York 110 User manual

22DEC2011
ACTIVE
110
Owner’s Manual
www.yorkfitness.com
Active 110 Cross Trainer
52047

www.yorkfitness.com
2
Congratulations on
purchasing your exercise
equipment from
You have chosen a high quality, safe and
innovative piece of equipment as your training
partner and we are certain it will keep you
motivated on the way to achieving your
personal fitness goals.
Please take the time to read this owner’s
manual as it will help you to get the most out
of your new exercise equipment.
For more information visit www.yorkfitness.com
Protect the environment by not disposing
of this product or batteries with household
waste. Check your local authority for
recycling advice and facilities.
CONTENTS
Safety information 03
Customer support 04
Care & Maintenance 05
Assembly instructions 05
Operational instructions 10
Troubleshooting 13
Fitness guide 14
Exploded drawing 16
Part list 17
Table of contents

www.yorkfitness.com
www.yorkfitness.com
3
Safety information
Please read this instruction manual before you
begin assembly. Great care has been taken
to design these instructions and following
them will help you with quicker assembly and
minimize the risk of injury.
It is important that you keep these instructions
for future reference.
This list is not exhaustive - You are responsible
for your own safety!
• Alwaysassembleandoperatetheequipmentona
levelsurface.
• Ensuretheequipmentisstablebeforeuse.
• Alwaysensurethattheequipmenthasadequate
spaceoneachside.
• Ensurethattheseatheightisadjustedcorrectly.You
shouldbestableandbalancedwhileonthesaddle.
• Adjusttheseatheighttoensurethatyouhavea
gooddownwardpedalstrokewithoutoverstretching,
don’tcompromiseyourbalance.
• Trytoensurethatyourbackisstraightwhile
exercising,especiallyforlongperiods.
• Thesafetylevelofthisequipmentcanonlybe
maintainedifitisregularlyexaminedforwearand
tear.
• Replacedefectivecomponentsimmediatelyand
keeptheequipmentoutofuseuntilitisrepaired.
• Useonlytheadjustmentsettingasdescribedinthe
instructions.Alwaysusethecorrectadjustmentpin
/xing.
• Alwayscheckthatanypins/xingsaretightand
securebeforeuseandafteradjustment.
• Neverleaveanyadjustmentdevicesprojectingfrom
theequipment.
• Alwaysconsultyourdoctorbeforeundertakingany
exerciseprogram.
• Alwayswearsuitableclothingandfootwear.(e.g.
tracksuit/shorts/trainingshoes)
• Removeallpersonaljewelrybeforeexercising.
• Ensureyouwarm-upwellbeforeusingthe
equipmentasthiswillhelptopreventmusclestrain.
• Aftereating,allow1-2hoursbeforeexercisingas
thiswillhelptopreventmusclestrain.
• Neveroverloadtheequipment.(Seemaximumuser
weight)
• Neverusetheequipmentinanyothermannerother
thanthewaysexplainedintheseinstructionsand
anywall-chartsupplied.
• Injuriestohealthmayresultfromincorrector
excessivetraining.
• Parentsandothersinchargeofchildrenshouldbe
awareoftheirresponsibility,becausethenatural
playinstinctandthefondnessofexperimenting
ofchildrencanleadtosituationsandbehaviorfor
whichthetrainingequipmentisnotintended.
• Ifchildrenareallowedtousetheequipment,their
mentalandphysicaldevelopmentandabovealltheir
temperamentshouldbetakenintoaccount.They
shouldbecontrolledandinstructedinthecorrect
useoftheequipment.
• Theequipmentisundernocircumstancessuitable
asachildren’stoy.
• Childrenshouldnotbeallowedonoraroundthe
equipment,especiallywhenitisnotinuse.
• Thisapplianceisnotintendedforusebypersons
(includingchildren)withreducedphysical,sensory
ormentalcapabilities,orlackofexperienceand
knowledge,unlesstheyhavebeengivensupervision
orinstructionconcerninguseoftheappliancebya
personresponsiblefortheirsafety.
• Thisproductisnotsuitablefortherapeuticpurposes.
• Thisproducthasanintegratedspeedindependent
brakingsystemwithoutaconstantpowermodethat
isgovernedbymagneticresistance.
• Thisproducthasbeentestedforuseinahome
environmentandiswarrantedforInHome,personal,
familyorhouseholduse.
• Duetoourcontinuouspolicyofproduct
development,YorkFitnessreservestherightto
changespecicationswithoutnotice.
CAUTION! The instructions must be followed carefully in
the assembly, use and maintenance of your equipment.
The warranty does not cover damage due to negligence
of the assembly, adjustment and maintenance
instructions described herein.
Maximum user weight: 110kg
Safety Standards
This equipment meets the requirements of the EU’s EMC
and Low Voltage directives (where applicable), EN957
1 & 9 - CLASS HC. Therefore the equipment carries the
following marks:

