York TCHD18 THRU 60 Quick start guide

TECHNICAL GUIDE
HORIZONTAL DISCHARGE
AIR CONDITIONERS
13 SEER – R-410A
MODELS:
TCHD18 THRU 60
(1.5 THRU 5 NOMINAL TONS, 1 PHASE)
Due to continuous product improvement, specifications
are subject to change without notice.
Visit us on the web at www.york.com
Additional rating information can be found at
www.ahridirectory.org
WARRANTY
Standard 5-year limited parts warranty.
Standard 10-year limited compressor warranty.
Extended 10-year limited parts warranty when product is
registered online within 90 days of purchase for replace-
ment or closing for new home construction.
®
556454-YTG-B-0410
FOR DISTRIBUTION USE ONLY - NOT TO BE USED AT POINT OF RETAIL SALE
DESCRIPTION
The 13 SEER Series condensing unit is the outdoor part of a
versatile system of air conditioning. It is designed to be custom-
matched with one of UPG’s complete line of evaporator sec-
tions, with each serving a specific function. Matching Air Han-
dlers are available for upflow, downflow, or horizontal
applications to provide a complete system. Electric Heaters are
available, if required. Add-On coils are available for use with
upflow, downflow, or horizontal furnaces and air handlers.
FEATURES
•Performance -Efficiency levels from 13.0 SEER/11.5 EER
with a loose coil and up to 15.5 SEER/13.5 EER when cou-
pled with a variable speed indoor blower.
•Easy to Install -Compact “slim-line” design allows for easy
installation in tight spaces. Units can be stacked.
•Lower Installation Cost -Installation time and costs are
reduced by easy power and control wiring connections. The
unit contains enough refrigerant for matching indoor coils
and 15 feet of interconnecting piping.
•Quiet Operation -Levels as low as 67 dBA. High efficiency
scroll compressor and swept wing fan design reducing oper-
ating sound to a mere whisper.
•State Of The Art Coil Technology -Micro-channel (MC2)
aluminum coil technology provides enhanced capacities and
efficiencies plus the benefit of maximum corrosion protection
especially in coastal applications (up to 7 times greater cor-
rosion resistance than conventional copper tube and alumi-
num fin coils).
•Compressor Protection -The compressor is internally pro-
tected against high pressure and temperature. This is
accomplished by the simultaneous operation of high pres-
sure relief valve and a temperature sensor which protects the
compressor if undesirable operating conditions occur. A liq-
uid line filter-drier further protects the compressor.
•Durable Cabinet -Heavy-gage steel cabinet and a tubular
base rail provide added support.
•Durable Finish -Automotive quality finish provides the ulti-
mate protection from harmful U.V. rays and rust creep ensur-
ing long-lasting high quality appearance. A powder-paint
topcoat is applied over a baked-on primer, using a galva-
nized, zinc coated steel base material. The result is a finish
that has been proven in testing to provide 33% greater dura-
bility than conventional powder-coat finishes.
•Aesthetic -Powder paint “Champagne” Color provides an
attractive retail finish.
•Low Maintenance -Long life permanently lubricated motor-
bearings need no annual servicing.
•Easy Service Access -Fully exposed refrigerant connec-
tions and a single panel covering the electrical controls make
for easy servicing of the unit.
•Secured Service Valve -Secured re-usable service valves
are provided on both the liquid and vapor sweat connections
for ease of evacuating and charging.
•Other Features:
- Factory supplied filter drier
- High pressure switch, low pressure switch
- Accumulator and crankcase heater in all sizes
- Up to 200’ line set out of the box
- Zero lot line clearances (6” clearance in either direction)
•Agency Listed -U.L. and C.U.L. listed - approved for out-
door application. The unit is certified in accordance with the
Unitary Small Equipment certification program, which is
based on ARI Standard 210/240.

556454-YTG-B-0410
2Johnson Controls Unitary Products
All dimensions are in inches. They are subject to change without notice.
Certified dimensions will be provided upon request.
.
Physical and Electrical Data
MODEL TCHD18
S41S3 TCHD24 S41S3 TCHD30 S41S3 TCHD36 S41S3 TCHD48 S41S3 TCHD60 S41S3
Unit Supply Voltage 208-230V, 1 60Hz
Normal Voltage Range 1187 to 252
Minimum Circuit Ampacity 11.8 17.4 17.5 23.1 27.1 34.3
Max. Overcurrent Device Amps 220 30 30 40 45 60
Min. Overcurrent Device Amps 315 20 20 25 30 35
Multi-Stage Compressor No No No No No No
Compressor Type Scroll Scroll Scroll Scroll Scroll Scroll
Compressor Amps Rated Load 9.0 13.5 12.8 17.3 20.5 26.3
Locked Rotor 48.0 58.3 64.0 96.7 115.0 134.0
Crankcase Heater Yes Yes Yes Yes Yes Yes
Fan Diameter Inches 17.5 17.5 23 23 23 23
Fan Motor Rated HP 1/8 1/8 1/4 1/4 1/4 1/4 Rated Load Amps 0.60 0.60 1.45 1.45 1.45 1.45
Nominal RPM 840 840 850 850 850 850
Coil Face Area Sq. Ft. 5.76 5.76 11.96 11.96 13.96 13.96 Rows Deep 1 1 1 1 1 1
Fins / Inches 23 23 23 23 23 23
Refrigerant Lines4
Max. Length 200 200 200 200 200 200
Max. Lift 65 65 65 65 65 65
Max. Drop 150 150 150 150 150 150
Liquid Line Set OD (Field Installed) 3 / 8 3 / 8 3 / 8 3 / 8 3 / 8 3 / 8
Vapor Line Set OD (Field Installed) 3 / 4 3 / 4 3 / 4 3 / 4 7 / 8 7 / 8
Unit Charge (Lbs. - Oz.) 52 - 14 3 - 5 4 - 0 4 - 8 5 - 5 5 - 6
Charge Per Foot, Oz. 0.68 0.68 0.68 0.68 0.70 0.70
Operating Weight Lbs. 130 135 195 215 240 250
1. Rated in accordance with ARI Standard 110, utilization range “A”.
2. Dual element fuses or HACR circuit breaker. Maximum allowable overcurrent protection.
3. Dual element fuses or HACR circuit breaker. Minimum recommended overcurrent protection.
4. When more than 50 feet of interconnecting tubing and more than 30 feet of vertical lift is used, consult the Application Data (part number
247077). For long-line applications, interconnecting lines over 100 feet must be installed with liquid line solenoid.
5. The Unit Charge is correct for the outdoor unit, matched indoor coil and 15 feet of refrigerant tubing. For tubing lengths other than 15 feet, add
or subtract the amount of refrigerant, using the difference in length multiplied by the per foot value.
B
C
A
Unit
Model
Dimensions
(Inches) Refrigerant Connection Service Valve Size
A1
1. Including Fan Guard.
B C Liquid Vapor
18 25-1/8 14-5/8 37
3/8” 3/4”
24 25-1/8 14-5/8 37
30 37-1/8 17-1/8 44-5/8
36 37-1/8 17-1/8 44-5/8
48 43-1/8 17-1/8 44-5/8 7/8”
60 43-1/8 17-1/8 44-5/8

556454-YTG-B-0410
Johnson Controls Unitary Products 3
System Charge for Various Matched Systems
Outdoor Unit TCHD18S41S3 TCHD24S41S3 TCHD30S41S3 TCHD36S41S3 TCHD48S41S3 TCHD60S41S3
Required Orifice or TXV 11TVM4F1 1TVM4F1 1TVM4G1 1TVM4G1 1TVM4J1 1TVM4K1
Factory Charge, lbs-oz 2 - 14 3 - 5 4 - 0 4 - 8 5 - 5 5 - 6
Indoor Coil 2,3 Additional Charge, oz
AHP24 –2––––
AHP36 – – 16 12 – –
AHP/SHP60 – – – – 11 –
AHX18 0 0 – – – –
AHX24 10 10 – – – –
AHX30 13 14 10 – – –
AHX36 – 20 16 12 – –
AHX42 – – 27 22 – –
AHX48 – – 26 22 11 –
AHX60 – – – 27 16 13
AV24 22––––
AV36 20 20 16 12 – –
AV/SV48 – – – 22 11 –
AV/SV60 ––––118
F*FP030 – 2 0 – – –
F*FP036 – – 8 4 – –
F*FP040 – – 10 7 – –
F*FP042 – – – 7 – –
F*FP048 – – – 16 11 –
F*FP060 – – – – 16 –
F*FV060 – – – 8 11 8
F6FP018 0–––––
F6FP024 33––––
F6FP030 14 15 10 – – –
F6FP036 –15107 – –
F6FP042 – – 20 16 – –
F6FP048 – – 10 7 11 –
F6FP060 – – – 271613
FC/MC/PC18 0–––––
FC/MC/PC24 00––––
FC/MC/PC30 442–––
FC/MC/PC32 13 14 10 6 – –
FC/MC/PC35 13 14 0 6 – –
FC/MC/PC36 6630––
FC/MC/PC37 20 21 16 12 – –
FC/MC/PC42 –931––
FC/MC/PC43 –20160 – –
FC/MC/PC48 – 322722 0 –
FC/MC/PC60 ––––10–
FC/MC62 ––––160
HC18 00––––
HC30 10 10 7 – – –
HC36 13 14 10 6 – –
HC42 – 211612 – –
HC60 –––70–
HD24 22 17 – – – –
HD36 28 20 14 11 – –
HD48 – – –3324–
HD60 ––––3022
For notes see Page 4.

556454-YTG-B-0410
4Johnson Controls Unitary Products
PROCEDURES:
1. Unit factory charge listed on the unit nameplate includes refrigerant for the condenser, the smallest evaporator and 15 feet of interconnecting
line tubing.
2. Verify the TXV and additional charge required for specific evaporator coil in the system using the above table.
3. Additional charge for the amount of interconnecting line tubing greater than 15 feet at the rate specified in Physical and Electrical Data Table.
4. For TXV matches requiring additional charge, the refrigerant needs to be weighed in for specific coil match and lineset length.
5. Permanently mark the unit nameplate with the total system charge. Total System Charge = Base Charge (as shipped) + adder for evaporator +
adder for line set.
UC18 1 – – – – –
UC24 5 5 – – – –
UC30 5 5 3 – – –
UC36 7 7 4 1 – –
UC42 – 9 3 0 – –
UC48 – 252117 6 –
UC60 ––––11–
FOOTNOTES:
1. For applications requiring a TXV use 1TVM series kit.
2. Systems matched with furnace or air handlers not equipped with blower-off delays may require blower Time Delay Kit 2FD06700224.
3. PC coils cannot be used in downflow or horizontal applications. FC coils cannot be used in horizontal applications.
System Charge for Various Matched Systems (Continued)
Outdoor Unit TCHD18S41S3 TCHD24S41S3 TCHD30S41S3 TCHD36S41S3 TCHD48S41S3 TCHD60S41S3
Required Orifice or TXV 11TVM4F1 1TVM4F1 1TVM4G1 1TVM4G1 1TVM4J1 1TVM4K1
Factory Charge, lbs-oz 2 - 14 3 - 5 4 - 0 4 - 8 5 - 5 5 - 6
Indoor Coil 2,3 Additional Charge, oz

