FLXA402 4-Wire Converter
HART Communication
TI 12A01F01-61EN
TI 12A01F01-61EN
©Copyright Nov. 2018
1st Edition Nov. 2018
Yokogawa Electric Corporation
2-9-32, Nakacho, Musashino-shi, Tokyo, 180-8750 Japan
FLEXA, FLXA, SENCOM and FieldMate are registered trademarks of Yokogawa Electric Corporation.
Contents
1. Outline......................................................................................................2
1.1 DownloadingandinstallingDDles...............................................................2
1.2 Functions Available via HART Communication.............................................3
1.2.1 Multi-drop mode .................................................................................................4
1.2.2 Write protection ..................................................................................................4
1.2.3 Device Variable Code.........................................................................................5
1.2.4 Diagnostics Command (Command 48)..............................................................6
1.3 Precaution ........................................................................................................10
2. DD Menu Structure (Device revision 1, DD revision 1) ................11
2.1 Online menu.....................................................................................................11
2.1.1 process_variables_root_menu........................................................................ 12
2.1.2 diagnostic_root_menu..................................................................................... 16
2.1.3 maintenance_root_menu ................................................................................ 17
2.1.4 device_root_menu........................................................................................... 23
2.2 O󰀪ine ...............................................................................................................35
Revision Information.....................................................................................37

HART Communication 2
TI 12A01F01-61EN Nov. 20, 2018-00
This document describes HART communication by FLXA402 4-Wire Converter.
Before communicating using the HART protocol, refer to the User’s Manual for the FLXA402
4-Wire Converter Operation of Converter IM 12A01A03-01EN for details of the parameters.
For latest User’s Manual, download it from our website or scan QR code.
http://www.yokogawa.com/an/xa402/download/
1. General
HART Communication superimposes specic waveforms called HART Communication
waveforms on the 4–20 mA analog signal from a FLXA402 to enable remote intercommunication
between the online FLXA402 and a setup tool (*).
*: FieldMate, Plant Resource Manager (PRM), or a handheld HART communicator may be used as the setup tool.
Note: When using FieldMate or a 375 Field Communicator, make sure you use the following or greater version of the product.
FieldMate R3.04.00 + Device Files R3.09.00
HART is a registered trademark of FIELD COMM GROUP. https://www.eldcommgroup.org/
1.1 InstallingDDles
To enable HART communication between a FLXA402 and setup tool, the device description
(DD) le of the FLXA402 needs to be installed in the setup tool. The DD le contains the HART
communication details and menu congurations specic to the FLXA402.
FieldMate is provided with the latest versions of DD les at the time when sold. The current
version of DD les can be downloaded from the following site (*):
YOKOGAWA : http://www.yokogawa.com/an/download/an-dl-eldbus-001en.htm
(*): The URL s is subject to change without prior notice. If the URL cannot be accessed, consult your nearest sales o󰀩ce or the
agency from which you purchased the product.
nBefore using FieldMate
Before using FieldMate, check the revision of Device Files.
CompatibilityamongrevisionsofFLXA402,FieldMateandDDle
HOUSING ASSY FieldMate
Software revision Device revision Revision of Device
Files
1.01.01 or later 1R3.09 or later
The software revision and the device revision are shown on the display of FLXA402
Main or Home screen which is introduced by pressing the Detail. (Figure 1)
Revision of FLXA402
Device revision for HART
Figure 1Software Revision
Nov. 20, 2018-00
No. TI 12A01F01-61EN 1st Edition : Nov. 2018(YK)
All Rights Reserved. Copyright © 2018, Yokogawa Electric Corporation

