FLXA402 4-Wire Converter
MODBUS Communication
TI 12A01F01-62EN
TI 12A01F01-62EN
©Copyright Nov. 2018
1st Edition Nov. 2018
2nd Edition Apr. 2019
Yokogawa Electric Corporation
2-9-32, Nakacho, Musashino-shi, Tokyo, 180-8750 Japan
CONTENTS
1. General ....................................................................................................2
1.1 MODBUS setup..................................................................................................2
1.2 MODBUS master................................................................................................3
1.3 Function code/Exception code........................................................................3
1.4 MODBUS communication ................................................................................4
1.5 MODBUS password ..........................................................................................5
1.6 How to change SENCOM SA address.............................................................5
1.7 Connection.........................................................................................................5
2. MODBUS map .........................................................................................6
2.1 COIL: Coil register.............................................................................................7
2.2 INPUT_REGISTER: Input Register ..................................................................8
2.2.1 Status..................................................................................................................9
2.2.2 mA Output, mA Input, Contact Output, Contact Input ..................................... 10
2.2.3 HART............................................................................................................... 10
2.2.4 Script.................................................................................................................11
2.2.5 Converter Alarm ...............................................................................................11
2.2.6 Sensor measured value .................................................................................. 12
2.3 HOLD_REGISTER............................................................................................14
2.3.1 Error setting (0- ).............................................................................................. 14
2.3.2 mA input settings (1700-) ................................................................................ 18
2.3.3 Contact input settings (1800-) ......................................................................... 18
2.3.4 mA output settings (1000-) .............................................................................. 19
2.3.5 Contact output settings (1500-)....................................................................... 21
2.3.6 Display settings (3000-)................................................................................... 22
2.3.7 Display settings Script (3500-)....................................................................... 24
2.3.8 Display settings Trend (3300-)....................................................................... 25
2.3.9 Display settings Others (3400-)..................................................................... 26
2.3.10 Advanced settings MODBUS setting (2100-)................................................ 26
2.3.11 Advanced settings HART setting (2000-)...................................................... 27
2.3.12 Advanced settings Ethernet setting (2200-).................................................. 28
2.3.13 Advanced settings Others setting (4000-)..................................................... 28
2.3.14 MODBUS native (4200-) ................................................................................. 28
2.4 Identication ....................................................................................................29
3. Alarm .....................................................................................................31
3.1 Alarm list (Converter)......................................................................................32
3.2 Alarm list (pH) ..................................................................................................34
3.3 Alarm list (SC)..................................................................................................35
3.4 Alarm list (ISC).................................................................................................36
3.5 Alarm list (DO)..................................................................................................37
Revision Information.....................................................................................38
FLEXA, FLXA, SENCOM and FieldMate are trademarks or registered trademarks of Yokogawa Electric Corporation.
All other company and product names mentioned in this document are trademarks or registered trademarks of their respective companies.

MODBUS Communication 2
TI 12A01F01-62EN
This document describes MODBUS communication by the FLXA402 4-Wire Converter.
Before communicating using the MODBUS protocol, refer to the User’s Manual of the FLXA402
4-Wire Converter (IM 12A01F031-03EN Operation of converter) for details of the parameters.
For latest User’s Manual, download it from our website or scan QR code.
http://www.yokogawa.com/an/xa402/download/
1. General
FLXA402 configures or obtains process data by using MODBUS/TCP protocol on physical
application: Ethernet, RS485.
MODBUS RTU is supported but not ASII.
1.1 MODBUS setup
lEthernet
FLXA402 uses Modbus/TCP, connection port 502.
For MODBUS/TCP, IP address, subnet mask, default gateway or DHCP should be set in
advance from HMI device.
The Ethernet conguration is reected onto the system, after FLXA402 reboots.
lRS485
FLXA402 communicates via RS485 MODBUS.
The following list shows the required setting by HMI to establish communication between a
master device and FLXA402 via RS485 MODBUS.
Converter address: 1 to 247 (initial value 1)
Transmission speed: 9600[bps], 38400[bps], 115200[bps]
Parity : Even, Odd, None
When Parity is Even or Odd, Stop bit is 1bit, when None, Stop bit is 2 bit.
Even or Odd is recommended for Parity.
Stop bit: 1 bit
Parity: Even
Mode: RTU
No. TI 12A01F01-62EN 2nd Edition: Apr. 2019 (YK)
All Rights Reserved. Copyright © 2018, Yokogawa Electric Corporation
Apr. 19, 2019-00

