York ECO R-22 User manual

Packaged Rooftop
Air Conditioning Units
50 THROUGH 100 TONS
R-407C and R-22
400VAC/3PH/50Hz
FORM 100.50-EG3 (802)
00566VIP
TM
Meets ASHRAE 90.1 - 2001
Efficiency Requirements
ASHRAE
90.1
COMPLIANT

YORK INTERNATIONAL
2
Introduction
Theeco2packaged rooftop – Designed to meet the de-
mands of the market for today and tomorrow.
Better Economy...
Reduce Energy Consumption
• High-efficiency eco2 rooftop units are optimized for
both R-22 and HFC-407C refrigerant, and are the
first environmentally responsible rooftop units that
meettheASHRAE90.1-2001 efficiencystandards.
• Multiplestepsofcapacity-controloffersuperior off-
designenergyperformance, while maintainingbet-
ter control of occupant comfort.
• The OptiLogicTM Control Center ensures that no
more than the proper amount of ventilation air is
utilized, avoiding the energy cost of conditioning
excess air.
Better Ecology...
Air Quality Features for the Indoor Environment
• A double-sloped stainless steel design ensures that
allcondensateisvoidedfromthedrainpan.Thedrain
pan is also visible and accessible for the periodic in-
spection and cleaning required by IAQ standards.
• Double-wall construction of the roof, floor, doors,
and walls prevents insulation fiber from entering
the supply air. The inner liner also facilitates peri-
odic cleaning of the unit to prevent harmful build-
up of bacteria or contaminants.
• The OptiLogicTM Control Center uses microproces-
sorlogictoanalyzeandoptimizeventilationdecisions.
• Atrueairflow-measurementstationcan be supplied,
to ensure the proper ventilation at all supply-air
volumes.
• Anavailablesensorcan monitortheCO2levelwithin
the building and adjust the ventilation rate on de-
mand, to maintain the air quality at a healthy level.
HFC-407C Refrigerant
for the Global Environment
The OptiLogicTM Control Center uses microprocessor logic to opti-
mize operation of the eco2 rooftop unit.
LD07431
LD07430

FORM 100.50-EG3 (802)
3
YORK INTERNATIONAL
TABLE OF CONTENTS
Introduction.............................................................2
Features and Benefits ............................................4
Nomenclature .........................................................7
Application Data .....................................................8
Physical Data........................................................12
Cooling Performance Data ...................................16
Heating Performance Data – Gas/Electric Heat ...36
Supply Fan Data...................................................37
Component Static Pressure Drops .......................40
Gas Heat Pressure Drops ....................................44
Electric Heat Pressure Drops ...............................46
Exhaust Fan Data.................................................48
Component Static Pressure Drops .......................50
Electrical Data ......................................................52
Controls................................................................54
Power Wiring........................................................60
Field Control Wiring..............................................63
GeneralArrangement Drawings ...........................64
Curb Layout Drawing ............................................69
Power/ControlEntryDrawing................................70
Guide Specifications .............................................71
TABLES
1 Physical Data .................................................12
2 Cooling Performance Data – 50 Ton Model....16
3 Cooling Performance Data – 55 Ton Model....18
4 Cooling Performance Data – 60 Ton Model....20
5 Cooling Performance Data – 65 Ton Model....22
6 Cooling Performance Data – 70 Ton Model....24
7 Cooling Performance Data – 75 Ton Model....26
8 Cooling Performance Data – 80 Ton Model....28
9 Cooling Performance Data – 85 Ton Model....30
10 Cooling Performance Data – 90 Ton Model....32
11 Cooling Performance Data – 95 Ton Model....34
12 Gas Heat Performance Data..........................36
13 Electric Heat Performance Data.....................36
14 50 Through 65 Ton Supply Fan Data..............37
15 70 Through 85 Ton Supply Fan Data..............38
16 90 Through 95 Ton Supply Fan Data..............39
17 Component Static Pressure Drops .................40
18 Gas Heat Pressure Drops ..............................44
19 Electric Heat Pressure Drops.........................46
20 60 Through 65 Ton Exhaust Fan Data............48
21 70 Through 85 Ton Exhaust Fan Data............49
22 90 Through 95 Ton Exhaust Fan Data............49
23 Component Static Pressure Drops .................50
24 Compressor Data...........................................52
25 Supply and Exhaust Fan Motor
Electrical Data................................................53
26 Condenser Fan Motors ..................................53
27 Control Transformer .......................................53
28 Electric Heat...................................................53
29 GeneralArrangement – 50-65 Ton Models
(BottomSupply/BottomReturn) .......................64
30 GeneralArrangement – 50-65 Ton Models
(SideSupply/FrontReturn) ..............................65
31 GeneralArrangement – 70-95 Ton Models
(BottomSupply/BottomReturn).......................66
32 GeneralArrangement – 70-95 Ton Models
(Side Supply/Front Return).............................67
33 GeneralArrangement – 70-95 Ton
Optional Side Return......................................68
34 Curb Layout Dimensions................................69
35 Power/Control Dimensions.............................70
FIGURES
1 Single-Point Power Supply Wiring..................60
2 Single-Point Power Supply Wiring with
Non-Fused Disconnect ..................................61
3 Dual-Point Power Supply Wiring ....................62
4 Field Control Wiring .......................................63
5 Gen.Agmt. Dwg. – 50-65 Ton Models
(Bottom Supply/Bottom Return) ...................... 64
6 Gen.Agmt. Dwg. – 50-65 Ton Models
(SideSupply/FrontReturn) ..............................65
7 Gen.Agmt. Dwg. – 70-95 Ton Models
(Bottom Supply/Bottom Return) ......................66
8 Gen.Agmt. Dwg. – 70-95 Ton Models
(SideSupply/FrontReturn) ..............................67
9 Gen.Agmt. Dwg. – 70-95 Ton Models
(Optional Side Return) ...................................68
10 Curb Layout Drawing .....................................69
11 Power/Control Entry Drawing –
50-95 Ton Model ............................................70

