York ZF SERIES User manual

R-410A
ZF SERIES
15 Ton/53 KW
50 Hertz
5326601-XIM-A-0117
TABLE OF CONTENTS
General . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2
Installation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5
Limitations. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5
Location . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7
Rigging And Handling . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7
Ductwork . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 12
Condensate Drain . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 13
Compressors . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 13
Filters . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 14
Power And Control Wiring . . . . . . . . . . . . . . . . . . . . . . . . . . . . 14
Optional Gas Heat . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 20
Options/Accessories . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 22
Economizer Sequences. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 22
Dry Bulb Changeover . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 22
Single Enthalpy Changeover . . . . . . . . . . . . . . . . . . . . . . . . . . 22
Dual Enthalpy Changeover . . . . . . . . . . . . . . . . . . . . . . . . . . . 22
Auto . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 22
Free Cooling Operation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 22
Power Exhaust . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 23
Setpoints . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 23
Inputs. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 23
Outputs . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 23
Operation. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 23
ZF180 Side Duct Application . . . . . . . . . . . . . . . . . . . . . . . . . . 31
Air Balance . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 33
Sequence Of Operation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 35
Cooling Sequence Of Operation . . . . . . . . . . . . . . . . . . . . . . . 35
No Outdoor Air Options . . . . . . . . . . . . . . . . . . . . . . . . . . . . 35
Cooling Operation Errors . . . . . . . . . . . . . . . . . . . . . . . . . . . 36
Electric Heating Sequence Of Operations . . . . . . . . . . . . . . . . 37
Electric Heat Operation Errors . . . . . . . . . . . . . . . . . . . . . . . 37
Gas Heating Sequence Of Operations . . . . . . . . . . . . . . . . . . 38
Gas Heating Operation Errors . . . . . . . . . . . . . . . . . . . . . . . 38
Start-Up (Cooling) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 40
Start-Up (Gas Heat) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 41
Checking Gas Heat Input . . . . . . . . . . . . . . . . . . . . . . . . . . . . 41
LIST OF TABLES
1 ZF180 Unit Limitations . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6
2 ZF180 Unit Weights Imperial . . . . . . . . . . . . . . . . . . . . . . . . . . 8
3 ZF180 Unit Weights Metric . . . . . . . . . . . . . . . . . . . . . . . . . . . 8
4 ZF180 Unit Accessory Weights Metric . . . . . . . . . . . . . . . . . . 8
5 ZF180 Unit Accessory Weights Imperial . . . . . . . . . . . . . . . . . 8
6 Utilities Entry Data . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 10
7 ZF180 Unit Clearances . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 11
8 Control Wire Sizes . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 15
9 Electrical Data . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 17
10 ZF180 Physical Data . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 18
11 Gas Application Data . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 20
12 Gas Pipe Sizing - Capacity of Pipe . . . . . . . . . . . . . . . . . . . . 20
13 Gas Heat Minimum Supply Air Imperial . . . . . . . . . . . . . . . . . 20
14 Gas Heat Minimum Supply Air Metric . . . . . . . . . . . . . . . . . . 20
15 Smart Equipment™ Economizer Board Details . . . . . . . . . . 2 4
16 Altitude/Temperature Correction Factors Imperial . . . . . . . . 28
17 Altitude/Temperature Correction Factors Metric . . . . . . . . . . 28
18 Air Flow Performance - Side Duct Application . . . . . . . . . . . 31
19 Air Flow Performance - Bottom Duct Application . . . . . . . . . 32
20 RPM Selection . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 33
21 Indoor Blower Specifications . . . . . . . . . . . . . . . . . . . . . . . . . 33
22 Power Exhaust Specifications . . . . . . . . . . . . . . . . . . . . . . . . 33
23 Additional Static Resistance Imperial . . . . . . . . . . . . . . . . . . 34
24 Additional Static Resistance Metric . . . . . . . . . . . . . . . . . . . . 34
25 Limit Control Setting . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 37
26 Electric Heat Anticipator Setpoint . . . . . . . . . . . . . . . . . . . . . 38
27 Gas Heat Limit Control Setting . . . . . . . . . . . . . . . . . . . . . . . 40
28 Gas Heat Anticipator Setpoints . . . . . . . . . . . . . . . . . . . . . . . 40
29 Gas Rate Cubic Feet Per Hour . . . . . . . . . . . . . . . . . . . . . . . 41
30 Smart Equipment™ UCB Details . . . . . . . . . . . . . . . . . . . . . 43
LIST OF FIGURES
1 ZF180 Component Location . . . . . . . . . . . . . . . . . . . . . . . . . . 6
2 Unit 4 Point Load Weight . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8
3 Unit 6 Point Load Weight . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8
4 Center of Gravity . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8
5 Unit Dimensions - ZF Cooling Only . . . . . . . . . . . . . . . . . . . . 9
6 Unit Dimensions - ZF Gas Heat . . . . . . . . . . . . . . . . . . . . . . . 9
7 ZF180 Unit Dimensions Rear View . . . . . . . . . . . . . . . . . . . 10
8 ZF180 Unit Dimensions Rain Hood . . . . . . . . . . . . . . . . . . . 11
9 Roof Curb Dimensions (All Models) . . . . . . . . . . . . . . . . . . . 12
10 Roof Curb Benefits . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 12
11 Unit Curb And Applications . . . . . . . . . . . . . . . . . . . . . . . . . . 12
12 Fixed Outdoor Air Damper . . . . . . . . . . . . . . . . . . . . . . . . . . 13
13 Condensate Drain . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 13
14 Field Wiring Disconnect - Cooling Unit With/Without Electric
Heat . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 15
15 Typical Field Wiring 24 Volt Thermostat . . . . . . . . . . . . . . . . 16
16 External Supply Connection External Shut-Off . . . . . . . . . . . 20
17 Bottom Supply Connection External Shut-Off . . . . . . . . . . . 20
18 Vent and Combustion Air Hood . . . . . . . . . . . . . . . . . . . . . . 22
19 SE-ECO1001-0 Economizer Controller . . . . . . . . . . . . . . . . 24
20 Belt Adjustment . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 27
21 Altitude/Temperature Correction Factors Imperial . . . . . . . . 2 9
22 Altitude/Temperature Correction Factors Metric . . . . . . . . . 29
23 Pressure Drop Across A Dry Indoor Coil Vs. Supply Air CFM . . . . 33
24 Gas Valve Piping . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 38
25 Gas Heat Limit And Auxiliary Location Down Discharge
Application . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 39
26 Gas Heat Limit and Auxiliary Location Side Discharge
Application . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 39
27 Gas Valve and Controls . . . . . . . . . . . . . . . . . . . . . . . . . . . . 40
28 Proper Pilot Flame Adjustment . . . . . . . . . . . . . . . . . . . . . . 42
29 Typical Flame . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 42
30 Typical Gas Valve . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 42
31 Unit Control Board . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 43
32 Start-Up & Service Data Instruction . . . . . . . . . . . . . . . . . . . 49