MODBUS Communication 3
TI 12A01F01-62EN
1.2 MODBUS master
lMaintenance
YOKOGAWA FieldMate is recommended for FLXA402 conguration via MODBUS.
FieldMate allows
• easy calibration by handheld FieldMate
• help function to setup temperature comp. table etc.
• remote control via Ethernet
• wide panel operation, larger than FLXA402
lData memory
YOKOGAWA GX series with RS485 MODBUS are recommended for process data saving.
MODBUS communication enables to store larger amount of process data than FLXA402 mA
output.
1.3 Function code/Exception code
MODBUS Function code used for FLXA402
Function Function Code (hex)
Read Coils 01
Write Single Coil 05
Write Multiple Coils 0F
Read Input Register 04
Read Holding Registers 03
Write Single Register 06
Write Multiple Register 10
Read Device Identication 2B
Exception responses
Exception Code Name Meaning
0x01 Illegal Function The Function Code received in the query is not an
allowable action for the server or slave.
0x02 Illegal Data Address The data address received in the query is not an
allowable address for the server or slave.
0x03 Illegal Data Values The value contained in the query data eld is not an
allowable value for the server or slave.
If parameter setting fails because the setting is out of the range, Exception code 0x03 is replied
indicating a fail setting. When multiple parameters are to be set, even a single forbidden setting
makes all the other parameter setting fail.
Apr. 19, 2019-00

MODBUS Communication 4
TI 12A01F01-62EN
1.4 MODBUS communication
The following must be cared when master devices other than FieldMate are used.
lMODBUS response timing
IR (Input Register) response to IR Read request within 50 ms after FLXA402 receives the
message. To the other request, FLXA402 replies within 100 ms after it receives the request.
Another request must be sent at least 100 ms after the last response was received from
FLXA402.
<50ms >100ms <100ms
User
FLXA402
HR RequestIR Request
IR： Input Register
HR： Holding Register
HR ResponseIR Response
lInput Register renewal cycle
Process value sent in Input Register is renewed every 500 ms. It is better to Read the process
value every 500 ms.
lHow to change the setting
• Turn ON Coil register 31 to grant access authority
• Change the Coil/Holding register
• Turn OFF the coil to restrict the access again after the renewal completes.
NOTE
Even if you have no access authority, you can register WASH Start/Stop, WASH Recovery stop.
For other parameters, follow the procedure above. If you try to write the parameters without
access, an error response (Error code 03) is replied.
NOTE
When FLXA402 has access to measured data, you cannot set devices by using HMI or other
devices on the network. Even after FLXA402 loses access, this situation remains unchanged for
3 seconds.
NOTE
When no message comes for 30 seconds from MODBUS master which has access, the access
turns OFF automatically.
Apr. 19, 2019-00

MODBUS Communication 5
TI 12A01F01-62EN
1.5 MODBUS password
Entering password on “MODBUS password” protects parameter setting and prohibits data input
except for “cancel MODBUS password” and “gain access authority.”
To be allowed to input data, go to password setting mode. Enter the password you created for
“cancel MODBUS password” then you are allowed to input.
1.6 How to change SENCOM SA address
SENCOM SA*sensor address are all 1 at the time of purchase. If you try to connect multiple
SENCOM SA before you change the address, the communication fails. When you change
SENCOM SA sensor, you have to connect the SENCOM SA one by one and change the
address.
*: SENCOM SA refers to SA11, some sensors connected to SA11.
SA11 is used when -S5 (SENCOM SA) is specied for FLXA402 1st/2nd input.
1.7 Connection
lEthernet
On the FLXA402 network, Ethernet MODBUS allows 2 sessions.
First session provides communication to Read process value periodically by connecting
constantly.
Second session is for maintenance only when maintenance is required. FieldMate is
recommended for 2nd session.
FLXA402 4-Wire Converter FieldMate
Maintenance
Data recording
GX
Ethernet
HUB
lRS485
FLXA402 communicates with one MODBUS master via RS485 MODBUS. RS485 is connected
constantly and provides communication for reading process value.
FLXA402 4-Wire Converter FieldMate
Maintenance
Data recording
GX
RS485
Bluetooth
NOTE
Although connections other than these mentioned above are available, they might disable
obtaining process value, if Read and setting change are implemented in a single session/
communication.
Apr. 19, 2019-00

MODBUS Communication 6
TI 12A01F01-62EN
2. MODBUS map
Data type for FLXA402 MODBUS map
Data type Denition
oat oating point (4byte)
IEEE754
NaN: 0x7FFFFFFF
int16 16 bit signed integer
uint16 16 bit unsigned integer
uint32 32 bit unsigned integer
ASCII character set (using one byte per
character), multiple registration possible
bit elds data assigning information on bit
Access (load/import) to multiple registration such as oat, uint32, ASCII etc. must be
implemented at once.
Latest revision does not support script, or arithmetic by multiple sensors.
Access
Function Function
Code
(hex)
Data
Access
BIt
Read Coils 01
Write Single Coil 05
Write Multiple Coils 0F
16 bits
Read Input Register 04
Read Holding Registers 03
Write Single Register 06
Write Multiple Register 10
Diagnostics Read Device Identication 2B
Apr. 19, 2019-00