YORK INTERNATIONAL
4
Features and Benefits
QUALITY ROOFTOP UNIT DESIGNED TO TODAY’S
STANDARDS
Ecological and Economical Design
• FirstpackagedRTUthatmeetsASHRAE 90.1-2001
with both R-22 and R-407C Refrigerants.
•Cooling and Heating – Superioroperating perfor-
manceprovidesloweroperatingcosts.Smallersteps
ofcoolingcapacityprovidetighter control of building
environmentandoccupantcomfortwhile optimizing
energy efficiency.
•Indoor Air Quality (IAQ) – Outside air economizer
provides energy savings in free cooling mode, and
canprovideahealthierandmorecomfortablebuild-
ingenvironmentbyintroducingfreshoutsideairinto
the building as needed. IndoorAir Quality (IAQ) re-
quirements for building ventilation and comfort are
controlledthroughthe microprocessorcontrolpanel.
Optionalairflow measurement provides an accurate
means of tracking air quality and alerting the occu-
pants or building owner to unhealthy situations.
•Premium Efficiency – Premium-efficiencymotors
are available for optimum energy efficiency. All mo-
tors used on the eco2packaged rooftop air condi-
tionermeetU.S.EPACT1992minimumrequirements.
•VFDsStandard onVAV Units–Variable-frequency-
drives provide the HVAC designer with a high-effi-
ciency,quietandmorereliablemeans of variable air
volume control from a packaged rooftop. On larger
rooftops,ASHRAE90.1-1999standardspecifiespart
load efficiency requirements that make VFDs the
cost-effective solution for meeting the standard.
VFDs can save the owner up to 40% of the energy
costscomparedtoinletguide vanesofferedoncom-
petitive units by reducing the power requirement.
VFDs use fewer parts, which leads to more reliabil-
ity.Also, with fewer moving parts, and the reduction
ofspeedinthe fan, theVFDoperatesatsignificantly
quieter operation than the inlet guide vane which
restrictsahighvolumeofairflow,whichcanactually
increase noise at part load conditions.
Additionally, the YORK VFD includes DC link reac-
tors as standard that have harmonic filtration com-
parabletoanAClinereactor.VFDsalsoprovidethe
added benefit of soft-starting the supply fan, which
helps to minimize demand charges associated with
inrush currents.
•NetworkConnectivitywith BACnet,LON orRoof-
Link Interface – Throughoptionalcommunications
protocols, the eco2rooftop unit can communicate to
any building automation system. There are four op-
tionsavailable:BACnetInternet Protocol(Ethernet),
BACnetMSTP(RS485),LONor a generic RoofLink
BAS interface, depending on the type of building
automation system. Without network communica-
tions,theeco2isdesignedtooperateinstand-alone
mode, or via contact closures for basic control.
•ProfessionalAppearance –Ahigh quality powder
coat paint finish is applied to the galvanized steel
exterior of the eco2unit to protect it from aggressive
environments helping to maintain a factory-quality
appearance for years.
•FlexSys Underfloor Air System Configuration –
the eco2 rooftop is the first packaged rooftop product
withdesignsspecifically forusewiththeYORKFlex-
Sys underfloor air system. Ask your local YORK
representative for more information.
Indoor Air Quality (IAQ)
•Double-Sloped Stainless Steel Drain Pan – This
double-sloped inclined stainless steel drain pan fa-
cilitates removal of evaporator condensate. Sloped
in two directions, this drain pan swiftly drains any
condensate from the unit. Best of all, the drain pan
is accessible for periodic cleaning required by IAQ
standards.
•Smart Ventilation – YORK maintains the leader-
ship role in IAQ products with adaptive ventilation
control.TheOptiLogicTMcontrolsprovidecontinuous
monitoring of air quality and take action by opening
theoutsideairdampers,bringingintheright amount
of fresh air before air impurities reach uncomfortable
or even dangerous levels.
• Air Flow Measurement – Precise measurement
of ventilation air flow is possible using an air flow
measurement station which can be installed in the
economizer section. Proper ventilation air flow is
requiredto ensure sufficientfreshairisin the build-
ing. A myriad of air flow measurement options are
available from minimum air flow to high-accuracy
full air flow capabilities.The complete system is de-
signed as an integrated component of the
OptiLogicTM controlsystem to ensure optimum sys-
tem performance.
•DoubleWallConstruction –Rigid double-wallcon-
struction throughout provides ease of cleaning and
protects against insulation fiber entrainment in the
breathable air. Double-wall construction also helps
improvetheacousticalcharacteristics of theairhan-
dling unit.
•Enhanced Filtration – The eco2 unit gives design-
ers the flexibility to meet various IAQ requirements
withafullrangeofrigidandthrowawayfilteroptions
at various efficiency levels.
•Demand Ventilation – Control of the economizer
is available to maintain a desired ventilation level
basedon a 0-10VDC inputfromasensor.Afactory-
supplied CO2 sensor is available for installation in
the occupied space.

FORM 100.50-EG3 (802)
5
YORK INTERNATIONAL
Reliable Cooling and Heating Technology
• Reliable,efficient,trouble-freeoperation is the true
measureof a packaged rooftop’svalue.That’swhy
YORKeco2PackagedRooftopAirConditionersuse
establishedscroll-compressortechnologytodeliver
dependable, economical performance in a wide
range of applications. With the eco2Packaged
Rooftop, you get the latest generation of compres-
sor enhancements added to the scroll’s inherent
strengths. The simplicity of a hermetic scroll com-
pressor allows the use of fewer moving parts to
minimize breakdown. YORK also employs the lat-
estsealingtechnologyto avoid metal-to-metalcon-
tact.Axial sealing is accomplished with floating tip
seals, while radial sealing utilizes a microcushion
of oil. The result: a maintenance-free compressor
providing minimum wear and maximum runtime.
•Gas Furnace – The eco2rooftop gas furnace is an
induced-draft gas furnace designed for high effi-
ciency and reliability. The furnace uses an alumi-
nized steel tubular heat exchanger and operates
attemperaturessufficientto preventacidicexhaust
gases from condensing in the heat exchanger at
low fire rates, unlike drum and tube style furnaces
that generate condensation formation.
GasheatunitsareU.L./C.U.L.listedandare tested
to ANSI standard Z21.47. Multiple modules pro-
vide redundancy not available in single power
burner applications.
Serviceability
•OptiLogicTM – Fully-integrated factory-packaged
controls are standard on every unit and include a
display unit with a 4x20 character LCD display.
OptiLogicTM continuallymonitorsall control setpoints
and configurations. If a unit sensor fails, the con-
trollerindicates an alarm. Ifdesired,YORK service
can provide remote monitoring and automatically
schedule a service technician to make the repair
and maintain your comfort.
•Access Doors – Full-sized access doors provide
easy access into the unit for routine maintenance
and inspection.
•Suction & Discharge Service Valves – Oversized
service valves to provide isolation and quick recla-
mationandchargingofsystemrefrigerantareavail-
ableto minimize downtime and simplifytheservice
and repair task.
•Convenience Outlet – For maintenance tasks re-
quiring power tools, an optional 110V GFCI power
supply can power lights, drills or any other power
hand tool needed.
•Filter MaintenanceAlarm –Anoptionalfiltermain-
tenancealarmindicateswhenafilterbecomesdirty
and requires replacement or cleaning.
Install with Ease and Safety
•Factory Run-Tested – Each unit is subjected to a
series of quality assurance checks as well as an
automatedqualitycontrolprocessbefore being run-
tested.Fans and drives are balancedatthefactory
during testing. The factory run-test ensures safe,
proper operation when the unit is installed and re-
duces installation and commissioning time.
•Single-Point Power Connection – Single-point
power connection reduces installation time by pro-
viding a single-point for incoming power, including
theoptionalconvenienceoutlet.Allincomingpower
is connected in one location, reducing the cost of
distributed power wiring.
•Rain Hoods Rotate Into Place – No bulky, field- in-
stalled rain hoods here. eco2rain hoods ship rotated
inside the unit. Once on the job, the installer merely
rotatesthehoodupward,caulksandfastensitinplace
with sheet metal screws – an easy, one-person job.
•Factory-mounted and Wired Controls –All con-
trolpointswithintheunitarefactory-installed,wired
and tested.
•Non-Fused Disconnect – An optional factory-in-
stalled non-fused disconnect switch simplifies unit
installationand serviceabilitybyeliminatingthe need
foraseparatedisconnectswitch. Check local codes
for acceptability.
Design Flexibility
•LowAmbient Operation – Head-pressure control
is accomplished via a VFD motor controller rather
thananinefficientandnoisycondenser fan damper.
By varying the speed of the condenser fan, better
controlandquieter operation is obtainedduring the
coolerweather.Lowambientcontrolsareavailable
on all systems offering higher mechanical cooling
capacity at low ambient conditions than competi-
tive units.
•HotGasBypass–Optionalonconstantvolumeunits,
hot gas bypass reduces the cycling of compressors
which helps prolong the life of the equipment.
•Duct Air Openings – Horizontal connections are
available on select configurations, offering more
flexibilityforductlayoutandimprovingsoundtrans-
mission characteristics.
•Compressor Sound Blankets – For applications
in sound-sensitive areas, compressor sound blan-
kets are available to reduce sound emitted from
the rooftop unit.

