Xvent Wind Instruction manual

Version 001 (25.8.2020) Page 1of 2D-502-0172
The Quick Manual will guide you through a quick installation of the product, but in no case could it replace the full operating manual. A
complete operating manual is available on our website www.xvent.cz or can be downloaded using a QR code.
Xvent s.r.o.
Poděbradská 289
53009 Pardubice-Trnová
[email protected]
-The air curtain is designed for indoor covered and dry areas with an ambient temperature from +5 ° C to +40 ° C.
-The air curtain can also be used for environments with higher non-condensing humidity corresponding to the degree of protection IP54
and IP44, according to EN 60529 depending on the type of air curtain. However, a maximum of 80%. The air curtain can also be used in a
corrosive environment C2, according to EN ISO 9223. The air curtain must not be operated in an environment with a risk of explosion and
increased dust.
-Neither the manufacturer nor the supplier is liable for damage caused by incorrect use of the air curtain. The risk is borne by the user.
-The air curtain must not be operated during finishing construction activities, especially during activities in which excessive dust is
generated, eg: grinding of concrete, plasterboard, etc ...
Use of the Wind air curtain
Technical parameters
Vertical installation
-The air curtain must stand on a flat, cohesive and firm surface.
-The correct height of the air curtain must be at least 100 mm longer than the
height of the opening. If the height of the opening is higher or equal to the air
curtain height, you must attach another air curtain.
-Use the "WIND-HOLDER" base (accessory) to fasten the air curtain to the floor.
QUICK MANUAL FOR USE AND INSTALLATION
Use a smart device (mobile phone, tablet, etc.) equipped with this technology to read the QR code.
Installation and connection of the air curtain may only be
carried out by a trained person with the appropriate
authorization for the connection of electrical equipment,
who has the appropriate tools at his disposal. During
installation, all instructions and recommendations given in
the Operation and Installation Manual for the WIND must be
observed.
Before starting any installation or maintenance work, it is
necessary to turn off the power and secure the switch
before turning it on again. When handling the air curtain,
take its weight into account and observe safety.
Anchoring the base
(anchors, dowel screws
must be diameter 10
mm. A washer must be
placed under the head
of the anchoring screw,
nuts, for better weight
distribution of the air
curtain. The air curtain
can be rotated ± 20 ° in
the base.
-The Wind air curtain is designed to separate the indoor and outdoor environment with a
stream of air. This function prevents the escape of indoor air from the indoor environment to
the outdoor environment with open doors, gates, etc.… Another function of the air curtain
with closed doors, gates is the possibility to heat the interior by hot air heating. When
purchasing additional accessories - filter, the air curtain is also used to filter the air of the
indoor environment.
-The air curtain is intended primarily for entrances to industrial halls, warehouses, sports
facilities, workshops, smaller establishments, and also to the entrances of commercial
premises.
Installation –general information
The air curtain must be positioned in the way, that the edge of exhaust of air curtain will be in direction
to the wall aligned towards the door frame of the screened opening. The minimum distance between
the side of the air curtain and the wall, the ceiling is 0.1 m and between the fan intake and the wall, the
ceiling is 0.3 m (from flammable substances 0.5 m). The air curtain - the exhaust must always be turned
at least 10 ° outwards from the opening. Otherwise, proper operation of the air curtain cannot be
guaranteed. Local installation conditions must be taken into account.

Version 001 (25.8.2020) Page 2of 2D-502-0172
Xvent s.r.o.
Poděbradská 289
53009 Pardubice-Trnová
[email protected]
Appropriate wiring may only be carried out by persons qualified for this activity with a valid authorization and knowledge of the
relevant standards and directives. Before starting any assembly work, it is necessary to turn off the power supply of the prepared
electrical installation for subsequent recovery of the unit. The unit must be connected to the main power supply by the TN-S system
(connected neutral) in accordance with the relevant regulations. The wiring diagrams on the product have higher priority than the
diagrams in this manual! A cable of the strand type (licna) provided with a crimped terminal (sleeve) as well as a solid conductor
(wire) in the range of cross-section from 0.2 to 1.5 mm² can be installed in the terminals. Push the wire into the terminals with
adequate force so as not to damage the terminals.
-Use the "WIND-CONNECT" part (accessory) to connect another air curtain for
chaining
-When chaining air curtains, it is necessary to additionally anchor each subsequent
air curtain from the side to maintain the stability of the entire assembly.
The maximum height of chained air curtains must not exceed 6.5 m.
-Prepare suitable auxiliary anchoring structures (brackets, threaded rods, etc.) according to the weight of the air curtain, to the surface to
which you will anchor the air curtain and according to the chosen method of suspension (ceiling, wall, etc.). Wind air curtain table of weights:
-For easier hanging, we
recommend using "WIND-
HINGE" hinges (accessories - 4
pcs in a package)
-Secure the screw connections
against unintentional
unscrewing with nuts.
-.
Electrical installation and wiring of the WIND air curtain
connection
Chained air curtains must not be joined before lifting to the working position. Only one air curtain for chaining is
handled at a time. The air curtains will be connected only after they have been anchored to the wall and ceiling.
-The correct length of the chain assembly must be at least 100 mm longer on each side than the length of the screened opening.
-The air curtains chained side by side are using the "WIND-CONNECT" connector (accessory).
Connection and
description of
power supply and
control terminals
for 1 piece of
WIND air curtain
Connection and
description of
supply and control
terminals for
chained air
curtains WIND
Connection of the air curtain WIND with controller ELEMENTAIR-E-M1
Connection of the chained air curtains WIND with controller ELEMENTAIR-E-M1
Horizontal installation –chaining of air curtains
Vertical installation –chaining of air curtains
Horizontal installation
For the correct rotation of the screen 10 ° (towards the outside), the total length of the hinge (on the far
side of the wall) must be 90 mm longer. Assumed lateral distance of the air curtain from the wall 100 mm. If
the distance from the wall is greater, you must adjust the angle of rotation.
DOOR OPENING
THREADED RODS
DOOR OPENING
THREADED RODS
AUXILIARY CONSOLE
THREADED RODS
DOOR OPENING
control
Power supply
Max. 8pcs
MAIN
SUPPLY
L - VALVE
Max. 8pcs
L - VALVE
MAIN
SUPPLY
control
Power supply
control
Power supply
air curtain Wind
control
Power supply
control
Power supply
control
Power supply
air curtain Wind 1
air curtain Wind 2