556454-YTG-B-0410
Johnson Controls Unitary Products 5
COOLING CAPACITY - With Air Handler Coils
UNIT
MODEL
AIR HANDLER COIL
MODEL1
COOLING
MODEL W RATED
CFM NET MBH SEER EER
TOTAL SENS.
13 SEER AC WITH MV - VARIABLE SPEED
TCHD18S41S3 MV12B 17 FC/MC18B 600 18.0 12.3 14.05 11.85 MV12B 17 FC/MC24B 600 18.4 12.9 14.50 12.15
MV12B 17 FC/MC30B 600 18.4 12.9 14.50 12.15
TCHD24S41S3
MV12B 17 FC/MC24B 800 23.6 17.2 14.65 12.25
MV12B 17 FC/MC30B 800 23.6 17.2 14.65 12.25
MV12B 17 FC/MC35B 800 23.6 17.3 14.85 12.20
MV16C 21 FC/MC35C 800 23.6 17.3 14.85 12.20
MV12B 17 FC/MC36B 800 23.6 17.4 14.85 12.20
MV16C 21 FC/MC36C 800 23.6 17.4 14.85 12.20
MV12B 17 FC/MC43B 800 24.2 17.7 15.00 12.45
MV16C 21 FC/MC43C 800 24.2 17.7 15.05 12.55
TCHD30S41S3
MV12B 17 FC/MC30B 1000 28.2 20.8 14.60 13.00
MV12B 17 FC/MC35B 1000 28.6 21.2 15.00 13.20
MV16C 21 FC/MC35C 1000 28.6 21.2 15.00 13.25
MV12B 17 FC/MC36B 1000 28.6 21.0 15.00 13.15
MV16C 21 FC/MC36C 1000 28.6 21.0 15.00 13.25
MV12B 17 FC/MC43B 1000 29.0 21.6 15.15 13.35
MV16C 21 FC/MC43C 1000 29.0 21.6 15.35 13.50
MV16C 21 FC/MC48C 1000 29.4 21.8 15.50 13.70
TCHD36S41S3
MV12B 17 FC/MC35B 1200 33.6 24.6 14.10 12.20
MV16C 21 FC/MC35C 1200 33.8 24.8 14.55 12.55
MV12B 17 FC/MC36B 1200 33.6 24.2 14.00 12.15
MV16C 21 FC/MC36C 1200 33.8 24.4 14.30 12.50
MV12B 17 FC/MC43B 1200 34.4 25.2 14.50 12.50
MV16C 21 FC/MC43C 1200 34.6 25.4 15.00 13.00
MV16C 21 FC/MC48C 1200 35.0 25.6 15.25 13.10
MV12D 24 FC/MC48D 1150 34.6 25.2 15.00 13.00
TCHD48S41S3
MV16C 21 FC/MC48C 1600 47.5 34.2 14.00 12.10
MV20D 24 FC/MC48D 1600 47.5 34.2 14.00 12.00
MV20D 24 FC/MC60D 1600 45.5 33.0 13.50 11.60
MV20D 24 FC/MC62D 1600 48.0 34.6 14.50 12.25
TCHD60S41S3 MV20D 24 FC/MC62D 1800 57.5 39.5 13.40 11.30
13 SEER AC WITH AV / SV - / F*FV VARIABLE SPEED
TCHD18S41S3 AV*24 17 – 610 18.1 13.1 14.25 11.50
AV*36 21 – 630 19.0 13.8 15.00 12.00
TCHD24S41S3 AV*24 17 – 800 23.2 17.1 14.25 11.75
AV*36 21 – 725 23.8 17.1 14.50 12.25
TCHD30S41S3 AV*36 21 – 960 28.8 21.3 15.50 13.25
TCHD36S41S3 AV*36 21 – 1190 34.4 25.3 14.50 12.25 AV/SV*48 24 – 1220 34.8 25.7 15.00 12.75
F*FV060 24 – 1200 33.2 23.8 14.55 12.45
TCHD48S41S3 AV/SV*48 24 – 1625 46.5 33.8 13.75 11.75 AV/SV*60 24 – 1560 47.0 34.0 13.75 11.75
F*FV060 24 – 1600 45.5 33.2 13.55 11.60
TCHD60S41S3 AV/SV*60 24 – 1730 56.0 37.7 13.25 11.00
F*FV060 24 – 1800 55.0 38.0 13.00 11.00
For notes see Page 6.

556454-YTG-B-0410
6Johnson Controls Unitary Products
— = Not applicable.
13 SEER AC WITH AHP / SHP / AHX / F*FP
TCHD18S41S3
AHX18 17 – 630 18.2 13.1 14.25 11.75
AHX24 17 – 590 18.3 13.0 14.25 11.75
AHX30 17 – 610 18.6 13.3 14.50 12.00
F6FP018 17 – 600 17.9 12.6 13.50 11.25
F6FP024 17 – 600 18.5 13.1 14.00 11.50
F6FP030 17 – 620 18.5 13.2 14.00 11.50
TCHD24S41S3
AHP24 17 – 850 23.0 16.8 13.15 11.05
AHX18 17 – 835 23.2 17.2 14.00 11.50
AHX24 17 – 800 23.6 17.3 14.00 12.75
AHX30 17 – 820 23.8 17.8 14.50 12.75
AHX36 21 – 815 24.2 18.1 15.00 12.25
F*FP030 17 – 800 23.0 16.7 13.10 11.00
F6FP024 17 – 840 23.4 17.4 14.00 11.50
F6FP030 17 – 850 23.4 17.4 13.75 11.25
F6FP036 21 – 855 23.8 17.9 14.25 11.75
TCHD30S41S3
AHP36 21 – 1000 28.4 21.2 13.75 12.20
AHX30 17 – 1025 28.4 21.3 14.50 12.50
AHX36 21 – 1005 29.0 21.7 15.25 13.25
AHX42 21 – 990 29.4 22.1 15.50 13.75
AHX48 24 – 1090 29.8 23.0 15.50 13.75
F*FP030 17 – 1000 27.6 20.0 13.20 11.85
F*FP036 21 – 1000 27.8 20.6 13.40 12.00
F*FP040 21 – 1000 27.8 20.4 13.40 12.00
F6FP030 17 – 1035 28.2 20.9 13.75 12.00
F6FP036 21 – 980 28.2 20.7 14.50 12.75
F6FP042 21 – 1065 29.6 22.4 15.25 13.50
F6FP048 24 – 1055 28.0 21.0 14.50 12.50
TCHD36S41S3
AHP36 21 – 1200 34.2 25.0 14.00 12.15
AHX36 21 – 1225 34.4 25.7 14.75 12.50
AHX42 21 – 1190 35.0 25.9 15.25 12.75
AHX48 24 – 1255 35.2 26.3 15.25 12.75
AHX60 24 – 1300 35.6 26.8 15.00 12.75
F*FP036 21 – 1200 33.0 23.8 13.00 11.35
F*FP040 21 – 1200 33.0 24.0 13.00 11.40
F*FP042 21 – 1200 33.0 24.0 13.00 11.40
F5FP048 24 – 1250 35.0 25.8 15.20 13.00
F6FP036 21 – 1210 33.4 24.3 13.75 11.75
F6FP042 21 – 1290 35.2 26.4 14.75 12.50
F6FP048 24 – 1125 32.2 23.3 14.00 11.75
F6FP060 24 – 1240 35.2 26.3 15.00 12.75
TCHD48S41S3
AHP/SHP60 24 – 1600 45.5 33.2 13.40 11.50
AHX48 24 – 1660 47.0 34.6 13.75 11.75
AHX60 24 – 1680 47.5 34.8 13.50 11.75
F5FP048 24 – 1700 47.5 35.0 13.75 12.00
F5FP060 24 – 1700 46.0 33.4 13.35 11.55
F6FP048 24 – 1625 45.0 33.2 13.00 11.00
F6FP060 24 – 1710 48.0 35.0 13.50 11.50
TCHD60S41S3 AHX60 24 – 1905 57.5 40.2 13.00 11.00
F6FP060 24 – 1710 56.5 38.7 13.00 11.00
Rated in accordance with DOE test procedures (Federal Register 12-27-79 and 3-18-88) and ARI Standards 210.
Cooling MBH based on 8°F entering air temperature, 50% RH, and rated air flow.
EER (Energy Efficiency Ratio) is the total cooling output in BTU’s at 95°F outdoor ambient divided by the total electric power in watt-hours at those conditions.
SEER (Seasonal Energy Efficiency Ratio) is the total cooling output in BTU’s during a normal annual usage period for cooling divided by the total electric power
input in watt-hours during the same period.
1. MC coils available with a factory installed horizontal drain pan. See price pages for specific model number.
COOLING CAPACITY - With Air Handler Coils (Continued)
UNIT
MODEL
AIR HANDLER COIL
MODEL1
COOLING
MODEL W RATED
CFM NET MBH SEER EER
TOTAL SENS.

556454-YTG-B-0410
Johnson Controls Unitary Products 7
COOLING CAPACITY - Upflow, Downflow & Horizontal Furnaces and Coils
UNIT MODEL
FURNACE** COIL
MODEL
COOLING
CFM RANGE
(Min.-max.) WRATED CFM NET MBH SEER1EER
TOTAL SENS.
TCHD18S41S3
450 - 750 14,17 FC/MC/PC24 600 18.0 12.6 13.00 11.00
450 - 750 14,17 FC/MC/PC30 600 18.0 12.6 13.00 11.00
450 - 750 14 FC/MC/PC32 600 18.1 12.6 13.00 11.05
450 - 750 17 FC/MC/PC35 600 18.1 12.6 13.00 11.05
450 - 750 14,17 FC/MC/PC36 600 18.2 12.6 13.00 11.15
450 - 750 14 FC/MC/PC37 600 18.4 12.7 13.10 11.25
450 - 750 17 HC36 600 18.1 12.6 13.00 11.05
450 - 750 14,17 HD24 600 18.7 12.9 13.25 11.35
450 - 750 14,17 UC24 600 18.1 12.6 13.00 11.10
450 - 750 14,17 UC30 600 18.1 12.6 13.00 11.10
TCHD24S41S3
600 - 1000 14,17 FC/MC/PC24 800 23.0 16.8 13.00 11.00
600 - 1000 14,17 FC/MC/PC30 800 23.0 16.8 13.00 11.00
600 - 1000 14 FC/MC/PC32 800 23.0 16.9 13.15 11.00
600 - 1000 17,21 FC/MC/PC35 800 23.0 16.9 13.15 11.00
600 - 1000 14,17,21 FC/MC/PC36 800 23.0 16.9 13.15 11.00
600 - 1000 14 FC/MC/PC37 800 23.6 17.3 13.30 11.20
600 - 1000 17,21 FC/MC/PC43 800 23.6 17.3 13.30 11.20
600 - 1000 14 HC30 800 22.8 16.6 13.00 11.00
600 - 1000 17 HC36 800 23.0 16.9 13.15 11.00
600 - 1000 21 HC42 800 23.6 17.3 13.30 11.20
600 - 1000 14,17 UC24 800 23.0 16.9 13.05 11.00
600 - 1000 14,17 UC30 800 23.0 16.9 13.05 11.00
TCHD30S41S3
800 - 1200 14,17 FC/MC/PC30 1000 27.6 20.4 13.25 11.85
800 - 1200 14,17 FC/MC/PC32 1000 28.0 20.8 13.50 12.00
800 - 1200 17,21 FC/MC/PC35 1000 28.0 20.8 13.50 12.00
800 - 1200 14,17,21 FC/MC/PC36 1000 28.0 20.6 13.45 12.00
800 - 1200 14 FC/MC/PC37 1000 28.4 21.2 13.75 12.20
800 - 1200 17,21 FC/MC/PC43 1000 28.4 21.2 13.70 12.20
800 - 1200 14,17 HC30 1000 27.6 20.4 13.35 11.80
800 - 1200 17 HC36 1000 28.0 20.8 13.50 12.00
800 - 1200 21 HC42 1000 28.4 21.2 13.75 12.20
800 - 1200 14,17,21 HD36 1000 27.6 20.0 13.30 11.85
800 - 1200 14,17 UC30 1000 27.8 20.4 13.40 12.00
800 - 1200 21,24 UC48 1000 26.8 20.0 13.00 11.50
TCHD36S41S3
1000 - 1400 14 FC/MC/PC32 1200 33.2 24.2 13.20 11.50
1000 - 1400 17,21 FC/MC/PC35 1200 33.2 24.2 13.20 11.50
1000 - 1400 14,17,21 FC/MC/PC36 1200 33.0 24.0 13.00 11.40
1000 - 1400 14 FC/MC/PC37 1200 33.8 24.8 13.50 11.70
1000 - 1400 17,21 FC/MC/PC43 1200 34.0 24.8 13.50 11.75
1000 - 1400 21,24 FC/MC/PC48 1200 34.4 25.2 13.65 12.00
1000 - 1400 17 HC36 1200 33.2 24.2 13.20 11.50
1000 - 1400 21 HC42 1200 33.8 25.0 13.50 11.70
1000 - 1400 14,17,21 HD36 1200 32.4 23.2 13.00 11.20
1000 - 1400 14,17,21,24 HD48 1200 34.2 24.8 13.65 11.85
TCHD48S41S3 1400 - 1800 21,24 FC/MC/PC48 1600 47.0 33.8 13.25 11.50 1400 - 1800 21,24 FC/MC62 1600 47.5 34.2 13.35 11.60
1400 - 1800 14,17,21,24 HD48 1600 47.0 33.4 13.20 11.50
TCHD60S41S3 1600 - 2000 21,24 FC/MC62 1800 57.0 39.5 13.00 11.00
1. Requires a 2FD06700224 Blower Time Delay unless a standard furnace is equipped with one.
** Refer to Quick Selection Chart for specific furnace match-up.