YORK INTERNATIONAL
6
Features and Benefits (continued)
•Fan Spring Isolators – One-inch spring isolation
is used to prevent vibration transmission from the
rooftop unit’s supply fan to the building. Two-inch
spring isolation is also available.
•Harsh Environments –Avarietyofcoil coating and
materialsareavailableaswellashail guards to pro-
tect coils from weather damage.
00567VIP
OPTIONAL
REPLACEABLE
CORE FILTER
DRIERS
OPTIONAL
HORIZONTAL
SUPPLY AIR
OPENINGS
ANGLED OR
RIGID FLAT
FILTER
SECTION
DISTRIBUTOR
TUBES
PROTECTED
IN PLASTIC
SLEEVES
OPTIONAL
AIRFLOW
MEASUREMENT
STATION
RAINHOODS TO
PREVENT
MOISTURE
FROM ENTERING
THE UNIT
FACTORY-
INSTALLED
OPTILOGIC
ROOFTOP
UNIT
CONTROLLER
V-BANKED
CONDENSER
COILS TO
PROTECT
FROM HAIL
DAMAGE
DOUBLE-SLOPED
STAINLESS STEEL
IAQ DRAIN
PAN AND
INTERMEDIATE
DRAIN PAN
COMPLETE
DOUBLE-WALL
CONSTRUCTION
OF WALLS,
FLOORS,
CEILING,
AND PANELS ANGLED
EVAPORATOR
COIL FOR
LOWER
FACE
VELOCITIES
DOORS ON BOTH
SIDES OF UNIT
AND TIE BACKS
FOR UNIT
SERVICING
CENTRIFUGAL
FAN POWERED
EXHAUST

FORM 100.50-EG3 (802)
7
YORK INTERNATIONAL
1 2 3 4 5 6 7 8 9 10 11 12 13 14 15 16
BASE PRODUCT TYPE NOMINALCAPACITY APPLICATION REFRIGERANT VOLTAGE DUCT LOCATIONS DESIGN SPECIAL
Y 0 5 0 B 45 B A
P055 C L X
060 RS
A065 B
070 R
L075 C S
080 N
085 G
090 E
095 C
V
F
NOMENCLATURE
BASIC MODEL NUMBER
: YORK
: Packaged
Rooftop
:Air-Cooled
: Scroll
: 400 / 3 / 50
: 50-ton
: 55-ton
: 60-ton
: 65-ton
: 70-ton
: 75-ton
: 80-ton
: 85-ton
: 90-ton
: 95-ton
: R-407C
: R-22 : Bottom Supply : Left Supply
: Right Supply
: Bottom Return
: Front Return
: Side Return
: Rev. Level A
: Special
: Std. Product
: Cooling Only
: Natural Gas Heat
: Natural Gas Heat SS HX
: Electric Heat
: Constant Volume
: VAV, VFD
:FlexSys

YORK INTERNATIONAL
8
Application Data
LOCATION
Of the many factors that can affect the acoustical char-
acteristics of a rooftop installation, one of the most im-
portantis theunitlocation.Ideally, therooftopunit should
be installed away from sound-sensitive areas, such as
conference rooms, auditoriums and executive offices.
Possible locations could be above storage areas, hall-
ways, mechanical or utility rooms, or bathrooms.
The eco2air conditioning units are designed for out-
door installation. When selecting a site for installation,
be guided by the following conditions:
• Unit must be installed on a level surface.
• For the outdoor location of the unit, select a place
having a minimum sun exposure and an adequate
supply of fresh air for the condenser.
• Alsoavoid locations beneath windows or between
structures.
• Optional condenser coil protection should be used
forseashorelocationsorotherharsh environments.
• The unit should be installed on a roof that is struc-
turally strong enough to support the weight of the
unit with a minimum of deflection. It is recom-
mended that the unit(s) be installed not more than
15feetfromamainsupportbeamtoprovideproper
structuralsupportandtominimize the transmission
of sound and vibration. Ideally, the center of grav-
ity should be located over a structural support or
building column.
• Location of unit(s) should also be away from build-
ingfluestacksorexhaustventilatorsto prevent pos-
siblereintroductionof contaminatedairthroughthe
outside air intakes.
• Be sure the supporting structures will not obstruct
the duct, gas or wiring connections.
• Proper service clearance space of 6-feet around
the perimeter of the unit, 8-feet on one side for coil
servicing, and 12-feet to any adjacent units is re-
quired to eliminate cross contamination of exhaust
and outdoor air, and for maintenance tasks such
as coil pull and cleaning. No obstructions should
be above the condensing unit section.
RIGGING
Proper rigging and handling of the equipment is man-
datory during unloading and setting it into position to
retain warranty status.
Spreader bars must beusedbycranestoprevent dam-
agetotheunitcasing.Allliftinglugs must be used when
lifting the rooftop unit. Fork lifts will damage the rooftop
unit and are not recommended.
Care must be taken to keep the unit in the upright posi-
tionduring rigging and to preventdamagetothe water-
tight seams in the unit casing. Avoid unnecessary jar-
ring or rough handling.
Ground Level Locations
It is important that the units be installed on a substan-
tialbase that will notsettle,causingstrain on the refrig-
erant lines and sheet metal and resulting in possible
leaks.Aone-piece concreteslabwith footers extended
below the frost line is highly recommended. Addition-
ally, the slab should be isolated from the main building
foundation to prevent noise and vibration transmission
to the building structure.
For ground level installations, precautions should be
taken to protect the unit from tampering by, or injury to,
unauthorizedpersons.Erecting a fence around the unit
is common practice.
ECONOMIZER
The economizer section is used for ventilation of the
conditioned space to maintain indoor air quality, and
also to reduce energy consumption by using outdoor
air cooling in lieu of mechanical cooling. If outdoor air
isappropriate for cooling, but notsufficientfor the cool-
ing demand, mechanical cooling will stage on as nec-
essary until the cooling load is met.
Dual (comparative or differential) enthalpy operation is
the most accurate and efficient means of economizer
operation. The OptiLogicTM control monitors the return
and outside air energy content, and selects the lower of
the two for operation.
VAV SUPPLY AIR PRESSURE CONTROL
Traditional packaged rooftop systems use inlet guide
vanes (IGVs) for ductstaticpressure control.These con-
trol supply duct pressure by modulating dampers (intro-
ducing losses and inefficiencies) on the inlet of the fan,
open and closed. YORK’s variable frequency drives
(VFDs) offer superior fan speed control and quieter,
energy efficient operation.

