The effect of the use of the tablet in aircraft is unknown. Using the tablet in an aircraft may affect
aircraft instrumentation, communication, and performance; may disrupt the network; and may be illegal.
Operating the wireless-enabled tablet may interfere with the functioning of inadequately protected medical
devices such as pacemakers. Consult a physician or the manufacturer of the medical device if you have any
questions.

1-888-44-XPLORE (9-7567)
WWW.XPLORETECH.COM
[e-mail]
6
Radio signals from your tablet will not affect the operation of most modern equipment, but certain electronic
equipment, including automotive systems, may not be shielded against radio signals from your tablet. Check
with the manufacturer of your motor vehicle or the manufacturer’s representative to determine whether using
the tablet will present any safety issues.
Avoid using the tablet in any environment that requires your full attention, such as when driving a vehicle. If
you need to use your tablet while driving, have a passenger use it for you or find a safe location to halt your
vehicle.
WARNING BATTERIES
Use only battery types specified in this handbook. Using any other type of battery can be dangerous and can
disable the tablet. Do not drop or mishandle the batteries, immerse them in water, or subject them to high
heat. Doing so could increase the risk of explosion or leakage, and possibly cause injury. The lithium-ion
batteries used in this equipment contain material that is hazardous to your health. If battery contents come in
contact with the eyes, IMMEDIATELY flush the affected area with clean water for 15 minutes and have
someone else summon medical attention for you. Unaffected persons should assist the affected individual in
the vital first flushing of the eyes. RECHARGING THE BATTERY MUST ONLY BE CARRIED OUT IN A NON-
HAZERDOUS AREA USING THE SUPPLIED AC ADAPTOR. The definition of hazardous areas can be found in
Standard EN 60079-10.
WARNING
When operating the tablet in a known explosive environment do not remove or replace the battery while the
circuit is live. Before removing the battery verify that the area is known to be free of ignitable concentrations of
flammable substances. EXPLOSION HAZARD –DO NOT DISCONNECT WHILE CIRCUIT IS LIVE UNLESS AREA IS
KNOWN TO BE NON-HAZERDOUS.
AVERISSEMENT –RISQUE D’EXPLOSION. NE PAS DÉBRANCHER TANT QUE LE CIRCUIT EST SOUS TENSION, À
MOINS QU’IL NE S’AGISSE D’UN EMPLACEMENT NON DANGEREUX.
WARNING
EXPLOSION HAZARD - DO NOT REPLACE THE BATTERY UNLESS POWER HAS BEEN SWITCHED OFF OR THE AREA
IS KNOWN TO BE NON-HAZARDOUS;
AVERTISSEMENT - RISQUE D’EXPLOSION - COUPER LE COURANT OU S’ASSURER QUE L’EMPLACEMENT EST
DESIGNE NON DANGEREUX AVANT DE REPLACER LE BATTERY
WARNING
EXPLOSION HAZARD - SUBSTITUTION OF COMPONENTS MAY IMPAIR SUITABILITY FOR CLASS I, DIViSION 2;
AVERTISSEMENT - RISQUE D’EXPLOSION - LA SUBSTITUTIOND E COMPOSANTSP EUTR ENDRE CE MATERIEL
INACCEPTABLE POUR LES EMPLACEMENTS DE CLASSE I, DIVISION 2;

1-888-44-XPLORE (9-7567)
WWW.XPLORETECH.COM
[e-mail]
7
WARNING
EXPLOSION HAZARD - DO NOT DISCONNECT EQUIPMENT UNLESS POWER HAS BEEN SWITCHED OFF OR THE
AREA IS KNOWN TO BE NON-HAZARDOUS
AVERTISSEMENT - RISQUE D’EXPLOSION - AVANT DE DECONNECTER L’EQUIPEMENT, COUPER LE COURANT OU
S’ASSURER QUE L’EMPLACEMENT EST DESIGNE NON DANGEREUX.
WARNING
Do not use any dock or any other accessory or attachment that is not manufactured or supplied by Xplore or an
authorized Xplore accessories supplier. Use of any accessory or attachment that is not supplied or approved for
use with the tablet by Xplore is not permitted because it may cause hazards.
Operate the tablet only from the type of power source indicated on the marking label. (See page 54 for more
information about the battery and power supply.) Route power supply cords so that they are not likely to be
walked on or pinched by items placed upon or against them. Pay particular attention to cords at plugs and
convenience receptacles, and at the point where cords exit from the tablet or its dock. Do not overload wall
outlets, extension cords, or integral convenience receptacles because this can cause fire or electric shock.
Unplug the tablet and refer the tablet and dock for service to qualified service personnel if any of the following
conditions occur:
The power supply cord or plug is damaged.
The tablet or dock does not operate normally when you follow the instructions in this book.
The tablet or dock exhibits a distinct change in performance.
Adjust only controls for which there are instructions in this book. An improper adjustment of other controls can
result in damage and may require extensive work by a qualified technician to restore the tablet or dock to
normal operation.
CAUTION
Avoid prolonged physical contact with the exposed metal surfaces on the front and back of the tablet. While
the tablet may not feel hot to the touch, prolonged physical contact with the tablet surface may cause low-heat
injury. In addition, be careful when removing a PC card that has been used for an extended time, as the card
may be hot.