556454-YTG-B-0410
8Johnson Controls Unitary Products
COOLING CAPACITY - With High Efficiency Motor Furnaces
UNIT
MODEL FURNACE MODEL COIL MODEL1WCOOLING
RATED
CFM Net MBH SEER EER
TOTAL SENS.
13 SEER AC WITH VARIABLE SPEED FURNACES2
TCHD18S41S3
T*(8,L)X*A12 FC/MC/PC18A 14 540 17.7 12.4 14.00 11.50
T*(8,L)X*B12 FC/MC/PC18B 17 580 17.9 12.6 14.25 11.75
T*9X*B12 FC/MC/PC18B 17 590 17.9 12.8 14.25 11.75
T*(8,L)X*A12 FC/MC/PC24A 14 595 18.5 13.2 14.70 12.00
T*(8,L)X*B12 FC/MC/PC24B 17 620 18.4 13.1 14.75 12.00
T*9X*B12 FC/MC/PC24B 17 615 18.5 13.2 14.75 12.00
T*(8,L)X*A12 FC/MC/PC30A 14 595 18.5 13.2 14.70 12.00
T*(8,L)X*B12 FC/MC/PC30B 17 620 18.4 13.1 14.75 12.00
T*9X*B12 FC/MC/PC30B 17 615 18.5 13.2 14.75 12.00
T*(8,L)X*A12 FC/MC/PC32A 14 590 18.4 13.1 14.55 12.00
T*(8,L)X*A12 HD24 14 605 19.0 13.9 13.75 12.25
T*(8,L)X*B12 HD24 17 655 18.6 14.3 14.75 12.00
T*(8,L)X*C16 HD24 21 650 18.1 14.0 15.00 11.50
T*9X*B12 HD24 17 630 19.0 13.9 13.75 12.25
T*(8,L)X*A12 UC18A 14 590 18.1 12.8 14.50 11.75
T*(8,L)X*B12 UC18B 17 595 18.0 12.7 14.50 11.75
T*9X*B12 UC18B 17 590 18.1 12.8 14.50 11.75
T*(8,L)X*A12 UC24A 14 570 18.4 13.0 14.75 12.00
T*(8,L)X*B12 UC24B 17 575 18.4 13.0 14.75 12.00
T*9X*B12 UC24B 17 615 18.7 13.5 14.75 12.00
T*(8,L)X*A12 UC30A 14 570 18.4 13.0 14.75 12.00
T*(8,L)X*B12 UC30B 17 625 18.4 13.3 15.00 12.25
T*9X*B12 UC30B 17 615 18.7 13.5 14.75 12.00
(Y*(8,L)C/T*8V)*A12 FC/MC/PC18A 14 620 18.1 13.0 14.50 12.05
(Y*(8,L)C/T*8V)*B12 FC/MC/PC18B 17 580 17.9 12.7 14.50 12.05
Y*9C*B12 FC/MC/PC18B 17 610 18.1 13.0 14.60 12.20
(Y*(8,L)C/T*8V)*A12 FC/MC/PC24A 14 640 18.5 13.4 14.70 12.20
(Y*(8,L)C/T*8V)*B12 FC/MC/PC24B 17 575 18.4 13.0 15.00 12.40
Y*9C*B12 FC/MC/PC24B 17 610 18.5 13.4 14.85 12.30
(Y*(8,L)C/T*8V)*A12 FC/MC/PC30A 14 640 18.5 13.4 14.70 12.20
(Y*(8,L)C/T*8V)*B12 FC/MC/PC30B 17 575 18.4 13.0 15.00 12.40
Y*9C*B12 FC/MC/PC30B 17 610 18.5 13.4 14.85 12.30
(Y*(8,L)C/T*8V)*A12 FC/MC/PC32A 14 590 18.4 13.1 14.55 12.20
(Y*(8,L)C/T*8V)*B12 FC/MC/PC35B 17 650 18.6 13.4 14.70 12.30
Y*9C*B12 FC/MC/PC35B 17 570 18.4 12.9 14.70 12.30
(Y*(8,L)C/T*8V)*C16 FC/MC/PC35C 21 600 18.6 13.4 15.05 12.55
Y*9C*C16 FC/MC/PC35C 21 645 18.6 13.4 14.85 12.40
(Y*(8,L)C/T*8V)*A12 FC/MC/PC36A 14 645 18.7 13.4 14.80 12.35
(Y*(8,L)C/T*8V)*B12 FC/MC/PC36B 17 650 18.7 13.5 15.00 12.45
Y*9C*B12 FC/MC/PC36B 17 635 18.7 13.5 15.00 12.45
(Y*(8,L)C/T*8V)*C16 FC/MC/PC36C 21 595 18.8 13.5 15.20 12.65
Y*9C*C16 FC/MC/PC36C 21 595 18.8 13.5 15.20 12.65
(Y*(8,L)C/T*8V)*A12 FC/MC/PC37A 14 625 18.7 13.5 14.80 12.35
(Y*(8,L)C/T*8V)*A12 HC18 14 620 18.1 13.0 14.50 12.05
(Y*(8,L)C/T*8V)*A12 HC30 14 590 18.2 12.8 14.50 12.05
(Y*(8,L)C/T*8V)*B12 HC36 17 650 18.7 13.6 14.75 12.40
Y*9C*B12 HC36 17 570 18.4 12.9 14.70 12.30
(Y*(8,L)C/T*8V)*A12 HD24 14 640 19.1 13.8 15.10 12.60
(Y*(8,L)C/T*8V)*B12 HD24 17 575 19.0 13.4 15.30 12.75
Y*9C*B12 HD24 17 610 19.2 13.9 15.20 12.70
(Y*(8,L)C/T*8V)*A12 HD36 14 645 18.5 12.9 14.60 12.25
(Y*(8,L)C/T*8V)*B12 HD36 17 650 18.5 12.9 14.70 12.30
(Y*(8,L)C/T*8V)*C16 HD36 21 595 18.6 12.9 15.00 12.50
For notes see Page 16.

556454-YTG-B-0410
Johnson Controls Unitary Products 9
TCHD18S41S3
Y*9C*B12 HD36 17 635 18.5 12.9 14.75 12.35
Y*9C*C16 HD36 21 595 18.6 12.9 15.00 12.50
(Y*(8,L)C/T*8V)*A12 UC18A 14 620 18.2 13.1 14.55 12.10
(Y*(8,L)C/T*8V)*B12 UC18B 17 580 18.0 12.7 14.50 12.15
Y*9C*B12 UC18B 17 610 18.2 13.1 14.70 12.25
(Y*(8,L)C/T*8V)*A12 UC24A 14 640 18.6 13.4 14.75 12.30
(Y*(8,L)C/T*8V)*B12 UC24B 17 575 18.4 13.1 15.00 12.45
Y*9C*B12 UC24B 17 610 18.7 13.4 14.85 12.40
(Y*(8,L)C/T*8V)*A12 UC30A 14 640 18.6 13.4 14.75 12.30
(Y*(8,L)C/T*8V)*B12 UC30B 17 575 18.4 13.1 15.00 12.45
Y*9C*B12 UC30B 17 610 18.7 13.4 14.85 12.40
(Y*(8,L)C/T*8V)*A12 UC36A 14 645 18.1 13.3 14.60 12.15
(Y*(8,L)C/T*8V)*B12 UC36B 17 650 18.1 13.3 14.70 12.20
Y*9C*B12 UC36B 17 635 18.1 13.4 14.75 12.25
(Y*(8,L)C/T*8V)*C16 UC36C 21 595 17.9 12.8 14.60 12.25
Y*9C*C16 UC36C 21 595 17.9 12.8 14.75 12.30
TCHD24S41S3
T*(8,L)X*A12 FC/MC/PC24A 14 775 23.4 17.3 14.50 11.75
T*(8,L)X*B12 FC/MC/PC24B 17 835 23.6 17.7 14.50 12.00
T*9X*B12 FC/MC/PC24B 17 775 23.4 17.3 14.50 11.75
T*(8,L)X*A12 FC/MC/PC30A 14 775 23.4 17.2 14.25 11.75
T*(8,L)X*B12 FC/MC/PC30B 17 835 23.6 17.7 14.50 12.00
T*9X*B12 FC/MC/PC30B 17 775 23.4 17.2 14.25 12.00
T*(8,L)X*A12 FC/MC/PC32A 14 800 23.6 17.6 14.75 12.00
T*(8,L)X*B12 FC/MC/PC35B 17 850 23.6 17.8 14.75 12.00
T*(8,L)X*C16 FC/MC/PC35C 21 625 22.8 15.9 14.25 11.75
T*(8,L)X*C20 FC/MC/PC35C 21 885 23.6 18.1 14.75 12.00
T*9X*B12 FC/MC/PC35B 17 785 23.8 17.7 14.75 12.00
T*9X*C16 FC/MC/PC35C 21 715 23.4 16.9 14.50 12.00
T*9X*C20 FC/MC/PC35C 21 825 23.6 17.6 14.50 12.00
T*(8,L)X*A12 FC/MC/PC36A 14 815 23.6 17.7 14.50 12.00
T*(8,L)X*B12 FC/MC/PC36B 17 835 23.8 17.8 14.75 12.00
T*(8,L)X*C16 FC/MC/PC36C 21 675 23.2 16.4 14.50 11.75
T*9X*B12 FC/MC/PC36B 17 775 23.6 17.6 14.50 12.00
T*9X*C16 FC/MC/PC36C 21 770 23.8 17.4 14.75 12.25
T*9X*C20 FC/MC/PC36C 21 810 23.6 17.6 14.50 12.00
T*(8,L)X*A12 FC/MC/PC37A 14 840 24.0 18.2 14.40 12.00
T*(8,L)X*B12 FC/MC/PC42B 17 865 24.2 18.4 14.75 12.00
T*(8,L)X*C16 FC/MC/PC42C 21 725 23.6 17.0 14.50 12.00
T*9X*B12 FC/MC/PC42B 17 805 23.8 17.8 14.75 12.00
T*9X*C16 FC/MC/PC42C 21 805 23.8 17.9 15.00 12.25
T*9X*C20 FC/MC/PC42C 21 790 23.6 17.6 14.50 12.00
T*(8,L)X*B12 FC/MC/PC43B 17 865 24.0 18.5 14.70 12.25
T*(8,L)X*C16 FC/MC/PC43C 21 655 23.0 16.2 14.25 11.75
T*9X*B12 FC/MC/PC43B 17 800 24.0 18.0 14.75 12.00
T*9X*C16 FC/MC/PC43C 21 735 23.6 17.2 14.75 12.00
T*9X*C20 FC/MC/PC43C 21 790 24.0 17.8 14.50 12.00
T*(8,L)X*C16 FC/MC/PC48C 21 685 23.6 16.8 14.50 12.00
T*9X*C16 FC/MC/PC48C 21 770 24.2 17.9 15.00 12.25
T*9X*C20 FC/MC/PC48C 21 815 24.2 18.2 14.75 12.00
T*(8,L)X*A12 HD36 14 815 23.0 17.0 14.25 11.75
T*(8,L)X*B12 HD36 17 855 23.0 17.0 14.25 11.75
T*(8,L)X*C16 HD36 21 855 23.0 17.0 14.25 11.75
For notes see Page 16.
COOLING CAPACITY - With High Efficiency Motor Furnaces (Continued)
UNIT
MODEL FURNACE MODEL COIL MODEL1WCOOLING
RATED
CFM Net MBH SEER EER
TOTAL SENS.
13 SEER AC WITH VARIABLE SPEED FURNACES2