FORM 100.50-EG3 (802)
9
YORK INTERNATIONAL
For VAV applications, the YORK eco2unit uses a VFD
to modulate fan speed and maintain a constant duct
static pressure. VFDs offer superior control over the
operation of the unit at part load, and offer the addi-
tional benefits of quieter and more efficient operation
when compared to IGV.
HARSH ENVIRONMENTS – CONDENSER AND
EVAPORATOR COIL PROTECTION
For harsh environmental conditions such as seashore
applications, YORK offers three types of coil protec-
tion: copper fin material, black fin and Technicoat coat-
ings. YORK recommends that for corrosive environ-
ments that copper fins be used to protect the evapora-
tor and/or condenser coils. In areas where chemicals
that can corrode copper are present, such as ammo-
nia,YORK recommends that the blackfinorTechnicoat
coating be used for maximum protection.
Copper Fin Condenser Coil
Copper fins can be used instead of aluminum for addi-
tional corrosion protection, however it is not suitable
for areas that are subject to acid rain or exposed to
ammonia.
Pre-Coated Condenser Fins
Black fin coating (yellow fin for evaporator fins) is pre-
coatedapplicationepoxyon aluminum finstocktoguard
fromcorrosiveagentsandinsulateagainstgalvanicpo-
tential. It is used for mild seashore or industrial loca-
tions.This can provide corrosionresistancecomparable
to copper fin coils in typical seashore locations.
Post-Coated Condenser Fins
Technicoat(apost-coated application of epoxy)canbe
usedforseashoreandothercorrosive applications with
the exception of strong alkaloides, oxidizers, wet bro-
mide, chlorine and fluorine in concentrations greater
than 100 ppm.
Any of the above suitable options should be selected
based on the particular project design parameters and
related environmental factors. The application should
befurtherreviewed and approved by the consulting en-
gineer or owner based on their knowledge of the job
site conditions.
BUILDING EXHAUST SYSTEMS
Building exhaust systems are often necessary when
economizers are used to bring in outdoor air. Without
properbuildingexhaust,thebuildingmaybecomeover-
pressurized. The exhaust system maintains the proper
building pressure by expelling the appropriate amount
of air from the building. Exhaust systems are typically
designed to exhaust approximately 10% less air than
whatisenteringthebuilding.Thisprovides a slight posi-
tive pressure in the building.
100% modulating exhaust with building static
pressure sensing and control
The 100% exhaust system can be configured with ei-
ther control actuated dampers or VFDs for modulating
control. The unit controller monitors the building pres-
sureusing a differential pressure transducer and main-
tains the required building static pressure by modulat-
ingthe exhaust control. Ifthebuildinghas other means
of exhaust or building pressure is not important, on/off
or barometric control may be used.
Powered exhaust with fan on/off control
The100% exhaust system canbeconfigured for on/off
operation eliminating the expense of the damper ac-
tuatorsorVFDs.Thisexhaustsystemcanbecontrolled
by either the outside air damper position, or a building
static pressure sensor.
Barometric exhaust
Barometricexhaustcanbeusedwhensmalleramounts
of air at low static pressure variations within the build-
ing or other means of building exhaust are employed.
Barometricexhaust is commonly usedwherethereare
only small fluctuations in building pressure or where
building static pressure control is not necessary.
ROOF CURB
YORK offers optional roof curbs designed specifically
for the eco2footprint. These curbs come disassembled
and require field assembly and installation. For bottom
supply and return openings, the curbs have matching
connections to ease installation. A pipe chase that
matches the rooftop unit pipe chase is also included in
thecurbfootprint forthrough-the-curbutilityconnections.

YORK INTERNATIONAL
10
The curb should be located according to the location
recommendations above, and properly sealed to pre-
vent moisture and air leakage into and out of the duct
system.Flexible collars should beusedwhenconnect-
ing the duct work to prevent unit noise transmission
and vibration into the building.
Duct work should be supported independently of the
unit.
ACOUSTICALCONSIDERATIONS
The eco2unit is designed for lower sound levels than
competitive units by using flexible fan connections, fan
spring isolators, double-wall construction, and lower
speed and horsepower fans. For VAV applications,
VFDs are used instead of inlet guide vanes.Additional
sound attenuation can be obtained using compressor
sound blankets and field-supplied sound attenuators
when necessary.
Evenwiththese equipment design features, the acous-
ticalcharacteristics of the entire installationmust never
beoverlooked.Additionalstepsforthe acoustical char-
acteristicsof a rooftopinstallationshouldbeaddressed
during the design phase of a project to avoid costly al-
terations after the installation of the equipment. During
the design phase of a project, the designing engineer
shouldconsider, at a minimum, theimpactof the equip-
mentlocation,rooftopinstallation,building structure,and
duct work.
SELECTION PROCEDURE
Given:
Total Cooling Load 920 mbh
Sensible Heat 610 mbh
Required Heating Capacity 875 mbh
Design Cooling Ambient Temp. 95°F
IndoorAir Temperature 80°F db/67°F wb
SupplyAir Flow 24,000 cfm
External Static Pressure 2.25 in. w.c.
Electrical Service 460V/3ph/60 Hz
UnitConfiguration/Options:0-100%modulatingecono-
mizer, barometric relief, premium efficiency supply fan
motor and VFD, and two-inch pleated filters, bottom
supply, bottom return.
Select Unit:
1. Determine the internal static pressure drop of the
cabinet by referencing Table 17.
Wet evaporator coil 0.58
Bottom return opening 0.15
Two-inch pleated filters 0.12
Mod. econ. dampers 0.56
Total 1.41 IWG
2. Determine the total static pressure by adding the
internal to the external static pressure.
TSP = 1.41 IWG + 2.25 IWG = 3.66 IWG total static pressure
3. DeterminetheBHPof thesupplyfan fromTable 15
using the supply air flow and total static pressure.
From the table, we interpolate to get 26.3 BHP at
724 rpm.
4. Determinethemotor heat gain of supplyairflowby
first calculating the motor energy and converting it
into Btuh.
Motor Energy
Motor kW = BHP x .746/efficiency
Motor kW = 26.3 x 0.746/0.94
Motor kW = 20.9 kW
Motor Heat Rejection (MHR)
MHR = 2545 x BHP/efficiency
MHR = 2545 x 26.3/0.94
MHR = 71.2 mbh
5. Calculate actual requiredtotalcooling capacity by
adding specified cooling capacity to motor heat
rejection.
Required Total Cooling Capacity
920 mbh + 71.3 mbh = 991 mbh
Required Sensible Cooling Capacity
610 mbh + 71.3 mbh = 681 mbh
Application Data (continued)

