Yanmar 8LV320 User manual

8LV320
8LV350
8LV370
8LV320Z
8LV350Z
8LV370Z
0A8LV-G00100
PRINTED IN JAPAN

Issued by : YANMAR CO.,LTD. Marine Operations Division
Edited by : YANMAR TECHNICAL SERVICE CO.,LTD.
8LV SeriesModel
OPERATION MANUAL
0A8LV-G00100Code
All Rights Reserved, Copyright
Date of issue: Jun. 2011
California
Proposition 65 Warning
Diesel engine exhaust and some of its
constituents are known to the state of
California to cause cancer, birth
defects, and other reproductive harm.
California
Proposition 65 Warning
Battery posts, terminals, and related
accessories contain lead and lead
compounds, chemicals known to the
state of California to cause cancer and
reproductive harm.
Wash hands after handling.
Disclaimers:
All information, illustrations and specifications in this manual are based on the latest
information available at the time of publishing. The illustrations used in this manual are
intended as representative reference views only. Moreover, because of our continuous
product improvement policy, we may modify information, illustrations and/or specifications
to explain and/or exemplify a product, service or maintenance improvement. We reserve
the right to make any change at any time without notice. Yanmar and are
registered trademarks of YANMAR CO., LTD. in Japan, the United States and/or other
countries.
All Rights Reserved:
No part of this publication may be reproduced or used in any form by any means -
graphic, electronic, or mechanical, including photocopying, recording, taping, or informa-
tion storage and retrieval systems - without the written permission of YANMAR CO., LTD.
8LV Series
1st Edition : Jun. 2011
OPERATION MANUAL
Overseas Office
■Yanmar (Head office)
1-32, Chayamachi, Kita-ku, Osaka, Japan 530-8311
■Yanmar Europe B.V. (YEU)
Brugplein 11, 1332 BS Almere-de Vaart, Netherlands
Phone: [phone] Fax: [phone]
■Yanmar Asia (Singapore) Corporation Pte Ltd. (YASC)
4 Tuas Lane, Singapore 638613
Phone: [phone] Fax: [phone]
Marine Operations Division
Production Dept.
Tsukaguchi Plant
Quality Assurance Dept.
3-1, 5-Chome, Tsukaguchi-honmachi, Amagasaki,
Hyogo, Japan 661-0001
Phone: [phone] Fax: [phone]
■
■Yanmar Engine (Shanghai). Co., Ltd.
18F, North Tower, Shanghai Stock Exchange Building
528 South Pudong Road, Pu Dong Shanghai, China 200120
Phone: [phone] Fax: [phone]
■Yanmar America Corporation (YA)
101 International Parkway
Adairsville, GA 30103, U.S.A.
Phone: [phone] Fax: [phone]

8LV Series Operation Manual i
TABLE OF
CONTENTS
8LV Series Operation Manual
Page
Introduction ............................................................................................. 1
Record of Ownership........................................................................... 2
Safety........................................................................................................ 3
Safety Precautions .............................................................................. 4
General Information....................................................................... 4
Before You Operate....................................................................... 4
During Operation and Maintenance............................................... 4
Location of Safety Decals.................................................................... 9
Product Overview.................................................................................. 11
Yanmar 8LV Features and Applications............................................ 11
New Engine Break-In................................................................... 12
Component Identification................................................................... 13
Service Side ................................................................................ 13
Non-Service Side......................................................................... 13
Location of Nameplate ...................................................................... 14
Function of Major Components ......................................................... 15
Vessel Control System (VCS) ........................................................... 16
Display......................................................................................... 17
Before You Operate............................................................................... 19
Diesel Fuel ........................................................................................ 20
Diesel Fuel Specifications ........................................................... 20
Filling the Fuel Tank .................................................................... 22
Bleeding the Fuel System............................................................ 22
Engine Oil.......................................................................................... 23
Engine Oil Specifications ............................................................ 23
Engine Oil Viscosity..................................................................... 23
Checking the Engine Oil .............................................................. 24
Adding Engine Oil........................................................................ 24
8LV_OPM.book i ページ ２０１１年１月１１日 火曜日 午後１２時８分

