YOKOGAWA JUXTA VJT6 Series User manual

Model VJT6
Thermocouple Converter
(Isolated Single-output and
Isolated Dual-output Types)
CAUTIONARY NOTES FOR SAFE USE OF THE
PRODUCT
This User’s Manual should be carefully read before installing
and operating the product. Please keep this User’s Manual for
future reference. For more information of the safety precautions,
please refer to the “Precautions on the Use of the JUXTA Series (IM
77J01A00-91Z1)”.
The related manuals and general specications
are shown in the table below.
Doc. Name Doc. Number
Precautions on the Use of the JUXTA Series (User’s Manual) IM 77J01A00-91Z1
Model VJT6 Thermocouple Converter
(User’s Manual)
IM 77J01T06-01E
(This manual)
Model VJT6 Thermocouple Converter
(General Specications)
GS 77J01T06-01E
User’s manuals in the above table are essential parts of the
product; keep it in a safe place for future reference.
This manual is intended for the following personnel;
• Engineers responsible for installation, wiring, and maintenance
of the equipment.
• Personnel responsible for normal daily operation of the
equipment.
The following symbol is used on the product and in this manual to
ensure safe usage.
WARNING
Calls attention to actions or conditions that could
cause serious or fatal injury to the user, and indicates
precautions that should be taken to prevent such
occurrences.
CAUTION
Calls attention to actions or conditions that could
cause injury to the user or damage to the instrument
or property and indicates precautions that should be
taken to prevent such occurrences.
QR Code
The product has a QR Code pasted for e󰀩cient plant
maintenance work and asset information management.
It enables conrming the specications of purchased products
and user’s manuals.
For more details, please refer to the following URL.
https://www.yokogawa.com/qr-code
* QR Code is a registered trademark of DENSO WAVE INCORPORATED.
CHECKING PRODUCT SPECIFICATIONS
AND PACKAGED ITEMS
(1) Checking the Model and Product Specications
Check that the model and specications indicated on the
nameplate attached to the main unit are as ordered.
(2) Packaged Items
Check that the package contains the following items:
• VJT6: 1 unit
Standard Accessories:
• Tag number label: 1 sheet
• RJC sensor (A1167HT): 1 piece
Not provided for the input signal code 7 (Type B).
• User’s Manual (this manual): 1 copy
IM 77J01T06-01E
11th Edition Mar. 2021
GENERAL
This plug-in type thermocouple converter is connected to an IEC/
JIS-standard thermocouple(TC) to convert temperature signals
into isolated DC current or DC voltage signals.
MODE AND SUFFIX CODES
Model Su󰀩x Codes Description
VJT6 -0 x x -x x x x /x Thermocouple Converter
Fixed code
-0 Always 0
Output 11 output
22 outputs
Power supply 6100-240 V AC/DC (*1)
715-30 V DC (*2)
Input signal
-1 K
-2 T
-3 E
-4 J
-5 R
-6 S
-7 B
-8 N
-Z Custom order
Output-1
A4 to 20 mA DC
B2 to 10mA DC
C1 to 5 mA DC
D0 to 20 mA DC
E0 to 16 mA DC
F0 to 10 mA DC
G0 to 1 mA DC
10 to 10 mV DC
20 to 100 mV DC
30 to 1 V DC
40 to 10 V DC
50 to 5 V DC
61 to 5 V DC
7-10 to +10 V DC
ZCustom order *3
Output-2
A4 to 20mA DC
61 to 5V DC
NNo output-2
ZCustom order *3
Burnout
UUP
DDOWN
NOFF
Option
/SN No socket (with socket if not
specied)
/C0 Coating *4
/FB Fuse bypass *4
/DF Fahrenheit unit
*1 Operating range: 85-264 V AC/DC
*2 Operating range: 12-36 V DC
*3 DC voltage signal or DC current signal
*4 When option code /C0 or /FB is specied, the conformity to the safety
and EMC standards is excluded. CE marking is not applicable.
Note: An exclusive User’s Manual might be attached to the
products whose su󰀩x codes or option codes contain the code
“Z” (made to customers’ specications). Please read it along
with this manual.
User’s
Manual
1
Thank you for purchasing the JUXTA Signal Conditioner.
Please read through this manual before use for correct handling.
2-9-32, Naka-cho Musashino-shi, Tokyo 180-8750 Japan
Phone: [phone] Facsimile: [phone]
http://www.yokogawa.com/ns/juxta/im/
You can download the latest manuals from the following website:

1. MOUNTING METHOD
CAUTION
●Plug/disconnect the main unit into/from the
socket vertically to the socket face. Otherwise the
terminals may bend and it may cause bad contact.
●The converter shall not tilt 5 degrees or more in
either direction when installed.
