Yolink Smart Lock M1 User manual

YoLink Smart Lock M1
Deadbolt
User Guide
YS7606-UC

US Live Tech Support:
1-800-355-0157
Monday-Friday, 9:00am - 5:00pm PST
Fullerton, CA 92831

Introduction . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1
Disclaimer & Warning . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2
Getting Started . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3
Hardware Functions . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4
Installation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7
Local Passcode . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 13
Smart Home Setup . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 14
YoLink App Guide . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 16
Details . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 19
Manage User or Visitor Passcode . . . . . . . . . . . . . . . . . . . . . 20
Automation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 21
Basic Lock Functions . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 22
Maintenance . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 24
Factory Reset . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 25
Specification . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 26
In-App Alexa/Google Assist Guide . . . . . . . . . . . . . . . . . . . . 27
Troubleshooting . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 28
Technical Support & Warranty . . . . . . . . . . . . . . . . . . . . . . . 30
FCC Statement . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 31
CONTENTS

1
INTRODUCTION
The YoLink Smart Lock M1, is a stand-alone electronic keypad deadbolt replace-
ment with smart phone remote features when paired with a YoLink Smart HUB
(sold separately) using the YoLink smart phone app. YoLink uses the newest in
communication network technology, connecting YoLink compatible smart
devices over longer distances while using less power.

DISCLAIMER & WARNING 2
DISCLAIMER:
• Carefully read instructions in their entirety before installing.
• Always use proper safety measures during the install of this product.
• Always have traditional keys on hand in case of electronic failure.
• Back Module (B) needs to be protected from weather.
WARNING
• Only use brand new, popular brand, alkaline non rechargeable AA batteries.
• Remove batteries from product when storing for extended periods of time.
• Do NOT use rechargeable batteries (Li-On, nickel blends, rechargeable
alkaline, or other).
• Do NOT use non-rechargeable zinc blend batteries.
• Do NOT mix old and new batteries.
• Do NOT puncture or damage batteries. Leakage can cause harm on skin
contact; toxic if ingested.
• Do not dispose of batteries in fire as they may explode. Please follow your
local battery disposal procedure.

3
GETTING STARTED
A.
B.
D.
G.
C.
E.
F.F1 F2
F3
REQUIRED TOOLS FOR INSTALL
• Phillips screwdriver
• x4 AA Batteries (Please read Warnings pg.2)
PARTS LIST
A. Front Module
B. Back Module
C. Strike Plate
D. Mounting Plate
E. Extendable Latch
F. Screws
G. Keys

4
HARDWARE FUNCTIONS
C S 1 2 5
1
2
3
4
6
7
Hardware Interface
1. Doorbell: Sends notification to YoLink App.
2. 0~9 Keypad: Enter passcode.
3. Unlock Button: Press after entring passcode.
4. Lock Button: Locks door.
5. 1~2 Switch: Set for left/right handed installation.
6. Set Button: Use to set local passcode.
7. Factory Reset: Press and hold for 20 sec to
factory reset lock.

5
LED Status Indicators
The LED backlighting on your lock can indicate basic information
regarding lock status. Refer to diagram below:
Keypad
Blue Backlight
Low light visibility.
Lock Button
Red- Single Blink
Door Locked.
Red- Multi Blink
Factory Reset.
Unlock Button
Green- Single Blink
Door Unlocked.
Green- Multi Blink
Connecting to cloud.

6
Other Hardware Features
3 Unlocking/Locking Methods:
• Traditional Key (2 Included).
• Using Keypad to enter local, managed and visitor passcodes.
• Remotely using YoLink App (YoLink HUB needed, sold separately).
Scramble PIN code: Enter random digits BEFORE, AFTER, or IN THE MIDDLE
of correct PIN code.
Security Keypad Freeze: If PIN code is incorrectly entered more than 5 times,
keypad will freeze for 5 minutes and lock with begin beeping continuously.
Low Battery Indicator: When batteries are low, the lock will beep multiple
times when a function is executed.

7
Step 1: Adjust Latch Backset
INSTALLATION
60mm(23/8′′)
70mm(23/4′′)
E.
Latch adjustable depending on door backset.
• Twist buckle, extend/retract, twist back.

8
Step 2: Install Latch & Strike Plate
F3

9
Step 3: Mount Front Module

10
Step 4: Fasten Back Mounting Plate
D.F1
** Do not use power screwdriver **

11
Step 5: Mount Back Module
** Do not use power screwdriver **
F2
12
C
S
12
C
S
12
S
C
B.
Be sure thumbturn oriented as shown when installing
LEFT HANDED RIGHT HANDED

12
Step 6: Set for Left/Right Handed Door, Install Battery Cover
12
C
S
Before installing battery cover, Set
your lock to Left or Right handed:
• Locate 1 | 2 switch on the back
module just below the battery tray.
• Set to 1 if hinges are on the LEFT
of the door when ENTERING
through the front.
• Set to 2 if hinges are on the RIGHT
of the door when ENTERING
through the front. 1 | 2 Switch

13
LOCAL PASSCODE
Default:
• Lock is set with a preprogrammed default local passcode. Strongly suggested
to change default password to a unique owner passcode.
• Default Passcode:
Changing Local Passcode
• Remove battery cover from back module.
• Press and release the S button found just
below battery tray.
• Enter a 4-8 digit code using the keypad.
• Then press and release the “ ” button.
• 2 beeps: Successfully saved.
3 beeps: Error, Try again.
0 beeps: Refer to troubleshooting.
C S 1 2
S Button
12345678

SMART HOME SETUP 14
YoLink Smart HUB
A YoLink Smart HUB is REQUIRED in order to remotely access your YoLink M1
door knob with your Smart Phone.
Other YoLink Devices (Available on Amazon)
Door sensors, water leak sensor, motion detector, Wall plugs, wall switch,
temp and humidity sensor, garage door opener and more in development.
YoLink Smart HUB
Required

15
Longer Distance, Lower Battery Consumption
YoLink offers its own Smart Home ecosystem that uses LoRa, a communication
technology that’s better than the rest. The YoLink Smart HUB can connect with
YoLink compatible smart devices up to a quarter mile away and its lower
bandwidth use extends battery life of YoLink devices.
Cloud
Internet LoRaNetwork

16
YOLINK APP GUIDE
YoLink Smart Phone App
The YoLink app can be found for both iOS or Android through the Apple App
Store or the Google play Store.
• iOS 9 or higher is required for Apple iPhones or tablets.
• Android 4.4 or higher is required for Android phones or tablets.

17
Log in or Create a YoLink Account
After downloading the YoLink app onto your smart
phone, open the app and log in.
If you don’t have a YoLink account, tap Sign up for an
account and follow the steps.