MODBUS Communication 7
TI 12A01F01-62EN
2.1 COIL: Coil register
address item name Value/description
0Reserved all 0
Do not change.
1
2
3
4
5
6
7
30 WRITE_STATUS Read only
Shows access authority.
31 WRITE_FLAG Gains access authority.
Turn ON this coil bit when modifying the setting by
Modbus protocol
50 CONVERTER_RESTART Restarts the converter
51 SQUAWK_SWITCH Starts backlight ashing.
On: Flash Once: After lighting on for 5 sec, automatically
lights o󰀨.
Endless: Light On until cancelling the ash
O󰀨: Stop the ash
52 MA_HOLD_0 mA output manual Hold status
ON: Hold
O󰀨: Hold o󰀨
53 MA_HOLD_1
54 MA_HOLD_2
55 MA_HOLD_3
56 S_MANUAL_WASH_0 Starts manual wash
On: Wash starts (after the wash time elapses, turns o󰀨
automatically)
O󰀨: Cancel Wash. The cancellation switches the mode to
Wash Recovery.
57 S_MANUAL_WASH_1
58 S_MANUAL_WASH_2
59 S_MANUAL_RECOVER_0 The cancellation of Wash switches the mode to Wash
Recovery automatically.
On: Switching to Wash Recovery enables this function
automatically, disabling manual switching from O󰀨
to On. When Wash recovery time elapses, the mode
automatically turns O󰀨.
O󰀨: Exit from Wash Recovery
60 S_MANUAL_RECOVER_1
61 S_MANUAL_RECOVER_2
62 S_ERROR_CANCEL_0 Cancels the error “Expiry time exceeded.”
Cancel the error with “On” then automatically switches
“O󰀨”
63 S_ERROR_CANCEL_1
64 S_ERROR_CANCEL_2
65 S_ERROR_CANCEL_3
66 AD_TOUCH_SCREEN_FLAG HMI of the converter switches from Adjust panel to Touch
panel.
Apr. 19, 2019-00

MODBUS Communication 8
TI 12A01F01-62EN
2.2 INPUT_REGISTER: Input Register
MODBUS address are assigned to parameters of the converter status including AO and HART.
Address from 1000 to 1999 are for the measured value obtained from sensors.
Address Name Comment
0 to 999 Converter Status on Converter, AO, HART. See 2.2.1
through 2.2.5.
1000 to 1063 Sensor 1-1 measured value Input Register for each sensor connection
number. For IR of each sensor type, see
2.2.6.
1100 to 1163 Sensor 1-2 measured value
1200 to 1263 Sensor 1-3 measured value
1300 to 1363 Sensor 1-4 measured value
1400 to 1463 Sensor 2-1 measured value
1500 to 1563 Sensor 2-2 measured value
1600 to 1663 Sensor 2-3 measured value
1700 to 1763 Sensor 2-4 measured value
52017 to 52056 Reserved
Sensor 1-1
Sensor 1-2
Sensor 2-3
Sensor 2-4
PH
SC
ISC
DO
Image of sensor connection
MODBUS address are assigned to designated sensor connection number to input sensor
measured value. Other address, which are not assigned to the sensor connection, shows “0”.
<Example>
When:
Sensor1: PH sensor module, Sensor2: SC sensor module
Sensor connection number 1-1 is PH, Sensor connection number 2-1 is SC.
This time,
Modbus address 1000 to 1023 are assigned to input of measured value from Sensor1 PH sensor
module.
Modbus address 1400 to 1425 are assigned to input of measured value from Sensor2 SC sensor
module.
“0” is read on other address : 1024-1063, 1100-1163, 1200-1263, 1300-1363, 1426-1463, 1500-
1563, 1700-1763.
Apr. 19, 2019-00

