TECHNICAL GUIDE
SPLIT-SYSTEM
AIR-COOLED
CONDENSING UNITS
MODELS: HA090
208/230/460
VOLT ONLY
208/230/575
VOLT ONLY
036-21338-001-C-0703
FOR DISTRIBUTION USE ONLY - NOT TO BE USED AT POINT OF RETAIL SALE
®
DESCRIPTION
These Sunline 2000 units are completely assembled, piped and wired
at the factory to provide one-piece shipment and rigging. Each unit is
pressurized with a holding charge of refrigerant-22 for storage and/or
shipping.
The compact design, clean styling, low silhouette, and quiet operation
make these condensing units suitable for almost any outdoor location.
On rooftops…because they weigh much less than a single package
unit of similar capacity and are much easier to rig and support. At
ground level…because their ample sub-cooling capacity allows them
to be located 60 feet below the evaporator coil.
All sheet metal parts are constructed of commercial grade (G90) gal-
vanized steel. After fabrication, each part is thoroughly cleaned to
remove any grease or dirt from its surfaces. The external parts are
coated with a powder paint to assure a quality finish for many years.
This UL approved coating system has passed the 750 hour, 20% salt
spray test per ASTM Standard B117.
All models include a 1-year limited warranty on the complete unit. The
compressor carries an additional 4-year warranty.
A complete line of Evaporator Blower units is also offered to meet your
precise capacity and air handling requirements. Refer to Form 036-
21300-001 for more information on this air side equipment.
FEATURES
• Condenser coil constructed of copper tubes and aluminum fins for
durability and long lasting efficient operation.
• Permanently attached base rails with fork-lift slots and lifting
holes. This design allows for 3-way fork-lift access and overhead
rigging.
• Both high and low pressure controls. Since these controls are
self-contained, there are no capillary lines to be damaged.
• Compressor line-break motor protection and crankcase heaters.
• Anti-short cycle timer to protect the compressor.
• A lockout circuit to prevent the unit from cycling on safety control.
• A 24-volt temperature control circuit.
• Low ambient operation to 45°Faccessories for 0°F low ambient
operation are available.
• A filter-drier (shipped in the unit's compressor compartment for
field installation near the evaporator coil).
• Service valves with a back-seating access port for pressure test-
ing the system. Copper stub-outs are factory mounted on the suc-
tion and liquid service valves to simplify the field piping
connections.
• Separate panel for easy access to the control box without affect-
ing air flow across the condenser coil.
• Gauge lines extend out from cabinet to facilitate servicing.
• Packaging suitable for outdoor storage
• Optional coil guard accessory protect coils with a decorative grille.
http://www.rezine.ne
t
Page 3

036-21338-001-C-0703
2Unitary Products Group
TABLE OF CONTENTS
DESCRIPTION . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1
FEATURES . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1
SEQUENCE OF OPERATION . . . . . . . . . . . . . . . . . 7
GUIDE SPECIFICATIONS . . . . . . . . . . . . . . . . . . . 11
LIST OF FIGURES
Fig. # Pg. #
1 TYPICAL FIELD WIRING WITH AIR HANDLER . . . . . 8
2 POINT LOADS . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8
3 TYPICAL FIELD WIRING WITH 7-1/2 TON
FURNACE . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 9
4 CENTER OF GRAVITY . . . . . . . . . . . . . . . . . . . . . . . 10
5 HA090 DIMENSIONS . . . . . . . . . . . . . . . . . . . . . . . . . 10
LIST OF TABLES
Tbl. # Pg. #
1 ARI RATINGS . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3
2 APPLICATION DATA . . . . . . . . . . . . . . . . . . . . . . . . . . 3
3 PHYSICAL DATA . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3
4 ELECTRICAL DATA . . . . . . . . . . . . . . . . . . . . . . . . . . . 4
5 UNIT COOLING CAPACITIES AND POWER
REQUIREMENTS . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4
6 SYSTEM COOLING CAPACITIES AND POWER
REQUIREMENTS (HA090/LA090) . . . . . . . . . . . . . . . . 5
7 HA090 CHARGING CURVE . . . . . . . . . . . . . . . . . . . . 6
8 CLEARANCES . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 9
9 UNIT DIMENSIONS & CLEARANCES HA090 . . . . . . 9
http://www.rezine.ne
t
Page 4

036-21338-001-C-0703
Unitary Products Group 3
TABLE 1: ARI RATINGS*
CONDENSING
UNIT MODEL
INDOOR BLOWER UNIT
MODEL
SYSTEM
MBH SYSTEM EER
CONDENSING UNIT
SOUND
LEVEL(BELS)
HA090 LA090 90 10.7 8.9
*. Certified in accordance with Unitary Large Equipment certification program, which is based on ARI Standard
340/360
TABLE 2: APPLICATION DATA
LIMITATION MIN. MAX.
Voltage Variation *
208/230-3-60 187V 252V
460-3-60 432V 504V
575-3-60 540V 630V
Ambient Air on Condenser Coil 45°F†125°F
*. Rated in accordance with ARI Standard 110, utilization range “A”.
†. Low Ambient accessories are available to permit stable system operation at ambient
temperatures down to 0°F.
Note: Refer to Form 035-15407-001 for refrigerant piping limitations
TABLE 3: PHYSICAL DATA
Model
HA
Compressor
Condenser Unit
Weight
(Lbs.)
Charge,
Lbs,-Oz.
(Refrigerant-22)
Fan (Propeller) Fan Motor*Coils†
Rating
(Tons)
Cap.
(Stages) Qty. Dia.
(in.)
Norm
CFM
Blades
Qty. RPM HP Rotation‡Face
Area‡
Finned
Length
(in.)
Rows
High Ship. Oper. Holding Oper.**
Qty Pitch
(Deg.)
090 7-1/2 1 2 24 7800 3 26 2 1110 3/4 CW 23.8 96 36 388 383 1-12 14.95
*. These PSC motors are directly connected to the condenser fans and have inherent protection, ball bearings and a 48” frame.
†. These condenser coils have 2 rows of 3/8” OD copper tubes and 16 aluminum fins per inch.
‡. When viewing the shaft end of the motor.
**. Includes matched indoor blower unit but no piping.
http://www.rezine.ne