TABLE OF CONTENTS
ii 8LV Series Operation Manual
Engine Coolant.................................................................................. 25
Engine Coolant Specifications..................................................... 25
Coolant (Closed Cooling System) ............................................... 25
Checking and Adding Coolant..................................................... 25
Checking the Engine Oil and Engine Coolant ................................... 26
Engine Operation .................................................................................. 27
Starting the Engine(Start Up) ............................................................ 28
If the Engine Fails to Start ........................................................... 29
After the Engine has Started ....................................................... 29
Warm Up Mode (Shift Disconnect).................................................... 29
Throttle and Shift Control .................................................................. 30
Neutral......................................................................................... 30
Forward ....................................................................................... 30
Reverse ....................................................................................... 30
Forward (Reverse) to Reverse (Forward) ................................... 30
Cautions During Operation................................................................ 31
Shut-Down the Engine (Stopping)..................................................... 32
Normal Stopping.......................................................................... 32
Emergency Stop.......................................................................... 33
Control the Backup Panel ................................................................. 33
Checking the Engine After Operation................................................ 34
Periodic Maintenance ........................................................................... 35
Precautions ....................................................................................... 36
The Importance of Periodic Maintenance.................................... 36
Performing Periodic Maintenance ............................................... 36
The Importance of Daily Checks ................................................. 36
Keep a Log of Engine Hours and Daily Checks .......................... 36
Yanmar Replacement Parts ........................................................ 36
Tools Required ............................................................................ 36
Ask Your Authorized Yanmar Marine Dealer or
Distributor for Help ...................................................................... 36
Tightening Fasteners................................................................... 37
EPA Maintenance Requirements ...................................................... 39
EPA Requirements for USA and Other Applicable Countries ..... 39
EPA Requirements...................................................................... 39
Conditions to Ensure Compliance with EPA Emission Standards .... 39
Inspection and Maintenance ....................................................... 39
Periodic Maintenance Schedule........................................................ 40
Inspection and Maintenance of EPA Emission-Related Parts..... 41
Periodic Maintenance Procedures .................................................... 42
Daily Checks ............................................................................... 42
After Initial 50 Hours of Operation ............................................... 43
Every 50 Hours of Operation....................................................... 44
Every 250 Hours of Operation..................................................... 46
Every 500 Hours of Operation..................................................... 51
Every 1000 Hours of Operation................................................... 52
Long-Term Storage ............................................................................... 53
Preparing the Engine for Long-Term Storage ................................... 54
Draining the Seawater Cooling System....................................... 54
8LV_OPM.book ii ページ ２０１１年１月１１日 火曜日 午後１２時８分

TABLE OF CONTENTS
8LV Series Operation Manual iii
Troubleshooting.................................................................................... 57
Troubleshooting After Starting........................................................... 58
Troubleshooting Information.............................................................. 59
Troubleshooting Chart....................................................................... 60
Failsafe Diagnosis Functional Specification Chart ............................ 65
Specifications........................................................................................ 67
Principal Engine Specifications ......................................................... 67
8LV Series Engine Specifications................................................ 67
8LV Series Marine Gear Specifications....................................... 68
System Diagrams .................................................................................. 69
Wiring Diagram.................................................................................. 69
8LV Wiring Diagram .................................................................... 70
EPA Warranty USA Only....................................................................... 73
YANMAR CO., LTD. Limited Emission Control System Warranty -
USA Only........................................................................................... 73
Your Warranty Rights and Obligations ........................................ 74
Warranty Period........................................................................... 74
Warranty Coverage ..................................................................... 74
Exclusions ................................................................................... 74
Owner’s Responsibility ................................................................ 74
Customer Assistance................................................................... 75
Maintenance Log......................................................................... 76
8LV_OPM.book iii ページ ２０１１年１月１１日 火曜日 午後１２時８分

TABLE OF CONTENTS
iv 8LV Series Operation Manual
This Page Intentionally Left Blank
8LV_OPM.book iv ページ ２０１１年１月１１日 火曜日 午後１２時８分