MODBUS Communication 9
TI 12A01F01-62EN
2.2.1 Status
address item name Type Value/description
0,1 converter status uint32
(bit elds)
MODBUS status of the converter
bit
0-3 changes at Housing HR setting
4-7 changes at Housing IR renewed
8-29 Reserved
30 Ethernet link up. ON at cable connection
31 Bluetooth link up, “ON” when Bluetooth is connected.
2,3 converter alarm uint32
(bit elds)
Integrated information on alarms of the converter or connected sensors.
See the table of alarms to know the bit assignment.
bit Integrated information on alarms of the converter
0SSA1-1/Analog sensor module1/DO70G Process error(Low)
1SSA1-1/Analog sensor module1/DO70G Process error(High)
2SSA1-2 Process error(Low)
3SSA1-2 Process error(High)
4SSA1-3 Process error(Low)
5SSA1-3 Process error(High)
6SSA1-4 Process error(Low)
7SSA1-4 Process error(High)
8SSA2-1/Analog sensor module2 Process error(Low)
9SSA2-1/Analog sensor module2 Process error(High)
10 SSA2-2 Process error(Low)
11 SSA2-2 Process error(High)
12 SSA2-3 Process error(Low)
13 SSA2-3 Process error(High)
14 SSA2-4 Process error(Low)
15 SSA2-4 Process error(High)
16 Converter setting Alarm on
17 Converter maintenance status on
18 Err on:Script fails on the converter
19 Err on:Calculation fails on the converter
20 Err on: S1 fails on the converter
21 Err on: S2 fails on the converter
22 Err on: S3 fails on the converter
23 Err on: S4 fails on the converter
24 Err on: mA1 fails on the converter
25 Err on: mA2 fails on the converter
26 Err on: mA3 fails on the converter
27 Err on: mA4 fails on the Converter
28 Err on: AI fails on the Converter
29 one of the following sensors is failure.: SSA1-1~2-4 / Analog
sensor (module) 1 or 2 / DO70G
30 Converter (Housing) failure
31 when any problem happens on Housing/SSA (including analog)
4Sensor connec-
tion status
uint16
(bit elds)
Sensor connection status of each Address CH
00: unconnected, 01: being connected,10: connect
bit
0, 1 Address CH1-1
2, 3 Address CH1-2
4, 5 Address CH1-3
6, 7 Address CH1-4
8, 9 Address CH2-1
10, 11 Address CH2-2
12, 13 Address CH2-3
14, 15 Address CH2-4
5,6 Sensor type uint32
(bit elds)
Connected sensor of each Address CH.
0000: none, 0001: PH, 0010: SC, 0011: ISC, 0100: DO, 0101: DO70G
bit
0-3 Address CH1-1
4-7 Address CH1-2
8-11 Address CH1-3
12-15 Address CH1-4
16-19 Address CH2-1
20-23 Address CH2-2
24-27 Address CH2-3
28-31 Address CH2-4
Apr. 19, 2019-00

MODBUS Communication 10
TI 12A01F01-62EN
address item name Type Value/description
7WASH/HOLD
status
uint16
(bit elds)
WASH/HOLD status
HOLD: ON: HOLD
WASH: slave bitON: being washed,
Master bitON: Wash recovering
bit
0-3 Reserved
4mA1_HOLD
5mA2_HOLD
6mA3_HOLD
7mA4_HOLD
8, 9 S1_WASH
10, 11 S2_WASH
12, 13 S3_WASH
14, 15 Reserved
2.2.2 mA Output, mA Input, Contact Output, Contact Input
address item name Type Value/description
8,9 AO_PROCESS_PARAM_1 oat analog output: process parameter
The measured value of process parameter assigned to
mA1 to mA4.
10,11 AO_PROCESS_PARAM_2
12,13 AO_PROCESS_PARAM_3
14,15 AO_PROCESS_PARAM_4
16,17 AO_mA1 oat analog output: current (3.6-22mA)
Output value of mA1 to mA4
18,19 AO_mA2
20,21 AO_mA3
22,23 AO_mA4
24,25 AI_CURRENT oat analog input [mA]
mA input information, conrmable by unit
26,27 AI_TEMP
28,29 AI_PRESSURE
30 CONTACT_INPUT_OUTPUT ushort
(bit
enum)
Contact output, Contact input
bit0: S1
bit1: S2
bit2: S3
bit3: S4
bit4-7: Reserved
bit8: DI1
bit9: DI2
bit10-15: Reserved
2.2.3 HART
address item name Type Value/description
31,32 HART_PV oat HART
Dynamic variables and their unit information
33,34 HART_SV oat
35,36 HART_TV oat
37,38 HART_QV oat
39 HART_UNIT_PV short
40 HART_UNIT_SV short
41 HART_UNIT_TV short
42 HART_UNIT_QV short
Apr. 19, 2019-00