5326601-XIM-A-0117
2Johnson Controls Unitary Products
General
YORK® Model ZF units are either single package air
conditioners or single package gas-fired central heating
furnaces with cooling unit. Both are designed for outdoor
installation on a rooftop or slab.
The units are completely assembled on rigid, permanently
attached base rails. All piping, refrigerant charge, and electrical
wiring is factory installed and tested. The units require electric
power, gas connection, duct connections, installation of
combustion air inlet hood, flue gas outlet hoods and fixed
outdoor air intake damper (units without economizer or
motorized damper option only) at the point of installation.
These gas-fired heaters have aluminized-steel or optional
stainless steel, tubular heat exchangers with spark ignition with
proven pilot. All gas heaters are shipped from the factory equipped
for natural gas use, but can be field converted to L.P./Propane with
Kit Model # 1NP0418. See Gas Heat Application Data Table.
Safety Considerations
This is a safety alert symbol. When you see this symbol on
labels or in manuals, be alert to the potential for personal injury.
Understand and pay particular attention the signal words
DANGER, WARNING or CAUTION.
DANGER indicates an imminently hazardous situation, which,
if not avoided, will result in death or serious injury.
WARNING indicates a potentially hazardous situation, which,
if not avoided, could result in death or serious injury.
CAUTION indicates a potentially hazardous situation, which, if
not avoided may result in minor or moderate injury. It is also
used to alert against unsafe practices and hazards involving
only property damage.
Due to system pressure, moving parts, and electrical
components, installation and servicing of air conditioning
equipment can be hazardous. Only qualified, trained service
personnel should install, repair, or service this equipment.
Untrained personnel can perform basic maintenance functions
of cleaning coils and filters and replacing filters.
Observe all precautions in the literature, labels, and tags
accompanying the equipment whenever working on air
conditioning equipment. Be sure to follow all other applicable
safety precautions and codes including ANSI Z223.1 or CSA-
B149.1- latest edition.
Improper installation may create a condition where the
operation of the product could cause personal injury or
property damage. Improper installation, adjustment,
alteration, service or maintenance can cause injury or
property damage. Refer to this manual for assistance or
for additional information, consult a qualified contractor,
installer or service agency.
This product must be installed in strict compliance with
the installation instructions and any applicable local,
state and national codes including, but not limited to
building, electrical, and mechanical codes.
Before performing service or maintenance operations on
unit, turn off main power switch to unit. Electrical shock
could cause personal injury. Improper installation,
adjustment, alteration, service or maintenance can
cause injury or property damage. Refer to this manual.
For assistance or additional information consult a
qualified installer, service agency or the gas supplier.
This system uses R-410A Refrigerant which operates at
higher pressures than R-22. No other refrigerant may be
used in this system. Gage sets, hoses, refrigerant
containers and recovery systems must be designed to
handle R-410A. If you are unsure, consult the equipment
manufacturer. Failure to use R-410A compatible servicing
equipment may result in property damage or injury.
If the information in this manual is not followed exactly, a
fire or explosion may result causing property damage,
personal injury or loss of life.
Do not store or use gasoline or other flammable vapors
and liquids in the vicinity of this or any other appliance.
WHAT TO DO IF YOU SMELL GAS:
a. Do not try to light any appliance.
b. Do not touch any electrical switch; do not use any
phone in your building.
c. Immediately call your gas supplier from a neighbor’s
phone. Follow the gas supplier’s instructions.
d. If you cannot reach your gas supplier, call the fire
department.
Installation and service must be performed by a qualified
installer, service agency or the gas supplier.

5326601-XIM-A-0117
Johnson Controls Unitary Products 3
Wear safety glasses and work gloves. Use quenching cloth and
have a fire extinguisher available during brazing operations.
Inspection
As soon as a unit is received, it should be inspected for possible
damage during transit. If damage is evident, the extent of the
damage should be noted on the carrier’s freight bill. A separate
request for inspection by the carrier’s agent should be made in
writing.
Reference
Additional information is available in the following reference
forms:
• Technical Guide - ZF180, 1056292
• General Installation - ZF180 5168276
• Smart Equipment™ Control Quick Start Guide - 1136326
Renewal Parts
Contact your local York® parts distribution center for authorized
replacement parts.
Approvals
Design certified by CSA as follows:
1. For use as a cooling only unit, cooling unit with
supplemental electric heat or a forced air furnace.
2. For outdoor installation only.
3. For installation on combustible material.
4. For use with natural gas (convertible to LP with kit).
This product must be installed in strict compliance with
the enclosed installation instructions and any applicable
local, state and national codes including, but not limited
to, building, electrical, and mechanical codes.
The furnace and its individual shut-off valve must be
disconnected from the gas supply piping system during
any pressure testing at pressures in excess of 1/2 PSIG.
Pressures greater than 1/2 PSIG will cause gas valve
damage resulting in a hazardous condition. If it is
subjected to a pressure greater than 1/2 PSIG, the gas
valve must be replaced.
The furnace must be isolated from the gas supply piping
system by closing its individual manual shut-off valve
during any pressure testing of the gas supply piping
system at test pressures equal to or less than 1/2 PSIG.
This product must be installed in strict compliance with
the enclosed installation instructions and any applicable
local, state, and national codes including, but not limited
to, building, electrical, and mechanical codes.
Improper installation may create a condition where the
operation of the product could cause personal injury or
property damage.
This system uses R-410A Refrigerant which operates at
higher pressures than R-22. No other refrigerant may be
used in this system.