HART Communication 3
TI 12A01F01-61EN Nov. 20, 2018-00
nInstalling DD File
For how to install the DD le, see the respective documentation for the setup tool you use.
For FieldMate R3.04.00+Device Files R3.09.00, installing DD File is not required.
nConnecting Setup Tool
Connect HART modem at the both ends of the load resistance which is 250 ohms or larger and is
installed between the setup tool terminals and mA1.
You can connect the setup tool to any interconnection terminals such as those in the central
control room, a converter’s junction box, or somewhere within the transmission loop.
1.2 Functions Available via HART
Communication
FLXA402 via Hart communication enables the following settings: Error settings (4.7), mA output
settings (4.3), Contact input settings (4.2), HART setting (4.6.2). Information on the sensor
settings or calibration are available as Read only. The numbers in the parentheses correspond
the section number in the User’s Manual IM 12A01F01-03EN.
Correspondences between menu structure and FLXA402 front panel display
+– Converter Menu ……… Shows the information of the Slot 1 sensor in FLXA402
+– HOLD ……… Enables Manual HOLD
+– WASH ……… Not operational
+– Detail ……… Read only
+– Trend ……… Disables reference
+– Other ……… Disables reference
+– Reset ……… Disables reference
+– Setting ……… Setting changeable: ma Output, ma Input, HART
+– Lang ……… Disables reference
+– Alarm ……… Disables reference
+– sensor Menu ……… Displays information of sensors on Slot1
+– Detail ……… Read only
+– Calibration ……… Not executable
+– Reset Wellness ……… Not executable
+– Reset ……… Not executable
+– Setting ……… Read only
Nov. 20, 2018-00

HART Communication 4
TI 12A01F01-61EN Nov. 20, 2018-00
1.2.1 Multi-drop mode
Multiple number of eld devices put in multi-drop mode can be connected in parallel on a single
cable. To enable the multi-drop mode, set the device address to a unique number from 1 to 63.
NOTE
Multi-drop mode communication requires the devices on the link to be given unique device
addresses for polling (polling addresses). If the same address is set in two or more devices,
correct communication is disabled.
Canceling multi-drop mode:
To release a device from the multi-drop mode, set the polling address to zero.
1.2.2 Write protection
Turning the slide switches ON disables the setting via HART communication (default: OFF).
If you create a password at "Setting" on the display, it protects HART setting, disabling writing
over HART parameters. See 1.3 in IM 12A01F01-03EN Operation of Converter
1
ON
2
Front view with the front panel opened
Reboot switch
(Do not use it)
Slide switch
(for HART only)
Figure 2 FLXA402
CAUTION
Slide switch 1 is for HART. DO NOT turn ON the Slide switch 2.
CAUTION
DO NOT push the button switch next to the Slide switches, when they are set to ON/OFF.
Nov. 20, 2018-00

