DESCRIPTION
The 12 SEER Series condensing unit is the outdoor part of a
versatile system of air conditioning. It is designed to be cus-
tom-matched with one of UPG’s complete line of evaporator
sections, each designed to serve a specific function. Match-
ing Air Handlers are available for upflow, downflow or hori-
zontal applications to provide a complete system. Electric
Heaters are available if required. Add-On coils are available
for use with upflow, downflow or horizontal furnaces and air
handlers.
WARRANTY
Single Phase Units:
5-year limited parts warranty.
10-year limited compressor warranty.
Three Phase Units:
1-year limited parts warranty.
5-year limited compressor warranty.
FEATURES
•QUALITY CONDENSER COILS - The coil is constructed
of enhanced copper tube and aluminum fins.
•COIL PROTECTION - Coils are protected from damage by
a polymer mesh applied between the coil face, and a PVC
coated steel coil guard.
•PROTECTED COMPRESSOR - The compressor is inter-
nally protected against high pressure and temperature.
This is accomplished by the simultaneous operation of
high pressure relief valve and a temperature sensor which
protects the compressor if undesirable operating condi-
tions occur. A liquid line filter-drier further protects the
compressor.
•DURABLE FINISH - The cabinet is made of pre-painted
steel. The pre-treated galvanized steel provides a better
paint to steel bond, which resists corrosion and rust creep.
Special primer formulas and matted textured champagne
finish insure less fading when exposed to sunlight.
•LOWER INSTALLED COST - Installation time and costs
are reduced by easy power and control wiring connec-
tions. Discharge line heat exchanger knockouts are pro-
vided, if required. Available in sweat connect models only.
The unit contains enough refrigerant for matching indoor
coils and 15 feet of interconnecting piping. The small base
dimension means less space is required on the ground or
roof.
•TOP DISCHARGE - The warm air from the top mounted
fan is blown up away from the structure and any landscap-
ing. This allows compact location on multi-unit applica-
tions.
•LOW OPERATING SOUND LEVEL - The upward air flow
carries the normal operating noise up away from the living
area. The rigid top panel effectively isolates any motor
sound. Isolator mounted compressor and the rippled fins
of the condenser coil muffle the normal fan motor and
compressor operating sounds.
•LOW MAINTENANCE - Long life permanently lubricated
motor-bearings need no annual servicing.
•EASY SERVICE ACCESS - Fully exposed refrigerant con-
nections, a single panel covering the electrical controls
and the molex plug in the control box connecting the con-
denser fan, make for easy servicing of the unit.
•SECURED SERVICE VALVES - Secured re-usable ser-
vice valves are provided on both the liquid and vapor
sweat connections for ease of evacuating and charging.
•U.L. and C.U.L. listed - approved for outdoor application.
Certified in accordance with the Unitary Small Equipment cer-
tification program, which is based on ARI Standard 210/240.

036-21001-005 Rev. C (0505)
2Unitary Products Group
Physical and Electrical Data - 1 Phase
MODEL DRCS0181BE DRCS0241BE DRCS0301BE DRCS0361BE DRCS0421BE DRCS0481BE DRCS0601BF
Unit Supply Voltage 208/230 – 1 – 60
Normal Voltage Range 187 to 252
Minimum Circuit Ampacity110.1 14.1 16.5 19.7 26.2 28.5 37.5
Max. Overcurrent Device Amps 215 25 25 30 45 50 60
Compressor Type3Recip Inertia Recip Recip ScrollBRecip ScrollB
Compressor Amps Rated Load 7.7 10.9 12.8 14.7 19.9 21.8 28.8
Locked Rotor 48 60 68 82 115 105 145
Crankcase Heater No No No Yes No No No
Fan Motor Amps Rated Load 0.5 0.5 0.5 1.3 1.3 1.3 1.5
Fan Diameter Inches 18 18 22 22 22 22 22
Fan Motor Rated HP 1/12 1/12 1/15 1/4 1/4 1/4 1/4 Nominal RPM 1,100 1,100 850 850 850 850 850
Nominal CFM 2,000 2,000 2,300 3,300 3,300 3,300 3,450
Coil Face Area Sq. Ft. 12.58 12.58 15.72 15.72 17.03 19.65 23.58 Rows Deep 1 1 1 1 1 1 1
Fin / Inches 18 18 18 18 18 18 22
Liquid Line OD 3/8 3/8 3/8 3/8 3/8 3/8 3/8
Vapor Line OD 3/4 3/4 3/4 3/4 7/8 7/8 1-1/8
Unit Charge (Lbs. - Oz.) 44 - 9 4 - 7 5 - 8 5 - 3 6 - 13 7 - 7 8 - 15
Charge Per Foot, Oz. 0.68 0.68 0.68 0.68 0.70 0.70 0.76
Operating Weight Lbs. 144 146 156 161 157 190 198
PHYSICAL AND ELECTRICAL DATA - 3 Phase
MODEL HABC-T036S HABC-T048S HABC-T060S HABC-W036S HABC-W048S HABC-W060S
Unit Supply Voltage 208/230 – 3 – 60 460 - 3 - 60
Normal Voltage Range 1187 to 252 432 to 504
Minimum Circuit Ampacity 13.3 18.9 22.9 7.6 9.6 12.0
Max. Overcurrent Device Amps 220 30 40 15 15 20
Compressor Type Inertia Inertia Scroll Inertia Inertia Scroll
Compressor Amps Rated Load 9.6 14.1 17.3 5.4 7.0 9.0
Locked Rotor 78.0 130.0 123.0 40.0 64.0 62.0
Crankcase Heater No No No No No No
Fan Motor Amps Rated Load 1.3 1.3 1.3 0.8 0.8 0.8
Fan Diameter Inches 22 22 22 22 22 22
Fan Motor Rated HP 1/4 1/4 1/4 1/4 1/4 1/4
Nominal RPM 850 850 850 850 850 850
Nominal CFM 3,300 3,300 3,400 3,300 3,300 3,400
Coil Face Area Sq. Ft. 15.72 17.03 23.58 15.72 17.03 23.58
Rows Deep 1 1 1 111
Fin / Inches 18 18 18 18 18 18
Liquid Line OD 3/8 3/8 3/8 3/8 3/8 3/8
Vapor Line OD 3/4 7/8 1-1/8 3/4 7/8 1-1/8
Unit Charge (Lbs. - Oz.) 46 - 2 7 - 10 9 - 3 6 - 2 7 - 10 9 - 3
Charge Per Foot, Oz. 0.68 0.70 0.76 0.68 0.70 0.76
Operating Weight Lbs. 157 184 198 157 184 198
1. Rated in accordance with ARI Standard 110, utilization range “A”.
2. Dual element fuses or HACR circuit breaker.
3. All scrolls listed with a superscript “B” are Bristol scrolls. All scrolls listed with a superscript “C” are Copeland scrolls.
4. The Unit Charge is correct for the outdoor unit, matched indoor coil and 15 feet of refrigerant tubing. For tubing lengths other than 15 feet, add or sub-
tract the amount of refrigerant, using the difference in length multiplied by the per foot value.

036-21001-005 Rev. C (0505)
Unitary Products Group 3
Additional R-22 Charge / Orifice Size for Various Matched Systems - 1 Phase
Outdoor Unit DRCS0181BE DRCS0241BE DRCS0301BE DRCS0361BE DRCS0421BE DRCS0481BE DRCS0601CE
Unit Orifice (s)153 59 63 73 78 87 –
Factory R-22 Charge, lbs-oz. 4 - 9 4 - 7 5 - 8 5 - 3 6 - 13 7 - 7 8 - 15
Indoor Coil5Coil Orifice4Orifice or TXV Kit 2- Additional Charge, Oz.3
G2FD024(S,H)14,17 61 53 + 3 59 + 3 – – – – –
701 + 3 701 + 3 – – – – –
G2FD030(S,H)17 65 53 + 6 59 + 6 63 + 4 – – – –
701 + 6 701 + 6 701 + 4 – – – –
G2FD035(S,H)14 65 53 + 6 59 + 6 63 + 4 73 + 0 – – –
701 + 6 701 + 6 701 + 4 702 + 0 – – –
G2FD036(S,H)17 75 – 59 + 10 63 + 8 73 + 6 – – –
– 701 + 10 701 + 8 702 + 6 – – –
G2FD036(S,H)21 75 – – 63 + 11 73 + 8 – – –
– – 701 + 11 702 + 8 – – –
G2FD042(S,H)21 78 – – 63 + 14 73 + 12 78 + 0 – –
– – 701 + 14 702 + 12 702 + 0 – –
G2FD046(S,H)17 78 – – 63 + 16 73 + 12 78 + 0 87 + 0 –
– – 701 + 16 702 + 12 702 + 0 703 + 0 –
G2FD048(S,H)21,24 84 – – – 73 + 16 78 + 10 87 + 11 –
– – – 702 + 16 702 + 10 703 + 11 –
G2FD060(S,H)24 90 – – – – – 87 + 15 –
– – – – – 703 + 15 703 + 5
G2FD061H24 90 – – – – – 87 + 19 –
– – – – – 703 + 19 703 + 11
G1HA024H14 61 053 + 03 059 + 03 – – – – –
G1HA024H14(T) TXV 701 + 03 + 03 – – – – –
G1HA036H14 75 – 59 + 12 63 + 11 73 + 08 – – –
G1HA036H14(T) TXV 702 – – + 11 + 08 – – –
G1HA036H17 78 – – 63 + 14 73 + 12 – – –
G1HA036H17(T) TXV 702 – – + 14 + 12 – – –
G1HA048H21 84 – – – 73 + 09 78 + 07 87 + 08
G1HA048H21(T) TXV 703 – – – + 09 + 07 + 08
G1HA060H24 90 – – – – – 87 + 15
G1HA060H24(T) TXV 703 – – – – – 87 + 15 703 + 5
G1HD024 59 53 + 5 59 + 4 – – – – –
701 + 5 701 + 4 – – – – –
G1HD036 69 – 59 + 13 63 + 11 73 + 7 – – –
– 701 + 13 701 + 11 702 + 7 – – –
G1HD048 81 – – – 73 + 13 78 + 3 87 + 4 –
– – – 702 + 13 702 + 3 703 + 4 –
G1HD060 93 – – – – – 87 + 12 –
– – – – – 703 + 12 703 + 0
G1FA/G1UA024S14,17(T) 59 53 + 0 59 + 0 – – – – –
7015+ 0 701 + 0 – – – –
G1FA/G1UA030S14(T) 65 – 59 + 3 63 + 0 – – – –
– 701 + 3 701 + 0 – – – –
G1FA/G1UA036S14(T) 73 – 59 + 8 63 + 6 73 + 3 – – –
– 701 + 8 701 + 6 702 + 3 – – –
G1FA/G1UA036S17,21(T) 73 – 59 + 6 63 + 4 73 + 0 – – –
– 701 + 6 701 + 4 702 + 0 – – –
G1FA/G1UA048S17(T) 84 – – 63 + 16 73 + 13 78 + 0 87 + 0 –
– – 701 + 16 702 + 13 702 + 0 703 + 0 –
G1FA/G1UA048S21(T) 84 – – 63 + 18 73 + 9 78 + 7 87 + 8 –
– – 701 + 18 702 + 9 702 + 7 703 + 8 –
G1FA/G1UA060S21,24(T) 90 – – – – 78 + 16 87 + 15 –
– – – – 702 + 16 703 + 15 703 + 5
G1NA030S17K 63 53 + 6 59 + 6 63 + 4 – – – –
701 + 6 701 + 6 701 + 4 – – – –
G1NA030S21M 78 53 + 6 59 + 6 63 + 4 – – – –
701 + 6 701 + 6 701 + 4 – – – –
See notes on Page 4.