8LV Series Operation Manual 1
8LV Series Operation Manual
INTRODUCTION
Welcome to the world of Yanmar Marine! Yanmar
Marine offers engines, drive systems and
accessories for all types of boats, from runabouts to
sailboats, and from cruisers to mega yachts. In
marine leisure boating, the worldwide reputation of
Yanmar Marine is second to none. We design our
engines to respect nature. This means quieter
engines, with minimal vibrations, cleaner than ever.
All of our engines meet applicable regulations,
including emissions, at the time of manufacture.
To help you enjoy your Yanmar 8LV series engine
for many years to come, please follow these
recommendations:
• Read and understand this Operation Manual
before you operate the machine to ensure that
you follow safe operating practices and
maintenance procedures.
• Keep this Operation Manual in a convenient place
for easy access.
• If this Operation Manual is lost or damaged, order
a new one from your authorized Yanmar Marine
dealer or distributor.
• Make sure this manual is transferred to
subsequent owners. This manual should be
considered a permanent part of the engine and
remain with it.
• Constant efforts are made to improve the quality
and performance of Yanmar products, so some
details included in this Operation Manual may
differ slightly from your engine. If you have any
questions about these differences, please contact
your authorized Yanmar Marine dealer or
distributor.
• The specifications and components (instrument
panel, fuel tank, etc.) described in this manual
may differ from ones installed on your vessel.
Please refer to the manual provided by the
manufacturer of these components.
• Refer to the Yanmar Limited Warranty Handbook
for a complete warranty description.
8LV_OPM.book 1 ページ ２０１１年１月１１日 火曜日 午後１２時８分

INTRODUCTION
28LV Series Operation Manual
RECORD OF OWNERSHIP
Take a few moments to record the information you need when you contact Yanmar for service, parts or
literature.
Engine Model: _______________________________________________________________________
Engine Serial No.: ____________________________________________________________________
Date Purchased: _____________________________________________________________________
Dealer: _____________________________________________________________________________
Dealer Phone: _______________________________________________________________________
8LV_OPM.book 2 ページ ２０１１年１月１１日 火曜日 午後１２時８分

8LV Series Operation Manual 3
8LV Series Operation Manual
SAFETY
Yanmar considers safety of great importance and
recommends that anyone that comes into close
contact with its products, such as those who install,
operate, maintain or service Yanmar products,
exercise care, common sense and comply with the
safety information in this manual and on the
machine’s safety decals. Keep the labels from
becoming dirty or torn and replace them if they are
lost or damaged. Also, if you need to replace a part
that has a label attached to it, make sure you order
the new part and label at the same time.
DANGER
DANGER indicates a hazardous situation
which, if not avoided, will result in death or
serious injury.
WARNING
WARNING indicates a hazardous situation
which, if not avoided, could result in death or
serious injury.
CAUTION
CAUTION indicates a hazardous situation
which, if not avoided, could result in minor or
moderate injury.
NOTICE
NOTICE indicates a situation which can cause
damage to the machine, personal property and/or
the environment or cause the equipment to operate
improperly.
A
This safety alert symbol appears
with most safety statements. It
means attention, become alert, your
safety is involved! Please read and
abide by the message that follows
the safety alert symbol.
8LV_OPM.book 3 ページ ２０１１年１月１１日 火曜日 午後１２時８分

SAFETY
48LV Series Operation Manual
SAFETY PRECAUTIONS
General Information
There is no substitute for common sense and
careful practices. Improper practices or
carelessness can cause burns, cuts, mutilation,
asphyxiation, other bodily injury or death. This
information contains general safety precautions
and guidelines that must be followed to reduce risk
to personal safety. Special safety precautions are
listed in specific procedures. Read and understand
all of the safety precautions before operation or
performing repairs or maintenance.
Before You Operate
WARNING
• Never permit anyone to install or
operate the engine without proper
training.
• Read and understand this Operation Manual
before you operate or service the engine to
ensure that you follow safe operating
practices and maintenance procedures.
• Safety signs and labels are additional
reminders for safe operating and maintenance
techniques.
• Contact your authorized Yanmar Marine
dealer or distributor for additional training.
During Operation and Maintenance
DANGER
CRUSH HAZARD
• Never stand under hoisted
engine. If the hoist mechanism
fails, the engine will fall on you.
• If the engine needs to be transported for
repair, have a helper assist you attach it to a
hoist and load it on a truck.
• The engine lifting eyes are engineered to lift
the weight of the marine engine only. Always
use the engine lifting eyes when lifting the
engine.
• Additional equipment is necessary to lift the
marine engine and marine gear together.
Always use lifting equipment with sufficient
capacity to lift the marine engine.
WARNING
EXPLOSION HAZARD
• While the engine is running or the
battery is charging, hydrogen gas
is being produced and can be
easily ignited. Keep the area
around the battery well-ventilated
and keep sparks, open flames and
any other form of ignition out of
the area.
8LV_OPM.book 4 ページ ２０１１年１月１１日 火曜日 午後１２時８分