HART Communication 5
TI 12A01F01-61EN Nov. 20, 2018-00
1.2.3 Device Variable Code
Use Device Variable Code for FLXA402 to set device variables from SV to QV.or to Read
process values on Command 9.
Code Name PV SV TV QV Code Name PV SV TV QV
0AO1 current*1 - X X X 25 Temp 1-1 XXXX
1AI XXXX 26 pH 1-1 XXXX
2Di󰀨erential pH XXXX* 27 ORP 1-1 XXXX
3Di󰀨erential ORP XXXX* 28 rH 1-1 XXXX
4Di󰀨erential Conduct XXXX* 29 Sensor mV1 1-1 - X X X
5Di󰀨erential Resist XXXX* 30 Sensor mV2 1-1 - X X X
6Di󰀨erential DO XXXX* 31 Sensor mV3 1-1 - X X X
7Average pH XXXX* 32 Conduct1 1-1 XXXX
8Average ORP XXXX* 33 Conduct2 1-1 XXXX
9Average Conduct XXXX* 34 Resist1 1-1 XXXX
10 Average Resist XXXX* 35 Resist2 1-1 XXXX
11 Average DO XXXX* 36 Concent1 1-1 XXXX
12 Ratio XXXX* 37 Concent2 1-1 XXXX
13 Passage XXXX* 38 USP 1-1 - X X X
14 Rejection XXXX* 39 Sensor Ohms 1-1 - X X X
15 Deviation XXXX* 40 Oxygen 1-1 XXXX
16 pH calc XXXX* 41 Sensor current 1-1 - X X X
17 Script 1 XXXX*
18 Script 2 XXXX*
19 Script 3 XXXX*
20 Script 4 XXXX*
21 Script 5 XXXX*
22 Script 6 XXXX*
23 Script 7 XXXX*
24 Script 8 XXXX*
42 Temp 2-1 XXXX 59 Temp 1-2 XXXX
43 pH 2-1 XXXX 60 pH 1-2 XXXX
44 ORP 2-1 XXXX 61 ORP 1-2 XXXX
45 rH 2-1 XXXX 62 rH 1-2 XXXX
46 Sensor mV1 2-1 - X X X 63 Sensor mV1 1-2 - X X X
47 Sensor mV2 2-1 - X X X 64 Sensor mV2 1-2 - X X X
48 Sensor mV3 2-1 - X X X 65 Sensor mV3 1-2 - X X X
49 Conduct1 2-1 XXXX 66 Conduct1 1-2 XXXX
50 Conduct2 2-1 XXXX 67 Conduct2 1-2 XXXX
51 Resist1 2-1 XXXX68 Resist1 1-2 XXXX
52 Resist2 2-1 XXXX 69 Resist2 1-2 XXXX
53 Concent1 2-1 XXXX 70 Concent1 1-2 XXXX
54 Concent2 2-1 XXXX 71 Concent2 1-2 XXXX
55 USP 2-1 - X X X 72 USP 1-2 - X X X
56 Sensor Ohms 2-1 - X X X 73 Sensor Ohms 1-2 - X X X
57 Oxygen 2-1 XXXX 74 Oxygen 1-2 XXXX
58 Sensor current 2-1 - X X X 75 Sensor current 1-2 - X X X
76 Temp 1-3 XXXX 93 Temp 1-4 XXXX
77 pH 1-3 XXXX 94 pH 1-4 XXXX
78 ORP 1-3 XXXX 95 ORP 1-4 XXXX
79 rH 1-3 XXXX 96 rH 1-4 XXXX
80 Sensor mV1 1-3 - X X X 97 Sensor mV1 1-4 - X X X
81 Sensor mV2 1-3 - X X X 98 Sensor mV2 1-4 - X X X
82 Sensor mV3 1-3 - X X X 99 Sensor mV3 1-4 - X X X
83 Conduct1 1-3 XXXX 100 Conduct1 1-4 XXXX
84 Conduct2 1-3 XXXX 101 Conduct2 1-4 XXXX
85 Resist1 1-3 XXXX 102 Resist1 1-4 XXXX
86 Resist2 1-3 XXXX 103 Resist2 1-4 XXXX
87 Concent1 1-3 XXXX 104 Concent1 1-4 XXXX
88 Concent2 1-3 XXXX 105 Concent2 1-4 XXXX
89 USP 1-3 - X X X 106 USP 1-4 - X X X
90 Sensor Ohms 1-3 - X X X 107 Sensor Ohms 1-4 - X X X
91 Oxygen 1-3 XXXX 108 Oxygen 1-4 XXXX
92 Sensor current 1-3 - X X X 109 Sensor current 1-4 - X X X
X congurable - not congurable
*Only (NaN) is displayed currently.