FORM 100.50-EG3 (802)
11
YORK INTERNATIONAL
6. Requiredtotalandsensiblecapacitiesare991mbh
and681mbh,respectively.The totalcapacityis82.6
tons, therefore a model YPAL085 is selected. Use
the Cooling Performance Data in Table 9. Locate
the table with the correct ambient air temperature.
Next, trace the 80°F entering air dry bulb tempera-
ture to match the 24,000 cfm and 67°F entering
wet bulb temperature condition. The resulting con-
ditions are, from the table, 996.5 mbh total cooling
capacity and 688.9 mbh sensible cooling capacity.
7. The high heat option for the YPAL085 provides
900 mbh of heat capacity with an input of 1,125
mbh. This is sufficient for the 875 mbh heating
requirement.
8. Determine net cooling and heating capacities if
required.
Net Cooling Capacity (NCC)
mbh = 996.5 mbh – 71.3 mbh
mbh = 925 mbh
Net Sensible Heat Capacity (NSHC)
mbh = 688.9 mbh - 71.3 mbh
mbh = 618 mbh
Net Heating Capacity (NHC)*
mbh = 875 mbh + 71.3 mbh
mbh = 946 mbh
* Note, net heating capacity is approximate because this example
uses the bhp calculated based on a wet evaporator coil (for
cooling mode).

YORK INTERNATIONAL
12
Physical Data
TABLE 1 – PHYSICAL DATA– MODELS 50-70
MODEL SIZE 050 055 060 065 070
GENERALDATA
Length (cm) w/o Hood 874 874 874 874 1140
Width (cm) w/o Hood 234 234 234 234 234
Height (cm) 208 208 208 208 208
Operating Weights (Kg) (Base Unit, No Options)
Cooling Only (Rigging & R407C) 3701 3797 3934 4029 5799
Option Weights (Kg)
Power Exhaust (Blower, Motor, Fan Skid & Mod Damper) 284 284 284 284 341
Power Exhaust (Blower, Motor, Fan Dkid, VFD & Baro Damper) 287 287 287 287 332
100%AMS (Measurement Station & Mounting) 50 50 50 50 57
25/75%AMS (Measurement Station & Mounting) 59 59 59 59 66
Min.AMS (Measurement Station & Mounting) 18 18 18 18 20
Barometric Only 16 16 16 16 20
375 MBH Gas Heat 73 73 73 73 73
750 MBH Gas Heat 147 147 147 147 147
1125 MBH Gas Heat n/a n/a n/a n/a 220
40 kW 195 195 195 195 204
80 kW 222 222 222 222 231
108 kW 204 204 204 204 213
150 kW 213 213 213 213 222
200 kW 222 222 222 222 231
250 kW 231 231 231 231 240
Condenser Wire Guard 15 15 15 15 18
Copper Condenser Coils (additional) 280 280 360 360 280
Copper Evaporator Coils (additional) 119 145 181 227 127
Roof Curb Weights (Kg)
14" Full Perimeter Roof Curb 374 374 374 374 463
14" Open Condenser Roof Curb 252 252 252 252 262
Compressor Data
Quantity/Size (Nominal HP) 4x13 4x13 4x15 4x15 4x10, 2x13
Type Scroll Scroll Scroll Scroll Scroll
Capacity Steps (%) 4x25 4x25 4x25 4x25 4x15, 2x20
Supply Fan and Drive
Quantity 1 1 1 1 1
Type FC FC FC FC FC
Size 25-22 25-22 25-22 25-22 28-25
Motor Size Range (Min. to Max. HP) 7.5-40 7.5-40 7.5-40 7.5-40 7.5-60
Air Flow Range (Min. to Max. m3/hr) 16,988-38,228 16,988-38,228 23785-45875 23785-45875 23785-54,367
Static Pressure Range (Min. to Max. ESP) 0-995 Pa 0-995 Pa 0-995 Pa 0-995 Pa 0-995 Pa
Exhaust Fan
Quantity 2 2 2 2 2
Type FC FC FC FC FC
Size 15-15 15-15 15-15 15-15 18-18
Motor Size Range (Min. to Max. HP) 5-20 5-20 5-20 5-20 10-20
Air Flow Range (Min. to Max. m3/hr) 0-33980 0-33980 0-33980 0-33980 0-33980
Static Pressure Range (Min. to Max. ESP) 0-498 Pa 0-498 Pa 0-498 Pa 0-498 Pa 0-498 Pa

FORM 100.50-EG3 (802)
13
YORK INTERNATIONAL
MODEL SIZE 050 055 060 065 070
Evaporator Coil
Size (Square Meters) 5 5 5 5 5
Number of Rows/Fins per cm 1 1 1 1 1
Tube Diameter (cm) /Surface 5/4 /enhanced 5/4 /enhanced 5/4 /enhanced 5/4 /enhanced 5/4 /enhanced
Condenser Coil (Aluminum Fins)
Size (Square Meters) 11 11 11 11 182
Number of Rows/Fins per cm 1 1 0 0 0
Tube Diameter (cm) 1 1 1 1 1
Condenser Coil (Copper Fins - Opt)
Size (square meters) 11 11 11 11 17
Number of rows/fins per cm 1 1 0 0 0
Tube Diameter 1 1 1 1 1
Condenser Fans
Quantity 4 4 4 4 6
Type Prop. Prop. Prop. Prop. Prop.
Diameter(Meters) 1 1 1 1 1
Power (Hp Each) 2 2 2 2 2
Filters - 5.08cm Throwaway
Quantity 8 / 12 8 / 12 8 / 12 8 / 12 10 / 15
Size (Length x Width) (Meters) .6x.4 / .6x.5 .6x.4 / .6x.5 .6x.4 / .6x.5 .6x.4 / .6x.5 .6x.4 / .6x.5
Total Filter Face Area (Square Meters) 6 6 6 6 7
Filters - 5.08cm Cleanable
Quantity 8 / 12 8 / 12 8 / 12 8 / 12 10 / 15
Size (Length x Width) (Meters) .6x.4 / .6x.5 .6x.4 / .6x.5 .6x.4 / .6x.5 .6x.4 / .6x.5 .6x.4 / .6x.5
Total Filter Face Area (Square Meters) 6 6 6 6 7
Filters - 5.08cm Pleated (30% Efficient)
Quantity 8 / 12 8 / 12 8 / 12 8 / 12 10 / 15
Size (Length x Width) (Meters) .6x.4 / .6x.5 .6x.4 / .6x.5 .6x.4 / .6x.5 .6x.4 / .6x.5 .6x.4 / .6x.5
Total Filter Face Area (Square Meters) 6 6 6 6 7
Filters -30.48cm Rigid 65%, 5.08cm 30% Prefilter
Quantity 1 / 4 / 9 1 / 4 / 9 1 / 4 / 9 1 / 4 / 9 2 / 8 / 9
Size (Length x Width) (Meters) .4x.5 /.6x.4 /.6x.5 .4x.5 /.6x.4 /.6x.5 .4x.5 /.6x.4 /.6x.5 .4x.5 /.6x.4 /.6x.5 .4x.5 /.6x.4 /.6x.5
Total Filter Face Area (Square Meters) 1 1 1 1 1
Filters -30.48cm Rigid 95%, 5.08cm 30% Prefilter
Quantity 1 / 4 / 9 1 / 4 / 9 1 / 4 / 9 1 / 4 / 9 2 / 8 / 9
Size (Length x Width) (Meters) .4x.5 /.6x.4 /.6x.5 .4x.5 /.6x.4 /.6x.5 .4x.5 /.6x.4 /.6x.5 .4x.5 /.6x.4 /.6x.5 .4x.5 /.6x.4 /.6x.5
Total Filter Face Area (Square Meters) 1 1 1 1 1
Filters - 5.08cm Carbon (30% Efficient)
Quantity 1 / 4 / 9 1 / 4 / 9 1 / 4 / 9 1 / 4 / 9 10 / 15
Size (Length x Width) (Meters) .4x.5 /.6x.4 /.6x.5 .4x.5 /.6x.4 /.6x.5 .4x.5 /.6x.4 /.6x.5 .4x.5 /.6x.4 /.6x.5 .6x.4 / .6x.5
Total Filter Face Area (Square Meters) 1 1 1 1 2
Minimum OA Temp. for Mech. Cig. 45 45 45 45 45
TABLE 1 – PHYSICAL DATA – MODELS 50-70 (CONT’D)