556454-YTG-B-0410
10 Johnson Controls Unitary Products
TCHD24S41S3
T*9X*B12 HD36 17 790 23.0 17.0 14.00 11.75
T*(8,L)X*A12 UC24A 14 785 23.6 17.3 14.50 12.00
T*(8,L)X*B12 UC24B 17 835 23.6 17.6 14.75 12.00
T*9X*B12 UC24B 17 775 23.6 17.3 14.50 12.00
T*(8,L)X*A12 UC30A 14 785 23.6 17.3 14.50 12.00
T*(8,L)X*B12 UC30B 17 835 23.6 17.6 14.75 12.00
T*9X*B12 UC30B 17 775 23.6 17.3 14.50 12.00
T*(8,L)X*A12 UC36A 14 780 22.8 16.7 14.05 12.00
T*(8,L)X*B12 UC36B 17 835 23.0 17.3 14.35 12.00
T*(8,L)X*C16 UC36C 21 875 23.2 17.6 14.40 12.00
T*9X*B12 UC36B 17 775 22.8 16.7 14.10 12.00
T*9X*C16 UC36C 21 815 23.0 16.9 14.35 12.25
T*9X*C20 UC36C 21 810 22.8 16.8 14.25 12.00
T*(8,L)X*B12 UC42B 17 755 23.6 17.2 14.75 12.25
T*(8,L)X*C16 UC42C 21 725 23.6 17.2 14.50 12.00
T*9X*B12 UC42B 17 805 23.8 17.6 14.50 12.00
T*9X*C16 UC42C 21 805 23.8 17.7 14.75 12.25
T*9X*C20 UC42C 21 790 23.4 17.1 14.25 11.75
T*(8,L)X*C16 UC48C 21 685 23.4 16.8 14.50 12.00
T*9X*C16 UC48C 21 770 23.6 17.6 14.40 12.25
T*9X*C20 UC48C 21 815 24.0 18.0 14.50 12.00
(Y*(8,L)C/T*8V)*A12 FC/MC/PC24A 14 805 23.6 17.3 14.50 12.10
(Y*(8,L)C/T*8V)*B12 FC/MC/PC24B 17 815 23.6 17.5 14.75 12.25
Y*9C*B12 FC/MC/PC24B 17 790 23.4 17.2 14.50 12.10
(Y*(8,L)C/T*8V)*A12 FC/MC/PC30A 14 805 23.6 17.2 14.50 12.10
(Y*(8,L)C/T*8V)*B12 FC/MC/PC30B 17 815 23.6 17.3 14.70 12.30
Y*9C*B12 FC/MC/PC30B 17 790 23.6 17.2 14.50 12.10
(Y*(8,L)C/T*8V)*A12 FC/MC/PC32A 14 775 23.6 17.5 14.20 12.00
(Y*(8,L)C/T*8V)*B12 FC/MC/PC35B 17 760 23.6 17.1 14.50 12.20
Y*9C*B12 FC/MC/PC35B 17 815 23.8 17.6 14.30 12.15
(Y*(8,L)C/T*8V)*C16 FC/MC/PC35C 21 855 24.0 18.1 14.75 12.45
(Y*(8,L)C/T*8V)*C20 FC/MC/PC35C 21 740 23.6 17.2 14.90 12.55
Y*9C*C16 FC/MC/PC35C 21 900 24.2 18.5 14.60 12.35
Y*9C*C20 FC/MC/PC35C 21 755 23.6 17.2 14.65 12.35
(Y*(8,L)C/T*8V)*A12 FC/MC/PC36A 14 805 23.6 17.4 14.50 12.15
(Y*(8,L)C/T*8V)*B12 FC/MC/PC36B 17 765 23.8 17.5 14.75 12.35
Y*9C*B12 FC/MC/PC36B 17 815 23.6 17.4 14.50 12.15
(Y*(8,L)C/T*8V)*C16 FC/MC/PC36C 21 855 24.0 18.1 14.85 12.50
(Y*(8,L)C/T*8V)*C20 FC/MC/PC36C 21 750 23.6 17.1 14.90 12.50
Y*9C*C16 FC/MC/PC36C 21 785 23.8 17.5 14.75 12.35
Y*9C*C20 FC/MC/PC36C 21 760 23.6 17.2 14.75 12.35
(Y*(8,L)C/T*8V)*A12 FC/MC/PC37A 14 805 24.0 17.7 14.40 12.15
(Y*(8,L)C/T*8V)*B12 FC/MC/PC43B 17 760 24.0 17.4 14.70 12.45
Y*9C*B12 FC/MC/PC43B 17 800 24.0 17.8 14.60 12.30
(Y*(8,L)C/T*8V)*C16 FC/MC/PC43C 21 895 24.4 18.9 14.90 12.60
(Y*(8,L)C/T*8V)*C20 FC/MC/PC43C 21 760 24.0 17.5 15.05 12.70
Y*9C*C16 FC/MC/PC43C 21 810 24.2 18.0 14.75 12.45
Y*9C*C20 FC/MC/PC43C 21 890 24.4 18.8 14.85 12.50
(Y*(8,L)C/T*8V)*C16 FC/MC/PC48C 21 815 24.4 18.4 15.15 12.80
Y*9C*C16 FC/MC/PC48C 21 890 24.6 19.1 15.00 12.60
(Y*(8,L)C/T*8V)*A12 HC18 14 775 22.8 16.5 14.00 11.65
For notes see Page 16.
COOLING CAPACITY - With High Efficiency Motor Furnaces (Continued)
UNIT
MODEL FURNACE MODEL COIL MODEL1WCOOLING
RATED
CFM Net MBH SEER EER
TOTAL SENS.
13 SEER AC WITH VARIABLE SPEED FURNACES2

556454-YTG-B-0410
Johnson Controls Unitary Products 11
TCHD24S41S3
(Y*(8,L)C/T*8V)*A12 HC30 14 775 23.4 17.2 14.10 12.00
(Y*(8,L)C/T*8V)*B12 HC36 17 760 23.6 17.1 14.50 12.20
Y*9C*B12 HC36 17 815 23.8 17.6 14.35 12.15
(Y*(8,L)C/T*8V)*C16 HC42 21 895 24.4 18.9 14.90 12.60
(Y*(8,L)C/T*8V)*C20 HC42 21 760 24.0 17.5 15.05 12.70
Y*9C*C16 HC42 21 810 24.2 18.0 14.75 12.45
Y*9C*C20 HC42 21 890 24.4 18.9 14.85 12.50
(Y*(8,L)C/T*8V)*A12 HD24 14 805 24.0 17.6 14.60 12.30
(Y*(8,L)C/T*8V)*B12 HD24 17 815 24.0 17.6 14.85 12.50
Y*9C*B12 HD24 17 790 24.0 17.6 14.60 12.30
(Y*(8,L)C/T*8V)*A12 HD36 14 805 23.4 16.8 14.30 12.10
(Y*(8,L)C/T*8V)*B12 HD36 17 760 23.4 16.5 14.35 12.10
(Y*(8,L)C/T*8V)*C16 HD36 21 855 23.8 17.4 14.70 12.35
(Y*(8,L)C/T*8V)*C20 HD36 21 750 23.4 16.4 14.75 12.40
Y*9C*B12 HD36 17 815 23.4 16.8 14.35 12.15
Y*9C*C16 HD36 21 785 23.6 16.8 14.60 12.35
Y*9C*C20 HD36 21 760 23.4 16.6 14.60 12.30
(Y*(8,L)C/T*8V)*A12 UC24A 14 805 23.6 17.4 14.55 12.10
(Y*(8,L)C/T*8V)*B12 UC24B 17 815 23.6 17.4 14.80 12.25
Y*9C*B12 UC24B 17 790 23.6 17.4 14.55 12.05
(Y*(8,L)C/T*8V)*A12 UC30A 14 805 23.6 17.4 14.55 12.10
(Y*(8,L)C/T*8V)*B12 UC30B 17 815 23.6 17.4 14.80 12.25
Y*9C*B12 UC30B 17 790 23.6 17.4 14.55 12.05
(Y*(8,L)C/T*8V)*A12 UC36A 14 805 22.8 16.7 14.05 11.85
(Y*(8,L)C/T*8V)*B12 UC36B 17 765 23.0 16.8 14.35 12.05
Y*9C*B12 UC36B 17 815 22.8 16.7 14.10 12.00
(Y*(8,L)C/T*8V)*C16 UC36C 21 855 23.2 17.4 14.40 12.10
(Y*(8,L)C/T*8V)*C20 UC36C 21 750 22.8 16.4 14.55 12.15
Y*9C*C16 UC36C 21 785 23.0 16.8 14.35 12.05
Y*9C*C20 UC36C 21 760 22.8 16.5 14.35 12.05
(Y*(8,L)C/T*8V)*C16 UC48C 21 815 23.4 17.3 14.65 12.25
Y*9C*C16 UC48C 21 880 23.6 17.9 14.40 12.15
TCHD30S41S3
T*(8,L)X*A12 FC/MC/PC30A 14 1065 28.2 21.1 14.05 12.50
T*(8,L)X*B12 FC/MC/PC30B 17 945 27.8 20.3 14.50 12.75
T*9X*B12 FC/MC/PC30B 17 1065 28.2 21.1 14.25 12.50
T*(8,L)X*A12 FC/MC/PC32A 14 970 28.0 20.7 13.65 12.25
T*(8,L)X*B12 FC/MC/PC35B 17 1090 28.4 21.6 14.50 12.75
T*(8,L)X*C16 FC/MC/PC35C 21 1090 28.4 21.6 14.75 13.00
T*(8,L)X*C20 FC/MC/PC35C 21 850 27.8 20.1 14.75 13.00
T*9X*B12 FC/MC/PC35B 17 1085 28.2 21.4 14.25 12.75
T*9X*C16 FC/MC/PC35C 21 1075 28.4 21.5 14.75 13.00
T*(8,L)X*A12 FC/MC/PC36A 14 995 28.2 20.7 14.00 12.25
T*(8,L)X*B12 FC/MC/PC36B 17 1075 28.4 21.5 14.50 12.50
T*(8,L)X*C16 FC/MC/PC36C 21 1090 28.4 21.2 14.75 13.00
T*(8,L)X*C20 FC/MC/PC36C 21 890 28.0 20.3 15.00 13.00
T*9X*B12 FC/MC/PC36B 17 1070 28.4 21.3 14.50 12.50
T*9X*C16 FC/MC/PC36C 21 1070 28.4 21.3 14.50 12.75
T*(8,L)X*A12 FC/MC/PC37A 14 1105 28.8 22.2 14.50 13.00
T*(8,L)X*B12 FC/MC/PC42B 17 1045 27.8 20.9 14.25 12.25
T*(8,L)X*C20 FC/MC/PC42C 21 920 27.0 19.9 14.50 12.50
T*9X*B12 FC/MC/PC42B 17 1045 27.8 20.9 14.25 12.25
T*9X*C16 FC/MC/PC42C 21 1035 27.6 20.3 14.25 12.25
For notes see Page 16.
COOLING CAPACITY - With High Efficiency Motor Furnaces (Continued)
UNIT
MODEL FURNACE MODEL COIL MODEL1WCOOLING
RATED
CFM Net MBH SEER EER
TOTAL SENS.
13 SEER AC WITH VARIABLE SPEED FURNACES2