HART Communication 6
TI 12A01F01-61EN Nov. 20, 2018-00
FLXA402 use the following extended Units code for each unit
Unit Unit Code
rH 240
S/m 241
µS/m 242
S/cm 243
Ohm m 244
MOhm m 245
%SAT 247
1.2.4 Diagnostics Command (Command 48)
HART Status Group CMD48
byte bit HART Alarm Name Alarm
Number NE107
Device Status - 0 PV Out of Limit - S
1Non-PV Out of Limit - S
2Loop Current Saturated - S
3Loop Current Fixed - N
4More Status Available - N
5Cold Start - N
6Conguration Changed - N
7Device Malfunction - N
Device Specic Status 0 0 0 Hardware failure 001 F
1Internal com. error 002 F
2IO mod. param. read error 003 F
3Com. mod. param. read error 004 F
4CPU param. read error 005 F
5Reserved 006 N
6Reserved 007 N
7Reserved 008 N
Device Specic Status 1 1 0 VGB calc. error 009 F
1Ratio calc. error 010 F
2Passage calc. error 011 F
3Rejection calc. error 012 F
4Deviation calc. error 013 F
5Script error 014 N
6Reserved 015 N
7Reserved 016 N
Device Specic Status 2 2 0 mA1 output burn out 017 F
1mA2 output burn out 018 F
2mA3 output burn out 019 F
3mA4 output burn out 020 F
4mA1 saturation 021 S
5mA2 saturation 022 S
6mA3 saturation 023 S
7mA4 saturation 024 S
Device Specic Status 3 3 0 AI exceeds limit 025 S
1AI out of range 026 F
2Expiry time exceeded 027 M
3Reserved N
4Wash response failure 029 M
5Reserved N
6Converter Error Simulation 031 C
7Fail safe occur 032 F

HART Communication 7
TI 12A01F01-61EN Nov. 20, 2018-00
HART Status Group CMD48
byte bit HART Alarm Name Alarm
Number NE107
Device Specic Status 4 4 0 Simulated mA value 1 033 C
1Simulated mA value 2 034 C
2Simulated mA value 3 035 C
3Simulated mA value 4 036 C
4Outputs in HOLD1 037 N
5Outputs in HOLD2 038 N
6Outputs in HOLD3 039 N
7Outputs in HOLD4 040 N
Device Specic Status 5 5 0 Output conguration error 041 F
1Other conguration error 042 C
2Reserved 043 N
3Reserved 044 N
4Reserved 045 N
5Reserved 046 N
6Reserved 047 N
7Reserved 048 N
Extended Device Status 6 0 Maintenance Required(NE107: M) - N
1Device Variable Alert *1 - S
2Critical Poew Failure F
3Failure (NE107: F) - N
4Out of Specication (NE107: S) - N
5Function Check (NE107: C) - N
6Reserved N
7Reserved N
Device Operationg Mode 7 0 Reserved N
1Reserved N
2Reserved N
3Reserved N
4Reserved N
5Reserved N
6Reserved N
7Reserved N
Standardized Status0 8 0 Device Variable Simulation Active C
1Non-Volatile Memory Defect F
2Volatile Memory Defect F
3Watchdog Reset Executed F
4Power Supply Conditions Out of Range S
5Environmental Conditions Out of Range S
6Electronic Defect F
7Device Conguration Locked - N
Standardized Status1 9 0 Status Simulation Active - N
1Discrete Variable Simulation Active - C
2Event Notication Overow N
3Reserved N
4Reserved N
5Reserved N
6Reserved N
7Reserved N
Analog Channel
Saturated
10 0Analog Channel 1 N
1Analog Channel 2 N
2Analog Channel 3 N
3Analog Channel 4 N
4Reserved N
5Reserved N
6Reserved N
7Reserved N

