Yeastar Technology TDM400 User manual

TDM400 Instruction
-1-
Hardware Installation
In order to successfully install the TDM400 card into your PC, please follow these
directions carefully. Otherwise, your hardware maybe will not function properly and
could become damaged.
Steps
1. Power down the PC
2. Unplug the PC from its main AC power supply
3. Insert the TDM400 into a 3.3- or 5-volt PCI slot (PCI 2.2 or greater required)
4. If your card have S2 (FXS) module (Green module), plug the hard disk power supply
cable to power jack.
5. Fix the TDM400 Card, connect the telephone lines.
6. Power on the PC
After following these steps, hardware installation is complete.
TDM400 can install 2 modules S2 (FXS) or O2 (FXO), each one with 2 ports for
connecting more analog telephones.
Red light: it stands for the FXO port.
Green light: it stands for the FXS port.
Port1 Port2 Port3 Port4
+5V(NC)
Ground
Ground
+12V
LED1
LED2
LED3
LED4
Module 2
Position2
S2
Module 1
Position1
O2 Power Jack
PCI 2.2 Slot
Figure 1: TDM400 Modules

TDM400 Instruction
-2-
Standard Package:
TDM400 mother card; Up to 2 daughter modules; 2 line cables and 1 power cable;
TDM400 Instruction.
Warranty: Yeastar is responsible for the quality of all cards and modules. Included
with the purchase of the TDM400 is 30 days of email technology support to get your
card running, 3 years warranty of hardware performance.
Each RJ 11 socket has 6 pins, TDM400 just use the middle 2 pin (3rd and 4th pin) to
connect to you 2-wire telephone line, other pins are not used.
1NC
2NC
3 TIP/RING
4
5NC
6NC
RJ 11 NC means not connect
Figure 2: TDM400 Jacks
Driver Installation river and guide from http://www.yeastar.com If you have any
you want to connect with PBX, TDM400 card’s FXS port should connect to PBX CO
Please download the d
problem about it, please contact us through [e-mail]
If
port and FXO port connect to PBX extension port.
