YOKOGAWA Dpharp vigilantplant EJA Series User manual

User’s
Manual
Yokogawa Electric Corporation
Model EJA Series
HART Protocol
IM 01C22T01-01E
IM 01C22T01-01E
7th Edition

i
CONTENTS
IM 01C22T01-01E
CONTENTS
PRELIMINARY ........................................................................................................ ii
1. ZERO POINT ADJUSTMENT .......................................................................1-1
1.1 Zero Point Adjustment ........................................................................ 1-1
1.1.1 Using the HART Communicator................................................... 1-2
1.1.2 Using the Transmitter Zero-adjustment Screw ............................ 1-2
1.2 Auto LRV (Change Low Range Value)............................................... 1-3
1.2.1 Using Model 275 — Apply Values ............................................... 1-3
1.2.2 Setting the Range Using the Range-setting Switch .................... 1-3
2. HART COMMUNICATOR OPERATION .......................................................2-1
2.1 Conditions of Communication Line ..................................................... 2-1
2.1.1 Interconnection Between DPharp and HART Communicator...... 2-1
2.1.2 Communication Line Requirements ............................................. 2-1
2.2 Basic Operation of the HART Communicator (Model 275) ................ 2-2
2.2.1 Keys and Functions...................................................................... 2-2
2.2.2 Display.......................................................................................... 2-3
2.2.3 Calling Up Menu Addresses ........................................................ 2-3
2.2.4 Entering, Setting, and Sending Data ........................................... 2-4
2.3 Parameters.......................................................................................... 2-5
2.3.1 Parameter Usage and Selection .................................................. 2-5
2.3.2 Menu Tree .................................................................................... 2-6
2.3.3 Setting Parameters....................................................................... 2-7
(1) Tag No......................................................................................... 2-7
(2) Unit.............................................................................................. 2-7
(3) Range Change............................................................................ 2-7
(4) Output Mode (Linear/Sq root) ..................................................... 2-8
(5) Damping Time Constants............................................................ 2-9
(6) Output Signal Low Cut Mode Setup............................................ 2-9
(7) Bi-directional Flow Measurement.............................................. 2-10
(8) Integral Indicator Display Mode................................................. 2-10
(9) Integral Indicator Scale ............................................................. 2-10
(10) Unit for Displayed Temperature................................................. 2-12
(11) Unit for Displayed Static Pressure ............................................ 2-12
(12) Test Output................................................................................ 2-12
(13) Sensor Trim ............................................................................... 2-13
(14) Trim Analog Output ................................................................... 2-14
(15) Burst Mode................................................................................ 2-16
(16) Multidrop Mode ......................................................................... 2-16
(17) External Switch Mode ............................................................... 2-17
(18) Software Write Protect .............................................................. 2-17
(19) Hardware Write Protect and Burnout Direction
(with Optional code /F1)............................................................ 2-19
(20) H2O Unit Select......................................................................... 2-19
2.4 Self-Diagnostics ................................................................................ 2-19
2.4.1 Checking for Problems............................................................... 2-19
(1) Identify Problems with HART Communicator............................ 2-19
(2) Checking with Integral Indicator ................................................ 2-20
3. PARAMETER LISTS .....................................................................................3-1
REVISION RECORD
FD No. IM 01C22T01-01E
7th Edition: Jan. 2008(KP)
All Rights Reserved, Copyright © 1995, Yokogawa Electric Corporation