MODBUS Communication 11
TI 12A01F01-62EN
2.2.4 Script
Latest revision does not support script, or arithmetic by multiple sensors.
address item name Type ** Value/description
43,44 SCRIPT_DIFFERENTIAL_PH oat di󰀨erential (pH) *
45,46 SCRIPT_DIFFERENTIAL_ORP oat di󰀨erential (ORP) *
47,48 SCRIPT_DIFFERENTIAL_CON-
DUCT
oat di󰀨erential (CONDUCT) *
49,50 SCRIPT_DIFFERENTIAL_RESIST oat di󰀨erential (RESIST) *
51,52 SCRIPT_DIFFERENTIAL_DO oat di󰀨erential (DO) *
53,54 SCRIPT_AVERAGE_PH oat average (pH) *
55,56 SCRIPT_AVERAGE_ORP oat average (ORP) *
57,58 SCRIPT_AVERAGE_CONDUCT oat average (CONDUCT) *
59,60 SCRIPT_AVERAGE_RESIST oat average (RESIST) *
61,62 SCRIPT_AVERAGE_DO oat average (DO) *
63,64 SCRIPT_RATIO oat ratio *
65,66 SCRIPT_PASSAGE oat passage *
67,68 SCRIPT_REJECTION oat rejection *
69,70 SCRIPT_DEVIATION oat deviation *
71,72 SCRIPT_PH_CALC oat pH calc *
73,74 PROGRAMMED_VALUE_1 oat Script calculation result *
75,76 PROGRAMMED_VALUE_2 oat
77,78 PROGRAMMED_VALUE_3 oat
79,80 PROGRAMMED_VALUE_4 oat
81,82 PROGRAMMED_VALUE_5 oat
83,84 PROGRAMMED_VALUE_6 oat
85,86 PROGRAMMED_VALUE_7 oat
87,88 PROGRAMMED_VALUE_8 oat
2.2.5 Converter Alarm
For bit assignment, see 3.1
address item name Type ** Value/description
500,501 CONVERTER_ALARM_MEASUREMENT ulong
(bit
enum)
See the table of alarms for
bit assignment.
502,503 CONVERTER_ALARM_IO
504,505 CONVERTER_ALARM_MAINTENANCE
506,507 CONVERTER_ALARM_SETTING
Apr. 19, 2019-00

MODBUS Communication 12
TI 12A01F01-62EN
2.2.6 Sensor measured value
lPH
address item name Type Value/description
0device_failure ushort
(bit enum)
See the table of alarms for bit assignment.
1sensor_failure ushort
(bit enum)
2meas_warning ushort
(bit enum)
3device_status ushort
(bit enum)
4, 5 temp_measure oat Temperature
6,7 pH_measure oat pH
8,9 ORP_measure oat ORP
10,11 rH_measure oat rH
12 temp_unit short Temperature unit 1:degC, 2:degF
13 reserved Reserved
14,15 Voltage_pH oat E.M.F (PH: glass electrode - reference electrode)
16,17 Voltage_ORP1 oat E.M.F.(ORP1: Metal electrode - reference electrode)
18,19 Voltage_ORP2 oat E.M.F.(ORP2: Metal electrode - glass electrode)
20,21 impedance1 oat When Impedance is set low, Impedance is shown with Ω,
when it is set high, NaN is shown. If it is set high, alarm
information tells the error presence.
22,23 impedance2 oat
lSC
address item name Type Value/description
0device_failure ushort
(bit enum)
See table of alarms for bit assignment.
1sensor_failure ushort
(bit enum)
2meas_warning ushort
(bit enum)
3device_status ushort
(bit enum)
4,5 temp_measure oat Temperature
6,7 SC1_measure oat Conductivity 1 or Resistivity 1
8,9 SC2_measure oat Conductivity 2 or Resistivity 2
10,11 concentration1 oat Concentration 1
12,13 concentration2 oat Concentration 2
14 temp_unit short Temperature unit 1:degC, 2:degF
15 SC1_unit short Conductivity/Resistivity Unit
1:S/cm, 2:S/m, 3:ohm*cm, 4:ohm*m
16 SC2_unit short
17 concentration1_unit short Concentration Unit
1:%, 2:ppm, 3:ppb, 4:ppt, 5:None
18 concentration2_unit short
19 reserved Reserved
20,21 sensor_ohm oat Resistivity between electrodes of sensors (Ω)
22,23 polarization oat Polarization
24,25 USP oat USP
Apr. 19, 2019-00

MODBUS Communication 13
TI 12A01F01-62EN
lISC
address item name Type Value/description
0device_failure ushort
(bit enum)
See the table of alarms for bit assignment.
1sensor_failure ushort
(bit enum)
2meas_warning ushort
(bit enum)
3device_status ushort
(bit enum)
4,5 temp_measure oat Temperature
6,7 SC1_measure oat Conductivity 1
8,9 SC2_measure oat Conductivity 2
10,11 concentration1 oat Concentration 1
12,13 concentration2 oat Concentration 2
14 temp_unit short Temperature Unit 1:degC, 2:degF
15 SC1_unit short Conductivity Unit
1:S/cm, 2:S/m
16 SC2_unit short
17 concentration1_unit short Concentration Unit
1:%, 2:ppm, 3:ppb, 4:ppt, 5:None
18 concentration2_unit short
19 reserved Reserved
20,21 sensor_ohm oat Measured resistance value (Ω)
lDO
address item name Type Value/description
0sensor_failure ushort
(bit enum)
See the table of alarms for bit assignment.
1meas_warning ushort
(bit enum)
2device_status ushort
(bit enum)
3temp_measure oat
4,5 do_measure oat Temperature
6,7 temp_unit short DO
8do_unit short Temperature Unit 1:degC, 2:degF
9sensor_current oat DO Unit1:mg/l, 2:ppm, 3:ppb, 4:%SAT
10,11 pressure_for_
measure
oat Current measurements (Unt: nA)
12,13 temp_unit short Pressure value
Apr. 19, 2019-00