5326601-XIM-A-0117
4Johnson Controls Unitary Products
Nomenclature
Z F 180 CA7 A 1 A1A A 1
Product Category
Z = A/C, Single Pkg., R-410A
B = Standard Static
E = VFD/VAV Std Static
H = VFD/VAV w/Bypass Std Static
L = VFD/VAV Customer Std Static
P = VFD IntelliSpeed Std Static
S = VFD w/Byp IntelliSp Std Static
V = VFD Cust IntelliSp Std Static
Blower Option
Product Generation
1 = First Generation
C = Cooling Only
Heat Type
30 = 300 MBH Input
40 = 400 MBH Input
Heat Capacity
Nominal Cooling Capacity
180 = 15 Ton
Product Identifier
F = Pkg AC Std Eff
Voltage
7 = 380/415-3-50
Additional Options
1 = STD Throwaway Filter
2 = 2" Pleated Filters (Merv 8)
3 = 4" Pleated Filters (Merv 13)
4 = Coil Guard (CG), STD Filter
5 = 2" Pleated Filter,CG
6 = 4" Pleated Filter,CG
A = No Economizer
B = Economizer w/Barometric RLF
1
C = Economizer w/o Barometric RLF
D = Economizer w/Power EXH
1
H = Motorized Damper
J = Motorized Damper w/Baro RLF
1
Outdoor Air Option
1 = No Service Options
2 = DSC (Disconnect Switch)
Refrigeration
A = Standard Refrigeration
B = ECC (E-Coat Cond Coil)
C = EEC (E-Coat Evap Coil)
F = ECC,EEC
Service Options
A = Stand Alone Simplicity SE
C = BACnet MSTP,Mdbs,N2 COM Card
D = CPC Control, DFS, APS
F = Fault Detection Diagnostics
G = Novar UCM Ctrl, DFS, APS
H = Hnywll Excel 10 CTRL,DFS,APS
J = CCS Single Zone
K = CCS Change Over Bypass
L = CCS VAV, APS
Controls Option
15 Ton York®50 Hz. Model Number Nomenclature
Two Stage Natural Gas Heat Options
N = 2 Stage Gas Aluminized Steel
S = 2 Stage Gas Stainless Steel
00
00 = Cooling Only
Gas MBH Input
A
Note: 1. Available Downflow Only
A = Std Cabinet
B = HFD (Hinged FLTR/Toolless DR)
C = HCD (Hinged & Toolless ACS DR)
E = SSD (SST Drain Pan)
F = SSD,HFD
G = SSD,HCD
H = SSD,DBW/HCD
A = No Sensors
B = PHM (Phase Monitor)
C = DFS (Dirty Filter Switch)
D = SAD (Supply Air Smoke DET)
E = RSD (Return Air Smoke DET)
F = PHM,DFS
G = PHM,SAD
H = PHM,RSD
J = DFS,SAD
K = DFS,RSD
L = SAD,RSD
M = PHM,DFS,SAD
N = PHM,DFS,RSD
P = PHM,SAD,RSD
Q = DFS,SAD,RSD
R = PHM,DFS,SAD,RSD
Sensors
Cabinet Options

5326601-XIM-A-0117
Johnson Controls Unitary Products 5
Installation
Installation Safety Information
Read these instructions before continuing this appliance
installation. This is an outdoor combination heating and cooling
unit. The installer must assure that these instructions are made
available to the consumer and with instructions to retain them
for future reference.
1. Refer to the unit rating plate for the approved type of gas
for this product.
2. Install this unit only in a location and position as specified
on Page 7 of these instructions.
3. Never test for gas leaks with an open flame. Use
commercially available soap solution made specifically for
the detection of leaks when checking all connections, as
specified on Pages 5, 21 and 41 of these instructions.
4. Always install furnace to operate within the furnace's
intended temperature-rise range with the duct system
and within the allowable external static pressure range,
as specified on the unit name/rating plate, specified on
Page 20 of these instructions.
5. This equipment is not to be used for temporary heating of
buildings or structures under construction.
Limitations
These units must be installed in accordance with the following:
Local Government/Agency regulations.
Refer to unit application data found in this document.
After installation, gas fired units must be adjusted to obtain a
temperature rise within the range specified on the unit rating
plate.
If components are to be added to a unit to meet local codes,
they are to be installed at the dealer’s and/or customer’s
expense.
Size of unit for proposed installation should be based on heat
loss/heat gain calculation made according to the methods of Air
Conditioning Contractors of America (ACCA).
This furnace is not to be used for temporary heating of buildings
or structures under construction.
FIRE OR EXPLOSION HAZARD
Failure to follow the safety warning exactly could result
in serious injury, death or property damage.
Never test for gas leaks with an open flame. use a
commercially available soap solution made specifically
for the detection of leaks to check all connections. A fire
or explosion may result causing property damage,
personal injury or loss of life.
The Smart Equipment™ control board used in this
product will effectively operate the cooling system down
to 0°F when this product is applied in a comfort cooling
application for people. An economizer is typically
included in this type of application. When applying this
product for process cooling applications (computer
rooms, switchgear, etc.), please reference applications
bulletin AE-011-07 or call the applications department
for Unitary Products @ 1-877-UPG-SERV for guidance.
Additional accessories may be needed for stable
operation at temperatures below 30°F.