ii
PRELIMINARY
IM 01C22T01-01E
PRELIMINARY
This manual describes the function, performance, and
operating procedures of the DPharp EJA Series with
HART protocol. The DPharp EJA Series with HART
protocol uses the same pressure sensing element as in
DPharp EJA with BRAIN protocol. Therefore, this
manual describes only the functions unique to HART
Communicator operating procedures which are not
covered in the DPharp EJA with BRAIN protocol
instruction manual. For the items listed below which
are common to both the HART protocol and BRAIN
protocol, see the applicable user’s manuals listed in
Table 1.
Contents of Individual User’s Manuals
•INTRODUCTION
•HANDLING CAUTIONS
•COMPONENT NAMES
•INSTALLATION
•INSTALLING IMPULSE PIPING
•WIRING
•OPERATION
— Zero Point Adjustment
(For BRAIN Protocol)
•BRAINTERMINAL BT200 OPERATION
(For BRAIN Protocol)
•MAINTENANCE
•PARAMETER SUMMARY
(For BRAIN Protocol)
•GENERAL SPECIFICATIONS
Contents of this User’s Manual for HART Protocol
—IM 01C22T01-01E—
•ZERO POINT ADJUSTMENT
•HART Communicator OPERATION
•PARAMETER LISTS
F01.EPS
Figure 1. Relationship between Individual Manuals and
HART Manual Contents
Table 1. Individual User’s Manuals
EJA110A, EJA120A, EJA130A IM 01C21B01-01E
EJA210A, EJA220A IM 01C21C01-01E
EJA310A, EJA430A, EJA440A IM 01C21D01-01E
EJA510A, EJA530A IM 01C21F01-01E
EJA110, EJA120 IM 01C22B01-01E
EJA210, EJA220 IM 01C22C01-01E
EJA310, EJA430 IM 01C22D01-01E
EJA118W, EJA118N, EJA118Y IM 01C22H01-01E
EJA438W, EJA438N IM 01C22J01-01E
EJA115 IM 01C22K01-01E
T01.EPS
Manual No.Model
CAUTION
Matching of communicator DD and instrument DD
Before using model 275 HART communicator,
check that the DD(Device Description) installed in
the communicator matches to that of instruments
to set up. To check the DD in the instrument or
the HART communicator, follow the steps below.
If the correct DD is not installed in the communi-
cator, you must upgrade the DD at the HART
official programming sites. For communication
tools other than Model 275 HART communicator,
contact vendors of each for upgrade information.
1. Checking the DD in the instrument
1) Connect the communicator to the instrument
to set up.
2) Call "Device setup" and press
[→]
.
3) Call "Review" and press
[→]
.
4) By pressing [NEXT] or [PREV], find "Fld dev
rev" to show the DD of the instrument.
F02.EPS
EJA:
Review
Fld dev rev
2
HELP PREV NEXT EXIT
"The instrument DD is
Version 2."
[Example]
2. Checking the DD in Model 275 HART commu-
nicator
1) Turn on the communicator alone.
2) Call "Utility" from main menu and press
[→]
.
3) Call "Simulation" and press
[→]
.
4) Select "YOKOGAWA" from manufacturers
list by pressing
[ ]
↓
and press
[→]
.
5) Select the model name of the instrument(i.e.
EJA) by pressing
[ ]
↓
and press
[→]
to
show the DD of the communicator.
F03.EPS
HART Communicator
Fld dev rev
1 Dev v1, DD v2
2 Dev v2, DD v1
[Example]
"The communicator DD
supports Version 1 and 2."
Version 1 and 2.

IM 01C22T01-01E
1-1
1. ZERO POINT ADJUSTMENT
1. ZERO POINT ADJUSTMENT
After operating preparation is completed, adjust the
zero point. The zero point adjustment can be made
using either of the following two methods.
For output signal checking, display the parameter %
rnge in the HART Communicator.
HART Communication
display
EJA:
Process variable
1 Pres 0.012nnH2O
2 % range 0.00%
3 A01 Out 4.002mA
4 Snsr temp 38.1C
5 Static pres
HELP DIAG HOME ESC
F0101.EPS
Zero-adjustment
screw
䊏Using the Transmitter Zero-adjustment
Screw
Before using the zero-adjustment screw outside the
transmitter case, confirm the following.
•Ext SW mode must be ENABLE. See Subsection
2.3.3 (17) for the setting procedure.
•Use a slotted screwdriver to turn the zero-adjustment
screw. Turn the screw clockwise to increase the
output or counterclockwise to decrease the output,
the zero point adjustment can be adjusted with a
resolution of 0.01% of the setting range.
The degree of zero adjustments varies with the
screw turning speed. Therefore, turn the screw
slowly for fine adjustment and quickly for coarse
adjustment.
CAUTION
Do not turn off the power to the transmitter
immediately after a zero adjustment. Powering
off within 30 seconds after a zero adjustment will
return the adjustment back to the previous
settings.
䊏Using the HART Communicator
Zero point can be adjusted by simple key operation of
the HART Communicator.
Select parameter Zero Trim, and press the OK (F4)
key twice. The zero point will be adjusted automati-
cally to the output signal 0% (4 mA DC). Confirm that
the setting value displayed for the parameter % rnge
is 0.0% before pressing the OK (F4) key. See Subsec-
tion for HART Communicator operating procedures.
1.1 Zero Point Adjustment
The DPharp supports several adjustment methods.
Select the method best suited for conditions matching
the state of the site.
Note that output signal can be checked by HART
Communicator.
Adjustment Method Description
Zero adjustment
using the HART
Communicator
Set the present
input to 0%.
P.1-2 ‘Zero trim’
Zero adjustment
using the
external zero-
adjustment
screw
Adjust zero point using the zero-
adjustment screw on the transmitter.
This permits zero adjustment without
using the HART Communicator.
Accurately adjust the output current to
4mA DC or other target output value
using an ammeter that accurately reads
output currents.
Adjust for 0% output
at input level of 0%.
Adjust output to
the reference
value obtained
using other
means.
P.1-2 ‘Lower
sensor trim’
If the input level
cannot easily be
made 0% (because of
tank level, etc.),
adjust output to the
reference value
obtained using other
means, such as a
glass gauge.
T0101.EPS