YORK INTERNATIONAL
14
Physical Data (continued)
TABLE 1 – PHYSICAL DATA– MODELS 75-95
MODEL SIZE 075 080 085 090 095
GENERALDATA
Length (cm) w/o Hood 1140 1140 1140 1240 1240
Width (cm) w/o Hood 234 234 234 234 234
Height (cm) 208 208 208 234 234
Operating Weights (Kg) (Base Unit, No Options)
Cooling Only (Rigging & R407C) 5897 5994 6092 6496 6594
Option Weights (Kg)
Power Exhaust (Blower, Motor, Fan Skid & Mod Damper) 341 341 341 347 347
Power Exhaust (Blower, Motor, Fan Skid, VFD & Baro Damper) 332 332 332 337 337
100%AMS (Measurement Station & Mounting) 57 57 57 64 64
25/75%AMS (Measurement Station & Mounting) 66 66 66 73 73
Min.AMS (Measurement Station & Mounting) 20 20 20 23 23
Barometric Only 20 20 20 25 25
375 MBH Gas Heat 73 73 73 73 73
750 MBH Gas Heat 147 147 147 147 147
1125 MBH Gas Heat 220 220 220 220 220
40 kW 204 204 204 222 222
80 kW 231 231 231 249 249
108 kW 213 213 213 231 231
150 kW 222 222 222 240 240
200 kW 231 231 231 249 249
250 kW 240 240 240 259 259
Condenser Wire Guard 18 18 18 20 20
Copper Condenser Coils (Additional) 280 480 480 540 540
Copper Evaporator Coils (Additional) 209 127 209 209 263
Roof Curb Weights (Kg)
14" Full Perimeter Roof Curb 463 463 463 472 472
14" Open Condenser Roof Curb 262 262 262 279 279
Compressor Data
Quantity/Size (Nominal Hp) 4x10, 2x13 6x13 6x13 2x13, 4x15 2x13, 4x15
Type Scroll Scroll Scroll Scroll Scroll
Capacity Steps (%) 4x15, 2x20 6x16 6x16 4x18, 2x15 4x18, 2x15
Supply Fan and Drive
Quantity 1 1 1 1 1
Type FC FC FC FC FC
Size 28-25 28-25 28-25 28-28 28-28
Motor Size Range (Min. to Max. Hp) 7.5-60 7.5-60 7.5-60 7.5-60 7.5-60
Air Flow Range (Min. to Max. m3/hr) 23785-54,367 23785-54,367 30582-61164 30582-61164 30582-61164
Static Pressure Range (Min. to Max. ESP) 0-995 Pa 0-995 Pa 0-995 Pa 0-995 Pa 0-995 Pa
Exhaust Fan
Quantity 2 2 2 2 2
Type FC FC FC FC FC
Size 18-18 18-18 18-18 18-18 18-18
Motor Size Range (Min. to Max. HP) 10-20 10-20 10-20 10-20 10-20
Air Flow Range (Min. to Max. m3/hr) 0-33980 0-33980 0-33980 0-33980 0-33980
Static Pressure Range (Min. to Max. ESP) 0-498 Pa 0-498 Pa 0-498 Pa 0-498 Pa 0-498 Pa

FORM 100.50-EG3 (802)
15
YORK INTERNATIONAL
MODEL SIZE 075 080 085 090 095
Evaporator Coil
Size (Square Meters) 5 5 5 5 5
Number of Rows/Fins per cm 1 1 1 1 1
Tube Diameter (cm) /Surface 5/4 /enhanced 5/4 /enhanced 5/4 /enhanced 5/4 /enhanced 5/4 /enhanced
Condenser Coil (Aluminum Fins)
Size (Square Meters) 17 17 17 17 17
Number of Rows/Fins per cm 0 0 0 0 0
Tube Diameter (cm) 1 1 1 1 1
Condenser Coil (Copper Fins - Opt)
Size (Square Meters) 17 17 17 17 17
Number of Rows/Fins per cm 0 0 0 0 0
Tube Diameter 1 1 1 1 1
Condenser Fans
Quantity 6 6 6 6 6
Type Prop. Prop. Prop. Prop. Prop.
Diameter(Meters) 1 1 1 1 1
Power (Hp Each) 2 2 2 2 2
Filters - 5.08cm Throwaway
Quantity 10 / 15 10 / 15 10 / 15 12 / 18 12 / 18
Size (Length x Width) (Meters) 6x.4 / .6x.5 .6x.4 / .6x.5 .6x.4 / .6x.5 .6x.4 / .6x.5 .6x.4 / .6x.5
Total Filter Face Area (Square Meters) 7 7 7 9 9
Filters - 5.08cm Cleanable
Quantity 10 / 15 10 / 15 10 / 15 12 / 18 12 / 18
Size (Length x Width) (Meters) .6x.4 / .6x.5 .6x.4 / .6x.5 .6x.4 / .6x.5 .6x.4 / .6x.5 .6x.4 / .6x.5
Total Filter Face Area (Square Meters) 7 7 7 9 9
Filters - 5.08cm Pleated (30% Efficient)
Quantity 10 / 15 10 / 15 10 / 15 12 / 18 12 / 18
Size (Length x Width) (Meters) .6x.4 / .6x.5 .6x.4 / .6x.5 .6x.4 / .6x.5 .6x.4 / .6x.5 .6x.4 / .6x.5
Total Filter Face Area (Square Meters) 7 7 7 9 9
Filters -30.48cm Rigid 65%, 5.08cm 30% Prefilter
Quantity 2 / 8 / 9 2 / 8 / 9 2 / 8 / 9 8 / 12 8 / 12
Size (Length x Width) (Meters) .4x.5 /.6x.4 /.6x.5 .4x.5 /.6x.4 /.6x.5 .4x.5 /.6x.4 /.6x.5 .6x.4 / .6x.5 .6x.4 / .6x.5
Total Filter Face Area (Square Meters) 1 1 1 2 2
Filters -30.48cm Rigid 95%, 5.08cm 30% Prefilter
Quantity 2 / 8 / 9 2 / 8 / 9 2 / 8 / 9 8 / 12 8 / 12
Size (Length x Width) (Meters) .4x.5 /.6x.4 /.6x.5 .4x.5 /.6x.4 /.6x.5 .4x.5 /.6x.4 /.6x.5 .6x.4 / .6x.5 .6x.4 / .6x.5
Total Filter Face Area (Square Meters) 1 1 1 2 2
Filters - 5.08cm Carbon (30% Efficient)
Quantity 10 / 15 10 / 15 10 / 15 12 / 18 12 / 18
Size (Length x Width) (Meters) .6x.4 / .6x.5 .6x.4 / .6x.5 .6x.4 / .6x.5 .6x.4 / .6x.5 .6x.4 / .6x.5
Total Filter Face Area (Square Meters) 2 2 2 2 2
Minimum OA Temp. for Mech. Cig. 45 45 45 45 45
TABLE 1 – PHYSICAL DATA – MODELS 75-95 (CONT’D)