5326601-XIM-A-0117
6Johnson Controls Unitary Products
Figure 1: ZF180 Component Location
Table 1: ZF180 Unit Limitations
Size (Tons) Unit Voltage
Unit Limitations
Applied Voltage Outdoor DB Temp
Min Max Max (°F) / (°C)
180 (15) 380/415-3-50 342 457 125.6 / 52
HIGH
EFFICIENCY
COMPRESSORS
COPPER TUBE/ALUMINUM FIN
CONDENSER COILS
ELECTRICAL
DISCONNECT
MOUNTING
LOCATION
(Field installed)
KNOCKOUT FOR
SIDE CONTROL
WIRING ENTRY
KNOCKOUT
FOR SIDE
POWER WIRING
ENTRY SIDE
KNOCKOUTS FOR SIDE
GAS SUPPLY ENTRY
HOLE FOR BOTTOM
GAS SUPPLY ENTRY
POWER VENTOR MOTOR
WITH POST PURGE CYCLE
BELT-DRIVE
BLOWER MOTOR
FULL PERIMETER
14 GAUGE BASE RAILS
WITH LIFTING HOLES
1" NPTI
CONDENSATE DRAIN
2" DISPOSABLE
FILTERS
LONG LASTING
POWDER PAINT FINISH
20 GAUGE
ALUMINIZED STEEL
TUBULAR HEAT EXCHANGERS
GAS/ELECTRIC
UNIT SHOWN

5326601-XIM-A-0117
Johnson Controls Unitary Products 7
Location
Use the following guidelines to select a suitable location for
these units:
1. Unit is designed for outdoor installation only.
2. Condenser coils must have an unlimited supply of air.
Where a choice of location is possible, position the unit on
either north or east side of building.
3. Suitable for mounting on roof curb.
4. For ground level installation, use a level concrete slab with
a minimum thickness of 4 inches. The length and width
should be at least 6 inches greater than the unit base rails.
Do not tie slab to the building foundation.
5. Roof structures must be able to support the weight of the
unit and its options/accessories. Unit must be installed on a
solid, level roof curb or appropriate angle iron frame.
6. Maintain level tolerance to 1/2” across the entire width and
length of unit.
Clearances
All units require particular clearances for proper operation and
service. Installer must make provisions for adequate
combustion and ventilation air in accordance with section 5.3 of
Air for Combustion and Ventilation of the National Fuel Gas
Code, ANSI Z223.1 – Latest Edition (in U.S.A.), or Sections 7.2,
7.3, or 7.4 of Gas Installation Codes, CSA-B149.1 (in Canada) -
Latest Edition, and/or applicable provisions of the local building
codes. Refer to Table 7 for clearances required for combustible
construction, servicing, and proper unit operation.
Rigging And Handling
Exercise care when moving the unit. Do not remove any
packaging until the unit is near the place of installation. Rig the
unit by attaching chain or cable slings to the lifting holes
provided in the base rails. Spreader bars, whose length
exceeds the largest dimension across the unit, MUST be used
across the top of the unit.
Units may be moved or lifted with a forklift, from the side only,
providing an accessory skid is used.
LENGTH OF FORKS MUST BE A MINIMUM OF 90 INCHES
(2286MM).
Excessive exposure of this furnace to contaminated
combustion air may result in equipment damage or
personal injury. Typical contaminates include:
permanent wave solution, chlorinated waxes and
cleaners, chlorine based swimming pool chemicals,
water softening chemicals, carbon tetrachloride,
Halogen type refrigerants, cleaning solvents (e.g.
perchloroethylene), printing inks, paint removers,
varnishes, hydrochloric acid, cements and glues,
antistatic fabric softeners for clothes dryers, masonry
acid washing materials.
Do not permit overhanging structures or shrubs to
obstruct condenser air discharge outlet, combustion air
inlet or vent outlets.
If a unit is to be installed on a roof curb other than a
York® roof curb, gasketing must be applied to all
surfaces that come in contact with the unit underside.
Before lifting, make sure the unit weight is distributed
equally on the rigging cables so it will lift evenly.
All panels must be secured in place when the unit is
lifted.
The condenser coils should be protected from rigging
cable damage with plywood or other suitable material.

5326601-XIM-A-0117
8Johnson Controls Unitary Products
Figure 2: Unit 4 Point Load Weight Figure 3: Unit 6 Point Load Weight
Figure 4: Center of Gravity
Table 2: ZF180 Unit Weights Imperial
A
B
C
D
FRONT
A
C
D
F
B
E
FRONT
1624 (64”)
XY
LEFT FRONT
Size
(Tons) Model Weight (lbs.) Center of Gravity 4 Point Load Location (lbs.) 6 Point Load Location (lbs.)
ShippingOperatingX Y ABCD A B C D E F
180 (15) ZF 1685 1680 66.5 45.7 391 443 449 397 256 277 302 306 281 259
Table 3: ZF180 Unit Weights Metric
Size
(Tons) Model Weight (kg.) Center of Gravity (mm) 4 point Load Location (kg.) 6 point Load Location (kg.)
ShippingOperatingX Y ABCDABCDEF
180 (15) ZF 766 764 1689 1161 178 202 204 180 116 126 137 139 128 118
Table 4: ZF180 Unit Accessory Weights Metric
Unit Accessory Weight (kg.)
Shipping Operating
Economizer 74.8 72.6
Power Exhaust 40.8 40.8
Gas Heat1
1. Weight given is for the maximum number of tube heat
exchangers available (8 tube).
108.9 108.9
Motorized Damper 68 68
Barometric Damper 22.7 22.7
Econ./Motorized Damper Rain Hood 27.2 27.2
Econ./Power Exhaust Rain Hood 43.1 43.1
Wood Skid 99.8 99.8
Roof Curb 86.2 86.2
Table 5: ZF180 Unit Accessory Weights Imperial
Unit Accessory Weight (lbs.)
Shipping Operating
Economizer 165 160
Power Exhaust 90 85
Gas Heat1
1. Weight given is for the maximum number of tube heat
exchangers available (8 tube).
240 240
Motorized Damper 150 150
Barometric Damper 50 45
Econ./Motorized Damper Rain Hood 60 55
Econ./Power Exhaust Rain Hood 95 90
Wood Skid 220 220
Roof Curb 190 185