HART Communication 8
TI 12A01F01-61EN Nov. 20, 2018-00
HART Status Group CMD48
byte bit HART Alarm Name Alarm
Number NE107
Standardized Status2 11 0Sub-Device List Changed N
1Duplicate master Detected. N
2Reserved N
3Reserved N
4Reserved N
5Reserved N
6Reserved N
7Reserved N
Standardized Status2
for Wireless HART
12 0Reserved N
1Reserved N
2Reserved N
3Reserved N
4Reserved N
5Reserved N
6Reserved N
7Reserved N
Analog Channel Fixed 13 0Analog Channel 1 N
1Analog Channel 2 N
2Analog Channel 3 N
3Analog Channel 4 N
4Reserved N
5Reserved N
6Reserved N
7Reserved N
Device Specic Status 6 14 0Sensor 1-1 device failure 101 F
1Sensor 1-2 device failure 201 F
2Sensor 1-3 device failure 301 F
3Sensor 1-4 device failure 401 F
4Sensor 2-1 device failure 501 F
5Reserved 601 N
6Reserved 701 N
7Reserved 801 N
Device Specic Status 7 15 0Sensor 1-1 conguration error 102 F
1Sensor 1-2 conguration error 202 F
2Sensor 1-3 conguration error 302 F
3Sensor 1-4 conguration error 402 F
4Sensor 2-1 conguration error 502 F
5Reserved 602 N
6Reserved 702 N
7Reserved 802 N
Device Specic Status 8 16 0Temp. 1-1 exceeds user limit 103 S
1Temp. 1-2 exceeds user limit 203 S
2Temp. 1-3 exceeds user limit 303 S
3Temp. 1-4 exceeds user limit 403 S
4Temp. 2-1 exceeds user limit 503 S
5Reserved 603 N
6Reserved 703 N
7Reserved 803 N
Device Specic Status 9 17 Process 1-1 exceeds user limit 104 S
1Process 1-2 exceeds user limit 204 S
2Process 1-3 exceeds user limit 304 S
3Process 1-4 exceeds user limit 404 S
4Process 2-1 exceeds user limit 504 S
5Reserved 604 N
6Reserved 704 N
7Reserved 804 N

HART Communication 9
TI 12A01F01-61EN Nov. 20, 2018-00
HART Status Group CMD48
byte bit HART Alarm Name Alarm
Number NE107
Device Specic Status 10 18 0Sensor 1-1 measurement warning 105 N
1Sensor 1-2 measurement warning 205 N
2Sensor 1-3 measurement warning 305 N
3Sensor 1-4 measurement warning 405 N
4Sensor 2-1 measurement warning 505 N
5Reserved 605 N
6Reserved 705 N
7Reserved 805 N
Device Specic Status 11 19 0Sensor 1-1 out of spec. 106 S
1Sensor 1-2 out of spec. 206 S
2Sensor 1-3 out of spec. 306 S
3Sensor 1-4 out of spec. 406 S
4Sensor 2-1 out of spec. 506 S
5Reserved 606 N
6Reserved 706 N
7Reserved 806 N
Device Specic Status 12 20 0Sensor 1-1 warning 107 N
1Sensor 1-2 warning 207 N
2Sensor 1-3 warning 307 N
3Sensor 1-4 warning 407 N
4Sensor 2-1 warning 507 N
5Reserved 607 N
6Reserved 707 N
7Reserved 807 N
Device Specic Status 13 21 0Sensor 1-1 disable 108 F
1Sensor 1-2 disable 208 F
2Sensor 1-3 disable 308 F
3Sensor 1-4 disable 408 F
4Sensor 2-1 disable 508 F
5Reserved 608 N
6Reserved 708 N
7Reserved 808 N
Device Specic Status 14 22 0Reserved N
1Reserved N
2Reserved N
3Reserved N
4Reserved N
5Reserved N
6Reserved N
7Reserved N
Device Specic Status 15 23 0Reserved N
1Reserved N
2Reserved N
3Reserved N
4Reserved N
5Reserved N
6Reserved N
7Reserved N
Device Specic Status 16 24 0Reserved N
1Reserved N
2Reserved N
3Reserved N
4Reserved N
5Reserved N
6Reserved N
7Reserved N
*: Reserved is xed 0.