036-21001-005 Rev. C (0505)
4Unitary Products Group
PROCEDURES:
1.Unit factory charge listed on the unit nameplate includes refrigerant for the condenser, the smallest evaporator and for 15 feet of interconnecting line tubing.
2. Verify the orifice size and additional charge required for specific evaporator coil in the system using the above table.
3. Additional charge for the amount of interconnecting line tubing greater than 15 feet at the rate specified in the table above.
4. Permanently mark the unit nameplate with the total system charge. Total System Charge = Base Charge (as shipped) + adder for
evaporator + adder for line set.
5. If the orifice in the evaporator was changed, verify the evaporator nameplate has been marked with the correct orifice size.
G1NA036S17L 63 – – 63 + 15 73 + 12 – – –
– – 701 + 15 702 + 12 – – –
G1NA048S21D 78 – – – 73 + 12 78 + 0 87 + 0 –
– – – 702 + 12 702 + 0 703 + 0 –
G1NA048S24P 63 – – – 73 + 13 78 + 2 87 + 1 –
– – – 702 + 13 702 + 2 703 + 1 –
G1NA060S24T 78 –––––––
––––––703+0
G1NF024SOF 63 –––––––
–––––––
G1NF036SOF 67 – 59 + 12 63 + 0 73 + 7 – – –
– 701 + 12 701 + 0 702 + 7 – – –
G1NF048SOF 78 – – – – 78 + 21 87 + 6 –
– – – – 702 + 21 703 + 6 –
G1NF060SOF 87 – – – – – 87 + 18 –
– – – – – 703 + 18 –
F(2,3)RP024N,H06(T) 61 53 + 4 59 + 4 – – – – –
701 + 4 701 + 4 – – – – –
F(2,3)RP030N06(T) 65 – 59 + 6 63 + 4 – – – –
– 701 + 6 701 + 4 – – – –
F(2,3)RP036N06(T) 75 – – 63 + 4 73 + 8 – – –
– – 701 + 4 702 + 8 – – –
F(2,3)RP042N06(T) 78 – – – 73 + 13 78 + 0 – –
– – – 702 + 13 702 + 0 – –
F(2,3)FP048N06(T) 84 – – – 73 + 16 78 + 10 87 + 11 –
– – – 702 + 16 702 + 10 703 + 11 –
F(2,3)FP060N06(T) 90 – – – – – 87 + 15 –
– – – – – 703 + 15 7035+ 5
F(2,3)FV060N06(T) 90 – – – – – 87 + 15 –
– – – – – 703 + 15 703 + 5
MDD30MSD 90 53 + 6 59 + 6 63 + 4 – – – –
701 + 6 107 + 6 701 + 4 – – – –
MDD48DSD 90 – – – 73 + 12 81 + 0 87 + 0 –
– – – 702 + 12 702 + 0 703 + 0 –
FOOTNOTES:
1. These orifices are factory mounted in the flow control device of each indoor coil and must be removed for TXV installation.
2. A TXV kit must be used with these coils to obtain system performance. (701,702,703 indicates 1TV07 ...series).
3. Systems matched with furnaces or air handlers not equipped with blower-off delays, may require blower Time Delay Kit #6918A5011.
4. These orifices are factory mounted in the flow control device of each indoor coil. A TXV is factory mounted if the model number has a (T) suffix.
5. This TXV is factory mounted in indoor coils, if the model number has a (T) suffix.
Additional R-22 Charge / Orifice Size for Various Matched Systems (Continued)- 1 Phase
Outdoor Unit DRCS0181BE DRCS0241BE DRCS0301BE DRCS0361BE DRCS0421BE DRCS0481BE DRCS0601CE
Unit Orifice (s)153 59 63 73 78 87 –
Factory R-22 Charge, lbs-oz. 4 - 9 4 - 7 5 - 8 5 - 3 6 - 13 7 - 7 8 - 15
Indoor Coil5Coil Orifice4Orifice or TXV Kit 2- Additional Charge, Oz.3

036-21001-005 Rev. C (0505)
Unitary Products Group 5
PROCEDURES:
1.Unit factory charge listed on the unit nameplate includes refrigerant for the condenser, the smallest evaporator and for 15 feet of interconnecting line tubing.
2.Verify the orifice size and additional charge required for specific evaporator coil in the system using the above table.
3.Additional charge for the amount of interconnecting line tubing greater than 15 feet at the rate specified in the table above.
4.Permanently mark the unit nameplate with the total system charge. Total System Charge = Base Charge (as shipped) + adder for evaporator + adder
for line set.
5.If the orifice in the evaporator was changed, verify the evaporator nameplate has been marked with the correct orifice size.
Additional R-22 Charge / Orifice Size for Various Matched Systems - 3 Phase
Outdoor Unit HABC-T,W036S HABC-T,W048S HABC-T,W060S
Unit Orifice (s) 1–––
Factory R-22 Charge, lbs-oz 6 - 2 7 - 10 9 - 3
Indoor Coil Coil Orifice TVX Kit2= Additional Charge, Oz3
G2FD035(S,H)14 65 702 + 0 – –
G2FD036(S,H)17,21 75 702 + 3 – –
G2FD042(S,H)21 78 702 + 0 – –
G2FD046(S,H)17 78 702 + 9 703 + 0 –
G2FD048(S,H)21,24 84 702 + 17 703 + 9 –
G2FD060(S,H)24 90 – 703 + 0 703 + 20
G2FD061H24 90 – 703 + 6 703 + 25
G1FA/G1UA036S14 73 702 + 1 – –
G1FA/G1UA036S17,21 73 702 + 0 – –
G1FA/G1UA048S17 84 – 703 + 2 –
G1FA/G1UA048S21 84 702 + 9 703 + 7 –
G1FA/G1UA060S21,24 90 – 703 + 14 703 + 20
G1NA036S17L 71 702 + 0 – –
G1NA048S21D 78 702 + 0 703 + 0 –
G1NA048S24P 78 702 + 0 703 + 0 –
G1NA060S24T 87 – – 703 + 0
G1NF036SOF 67 702 + 0 – –
G1NF048SOF 78 – 702 + 0 –
G1NF060SOF 87 – – 703 + 0
G1HD036 69 702 + 5 – –
G1HD048 81 702 + 11 703 + 0 –
G1HD060 93 – 703 + 0 703 + 20
FOOTNOTES:
1. These orifices are factory mounted in the flow control device of each indoor coil and must be removed for TXV installation.
2. A TXV kit must be used with these coils to obtain system performance. (701,702,703 indicates 1TV07 ...series).
3. Systems matched with furnaces or air handlers not equipped with blower-off delays, may require blower Time Delay Kit #6918A5011.