RETURN AIR
SUPPLY AIR
OUTDOOR AIR
(Discharge)
OUTDOOR AIR
(Economizer)
3181 (125-1/4")
1235 (48-5/8")
616 (24-1/4")
1235 (48-5/8")
3181 (125-1/4")
616 (24-1/4")
RETURN AIR
OUTDOOR AIR
(Economizer)
SUPPLY AIR
OUTDOOR AIR
(Discharge)
5326601-XIM-A-0117
Johnson Controls Unitary Products 9
Figure 6: Unit Dimensions - ZF Gas Heat
Figure 5: Unit Dimensions - ZF Cooling Only

5326601-XIM-A-0117
10 Johnson Controls Unitary Products
Figure 7: ZF180 Unit Dimensions Rear View
NOTE: Units are shipped with the bottom duct openings
covered. An accessory flange kit is available for
connecting side ducts.
For bottom duct applications:
1. Remove the side panels from the supply and return air
compartments to gain access to the bottom supply and
return air duct covers.
2. Remove and discard the bottom duct covers. Duct
openings are closed with sheet metal covers except when
the unit includes a power exhaust option. The covering
consists of a heavy black paper composition.
3. Replace the side supply and return air compartment
panels.
For side duct applications:
1. Replace the side panels on the supply and return air
compartments with the accessory flange kit panels.
2. Connect ductwork to the flanges on those panels.
Table 6: Utilities Entry Data
HOLE OPENING SIZE
(DIA.) (MM/IN.) USED FOR
A29/1-1/8” KO Control Wiring Side
19/3/4” NPS (Fem.) Bottom
B92/3-5/8” KO Power Wiring Side
76/3” NPS (Fem.) Bottom
C60/2-3/8” KO Gas Piping (Front)1
D43/1-11/16” Hole Gas Piping (Bottom)1, 2
1. One-inch gas piping NPT required.
2. Opening in the bottom of the unit can be located by the slice in
the insulation.
NOTE: All entry holes should be field sealed to prevent rain
water entry into the building.
SUPPLY
AIR
RETURN
AIR
OUTDOOR
AIR
130
(5-1/8")
474
(18-5/8")
705
(27-3/4")
727 (28-5/8”)
1029
(40-1/2")
OUTDOOR AIR
COMPARTMENT
ACCESS
FILTER
ACCESS
1" NPT FEMALE
COND. DRAIN
CONNECTION
DOT PLUG
(For pressure
drop reading)
EVAPORATOR
SECTION
1026
(40-3/8")
COMPRESSOR
ACCESS
SUPPLY AIR
ACCESS
RETURN AIR
ACCESS
REAR
VIEW
Dimensions listed are for side
duct flange openings; see
Field Accessories for Side
Duct Flange Kit.

5326601-XIM-A-0117
Johnson Controls Unitary Products 11
Figure 8: ZF180 Unit Dimensions Rain Hood
Note: ELEC/ELEC Models: Units and ductwork are approved for zero clearance to combustible material when
equipped with electric heaters.
GAS/ELEC Models: A 1" clearance must be provided between any combustible material and the supply air
ductwork for a distance of 3 feet from the unit.
The products of combustion must not be allowed to accumulate within a confined space and recirculate.
Locate unit so that the vent air outlet hood is at least:
• Three (3) feet above any force air inlet located within 10 horizontal feet (excluding those integral to the unit).
• Four (4) feet below, four horizontal feet from, or one foot above any door or gravity air inlet into the building.
• Four (4) feet from electric and gas meters, regulators and relief equipment.
Table 7: ZF180 Unit Clearances
Direction Distance (mm)/(in.) Direction Distance (mm)/(in.)
Top1
1. Units must be installed outdoors. Over hanging structure or shrubs should not obscure condenser air discharge outlet.
1829/72 With 914/36 Maximum Horizontal
Overhang (For Condenser Air Discharge) Right 914/36
Front 914/36 Bottom2
2. Units may be installed on combustable floors made from wood or class A, B or C roof covering materials.
0
Rear 610/24 (W/O Economizer) Left 610/24 (W/O Economizer)
1245/49 (W/Economizer) 1245/36 (W/Economizer)3
3. If economizer is factory installed, the unassembled rain hood must be removed from its ride along position in front of the evaporator coil, or
in the outdoor air compartment, prior to final installation.
REAR VIEW
DETAIL “Y”
UNIT WITH RAIN HOODS
LH VIEW
716
(28-3/16”)
2337
(92”)
930
(36-5/8”)
127 (5”)
410
(16-1/8”)
SUPPLY AIR
COMPARTMENT
POWER EXHAUST
RAIN HOOD
(on Return Air Compartment)
ECONOMIZER
MOTORIZED
DAMPER
RAIN HOOD
(on Outdoor Air Compartment) ECONOMIZER / MOTORIZED DAMPER
AND POWER EXHAUST RAIN HOODS
FIXED
OUTDOOR AIR
INTAKE HOOD
(located on
Return Air
Compartment)
25 (1“) CONDENSATE
DRAIN
(Must be trapped)