1-888-44-XPLORE (9-7567)
WWW.XPLORETECH.COM
[e-mail]
8
Welcome
Welcome to the Xplore Technologies Bobcat tablet, the rugged tablet designed, tested, and manufactured to
meet the environmental and physical real-world challenges faced by today’s mobile workers. Based on years of
experience in rugged mobile applications, the BOBCAT is designed to withstand the abuses of everyday wear
and tear. Advanced technology, innovative design, and a rugged case are just a few highlights of your BOBCAT
system.

1-888-44-XPLORE (9-7567)
WWW.XPLORETECH.COM
[e-mail]
9
Note: This handbook assumes that you have basic experience using Microsoft Windows 7 or Microsoft Window
8.1.
About Your Computer
The BOBCAT is a high-performance tablet that runs on Microsoft Windows operating system. The method you
use to control the tablet is as follows:
Tablet Model
BOBCAT
Touchscreen
Projected Capacitive Touch (PCT)
Control Method
Pen (standard with the tablet)
Multi-finger touch

1-888-44-XPLORE (9-7567)
WWW.XPLORETECH.COM
[e-mail]
10
Note: In this handbook, all information applies to all models unless otherwise noted.
All BOBCAT tablets have been engineered and tested to meet Military Standards for Environmental Extremes
(MIL STD 810G). Your tablet includes the following features that make it exceptionally rugged and durable:
Durable, long-lasting, plastic enclosure
Interior magnesium alloy frame
Bumper system and gasket protection mechanisms
Solid State storage memory
Integrated, protected wireless LAN and WAN antennas for dual mode operation
Chemically treated rugged Display Glass
Package Contents
Check to make sure your package includes the following items:
Quick Start Guide
AC adapter
BOBCAT tablet
Warranty information kit
Optional Accessories
Your package may also include any optional accessories you ordered.
Docking Options
Vehicle Docking Station
Carrying Cases
Carrying handle with Stylus and Shoulder Strap
Tablet backside hand-strap
Memory
SD memory
Additional Accessories (Optional)
CAC reader expansion bay
1D2D bar code scanner
Auto adapter (cigarette lighter adapter)

1-888-44-XPLORE (9-7567)
WWW.XPLORETECH.COM
[e-mail]
11
Contacting Xplore: Service & Questions
Note: To troubleshoot problems (including wireless and GPS problems), before you call, read the FAQ page of
the Xplore Technologies Web site. Go to http://www.xploretech.com; then select Customer Support; then
FAQ.
If you purchased your tablet from an authorized Xplore dealer, contact the dealer for service and support.
If you purchased your tablet directly from Xplore, use any of the following methods to contact Xplore for
service and support:
Website: http://www.xploretech.com
E-mail: [e-mail]
Toll free: 1-866-296-8541, extension 222
Fax: [phone]
Before you contact Xplore, have the following information ready so that the customer support representative
can quickly provide a solution:
Product name: BOBCAT
Product serial number
The serial number is on the back of the tablet
Conditions under which the problem occurred
Any error messages that were displayed
Type of device connected, if any

1-888-44-XPLORE (9-7567)
WWW.XPLORETECH.COM
[e-mail]
12
Getting Started
This chapter gives you an overview of your tablet and includes a quick-start guide.
Front View
Built-In Microphone
Enables you to input mono audio
Front Camera
HD Video Front Facing Camera for video conferencing, video capture or still
picture capture
Status Indicator
Indicates the computer status (on, off, charging)
Home Button
Home Button for easy navigation within the Microsoft Windows environment.
Auto Light Sensor
Detects ambient light conditions
Ambient Light Sensor
Front Camera
Built In Microphone
Status Indicator
Home Button
Camera LED Indicator

1-888-44-XPLORE (9-7567)
WWW.XPLORETECH.COM
[e-mail]
13
Back View
Speaker
Integrated Speaker for Audio Playback
Input Power Port
Powers the commuter when connected to external power supply.
Battery Cover
Provides access to the battery.
Rear 5MP Camera
5 MegaPixel rear facing camera for High Quality still photography or HD Video
environment.
Camera Flash
5.0 MP Camera
Device Information
I/O Port Door
Speaker
Battery Cover
Input Power Port
Expansion Port Cover
Capacitive Stylist Pen