MODBUS Communication 14
TI 12A01F01-62EN
2.3 HOLD_REGISTER
2.3.1 Error setting (0- )
For further information, see section 4.7 “Error settings” in the User’s Manual IM 12A01F01-03EN
Operation of Converter.
nError settings
See Chapter 3 for bit assignment.
Register (by bit) 4 alarm types :
Measurement alarm, I/O alarm, Maintenance status, Setting error,
according to NE107 :
Failure (F), Function check (S), Out of specication (C), Maintenance required (M), and (O󰀨), (N).
If you assign bit “0” to an alarm , the alarm reads “O󰀨”.
If you assign a bit number to multiple alarms simultaneously, priority in the validity goes
F>S>C>M.
CAUTION
When you want to revise an alarm priority from high to low, rst provide bit “0” with the lower one,
then give “1” to the higher one.
lError settings- Converter
address NE107 item name Type
0,1 FMeasurement alarm uint32
(bit elds)
2,3 I/O alarm
4,5 Mantenance Status
6,7 Setting alarm
8,9 CMeasurement alarm
10,11 I/O alarm
12,13 Mantenance Status
14,15 Setting alarm
16,17 SMeasurement alarm
18,19 I/O alarm
20,21 Mantenance Status
22,23 Setting alarm
24,25 MMeasurement alarm
26,27 I/O alarm
28,29 Mantenance Status
30,31 Setting alarm
Apr. 19, 2019-00

MODBUS Communication 15
TI 12A01F01-62EN
lError settings-sensor
Address NE107 Address NE107 Address NE107 Address NE107 Name Type
32 F48 C64 S80 MPH Device fail uint16
(bit
elds)
33 49 65 81 Sensor status
34 50 66 82 Measure alarm
35 51 67 83 Device status
36 52 68 84 SC Device fail
37 53 69 85 Sensor status
38 54 70 86 Measure alarm
39 55 71 87 Device status
40 56 72 88 ISC Device fail
41 57 73 89 Sensor status
42 58 74 90 Measure alarm
43 59 75 91 Device status
44 60 76 92 DO Device fail
45 61 77 93 Sensor status
46 62 78 94 Measure alarm
47 63 79 95 Device status
nError simulation
Simulate the following 4 alarms and output (Error simulate) by the bit.
Measure alarm
I/O alarm
Maintenance status
Setting alarm
ERROR: Provide the alarms with simulated alarm status by bit.
(1: Error on, 0: Error o󰀨)
MODE: Dene alarms to simulate by bit.
(1: Error simulate ON, 0: Error simulate OFF)
lConverter error simulation
Address Nane Type
100, 101 MODE Measurement alarm uint32
(bit elds)
102, 103 I/O alarm
104, 105 Mantenance Status
106, 107 Setting alarm
108, 109 ALARM Measurement alarm
110, 111 I/O alarm
112, 113 Mantenance Status
114, 115 Setting alarm
Apr. 19, 2019-00

MODBUS Communication 16
TI 12A01F01-62EN
lSensor error simulation (mode)
Address
Connection
number
Address
Connection
number
Address
Connection
number
Address
Connection
number
Name Type
200 1-1 216 1-2 232 1-3 248 1-4 PH Device fail uint16
(bit
elds)
201 217 233 249 Sensor status
202 218 234 250 Measure alarm
203 219 235 251 Device status
204 220 236 252 SC Device fail
205 221 237 253 Sensor status
206 222 238 254 Measure alarm
207 223 239 255 Device status
208 224 240 256 ISC Device fail
209 225 241 257 Sensor status
210 226 242 258 Measure alarm
211 227 243 259 Device status
212 228 244 260 DO Device fail
213 229 245 261 Sensor status
214 230 246 262 Measure alarm
215 231 247 263 Device status
264 2-1 280 2-2 296 2-3 312 2-4 PH Device fail
265 281 297 313 Sensor status
266 282 298 314 Measure alarm
267 283 299 315 Device status
268 284 300 316 SC Device fail
269 285 301 317 Sensor status
270 286 302 318 Measure alarm
271 287 303 319 Device status
272 288 304 320 ISC Device fail
273 289 305 321 Sensor status
274 290 306 322 Measure alarm
275 291 307 323 Device status
276 292 308 324 DO Device fail
277 293 309 325 Sensor status
278 294 310 326 Measure alarm
279 295 311 327 Device status
Nov. 26, 2018-01