SAFETY
8LV Series Operation Manual 5
WARNING
FIRE AND EXPLOSION HAZARD
• Diesel fuel is flammable and
explosive under certain
conditions.
• Never use a shop rag to catch the fuel.
• Wipe up all spills immediately.
• Never refuel with the engine running.
• Never use diesel fuel as a cleaning agent.
• Store any containers containing fuel or other
flammable products in a well-ventilated area,
away from any combustibles or sources of
ignition.
• Never jump-start the engine. Sparks caused
by shorting the battery to the starter terminals
may cause a fire or explosion. Only use the
key switch to start the engine.
WARNING
FIRE HAZARD
• Undersized wiring systems can
cause an electrical fire.
• Store any equipment in a designated area
away from moving parts.
• Never use the engine compartment for
storage.
WARNING
SEVER HAZARD
• Rotating parts can cause severe
injury or death. Never wear
jewelry, unbuttoned cuffs, ties or
loose fitting clothing and Always
tie long hair back when working
near moving/rotating parts such
as the flywheel or PTO shaft. Keep
hands, feet and tools away from
all moving parts. Never operate
the engine without the guards in
place.
• Before you start the engine make sure that all
bystanders are clear of the area. Keep
children and pets away while the engine is
operating.
• Check the engine that any tools or shop rags
used during maintenance have been removed
from the area.
WARNING
ALCOHOL AND DRUG HAZARD
• Never operate the engine while
under the influence of alcohol or
drugs or feeling ill.
WARNING
EXPOSURE HAZARD
• Always wear personal protective
equipment including appropriate
clothing, gloves, work shoes, eye
and hearing protection as
required by the task at hand.
WARNING
ENTANGLEMENT HAZARD
• Never leave the key in the key
switch when you are servicing the
engine. Someone may
accidentally start the engine and
not realize you are servicing it.
• Never operate the engine while wearing a
headset to listen to music or radio because it
will be difficult to hear the warning signals.
8LV_OPM.book 5 ページ ２０１１年１月１１日 火曜日 午後１２時８分

SAFETY
68LV Series Operation Manual
WARNING
PIERCING HAZARD
• Avoid skin contact with
high-pressure diesel fuel spray
caused by a fuel system leak such
as a broken fuel injection line.
High-pressure fuel can penetrate
your skin and result in serious
injury. If you are exposed to
high-pressure fuel spray, obtain
prompt medical treatment.
• Never check for a fuel leak with your hands.
Always use a piece of wood or cardboard.
Contact your authorized Yanmar Marine
dealer or distributor repair the damage.
WARNING
BURN HAZARD
• Some of the engine surfaces
become very hot during operation
and shortly after shut-down. Keep
hands and other body parts away
from hot engine surfaces.
WARNING
SUDDEN MOVEMENT HAZARD
• Always stop the engine before beginning
service.
• Be sure the boat is in open water away from
other boats, docks or other obstructions
before increasing rpm. Avoid unexpected
equipment movement. Shift the marine gear
into the NEUTRAL position any time the
engine is at idle.
• To prevent accidental equipment movement,
Never start the engine in gear.
WARNING
EXHAUST HAZARD
• Never block windows, vents or
other means of ventilation if the
engine is operating in an
enclosed area. All internal
combustion engines create
carbon monoxide gas during
operation and special precautions
are required to avoid carbon
monoxide poisoning.
• Always ensure that all connections are
tightened to specifications after repair is
made to the exhaust system. All internal
combustion engines create carbon monoxide
gas during operation and special precautions
are required to avoid carbon monoxide
poisoning.
WARNING
WELDING HAZARD
• Always turn off the battery switch (if
equipped) or disconnect the negative battery
cable and the leads to the alternator when
welding on the equipment.
• Remove the engine control unit multi-pin
connector. Connect the weld clamp to the
component to be welded and as close as
possible to the welding point.
• Never connect the weld clamp to the engine
or in a manner which would allow current to
pass through a mounting bracket.
• When welding is completed, reconnect the
alternator and engine control unit prior to
reconnecting the batteries.
WARNING
SHOCK HAZARD
• Always turn off the battery switch
(if equipped) or disconnect the
negative battery cable before
servicing the equipment.
• Always keep the electrical connectors and
terminals clean. Check the electrical
harnesses for cracks, abrasions, and
damaged or corroded connectors.
• Never use undersized wiring for the electrical
system.
8LV_OPM.book 6 ページ ２０１１年１月１１日 火曜日 午後１２時８分