5326601-XIM-A-0117
12 Johnson Controls Unitary Products
Ductwork
Ductwork should be designed and sized according to the
methods in Manual D of the Air Conditioning Contractors of
America (ACCA) or as recommended by any other recognized
authority such as ASHRAE or SMACNA.
A closed return duct system should be used. This will not
preclude use of economizers or outdoor fresh air intake. The
supply and return air duct connections at the unit should be
made with flexible joints to minimize noise.
The supply and return air duct systems should be designed for
the CFM and static pressure requirements of the job. They
should NOT be sized to match the dimensions of the duct
connections on the unit.
Refer to Figure 5 for bottom air duct openings. Refer to Figure 7
for side air duct openings.
NOTE: It is recommended that, in Canada, the outlet duct be
provided with a removable access panel. It is
recommended that this opening be accessible when
the unit is installed in service, and of a size such that
smoke or reflected light may be observed inside the
casing to indicate the presence of leaks in the heat
exchanger. The cover should be attached in a
manner adequate to prevent leakage.
Figure 9: Roof Curb Dimensions (All Models)
* Supply and Return air (including duct
support rails) as shown, are typical for
Downflow duct applications
For location of Sideflow duct applica-
tions (on back of unit), refer to Unit
Dimension details.
Figure 10: Roof Curb Benefits Figure 11: Unit Curb And Applications

5326601-XIM-A-0117
Johnson Controls Unitary Products 13
Fixed Outdoor Air Intake Damper
This damper is shipped inside the return air compartment. It is
completely assembled and ready for installation. A damper
baffle inside of the hood is adjustable to provide variable
amounts of outdoor air intake on units that are not provided with
an economizer or a motorized damper option. Refer to the
Fixed Outdoor Damper Figure 12.
Gasketing and mounting screws are provided in a parts bag
attached to the hood assembly. Apply gasketing to the three
flange surfaces on the hood prior to installing the hood. Extend
gasketing 1/4 inch beyond the top and bottom of the two side
flanges to insure adequate sealing.
Adjusting the damper to the desired air flow may be done
before mounting the hood into position or after installation by
removing the front hood panel or the screen on the bottom of
the hood. Damper baffle in position 1 will allow approximately
10% outdoor air flow, position 2 approximately 15% and, to
allow approximately 25%, remove the damper baffle.
On units with bottom return air application install the damper
assembly over the opening in the side return air access panel.
Remove and discard the opening cover and the covering over
the hood mounting holes (used for shipping) before installing.
Secure with the screws provided.
On units with side return air applications, install the damper
assembly on the return air ductwork as close to the unit as
possible. Cut an opening 16 inches high by 18 inches wide in the
ductwork to accommodate the damper. Using the holes in the
hood flanges as a template, drill 9/64 inch diameter (#26 drill)
holes into the ductwork and secure with the screws provided.
Figure 12: Fixed Outdoor Air Damper
Condensate Drain
Plumbing must conform to local codes. Use a sealing compound
on male pipe threads. Install a condensate drain line from the
one-inch NPT female connection on the unit to an open drain.
NOTE: The condensate drain operates in a negative pressure
in the cabinet. The condensate drain line MUST be
trapped to provide proper drainage. See Figure 13.
Figure 13: Condensate Drain
Compressors
The scroll compressor used in this product is specifically
designed to operate with R-410A Refrigerant and cannot be
interchanged.
The compressor also uses a polyolester (POE oil), Mobil 3MA
POE. This oil is extremely hygroscopic, meaning it absorbs water
readily. POE oil can absorb 15 times as much water as other oils
If outdoor air intake will not be required on units with
bottom return air applications, the damper assembly
should still be mounted on the side return air access
panel, per the instructions above, to insure moisture is
not drawn into the unit during operation. The covering
over the mounting holes only need be removed. Do not
remove the opening cover.
This system uses R-410A Refrigerant which operates at
higher pressures than R-22. No other refrigerant may be
used in this system.
*
Side Supply
Air Access
Panel
Damper
Baffle
Hood
Screen
* Gasketed
Flange Rear View
Side Return Air
Access Panel
Outdoor Air
Opening Cover
2
1
Base
Pan
Base
Rails
Drain
Plug
2”
3” Min.
Unit Condensate
Connection