HART Communication 10
TI 12A01F01-61EN Nov. 20, 2018-00
1.3 Precaution
lSetting on the FLXA402 and a setup tool
HART/MODBUS network/the panel operation, they cannot be established simultaneously to
change the setting of FLXA402.
During the panel operation or the setting via MODBUS network, establishing HART connection
issues a fail.
We recommend mA output to be on Manual Hold status while you are changing the setting.
(See 3.7 Hold operation (manual Hold) on IM 12A01F01-03EN Operation of Converter.
lAccess to parameters (Printout, Up/Download of parameters)
The large number of parameters are congured in FLXA402. Therefore, it may take several
minutes to carry our operation by using a lot of parameters.
lNote on Display
Update the menu display whenever the setting of FLXA402 is revised.

HART Communication 11
TI 12A01F01-61EN Nov. 20, 2018-00
2. DD Menu Structure (Device revision 1, DD revision 1)
2.1 Online menu
process_variables_root_menu
device_root_menu
diagnostic_root_menu
maintenance_root_menu

HART Communication 12
TI 12A01F01-61EN Nov. 20, 2018-00
2.1.1 process_variables_root_menu
Process variables
root menu Dynamic variables
PV
PV % rnge
SV
TV
QV
PV is
SV is
TV is
QV is
Device variables
CH1-1
Sensor type
PH sensor
pH 1-1
ORP 1-1
rH 1-1
Temp 1-1
Sensor mV1 1-1
Sensor mV2 1-1
Sensor mV3 1-1
SC sensor
Conduct1 1-1
Conduct2 1-1
Resist1 1-1
Resist2 1-1
Temp1-1
Concent1 1-1
Concent2 1-1
USP 1-1
Sensor ohms 1-1
ISC sensor
Conduct1 1-1
Conduct2 1-1
Temp1-1
Sensor ohms 1-1
DO sensor
Oxygen1-1
Temp 1-1
Sensor current 1-1
CH1-2 …
CH1-3 …
CH1-4 …
CH2-1 …
Converter
AO1 current
AI
Di󰀨erential pH
Di󰀨erential ORP
Di󰀨erential Conduct
Di󰀨erential Resist
Di󰀨erential DO
Average pH
Average ORP

HART Communication 13
TI 12A01F01-61EN Nov. 20, 2018-00
Average Conduct
Average Resist
Average DO
Ratio
Passage
Rejection
Deviation
pH calc
Script 1
Script 2
Script 3
Script 4
Script 5
Script 6
Script 7
Script 8
Dynamic variables
status
PV quality
PV limit
SV quality
SV limit
TV quality
TV limit
QV quality
QV limit
Device variables
status
CH1-1
PH sensor
pH 1-1 quality
pH 1-1 limit
ORP 1-1 quality
ORP 1-1 limit
rH 1-1 quality
rH 1-1 limit
Temp 1-1 quality
Temp 1-1 limit
Sensor mV1 1-1 quality
Sensor mV1 1-1 limit
Sensor mV2 1-1 quality
Sensor mV2 1-1 limit
Sensor mV3 1-1 quality
Sensor mV3 1-1 limit
SC sensor
Conduct1 1-1 quality
Conduct1 1-1 limit
Conduct2 1-1 quality
Conduct2 1-1 limit
Resist1 1-1 quality
Resist1 1-1 limit
Resist2 1-1 quality
Resist2 1-1 limit
Temp 1-1 quality
Temp 1-1 limit
Concent1 1-1 quality
Concent1 1-1 limit
Concent2 1-1 quality
Concent2 1-1 limit
USP 1-1 quality