SAFETY
8LV Series Operation Manual 7
WARNING
Never remove the coolant filler cap if the engine
is hot. Steam and hot engine coolant will spray
out and seriously burn you. Allow the engine to
cool down before you attempt to remove the
cap.
CAUTION
POOR LIGHTING HAZARD
• Ensure that the work area is adequately
illuminated. Always install wire cages on
portable safety lamps.
CAUTION
TO O L H A Z A R D
• Always use tools appropriate for the task at
hand and use the correct size tool for
loosening or tightening machine parts.
CAUTION
FLYING OBJECT HAZARD
• Always wear eye protection when servicing
the engine or when using compressed air or
high-pressure water. Dust, flying debris,
compressed air, pressurized water or steam
may injure your eyes.
CAUTION
COOLANT HAZARD
• Wear eye protection
and rubber gloves
when you handle Long
Life engine coolant. If
contact with the eyes
or skin should occur,
flush eyes and wash
immediately with
clean water.
CAUTION
• DO NOT drain the coolant system. A full
coolant system will prevent corrosion and
frost damage.
• If seawater is left inside of the engine, it may
freeze and damage parts of the cooling
system when the ambient temperature is
below 0 °C (32 °F).
NOTICE
It is important to perform daily checks as listed in
the Operation Manual. Periodic maintenance
prevents unexpected downtime, reduces the
number of accidents due to poor engine
performance and helps extend the life of the
engine.
NOTICE
Contact your authorized Yanmar Marine dealer or
distributor if you need to operate the engine at high
altitudes. At high altitudes the engine will lose
power, run rough and produce exhaust gases that
exceed the design specifications.
NOTICENOTICE
Always be environmentally
responsible.
Follow the guidelines of the EPA or other
governmental agencies for the proper disposal of
hazardous materials such as engine oil, diesel fuel
and engine coolant. Consult the local authorities or
reclamation facility.
NOTICE
Never dispose of hazardous materials by dumping
them into a sewer, on the ground or into ground
water or waterways.
NOTICE
If a Yanmar Marine Engine is installed at an angle
that exceeds the specifications stated in the
Yanmar Marine Installation manuals, engine oil may
enter the combustion chamber causing excessive
engine speed, white exhaust smoke and serious
engine damage. This applies to engines that run
continuously or those that run for short periods of
time.
8LV_OPM.book 7 ページ ２０１１年１月１１日 火曜日 午後１２時８分