●When the converter is not connected to the socket,
it is necessary to protect the socket against ingress
of dust to the connector part.
●Keep this product in a conductive bag when
plugged out, during transport or storage.
1.1 Wall Mounting
Loosen the main unit-xing screw of the product and pull out the
main unit from the socket. Fix the socket on the wall with screws.
Next, insert the main unit into the socket and fasten the main unit
with the main unit-xing screw.
29.5 or more
22±0.2
2-M4 or
2-ø
4.5 or more
Mounting Dimensions
Unit: mm
59±0.3
Main unit-fixing screw
Socket
Main unit
Threaded hole for
fixing the main unit
Mounting screws
1.2 DIN Rail Mounting
Insert a DIN rail into the upper part of the DIN rail groove on the
rear of the socket, and then slide the slide lock at the lower part of
the socket upwards until the socket is xed into position as shown
below.
DIN rail
DIN rail
(Rear of socket)
Slide lock
DIN rail
Fit into here
Push
1.3 Mounting Using a Multi-mounting Base
When using a multi-mounting base, see the User’s Manual for
VJCE-01A (VJ Mounting Base for communication) (IM 77J01C51-
11E).
1.4 Using a Duct
When using a wiring duct, install the duct at leaset 30 mm away
from the top and bottom faces of the main unit.
2. INSTALLATION AND ENVIRONMENTAL
CONDITIONS
• Avoid the following environments for installation locations:
Areas with vibrations, corrosive gases, dust, water, oil,
solvents, direct sunlight, radiation, a strong electric eld,
and/or a strong magnetic eld, direct radiant heat, wind,
temperature uctuation, 2000 m or more above sea level,
outdoors.
• If there is any risk of a surge being induced into the power line
and/or signal lines due to lightning or other factors, a dedicated
lightning arrester should be used as protection for both the
product and a eld-installed device.
• Use indoors at an altitude of 2000 m or less.
• Operating temperature/humidity range: −10 to 55°C (−10
to 45°C for side-by-side mounting*)/5 to 90%RH (no
condensation)
* If the previous model (style S3.xx earlier) is installed
together, the ambient temperature is 0 to 40°C.
• Continuous vibration: (at 5 to 9 Hz) Half amplitude of 3 mm or
less (at 9 to 150 Hz) 9.8m/s2or less, 1 oct/min for 90 minutes
each in the three axis directions
• Impact: 98 m/s2or less, 11 ms, 3 axes, 6 directions, 3 times
each
3. EXTERNAL WIRING
WARNING
●To avoid the risk of an electric shock, turn o󰀨 the
power supply and use a tester or similar device to
ensure that no power is supplied to a cable to be
connected, before carrying out wiring work.
●Do not operate the product in the presence of
ammable or explosive gases or vapors. To do so is
highly dangerous.
●Use of the product ignoring the specications may
cause overheating or damage. Before turning on
the power, ensure the following:
• Power supply voltage and input signal value
applied to the product should meet the required
specications.
• The external wiring to the terminals and wiring to
ground are as specications.
Wiring should be connected to the terminals on the socket of the
product. The terminals for external connections are of M3 screws.
Use crimp-on terminal lugs for connections to the terminals.
• Recommended cables: A nominal cross-sectional area of
0.5 mm2 or thicker for signal cables, and that of 1.25 mm2 or
thicker for power cables.
1011
321
4
56
789
Signal
line
RJC
sensor
Terminal
screw
1011
3 2 1
4
56
789
1110 8
L+ N– GND
7
9
+
–
2
1
3
4
5
+
–
+
–
RJC
Power supply
RJC sensor
(A1167HT)
Mounting position of RJC Wiring
Output-2
Input signal
Output-1
Recommended crimp-on lug
size (Unit: mm)
5.5 or less
5.5 or more
ø3.2 to 3.5
2IM 77J01T06-01E 11th Edition

CAUTION
●Do not use output-2 for the isolated single-output
type.
●The power line and input/output signal lines should
be installed away from noise-generating sources.
Other wise accuracy cannot be guaranteed.
●Make sure to earth ground the ground terminal
through minimum resistance. The length and
thickness of the grounding cable should be as
short and thick as possible. Directly connect the
lead from the ground terminal (terminal no. 8) of
the product to the ground. Do not carry out daisy-
chained inter-ground terminal wiring.
●The product is sensitive to static electricity;
exercise care in operating it. Before you operate
the product, touch a nearby metal part to discharge
static electricity.
●If the ambient temperature is 50 °C or more, please
use the cable that the rated temperature is 70 °C or
more.
4. RJC Sensor
CAUTION
The product works normally when the RJC sensor
“A1167HT” (see the gures below) is connected to the
socket. If another RJC sensor is connected, it does not
work normally. Make sure that the correct RJC sensor
is connected referring to the gures below.