5326601-XIM-A-0117
14 Johnson Controls Unitary Products
designed for HCFC and CFC refrigerants. Take all necessary
precautions to avoid exposure of the oil to the atmosphere.
POE (polyolester) compressor lubricants are known to cause
long term damage to some synthetic roofing materials.
Procedures which risk oil leakage include, but are not limited to,
compressor replacement, repairing refrigerant leaks, replacing
refrigerant components such as filter drier, pressure switch,
metering device or coil.
Units are shipped with compressor mountings which are
factory-adjusted and ready for operation.
Filters
Two-inch filters are supplied with each unit, but units can be
converted easily to four-inch filters. Filters must always be
installed ahead of the evaporator coil and must be kept clean or
replaced with same size and type. Dirty filters will reduce the
capacity of the unit and will result in frosted coils or safety
shutdown. Minimum filter area and required sizes are shown in
Physical Data Table 10.
Power And Control Wiring
Field wiring to the unit, fuses, and disconnects must conform to
provisions of National Electrical Code (NEC), ANSI/NFPA No.
70 – Latest Edition (in U.S.A.), current Canadian Electrical
Code C221, and/or local ordinances. The unit must be
electrically grounded in accordance with NEC and CEC as
specified above and/or local codes.
Voltage tolerances which must be maintained at the
compressor terminals during starting and running conditions are
indicated on the unit Rating Plate and Table 1.
The internal wiring harnesses furnished with this unit are an
integral part of the design certified unit. Field alteration to
comply with electrical codes should not be required. If any of
the wire supplied with the unit must be replaced, replacement
wire must be of the type shown on the wiring diagram and the
same minimum gauge as the replaced wire.
A disconnect must be utilized for these units. Factory installed
disconnects are available. If installing a disconnect (field
supplied or York International® supplied accessory), refer to
Figure 1 for the recommended mounting location.
NOTE: Since not all local codes allow the mounting of a
disconnect on the unit, please confirm compliance with
local code before mounting a disconnect on the unit.
Electrical line must be sized properly to carry the load. USE
COPPER CONDUCTORS ONLY. Each unit must be wired with
a separate branch circuit fed directly from the meter panel and
properly fused.
Refer to Figures 14 and 15 for typical field wiring and to the
appropriate unit wiring diagram mounted inside control doors
for control circuit and power wiring information.
Power Wiring Detail
Units are factory wired for the voltage shown on the unit
nameplate. Refer to Electrical Data Table 9 to size power
wiring, fuses, and disconnect switch.
Power wiring is brought into the unit through the side of the unit
or the basepan inside the curb.
Do not leave the system open to the atmosphere. Unit
damage could occur due to moisture being absorbed by
the POE oil in the system. This type of oil is highly
susceptible to moisture absorption
Exposure, even if immediately cleaned up, may cause
embrittlement (leading to cracking) to occur in one year
or more. When performing any service that may risk
exposure of compressor oil to the roof, take precautions
to protect roofing.
Do not loosen compressor mounting bolts.
Make sure that panel latches are properly positioned on
the unit to maintain an airtight seal.
Avoid damage to internal components if drilling holes for
disconnect mounting.
When connecting electrical power and control wiring to
the unit, water-proof connectors must be used so that
water or moisture cannot be drawn into the unit during
normal operation. The above water-proofing conditions
will also apply when installing a field supplied disconnect
switch.

5326601-XIM-A-0117
Johnson Controls Unitary Products 15
Figure 14: Field Wiring Disconnect - Cooling Unit With/Without Electric Heat
Thermostat Wiring
The thermostat should be located on an inside wall approximately
56 inch above the floor where it will not be subject to drafts, sun
exposure or heat from electrical fixtures or appliances. Follow the
manufacturer's instructions enclosed with thermostat for general
installation procedure. Seven (7) color-coded, insulated wires
should be used to connect the thermostat to the unit. Refer to
Table 8 for control wire sizing and maximum length.
Space Sensor
The space sensor, if used, should be located on an inside wall
approximately 56 inches above the floor where it will not be
subject to drafts, sun exposure or heat from electrical fixtures or
appliances. Follow manufacturer's instructions enclosed with
sensor for general installation procedure.
THREE
PHASE
POWER
SUPPLY
FACTORY OR FIELD
SUPPLIED DISCONNECT
GROUND
LUG
TERMINAL BLOCK TB1
Table 8: Control Wire Sizes
Wire Size Maximum Length1
1. From the unit to the thermostat and back to the unit.
18 AWG 150 Feet

5326601-XIM-A-0117
16 Johnson Controls Unitary Products
Figure 15: Typical Field Wiring 24 Volt Thermostat
OCC
C
RC
G
Y2
Y1
W2
W1
X
R
THERMOSTAT
TERMINALS
CONTROL
TERMINAL
BLOCK
TERMINALS ON A
LIMITED NUMBER
OF THERMOSTATS
1
4
3
1
2
4
Second stageŚĞĂƟŶŐŶot required on single stage heĂƟŶg units.
Jumper is required if there is no Smoke Detector circuit.
Jumper is required for any coŵďŝŶĂƟŽŶ of R, RC, or RH.
5
5
OCC is an output from the thermostat to indicate the Occupied ĐŽŶĚŝƟon.
X is an input to the thermostat to display Error Status condiƟons.
3
W2
Y1
G
OCC
Y2
X
R
SD-24
C
W1
2
24V
C
24 VAC
Class 2
SD-24
Jumper Located on Harness
Smoke
Detector
SD-R
24V Output
R
(If No Smoke Detector) (If Smoke Detector Is Used)

5326601-XIM-A-0117
Johnson Controls Unitary Products 17
Table 9: Electrical Data
ZF180 - Standard Drive
Size
(Tons) Volt
Compressors
(each) OD Fan
Motors
(each)
Supply
Blower
Motor
Pwr
Conv
Outlet
Electric Heat Option MCA1
(Amps)
1. Minimum Circuit Ampacity.
Max Fuse2/
Breaker3
Size
(Amps)
2. Dual Element, Time Delay Type.
3. HACR type per NEC.
RLA LRA MCC
C1 C2 C1 C2 C1 C2 FLA FLA FLA Model kW Stages Amps
180
(15)
380-3-50 16.7 13 111 101 26 20.3 2.1 6.3 0 NONE - - - 44.4 60
415-3-50 16.7 13 111 101 26 20.3 2.1 6.7 0 NONE - - - 44.8 60

