Yamaha RCX222 User manual

User’s Manual ENGLISH E
YAMAHA 2-AXIS ROBOT CONTROLLER
RCX222
YAMAHA MOTOR CO., LTD.
IM Operations
882 Soude, Naka-ku, Hamamatsu, Shizuoka 435-0054.Japan
URL http://www.yamaha-motor.jp/robot/index.html
YAMAHA MOTOR CO., LTD.
E99-Ver. 1.17


1
INTRODUCTION
Introduction
Our sincere thanks for your purchase of this YAMAHA robot controller.
This manual explains how to install and operate the YAMAHA robot controller. Be sure to
read this manual carefully as well as related manuals and comply with their instructions
for using the YAMAHA robot controller safely and correctly.
Refer to the "Programming Manual" that comes with the robot controller for detailed
information on robot programs.

BEFORE USING THE ROBOT CONTROLLER (BE SURE TO READ THE FOLLOWING NOTES)
2
Before using the robot controller (Be sure to read the following notes)
Please be sure to perform the following tasks before using the robot controller.
Failing to perform these tasks will require absolute reset for setting the origin position
each time the power is turned on or may cause abnormal operation (vibration, noise).
[1] When connecting the power supply to the robot controller
Always make a secure connection to the ground terminal on the robot controller to
ensure safety and prevent malfunctions due to noise.
Reference
Refer to "4. Connecting to the power" in Chapter 3, "Installation".
[2] When connecting the battery cable to the robot controller
The absolute batteries shipped with the controller are unused, and the battery
connectors are left disconnected to prevent discharge. After installing the controller,
always be sure to connect the absolute battery while referring to "9. Connecting the
absolute battery" in Chapter 3 before connecting the robot cables.
An error (relating to absolute settings) is always issued if the robot controller power
is turned on without connecting the absolute batteries, so the origin position cannot
be detected. This means the robot connected to this controller cannot be used with
absolute specifications.
[3] When connecting robot cables to the robot controller
Be sure to keep robot cables separate from the robot controller power connection
lines and other equipment power lines. Using in close contact with lines carrying
power may cause malfunctions or abnormal operation.
Reference
Absolute reset is always required when the robot controller power is first
turned on after connecting the robot cable to the robot controller. Perform
absolute reset while referring to "11.8 Absolute reset" in Chapter 4,
"Operation".
Absolute reset is also required after the robot cable was disconnected from
the robot controller and then reconnected.

3
OVERVIEW OF THE RCX SERIES
Overview of the RCX series
The YAMAHA RCX series robot controllers were developed based on years of YAMAHA
experience and proven achievements in robotics and electronics. These controllers are
specifically designed to operate YAMAHA industrial robots efficiently and accurately.
Despite their compact size, the RCX series controllers operate efficiently as multi-axis
controllers with a variety of functions.
Major features and functions are:
1. Multi-task function
Up to 8 tasks* can be run simultaneously in a specified priority. (Low priority tasks
are halted while high priority tasks are run.)
I/O parallel processing and interrupt processing are also available, so that operational
efficiency of the total robot system including peripheral units is greatly improved.
(*: Refer to the programming manual for more details on multi-tasking.)
2. Robot language
The RCX series controller comes with a BASIC-like high-level robot language that
conforms to the industrial robot programming language SLIM *1. This robot language
allows easy programming even of complex movements such as multi-task operations
and uses a compiling method *2for rapid execution of programs.
(*1: Standard Language for Industrial Manipulators)
(*2: This compiling method checks the syntax in a robot language program, converts
it into intermediate codes, and creates an execution file (object file) before actually
performing the program.)
3. Movement command
• Arch motion
Spatial movement during pick-and-place work can be freely set according to the
work environment. This is effective in reducing cycle time.
4. Maintenance
Software servo control provides unit standardization. This allows connection to most
YAMAHA robot models and simplifies maintenance.
5. CE marking *
As a YAMAHA robot series product, the RCX series robot controller is designed to
conform to machinery directives, low-voltage directives and EMC (Electromagnetic
compatibility) directives. In this case, the robot controller is set to operate under
"SAFE" mode. (* For CE marking compliance, see the CE marking supplement manual.)
This manual explains how to handle and operate the YAMAHA robot controllers
correctly and effectively, as well as I/O interface connections.
Read this manual carefully before installing and using the robot controller. Also refer
to the separate "Programming Manual" and "Robot User's Manual" as needed.

4