YORK INTERNATIONAL
16
Cooling Performance Data – 50 Ton Model
TABLE 2 – COOLING PERFORMANCE DATA* – 50 TON MODEL
* Rated performance is at sea level. Cooling capacities are gross cooling capacity.
35°C AIR ON CONDENSER COIL
* Rated performance is at sea level. Cooling capacities are gross cooling capacity.
29.4°C AIR ON CONDENSER COIL
CAPACITY (kW) AT ENTERING DRY BULB (°C)
ENTERING 32 30 28 27 25 23
m3/hr WB (°C) CAP SHC CAP SHC CAP SHC CAP SHC CAP SHC CAP SHC
22 189 141 188 125 187 111 186 99 186 86 – –
22653 19 179 162 175 148 173 134 173 121 171 108 170 96
17 179 179 170 172 164 169 160 156 156 143 157 125
22 190 143 189 126 188 112 187 100 187 86 – –
25485 19 180 165 175 150 173 135 173 122 172 109 171 97
17 180 180 172 174 166 168 161 153 157 140 158 122
22 191 146 190 128 189 113 188 101 187 87 – –
29733 19 181 168 176 152 175 138 174 124 173 110 172 97
17 181 181 173 176 167 164 162 150 158 137 159 119
22 196 156 193 134 193 119 192 104 191 89 – –
31148 19 186 184 181 163 180 147 179 130 178 115 176 100
17 189 189 181 183 175 179 167 158 165 144 164 126
CAPACITY (kW) AT ENTERING DRY BULB (°C)
ENTERING 32 30 28 27 25 23
m3/hr WB (°C) CAP SHC CAP SHC CAP SHC CAP SHC CAP SHC CAP SHC
22 182 138 181 121 180 108 180 96 179 83
22653 19 173 159 170 146 167 131 167 118 165 107 164 93
17 173 173 166 167 159 150 156 140 153 128 153 114
22 183 140 182 123 181 109 180 97 180 84 – –
25485 19 174 162 171 148 168 133 168 119 166 107 165 94
17 175 175 167 169 160 152 157 142 154 130 154 115
22 184 143 183 124 182 110 181 97 180 84 – –
29733 19 175 165 171 150 169 135 169 120 167 107 166 94
17 177 177 169 171 162 155 158 144 155 132 155 117
22 188 153 187 132 186 116 185 101 184 87 – –
31148 19 182 182 175 159 174 144 173 128 171 109 170 97
17 184 184 176 178 169 169 162 153 159 140 159 125

FORM 100.50-EG3 (802)
17
YORK INTERNATIONAL
TABLE 2 – COOLING PERFORMANCE DATA* – 50 TON MODEL (CONT’D)
46.1°C AIR ON CONDENSER COIL
* Rated performance is at sea level. Cooling capacities are gross cooling capacity.
40.5°C AIR ON CONDENSER COIL
* Rated performance is at sea level. Cooling capacities are gross cooling capacity.
CAPACITY (kW) AT ENTERING DRY BULB (°C)
ENTERING 32 30 28 27 25 23
m3/hr WB (°C) CAP SHC CAP SHC CAP SHC CAP SHC CAP SHC CAP SHC
22 175 136 175 119 174 105 173 93 173 80 – –
22653 19 164 154 162 142 160 128 160 114 160 102 159 90
17 168 168 161 163 150 147 150 135 148 126 147 111
22 176 138 176 120 174 106 174 94 173 81 – –
25485 19 165 156 163 144 161 130 161 115 161 103 160 90
17 169 169 162 164 152 149 151 137 149 127 148 113
22 177 140 176 122 175 108 175 95 174 81 – –
29733 19 167 160 164 146 162 132 162 117 162 104 161 91
17 171 171 164 166 154 152 152 140 150 129 149 114
22 181 149 180 129 179 113 178 98 177 83 – –
31148 19 175 177 169 157 167 141 166 125 165 109 164 94
17 179 179 171 173 163 164 155 151 153 137 152 120
CAPACITY (kW) AT ENTERING DRY BULB (°C)
ENTERING 32 30 28 27 25 23
m3/hr WB (°C) CAP SHC CAP SHC CAP SHC CAP SHC CAP SHC CAP SHC
22 168 133 167 115 165 101 164 90 163 78
22653 19 159 153 155 138 154 126 152 112 151 99 151 87
17 161 161 154 156 145 147 142 132 140 123 139 109
22 169 135 168 116 166 102 165 90 164 78 – –
25485 19 160 156 156 140 154 127 153 113 152 100 151 87
17 163 163 155 157 147 149 143 135 140 124 139 110
22 170 137 169 118 167 104 166 91 165 79 – –
29733 19 162 158 157 142 155 129 154 114 153 101 152 88
17 165 165 157 158 149 151 144 138 142 126 140 111
22 174 147 172 125 171 109 170 95 169 80 – –
31148 19 169 172 160 151 160 137 159 121 158 106 156 91
17 172 172 163 165 157 160 150 150 146 134 145 118