HART Communication 14
TI 12A01F01-61EN Nov. 20, 2018-00
USP 1-1 limit
Sensor Ohms 1-1 quality
Sensor Ohms 1-1 limit
ISC sensor
Conduct1 1-1 quality
Conduct1 1-1 limit
Conduct2 1-1 quality
Conduct2 1-1 limit
Temp 1-1 quality
Temp 1-1 limit
Sensor Ohms 1-1 quality
Sensor Ohms 1-1 limit
DO sensor
Oxygen 1-1 quality
Oxygen 1-1 limit
Temp 1-1 quality
Temp 1-1 limit
Sensor current 1-1 quality
Sensor current 1-1 limit
CH1-2 …
CH1-3 …
CH1-4 …
CH2-1 …
Converter
AO1 current quality
AO1 current limit
AI quality
AI limit
Di󰀨erential pH quality
Di󰀨erential pH limit
Di󰀨erential ORP
quality
Di󰀨erential ORP limit
Di󰀨erential Conduct
quality
Di󰀨erential Conduct
limit
Di󰀨erential Resist
quality
Di󰀨erential Resist
limit
Di󰀨erential DO
quality
Di󰀨erential DO limit
Average pH quality
Average pH limit
Average ORP quality
Average ORP limit
Average Conduct
quality
Average Conduct
limit
Average Resist
quality
Average Resist limit
Average DO quality
Average DO limit
Ratio quality
Ratio limit
Passage quality

HART Communication 15
TI 12A01F01-61EN Nov. 20, 2018-00
Passage limit
Rejection quality
Rejection limit
Deviation quality
Deviation limit
pH calc quality
pH calc limit
Script 1 quality
Script 1 limit
Script 2 quality
Script 2 limit
Script 3 quality
Script 3 limit
Script 4 quality
Script 4 limit
Script 5 quality
Script 5 limit
Script 6 quality
Script 6 limit
Script 7 quality
Script 7 limit
Script 8 quality
Script 8 limit
View input/output
AO1 current
AO2 current
AO3 current
AO4 current
AI current
Contact in/out
Sensor variables
CH1-1
PH sensor
IMP1 1-1
IMP2 1-1
Sensor mV1 1-1
Sensor mV2 1-1
Sensor mV3 1-1
SC sensor
Sensor Ohms 1-1
Polarization 1-1
ISC sensor
Sensor Ohms 1-1
DO sensor
Sensor current 1-1
Polarization voltage 1-1
Available KOH 1-1
Pressure level (process)
CH1-2 …
CH1-3 …
CH1-4 …
CH2-1 …
User select User select values
[selected device variavle name]
[selected device variavle name]
[selected device variavle name]

HART Communication 16
TI 12A01F01-61EN Nov. 20, 2018-00
[selected device variavle name]
[selected device variavle name]
[selected device variavle name]
[selected device variavle name]
[selected device variavle name]
User select codes
User select code 1
User select code 2
User select code 3
User select code 4
User select code 5
User select code 6
User select code 7
User select code 8
2.1.2 diagnostic_root_menu
Diagnostics root menu
Device status
Device Status
Extended Device Status
Standardized Status 0
Standardized Status 1
Device Specic Status 0
Device Specic Status 1
Device Specic Status 2
Device Specic Status 3
Device Specic Status 4
Device Specic Status 5
Device Specic Status 6
Device Specic Status 7
Device Specic Status 8
Device Specic Status 9
Device Specic Status 10
Device Specic Status 11
Device Specic Status 12
Device Specic Status 13
Cong changed count
Clear cong changed ag
Detailed device status
CH1-1
PH sensor
SC sensor
ISC sensor
DO sensor
CH1-2 …
CH1-3 …
CH1-4 …
CH2-1 …
Converter

HART Communication 17
TI 12A01F01-61EN Nov. 20, 2018-00
2.1.3 maintenance_root_menu
Maintenance root
menu
Test
Simulation all clear
Test auto release time
Loop current(AO1) test
AO2 test
AO3 test
AO4 test
Status simulation
Display
Squawk
Adjust touch panel
Luminance select
Error conguration
Converter
Measurement alarm
VGB calc. error
Ratio calc. error
Passage calc. error
Rejection calc. error
Deviation calc. error
Script Error 1
Script Error 2
Script Error 3
Script Error 4
I/O alarm
Fail safe occur
Maintenance status
Outputs in HOLD 1
Outputs in HOLD 2
Outputs in HOLD 3
Outputs in HOLD 4
Wash response failure 1
Wash response failure 2
Wash response failure 3
Wash response failure 4
Setting alarm
mA 1 conguration error
mA 2 conguration error
mA 3 conguration error
mA 4 conguration error
Error in mA table 1
Error in mA table 2
Error in mA table 3
Error in mA table 4
Display 1-1 setting error
Display 1-2 setting error
Display 1-3 setting error
Display 1-4 setting error
Display 2-1 setting error
Display 2-2 setting error
Display 2-3 setting error
Display 2-4 setting error
HART setting error
Contact cong. error 1

