XSPC PETG Toolkit User manual

Box Contents
- Heavy Duty Hose Cutter
- PETG Easy Bending Tool
- Bending Rubber
- PETG Chamfer Tool
- PETG Edging Sand a er
XSpc ®PETG Toolkit
1. Soak the bending rubber in warm water before
inserting it into the PETG tube. Now insert the PETG
tube into the tool.
3. Slide the tube forward and heat it at the location of
the mark, until it becomes soft. Make sure to rotate the
tube to make sure heat is a lied evenly. You can use
a hair drier or heat gun for this. Don't get the heat gun
too close to the tubing, or you will a ly too much
heat.
The ste s below should be followed for each
iece of tubing in your build. Be sure to measure
each length carefully before cutting it to size.
It's likely there will be some wastage, so always
order more tube than you ex ect to use in your
build.
2. Make a mark at the intended bend location. When
heating the tubing a ly heat to the area in front of the
mark. A 90° bend for exam le will take around 30mm
of tube.
4. Slide the tube back into the tool, so that the mark
lines u with the to of the tool.
Ste s 5-10 over age >

7. Use the chamfer tool to add an edge to each end of
the cut tube. You must only rotate anti-clockwise. If
you turn clockwise the blades will dig into the tube and
give a oor finish.
8. Use the sand a er to clean the chamfered edges
of the tube. Do not sand the sides of the tube as this
may sto the tube sealing in the fitting.
5. Bend the tube over the head of the tool until you get
the desired angle. Hold it steady and allow the tube to
cool before removing it from the tool.
6. Remove the bending rubber and trim the edges of
the PETG tubing to the correct length for your build. To
remove the bending rubber, just twist and ull.
www.xs- c.com/su ort
9. Place the com ression fittings nut and o-ring over
the PETG tube and ush the chamfered end of the
tube into the fitting. You will need to use some force to
get the tubing ast the two internal o-rings.
10. Screw the nut down until the fitting is com letely
closed and sealed.