MODBUS Communication 17
TI 12A01F01-62EN
lSensor error simulation
Address
Connection
number
Address
Connection
number
Address
Connection
number
Address
Connection
number
Name Type
400 1-1 416 1-2 432 1-3 448 1-4 PH Device fail uint16
(bit
elds)
401 417 433 449 Sensor status
402 418 434 450 Measure alarm
403 419 435 451 Device status
404 420 436 452 SC Device fail
405 421 437 453 Sensor status
406 422 438 454 Measure alarm
407 423 439 455 Device status
408 424 440 456 ISC Device fail
409 425 441 457 Sensor status
410 426 442 458 Measure alarm
411 427 443 459 Device status
412 428 444 460 DO Device fail
413 429 445 461 Sensor status
414 430 446 462 Measure alarm
415 431 447 463 Device status
464 2-1 480 2-2 496 2-3 512 2-4 PH Device fail
465 481 497 513 Sensor status
466 482 498 514 Measure alarm
467 483 499 515 Device status
468 484 500 516 SC Device fail
469 485 501 517 Sensor status
470 486 502 518 Measure alarm
471 487 503 519 Device status
472 488 504 520 ISC Device fail
473 489 505 521 Sensor status
474 490 506 522 Measure alarm
475 491 507 523 Device status
476 492 508 524 DO Device fail
477 493 509 525 Sensor status
478 494 510 526 Measure alarm
479 495 511 527 Device status
Apr. 19, 2019-00

MODBUS Communication 18
TI 12A01F01-62EN
2.3.2 mA input settings (1700-)
Address Parameter Type Description
1700 Type int16 None(0), Current(1), Temperature(2),
Pressure(3)
1701, 1702 Temperature 4mA oat -40~260
1703, 1704 20mA oat -40~260
1705, 1706 Pressure 4mA oat 0.0~999.9
1707, 1708 20mA oat 0.0~999.9
1709, 1710 Damping time oat 0~3600
1711, 1712 AI upper limit oat 3.8~20.5 (Upper limit > Lower limit)
1713, 1714 AI lower limit oat 3.8~20.5 (Upper limit > Lower limit)
1715 Pressure Comp. int16 Disabled(0), Enabled(1)
2.3.3 Contact input settings (1800-)
Address Parameter Type Description
1800 Contact input1 Contact input
Type
int16 Disabled(0), Contact input Wash(1), Contact
input change range(2)
1801 Contact input
Wash
int16 S1(0), S2(1), S3(2)
1802 Contact input
change range
int16 mA1(1), mA2(2), mA3 (Ad)(3), mA4 (Ad)(4)
1803 Contact input2
(Ad)
Contact input
Type
int16 Disabled(0), Contact input Wash(1), Contact
input change range(2)
1804 Contact input
Wash
int16 S1(0), S2(1), S3(2)
1805 Contact input
change range
int16 mA1(1), mA2(2), mA3(3), mA4(4)
Apr. 19, 2019-00

MODBUS Communication 19
TI 12A01F01-62EN
2.3.4 mA output settings (1000-)
Address Parameter Type Description
mA1 mA2 mA3(Ad) mA4(Ad) mA#: # refers to 1 to 4.
1000 1105 1210 1315 mA# int16 Output(0), Simulate(1), O󰀨(2)
1001 1106 1211 1316 mA#
(output)
Process
parameter
int16 pH(0), Temperature(1), ORP(2), rH(3),
Conductivity-TC1(4), Conductivity-
TC2(5), Resistivity-TC1(6), Resistivity-
TC2(7), Concentration-TC1(8),
Concentration-TC2(9), Oxygen(10),
Di󰀨erential pH(11), Di󰀨erential
ORP(12), Di󰀨erential CONDUCT(13),
Di󰀨erential RESIST(14), Di󰀨erential
DO(15), Average pH(16), Average
ORP(17), Average CONDUCT(18),
Average RESIST(19), Average
DO(20), Ratio(21), Passage(%)(22),
Rejection(%)(23), Deviation(%)(24),
pH calc.(VGB)(25), AI(26), Script1(27),
Script2(28), Script3(29), Script4(30),
Script5(31), Script6(32), Script7(33),
Script8(34)
1002 1107 1212 1317 Process
parameter slot
int16 Sensor1-1(0), Sensor1-2(1),
Sensor1-3(2), Sensor1-4(3),
Sensor2-1(4), Sensor2-2(5),
Sensor2-3(6), Sensor2-4(7),
Converter(8)
1003 1108 1213 1318 Output setup int16 Linear(0), Table(1)
1004, 1005 1109, 1110 1214, 1215 1319, 1320 Linear 0% oat arbitrary
1006, 1007 1111, 1112 1216, 1217 1321, 1322 Linear 100% oat arbitrary
1008, 1009 1113, 1114 1218, 1219 1323, 1324 Sub linear 0% oat arbitrary
1010, 1011 1115, 1116 1220, 1221 1325, 1326 Sub linear
100%
oat arbitrary
1012 1117 1222 1327 Burn int16 O󰀨(0), Low(1), High(2)
1013, 1014 1118, 1119 1223, 1224 1328, 1329 Damping time oat 0~3600
1015, 1016 1120, 1121 1225, 1226 1330, 1331 mA#
(simulate)
Simulation % oat -11.25~112.5
1017 1122 1227 1332
mA#
(Congure
Hold)
Last or Fixed int16 Last(0), Fixed(1)
1018, 1019 1123, 1124 1228, 1229 1333, 1334 Fixed value mA oat 2.2~22.0
1020 1125 1230 1335 Hold during
calibration
int16 Disabled(0), Enabled(1)
Apr. 19, 2019-00