IM 01C22T01-01E
1-2
1. ZERO POINT ADJUSTMENT
1.1.1 Using the HART Communicator
(1) Zeroing — Zero trim
NOTE
Zero trim carries out the zero adjustment and
sets the input values at present, equal to 0
mmH2O. Use this setting to set LRV = 0 mmH2O.
1
1. Device setup
2. Diag/Service
3. Calibration
3. Sensor trim
1. Zero trim
EJA:
WARN-LOOP should be
removed from
automatic control
ABORT OK
F0102.EPS
Press OK (F4).
(OK)
2
EJA:
WARN-This will affect
sensor calibration
ABORT OK
Press OK (F4).
(OK)
3
EJA:
Apply O input to
sensor
ABORT OK
A pressure of 0 mmH
2
O is applied.
Press OK (F4) after the pressure
has become stable.
(OK)
(2) Arbitrary Level Adjustment — Lower
Sensor Trim
This zero adjustment applies to tank level measure-
ments, etc. where the actual tank level cannot be set to
zero. For this adjustment, use the actual tank level
obtained with a glass gauge or the like to meet the
DPharp output.
2500 mmH2O
0 mmH2O
Actual level
1350 mmH2O
DPharp span: 0 to 2500 mmH2O
Actual level: 1350 mmH2O
Transmitter output: 1383 mmH2O
DPharp
F0103.EPS
1
1. Device setup
2. Diag/Service
3. Calibration
3. Sensor trim
2. Lower Sensor Trim
EJA:
Apply low pressure
ABORT OK
F0104.EPS
Check the tank level at present, and
press OK (F4).
(OK)
2
EJA:
Press OK when
pressure is stable
ABORT OK Press OK (F4).
(OK)
3
EJA:
ENTER applied
Pressure Value
0.000 mmH2O
0.000
HELP DEL ABORT ENTER Enter the value of the actual level
(1350 mmH
2
O), and press ENTER
(F4).
(ENTER)
‘1 3 5 0’
NOTE
Lower Sensor trim adjusts the input value at
present. See Fine Input Adjustment for detail.
1.1.2 Using the Transmitter Zero-adjust-
ment Screw
Turn the zero-adjustment screw on the outside of the
transmitter case using a slotted screwdriver. Turn the
screw to the right to increase the zero point or to the
left to decrease the zero output; the zero adjusts in
increments of 0.01% of the range setting.
Note that the amount of adjustment to the zero point
changes according to the speed at which the screw is
turned. To make fine adjustments, turn the screw
slowly; to make coarse adjustments, turn the screw
quickly.
Note: When a zero point adjustment has been made do not turn of
the transmitter less than 30 seconds after adjustment.