036-21001-005 Rev. C (0505)
6Unitary Products Group
- = Not applicable.
COOLING CAPACITY - With Air Handler Coils
UNIT MODEL AIR HANDLER COIL1
MODEL
COOLING
MODEL ELECTRIC2
HEAT KW WRATED
CFM NET MBH SEER W/O TXV SEER
WITH TXV3EER
TOTAL SENS.
1 PH 12 SEER AC WITH N1AH / G2FD
DRCS0181BE N1AHB0806 2,5,8,10 17 G2FD024(S,H)17 600 19.6 13.2 12.50 12.50 11.60
DRCS0241BE N1AHB0806 2,5,8,10 17 G2FD024(S,H)17 750 23.6 16.9 12.00 12.00 11.00
N1AHB0806 2,5,8,10 17 G2FD030(S,H)17 750 24.0 17.3 12.00 12.00 11.10
DRCS0301BE N1AHB1206 2,5,8,10 17 G2FD030(S,H)17 1000 30.0 21.3 12.00 12.00 11.00
N1AHB1206 2,5,8,10 17 G2FD036(S,H)17 1000 30.6 21.8 12.25 12.25 11.20
DRCS0361BE N1AHB1206 5,8,10,15,19 17 G2FD036(S,H)17 1200 33.8 23.6 11.50 11.50 10.70
N1AHB1206 5,8,10,15,19 17 G2FD046(S,H)17 1200 35.0 24.4 12.00 12.00 10.90
DRCS0421BE N1AHC1606 5,8,10,15,20 21 G2FD042(S,H)21 1400 41.0 29.3 12.00 – 10.50
N1AHC1606 5,8,10,15,20 21 G2FD048(S,H)21 1400 42.5 30.6 12.00 – 10.75
DRCS0481BE N1AHC1606 5,8,10,15,20 21 G2FD048(S,H)21 1575 46.5 36.0 12.20 12.20 10.90 N1AHD2006 8,10,15,20,25,30 24 G2FD060(S,H)24 1575 48.0 36.4 12.50 12.50 11.10
N1AHD2006 8,10,15,20,25,30 24 G2FD061H24 1575 48.5 34.5 12.50 12.50 11.20
DRCS0601CE N1AHD2006 8,10,15,20,25,30 24 G2FD060(S,H)24 1800 57.5 42.6 – 12.00 10.40
N1AHD2006 8,10,15,20,25,30 24 G2FD061H24 1850 58.0 43.2 – 12.00 10.45
3 PH 12 SEER AC WITH N1AH / G2FD
HABC-(T,W)036S N1AHB1246 5,8,10,15,18 17 G2FD036(S,H)17 1255 33.6 24.9 – 12.00 10.65 N1AHB1246 5,8,10,15,18 17 G2FD046(S,H)17 1250 34.8 25.8 – 12.00 10.95
N1AHC1646 5,8,10,15,18 21 G2FD048(S,H)21 1600 45.5 33.7 – 12.20 11.20
HABC-(T,W)048S N1AHD2046 8,10,15,20,25,30 24 G2FD060(S,H)24 1620 47.0 34.8 – 12.50 11.45
N1AHD2046 8,10,15,20,25,30 24 G2FD061H24 1600 47.5 35.2 – 12.50 11.50
HABC-(T,W)060S N1AHD2046 8,10,15,20,25,30 24 G2FD060(S,H)24(T) 1800 56.5 43.4 – 12.00 10.10
N1AHD2046 8,10,15,20,25,30 24 G2FD061H24 1800 56.5 43.8 – 12.00 10.15
1 PH 12 SEER / N1VS - VARIABLE SPEED
DRCS0181BE N1VSB12 10,15,18 17 G2FD024(S,H)17 650 20.2 13.2 13.75 13.75 12.80
DRCS0241BE N1VSB12 10,15,18 17 G2FD024(S,H)17 725 24.2 16.9 13.35 13.35 12.15
N1VSB12 10,15,18 17 G2FD036(S,H)17 775 25.2 17.8 13.50 13.50 12.50
DRCS0301BE N1VSB12 10,15,18 17 G2FD036(S,H)17 1000 31.0 21.9 13.25 13.25 12.15 N1VSB12 10,15,18 17 G2FD046(S,H)17 1000 32.0 22.3 13.75 13.75 12.55
N1VSB12 10,15,18 17 G2FD046(S,H)17 1000 32.0 22.3 13.75 13.75 12.55
DRCS0361BE N1VSB12 10,15,18 17 G2FD036(S,H)17 1200 34.8 23.6 12.40 12.40 11.35 N1VSB12 10,15,18 17 G2FD046(S,H)17 1210 35.8 24.4 13.00 13.00 11.65
N1VSC16 10,15,18 21 G2FD048(S,H)21 1155 36.8 25.1 13.40 13.40 12.20
DRCS0421BE N1VSC16 10,15,18 21 G2FD048(S,H)21 1400 43.0 30.6 13.00 – 11.55
N1VSC16 10,15,18 21 G2FD048(S,H)21 1590 47.0 30.6 12.80 – 11.40
DRCS0481BE N1VSC16 10,15,18 21 G2FD048(S,H)21 1590 47.0 34.9 12.80 12.80 11.40 N1VSD20 10,15,18,30 24 G2FD060(S,H)24 1560 48.5 36.0 13.25 13.25 11.75
N1VSD20 10,15,18,30 24 G2FD061H24 1560 49.0 36.4 13.30 13.30 11.90
DRCS0601CE N1VSD20 10,15,18,30 24 G2FD060(S,H)24 1780 56.0 42.3 – 12.10 10.25
N1VSD20 10,15,18,30 24 G2FD061H24 1780 56.5 42.7 – 12.25 10.40
1 PH 12 SEER AC / F2RP / RC / FC4,5
DRCS0181BE F2RC/F2FC024 5,8,10 18 – 600 20.0 13.2 12.50 12.50 11.70
F2RP/F2FP024 5,8,10 18 – 600 20.0 13.2 12.50 12.50 11.70
DRCS0241BE
F2RC/F2FC024 5,8,10 18 – 750 23.4 17.5 11.50 11.50 10.85
F2RC/F2FC030 5,8,10,15 18 – 750 23.4 17.5 11.50 11.50 10.85
F2RP/F2FP024 5,8,10 18 – 750 23.6 17.5 12.00 12.00 10.90
F2RP/F2FP030 5,8,10,15 18 – 750 24.0 17.9 12.00 12.00 11.10
DRCS0301BE
F2RC/F2FC030 5,8,10,15 18 – 1000 29.8 21.5 12.00 12.00 11.00
F2RC/F2FC036 5,8,10,15 21 – 1000 31.0 22.4 12.25 12.25 11.30
F2RP/F2FP030 5,8,10,15 18 – 1000 30.2 22.9 12.00 12.00 11.15
F2RP/F2FP036 5,8,10,15,19 21 – 1000 30.2 23.5 12.00 12.00 11.15
DRCS0361BE
F2RC/F2FC036 5,8,10,15 21 – 1200 34.6 26.2 12.00 12.00 10.85
F2RP/F2FP036 5,8,10,15,19 21 – 1200 34.6 26.2 12.00 12.00 10.85
F2RP/F2FP042 5,8,10,15 21 – 1200 34.8 26.3 11.60 11.60 10.70
F2FP048 5,8,10,15,20,25 24 – 1200 35.4 26.7 12.00 12.00 10.90
DRCS0421BE F2RP/F2FP042 5,8,10,15 21 – 1400 40.5 28.9 11.80 – 10.35
F2FP048 5,8,10,15,20,25 24 – 1400 42.5 30.5 12.00 – 10.55
DRCS0481BE F2FP048 5,8,10,15,20,25 24 – 1565 46.5 34.9 11.40 11.40 10.75 F2FP060 5,8,10,15,20,25 24 – 1575 48.0 35.9 11.50 11.50 10.70
F2FV060 8,10,15,20,25 24 – 1560 48.5 35.9 13.20 13.20 11.70
DRCS0601CE F2FP060 5,8,10,15,20,25 24 – 1800 56.0 42.0 – 12.00 10.00
F2FV060 8,10,15,20,25 24 – 1780 56.0 42.3 – 12.10 10.30
Rated in accordance with DOE test procedures (Federal Register 12-27-79 and 3-18-88) and ARI Standards 210.
Cooling MBH based on 80°F entering air temperature, 50% RH, and rated air flow.
EER (Energy Efficiency Ratio) is the total cooling output in BTU’s at a 95°F outdoor ambient divided by the total electric power in watt-hours at those conditions.
SEER (Seasonal Energy Efficiency Ratio) is the total cooling output in BTU’s during a normal annual usage period for cooling divided by the total electric power
input in watt-hours during the same period.
1. G2FD coils available with a factory installed horizontal drain pan. See price pages for specific model number.
2. Single phase units require single phase 2HK heaters. Three phase units require three phase 2HK heaters.
3. TXV = Thermal Expansion Valve kit required. Use 1TV700 series kit.
4. To meet R=4.2 insulation requirements, substitute F2FP for F2RP, and F2FC for F2RC. models. All ratings remain the same.
5. FG8, FG9, and FL8 furnaces and F2RP / F2RC air handlers have B.O.D (Blower on Delay) standard.

036-21001-005 Rev. C (0505)
Unitary Products Group 7
COOLING CAPACITY - Upflow, Downflow & Horizontal Furnaces and Coils
UNIT MODEL FURNACE** COIL
MODEL
COOLING
CFM RANGE
(Min.-max.) WRATEDCFM
NET MBH SEER
W/O TXV SEER + TXV1EER
TOTAL SENS.
DRCS0181BE 525
675
14,17 G1FA024S14,17 600 19.2 13.0 12.00* 12.00 11.35
14 G1HA024H14 600 19.2 13.6 12.00* – 11.50
14 G1HA024H14T 600 19.2 13.6 – 12.00* 11.60
- G1HD024 600 20.0 13.5 12.50* 12.50 11.70
17 G1NA030S17K 600 20.0 13.5 12.75* 12.75 11.75
21 G1NA030S21M 600 20.0 13.5 12.50* 12.50 11.75
14,17 G1UA024S14,17 600 19.2 13.0 12.00* 12.00 11.35
14,17 G2FD024(S,H)14,17 600 19.6 13.2 12.50* 12.50 11.60
17 G2FD030(S,H)17 600 20.0 13.5 12.60* 12.60 11.75
14 G2FD035(S,H)14 600 20.0 13.5 12.60* 12.60 11.75
19 MDD30MSD 600 20.0 13.5 12.50* 12.50 11.75
DRCS0241BE 650
850
14,17 G1FA024S14,17 750 23.0 16.4 11.80* 11.80 10.70
14 G1FA030S14 750 23.6 16.9 12.00* 12.00 11.00
14 G1FA036S14 750 24.2 17.6 12.00* 12.00 11.25
17,21 G1FA036S17,21 750 24.0 17.3 12.00* 12.00 11.10
14 G1HA024H14 750 19.2 13.6 12.00* – 10.90
14 G1HA024H14T 800 23.5 16.7 – 12.00* 10.90
14 G1HA036H14 800 24.6 17.5 12.00 – 11.35
- G1HD024 750 24.0 17.2 12.00* 12.00 11.05
- G1HD036 750 24.6 17.6 12.10* 12.10 11.35
17 G1NA030S17K 750 24.0 17.2 12.00* 12.00 11.15
21 G1NA030S21M 750 24.0 17.2 12.00* 12.00 11.15
14,17 G1UA024S14,17 750 23.0 16.4 11.80* 11.80 10.70
14 G1UA030S14 750 23.6 16.9 12.00* 12.00 11.00
14 G1UA036S14 750 24.2 17.6 12.00* 12.00 11.25
17,21 G1UA036S17,21 750 24.0 17.3 12.00* 12.00 11.10
14,17 G2FD024(S,H)14,17 750 23.6 16.9 12.00* 12.00 11.00
17 G2FD030(S,H)17 750 24.0 17.3 12.00* 12.00 11.10
14 G2FD035(S,H)14 750 24.0 17.3 12.10* 12.10 11.10
17 G2FD036(S,H)17 750 24.6 17.8 12.15* 12.15 11.35
19 MDD30MSD 750 24.0 17.2 12.00* 12.00 11.15
DRCS0301BE 875
1125
14 G1FA030S14 1000 29.2 20.7 11.85* 11.85 10.80
14 G1FA036S14 1000 30.4 21.6 12.00* 12.00 11.10
17,21 G1FA036S17,21 1000 30.0 21.3 12.00* 12.00 11.00
17 G1FA048S17 1000 31.2 22.3 12.50* 12.50 11.45
21 G1FA048S21 1000 31.2 22.3 12.50* 12.50 11.35
14 G1HA036H14 1000 30.3 21.5 12.00* – 11.25
14 G1HA036H14 1000 30.2 21.4 – 12.00* 11.25
17 G1HA036H17 1000 30.4 21.9 12.00* – 11.35
17 G1HA036H17T 1000 30.5 22.0 – 12.00* 11.35
- G1HD036 1000 30.8 21.9 12.75* 12.75 11.25
17 G1NA030S17K 1000 30.2 21.4 12.00* 12.00 11.05
21 G1NA030S21M 1000 30.2 21.4 12.00* 12.00 11.05
17 G1NA036S17L 1000 31.4 22.3 12.50* 12.50 11.45
14 G1UA030S14 1000 29.2 20.7 11.85* 11.85 10.80
14 G1UA036S14 1000 30.4 21.6 12.00* 12.00 11.10
17,21 G1UA036S17,21 1000 30.0 21.3 12.00* 12.00 11.00
17 G1UA048S17 1000 31.2 22.3 12.50* 12.50 11.45
21 G1UA048S21 1000 31.2 22.3 12.50* 12.50 11.35
17 G2FD030(S,H)17 1000 30.0 21.3 12.00* 12.00 11.00
14 G2FD035(S,H)14 1000 30.0 21.3 12.00* 12.00 11.00
17 G2FD036(S,H)17 1000 30.6 21.8 12.25* 12.25 11.20
21 G2FD036(S,H)21 1000 30.8 21.9 12.25* 12.25 11.25
21 G2FD042(S,H)21 1000 31.0 22.1 12.50* 12.50 11.35
17 G2FD046(S,H)17 1000 31.4 22.3 12.50* 12.50 11.45
19 MDD30MSD 1000 30.2 21.4 12.00* 12.00 11.05
For Notes See Page 9.