556454-YTG-B-0410
12 Johnson Controls Unitary Products
TCHD30S41S3
T*(8,L)X*B12 FC/MC/PC43B 17 1115 28.8 21.6 14.25 12.25
T*(8,L)X*C20 FC/MC/PC43C 21 870 26.4 21.3 14.50 12.50
T*9X*B12 FC/MC/PC43B 17 1095 28.8 21.6 14.25 12.25
T*9X*C16 FC/MC/PC43C 21 1055 28.8 21.1 14.25 12.25
T*(8,L)X*C20 FC/MC/PC48C 21 890 28.8 20.9 15.50 13.50
T*9X*C16 FC/MC/PC48C 21 1075 29.4 22.6 15.25 13.25
T*(8,L)X*A12 HD36 14 1065 28.0 21.0 14.00 12.50
T*(8,L)X*B12 HD36 17 1065 28.0 21.0 14.00 12.50
T*(8,L)X*C16 HD36 21 1065 28.2 21.1 14.00 12.75
T*9X*B12 HD36 17 1065 28.0 21.0 14.00 12.50
T*(8,L)X*A12 UC30A 14 1065 28.2 21.3 14.00 12.50
T*(8,L)X*B12 UC30B 17 945 28.0 20.5 14.50 12.75
T*9X*B12 UC30B 17 1065 28.2 21.3 14.30 12.50
T*(8,L)X*A12 UC36A 14 995 26.8 19.5 13.50 11.75
T*(8,L)X*B12 UC36B 17 1065 28.2 21.3 14.50 12.50
T*(8,L)X*C16 UC36C 21 1075 28.4 21.3 14.75 12.75
T*(8,L)X*C20 UC36C 21 890 26.6 19.4 14.25 12.25
T*9X*B12 UC36B 17 1070 28.2 21.3 14.50 12.50
T*9X*C16 UC36C 21 1070 28.4 21.3 14.50 12.75
T*(8,L)X*B12 UC42B 17 1025 27.2 20.3 13.75 12.00
T*(8,L)X*C16 UC42C 21 825 26.0 18.2 14.25 12.25
T*(8,L)X*C20 UC42C 21 950 27.0 19.5 14.50 12.50
T*9X*B12 UC42B 17 1025 27.2 20.3 13.75 12.00
T*9X*C16 UC42C 21 1030 27.4 20.3 14.00 12.25
T*(8,L)X*C16 UC48C 21 815 26.4 18.9 14.50 12.50
T*(8,L)X*C20 UC48C 21 960 27.4 20.1 14.75 12.75
T*9X*C16 UC48C 21 1035 27.6 20.7 14.25 12.25
(Y*(8,L)C/T*8V)*A12 FC/MC/PC30A 14 1055 28.2 21.4 14.05 12.40
(Y*(8,L)C/T*8V)*B12 FC/MC/PC30B 17 955 28.2 21.0 15.00 13.15
Y*9C*B12 FC/MC/PC30B 17 1050 28.2 21.2 14.50 12.75
(Y*(8,L)C/T*8V)*A12 FC/MC/PC32A 14 1045 28.0 21.0 13.65 12.10
(Y*(8,L)C/T*8V)*B12 FC/MC/PC35B 17 995 28.4 21.2 14.50 13.00
Y*9C*B12 FC/MC/PC35B 17 1045 28.2 21.6 14.25 12.50
(Y*(8,L)C/T*8V)*C16 FC/MC/PC35C 21 1025 28.4 21.4 15.00 13.15
(Y*(8,L)C/T*8V)*C20 FC/MC/PC35C 21 1080 28.8 22.2 15.05 13.20
Y*9C*C16 FC/MC/PC35C 21 1005 28.4 21.4 15.00 13.10
Y*9C*C20 FC/MC/PC35C 21 985 28.4 21.4 15.00 13.10
(Y*(8,L)C/T*8V)*A12 FC/MC/PC36A 14 1000 28.2 21.0 14.50 12.75
(Y*(8,L)C/T*8V)*B12 FC/MC/PC36B 17 985 28.4 21.0 14.80 13.05
Y*9C*B12 FC/MC/PC36B 17 985 28.4 21.0 14.70 13.00
(Y*(8,L)C/T*8V)*C16 FC/MC/PC36C 21 1020 28.4 21.2 15.00 13.15
(Y*(8,L)C/T*8V)*C20 FC/MC/PC36C 21 1055 28.8 21.8 15.20 13.35
Y*9C*C16 FC/MC/PC36C 21 1005 28.4 21.2 15.00 13.20
Y*9C*C20 FC/MC/PC36C 21 1045 28.4 21.0 14.75 13.05
(Y*(8,L)C/T*8V)*A12 FC/MC/PC37A 14 980 28.8 21.6 14.50 12.80
(Y*(8,L)C/T*8V)*B12 FC/MC/PC43B 17 990 28.8 21.8 15.00 13.20
Y*9C*B12 FC/MC/PC43B 17 1035 28.8 21.6 14.50 12.85
(Y*(8,L)C/T*8V)*C16 FC/MC/PC43C 21 990 29.0 21.8 15.35 13.60
(Y*(8,L)C/T*8V)*C20 FC/MC/PC43C 21 1000 29.0 21.8 15.40 13.65
Y*9C*C16 FC/MC/PC43C 21 1030 28.8 21.6 14.80 13.15
Y*9C*C20 FC/MC/PC43C 21 995 29.0 21.8 15.20 13.45
(Y*(8,L)C/T*8V)*A12 HC30 14 1030 27.6 20.6 13.50 12.00
(Y*(8,L)C/T*8V)*B12 HC36 17 995 28.4 21.2 14.50 13.00
Y*9C*B12 HC36 17 1045 28.2 21.6 14.30 12.50
For notes see Page 16.
COOLING CAPACITY - With High Efficiency Motor Furnaces (Continued)
UNIT
MODEL FURNACE MODEL COIL MODEL1WCOOLING
RATED
CFM Net MBH SEER EER
TOTAL SENS.
13 SEER AC WITH VARIABLE SPEED FURNACES2

556454-YTG-B-0410
Johnson Controls Unitary Products 13
TCHD30S41S3
(Y*(8,L)C/T*8V)*C16 HC42 21 990 29.0 21.8 15.35 13.60
(Y*(8,L)C/T*8V)*C20 HC42 21 1000 29.0 21.8 15.40 13.65
Y*9C*C16 HC42 21 1030 28.8 21.8 14.80 13.15
Y*9C*C20 HC42 21 995 29.0 21.8 15.20 13.45
(Y*(8,L)C/T*8V)*A12 HD36 14 1000 28.0 20.2 14.30 12.65
(Y*(8,L)C/T*8V)*B12 HD36 17 985 28.0 20.4 14.65 13.00
(Y*(8,L)C/T*8V)*C16 HD36 21 1020 28.2 20.4 14.80 13.05
(Y*(8,L)C/T*8V)*C20 HD36 21 1055 28.4 21.0 15.00 13.25
Y*9C*B12 HD36 17 985 28.0 20.4 14.60 12.85
Y*9C*C16 HD36 21 1005 28.2 20.4 14.85 13.05
Y*9C*C20 HD36 21 1045 28.0 20.4 14.65 13.00
(Y*(8,L)C/T*8V)*A12 UC30A 14 1055 28.2 21.6 14.00 12.40
(Y*(8,L)C/T*8V)*B12 UC30B 17 955 28.4 21.0 15.00 13.20
Y*9C*B12 UC30B 17 1000 28.2 20.8 14.30 12.70
(Y*(8,L)C/T*8V)*A12 UC36A 14 1000 28.2 20.8 14.30 12.70
(Y*(8,L)C/T*8V)*B12 UC36B 17 985 28.2 21.0 14.65 13.00
Y*9C*B12 UC36B 17 985 28.2 21.0 14.55 13.00
(Y*(8,L)C/T*8V)*C16 UC36C 21 1020 28.4 21.0 14.80 13.10
(Y*(8,L)C/T*8V)*C20 UC36C 21 1035 27.8 21.0 14.75 13.00
Y*9C*C16 UC36C 21 1000 28.4 21.0 14.80 13.10
Y*9C*C20 UC36C 21 1045 28.2 21.0 14.65 13.00
TCHD36S41S3
T*(8,L)X*A12 FC/MC/PC32A 14 1160 32.6 23.6 13.45 11.50
T*(8,L)X*B12 FC/MC/PC35B 17 1275 33.4 24.8 13.55 11.75
T*(8,L)X*C16 FC/MC/PC35C 21 1105 33.6 24.3 14.20 12.25
T*(8,L)X*C20 FC/MC/PC35C 21 1225 33.8 24.9 14.25 12.25
T*9X*B12 FC/MC/PC35B 17 1265 33.4 24.8 13.65 11.75
T*9X*C16 FC/MC/PC35C 21 1270 33.6 25.0 14.00 12.00
T*9X*C20 FC/MC/PC35C 21 1195 33.6 24.3 13.80 12.00
T*(8,L)X*A12 FC/MC/PC36A 14 1185 33.0 24.1 13.25 11.50
T*(8,L)X*B12 FC/MC/PC36B 17 1255 33.2 24.5 13.50 11.75
T*(8,L)X*C16 FC/MC/PC36C 21 1100 33.2 23.7 14.00 12.00
T*(8,L)X*C20 FC/MC/PC36C 21 1265 33.6 24.8 14.25 12.25
T*9X*B12 FC/MC/PC36B 17 1245 33.2 24.7 13.50 11.50
T*9X*C16 FC/MC/PC36C 21 1265 33.6 25.1 13.75 12.00
T*9X*C20 FC/MC/PC36C 21 1195 33.2 24.3 13.75 12.00
T*(8,L)X*A12 FC/MC/PC37A 14 1290 33.0 24.8 14.05 12.00
T*(8,L)X*B12 FC/MC/PC42B 17 1160 32.4 23.7 13.50 11.75
T*(8,L)X*C16 FC/MC/PC42C 21 1200 32.6 23.7 14.00 12.00
T*(8,L)X*C20 FC/MC/PC42C 21 1240 33.0 24.3 14.25 12.00
T*9X*B12 FC/MC/PC42B 17 1235 32.8 24.1 13.50 11.50
T*9X*C16 FC/MC/PC42C 21 1235 32.8 24.1 13.75 11.50
T*9X*C20 FC/MC/PC42C 21 1185 32.4 23.5 13.50 11.50
T*(8,L)X*B12 FC/MC/PC43B 17 1300 34.2 25.7 14.00 12.00
T*(8,L)X*C16 FC/MC/PC43C 21 1175 34.4 25.3 14.75 12.50
T*(8,L)X*C20 FC/MC/PC43C 21 1250 34.6 26.1 15.00 12.50
T*9X*B12 FC/MC/PC43B 17 1270 34.2 25.7 14.00 12.00
T*9X*C16 FC/MC/PC43C 21 1260 34.2 25.9 14.20 12.25
T*9X*C20 FC/MC/PC43C 21 1185 34.2 25.3 14.65 12.25
T*(8,L)X*C16 FC/MC/PC48C 21 1185 34.8 25.9 15.10 12.75
T*(8,L)X*C20 FC/MC/PC48C 21 1270 35.2 26.4 15.00 12.75
T*9X*C16 FC/MC/PC48C 21 1280 35.0 26.3 14.50 12.50
T*9X*C20 FC/MC/PC48C 21 1205 34.6 25.7 14.55 12.50
For notes see Page 16.
COOLING CAPACITY - With High Efficiency Motor Furnaces (Continued)
UNIT
MODEL FURNACE MODEL COIL MODEL1WCOOLING
RATED
CFM Net MBH SEER EER
TOTAL SENS.
13 SEER AC WITH VARIABLE SPEED FURNACES2