IM 01C22T01-01E
1-3
1. ZERO POINT ADJUSTMENT
1.2 Auto LRV (Change Low
Range Value)
1.2.1 Using Model 275 — Apply Values
Display the Apply Values display, and adjust the zero
point as follows:
1
1. Device setup
3. Basic setup
3. Re-range
2. Apply values
EJA:
WARN-LOOP should be
removed from
automatic control
ABORT OK
F0105.EPS
Press OK (F4).
(OK)
2
EJA:
Set the:
1 4mA
2 20mA
3 Exit
ABORT ENTER Select 4 mA, and press ENTER
(F4).
(ENTER)
3
EJA:
Apply New 4ma input
ABORT OK Apply a pressure corresponding to
0% of the measurement range.
(OK)
4
EJA:
Current applied
Process value:
0.06 mmH2O
1 Set as 4mA value
2 Read new value
3 Leave as found
ABORT ENTER LRV (0%) is read as –0.06 mmH
2
O.
Select Set as 4mA value, and
press ENTER (F4).
(ENTER)
‘Pressure stabilizing’
1.2.2 Setting the Range Using the Range-
setting Switch
With actual pressure(s) being applied to the transmitter,
the range-setting switch (push-button) attached to the
integral indicator plate and the external zero-adjust-
ment screw allow users to change the lower- and
upper-range values for the measurement range (LRV
and URV) without the use of a HART Communicator.
However, a change in the display settings (scale range
and engineering unit) for the integral indicator requires
a HART Communicator.
Follow the procedure below to change the LRV and
URV settings.
Example: Rerange LRV to 0 and HRV to 20 kPa.
1) Connect the transmitter and allow them to warm up
for at least five minutes.
2) Press the range-setting push-button.
The integral indicator then displays LSET.
3) Apply a pressure of 0 kPa (atmospheric pressure) to
the high-pressure side of the transmitter. (Note 1)
4) Turn the external zero-adjustment screw (either in
the output-increase or -decrease direction).
The integral indicator displays the output signal (in
%). (Note 2)
5) Adjust the output signal to 0% (1 V DC) by
rotating the external zero-adjustment screw. Doing
so completes the LRV setting.
6) Press the range-setting pushbutton.
The integral indicator then displays USET.
7) Apply a pressure of 20 kPa to the high-pressure
side of the transmitter. (Note 1)
8) Turn the external zero-adjustment screw (either in
the output-increase or -decrease direction).
The integral indicator displays the output signal (in
%). (Note 2)
9) Adjust the output signal to 100% (5 V DC) by
rotating the external zero-adjustment screw. Doing
so completes the URV setting.
10)Press the range-setting pushbutton.
The transmitter then switches back to the normal
operation mode while maintaining the measurement
range at 0 to 20 kPa.
Note 1: Wait until the pressure inside the pressure-detector section
has stabilized before proceeding to the next step.
Note 2: If the pressure applied to the transmitter exceeds the
previous LRV (or URV) , the integral indicator may display
error number “Er.07” (In this case, the output signal percent
and “Er.07” are displayed alternately every two seconds).
Although “Er.07” is displayed, there is no need to worry and
you may proceed to the next step. However, should any
other error number be displayed, take the appropriate
measure in reference to Section 2.4 Self-Diagnostics,
“Errors Messages.”

IM 01C22T01-01E
1-4
1. ZERO POINT ADJUSTMENT
IMPORTANT
1. Do not turn off the power to the transmitter
immediately after completion of the change in
the LRV (and/or URV) setting(s). Note that
powering off within thirty seconds after setting
will ca use a return to the previous settings.
2. Changing LRV automatically changes URV to
the following value.
URV  previous URV  (new LRV  previous LRV)
3. If the range-setting push-button and external
zero-adjustment screw are not touched during
a range-change operation, the transmitter
automatically switches back to the normal
operation mode.
F0106.EPS
Integral indicator
Range-setting switch
(Push-button)
Note: Use a thin bar which has a blunt tip, e.g.,
a hexagonal wrench, to press the range-
setting push-button.
Figure 1.2.1Range-setting Switch

IM 01C22T01-01E
2-1
2. HART COMMUNICATOR OPERATION
2. HART COMMUNICATOR OPERATION
2.1 Conditions of Communica-
tion Line
2.1.1 Interconnection Between DPharp
and HART Communicator
The HART Communicator can interface with the
transmitter from the control room, the transmitter site,
or any other wiring termination point in the loop,
provided there is a minimum of 250 Ωbetween the
connection and the power supply. To communicate, it
must be connected in parallel with the transmitter; the
connections are non-polarized. Figure 2.1.1 illustrates
the wiring connections for direct interface at the
transmitter site for the DPharp. The HART Communi-
cator can be used for remote access from any terminal
strip as well.
DPharp
HART communicator
Relaying
terminals
Distributor
Control room
Terminal
board
F0201.EPS
HART
communicator
Figure 2.1.1 Interconnection Diagram
2.1.2 Communication Line Requirements
Specifications for Communication Line:
Supply voltage(general use type); 16.4 to 42 V DC
Load resistance; 250 to 600 W (Including cable
resistance)
Minimum cable size; 24 AWG, (0.51 mm diameter)
Cable type; Single pair shielded or multiple pair with
overall shield
Maximum twisted-pair length; 10,000 ft (3,048 m)
Maximum multiple twisted-pair length; 5,000 ft
(1,524 m)
Use the following formula to determine cable length
for a specific application;
L = –
65×106
(R×C) (Cf+10,000)
C
Where: L = length in feet or meters.
R=resistance in ohms, current sense
resistance plus barrier resistance.
C=cable capacitance in pF/ft, or pF/m.
Cf=Maximum shunt capacitance of field
devices in pF.