036-21001-005 Rev. C (0505)
8Unitary Products Group
DRCS0361BE 1050
1350
14 G1FA036S14 1200 33.6 23.4 11.50* 11.50 10.60
17,21 G1FA036S17,21 1200 33.0 23.0 11.25* 11.25 10.45
17 G1FA048S17 1200 35.0 24.4 12.00* 12.00 10.90
21 G1FA048S21 1200 34.0 25.2 12.00* 12.00 10.70
14 G1HA036H14 1150 33.5 23.8 12.00* – 10.75
14 G1HA036H14 1150 33.4 23.7 – 12.00* 10.75
17 G1HA036H17 1200 34.0 24.5 12.00* – 10.80
17 G1HA036H17T 1200 34.0 24.5 – 12.00* 10.80
21 G1HA048H21 1200 34.0 24.8 12.00* – 10.70
21 G1HA048H21T 1200 33.3 24.3 – 12.00 10.70
- G1HD036 1200 34.0 23.7 11.80* 11.80 10.70
- G1HD048 1200 35.4 24.7 12.00* 12.00 11.00
17 G1NA036S17L 1200 35.0 24.8 12.00* 12.00 10.90
21 G1NA048S21D 1200 35.0 24.8 12.00* 12.00 10.90
14 G1UA036S14 1200 33.6 23.4 11.50* 11.50 10.60
17,21 G1UA036S17,21 1200 33.0 23.0 11.25* 11.25 10.45
17 G1UA048S17 1200 35.0 24.4 12.00* 12.00 10.90
21 G1UA048S21 1200 34.0 25.2 12.00* 12.00 10.70
21 G1NA048S21D 1200 35.0 25.2 12.00* 12.00 10.40
14 G2FD035(S,H)14 1200 33.0 23.0 11.25* 11.25 10.45
17 G2FD036(S,H)17 1200 33.8 23.6 11.50* 11.50 10.70
21 G2FD036(S,H)21 1200 34.2 23.8 12.50* 12.50 10.75
21 G2FD042(S,H)21 1200 34.6 24.1 12.00* 12.00 10.80
17 G2FD046(S,H)17 1200 35.0 24.4 12.00* 12.00 10.90
21,24 G2FD048(S,H)21,24 1200 36.0 25.1 12.10* 12.10 11.10
19 MDD48MSD 1200 35.0 25.2 12.00* 12.00 10.40
HABC-(T,W)036S 1050
1350
14 G1FA036S14 1235 33.4 25.0 – 11.50 10.65
17,21 G1FA036S17,21 1235 33.0 24.4 – 11.50 10.55
21 G1FA048S21 1235 35.0 25.9 – 12.00 10.70
- G1HD036 1235 33.4 24.7 – 11.80 10.70
- G1HD048 1235 35.0 25.8 – 12.00 11.05
17 G1NA036S17L 1200 35.0 24.4 – 12.00 10.90
21 G1NA048S21D 1200 35.0 24.4 – 12.00 10.90
14 G1UA036S14 1200 33.4 25.0 – 11.50 10.65
17,21 G1UA036S17,21 1235 33.0 24.4 – 11.50 10.55
21 G1UA048S21 1235 35.0 25.9 – 12.00 10.70
14 G2FD035(S,H)14 1200 32.8 24.3 – 11.55 10.55
17 G2FD036(S,H)17 1250 33.6 24.9 – 12.00 10.65
21 G2FD036(S,H)21 1200 34.2 25.3 – 12.00 10.90
21 G2FD042(S,H)21 1235 34.4 25.5 – 12.00 10.90
17 G2FD046(S,H)17 1250 34.8 25.8 – 12.00 10.95
21,24 G2FD048(S,H)21,24 1250 35.4 26.2 – 12.10 11.15
DRCS0421BE 1225
1575
17 G1FA048S17 1400 42.0 30.2 12.00* – 10.60
21 G1FA048S21 1400 41.5 29.7 12.00 – 10.65
21,24 G1FA060S21,24 1400 43.0 30.7 12.50 – 10.95
21 G1HA048H21 1400 41.5 30.3 12.00* – 10.65
21 G1HA048H21T 1400 40.7 29.7 – 12.00 10.65
- G1HD048 1400 41.5 29.7 12.00 – 10.60
21 G1NA048S21D 1400 41.0 28.6 12.00* – 10.40
17 G1UA048S17 1400 42.0 30.2 12.00* – 10.60
21 G1UA048S21 1400 41.5 29.7 12.00 – 10.65
21,24 G1UA060S21,24 1400 43.0 30.7 12.50* – 10.95
21 G2FD042(S,H)21 1400 41.0 29.3 12.00* – 10.50
17 G2FD046(S,H)17 1400 42.0 30.2 12.00* – 10.60
21,24 G2FD048(S,H)21,24 1400 42.5 30.6 12.00 – 10.75
19 MDD48DSD 1400 41.0 28.6 12.00* - 10.40
For Notes See Page 9.
COOLING CAPACITY - Upflow, Downflow & Horizontal Furnaces and Coils (Continued)
UNIT MODEL FURNACE** COIL
MODEL
COOLING
CFM RANGE
(Min.-max.) WRATEDCFM
NET MBH SEER
W/O TXV SEER + TXV1EER
TOTAL SENS.

036-21001-005 Rev. C (0505)
Unitary Products Group 9
*Requires 2FD Blower Time Delay unless a standard furnace is equipped with one.
** Refer to Quick Selection Chart for specific furnace match-up.
DRCS0481BE 1375
1775
17 G1FA048S17 1575 45.5 34.1 12.00* 12.00 11.00
21 G1FA048S21 1575 46.5 34.9 12.00* 12.00 11.00
21,24 G1FA060S21,24 1575 48.0 36.0 12.50* 12.50 11.10
21 G1HA048H21 1550 46.0 33.6 12.00* – 11.10
21 G1HA048H21T 1525 46.0 33.6 – 12.00* 11.11
24 G1HA060H24 1575 47.0 33.8 12.00* – 11.10
24 G1HA060H24T 1575 47.0 33.8 – 12.00* 11.10
- G1HD048 1575 46.0 34.5 12.00* 12.00 10.80
- G1HD060 1575 47.5 35.6 12.40* 12.40 11.05
21 G1NA048S21D 1575 46.0 34.5 12.00* 12.00 10.70
17 G1UA048S17 1575 45.5 34.1 12.00* 12.00 11.00
21 G1UA048S21 1575 46.5 34.9 12.00* 12.00 11.00
21,24 G1UA060S21,24 1575 48.0 36.0 12.50* 12.50 11.10
17 G2FD046(S,H)17 1575 45.5 34.1 12.00* 12.00 10.80
21,24 G2FD048(S,H)21,24 1575 46.5 34.9 12.20* 12.20 10.90
24 G2FD060(S,H)24 1575 48.0 36.0 12.50* 12.50 11.10
24 G2FD061H24 1575 48.5 36.4 12.50* 12.50 11.20
19 MDD48DSD 1575 46.0 34.5 12.00* 12.00 10.70
HABC-(T,W)048S 1400
1800
17 G1FA048S17 1500 44.5 32.9 – 12.00 10.50
21 G1FA048S21 1600 45.5 33.7 – 12.00 11.00
21,24 G1FA060S21,24 1600 47.0 34.8 – 12.50 11.45
- G1HD048 1600 45.0 33.3 – 12.00 11.15
- G1HD060 1600 46.5 36.1 – 12.40 11.40
21 G1NA048S21D 1400 46.0 34.0 – 12.00 11.20
17 G1UA048S17 1500 44.5 32.9 – 12.00 10.50
21 G1UA048S21 1600 45.5 33.7 – 12.00 11.00
21,24 G1UA060S21,24 1600 47.0 34.8 – 12.50 11.45
17 G2FD046(S,H)17 1500 44.5 32.9 – 12.00 10.50
21,24 G2FD048(S,H)21,24 1600 45.5 33.7 – 12.20 11.20
24 G2FD060(S,H)24 1600 47.0 34.8 – 12.50 11.45
24 G2FD061H24 1600 47.5 35.2 – 12.50 11.50
DRCS0601BF 1600
2200
21 G1FA060S21(T) 1800 56.5 43.4 – 12.00 10.10
- G1HD060 1800 55.5 42.8 – 11.75 10.00
24 G1NA060S24T 1800 55.5 42.1 – 11.75 10.00
21 G1UA060S21(T) 1800 56.5 43.4 – 12.00 10.10
24 G2FD060(S,H)24(T) 1800 56.5 43.4 – 12.00 10.10
24 G2FD061H24 1800 56.5 43.8 – 12.00 10.15
24 G1HA60S24(T) 1710 56.0 42.5 – 12.00 10.15
HABC-(T,W)060S 1600
2200
21,24 G1FA060S21,24 1800 57.5 42.6 – 12.00 10.40
24 G1HA060H24T 1800 57.5 41.4 – 12.00* 10.40
- G1HD060 2000 57.5 42.6 – 12.00 10.25
24 G1NA060S24T 1850 57.5 38.9 – 12.00* 10.50
21,24 G1UA060S21,24 1800 57.5 42.6 – 12.00 10.40
24 G2FD060(S,H)24 1800 57.5 42.6 – 12.00 10.40
24 G2FD061H24 1850 58.0 43.2 – 12.00 10.45
1. TXV = Use 1TV700 Series Kit.
COOLING CAPACITY - Upflow, Downflow & Horizontal Furnaces and Coils (Continued)
UNIT MODEL FURNACE** COIL
MODEL
COOLING
CFM RANGE
(Min.-max.) WRATEDCFM
NET MBH SEER
W/O TXV SEER + TXV1EER
TOTAL SENS.

036-21001-005 Rev. C (0505)
10 Unitary Products Group
COOLING CAPACITY - With Variable Speed Furnaces
UNIT MODEL VARIABLE SPEED
FURNACE MODEL COIL MODEL1WCOOLING
RATED
CFM NET MBH SEER W/O TXV SEER
+ TXV2EER
TOTAL SENS.
1 PH 12 SEER AC - VARIABLE SPEED3
DRCS0181BE
G8V***12UHA/(F,L)C8V***A12UH G1FA024S14 14 600 19.6 13.4 – 13.00 12.55
G8V***12UHA/(F,L)C8V***A12UH G2FD024(S,H)14 14 600 20.0 13.6 – 14.00 12.90
G9V***12DHB G2FD024(S,H)17 17 620 20.2 14.0 – 13.75 12.90
G9V***12UPB G1FA024S17 17 620 19.6 13.4 – 13.00 12.45
G9V***12UPB G2FD024(S,H)17 17 620 20.0 13.6 – 13.75 12.80
DRCS0241BE
G8V***12UHA/(F,L)C8V***A12UH G1FA024S14 14 750 23.4 16.8 – 13.00 11.60
G8V***12UHA/(F,L)C8V***A12UH G2FD024(S,H)14 14 750 24.0 17.3 – 13.00 12.05
G9V***12DHB G2FD024(S,H)17 17 815 24.2 17.5 – 12.50 11.85
G9V***12UPB G1FA024S17 17 730 23.6 17.0 – 13.00 11.80
G9V***12UPB G2FD024(S,H)17 17 730 24.2 17.5 – 13.00 12.10
DRCS0301BE
G8V***12UHA/(F,L)C8V***A12UH G1FA030S14 14 975 29.6 21.1 – 12.50 11.55
G8V***12UHA/(F,L)C8V***A12UH G2FD035(S,H)14 14 975 30.4 21.7 – 13.00 11.80
G8V***16UHB/(F,L)C8V***B16UH G1FA036S17 17 1050 30.6 21.9 – 13.00 11.95
G8V***16UHB/(F,L)C8V***B16UH G2FD030(S,H)17 17 1050 30.6 21.9 – 13.00 11.95
G9V***12DHB G2FD030(S,H)17 17 1050 30.6 21.9 – 12.50 11.60
G9V***12UPB G1FA036S17 17 1020 30.4 21.7 – 12.75 11.70
G9V***12UPB G2FD030(S,H)17 17 1020 30.4 21.7 – 12.75 11.70
G9V***16UPC G1FA036S21 21 1000 30.6 21.9 – 13.00 12.00
G9V***16UPC G2FD036(S,H)21 21 1000 31.4 22.5 – 13.00 12.30
DRCS0361BE
G8V***12UHA/(F,L)C8V***A12UH G1FA036S14 14 1185 33.8 23.6 – 12.00 10.95
G8V***12UHA/(F,L)C8V***A12UH G2FD035(S,H)14 14 1185 33.2 23.2 – 11.50 10.80
G8V***16UHB/(F,L)C8V***B16UH G1FA036S17 17 1200 33.4 23.4 – 12.00 11.15
G8V***16UHB/(F,L)C8V***B16UH G2FD036(S,H)17 17 1200 34.4 24.2 – 12.25 11.40
G8V***20UHC/(F,L)C8V***C20UH G1FA036S21 21 1200 33.6 23.6 – 12.00 11.30
G8V***20UHC/(F,L)C8V***C20UH G2FD036(S,H)21 21 1200 34.8 24.4 – 13.00 11.60
G9V***12DHB G2FD036(S,H)17 17 1130 34.4 24.4 – 12.00 11.15
G9V***12UPB G1FA036S17 17 1220 33.2 23.2 – 11.50 10.80
G9V***12UPB G2FD036(S,H)17 17 1200 34.0 23.8 – 12.00 11.05
G9V***16UPC G1FA036S21 21 1200 33.4 23.4 – 12.00 11.15
G9V***16UPC G2FD036(S,H)21 21 1200 34.8 24.4 – 12.75 11.45
G9V***20UPC G1FA048S21 21 1200 34.6 25.8 – 13.00 11.60
G9V***20UPC G2FD042(S,H)21 21 1200 35.2 24.7 – 13.00 11.65
G9V***20UPD G2FD048(S,H)24 24 1260 36.4 25.5 – 12.75 11.65
HABC-(T,W)036S
G8V***12UHA/(F,L)C8V***A12UH G1FA036S14 14 1185 33.6 25.2 – 12.00 11.05
G8V***12UHA/(F,L)C8V***A12UH G2FD035(S,H)14 14 1185 33.0 24.5 – 12.00 10.90
G8V***16UHB/(F,L)C8V***B16UH G1FA036S17 17 1250 33.4 24.8 – 12.00 11.15
G8V***16UHB/(F,L)C8V***B16UH G2FD036(S,H)17 17 1250 34.0 25.3 – 12.50 11.30
G8V***20UHC/(F,L)C8V***C20UH G1FA036S21 21 1200 33.6 25.0 – 12.25 11.45
G8V***20UHC/(F,L)C8V***C20UH G2FD036(S,H)21 21 1200 34.8 25.9 – 13.00 11.75
G9V***12UPB G1FA036S17 17 1220 33.2 24.6 – 12.00 10.95
G9V***12UPB G2FD036(S,H)17 17 1200 34.0 25.3 – 12.25 11.10
G9V***16UPC G1FA036S21 21 1260 33.4 24.8 – 12.00 11.15
G9V***16UPC G2FD036(S,H)21 21 1200 34.8 25.9 – 12.75 11.60
G9V***20UPC G1FA048S21 21 1260 35.6 26.5 – 13.00 11.50
G9V***20UPC G2FD042(S,H)21 21 1260 35.0 26.1 – 12.75 11.65
G9V***20UPD G2FD048(S,H)24 24 1260 35.8 26.6 – 13.00 11.85
DRCS0421BE
G8V***16UHB/(F,L)C8V***B16UH G1FA048S17 17 1400 42.5 30.7 – 12.50 11.05
G8V***20UHC/(F,L)C8V***C20UH G1FA048S21 21 1400 42.0 30.2 – 12.50 11.15
G9V***20DHD G2FD048(S,H)24 24 1365 43.0 31.1 – 12.80 11.35
G9V***16UPC G1FA048S21 21 1400 42.0 30.2 – 12.50 11.10
G9V***20UPD G1FA060S24 24 1430 43.5 31.2 – 13.00 11.35
G9V***20UPD G2FD048(S,H)24 24 1430 43.0 31.1 – 12.25 11.05
For Notes See Page 11.