MODBUS Communication 20
TI 12A01F01-62EN
l21point- mA Output
mA1 mA2 Type value *1
Position Value Position Value Position Value
point 1. 1021, 1022 1063, 1064 1126, 1127 1168, 1169 oat 0
point 2. 1023, 1024 1065, 1066 1128, 1129 1170, 1171
point 3. 1025, 1026 1067, 1068 1130, 1131 1172, 1173
point 4. 1027, 1028 1069, 1070 1132, 1133 1174, 1175
point 5. 1029, 1030 1071, 1072 1134, 1135 1176, 1177
point 6. 1031, 1032 1073, 1074 1136, 1137 1178, 1179
point 7. 1033, 1034 1075, 1076 1138, 1139 1180, 1181
point 8. 1035, 1036 1077, 1078 1140, 1141 1182, 1183
point 9. 1037, 1038 1079, 1080 1142, 1143 1184, 1185
point 10. 1039, 1040 1081, 1082 1144, 1145 1186, 1187
point 11. 1041, 1042 1083, 1084 1146, 1147 1188, 1189
point 12. 1043, 1044 1085, 1086 1148, 1149 1190, 1191
point 13. 1045, 1046 1087, 1088 1150, 1151 1192, 1193
point 14. 1047, 1048 1089, 1090 1152, 1153 1194, 1195
point 15. 1049, 1050 1091, 1092 1154, 1155 1196, 1197
point 16. 1051, 1052 1093, 1094 1156, 1157 1198, 1199
point 17. 1053, 1054 1095, 1096 1158, 1159 1200, 1201
point 18. 1055, 1056 1097, 1098 1160, 1161 1202, 1203
point 19. 1057, 1058 1099, 1100 1162, 1163 1204, 1205
point 20. 1059, 1060 1101, 1102 1164, 1165 1206, 1207
point 21. 1061, 1062 1103, 1104 1166, 1167 1208, 1209 100
mA3(Ad) mA4(Ad) Type value *1
Position Value Position Value Position Value
point 1. 1231, 1232 1273, 1274 1336, 1337 1378, 1379 oat 0
point 2. 1233, 1234 1275, 1276 1338, 1339 1380, 1381
point 3. 1235, 1236 1277, 1278 1340, 1341 1382, 1383
point 4. 1237, 1238 1279, 1280 1342, 1343 1384, 1385
point 5. 1239, 1240 1281, 1282 1344, 1345 1386, 1387
point 6. 1241, 1242 1283, 1284 1346, 1347 1388, 1389
point 7. 1243, 1244 1285, 1286 1348, 1349 1390, 1391
point 8. 1245, 1246 1287, 1288 1350, 1351 1392, 1393
point 9. 1247, 1248 1289, 1290 1352, 1353 1394, 1395
point 10. 1249, 1250 1291, 1292 1354, 1355 1396, 1397
point 11. 1251, 1252 1293, 1294 1356, 1357 1398, 1399
point 12. 1253, 1254 1295, 1296 1358, 1359 1400, 1401
point 13. 1255, 1256 1297, 1298 1360, 1361 1402, 1403
point 14. 1257, 1258 1299, 1300 1362, 1363 1404, 1405
point 15. 1259, 1260 1301, 1302 1364, 1365 1406, 1407
point 16. 1261, 1262 1303, 1304 1366, 1367 1408, 1409
point 17. 1263, 1264 1305, 1306 1368, 1369 1410, 1411
point 18. 1265, 1266 1307, 1308 1370, 1371 1412, 1413
point 19. 1267, 1268 1309, 1310 1372, 1373 1414, 1415
point 20. 1269, 1270 1311, 1312 1374, 1375 1416, 1417
point 21. 1271, 1272 1313, 1314 1376, 1377 1418, 1419 100
*1: Percentage is monotonic increase. Setting range is 0-100 %.but point1 is xed to 0 %, point 21 is xed to 100 %.
OUtput value is either monotonic increase or decrease. Setting range is arbitrary.
Apr. 19, 2019-00
