Xtreme Power 96421 Original instruction manual

2000W FITNESS WHOLE BODY VIBRATION PLATE
EXERCISE MACHINE
SAVE THIS MANUAL: KEEP THIS MANUAL FOR SAFETY WARNINGS, PRECAUTIONS, ASSEMBLY,
OPERATING, INSPECTION, MAINTENANCE AND CLEANING PROCEDURES. WRITE THE
PRODUCT’S SERIAL NUMBER ON THE BACK OF THE MANUAL NEAR THE ASSEMBLY DIAGRAM
(OR MONTH AND YEAR OF PURCHASE IF PRODUCT HAS NO NUMBER).
OWNER’S MANUAL AND SAFETY INSTRUCTIONS
ITEM: 96421
FOR QUESTIONS PLEASE CALL OUR CUSTOMER SUPPORT: [phone] MON-FRI 9AM TO 3PM PST

IMPORTANT SAFETY INFORMATION
GENERAL SAFETY WARNINGS
Before using this exercise machine, it is essential that you read the entire user manual,
including all warnings and safety instructions. You should also convey all such warnings
and instructions to any other person using this exercise machine. Retain this user manual
for future reference.
SAFETY
IMPORTANT: Attention User: This User’s Guide contains important information about the
installation, operation and safe use of this bud trimming machine. This Guide should be
given to the owner and/or operator of this equipment.
1
Before beginning any exercise program, you should consult a physician for a physical
examination and clearance to engage in the program, or personal injury could result.
If you have any known medical condition, or any physical limitation on your ability to exercise,
seek the advice of a physician before using the machine, in order to avoid possible personal
injury.
If while using the machine, you experience any dizziness, faintness, shortness of breath or
pain, you must stop using the machine immediately and consult a physician. Failure to do so
could result in personal injury.
Always follow the directions on the machine’s console for proper operation. Close supervision
is required when the machine is used by or near, children or disabled persons.
To avoid the risk of electric shock, this equipment must only be connected to a supply main
with protective earth grounding.
Do not operate the machine while tired or under the inuence of drugs, alcohol or other
medication.
Always take care when getting on and off the machine. Use the handles on the
machine as needed, to maintain stability when getting on and off the machine.
Never reach into or under the machine, or tip the machine on its side, while it is in operation.
Replacement parts must be specic to this machine and supplied by the manufacturer only.
Unauthorized substitutions may result in bodily injury or equipment damage.
To reduce the risk of electrical shock, always unplug the machine before cleaning or servicing
it.
To reduce the risk of electrical shock, re, burns or other injury, always plug the machine into
a properly-grounded electrical outlet.
The machine should be set up on a hard, level surface in an area free of obstructions within at
least three feet of the vibration platform.
The machine should not be used outdoors, near a pool, or near any source of water or
extreme humidity
It is important at all times to maintain balance while on the machine.
Only one person should use the machine at a time. Failure to do so may cause injury or
damage the machine.

IMPORTANT SAFETY INFORMATION
2
Hold the safety handle correctly before you begin exercise to help you keep balance.
Check the exercise speed level before you operate the machine to ensure it is at a
comfortable and safe speed.
Ensure that there is sufcient gad between your feet. Recommended gap should be around
30cm.
Do not use this machine for anything other than intended purposes.
WARNINGS AND DISCLAIMERS
XtremePowerUS claims no liability for any damage or injury that result from the use of
the machine by persons who have not read and understood the cautions contained in
this manual, or through any misuse of the unit. You are responsible for your safety while
operating this machine.
To receive maximum performance and satisfaction from the machine, it is important that
you read and understand the safety precautions before using the machine.
Always unplug the machine when not in use.
IMPORTANT: The manufacturer does not accept responsibility for damages caused to or
by the trimmer resulting from an inadequate use or assembly.
Do not operate or touch the machine with wet hands. Doing so may cause electric shock and/
or damage to the machine.