036-21001-005 Rev. C (0505)
Unitary Products Group 11
DRCS0481BE
G8V***20UHC/(F,L)C8V***C20UH G1FA048S21 21 1610 46.5 34.9 – 12.10 11.15
G8V***20UHC/(F,L)C8V***C20UH G2FD048(S,H)21 21 1610 46.5 34.9 – 12.25 11.05
G9V***20DHD G2FD048(S,H)24 24 1610 47.0 35.4 – 12.40 11.00
G9V***16UPC G1FA048S21 21 1480 46.0 34.4 – 12.10 10.90
G9V***16UPC G2FD048(S,H)21 21 1480 46.0 34.4 – 12.30 10.80
G9V***20UPC G1FA048S21 21 1590 46.5 34.9 – 12.10 11.10
G9V***20UPC G2FD048(S,H)21 21 1590 46.5 34.9 – 12.25 11.00
G9V***20UPD G1FA060S24 24 1560 48.5 36.5 – 13.00 11.45
G9V***20UPD G2FD048(S,H)24 24 1560 47.0 35.4 – 12.50 11.20
G9V***20UPD G2FD060(S,H)24 24 1560 48.5 36.5 – 13.00 11.45
HABC-(T,W)048S
G8V***20UHC/(F,L)C8V***C20UH G1FA048S21 21 1610 45.5 33.7 – 12.20 11.20
G8V***20UHC/(F,L)C8V***C20UH G2FD048(S,H)21 21 1610 45.5 33.7 – 12.25 11.40
G9V***16UPC G1FA048S21 21 1480 45.0 33.2 – 12.20 10.95
G9V***16UPC G2FD048(S,H)21 21 1480 45.0 33.2 – 12.30 11.10
G9V***20UPC G1FA048S21 21 1590 45.5 33.7 – 12.10 11.15
G9V***20UPC G2FD048(S,H)21 21 1590 45.5 33.7 – 12.25 11.35
G9V***20UPD G1FA060S24 24 1620 47.0 34.8 – 12.75 11.65
G9V***20UPD G2FD048(S,H)24 24 1620 45.5 33.7 – 12.25 11.30
G9V***20UPD G2FD060(S,H)24 24 1620 47.0 34.8 – 12.75 11.65
DRCS0601BF
(G,L)8V***20UHD G1FA/G1UA060S21(T) 21 1730 56.0 42.8 – 12.10 10.20
(G,L)8V***20UHD G2FD060(S,H)24(T) 24 1730 56.0 42.8 – 12.10 10.20
(G,L)8V***20UHD G2FD061H24 24 1730 56.5 43.2 – 12.10 10.30
G9V***20UPC G1FA/G1UA060S21(T) 21 1640 56.0 41.8 – 12.10 10.10
G9V***20UPC G2FD060(S,H)24(T) 24 1640 56.0 41.8 – 12.10 10.10
G9V***20UPC G2FD061H24 24 1640 56.5 42.0 – 12.10 10.25
G9V***20UPD G1FA/G1UA060S24(T) 24 1620 56.0 41.6 – 12.10 10.30
G9V***20UPD G2FD060(S,H)24(T) 24 1620 56.0 41.6 – 12.10 10.30
G9V***20UPD G2FD061H24 24 1620 56.5 41.9 – 12.25 10.40
G9V***20DHC G2FD060(S,H)24(T) 24 1575 55.5 40.9 – 12.10 10.20
G9V***20DHC G2FD061H24 24 1575 56.0 41.0 – 12.10 10.20
G9V***20DHC G1HA60H24(T) 24 1575 55.5 40.9 – 12.00 10.20
G9V***20DHC G1HD060 - 1575 55.0 40.2 – 11.75 10.10
G9V***20DHD G2FD060(S,H)24(T) 24 1610 56.0 41.4 – 12.10 10.25
G9V***20DHD G2FD061H24 24 1610 56.0 41.7 – 12.10 10.30
G9V***20UHD G1HA60H24(T) 24 1610 56.0 41.4 – 12.00 10.25
G9V***20UHD G1HD060 - 1610 55.0 40.6 – 12.00 10.15
(F,L)C8V***C20UH G1FA/G1UA060S21(T) 21 1730 56.0 42.8 – 12.10 10.20
(F,L)C8V***C20UH G2FD060(S,H)24(T) 24 1730 56.0 42.8 – 12.10 10.20
(F,L)C8V***C20UH G2FD061H24 24 1730 56.5 43.2 – 12.10 10.30
HABC-(T,W)060S
G9V***20DHD G2FD060(S,H)24 24 1805 57.0 42.6 – 11.50 10.00
G9V***20UPC G1FA060S21 21 1620 57.0 42.1 – 12.10 10.20
G9V***20UPD G1FA060S24 24 1620 57.0 42.1 – 12.10 10.40
G9V***20UPD G2FD060(S,H)24 24 1620 57.0 42.1 – 12.10 10.40
G9V***20UPD G2FD061H24 24 1800 58.0 43.2 – 12.10 10.55
1. G2FD coils available with a factory installed horizontal drain pan. See price pages for specific model number.
2. TXV = Use 1TV700 Series Kit.
3. Variable speed furnaces have B.O.D (Blower on Delay) standard.
COOLING CAPACITY - With Variable Speed Furnaces
UNIT MODEL VARIABLE SPEED
FURNACE MODEL COIL MODEL1WCOOLING
RATED
CFM NET MBH SEER W/O TXV SEER
+ TXV2EER
TOTAL SENS.

036-21001-005 Rev. C (0505)
12 Unitary Products Group
All dimensions are in inches. They are subject to change without
notice. Certified dimensions will be provided upon request.
ACCESSORIES*
Refer to Price Manual for specific model numbers.
Hard Start Kit - Provides increased starting torque for areas
with low voltage.
Compressor Blanket - Designed to further reduce the nor-
mal compressor operating sound. Refer to price pages for
specific match-ups.
Off Cycle Timer Delay - Provides a 5-minute off cycle to pre-
vent rapid recycling of the compressor.
Room Thermostats - A wide selection of compatible thermo-
sets are available to provide optimum performance and fea-
tures for any installation.
1 Heat Stage only, manual, mechanical thermostat. Add sub-
base for 1H/1C.
1H/1C, manual change-over electronic non-programmable
thermostat.
1H/1C, auto/manual changeover, electronic programmable,
deluxe 7-day, thermostat.
1H/1C, auto/manual changeover, electronic programmable.
* For the most current accessory information, refer to the
price book or consult factory.
SOUND POWER RATINGS
* Rated in accordance with ARI 270-95 Standards.
DIMENSIONS - 1 Phase
Unit
Model Dimensions (Inches) Refrigerant Connection Line Size
A1
1. Including Fan Guard.
* Expander fitting required for 1-1/8” line set.
B C Liquid Vapor
018 25 35 23
3/8”
3/4”
024 25 35 23
030 27 37 27
036 27 37 27
042 29 37 27 7/8”
048 33 37 27
060 39 37 27 7/8”*
DIMENSIONS - 3 Phase
Unit
Model Dimensions (Inches) Refrigerant
Connection
Line Size
A1
1. Including Fan Guard.
* Reducer Required
B C Liquid Vapor
036 27 37 27 3/8” 3/4”
048 29 37 27 3/8” 7/8”
060 39 37 27 3/8” 1-1/8”*
A
B
C
UNIT
MODEL (dBA)*
018 75
024 80
030 76
036 79
042 78
048 80
060 76