IM 01C22T01-01E
2-2
2. HART COMMUNICATOR OPERATION
2.2 Basic Operation of the HART Communicator (Model 275)
2.2.1 Keys and Functions
LCD (Liquid crystal display)
(21 characters×8 lines)
Communication Cable
Function keys
Functions of the keys are indicated on the
display.
Pressing (HOME) when the display is
as shown changes the display to “Online”
menu. (See 2.2.2 “Display”.)
Hot key
Call up setting menu
1. Keypad Input
2. Enable Write
3. New Password
Shift keys
Use to enter alphabetic characters.
1. Changes the display contents.
2. Moves the position where a number or
character is to be entered.
Pressing calls up the display
corresponding to the item pointed with the
highlighting cursor.
Pressing returns to the previous
display. (See 2.2.3.)
Alphanumeric keys
1.Enters numbers and characters.
2.Selects the desired menu item with the
corresponding number. (See 2.2.4.)
Pressing single key enters the number.
Pressing the key with shift key enters the
alphabetic character.
Moves the highlighting cursor on the display to
select the desired item.
To enter “7”,
To enter “C”,
“7”
“C”
(Press) (ENTER)
Power ON/OFF
F0202.EPS
EJA:YOKOGAWA
Process variables
1 Pres 0.00 mmH2O
2 % rnge 0.00 %
3 A01 Out 4.000mA
4 Snsr temp 37.0C
5 Static Pres
HELP HOME
Figure 2.2.1 The HART Communicator

IM 01C22T01-01E
2-3
2. HART COMMUNICATOR OPERATION
2.2.2 Display
The HART communicator searches for a transmitter on
the 4 to 20mA loop when it is turned on. When the
HART communicator is connected to the transmitter,
Online menu (Top menu) is started automatically and
the following display appears. If no transmitter is
found, you select Online menu.
Manufacturer’s
transmitter type Tag (8 Characters) <a>
<b>
<c>
<d>
<e>
Function keys
EJA :YOKOGAWA
Online
1 Device setup
2 Pres 0.13 mmH2O
3 A01 Out 4.001 mA
4 LRV 0.00 mmH2O
5 URV 3000.00 mmH2O
F0203.EPS
The highlighting cursor
Pressing one of the SHIFT keys makes the arrow
mark corresponding to the pressed key appear.
Appears when the voltage level of the battery is low.
Figure 2.2.2 Display
<a> appears and flashes during communication
between the HART communicator and the
transmitter. At Burst mode, appears.
<b> The menu items selected from the previous menu.
<c> The items to be used from the menu of <b>.
<d> or appears when the item is scrolled out of
the display.
<e> The labels of function corresponding to each
function key appears. These labels reflect cur-
rently available choices.
2.2.3 Calling Up Menu Addresses
Subsection 2.3.2 shows the configuration of all menu
items available with the HART communicator. The
desired item can be displayed with ease by understand-
ing the menu configuration.
When the HART communicator is connected to the
transmitter, Online menu will be displayed after power
is turned on. Call up the desired item as follows:
Function Key Labels
F1
HELP
access on-line
help
RETRY
try to re-
establish
communication
EXIT
leave the
current menu
YES
answer to
yes/no question
ALL
include current
Hot Key item on
Hot Key Menu
for all devices
F2
ON/OFF
activates or
deactivates a
binary variable
DEL
delete current
character or Hot
Key Menu item
SEND
send data to
device, or mark
data to send
PGUP
move up one
help screen
PREV
go to previous
message in a
list of messages
F3
ABORT
terminate
current task
ESC
leave value
unchanged
QUIT
terminate session
because of a
comunication
error
PGDN
move down one
help screen
NEXT
go to next
message in the
list of messages
HOME
go to the top
menu in the
device
description
SKIP
do not mark
variable to be
sent in off-line
configuration
ONE
include Hot Key
item for one
device
BACK
go back to
menu from
which HOME
was pressed
EDIT
edit a variable
value
ADD
add current item
to Hot Key
Menu
SAVE
save information
to
communicator
SEND
send data to
device, or mark
data to send
F4
OK
acknowledge
information on
screen
ENTER
accept user-
entered data
NEXT
leave the
current menu
NO
answer to
yes/no question
F0204.EPS
Key Operation
There are two choices to select the desired menu item.
1. Use the or key to select the desired item,
and then press the key.
2. Press the number displayed for the desired item.
•To return to the previous display, press the key.
*If
ABORT
,
ESC
and
EXIT
are displayed,
press the desired function key.
Example: Call up the Tag item, to change the tag.
Check to see where item Tag is located in the menu
configuration. Then, call up Tag item on the display
according to the menu configuration.
Device setup
Pres
P01 Out
LRV
URV
Process variables
Diag/Service
Basic Setup
Detailed Setup
Review
Tag
Unit
Re-range
Device information
.
.
.
EJA:YOKOGAWA
Tag
YOKOGAWA
YOKOGAWA
HELP DEL ESC ENTER