SAFETY
88LV Series Operation Manual
NOTICE
If you have an installation with two or three engines,
and only one engine is operating, please note that if
the propeller shaft thru-hull (stuffing box) is
lubricated by engine water pressure and the
engines are interconnected, care must be taken
that water from the running engine does not enter
the exhaust of the non-running engine(s). This
water could cause seizure of the non-running
engine(s). Contact your authorized Yanmar Marine
dealer or distributor for a complete explanation of
this condition.
NOTICE
If you have an installation with two or three engines,
and only one engine is operating, the water pickup
(thru-hull) of the non-running engine(s) should be
closed. This will prevent water from being forced
past the seawater pump and eventually finding its
way into the engine. The result of water entering
the engine could cause seizure or other serious
problems.
NOTICE
If you have an installation with two or three engines,
and only one engine is operating, it is important to
limit the amount of throttle applied to the running
engine. If you observe black smoke or movement of
the throttle does not increase engine rpm, you are
overloading the engine that is running. Immediately
throttle back to approximately 2/3 throttle or to a
setting where the engine performs normally. Failure
to do so may cause the running engine to overheat
or cause excess carbon buildup which may shorten
the engine's life.
NOTICE
New Engine Break In: On the initial engine start-up,
check for proper engine oil pressure, diesel fuel
leaks, engine oil leaks, coolant leaks, and for
proper operation of the indicators and/or gauges.
During the first 50 hours of operation operate your
new engine under a substantial load at all times.
For best break-in results operate the engine at
various speeds. Operating the engine in NEUTRAL
must be avoided. During the first 50 hours, avoid
operation below 2000 min-1 (rpm). During the
break-in period, carefully observe the engine oil
pressure and engine temperature. During the
break-in period, check the engine oil and coolant
levels frequently.
NOTICE
If any indicator illuminates during engine operation,
stop the engine immediately. Determine the cause
and repair the problem before you continue to
operate the engine. Contact your authorized
Yanmar Marine dealer or distributor for service
before operating the engine.
NOTICE
Observe the following environmental operating
conditions to maintain engine performance and
avoid premature engine wear:
• Avoid operating in extremely dusty conditions.
• Avoid operating in the presence of chemical
gases or fumes.
• Never run the engine if the ambient temperature
is above +40 °C (+104 °F) or below -16 °C
(+3 °F).
• If the ambient temperature exceeds +40 °C
(+104 °F), the engine may overheat and cause
the engine oil to break down.
• If the ambient temperature is below -16 °C
(+3 °F), rubber components such as gaskets and
seals will harden causing premature engine wear
and damage.
• Contact your authorized Yanmar Marine engine
dealer or distributor if the engine will be operated
outside of this standard temperature range.
NOTICE
Never engage the starter motor while the engine is
running. Damage to the starter motor pinion and/or
ring gear will result.
NOTICE
Any part which is found defective as a result of
inspection, or any part whose measured value does
not satisfy the standard or limit, must be replaced.
NOTICE
Modifications may impair the engine’s safety and
performance characteristics and shorten the
engine’s life. Any alterations to this engine may void
its warranty. Be sure to use Yanmar genuine
replacement parts.
8LV_OPM.book 8 ページ ２０１１年１月１１日 火曜日 午後１２時８分

SAFETY
8LV Series Operation Manual 9
LOCATION OF SAFETY DECALS
Figure 1 and Figure 2 show the location of safety decals on Yanmar 8LV series marine engines.
Figure 1
DO NOT STEP
ON COVERS.
POSSIBILITY
OF A FALL.
119578-07890
CAUTION : Overcranking
engine with water lift
muff l er can cause damage.
128171-07150
456
32
1
037426-00X00
No. Part Number
1 128296-07260
2 128171-07150
3 128296-07300
4 128296-07350
5 196630-12980
6 119578-07890
8LV_OPM.book 9 ページ ２０１１年１月１１日 火曜日 午後１２時８分

SAFETY
10 8LV Series Operation Manual
Figure 2
037427-00X00
12
No. Part Number
1 120324-07240
2 128296-07300
8LV_OPM.book 10 ページ ２０１１年１月１１日 火曜日 午後１２時８分

8LV Series Operation Manual 11
8LV Series Operation Manual
PRODUCT
OVERVIEW
YANMAR 8LV FEATURES AND
APPLICATIONS
The 8LV series are four-stroke direct injection
diesel engines equipped with liquid coolant
systems.
The 8LV series is V-8-cylinder and turbocharged
with an air cooler and equipped a common rail fuel
injection system.
This engine is designed for pleasure craft use.
It is recommended that new vessels be propped so
the engines can operate at 95 % load at 3800 min-1
(rpm).
Failure to do so can lead to reduced vessel
performance, lead to increased smoke levels and
cause permanent damage to your engine.
The engine must be installed correctly with coolant
lines, exhaust gas lines and electrical wiring. Any
auxiliary equipment attached to the engine should
be easy to use and accessible for service. To
handle the drive equipment, propulsion systems
(including the propeller) and other onboard
equipment, always observe the instructions and
cautions given in the operation manuals supplied
by the shipyard and equipment manufacturers.
The 8LV series engines are designed to be
operated at maximum throttle (3600 to 3800 min-1
(rpm)) for less than 5 % of total engine time (30
minutes out of every 10 hours) and cruising speed
(3600 min-1 (rpm) or less) for less than 90 % of
total engine time (9 hours out of every 10 hours).
The laws of some countries may require hull and
engine inspections, depending on the use, size and
cruising area of the boat. The installation, fitting
and surveying of this engine all require specialized
knowledge and engineering skills. See Yanmar’s
local subsidiary in your region or your authorized
Yanmar Marine dealer or distributor.
8LV_OPM.book 11 ページ ２０１１年１月１１日 火曜日 午後１２時８分