036-21001-005 Rev. C (0505)
Unitary Products Group 13
TYPICAL INSTALLATION
TYPICAL FIELD WIRING - 1 Phase Application
TYPICAL FIELD WIRING - 3 Phase Application
MINIMUM 18” SERVICE ACCESS
CLEARANCE ON ONE SIDE
60” OVERHEAD
CLEARANCE
10” CLEARANCE
COIL AREA
WEATHERPROOF
DISCONNECT
SWITCH
THERMOSTAT TO FURNACE OR
AIR HANDLER
TERMINAL BLOCK
NEC CLASS 1 WIRING
NEC CLASS 2 WIRING
TO INDOOR COIL
SEAL OPENING(S) WITH
PERMAGUM OR EQUIVALENT
CONTROL ACCESS PANEL
NOTE: ALL OUTDOOR WIRING
MUST BE WEATHERPROOF.
ALL FIELD WIRING TO BE IN ACCORDANCE WITH ELECTRIC CODE (NEC) AND/OR LOCAL CODES
POWER WIRING
208/230-1-60
CONTACTOR
TERMINALS
COIL
GND.
LUG
CYRGW
YRGW
POWER WIRING
CONTROL WIRING
FACTORY WIRING
24 VOLT CONTROL WIRING
MINIMUM 18 GA. WIRE
(NEC CLASS 2)
FURNACE OR AIR HANDLER TERMINAL BLOCK
ROOM THERMOSTAT
CONDENSING UNIT
ALL OUTDOOR WIRING MUST BE WEATHERPROOF. USE COPPER CONDUCTORS ONLY.
TERMINAL W IS ONLY
REQUIRED ON SYSTEMS
WITH HEAT.
*
*
ALL FIELD WIRING TO BE IN ACCORDANCE WITH ELECTRIC CODE (NEC) AND/OR LOCAL CODES
POWER WIRING
208/230-3-60
460-3-60
CONTACTOR
TERMINALS
COIL
GND.
LUG
CYRGW
YRGW
POWER WIRING
CONTROL WIRING
FACTORY WIRING
24 VOLT CONTROL WIRING
MINIMUM 18 GA. WIRE
(NEC CLASS 2)
FURNACE OR AIR HANDLER TERMINAL BLOCK
ROOM THERMOSTAT
CONDENSING UNIT
ALL OUTDOOR WIRING MUST BE WEATHERPROOF. USE COPPER CONDUCTORS ONLY.
TERMINAL W IS ONLY
REQUIRED ON SYSTEMS
WITH HEAT.
*
*

036-21001-005 Rev. C (0505)
14 Unitary Products Group
Multipliers for determining the performance with other indoor sections.
NOTE: For dry bulb temperatures different than those listed (between 73-87 F), sensible capacity increases by 1060 BTUH per 1000 CFM per degree above the
listed temperature and decreases by 1060 BTUH per 1000 CFM per degree belowthe listed temperature.
COOLING PERFORMANCE DATA
AIR CONDITIONER MODEL NO. DRCS0181BE
INDOOR COIL MODEL NO. G1FA024S14,17
CONDENSING|
ENTERING AIR
TEMPERATURE
IDCFM 500 650 800
ID DB (°F) 85 80 75 85 80 75 85 80 75
ID WB (°F) 72 67 63 72 67 63 72 67 63
75 T.C. 20.1 19.3 18.2 20.1 19.4 18.6 20.1 19.5 18.9 S.C. 11.711.511.312.112.212.212.512.813.1
KW 1.26 1.25 1.25 1.27 1.26 1.26 1.27 1.26 1.26
85 T.C. 19.8 18.7 17.0 20.0 19.1 17.7 20.3 19.5 18.3 S.C. 11.711.410.912.712.512.113.613.513.4
KW 1.37 1.35 1.34 1.37 1.36 1.35 1.38 1.37 1.36
95 T.C. 19.5 18.1 15.8 20.0 19.2 16.7 20.5 19.5 17.7 S.C. 11.711.310.413.213.012.014.714.213.6
KW 1.47 1.45 1.43 1.48 1.47 1.45 1.49 1.48 1.46
105 T.C. 18.1 16.3 14.2 18.7 17.1 15.0 19.4 17.8 15.8 S.C. 11.3 10.6 9.7 13.0 12.2 11.3 14.7 13.8 12.9
KW 1.58 1.55 1.52 1.59 1.57 2.53 1.61 1.58 3.54
115 T.C. 16.6 14.5 12.7 17.5 15.3 13.2 18.3 16.1 13.8 S.C. 10.8 9.8 9.1 12.7 11.6 10.6 14.7 13.4 12.1
KW 1.69 1.65 1.61 1.71 1.67 3.62 1.73 1.69 5.62
125 T.C. 15.2 12.7 11.1 16.2 13.6 11.5 17.3 14.5 11.9 S.C. 10.4 9.1 8.4 12.5 11.1 9.9 14.6 13.0 11.4
KW 1.79 1.75 1.70 1.82 1.77 4.70 1.85 1.79 7.70
NOTE: ALL CAPACITIES ARE NET WITH INDOOR FAN HEAT ALREADY DEDUCTED AT 1250 BTUH/1000 CFM.
Air Handler Coil T.C. S.C. KW
F2RC/F2FC024 1.04 1.17 1.01
F2RP/F2FP024 1.04 1.04 1.01
N1AHB0806 G2FD024(S,H)14,17 1.02 1.02 1.00
N1VSB12 G2FD024(S,H)17 1.05 1.21 0.93
G1HD024 1.04 1.04 1.01
G1NA030S17K 1.04 1.04 1.01
G1NA030S21M 1.04 1.17 1.01
G1UA024S14,17 1.00 1.00 1.00
G2FD024(S,H)14,17 1.02 1.02 1.00
G2FD030(S,H)17 1.04 1.04 1.01
G2FD035(S,H)17 1.04 1.04 1.01
MDD30MSD 1.04 1.04 1.01
Variable Speed
Furnace Coil T.C. S.C. KW
G8V***12UHA G1FA024S14 1.02 1.03 0.92
G8V***12UHA G2FD024(S,H)14 1.04 1.05 0.92
G9V***12DHB G2FD024(S,H)17 1.05 1.07 0.93
G9V***12UPB G1FA024S17 1.02 1.03 0.93
G9V***12UPB G2FD024(S,H)17 1.04 1.05 0.92

036-21001-005 Rev. C (0505)
Unitary Products Group 15
Multipliers for determining the performance with other indoor sections.
NOTE: For dry bulb temperatures different than those listed (between 73-87 F), sensible capacity increases by 1060 BTUH per 1000 CFM per degree above the
listed temperature and decreases by 1060 BTUH per 1000 CFM per degree belowthe listed temperature.
COOLING PERFORMANCE DATA
AIR CONDITIONER MODEL NO. DRCS0241BE
INDOOR COIL MODEL NO. G1FA036S17,21
CONDENSING
ENTERING AIR
TEMPERATURE
IDCFM 600 800 1000
ID DB (°F) 85 80 75 85 80 75 85 80 75
ID WB (°F) 72 67 63 72 67 63 72 67 63
75 T.C. 25.4 24.2 22.5 25.6 24.5 23.2 25.8 24.9 23.9 S.C. 14.6 14.6 13.8 15.4 15.6 15.4 16.3 16.6 17.1
KW 1.61 1.60 1.59 1.61 1.60 1.59 1.62 1.61 1.60
85 T.C. 24.9 23.6 21.4 25.1 23.9 22.2 25.3 24.2 23.0 S.C. 14.8 14.7 13.8 15.9 16.1 15.6 17.0 17.5 17.5
KW 1.75 1.74 1.71 1.76 1.75 1.73 1.78 1.76 1.74
95 T.C. 24.4 23.0 20.3 24.6 23.2 21.2 24.8 23.5 22.2 S.C. 14.9 14.7 13.7 16.3 16.6 15.8 17.7 18.4 17.9
KW 1.90 1.88 1.84 1.92 1.89 1.86 1.93 1.90 1.88
105 T.C. 22.9 20.8 18.2 23.3 21.4 19.1 23.8 22.0 20.0 S.C. 14.5 13.8 12.9 16.3 16.0 15.0 18.1 18.1 17.2
KW 2.04 2.01 1.96 2.07 2.02 1.98 2.09 2.04 2.00
115 T.C. 21.3 18.6 16.2 22.0 19.5 17.0 22.8 20.5 17.7 S.C. 14.0 12.9 12.0 16.3 15.3 14.2 18.6 17.8 16.4
KW 2.19 2.13 2.08 2.22 2.16 2.10 2.25 2.18 2.12
125 T.C. 19.8 16.4 14.2 20.7 17.6 14.9 21.8 19.0 15.4 S.C. 13.5 12.0 11.1 16.3 14.6 13.4 19.1 17.5 15.6
KW 2.34 2.25 2.20 2.37 2.30 2.22 2.41 2.32 2.24
NOTE: ALL CAPACITIES ARE NET WITH INDOOR FAN HEAT ALREADY DEDUCTED AT 1250 BTUH/1000 CFM.
Air Handler Coil T.C. S.C. KW
F2RP/F2FP024 0.99 1.01 1.00
F2RP/F2FP030 1.00 1.03 1.00
F2RC/F2FC024 0.98 1.01 1.00
F2RC/F2FC030 0.98 1.01 0.99
N1AHB0806 G2FD024(S,H)17 0.99 0.98 0.99
N1AHB0806 G2FD030(S,H)17 1.00 1.00 1.00
N1VSB12 G2FD024(S,H)17 0.99 1.05 0.92
N1VSB12 G2FD036(S,H)17 1.05 1.17 0.94
G1FA024S14,17 0.96 0.95 1.00
G1FA030S14 0.99 0.98 0.99
G1FA036S14 1.01 1.02 1.00
G1HD024 1.00 0.99 1.01
G1HD036 1.03 1.04 1.00
G1NA030S17K 1.00 1.00 1.00
G1NA030S21M 1.00 1.00 1.00
G1UA024S14,17 0.96 0.95 1.00
G1UA030S14 0.99 0.98 0.99
G1UA036S14 1.01 1.02 1.00
G1UA036S17,21 1.00 1.00 1.00
G2FD024(S,H)14,17 0.99 0.98 0.99
G2FD030(S,H)17 1.00 1.00 1.00
G2FD035(S,H)14 1.00 1.00 1.00
G2FD036(S,H)17 1.03 1.03 1.00
MDD30MSD 1.00 1.00 1.00
Variable Speed
Furnace Coil T.C. S.C. KW
G8V***12UHA G1FA024S14 0.98 0.97 0.93
G8V***12UHA G2FD024(S,H)14 1.00 1.00 0.92
G9V***12DHB G2FD024(S,H)17 1.01 1.01 0.94
G9V***12UPB G1FA024S17 0.98 0.98 0.93
G9V***12UPB G2FD024(S,H)17 1.01 1.01 0.93

