XtendLan TESTMON351-UL User manual

3.5” TFT VIDEO / AUDIO & CABLE TESTER
USER’S MANUAL
TESTMON351-UL

1
CONTENTS
1. Purpose ......................................................................................................................2
2. System specification ................................................................................................... 2
3. Product Outlook.......................................................................................................... 3
4. Key pad description .................................................................................................... 4
5. Function item and description..................................................................................... 4
6. OSD function items and description............................................................................ 4
7. Coaxial cable test function.......................................................................................... 4
8. CAT.5 cable test function……………………………………………………..…………..….5

2
1. Purpose:
This product can receive the standard NTSC/PAL signal and measure the coaxial cable and CAT.5
quality to display on the 3.5” TFT – LCD
2. System specification:
Item Specification
Panel Size 3.5 INCH DIAGONAL COLOR TFT
Resolution 480(H)x234(H) Dot
Active Area 72.00(W)x50.544(H)mm
Dot Pitch 0.150(H)x0.216(V)mm
Pixel Configuration R.G.B.Delta
View Angle Top=10deg., Bottom=30deg., Left=40deg., Right=40.,
Panel Dimension 83(W)x60.5(H)x3.2(D)mm
Back Light LED 6 Type
Video Input NTSC Composite Signal Input(H=15.734KHZ ±0.1KHz V=60Hz±1%)
Video Input PAL Composite Signal Input(H=15.625KHZ ±0.1KHz V=50Hz±1%)
Video Type 1.0Vp-p/75Ω
Video System NTSC / PAL auto switch
Input Source Built in 1 BNC connector for CVBS in and 1 RCA connector for Audio in
Input Voltage DC12V REGULATOR
Power Consumption NORMAL : DC12V, 170mA (2W) CHARGE : DC12V, 1A (12W)
Speaker Output 1 AUDIO CHANEL (SP OUT 1W MAX)
Working Time 6hr
Charge Time 5hr
Low Voltage Triggering 10.7 V
System Cut off Voltage 9.3 V
Keypad Control 6 KEY (MODE / UP/ DOWN / LEFT / RIGHT / EXIT KEY)
Operation Operating Temperature 0°C~50°C
Storage Temperature -25°C~80°C
Weight 320g

3
3. Product Outlook:
TOPVIEW
FRONTPANEL
Product Outlook

4
4 Key pad description:
Key name Function
MODE Function select (Camera OSD control、Coaxial tester、CAT.5 tester)
UP Volume increase\ Item select
DOWN Volume decrease \ Item select
LEFT Screen mirror \ Value decrease
RIGHT Screen upside-down \ Value increase
EXIT Withdraw setting
Keypad definition
5 Function items and description
FUNCTION ITEM Description
CONTRAST 0 ~ 100 Adjust contrast value from 0~100
BRIGHTNESS 0 ~ 100 Adjust brightness value from 0~100
COLOR 0 ~ 100 Adjust color value from 0~100
TINT 0 ~ 100 Adjust tint value from 0~100
1. If you do not push the function button over 15 seconds，the display will disappear
2. All the functions value could be memorize after power off.
3. Press EXIT key to withdraw from the mode
6 OSD function items and description
1. This function is only support OSD control camera. Please refer to the camera user’s manual.
2. All of the function keys as below will show on the camera user’s manual.
7 Coaxial cable test function
1. Press the MODE till the coaxial appear, 3 status will show on the screen when you connect the cable
with terminal.
2. Press EXIT key to withdraw from the mode.
UP DN RTN ETR/MNU

5
ITEM VALUE CABLE QUALITY
1 0~30ΩSHORT
2 30~150ΩGOOD
3 150Ω~∞OPEN
8 CAT.5 cable test function
ITEM CABLE QUALITY DESCRIPTION
1 OPEN Open loop will appear.
2 SHORT Wire short in same pair will appear
3 OK All of the RJ45 pins correct.
4 REVERSE When 2 wires in the same pair opposite will appear
5 ERROR Any wire of different pairs short will appear.
1. it can only test the 568B type connection.
2. Press the MODE till the CAT.5 pair indication appear, 5 status will show on the screen when you
connect the CAT.5 cable with terminal.
3. Press EXIT key to withdraw from the mode.
