Yakima DoubleHaul User manual

Instruction #1035940D - Page 1 of 9
DoubleHaul
DoubleHaul front (1X)
DoubleHaul (avant) (1X)
Parte delantera del DoubleHaul (1X)
DoubleHaul rear (1X)
DoubleHaul (arrière) (1X)
Parte trasera del DoubleHaul (1X)
coupler (2X)
raccord (2X)
acoplador (2X)
M8 screw (4X)
vis M8 (4X)
tornillo M8 (4X)
felt pad (4X)
garniture (4X)
almohadilla (4X)
M8 nylock nut (4X)
écrou autofreiné M8 (4X)
tuerca nylock M8 (4X)
lock washer (4X)
rondelle de sécurité (4X)
arandela de cierre (4X)
washer (8X)
rondelle (x 8)
arandela (8X)
13 x 19 mm wrench (1X)
clé 13 x 19 mm (1X)
llave de 13 x 19 mm (1X)
key (2X)
clé (2X)
llave (2X)
clip-on pad (8x)
coussinet amovible (8x)
cojín extraíble (8x)
knob (8X)
bouton (8X)
perilla (8X)
accessory lock (1X)
bouton à serrure (x 1)
cerradura accesoria (1X)
lower bail (4x)
mâchoire inférieure (x 4)
mordaza inferior (4x)
6 mm wrench (1x)
clé 6 mm (x 1)
llave de 6 mm (1x)
lock plate (1x)
plaque de verrouillage (x 1)
placa de cierre (1x)
Pour le français, allez à la page 6. Para español ir a la página 6.
CONTENTS • CONTENU • CONTENIDO
Maximum size - 40 mm
SmarT-Slot Kit 3
Yakima Part # 8007356
CROSSBAR SPREAD
27” - 108” (68.6 - 274.3 cm)
STIPPING GUIDES
AVAILABLE ACCESSORIES
135 mm
134 mm
110 mm
80 mm
200 mm
140 mm
115 mm
93 mm
A
B
C
D
C
A
B
D
UPPER COMPARTMENT
COMPARTIMENT SUPÉRIEUR
COMPARTIMIENTO SUPERIOR
LOWER COMPARTMENT
COMPARTIMENT INFÉRIEUR
COMPARTIMIENTO INFERIOR
4 ly rods (2 rods up to 12-wt and 2 rods up
10-wt). Longer rods may be broken down to it.
LOAD CAPACITY

Instruction #1035940D - Page 2 of 9
JOIN THE TWO HALVES TOGETHER.
1
INSTALLATION • INSTALLATION • INSTALACIÓN
Join the front and rear halves
together with the couplers. Using the
6 mm hex wrench and the 13 x 19mm
open wrench. Install the hardware as
shown. Tighten to 10 Nm.
Turn the thumbscrews
on the mounting
plates a few turns to
allow the mounting
plate to slide freely.
4X
2X
LOOSEN THE MOUNTING PLATES.
2
NOTE: If you wish to use DoubleHaul in its half-sized coniguration, proceed to page 5.

Instruction #1035940D - Page 3 of 9
Do not allow DoubleHaul to tip
and damage your vehicle!
Front and rear clamps must
remain on opposite sides of
the center couplers!
cen
t
er coup
l
er
raccords centraux
acoplador de centro
2X
PLACE DOUBLEHAUL ONTO YOUR CROSSBARS.
• Consider rear-hatch access when
choosing your position.
• With assistance from a friend,
carefully place and position
DoubleHaul on your crossbars.
• Slide the plates so they are
centered over your crossbars.
• Continue to support DoubleHaul
as necessary until the mounts have
been fully tightened in the next step!
3
ATTACH THE MOUNTING HARDWARE.
4
2X
4X2X 8X
Guide the clamps
around the crossbar
and up through the
mounting plates,
then attach and
tighten the knobs
to 2 Nm. The
knobs must be
oriented as shown.
Then tighten the
thumbscrew (make
sure the bolt is
captured in the
underside channel).
2 Nm
27” (686 mm) Minimum
TEST THE INSTALLATION.
5
Test the installation by pulling and pushing in all
directions. The DoubleHaul should not slide or move
on the crossbars. Re-tighten the knobs if necessary.
Note: For mounting on 2"
round or 2" square steel tubing,
remove the plastic bails from
the U-bolts before assembling
the clamping system.

Instruction #1035940D - Page 4 of 9
LOAD YOUR RODS.
1
Close the box and use
the key to lock it.
Rest the reels
on their sides
and ensure
the rods are
fully inserted.
LOADING • CHARGEMENT • CARGA
Set the lock plate
onto one of the
mounting plates as
shown. Then screw the
accessory lock onto the
thumbscrew bolt. The
knobs must be oriented
as shown for the plate
to seat properly. Use
the key to lock the
accessory lock.
LOCK THE CARRIER TO THE CROSSBARS.
OPTIONAL • FACULTATIF • OPCIONAL
Insert your rods with guides facing up,
or to the side, to avoid catching them on
the edge of the compartments. The top
compartments are suitable for most 12-wt
rods while the bottom compartments are
limited to itting most 10-wt rods.
Press the button
and open the
door completely.
6
The included felt pads
are optional and provide
additional protection for
your reels from contact
with the inner vertical
wall on the DoubleHaul.
For extended trips
or when traveling
on dirt roads, use
the included clip-on
pads for additional
guide and rod
protection.

Instruction #1035940D - Page 5 of 9
A. Unlock and remove the accessory lock and lock plate.
B. Loosen and remove the knobs and clamps.
C. With assistance from a friend, lift the DoubleHaul off of the crossbars and store it in a safe place.
REMOVAL • DÉPOSE • DESINSTALACIÓN
WEIGHT LIMITS • LIMITES DE CHARGEMENT • LÍMITES DE PESO
=
Rack
DoubleHaul
52 lbs./23.5 kg
Not more than
165 lbs. (75 kg) unless
otherwise noted.
HALF SIZE CONFIGURATION • CONFIGURATION DEMI-LONGUEUR •
A
B
A. Using the 6mm hex wrench and the
13x19mm open wrench, remove the end cowl
from the front portion of the DoubleHaul.
B. Using the 6mm hex wrench and the
13x19mm open wrench, install the end cowl
to the rear portion of the DoubleHaul using
the hardware you removed in step (A).
C. Remove the thumbscrew and bolt. Then the
top and bottom mounting plates from the
front portion of the DoubleHaul.
D. Install the plates as shown onto the rear portion of the
DoubleHaul and loosely tighten the hardware. Make
sure the bolt head is captured in the underside channel.
C
D
E. Return to installation step 3.