PRODUCT OVERVIEW
12 8LV Series Operation Manual
New Engine Break-In
As with all reciprocating engines, the way your
engine is operated during its first 50 hours of
operation plays a very significant role in
determining how long it will last and how well the
engine will perform over its lifetime.
A new Yanmar diesel engine must be operated at
suitable speeds and power settings during the
break-in period to make the sliding parts, such as
piston rings, break-in properly and to stabilize
engine combustion.
During the break-in period, the engine coolant
temperature gauge should be monitored,
temperature should be lower than 80 °C (176 °F).
During the first 10 hours of operation, the engine
should be run at maximum min-1 (rpm) minus 400
to 500 min-1 (rpm) (approximately 60 to 70 % of
load) most of the time. This will ensure the sliding
parts break in properly. During this period, avoid
operating at maximum engine speed and load to
avoid damaging or scoring sliding parts.
NOTICE
Do not operate at WOT (wide open throttle) for
more than a minute at a time during the first
10 hours of operation.
Do not operate the engine at low idle or at low
speed and light load for more than 30 minutes at a
time. Since unburned fuel and engine oil will adhere
to the piston rings when operating at low speeds for
long periods, this will interfere with proper
movement of the rings and the lube oil consumption
may increase. Low idle speed does not allow
break-in of sliding parts.
If operating engine at low speed and light load, you
must rev up the engine (i.e. increase the engine
speed for a short time) to clean the carbon from the
cylinders and fuel injection valve.
Perform this procedure in seawaters:
• With the position of marine gear in NEUTRAL,
accelerate from the low speed position to the high
speed position briefly.
• Repeat this process five times.
Once past the initial 10 hours until 50 hours, the
engine should be used over its full operating range,
with special emphasis on running at relatively high
power settings. This is not the time for an extended
cruise at idle or low speed. The boat should be run
at maximum speed minus 400 min-1 (rpm) most of
the time (approximately 70 % load), with a 10
minute run at maximum minus 300 min-1 (rpm)
(approximately 80 % load) every 30 minutes and a
4 - 5 minute period of operation at WOT (wide open
throttle) once each 30 minutes. During this period,
be sure not to operate your engine at low speed
and light load for more than 30 minutes. If operating
engine at low speed and light load by necessity, just
after the low idle operation, be sure to rev up the
engine.
To complete engine break-in, perform After Initial
50 Hours of Operation maintenance procedures on
page 43.
8LV_OPM.book 12 ページ ２０１１年１月１１日 火曜日 午後１２時８分

PRODUCT OVERVIEW
8LV Series Operation Manual 13
COMPONENT IDENTIFICATION
Service Side
Figure 1 and Figure 2 illustrate a typical version of a 8LV series engine. Your engine may have different
equipment from that illustrated.
Figure 1
Non-Service Side
Figure 2
037423-00E00
Dipstick
Lubricating oil
feeding port
Fuel filter
Fuel oil cooler
Fuel priming pump
Lubricating oil filter
Alternator
Turbo-charger
Mixing elbow
Turbo-charger
Silencer
Silencer
037424-00E00
ECUbox
Heat exchanger
Engine lubricating oil cooler Seawater pump
Air cooler
8LV_OPM.book 13 ページ ２０１１年１月１１日 火曜日 午後１２時８分

PRODUCT OVERVIEW
14 8LV Series Operation Manual
LOCATION OF NAMEPLATE
The nameplate of Yanmar 8LV series engines are
shown in Figure 3. Check the engine’s model,
output, rpm and serial number on the nameplate.
Please replace if damaged or lost.
The engine nameplate is attached to the top
surface of the engine air cooler (Figure 4).
Figure 3
Figure 4
/
/
Gear Model
ENG.No.
MFG. DATE
/
Model
min-1
min-1
min-1
Continuous power kW
Speed of prop. shaft
Fuel stop power kW
129670-07200
037425-00X00
/
/
Gear Model
ENG.No.
MFG. DATE
/
Model
min-1
min-1
min-1
Continuous power kW
Speed of prop. shaft
Fuel stop power kW
8LV_OPM.book 14 ページ ２０１１年１月１１日 火曜日 午後１２時８分