036-21001-005 Rev. C (0505)
16 Unitary Products Group
Multipliers for determining the performance with other indoor sections.
NOTE: For dry bulb temperatures different than those listed (between 73-87 F), sensible capacity increases by 1060 BTUH per 1000 CFM per degree above the
listed temperature and decreases by 1060 BTUH per 1000 CFM per degree belowthe listed temperature.
COOLING PERFORMANCE DATA
AIR CONDITIONER MODEL NO. DRCS0301BE
INDOOR COIL MODEL NO. G1FA036S17,21
CONDENSING
ENTERING AIR
TEMPERATURE
IDCFM 800 1000 1200
ID DB (°F) 85 80 75 85 80 75 85 80 75
ID WB (°F) 72 67 63 72 67 63 72 67 63
75 T.C. 31.9 30.6 28.9 27.4 30.9 29.4 23.0 31.2 29.9 S.C. 18.9 19.1 18.9 19.7 20.1 20.3 20.5 21.2 21.8
KW 1.97 1.95 1.94 1.98 1.96 1.95 1.98 1.97 1.95
85 T.C. 31.4 29.3 27.0 28.2 30.1 28.9 25.0 30.6 30.9 S.C. 19.2 18.9 18.1 20.1 20.7 20.2 21.1 22.0 22.4
KW 2.16 2.13 2.09 2.15 2.15 2.13 2.14 2.16 2.16
95 T.C. 30.9 28.1 25.0 29.0 29.2 28.4 27.1 30.1 31.9 S.C. 19.5 18.7 17.3 20.6 20.7 20.1 21.6 22.8 22.9
KW 2.35 2.30 2.24 2.32 2.34 2.31 2.29 2.34 2.37
105 T.C. 28.6 25.5 22.3 28.2 26.8 24.6 27.9 27.8 26.8 S.C. 18.7 17.7 16.2 20.4 20.1 18.7 22.2 22.1 21.2
KW 2.53 2.45 2.40 2.53 2.49 2.44 2.53 2.51 2.48
115 T.C. 26.3 23.0 19.7 27.5 24.2 20.7 28.6 25.5 21.8 S.C. 17.9 16.7 15.2 20.3 19.0 17.3 22.8 21.3 19.5
KW 2.70 2.61 2.55 2.74 2.64 2.57 2.77 2.68 2.59
125 T.C. 24.0 20.4 17.0 26.7 21.7 16.8 29.4 23.2 16.7 S.C. 17.1 15.6 14.1 20.2 17.9 16.0 23.3 20.5 17.8
KW 2.88 2.76 2.70 2.94 2.79 2.70 3.00 2.84 2.69
NOTE: ALL CAPACITIES ARE NET WITH INDOOR FAN HEAT ALREADY DEDUCTED AT 1250 BTUH/1000 CFM.
Air Handler Coil T.C. S.C. KW
F2RP/F2FP030 1.01 1.08 0.99
F2RP/F2FP036 1.03 1.10 1.01
F2RC/F2FC030 0.99 1.01 0.99
F2RC/F2FC036 1.03 1.05 1.01
N1AHB1206 G2FD030(S,H)17 1.00 1.00 1.00
N1AHB1206 G2FD036(S,H)17 1.02 1.03 1.00
N1VSB12 G2FD036(S,H)17 1.03 1.12 0.94
N1VSB12 G2FD046(S,H)17 1.07 1.15 0.95
G1FA030S14 0.97 0.98 0.99
G1FA036S14 1.01 1.02 1.00
G1FA048S17 1.04 1.05 1.00
G1FA048S21 1.04 0.99 1.01
G1HD036 1.03 1.03 1.00
G1NA036S17L 1.05 1.05 1.01
G1NA030S17K 1.01 1.01 1.00
G1NA030S21M 1.01 1.01 1.00
G1UA030S14 0.97 0.98 0.99
G1UA036S14 1.01 1.02 1.00
G1UA036S17,21 1.00 1.00 1.00
G1UA048S17 1.04 1.05 1.00
G1UA048S21 1.04 0.99 1.01
G2FD030(S,H)17 1.00 1.00 1.00
G2FD035(S,H)14 1.00 1.00 1.00
G2FD036(S,H)17 1.02 1.03 1.00
G2FD036(S,H)21 1.03 1.03 1.00
G2FD042(S,H)21 1.03 1.04 1.00
G2FD046(S,H)17 1.05 1.05 1.01
MDD48DSD 1.03 0.97 1.01
Variable Speed
Furnace Coil T.C. S.C. KW
G8V***12UHA G1FA030S14 0.99 0.99 0.94
G8V***12UHA G2FD035(S,H)14 1.01 1.02 0.94
G8V***16UHB G1FA036S17 1.02 1.03 0.94
G8V***16UHB G2FD030(S,H)17 1.02 1.03 0.94
G9V***12DHB G2FD030(S,H)17 1.02 1.03 0.97
G9V***12UPB G1FA036S17 1.01 1.02 0.95
G9V***12UPB G2FD030(S,H)17 1.01 1.02 0.95
G9V***16UPC G1FA036S21 1.02 1.03 0.94
G9V***16UPC G2FD036(S,H)21 1.05 1.06 0.94

036-21001-005 Rev. C (0505)
Unitary Products Group 17
Multipliers for determining the performance with other indoor sections.
NOTE: For dry bulb temperatures different than those listed (between 73-87 F), sensible capacity increases by 1060 BTUH per 1000 CFM per degree above the
listed temperature and decreases by 1060 BTUH per 1000 CFM per degree belowthe listed temperature.
COOLING PERFORMANCE DATA
AIR CONDITIONER MODEL NO. DRCS0361BE
INDOOR COIL MODEL NO. G1FA048S21
CONDENSING
ENTERING AIR
TEMPERATURE
IDCFM 1000 1200 1400
ID DB (°F) 85 80 75 85 80 75 85 80 75
ID WB (°F) 72 67 63 72 67 63 72 67 63
75 T.C. 36.7 34.3 32.3 36.9 34.9 32.8 37.2 35.4 33.2 S.C. 23.2 22.8 22.5 24.3 24.2 23.9 25.4 25.6 25.4
KW 2.31 2.30 2.27 2.33 2.30 2.28 2.34 2.31 2.30
85 T.C. 35.3 33.1 30.9 35.7 33.7 31.4 36.2 34.2 31.9 S.C. 23.2 22.6 21.9 24.8 24.3 23.6 26.3 26.0 25.3
KW 2.51 2.48 2.45 2.53 2.50 2.47 2.54 2.51 2.48
95 T.C. 34.0 31.9 29.6 34.5 33.6 30.0 35.1 33.0 30.5 S.C. 23.3 22.4 21.3 25.3 23.4 23.3 27.3 26.4 25.2
KW 2.71 2.67 2.64 2.73 2.73 2.66 2.74 2.71 2.67
105 T.C. 31.8 29.5 27.2 32.3 30.0 27.6 32.9 30.5 28.0 S.C. 22.6 21.6 20.5 24.8 23.7 22.5 26.9 25.8 24.5
KW 2.93 2.88 2.82 2.94 2.90 2.85 2.96 2.92 2.87
115 T.C. 29.6 27.2 24.8 30.1 27.6 25.1 30.6 28.0 25.4 S.C. 22.0 20.8 19.7 24.3 23.0 21.8 26.6 25.2 23.9
KW 3.15 3.09 3.01 3.16 3.11 3.04 3.18 3.13 3.07
125 T.C. 27.3 24.8 22.4 27.8 25.2 22.6 28.4 25.5 22.9 S.C. 21.4 20.0 19.0 23.8 22.3 21.1 26.2 24.6 23.2
KW 3.36 3.29 3.19 3.38 3.31 3.23 3.39 3.33 3.26
NOTE: ALL CAPACITIES ARE NET WITH INDOOR FAN HEAT ALREADY DEDUCTED AT 1250 BTUH/1000 CFM.
Air Handler Coil T.C. S.C. KW
F2RC/F2FC036 1.02 1.04 1.00
F2RP/F2FP036 1.02 1.03 1.00
F2RP/F2FP042 1.02 1.04 1.02
F2FP048 1.04 1.06 1.02
N1VSB12 G2FD036(S,H)17 1.02 1.03 0.96
N1VSB12 G2FD046(S,H)17 1.05 1.08 0.97
N1VSC16 G2FD048(S,H)21 1.08 1.11 0.95
N1AHB1206 G2FD036(S,H)17 0.99 0.94 0.99
N1AHB1206 G2FD046(S,H)17 1.03 0.97 1.01
G1FA036S17,21 0.97 0.91 0.99
G1FA036S14 0.99 0.93 1.00
G1FA048S17 1.03 0.97 1.01
G1HD036 1.00 0.94 1.00
G1HD048 1.04 0.98 1.01
G1NA048S21D 1.03 0.99 1.01
G1NA036S17L 1.03 0.99 1.01
G1UA036S17,21 0.97 0.91 0.99
G1UA036S14 0.99 0.93 1.00
G1UA048S17 1.03 0.97 1.01
G1UA048S21 1.00 1.00 1.00
G2FD035(S,H)14 0.97 0.91 0.99
G2FD036(S,H)17 0.99 0.94 0.99
G2FD036(S,H)21 1.01 0.95 1.00
G2FD042(S,H)21 1.02 0.96 1.01
G2FD046(S,H)17 1.03 0.97 1.01
G2FD048(S,H)21,24 1.06 1.00 1.02
MDD48DSD 1.03 0.97 1.01
Variable Speed
Furnace Coil T.C. S.C. KW
G8V***12UHA G1FA036S14 0.99 0.94 0.97
G8V***12UHA G2FD035(S,H)14 0.98 0.92 0.97
G8V***16UHB G1FA036S17 0.98 0.93 0.94
G8V***16UHB G2FD036(S,H)17 1.01 0.96 0.95
G8V***20UHC G1FA036S21 0.99 0.94 0.94
G8V***20UHC G2FD036(S,H)21 1.02 0.97 0.94
G9V***12DHB G2FD036(S,H)17 1.01 0.97 0.97
G9V***12UPB G1FA036S17 0.98 0.92 0.97
G9V***12UPB G2FD036(S,H)17 1.00 0.94 0.97
G9V***16UPC G1FA036S21 0.98 0.93 0.94
G9V***16UPC G2FD036(S,H)21 1.02 0.97 0.96
G9V***20UPC G1FA048S21 1.02 1.02 0.94
G9V***20UPC G2FD042(S,H)21 1.04 0.98 0.95
G9V***20UPD G2FD048(S,H)24 1.07 1.01 0.98