556454-YTG-B-0410
14 Johnson Controls Unitary Products
TCHD36S41S3
T*9X*D20 FC/MC/PC48D 24 1240 34.8 25.7 14.75 12.50
T*(8,L)X*A12 HD36 14 1270 33.2 24.2 13.40 11.75
T*(8,L)X*B12 HD36 17 1270 33.2 24.2 13.70 11.75
T*9X*B12 HD36 17 1270 33.4 24.4 13.85 11.75
T*(8,L)X*C16 HD48 21 1120 34.2 24.9 14.00 12.50
T*(8,L)X*C20 HD48 21 1245 34.8 26.0 14.00 12.75
T*9X*C20 HD48 21 1245 34.8 26.0 14.00 12.75
T*9X*D20 HD48 24 1260 34.8 26.3 14.00 12.75
T*(8,L)X*B12 UC36B 17 1205 32.0 23.5 13.00 11.00
T*(8,L)X*C16 UC36C 21 1180 32.4 23.7 13.75 11.75
T*(8,L)X*C20 UC36C 21 1225 32.6 24.5 13.75 11.75
T*9X*B12 UC36B 17 1195 31.8 23.5 13.00 11.00
T*9X*C16 UC36C 21 1205 32.0 23.5 13.00 11.25
T*9X*C20 UC36C 21 1195 32.2 23.7 13.25 11.50
T*(8,L)X*B12 UC42B 17 1215 32.4 23.3 13.00 11.25
T*(8,L)X*C16 UC42C 21 1170 32.4 23.1 13.75 11.75
T*(8,L)X*C20 UC42C 21 1225 32.6 23.7 13.75 11.75
T*9X*B12 UC42B 17 1215 32.4 23.5 13.00 11.25
T*9X*C16 UC42C 21 1215 32.4 23.5 13.25 11.50
T*9X*C20 UC42C 21 1185 32.6 23.5 13.50 11.50
T*(8,L)X*C16 UC48C 21 1185 32.8 23.9 14.25 12.00
T*(8,L)X*C20 UC48C 21 1245 33.2 24.7 14.00 12.00
T*9X*C16 UC48C 21 1240 33.0 24.3 13.50 11.75
T*9X*C20 UC48C 21 1205 32.6 23.7 13.75 11.75
T*9X*D20 UC48D 24 1225 32.6 23.7 13.75 11.75
(Y*(8,L)C/T*8V)*A12 FC/MC/PC32A 14 1045 32.6 23.0 13.45 11.70
(Y*(8,L)C/T*8V)*B12 FC/MC/PC35B 17 1220 33.4 24.6 13.55 11.75
Y*9C*B12 FC/MC/PC35B 17 1190 33.4 24.6 13.65 11.85
(Y*(8,L)C/T*8V)*C16 FC/MC/PC35C 21 1235 33.6 24.8 14.20 12.30
(Y*(8,L)C/T*8V)*C20 FC/MC/PC35C 21 1170 33.8 24.8 14.50 12.55
Y*9C*C16 FC/MC/PC35C 21 1215 33.6 24.8 14.05 12.15
Y*9C*C20 FC/MC/PC35C 21 1275 34.2 25.4 13.80 12.00
(Y*(8,L)C/T*8V)*A12 FC/MC/PC36A 14 1190 33.2 24.2 13.55 11.70
(Y*(8,L)C/T*8V)*B12 FC/MC/PC36B 17 1220 33.2 24.2 13.85 12.00
Y*9C*B12 FC/MC/PC36B 17 1165 33.4 24.2 14.00 12.05
(Y*(8,L)C/T*8V)*C16 FC/MC/PC36C 21 1235 33.4 24.4 14.30 12.30
(Y*(8,L)C/T*8V)*C20 FC/MC/PC36C 21 1240 33.6 24.4 14.50 12.40
Y*9C*C16 FC/MC/PC36C 21 1185 33.6 24.4 14.35 12.35
Y*9C*C20 FC/MC/PC36C 21 1270 34.0 25.2 14.00 12.10
(Y*(8,L)C/T*8V)*A12 FC/MC/PC37A 14 980 33.0 23.0 14.05 12.15
(Y*(8,L)C/T*8V)*B12 FC/MC/PC43B 17 1210 34.2 25.2 14.00 12.10
Y*9C*B12 FC/MC/PC43B 17 1200 34.2 25.2 14.00 12.10
(Y*(8,L)C/T*8V)*C16 FC/MC/PC43C 21 1205 34.4 25.4 14.75 12.70
(Y*(8,L)C/T*8V)*C20 FC/MC/PC43C 21 1190 34.6 25.4 15.00 12.85
Y*9C*C16 FC/MC/PC43C 21 1240 34.2 25.2 14.20 12.25
Y*9C*C20 FC/MC/PC43C 21 1200 34.4 25.4 14.65 12.60
(Y*(8,L)C/T*8V)*C16 FC/MC/PC48C 21 1210 35.0 26.0 15.10 13.00
(Y*(8,L)C/T*8V)*C20 FC/MC/PC48C 21 1155 35.2 26.0 15.35 13.20
Y*9C*C16 FC/MC/PC48C 21 1195 35.0 25.8 14.85 12.80
Y*9C*C20 FC/MC/PC48C 21 1315 35.2 26.8 14.55 12.55
Y*9C*D20 FC/MC/PC48D 24 1240 35.2 26.2 15.00 13.00
For notes see Page 16.
COOLING CAPACITY - With High Efficiency Motor Furnaces (Continued)
UNIT
MODEL FURNACE MODEL COIL MODEL1WCOOLING
RATED
CFM Net MBH SEER EER
TOTAL SENS.
13 SEER AC WITH VARIABLE SPEED FURNACES2

556454-YTG-B-0410
Johnson Controls Unitary Products 15
TCHD36S41S3
(Y*(8,L)C/T*8V)*B12 HC36 17 1220 33.4 24.4 13.55 11.80
Y*9C*B12 HC36 17 1190 33.2 24.0 13.60 11.75
(Y*(8,L)C/T*8V)*C16 HC42 21 1205 34.6 25.4 14.75 12.75
(Y*(8,L)C/T*8V)*C20 HC42 21 1190 34.6 25.6 15.00 13.00
Y*9C*C16 HC42 21 1240 34.4 25.2 14.25 12.30
Y*9C*C20 HC42 21 1200 34.6 25.4 14.65 12.65
Y*9C*D20 HC60 24 1225 33.6 24.8 14.50 12.45
(Y*(8,L)C/T*8V)*A12 HD36 14 1190 33.2 23.4 13.40 11.70
(Y*(8,L)C/T*8V)*B12 HD36 17 1220 33.2 23.6 13.70 12.00
(Y*(8,L)C/T*8V)*C16 HD36 21 1235 33.4 23.6 14.15 12.30
(Y*(8,L)C/T*8V)*C20 HD36 21 1240 33.6 23.6 14.30 12.40
Y*9C*B12 HD36 17 1165 33.4 23.6 13.85 12.05
Y*9C*C16 HD36 21 1185 33.4 23.6 14.20 12.35
Y*9C*C20 HD36 21 1265 33.8 24.6 13.85 12.05
(Y*(8,L)C/T*8V)*B12 HD48 17 1210 34.6 25.2 14.50 12.45
(Y*(8,L)C/T*8V)*C16 HD48 21 1210 34.8 25.4 15.00 13.00
(Y*(8,L)C/T*8V)*C20 HD48 21 1155 34.8 25.4 15.20 13.05
Y*9C*B12 HD48 17 1150 34.4 25.2 14.25 12.35
Y*9C*C16 HD48 21 1195 34.6 25.2 14.70 12.70
Y*9C*C20 HD48 21 1300 34.8 26.2 14.35 12.40
Y*9C*D20 HD48 24 1225 34.8 25.6 15.00 12.85
(Y*(8,L)C/T*8V)*B12 UC36B 17 1210 32.4 23.2 13.45 11.65
Y*9C*B12 UC36B 17 1165 32.6 23.4 13.60 11.75
(Y*(8,L)C/T*8V)*C16 UC36C 21 1215 32.6 23.4 14.00 12.00
(Y*(8,L)C/T*8V)*C20 UC36C 21 1225 32.8 23.4 14.05 12.10
Y*9C*C16 UC36C 21 1185 32.6 23.4 14.00 12.05
Y*9C*C20 UC36C 21 1235 33.0 24.6 13.65 11.75
(Y*(8,L)C/T*8V)*C16 UC48C 21 1210 33.6 24.8 14.55 12.45
(Y*(8,L)C/T*8V)*C20 UC48C 21 1155 33.6 24.8 14.75 12.60
Y*9C*C16 UC48C 21 1195 33.4 24.6 14.25 12.25
Y*9C*C20 UC48C 21 1265 33.8 25.4 14.00 12.00
Y*9C*D20 UC48D 24 1240 33.4 24.6 14.35 12.30
TCHD48S41S3
T*(8,L)X*C16 FC/MC/PC48C 21 1600 47.0 34.0 13.50 11.50
T*(8,L)X*C20 FC/MC/PC48C 21 1660 47.5 34.6 13.50 11.75
T*9X*C16 FC/MC/PC48C 21 1565 47.0 33.6 13.25 11.50
T*9X*C20 FC/MC/PC48C 21 1615 47.0 34.2 13.50 11.50
T*9X*D20 FC/MC/PC48D 24 1635 47.0 34.2 13.50 11.50
T*(8,L)X*C16 FC/PC60C 21 1605 46.5 33.6 13.25 11.50
T*(8,L)X*C20 FC/PC60C 21 1595 46.5 33.6 13.50 11.50
T*(8,L)X*C20 FC/MC/PC60D 21 1595 46.5 33.6 13.50 11.50
T*9X*C16 FC/PC60C 21 1575 45.5 33.6 13.00 11.25
T*9X*C20 FC/PC60C 21 1625 45.5 33.6 13.25 11.25
T*9X*D20 FC/MC/PC60D 24 1490 46.5 32.8 13.50 11.75
T*(8,L)X*C16 FC/MC62D 21 1610 47.0 34.4 13.50 11.50
T*(8,L)X*C20 FC/MC62D 21 1665 47.5 34.4 13.75 11.75
T*9X*C16 FC/MC62D 21 1550 47.0 34.2 13.50 11.50
T*9X*C20 FC/MC62D 21 1595 47.5 34.4 13.50 11.50
T*9X*D20 FC/MC62D 24 1610 47.0 34.2 13.50 11.50
T*(8,L)X*C16 HD48 21 1610 48.0 33.9 13.45 12.00
T*(8,L)X*C20 HD48 21 1665 48.0 33.9 13.45 12.00
T*9X*C16 HD48 21 1575 48.0 33.9 13.35 12.00
T*9X*C20 HD48 21 1625 48.0 33.9 13.35 12.00
For notes see Page 16.
COOLING CAPACITY - With High Efficiency Motor Furnaces (Continued)
UNIT
MODEL FURNACE MODEL COIL MODEL1WCOOLING
RATED
CFM Net MBH SEER EER
TOTAL SENS.
13 SEER AC WITH VARIABLE SPEED FURNACES2