The RJC sensor for the product
(For the VJT6 with style of 3.00
or higher)
The RJC sensor for the VJT6 with
former style
“Not available for the VJT6 with
style of 3.00 or higher”
Part number: A1167HT Part number: E9786WA
The style of VJT6 is indicated on the nameplate attached to
the side face of the main unit.
5. MAINTENANCE
The product starts running immediately when the power is turned
on; however, it needs 10 to 15 minutes of warm-up before it
meets the specied performance.
5.1 Calibration Apparatus
• Calibrator (YOKOGAWA Meters & Instruments‘ CA150 or
equivalent): 1
• Temperature sensor (Yokogawa Meters & Instruments‘
B9108WA or equivalent): 1
• Digital multimater (YOKOGAWA DM7560 or equivalent): 1
• Precision resistor of 250 Ω ± 0.01%, 1 W
5.2 Calibration Procedure
1. Connect the instruments as shown below. First adjust the
output-1 signal and then the output-2 signal.
1011
3 2 1
4
56
789
1110 8
Temperature sensor (B9108WA)
1
3
–
+
2
5
R-
+
7
9
R
Calibrator
R: 250 Ω
precision resistor
for current output
Power supply
Output-2
Input
Output-1
L+ N- GND
Digital
multimater
-
+
Digital
multimater
2. Use the calibrator and apply input signals equivalent to 0, 25,
50, 75, and 100% of the input span to the product.
3. Check to see the corresponding output voltages are 0, 25, 50,
75, and 100% respectively and within the specied accuracy
rating. “R” is used for current output.
• If the output signals are out of the accuracy rating range,
adjust the output signal level using the zero and span
adjustment volumes on front face of the product.
Zero-adjustment volume
Output-1
Span-adjustment volume
Zero-adjustment volume
Output-2
Span-adjustment volume
3IM 77J01T06-01E 11th Edition

6. SAFETY AND EMC STANDARDS
The following will be acquired.
Safety:
IEC/EN 61010-1 compliance (CE)
IEC/EN 61010-2-030 compliance (CE)
CAN/CSA-C22.2 No.61010-1 (CSA)
CAN/CSA-C22.2 No.61010-2-030 (CSA)
UL61010-1 (CSA NRTL/C)
UL61010-2-030 (CSA NRTL/C)
Overvoltage category: II
Pollution degree: 2
Measurement category: O (other)
Rated power voltage: 15-30 V DC (±10%) 2.4 W or
100-240V AC/DC (±10%) 50/60 Hz
2.6 W 6.7 VA
Rated voltage (Input signal) : ±0.15 V DC
Rated voltage (Analog output signal): −10 to +10 V DC,
0 to 20 mA DC
Rated transient overvoltage: 1500 V (*)
* This is a reference safety standard value for the
measurement Category O. This value is not necessarily
a guarantee of instrument performance.
CAUTION
This instrument is for Measurement Category O
(other). Do not use it for measurements in locations
falling under Measurement Categories II, III, and IV.
Internal Wiring
Outlet
Entrance
Cable
III T
O
II
IV
Measurement
category
Description Remarks
O (other) For measurements
performed on circuits not
directly connected to MAINS.
II CAT.II For measurements
performed on circuits directly
connected to the low-voltage
installation.
Appliances,
portable
equipments,
etc.
III CAT.III For measurements
performed in the building
installation.
Distribution
board, circuit
breaker, etc.
IV CAT.IV For measurements
performed at the source of
the low-voltage installation.
Overhead
wire, cable
systems, etc.
EMC standards:
• CE:
EN 61326-1 Class A, Table 2
EN 61326-2-3
* The instrument continues to operate at a measurement
accuracy of within ±20% of the range during testing.
EN 55011 Class A, Group 1
EN 61000-3-2
EN 61000-3-3
• RCM:
EN 55011 Class A, Group 1
• KC:
Electromagnetic wave interference prevention standard,
electromagnetic wave protection standard
CAUTION
Caution to comply with EMC standards: When
operating this instrument by external power supply,
use an independent power unit conforming to CE-
marking. Be sure to use the lightning arrester to
comply EMC standards.
Note: When option code /C0 or /FB is specied, the conformity to
the safety and EMC standards is excluded.
7. ENVIRONMENT STANDARD
EU RoHS directive: EN IEC 63000
(However, when option code /C0 or /FB is specied, CE mark-
ing is not applicable because the product does not comply
with the Safety and EMC standards.)
8. TRANSPORT AND STORAGE CONDITIONS
• Temperature: -25 to 70°C
• Temperature change rate: 20°C per hour or less
• Humidity: 5 to 95%RH (no condensation)
CAUTION
Keep this product in a conductive bag when plugged
out, during transport or storage.
4IM 77J01T06-01E 11th Edition