036-21001-005 Rev. C (0505)
18 Unitary Products Group
Multipliers for determining the performance with other indoor sections.
NOTE: For dry bulb temperatures different than those listed (between 73-87 F), sensible capacity increases by 1060 BTUH per 1000 CFM per degree above the
listed temperature and decreases by 1060 BTUH per 1000 CFM per degree belowthe listed temperature.
COOLING PERFORMANCE DATA
AIR CONDITIONER MODEL NO. HABC-(T,W)036S
INDOOR COIL MODEL NO. G1FA048S21
CONDENSING
ENTERING AIR
TEMPERATURE
IDCFM 1000 1200 1400
ID DB (°F) 85 80 75 85 80 75 85 80 75
ID WB (°F) 72 67 63 72 67 63 72 67 63
75 T.C. 39.7 37.5 36.7 39.0 37.7 36.8 39.0 37.6 36.8 S.C. 23.9 23.8 25.0 23.5 24.3 25.3 24.0 25.1 25.6
KW 2.97 2.94 2.91 2.97 2.95 2.91 2.96 2.94 2.92
85 T.C. 38.3 36.1 34.4 37.9 36.3 34.6 38.0 36.4 34.9 S.C. 24.0 23.7 24.0 24.1 24.5 24.7 24.7 25.3 25.2
KW 3.23 3.18 3.13 3.23 3.20 3.14 3.23 3.20 3.15
95 T.C. 36.9 34.6 32.2 36.9 34.9 32.6 37.0 35.2 33.0 S.C. 24.2 23.7 22.9 24.7 24.6 23.9 25.3 25.5 24.8
KW 3.49 3.43 3.34 3.50 3.44 3.36 3.50 3.46 3.37
105 T.C. 35.5 33.2 30.0 35.8 33.6 30.4 36.0 34.0 31.0 S.C. 24.3 23.6 21.9 25.4 24.9 23.6 26.0 25.6 24.4
KW 3.75 3.67 3.56 3.76 3.69 3.58 3.77 3.72 3.59
115 T.C. 33.2 30.4 26.7 33.4 30.8 27.2 33.6 31.3 27.7 S.C. 23.7 22.5 20.7 24.5 23.6 21.9 25.4 24.6 23.0
KW 4.01 3.88 3.75 4.02 3.91 3.77 4.03 3.93 3.78
125 T.C. 31.0 27.6 23.5 31.1 28.1 24.1 31.3 28.5 24.4 S.C. 23.1 21.3 19.6 23.7 22.3 20.2 24.8 23.7 21.6
KW 4.26 4.10 3.94 4.28 4.12 3.95 4.30 4.15 3.97
NOTE: ALL CAPACITIES ARE NET WITH INDOOR FAN HEAT ALREADY DEDUCTED AT 1250 BTUH/1000 CFM.
Air Handler Coil T.C. S.C. KW
N1AHB1246 G2FD036(S,H)17 1.02 1.02 1.01
N1AHB1246 G2FD046(S,H)17 1.05 1.06 1.02
G1FA036S14 1.01 1.02 1.00
G1FA036S17,21 1.00 1.00 1.00
G2FD035(S,H)14 0.99 1.00 0.99
G2FD036(S,H)17 1.02 1.02 1.01
G2FD036(S,H)21 1.04 1.04 1.00
G2FD042(S,H)21 1.04 1.05 1.01
G2FD046(S,H)17 1.05 1.06 1.02
G2FD048(S,H)21,24 1.07 1.07 1.02
G1HD036 1.01 1.01 1.00
G1HD048 1.06 1.06 1.01
G1NA036S17L 1.06 1.00 1.03
G1NA048S21D 1.06 1.00 1.03
G1UA036S14 1.01 1.02 1.00
G1UA036S17,21 1.00 1.00 1.00
G1UA048S21 1.06 1.06 1.05
Variable Speed
Furnace Coil T.C. S.C. KW
G8V***12UHA G1FA036S14 0.96 0.97 0.93
G8V***12UHA G2FD035(S,H)14 0.94 0.95 0.93
G8V***16UHB G1FA036S17 0.95 0.96 0.92
G8V***16UHB G2FD036(S,H)17 0.97 0.98 0.92
G8V***20UHC G1FA036S21 0.96 0.97 0.90
G8V***20UHC G2FD036(S,H)21 0.99 1.00 0.91
G9V***12UPB G1FA036S17 0.95 0.95 0.93
G9V***12UPB G2FD036(S,H)17 0.97 0.98 0.94
G9V***16UPC G1FA036S21 0.95 0.96 0.92
G9V***16UPC G2FD036(S,H)21 0.99 1.00 0.92
G9V***20UPC G1FA048S21 1.02 1.02 0.95
G9V***20UPC G2FD042(S,H)21 1.00 1.01 0.92
G9V***20UPD G2FD048(S,H)24 1.02 1.03 0.92

036-21001-005 Rev. C (0505)
Unitary Products Group 19
Multipliers for determining the performance with other indoor sections.
NOTE: For dry bulb temperatures different than those listed (between 73-87 F), sensible capacity increases by 1060 BTUH per 1000 CFM per degree above the
listed temperature and decreases by 1060 BTUH per 1000 CFM per degree belowthe listed temperature.
COOLING PERFORMANCE DATA
AIR CONDITIONER MODEL NO. DRCS0421BE
INDOOR COIL MODEL NO. G1FA048S21
CONDENSING
ENTERING AIR
TEMPERATURE
IDCFM 1200 1400 1600
ID DB (°F) 85 80 75 85 80 75 85 80 75
ID WB (°F) 72 67 63 72 67 63 72 67 63
75 T.C. 46.4 45.7 43.0 46.4 45.9 43.3 46.5 46.0 43.5 S.C. 27.0 27.5 27.8 27.9 29.0 29.5 28.8 30.5 31.2
KW 2.45 2.44 2.45 2.47 2.45 2.46 2.48 2.45 2.46
85 T.C. 45.5 44.1 41.1 45.6 44.4 41.6 45.7 44.7 42.0 S.C. 27.5 27.5 27.2 28.6 29.2 29.1 29.7 30.9 31.0
KW 2.76 2.75 2.75 2.77 2.76 2.76 2.78 2.76 2.76
95 T.C. 44.6 42.5 39.2 44.8 43.0 39.8 45.0 43.4 40.4 S.C. 28.0 27.6 26.5 29.3 29.5 28.6 30.7 31.4 30.7
KW 3.07 3.06 3.05 3.08 3.07 3.06 3.09 3.07 3.06
105 T.C. 43.7 41.0 37.4 43.9 41.5 38.1 44.2 42.0 38.9 S.C. 28.4 27.6 25.9 30.0 29.7 28.2 31.6 31.8 30.5
KW 3.39 3.38 3.36 3.39 3.38 3.36 3.40 3.39 3.37
115 T.C. 41.2 38.1 34.1 41.6 38.7 34.9 42.0 39.3 35.7 S.C. 27.8 26.7 24.8 29.8 28.9 27.0 31.8 31.0 29.2
KW 3.80 3.77 3.73 3.81 3.78 3.74 3.81 3.79 3.75
125 T.C. 38.7 35.3 30.9 39.3 35.9 31.8 39.9 36.5 32.6 S.C. 27.1 25.7 23.7 29.5 28.0 25.8 31.9 30.3 27.9
KW 4.21 4.16 4.11 4.22 4.18 4.12 4.23 4.19 4.13
NOTE: ALL CAPACITIES ARE NET WITH INDOOR FAN HEAT ALREADY DEDUCTED AT 1250 BTUH/1000 CFM.
Air Handler Coil T.C. S.C. KW
F2RP/F2FP042 1.02 1.04 1.02
F2FP048 1.04 1.06 1.02
N1AHC1606 G2FD042(S,H)21 0.99 0.99 1.00
N1AHC1606 G2FD048(S,H)21 1.02 1.03 1.02
N1VSC16 G2FD048(S,H)21 1.08 1.11 0.95
G1FA048S17 1.01 1.02 1.02
G1FA060S21,24 1.04 1.03 1.01
G1HD048 1.00 1.00 1.01
G1NA048S21D 0.99 0.96 1.01
G1UA048S17 1.01 1.02 1.02
G1UA048S21 1.00 1.00 1.00
G1UA060S21,24 1.04 1.03 1.01
G2FD042(S,H)21 0.99 0.99 1.00
G2FD046(S,H)17 1.01 1.02 1.02
G2FD048(S,H)21,24 1.02 1.03 1.02
MDD48DSD 0.99 0.96 1.01
Variable Speed
Furnace Coil T.C. S.C. KW
G8V***16UHB G1FA048S17 1.02 1.03 0.99
G8V***20UHC G1FA048S21 1.01 1.02 0.97
G9V***20DHD G2FD048(S,H)24 1.04 1.05 0.97
G9V***16UPC G1FA048S21 1.01 1.02 0.97
G9V***20UPD G1FA060S24 1.05 1.05 0.98
G9V***20UPD G2FD048(S,H)24 1.04 1.05 1.00

036-21001-005 Rev. C (0505)
20 Unitary Products Group
Multipliers for determining the performance with other indoor sections.
NOTE: For dry bulb temperatures different than those listed (between 73-87 F), sensible capacity increases by 1060 BTUH per 1000 CFM per degree above the
listed temperature and decreases by 1060 BTUH per 1000 CFM per degree belowthe listed temperature.
COOLING PERFORMANCE DATA
AIR CONDITIONER MODEL NO. DRCS0481BE
INDOOR COIL MODEL NO. G1FA048S21
CONDENSING
ENTERING AIR
TEMPERATURE
IDCFM 1375 1575 1775
ID DB (°F) 85 80 75 85 80 75 85 80 75
ID WB (°F) 72 67 63 72 67 63 72 67 63
75 T.C. 52.8 49.9 45.4 53.5 50.6 46.8 54.2 51.3 48.2 S.C. 33.3 32.7 31.5 34.9 34.5 33.6 36.5 36.2 35.7
KW 3.14 3.09 3.03 3.15 3.10 3.04 3.17 3.12 3.06
85 T.C. 50.9 47.1 42.4 51.6 48.1 43.5 52.3 49.1 44.7 S.C. 33.3 32.0 30.4 35.3 34.2 32.6 37.4 36.3 34.7
KW 3.44 3.35 3.30 3.46 3.38 3.31 3.47 3.40 3.32
95 T.C. 49.0 44.3 39.4 49.7 45.5 40.3 50.3 46.8 41.2 S.C. 33.2 31.2 29.3 35.8 34.1 31.5 38.4 36.5 33.7
KW 3.74 3.62 3.57 3.76 3.56 3.57 3.78 3.69 3.58
105 T.C. 44.7 40.0 35.8 45.4 41.0 36.5 46.1 42.0 37.1 S.C. 31.9 29.8 27.8 34.5 32.2 29.9 37.0 34.7 32.1
KW 4.01 3.89 3.80 4.04 3.91 3.81 4.07 3.94 3.83
115 T.C. 40.5 35.7 32.1 41.2 36.5 32.6 41.9 37.2 33.1 S.C. 30.5 28.3 26.3 33.1 30.5 28.4 35.7 32.8 30.5
KW 4.28 4.15 4.02 4.32 4.17 4.05 4.35 4.19 4.08
125 T.C. 36.3 31.3 28.5 36.9 31.9 28.8 37.6 32.5 29.1 S.C. 29.2 26.8 24.8 31.8 28.9 26.8 34.4 31.0 28.8
KW 4.55 4.42 4.25 4.60 4.43 4.29 4.64 4.44 4.33
NOTE: ALL CAPACITIES ARE NET WITH INDOOR FAN HEAT ALREADY DEDUCTED AT 1250 BTUH/1000 CFM.
Air Handler Coil T.C. S.C. KW
F2FP048 1.00 1.00 1.02
F2FP060 1.03 1.03 1.06
F2FV060 1.06 1.10 0.95
N1AHC1606 G2FD048(S,H)21,24 1.00 1.00 1.01
N1AHD2006 G2FD060(S,H)24 1.03 1.03 1.02
N1AHD2006 G2FD061H24 1.04 1.04 1.02
N1VSC16 G2FD048(S,H)21 1.01 1.02 0.97
N1VSD20 G2FD060(S,H)24 1.04 1.06 0.99
N1VSD20 G2FD061H24 1.05 1.07 0.99
G1FA048S17 0.98 0.98 0.98
G1FA060S21,24 1.03 1.03 1.02
G1HD048 0.99 0.99 1.01
G1HD060 1.02 1.02 1.02
G1NA048S21D 0.99 0.99 1.02
G1UA048S17 0.98 0.98 0.98
G1UA048S21 1.00 1.00 1.00
G1UA060S21,24 1.03 1.03 1.02
G2FD046(S,H)17 0.98 0.98 1.00
G2FD048(S,H)21,24 1.00 1.00 1.01
G2FD060(S,H)24 1.03 1.03 1.02
G2FD061H24 1.04 1.04 1.02
MDD48DSD 0.99 0.99 1.02
Variable Speed
Furnace Coil T.C. S.C. KW
G8V***20UHC G1FA048S21 1.00 1.00 0.99
G8V***20UHC G2FD048(S,H)21 1.00 1.00 1.00
G9V***20DHD G2FD048(S,H)24 1.01 1.01 1.01
G9V***16UPC G1FA048S21 0.99 0.99 1.00
G9V***16UPC G2FD048(S,H)21 0.99 0.98 1.01
G9V***20UPC G1FA048S21 1.00 1.00 0.99
G9V***20UPC G2FD048(S,H)21 1.00 1.00 1.00
G9V***20UPD G1FA060S24 1.04 1.05 1.00
G9V***20UPD G2FD048(S,H)24 1.01 1.01 0.99
G9V***20UPD G2FD060(S,H)24 1.04 1.05 1.00