5326601-XIM-A-0117
18 Johnson Controls Unitary Products
Table 10: ZF180 Physical Data
Component Models
ZF180
Nominal Tonnage 15
Brand YORK
Country of Origin Made in USA
Rated Voltage Range 380-415 Volts
Rated Frequency 50Hz
Nominal CFM 6000
Rated Cooling Capacity (T1) - BTUH 204831
Rated Power Input (T1) - KW 17.92
Energy Efficiency Ratio (EER) (T1) - BTUH/W 11.43
Rated Cooling Capacity (T3) - BTUH 155436
Rated Power Input (T3) - KW 20.92
Rated Current (T3) - AMPS 36.6
Energy Efficiency Ratio (EER) (T3) - BTUH/W 7.43
Refrigerant Used R410A
Refrigerant charge (lb-oz)
System 1 22-8
System 2 21-8
AHRI HEATING PERFORMANCE
Heating model N30 N40
Heat input (K Btu) 300 400
Heat output (K Btu) 240 320
AFUE% - -
Steady state efficiency (%) 80 80
No. burners 6 8
No. stages 2 2
Temperature Rise Range (ºF) 20-50 35-65
Gas Limit Setting (ºF) 195 195
Gas piping connection (in.) 1 1
DIMENSIONS (inches)
Length 125-1/4
Width 92
Height 48-5/8
OPERATING WT. (lbs.) 1680
COMPRESSORS
Type Scroll
Quantity 2
Unit Capacity Steps (%) 50 / 100
CONDENSER COIL DATA
Face area (Sq. Ft.) 36.0
Rows 3
Fins per inch 13.5
Tube diameter (in.) 3/8
Circuitry Type Standard
EVAPORATOR COIL DATA
Face area (Sq. Ft.) 15.5
Rows 4
Fins per inch 14
Tube diameter 3/8
Circuitry Type Intertwined
Refrigerant control TXV

5326601-XIM-A-0117
Johnson Controls Unitary Products 19
CONDENSER FAN DATA
Quantity 2
Fan diameter (Inch) 30
Type Prop
Drive type Direct
No. speeds 1
Number of motors 2
Motor HP each 1.25
RPM 950
Nominal total CFM 6000
BELT DRIVE EVAP FAN DATA
Quantity 1
Fan Size (Inch) 15 X 15
Type Centrifugal
Motor Sheave 1VP62
Blower Sheave BK75
Belt BX68
Motor HP each 4.0
RPM 1450
Frame size 184T
FILTERS
Quantity - Size
5 - (18 x 24 x 2)1,2
-
5 - (18 x 24 x 4)3
-
1. 2 In. Throwaway, Standard, MERV (Minimum Efficiency Reporting
Value) 3.
2. 2 In. Pleated, Optional, MERV 8.
3. 4 In. Pleated, Optional, MERV 13.
Table 10: ZF180 Physical Data (Continued)
Component Models
ZF180
Nominal Tonnage 15

5326601-XIM-A-0117
20 Johnson Controls Unitary Products
Optional Gas Heat
These gas-fired heaters have aluminized-steel or optional
stainless steel, tubular heat exchangers with spark ignition with
proven pilot.
Gas Piping
Proper sizing of gas piping depends on the cubic feet per hour
of gas flow required, specific gravity of the gas and the length of
run. “National Fuel Gas Code” Z223.1 (in U.S.A.) or the current
Gas Installation Codes CSA-B149.1 (in Canada) should be
followed in all cases unless superseded by local codes or gas
utility requirements. Refer to the Pipe Sizing Table 13. The
heating value of the gas may differ with locality. The value
should be checked with the local gas utility.
NOTE: There may be a local gas utility requirement specifying
a minimum diameter for gas piping. All units require a
one-inch pipe connection at the entrance fitting.
Figure 16: External Supply Connection External Shut-Off
Figure 17: Bottom Supply Connection External Shut-Off
NOTE: Maximum capacity of pipe in cubic feet of gas per hour
based upon a pressure drop of 0.3 inch W.C. and 0.6
specific gravity gas.
Gas Connection
The gas supply line can be routed within the space and roof curb,
exiting through the unit’s basepan. Refer to Figure 5 for the gas
piping inlet location. Typical supply piping arrangements are
shown in Figures 16 and 17. All pipe nipples, fittings, and the gas
cock are field supplied.
Gas piping recommendations:
1. A drip leg and a ground joint union must be installed in the
gas piping.
2. Where required by local codes, a manual shut-off valve
must be installed outside of the unit.
3. Use wrought iron or steel pipe for all gas lines. Pipe dope
should be applied sparingly to male threads only.
Table 11: Gas Application Data
Unit Input
(MBH) Output (MBH) Temp Rise
(°F)
Size Opt.
180 N30 300 240 20-50
N40 400 320 30-60
Drip Leg
Main
Manual
Shut-off
Valve
Drip Leg
Main
Manual
Shut-off
Valve
Table 12: Gas Pipe Sizing - Capacity of Pipe
Length of
Pipe ft. (m)
Nominal Iron Pipe Size
1 in. 1-1/4 in.
10 (3) 520 (14.7) 1050 (29.7)
20 (6) 350 (9.9) 730 (20.6)
30 (9.1) 285 (8) 590 (16.7)
40 (12.1) 245 (6.9) 500 (14.1)
50 (15.2) 215 (6) 440 (12.4)
60 (18.2) 195 (5.5) 400 (12.4)
70 (21.3) 180 (5) 370 (10.4)
80 (24.3) 170 (4.8) 350 (9.9)
90 (27.4) 160 (4.5) 320 (9)
100 (30.4) 150 (4.2) 305 (8.6)
Table 13: Gas Heat Minimum Supply Air Imperial
Size
(Tons) Heat Size
Supply Air (CFM)
Cooling Heating
Min Max Min Max
180
(15)
N30 4500 7000 4500 7000
N40 4500 7000 4500 7000
Table 14: Gas Heat Minimum Supply Air Metric
Size
(Tons) Heat Size
Supply Air (M3/S)
Cooling Heating
Min Max Min Max
180
(15)
N30 2.13 3.3 2.13 3.3
N40 2.13 3.3 2.13 3.3
Natural gas may contain some propane. Propane is an
excellent solvent and will quickly dissolve white lead and
most standard commercial compounds. A special pipe
dope must be used when assembling wrought iron or
steel pipe. Shellac based compounds such as Gaskolac
or Stalastic, and compounds such as Rectorseal #5,
Clydes’s or John Crane may be used.