www.yorkfitness.com
4
Customer support
Customer Support
Should you require any assistance regarding this product please gather the following information and then contact us
using the details below:
• SerialNo.-Thiscanbefoundonthestickerbelow,locatedasindicated.
• Originalpurchasedate
• Placeofpurchase
• Informationabouttheplaceandconditionsofuse
• Precisedescriptionoftheissue/defect
IMPORTANT!! - Please retain your sales receipt, York Fitness Customer Care may request
proof of purchase to validate eligibility for warranty service. Warranty cover starts from the
date shown on the proof of purchase.
Contact Us
ENGLAND
The best way to contact us is via the website:
www.yorkfitness.com
York Barbell UK Ltd.
York Way, Daventry,
England, NN11 4YB
Tel: [phone]
AUSTRALIA
The best way to contact us is via the website:
www.yorkfitness.com.au
York Fitness Australia
1/2 Swaffham Rd, Minto,
PO Box 5130, NSW 2566
Tel: [phone]
Use only on a level surface
Not suitable for therapeutic purpose
Manufacturer: YORK BARBELL
Contact: www.yorkfitness.com
Product Name: YORK ACTIVE 110 CROSS TRAINER
Max User Weight: 110KG
Safety Standards: EN957 1 & 9 - Class HC
Electrical info: 2 x AA batteries
SERIAL NO: 52047-
Product’s Name
Serial Number
This product label is an example only, it is not the
real product name and serial number of the item
you have bought. Underside of the
main body.
ACTIVE
110

www.yorkfitness.com
www.yorkfitness.com
5
Assembly instructions
F10 x 2
ALLEN BOLT
(M8 X P1.25 X 45MM)
F1 x 8
CURVED WASHER
(Ø8 X Ø19 X 2T)
F11 x 4
CARRIAGE BOLT
(M8 X P1.25 X 75MM)
F3 x 4
CARRIAGE BOLT
(M8 X P1.25 X 35MM)
F2 x 10
ACORN NUT
(M8)
F7 x 6 F4 x 2
F9 x 2
REGULAR WASHER
(Ø8 X Ø16 X 1T)
SCREWDRIVER
BOX SPANNER
ALLEN KEY ALLEN KEY
WRENCH
F5 x 6
ALLEN BOLT
(M6 X 40MM)
F6 x 6
FLAT WASHER
(Ø6 X Ø16 X 2T)
F8 x 6
SPRING WASHER
(Ø6)
• Prepare your work area-Itisimportantyouassembletheproductinacleanandunclutteredspace.
• Work with a friend-Werecommendyouhavesomeoneassistyouwiththeassemblyas
someofthecomponentsarequiteheavy.
• Open the carton -Checkanywarningsonthecartonandmakesureyouhaveittherightwayup.
• Unpack the carton-Removeallthepartsandlaythemoutontheoor.
Make sure you have the following parts:
Care & Maintenance
• This equipment should not be placed outdoors, in a garage or an outbuilding. Keep the
equipment in a dry place with as little temperature variation as possible.
• We recommend placing a mat beneath the equipment to protect both the equipment and
your flooring.
• Alwaysplacetheequipmentinadryenvironment.
• Useawarm,dampclothtokeeptheproductclean.
• Nowetcleaningofelectricalcomponents.Unplugbeforeanycareandmaintenance.
• Thesafetyleveloftheequipmentcanbemaintainedonlyifitisregularlyexaminedfor
damageandwear.Thisincludesanyropes,pulleys,nuts,bolts,movingparts,bushes,
chains,wheels,bearings&connectionpointsetc.
• Ensurethatyouinspecttheproductregularly-atleastonceaweekisrecommended.
• Ensurethatallxingsaretightbeforeuse.
• Alwaysreplacedamaged/worncomponentswithoriginalpartsfromthemanufacturer.