DIAGRAMS
3

4
PARTS LIST

INSTALLATION
STEP 1: Adjust the height of the machine foot to keep
the machine balanced.
STEP 2: Connect three connectors between the
support tube and the controller, then place the
support tube toward the rear of the machine vertically.
Then tighten the tube with 4 of the M8x12 screws.
STEP 3: Place the two lower safety handles to the
machine body and tighten them with 4 of the M6 x
12 screws.
STEP 4: Connect the two upper safety handles
then tighten them with 4 of the M5 x 12 screws.
Then tighten the two upper safety handles to the
top support tube with two of the M8 x 50 screws.
STEP 4: Connect three connectors between
the console and the support tube, then tighten
the console with three of the M6 x 12 screws.
NOTE: Wires should not be pressed by console
after assembly.
5

FEATURES
Choose from three pre-set programs, each stimulates different terrain proles
and varied levels:
P1: Cardiovascular Exercise
P2: Detoxifying Program
P3: Body Perfection Program
Variants of Speed Range
Reduce unwanted body fat effectively with variants of speed range and strong
massage vibration.
Ergonomic Construction with Streamlined Design
Unique ergonomic design with a streamlined form.
User Friendly Console with Window Display Screens
The user friendly console features LCD screens that you can manually customize
your workout routine. Also shows your desired workout time and level of speed.
Durable Steel Frame
The durable steel frame features a tough and sporty design.
Current Overload Protection
Static Electricity Resistance
1. Improves blood circulation
2. Intestinal improvement
3. Thigh rming
4. Rear rming function
5. Waist and Abdomen shaping function
6. Shoulder shaping function
EFFECTIVENESS AND TRAINING GUIDE
6

7
INSTRUCTIONS FOR USE
1. Insert the power plug into the power socket of the machine. Check the voltage
and switch on the power switch.
2. Choose your desired posture while on the machine (examples above)
3. Press the start button to begin the program.
4. Set your stats by pressing the program button sequentially. Hold the BMI sensor
on handles to get your BMI readout.
POWER SWITCH: Secure the electrical cord to
the power connector. Turn on main power with
this switch.

8
SUGGESTIONS AND INFORMATION

PRECAUTIONS AND MAINTENANCE
Do not store this machine near heat or an open ame, under direct sunlight or
in especially humid areas.
Usage temperature: 0-35°C
Keeping temperature: 5-50°C
Humidity: Under 40-80%
Keep the machine’s:
Before cleaning, ensure the main switch is turned off and the AC plug is removed
from the electrical outlet.
Maintenance
Do not use the machine for an extended period of time the rst time. Get used to the
machine rst. Increase over time.
If the machine is not in use for an extended period of time, cover it to protect from
dust.
Do not store the machine under direct sunlight or in high temperatures.
Do not coil the power cord as it may cause the machine to malfunction.
Switch off the power and remove the plug from the socket every time after use.
Do not use the machine in wet areas such as a bathroom, spa or pool.
Using a corrosive cleaner is prohibited. Do not use benzene or thinner to clean the
machine.
9

10
EXERCISE SUGGESTIONS
STRAIGHT STANDING
POSE
WALKING STYLE
LEFT LEG IN FRONT
HORSE RIDING POSE
STAND-A-SIDE POSE WALKING STYLE
RIGHT LEG IN FRONT
STRAIGHT STANDING
POSE

EXERCISE SUGGESTIONS
LOTUS POSE PUSH UP POSE
BOW AND ARROW
STEP POSE
BENT LEG POSE SITTING POSE
11

Record Product’s Serial Number Here:
Note: If product has no serial number, record month and year of purchase instead.
Note: Some parts are listed and shown for illustration purposes only and are not available
individually as replacement parts.
SPECIFICATIONS
12
THE MANUFACTURER AND/OR DISTRIBUTOR HAS PROVIDED THE PARTS LIST AND ASSEMBLY
DIAGRAM IN THIS MANUAL AS A REFERENCE TOOL ONLY. NEITHER THE MANUFACTURER OR
DISTRIBUTOR MAKES ANY REPRESENTATION OR WARRANTY OF ANY KIND TO THE BUYER THAT
HE OR SHE IS QUALIFIED TO MAKE ANY REPAIRS TO THE PRODUCT, OR THAT HE OR SHE IS
QUALIFIED TO REPLACE ANY PARTS OF THE PRODUCT. IN FACT, THE MANUFACTURER AND/OR
DISTRIBUTOR EXPRESSLY STATES THAT ALL REPAIRS AND PARTS REPLACEMENTS SHOULD BE
UNDERTAKEN BY CERTIFIED AND LICENSED TECHNICIANS, AND NOT BY THE BUYER. THE BUYER
ASSUMES ALL RISK AND LIABILITY ARISING OUT OF HIS OR HER REPAIRS TO THE ORIGINAL
PRODUCT OR REPLACEMENT PARTS THERETO, OR ARISING OUT OF HIS OR HER INSTALLATION
OF REPLACEMENT PARTS THERETO.
PLEASE READ THE FOLLOWING CAREFULLY