556454-YTG-B-0410
16 Johnson Controls Unitary Products
TCHD48S41S3
T*9X*D20 HD48 24 1645 48.0 33.9 13.35 12.00
T*(8,L)X*C16 UC48C 21 1640 45.5 32.8 13.00 11.00
T*(8,L)X*C20 UC48C 21 1515 45.0 31.6 13.05 11.50
T*9X*C16 UC48C 21 1565 45.0 32.8 13.00 11.00
T*9X*C20 UC48C 21 1615 45.5 32.8 13.00 11.25
T*9X*D20 UC48D 24 1635 45.0 32.8 13.00 11.00
T*(8,L)X*C16 UC60C 21 1640 45.5 32.4 13.00 11.25
T*(8,L)X*C20 UC60C 21 1540 45.0 32.2 13.50 11.75
T*(8,L)X*C20 UC60D 21 1540 45.0 32.2 13.75 11.75
T*9X*D20 UC60D 24 1490 45.0 31.6 13.20 11.50
(Y*(8,L)C/T*8V)*C16 FC/MC/PC48C 21 1615 47.0 34.2 13.50 11.70
(Y*(8,L)C/T*8V)*C20 FC/MC/PC48C 21 1640 47.5 34.4 13.50 11.75
Y*9C*C16 FC/MC/PC48C 21 1590 47.0 33.8 13.45 11.65
Y*9C*C20 FC/MC/PC48C 21 1655 47.5 34.4 13.50 11.70
Y*9C*D20 FC/MC/PC48D 24 1645 47.5 34.4 13.50 11.70
Y*9C*D20 FC/MC/PC60D 24 1615 47.0 34.4 13.50 11.75
Y*9C*D20 FC/MC62D 24 1630 47.5 34.6 13.65 11.85
(Y*(8,L)C/T*8V)*C16 FC/PC60C 21 1625 47.5 34.4 13.60 11.80
(Y*(8,L)C/T*8V)*C20 FC/PC60C 21 1605 47.5 34.6 14.00 12.05
Y*9C*C16 FC/PC60C 21 1590 47.0 34.4 13.40 11.65
Y*9C*C20 FC/PC60C 21 1655 47.0 34.4 13.35 11.65
Y*9C*D20 HC60 24 1615 46.0 33.4 13.35 11.40
(Y*(8,L)C/T*8V)*C16 HD48 21 1615 47.0 33.6 13.45 11.65
(Y*(8,L)C/T*8V)*C20 HD48 21 1640 47.0 33.6 13.45 11.65
Y*9C*C16 HD48 21 1590 47.0 33.6 13.35 11.60
Y*9C*C20 HD48 21 1655 47.0 33.6 13.35 11.60
Y*9C*D20 HD48 24 1645 47.0 33.6 13.35 11.60
(Y*(8,L)C/T*8V)*C16 HD60 21 1625 47.5 34.4 13.70 11.85
(Y*(8,L)C/T*8V)*C20 HD60 21 1605 47.5 34.6 14.00 12.05
Y*9C*C16 HD60 21 1590 47.0 34.2 13.50 11.65
Y*9C*C20 HD60 21 1655 47.0 34.2 13.50 11.65
Y*9C*D20 HD60 24 1615 47.5 34.4 13.60 11.75
(Y*(8,L)C/T*8V)*C16 UC48C 21 1615 45.5 33.2 13.10 11.35
(Y*(8,L)C/T*8V)*C20 UC48C 21 1640 45.5 33.0 13.05 11.35
Y*9C*C16 UC48C 21 1590 45.5 33.0 13.00 11.30
Y*9C*C20 UC48C 21 1655 45.5 33.0 13.00 11.30
Y*9C*D20 UC48D 24 1645 45.5 33.0 13.00 11.30
(Y*(8,L)C/T*8V)*C16 UC60C 21 1625 46.0 32.8 13.30 11.50
(Y*(8,L)C/T*8V)*C20 UC60C 21 1605 46.0 33.0 13.55 11.70
Y*9C*C16 UC60C 21 1590 45.5 32.8 13.05 11.30
Y*9C*C20 UC60C 21 1655 45.5 32.8 13.05 11.30
Y*9C*D20 UC60D 24 1615 46.0 32.8 13.20 11.40
TCHD60S41S3
T*(8,L)X*C20 FC/MC62D 21 1665 56.5 38.2 13.25 11.25
(Y*(8,L)C/T*8V)*C20 FC/MC62D 21 1615 56.5 38.5 13.30 11.30
Y*9C*C20 FC/MC62D 21 1655 56.5 38.0 13.15 11.10
Y*9C*D20 FC/MC62D 24 1630 56.5 38.0 13.30 11.20
(Y*(8,L)C/T*8V)*C20 HD60 21 1605 56.0 37.8 13.40 11.40
Y*9C*C20 HD60 21 1655 56.0 37.4 13.00 11.10
Y*9C*D20 HD60 24 1615 56.0 37.6 13.10 11.15
1. MC coils available with a factory installed horizontal drain pan. See price pages for specific model number.
2. Variable speed furnaces have B.O.D (Blower on Delay) standard.
COOLING CAPACITY - With High Efficiency Motor Furnaces (Continued)
UNIT
MODEL FURNACE MODEL COIL MODEL1WCOOLING
RATED
CFM Net MBH SEER EER
TOTAL SENS.
13 SEER AC WITH VARIABLE SPEED FURNACES2

556454-YTG-B-0410
Johnson Controls Unitary Products 17
ACCESSORIES
Refer to Price Manual for specific model numbers.
Hard Start Kit - Required when using TXV indoor coil. Also,
provides increased starting torque for areas with low voltage.
Off Cycle Timer Delay - Provides a 5-minute off cycle to pre-
vent rapid recycling of the compressor.
Thermostats - Compatible thermostat controls are available
through accessory sourcing. For optimum performance and
installation, refer to the UPGNET “Low Voltage Wiring Diagram”
document to select and apply controls.
SOUND POWER RATINGS*
* Rated in accordance with ARI 270-95 Standards.
TYPICAL INSTALLATION
TYPICAL FIELD WIRING
Model Start Kit Numbers
18, 24, 30, 60 S1-2SA06704006
36 S1-2SA06715006
48 S1-2SA06708006
UNIT MODEL (dBA)
18 67
24 68
30 71
36 71
42 71
48 71
60 71
THERMOSTAT
SEAL OPENING(S) WITH
PERMAGUM OR EQUIVALENT
TO INDOOR COIL
TO FURNACE OR
AIR HANDLER
TERMINAL BLOCK
NEC CLASS 2 WIRING
NEC CLASS 1 WIRING
ALL OUTDOOR WIRING
MUST BE WEATHERPROOF. CONTROL
ACCESS
PANEL
WEATHERPROOF
DISCONNECT
SWITCH
MINIMUM 18” SERVICE
ACCESS CLEARANCE
ON ONE SIDE
6” CLEARANCE
AROUND PERIMETER
NOTE:
ALL FIELD WIRING TO BE IN ACCORDANCE WITH ELECTRIC CODE (NEC) AND/OR LOCAL CODES
POWER WIRING
208/230-1-60
CONTACTOR
TERMINALS
COIL
GND.
LUG
CYRGW
YRGW
POWER WIRING
CONTROL WIRING
FACTORY WIRING
24 VOLT CONTROL WIRING
MINIMUM 18 GA. WIRE
(NEC CLASS 2)
FURNACE OR AIR HANDLER TERMINAL BLOCK
ROOM THERMOSTAT
CONDENSING UNIT
ALL OUTDOOR WIRING MUST BE WEATHERPROOF. USE COPPER CONDUCTORS ONLY.
TERMINAL W IS ONLY
REQUIRED ON SYSTEMS
WITH HEAT.
*
*

556454-YTG-B-0410
18 Johnson Controls Unitary Products
Multipliers for determining the performance with other indoor sections.
NOTE: For dry bulb temperatures different than those listed (between 73-87 F), sensible capacity increases by 1060 BTUH per 1000 CFM per degree above the listed
temperature and decreases by 1060 BTUH per 1000 CFM per degree below the listed temperature.
Continued on next page.
COOLING PERFORMANCE DATA
AIR CONDITIONER MODEL NO. TCHD18S41S3
INDOOR COIL MODEL NO. FC/MC/PC24
CONDENSING
ENTERING AIR
TEMPERATURE
IDCFM 450 600 750
ID DB (°F) 80 80 75 80 80 80 80 75 80 80 80 80 75 80 80
ID WB (°F) 57 62 62 67 72 57 62 62 67 72 57 62 62 67 72
65 T.C. 17.3 18.2 18.6 19.7 21.5 18.9 19.0 19.2 20.6 22.5 20.4 19.7 19.8 21.5 23.4 S.C. 16.6 14.5 12.6 12.2 9.9 18.0 16.9 14.3 14.2 10.7 19.4 19.3 15.9 16.2 11.6
KW 1.07 1.08 1.09 1.08 1.07 1.07 1.07 1.09 1.07 1.07 1.07 1.07 1.08 1.07 1.08
75 T.C. 16.2 17.3 17.8 18.9 20.7 17.8 18.2 18.4 19.7 21.5 19.4 19.1 19.0 20.5 22.3 S.C. 15.7 13.9 12.2 11.8 9.6 17.2 16.4 13.9 13.7 10.5 18.7 18.8 15.6 15.6 11.4
KW 1.28 1.28 1.28 1.27 1.25 1.27 1.27 1.27 1.26 1.25 1.26 1.26 1.27 1.26 1.26
85 T.C. 15.1 16.5 16.9 18.1 20.0 16.7 17.5 17.6 18.9 20.5 18.3 18.5 18.2 19.6 21.1 S.C. 14.8 13.3 11.8 11.4 9.3 16.4 15.8 13.5 13.1 10.2 18.0 18.4 15.3 14.9 11.2
KW 1.48 1.48 1.47 1.46 1.44 1.46 1.46 1.46 1.45 1.43 1.44 1.44 1.46 1.44 1.43
95 T.C. 14.0 15.7 16.1 17.3 19.2 15.6 16.8 16.8 18.0 19.6 17.3 18.0 17.4 18.7 19.9 S.C. 14.0 12.7 11.3 11.0 8.9 15.7 15.3 13.1 12.6 10.0 17.4 17.9 14.9 14.2 11.0
KW 1.68 1.68 1.66 1.64 1.62 1.65 1.66 1.65 1.64 1.61 1.63 1.63 1.64 1.63 1.61
105 T.C. 13.4 14.5 14.9 16.0 18.1 14.8 15.6 15.6 16.8 18.5 16.3 16.7 16.2 17.6 18.9 S.C. 13.3 12.2 10.7 10.4 8.5 14.8 14.5 12.4 12.0 9.5 16.3 16.7 14.1 13.7 10.5
KW 2.16 2.12 2.11 2.12 1.93 2.08 2.06 2.07 2.04 1.92 1.99 1.99 2.02 1.95 1.91
115 T.C. 12.7 13.5 13.7 14.7 16.9 14.0 14.5 14.4 15.6 17.4 15.3 15.6 15.1 16.5 17.9 S.C. 12.6 11.6 10.0 9.8 8.0 14.0 13.6 11.6 11.5 9.0 15.3 15.6 13.2 13.2 10.0
KW 2.63 2.54 2.55 2.58 2.23 2.48 2.44 2.47 2.42 2.21 2.34 2.34 2.40 2.27 2.20
125 T.C. 12.1 12.4 12.6 13.4 15.8 13.2 13.4 13.2 14.4 16.3 14.3 14.4 13.9 15.5 16.8 S.C. 12.0 11.1 9.4 9.2 7.6 13.1 12.8 10.9 10.9 8.5 14.3 14.5 12.4 12.7 9.5
KW 3.10 2.97 3.00 3.04 2.53 2.89 2.83 2.88 2.81 2.51 2.69 2.68 2.77 2.58 2.49
NOTE: ALL CAPACITIES INCLUDE INDOOR FAN HEAT AT 1250 BTUH/1000 CFM.
Air Handlers Coils T.C. S.C. KW
– FC/MC/PC30 1.00 1.00 1.00
– FC/MC/PC32 1.01 1.00 1.00
– FC/MC/PC35 1.01 1.00 1.00
– FC/MC/PC36 1.01 1.00 1.00
– FC/MC/PC37 1.02 1.01 1.00
– HC36 1.01 1.00 1.00
– HD24 1.04 1.02 1.01
– UC24 1.01 1.00 1.00
– UC30 1.01 1.00 1.00
AHX18 – 1.01 1.04 0.95
AHX24 – 1.02 1.03 0.95
AHX30 – 1.03 1.06 0.95
AV*24 – 1.01 1.04 0.96
AV*36 – 1.06 1.10 0.97
F6FP018 – 0.99 1.00 0.97
F6FP024 – 1.03 1.04 0.98
F6FP030 – 1.03 1.05 0.98
MV12B FC/MC18B 1.00 0.98 0.93
MV12B FC/MC24B 1.02 1.02 0.93
MV12B FC/MC30B 1.02 1.02 0.93