HART Communication 18
TI 12A01F01-61EN Nov. 20, 2018-00
Contact cong. error 2
Contact cong. error 3
Contact cong. error 4
PH sensor
Sensor status
Sensor not detect
Temp element not detect
ID chip failure
LE detect
calibration due
imp1 glasbreak detect
imp2 glasbreak detect
Measurement warning
temp too high
temp too low
pH too high
pH too low
ORP too high
ORP too low
rH too high
rH too low
imp(pH/ORP) too high
imp(pH/ORP) too low
imp(ref) too high
imp(ref) too low
pH temp comp warning
SSA temp out.
Operating spec
Device status
SENCOM Comm.
Error
SC sensor
Sensor status
Sensor not detect
Temp element not detect
ID chip failure
calibration due
Measurement warning
temp too high
temp too low
conductivity too high
conductivity too low
temp comp1 warning
temp comp2 warning
USP limit exceeded
USP margin exceeded
Polarization detected
matrix1 error
matrix2 error
conc table error
SSA temp out.
Operating spec
Device status
SENCOM Comm.
Error
ISC sensor
Sensor status

HART Communication 19
TI 12A01F01-61EN Nov. 20, 2018-00
Sensor not detect
Temp element not detect
ID chip failure
calibration due
Measurement warning
temp too high
temp too low
conductivity too high
conductivity too low
temp comp1 warning
temp comp2 warning
matrix1 error
matrix2 error
conc table error
SSA temp out.
Operating spec
Device status
SENCOM Comm.
Error
DO sensor
Sensor status
Sensor not detect
Temp element not detect
ID chip failure
sensor membrane failure
calibration due
Measurement warning
temp too high
temp too low
DO too high
DO too low
SSA temp out.
Operating spec
Device status
SENCOM Comm.
Error
Condensed status
map
Device status
Primary Variable Out of
Limits
Non-Primary Variable
Out of Limits
Loop Current Saturated
Loop Current Fixed
More Status Available
Cold Start
Conguration
Changed
Device Malfunction
Ext dev status
Maintenance required
Device variable alert
Failure
Out of Specication
Function Check

HART Communication 20
TI 12A01F01-61EN Nov. 20, 2018-00
Device diagnostic
status 0
Device conguration
locked
Device diagnostic
status 1
Status simulation
active
Discrete Variable
Simulation active
Device Specic
Status 0
Hardware failure
Internal com. error
IO mod. param. read
error
Com. mod. param.
read error
CPU param. read error
Device Specic
Status 1
VGB calc. error
Ratio calc. error
Passage calc. error
Rejection calc. error
Deviation calc. error
Script error
Device Specic
Status 2
mA 1 output burn out
mA 2 output burn out
mA 3 output burn out
mA 4 output burn out
mA 1 saturation
mA 2 saturation
mA 3 saturation
mA 4 saturation
Device Specic
Status 3
AI exceeds limit
AI out of range
Expiry time exceeded
Wash response failure
Converter Error
Simulation
Fail safe occur
Device Specic
Status 4
Simulated mA value 1
Simulated mA value 2
Simulated mA value 3
Simulated mA value 4
Outputs in HOLD1
Outputs in HOLD2
Outputs in HOLD3
Outputs in HOLD4