1-888-44-XPLORE (9-7567)
WWW.XPLORETECH.COM
[e-mail]
14
Right Side View
Power (On/Off )
Press to power computer, press and hold for 4 seconds to force power off use
Suspend (On/Off )
Momentarily depress to enter/exit Suspend mode.
Screen Orientation lock
Locks the screen in current position regardless of tablet orientation when pressed.
Press again to un-lock screen orientation.
Volume Up/ Down
Press top of rocker button to increase Audio volume Press bottom of rocker button to
decrease Audio volume
19V dc Power Input
Pull back cover to expose connector Jack for AC power supply
LAN Connector
RJ45 for Ethernet LAN data connection.
Serial Port
RS232 Serial port expansion area –uses dongle cable for full serial device interface
Ethernet LAN Port
Down
Up
Power (On/Off)
Suspend/Resume Button
19V dc Power jack
Screen Orientation Lock
Serial Port (RS232)
Volume

1-888-44-XPLORE (9-7567)
WWW.XPLORETECH.COM
[e-mail]
15
Left Side View
Audio connector
Headset connector for smartphone compatible earphones and microphone
USB Ports
Two full size USB 3.0
HDMI Output
Micro HDMI out connector for connection to External Monitor or HDTV device
Micro WAN SIM Slot
Wireless Data Provider SIM card (insert contacts facing up).
Battery Shipping
Switch
Safety Switch to isolate Battery during shipping. It must be turned on (thrown toward
tablet top) for the device to operate. See First time operation section.
Micro SD Card Slot
MicroSDXC memory card slot for user memory expansion (insert contacts facing up)
Battery Shipping
Switch
Micro SD Card Slot
USB 3.0 Ports
Audio Connector
Micro HDMI-Out
Micro WAN SIM Card
Slot

1-888-44-XPLORE (9-7567)
WWW.XPLORETECH.COM
[e-mail]
16
Bottom View
Dock Connector
Enables you to connect the G2 xDock Vehicle Docking Stations.
Guide Pin Receptacles
Help assure a secure connection of the optional xDock.
Note: See “Optional accessories” on page 16.
Kensington Lock Slot
Connector for the optional Kensington MicroSaver™ or equivalent compatible
Security cable
Note: Contact your reseller for information regarding the Kensington security
cable.
Kensington Lock
Docking Connector for the optional
Xplore Tablet Dock
Guide Pin Receptacles

1-888-44-XPLORE (9-7567)
WWW.XPLORETECH.COM
[e-mail]
17
LED and Camera Status Indicator Table
Bobcat LED Profile
LED / Camera Status Indicators
System State
Power Source
OFF
ON
Sleep
Error
External
Orange
Green
Green Slow Blink
Red Fast Blink
Battery Charge
Orange Blink
Orange Blink
Orange Blink
Red Fast Blink
Battery Power
OFF
Green
Green Slow Blink
Red Fast Blink
Battery Low <15%
OFF
Red Blink
Red Blink
Red Fast Blink
Battery Critical Low <8%
OFF
Red
Red
Red Fast Blink
System On + Camera On
OFF
Blue
Green Slow Blink
Red Fast Blink
System On + Camera On
Battery Low <15%
OFF
Blue
Green Slow Blink
Red Fast Blink
System On + Camera On
Battery Critical Low
<8%
OFF
Blue
Green Slow Blink
Red Fast Blink
LED Status Indicator
Camera Status Camera
Indicator

1-888-44-XPLORE (9-7567)
WWW.XPLORETECH.COM
[e-mail]
18
Quick Start Guide
First Time Turning On the Computer
1. Find and Turn the Battery switch ON. A small screwdriver or paperclip may be used for this purpose.
For Safety reasons the tablet is shipped with the Battery switch OFF and the tablet will not operate if
this step is not taken. It is not necessary to turn the Battery switch of the device ON or OFF during
normal device operation so this operation is only needed on initial device operation.
Battery Switch is ON when thrown toward the top side of the tablet.
2. Make sure the battery is charged or that the computer is plugged into an external power source.
3. Press the Power On/Off/Suspend/Resume button.
4. Xplore Technologies Logo should display. Allow device to finish boot- up and follow configuration
instructions on your screen
Battery Switch
Power On/Off Display Toggle and
Suspend/Resume Button

1-888-44-XPLORE (9-7567)
WWW.XPLORETECH.COM
[e-mail]
19
Using The Tablet
Suspend Operation
To conserve battery power when you do not want to turn off the computer, put the computer into Suspend
mode. (You can suspend operation without closing any apps.). The default configuration at time of purchase is
for the system to enter suspend mode automatically after 5 minutes of no activity.
To manually enter suspend mode press the Power switch briefly and release. The display should switch off,
without any confirmation menu being presented.
Resume Operation
To resume tablet operation from Suspend mode follow the same procedure as turning the tablet on.
1. Press the Power On/Off/Suspend/Resume button
If this is not successful the battery on the tablet may have fully discharged. Plug the tablet into AC power and
repeat the procedure
Power On/Off Display Toggle and
Suspend/Resume Button
Power On/Off Display Toggle and
Suspend/Resume Button

1-888-44-XPLORE (9-7567)
WWW.XPLORETECH.COM
[e-mail]
20
Screen Input Operation
Touch- Select Item or Option
Touch and Hold- Open Special
Drag- Scroll the screen
Flick- Scroll the screen quickly
Drag and drop- Move an item
Pinch - Zoom