556454-YTG-B-0410
Johnson Controls Unitary Products 19
Furnaces Coils T.C. S.C. KW
T*(8,L)X*A12 FC/MC/PC18A 0.98 0.98 0.94
T*(8,L)X*B12 FC/MC/PC18B 0.99 1.00 0.93
T*9X*B12 FC/MC/PC18B 0.99 1.02 0.93
T*(8,L)X*A12 FC/MC/PC24A 1.03 1.05 0.94
T*(8,L)X*B12 FC/MC/PC24B 1.02 1.04 0.94
T*9X*B12 FC/MC/PC24B 1.03 1.05 0.94
T*(8,L)X*A12 FC/MC/PC30A 1.03 1.05 0.94
T*(8,L)X*B12 FC/MC/PC30B 1.02 1.04 0.94
T*9X*B12 FC/MC/PC30B 1.03 1.05 0.94
T*(8,L)X*A12 FC/MC/PC32A 1.02 1.04 0.94
T*(8,L)X*A12 HD24 1.06 1.10 0.95
T*(8,L)X*B12 HD24 1.03 1.13 0.95
T*(8,L)X*C16 HD24 1.01 1.11 0.96
T*9X*B12 HD24 1.06 1.10 0.95
T*(8,L)X*A12 UC18A 1.01 1.02 0.94
T*(8,L)X*B12 UC18B 1.00 1.01 0.94
T*9X*B12 UC18B 1.01 1.02 0.94
T*(8,L)X*A12 UC24A 1.02 1.03 0.94
T*(8,L)X*B12 UC24B 1.02 1.03 0.94
T*9X*B12 UC24B 1.04 1.07 0.95
T*(8,L)X*A12 UC30A 1.02 1.03 0.94
T*(8,L)X*B12 UC30B 1.02 1.06 0.92
T*9X*B12 UC30B 1.04 1.07 0.95
(Y*(8,L)C/T*8V)*A12 FC/MC/PC18A 1.01 1.03 0.92
(Y*(8,L)C/T*8V)*B12 FC/MC/PC18B 0.99 1.01 0.91
Y*9C*B12 FC/MC/PC18B 1.01 1.03 0.91
(Y*(8,L)C/T*8V)*A12 FC/MC/PC24A 1.03 1.06 0.93
(Y*(8,L)C/T*8V)*B12 FC/MC/PC24B 1.02 1.03 0.91
Y*9C*B12 FC/MC/PC24B 1.03 1.06 0.92
(Y*(8,L)C/T*8V)*A12 FC/MC/PC30A 1.03 1.06 0.93
(Y*(8,L)C/T*8V)*B12 FC/MC/PC30B 1.02 1.03 0.91
Y*9C*B12 FC/MC/PC30B 1.03 1.06 0.92
(Y*(8,L)C/T*8V)*A12 FC/MC/PC32A 1.02 1.04 0.92
(Y*(8,L)C/T*8V)*B12 FC/MC/PC35B 1.03 1.06 0.92
Y*9C*B12 FC/MC/PC35B 1.02 1.02 0.91
(Y*(8,L)C/T*8V)*C16 FC/MC/PC35C 1.03 1.06 0.91
Y*9C*C16 FC/MC/PC35C 1.03 1.06 0.92
(Y*(8,L)C/T*8V)*A12 FC/MC/PC36A 1.04 1.06 0.93
(Y*(8,L)C/T*8V)*B12 FC/MC/PC36B 1.04 1.07 0.92
Y*9C*B12 FC/MC/PC36B 1.04 1.07 0.92
(Y*(8,L)C/T*8V)*C16 FC/MC/PC36C 1.04 1.07 0.91
Y*9C*C16 FC/MC/PC36C 1.04 1.07 0.91
(Y*(8,L)C/T*8V)*A12 FC/MC/PC37A 1.04 1.07 0.93
(Y*(8,L)C/T*8V)*A12 HC18 1.01 1.03 0.92
(Y*(8,L)C/T*8V)*A12 HC30 1.01 1.02 0.92
(Y*(8,L)C/T*8V)*B12 HC36 1.04 1.08 0.92
Y*9C*B12 HC36 1.02 1.02 0.91
(Y*(8,L)C/T*8V)*A12 HD24 1.06 1.10 0.93
(Y*(8,L)C/T*8V)*B12 HD24 1.06 1.06 0.91
Y*9C*B12 HD24 1.07 1.10 0.92
(Y*(8,L)C/T*8V)*A12 HD36 1.03 1.02 0.92
(Y*(8,L)C/T*8V)*B12 HD36 1.03 1.02 0.92
(Y*(8,L)C/T*8V)*C16 HD36 1.03 1.02 0.91
Y*9C*B12 HD36 1.03 1.02 0.92
Y*9C*C16 HD36 1.03 1.02 0.91
(Y*(8,L)C/T*8V)*A12 UC18A 1.01 1.04 0.92
(Y*(8,L)C/T*8V)*B12 UC18B 1.00 1.01 0.91
Y*9C*B12 UC18B 1.01 1.04 0.91
(Y*(8,L)C/T*8V)*A12 UC24A 1.03 1.06 0.92
(Y*(8,L)C/T*8V)*B12 UC24B 1.02 1.04 0.90
Y*9C*B12 UC24B 1.04 1.06 0.92
(Y*(8,L)C/T*8V)*A12 UC30A 1.03 1.06 0.92
(Y*(8,L)C/T*8V)*B12 UC30B 1.02 1.04 0.90
Y*9C*B12 UC30B 1.04 1.06 0.92
(Y*(8,L)C/T*8V)*A12 UC36A 1.01 1.06 0.91
(Y*(8,L)C/T*8V)*B12 UC36B 1.01 1.06 0.91
Y*9C*B12 UC36B 1.01 1.06 0.90
(Y*(8,L)C/T*8V)*C16 UC36C 0.99 1.02 0.89
Y*9C*C16 UC36C 0.99 1.02 0.89
Furnaces Coils T.C. S.C. KW

556454-YTG-B-0410
20 Johnson Controls Unitary Products
Multipliers for determining the performance with other indoor sections.
NOTE: For dry bulb temperatures different than those listed (between 73-87 F), sensible capacity increases by 1060 BTUH per 1000 CFM per degree above the listed
temperature and decreases by 1060 BTUH per 1000 CFM per degree below the listed temperature.
Continued on next page.
COOLING PERFORMANCE DATA
AIR CONDITIONER MODEL NO. TCHD24S41S3
INDOOR COIL MODEL NO. FC/MC/PC24
CONDENSING
ENTERING AIR
TEMPERATURE
IDCFM 600 800 1000
ID DB (°F) 80 80 75 80 80 80 80 75 80 80 80 80 75 80 80
ID WB (°F) 57 62 62 67 72 57 62 62 67 72 57 62 62 67 72
65 T.C. 19.8 23.1 22.5 24.9 29.0 22.4 23.8 23.6 25.9 29.9 25.0 24.6 24.8 27.0 30.9 S.C. 20.1 19.1 15.9 15.9 12.8 22.8 21.6 18.3 17.9 14.0 25.4 24.0 20.7 20.0 15.2
KW 1.32 1.32 1.34 1.36 1.36 1.35 1.32 1.35 1.37 1.34 1.37 1.33 1.36 1.38 1.33
75 T.C. 18.9 21.9 21.1 23.9 28.0 21.4 22.9 22.4 25.0 28.8 24.0 23.9 23.7 26.0 29.5 S.C. 19.2 18.7 15.4 15.5 12.3 21.8 21.2 17.9 17.5 13.6 24.4 23.7 20.3 19.6 14.9
KW 1.59 1.58 1.58 1.60 1.59 1.60 1.58 1.59 1.61 1.58 1.61 1.58 1.60 1.62 1.57
85 T.C. 18.0 20.8 19.6 23.0 27.0 20.5 22.0 21.1 24.0 27.6 23.0 23.2 22.6 25.0 28.2 S.C. 18.2 18.2 15.0 15.1 11.9 20.8 20.8 17.4 17.2 13.3 23.4 23.3 19.9 19.3 14.6
KW 1.85 1.85 1.83 1.84 1.82 1.85 1.85 1.84 1.85 1.82 1.85 1.84 1.84 1.86 1.81
95 T.C. 17.0 19.6 18.2 22.0 26.1 19.5 21.1 19.9 23.0 26.5 22.0 22.5 21.5 24.0 26.9 S.C. 17.3 17.8 14.5 14.7 11.4 19.8 20.4 17.0 16.8 12.9 22.4 22.9 19.5 18.9 14.4
KW 2.11 2.12 2.07 2.08 2.06 2.10 2.11 2.08 2.09 2.05 2.09 2.10 2.09 2.10 2.05
105 T.C. 16.2 18.8 17.8 21.7 25.4 18.6 20.1 19.1 22.4 25.6 21.1 21.4 20.4 23.1 25.8 S.C. 16.4 17.1 14.1 14.2 11.2 18.9 19.3 16.4 16.4 12.6 21.4 21.5 18.7 18.5 14.0
KW 2.51 2.57 2.48 2.41 2.37 2.44 2.49 2.46 2.40 2.37 2.38 2.41 2.45 2.39 2.37
115 T.C. 15.3 18.0 17.3 21.4 24.8 17.8 19.2 18.3 21.7 24.8 20.3 20.3 19.3 22.1 24.8 S.C. 15.5 16.4 13.6 13.8 10.9 17.9 18.3 15.8 15.9 12.3 20.4 20.1 18.0 18.1 13.7
KW 2.89 3.01 2.87 2.72 2.67 2.78 2.87 2.84 2.69 2.67 2.67 2.72 2.81 2.66 2.67
125 T.C. 14.4 17.2 16.9 21.1 24.2 16.9 18.2 17.6 21.1 24.0 19.4 19.2 18.3 21.2 23.7 S.C. 14.6 15.8 13.2 13.3 10.7 17.0 17.3 15.2 15.5 12.0 19.4 18.8 17.2 17.7 13.3
KW 3.28 3.46 3.27 3.04 2.98 3.12 3.24 3.22 2.99 2.98 2.95 3.03 3.17 2.94 2.98
NOTE: ALL CAPACITIES INCLUDE INDOOR FAN HEAT AT 1250 BTUH/1000 CFM.
Air Handlers Coils T.C. S.C. KW
– FC/MC/PC30 1.00 1.00 1.00
– FC/MC/PC32 1.00 1.01 1.00
– FC/MC/PC35 1.00 1.01 1.00
– FC/MC/PC36 1.00 1.01 1.00
– FC/MC/PC37 1.03 1.03 1.01
– FC/MC/PC43 1.03 1.03 1.01
– HC30 0.99 0.99 0.99
– HC36 1.00 1.01 1.00
– HC42 1.03 1.03 1.01
– UC24 1.00 1.01 1.00
– UC30 1.00 1.01 1.00
AHP24 – 1.00 1.00 1.00
AHX18 – 1.01 1.02 0.96
AHX24 – 1.03 1.03 0.89
AHX30 – 1.03 1.06 0.89
AHX36 – 1.05 1.08 0.94
AV*24 – 1.01 1.02 0.94
AV*36 – 1.03 1.02 0.93
F*FP030 – 1.00 0.99 1.00
F6FP024 – 1.02 1.04 0.97
F6FP030 – 1.02 1.04 0.99
F6FP036 – 1.03 1.07 0.97
MV12B FC/MC24B 1.03 1.02 0.92
MV12B FC/MC30B 1.03 1.02 0.92
MV12B FC/MC35B 1.03 1.03 0.93
MV16C FC/MC35C 1.03 1.03 0.93
MV12B FC/MC36B 1.03 1.04 0.93
MV16C FC/MC36C 1.03 1.04 0.93
MV12B FC/MC43B 1.05 1.05 0.93
MV16C FC/MC43C 1.05 1.05 0.92
Air Handlers Coils T.C. S.C. KW