YORK INTERNATIONAL
18
TABLE 3 – COOLING PERFORMANCE DATA* – 55 TON MODEL
Cooling Performance Data – 55 Ton Model
* Rated performance is at sea level. Cooling capacities are gross cooling capacity.
35°C AIR ON CONDENSER COIL
* Rated performance is at sea level. Cooling capacities are gross cooling capacity.
29.4°C AIR ON CONDENSER COIL
CAPACITY (kW) AT ENTERING DRY BULB (°C)
ENTERING 32 30 28 27 25 23
m3/hr WB (°C) CAP SHC CAP SHC CAP SHC CAP SHC CAP SHC CAP SHC
22 197 148 197 130 196 116 195 103 194 89 – –
20388 19 185 167 181 153 181 139 182 125 180 113 178 100
17 183 183 175 178 166 171 167 147 166 136 166 123
22 202 159 201 138 201 123 200 107 198 92 – –
27184 19 192 186 186 166 186 150 186 134 185 119 183 104
17 193 193 185 187 177 174 173 159 171 146 171 131
22 209 175 207 150 207 132 206 113 204 96 – –
32706 19 202 211 193 183 193 164 192 145 192 127 190 109
17 206 206 197 199 190 195 180 176 178 159 177 141
22 210 177 208 151 208 133 206 114 205 96 – –
33980 19 204 213 194 185 193 166 193 147 193 128 191 110
17 208 208 199 201 192 197 181 178 179 161 178 143
CAPACITY (kW) AT ENTERING DRY BULB (°C)
ENTERING 32 30 28 27 25 23
m3/hr WB (°C) CAP SHC CAP SHC CAP SHC CAP SHC CAP SHC CAP SHC
22 190 145 190 126 189 113 189 100 187 87 – –
20388 19 178 162 175 150 175 136 175 122 174 113 173 97
17 178 178 171 173 163 167 162 145 161 133 160 119
22 195 156 194 135 193 120 193 107 192 89 – –
27184 19 186 182 180 162 179 147 179 131 178 113 177 101
17 188 188 180 182 172 170 167 156 165 143 165 128
22 201 171 200 148 199 129 198 129 197 92 – –
32706 19 197 205 187 178 186 162 185 143 184 122 183 106
17 200 200 192 194 184 189 173 171 171 157 171 140
22 202 173 201 149 200 130 199 132 198 92 – –
33980 19 198 207 187 180 187 164 186 144 185 123 184 107
17 202 202 193 196 185 190 174 173 172 158 172 142

FORM 100.50-EG3 (802)
19
YORK INTERNATIONAL
TABLE 3 – COOLING PERFORMANCE DATA* – 55 TON MODEL (CONT’D)
46.1°C AIR ON CONDENSER COIL
* Rated performance is at sea level. Cooling capacities are gross cooling capacity.
40.5°C AIR ON CONDENSER COIL
* Rated performance is at sea level. Cooling capacities are gross cooling capacity.
CAPACITY (kW) AT ENTERING DRY BULB (°C)
ENTERING 32 30 28 27 25 23
m3/hr WB (°C) CAP SHC CAP SHC CAP SHC CAP SHC CAP SHC CAP SHC
22 177 139 175 120 174 106 173 94 172 80 – –
20388 19 166 159 164 144 162 130 161 116 161 104 161 91
17 166 166 160 162 152 151 149 137 147 127 146 113
22 182 150 181 130 180 115 180 105 178 84 – –
27184 19 175 174 169 157 168 141 167 125 165 111 165 96
17 177 177 170 172 162 164 156 153 154 137 153 121
22 193 166 193 144 193 127 191 128 190 90 – –
32706 19 191 200 181 176 180 159 179 140 175 121 177 104
17 195 195 186 188 179 184 167 174 165 153 164 135
22 195 168 194 146 194 128 193 131 192 91 – –
33980 19 194 202 183 179 181 161 181 142 177 123 178 105
17 197 197 188 190 182 187 169 176 167 156 166 137
CAPACITY (kW) AT ENTERING DRY BULB (°C)
ENTERING 32 30 28 27 25 23
m3/hr WB (°C) CAP SHC CAP SHC CAP SHC CAP SHC CAP SHC CAP SHC
22 177 139 175 119 174 106 173 94 172 80 – –
20388 19 166 158 164 144 161 130 161 115 161 104 160 91
17 166 166 160 162 152 151 149 137 147 126 146 113
22 181 150 179 129 178 113 177 98 176 83 – –
27184 19 173 173 166 154 165 140 165 124 164 110 164 95
17 175 175 166 168 160 162 155 152 152 136 151 121
22 185 165 185 141 183 122 184 105 181 87 – –
32706 19 184 192 170 169 171 154 171 136 169 118 168 100
17 187 187 175 176 172 177 164 172 158 150 157 131
22 186 167 185 143 184 123 185 106 182 87 – –
33980 19 185 193 171 171 172 156 172 137 170 119 169 101
17 189 189 176 178 173 178 165 173 159 151 158 133

YORK INTERNATIONAL
20
TABLE 4 – COOLING PERFORMANCE DATA* – 60 TON MODEL
Cooling Performance Data – 60 Ton Model
29.4°C AIR ON CONDENSER COIL
* Rated performance is at sea level. Cooling capacities are gross cooling capacity.
35°C AIR ON CONDENSER COIL
* Rated performance is at sea level. Cooling capacities are gross cooling capacity.
CAPACITY (kW) AT ENTERING DRY BULB (°C)
ENTERING 32 30 28 27 25 23
m3/hr WB (°C) CAP SHC CAP SHC CAP SHC CAP SHC CAP SHC CAP SHC
22 224 170 223 150 222 119 221 117 219 101 – –
23786 19 213 199 205 177 205 147 204 144 204 129 202 113
17 209 209 200 203 196 169 189 175 186 160 187 139
22 232 192 229 165 229 138 228 125 226 106 – –
30582 19 224 225 213 199 213 173 212 160 212 141 210 121
17 225 225 215 218 208 202 198 192 196 180 195 170
22 238 208 234 176 233 156 232 131 231 110 – –
35679 19 232 242 219 215 219 195 218 171 217 149 215 126
17 237 237 226 228 217 224 204 205 203 199 201 195
22 239 213 235 178 234 161 233 133 232 111 – –
38228 19 234 244 221 219 220 201 219 174 219 151 216 127
17 239 239 229 231 220 226 206 208 205 204 203 202
CAPACITY (kW) AT ENTERING DRY BULB (°C)
ENTERING 32 30 28 27 25 23
m3/hr WB (°C) CAP SHC CAP SHC CAP SHC CAP SHC CAP SHC CAP SHC
22 216 167 214 146 213 126 213 113 211 98 – –
23786 19 208 186 199 160 198 154 197 141 196 127 195 110
17 204 204 195 197 188 179 184 168 182 153 183 135
22 223 188 221 162 220 139 219 122 218 103 – –
30582 19 218 216 210 182 206 173 205 156 203 133 202 117
17 219 219 209 211 201 199 192 187 187 179 184 169
22 229 204 226 174 225 151 223 129 222 107 – –
35679 19 225 235 218 210 212 191 210 167 208 142 207 123
17 229 229 219 222 210 216 198 201 191 198 185 192
22 230 208 227 177 226 155 225 130 223 108 – –
38228 19 227 236 221 217 213 196 211 170 209 144 208 124
17 232 232 222 224 213 219 199 205 192 202 186 195