www.yorkfitness.com
6
D
11
22
3 3
D9
F11
F1
F2
J3
I2
F1 x 4 F11 x 4 F2 x 4
STEP 2
STEP 1
Assembly instructions

www.yorkfitness.com
www.yorkfitness.com
7
B
B9
F2
F1
F4
B4
B7
B6
B5
F1 x 4 F3 x 4 F2 x 4
F4
C9
C2
C10
F10
F9
1
2
3
4
F2
C7
C8
F10 x 2 F2 x 2 F4 x 2
Parts pre-installed on post
F9 x 2
STEP 4
STEP 3

www.yorkfitness.com
8
A1
A
INSTALLED BEHIND CONSOLE
F5
F8
F6
F7
F7 x 6
F5 x 6 F6 x 6 F8 x 6
STEP 6
STEP 5
Assembly instructions

www.yorkfitness.com
www.yorkfitness.com
9
Final Check
Your cross trainer is now assembled.
Please make the following final checks:
• Makesureallscrews/boltsaretightened.
• Makesuretheequipmentisonaat,levelsurface.
ACTIVE
110

www.yorkfitness.com
10
Console:
Operational instructions
RPM SPEED
RESET
RECOVERY
SET
MODE
TIME DISTANCE CALORIES PULSE
BATTERIES REPLACEMENT INSTRUCTIONS:
1. Removethemeterfromthecrosstrainer.
2. Openthebatterycompartmentcover.
3. Removebatterybypullingthebatteryindirectionofspringandlift
oppositeendupwards.
4. Insert2AAbatteriesensuringyoumatchthepolaritymarkings
(+and-)onthebatterieswiththeindicatorsinthebattery
compartment.Pushatend(-)againstspringandwhenclearpush
otherendintoholder.
5. Closethebatterycompartment.
Tips & Warnings
• Alwayschangebothbatteriesatthesametime.
• Alwaysusethesametypeofbatteries.
• NeverrechargeAlkalineAAbatteries.
• Donottrytoheat,ignite,disassembleorthrowAAbatteriesintoare.
• Donotleaveoldbatteriesintheconsole,andremovebatteriesfrom
theconsoleifyouwon’tbeusingitforalongtime.
Protect the environment by not disposing
of this product or batteries with household
waste. Check your local authority for
recycling advice and facilities.

www.yorkfitness.com
www.yorkfitness.com
11
Key Function:
KEYS FUNCTIONS
MODE Press “MODE” button to select an option.
SET To select a value during setup. You can hold the button to increase the
value faster. (The computer has to be in stop condition)
RESET The user may press “RESET” button to reset each function or hold on for
2 seconds to reset all functions.
RECOVERY Press the key to activate heart rate recovery function.
Display:
DISPLAY DESCRIPTION
SCAN Display all functions from RPM > SPEED > DISTANCE > CALORIES > PULSE
RPM Displays the Rotation Per Minute. The RPM and SPEED will switch every 6
seconds during workout.
SPEED Displays the current training speed. Maximum speed is 99.9KM/H.
TIME Without a preset target, it will display the time exercised during your
workout. In target mode, it will display the value left to your preset target.
DISTANCE Without a preset target, it will display the distance traveled during your
workout. In target mode, it will display the value left to your preset target.
CALORIE Without a preset target, it will display the calories burned during your
workout. In target mode, it will display the value left to your preset target.
PULSE Displays your pulse rate in beats per minute during your workout.
TEMPERATURE Displays the current room temperature
CALENDAR Displays the current date
CLOCK Displays the current time
Program select and setting Value
1. UsetheMODEbuttontoselectafunction:RPM > SPEED > DISTANCE > CALORIES > PULSE
2. UsetheSETbuttontoselectavalue.
3. PressMODEagaintoconrmvalueandskiptonextfunction.
4. Thecountdownwillbeginwhenyoustartpedalling.
5. Whenyoureachthetarget,thecomputerwillproducebeepsoundsandthenstop.
Wake-Up Function
The monitor will entry SLEEP mode (LCD off) when there is no signal input and no key be pressed
after 4 minutes. Press the screen to start the monitor.

www.yorkfitness.com
12
Hand Pulse Sensors
This cross trainer is fitted with 2 hand pulse
sensors. To obtain a pulse reading you must
have both your left and right hands on the
sensors at the same time. Do not grip the hand
sensors too tight and allow the computer a few
seconds to display the reading.
Adjusting The Resistance
This cross trainer features a speed independent
braking (resistance) system. The resistance is
controlled by a magnet, which is moved closer
or further away from the flywheel - the closer
the magnet is to the flywheel the higher the
resistance.
Levelling Your Cross Trainer
To help you level the cross trainer on uneven
surface, 2 height adjusters are included on the
rear stabilizers. Simply twist these around to
adjust the height of the cross trainer.
Operational instructions
ACTIVE
110
Hand Pulse Sensor
ACTIVE
110
Resistance Level
ACTIVE
110

www.yorkfitness.com
www.yorkfitness.com
13
If you have a problem with your cross trainer, before you do anything else please check that all
the cables have been connected correctly. Loose cables are very common and many problems
can be solved by making sure the cables are properly connected.
The following table details the most common problems and how to fix them. If you still have a problem
after going through the troubleshooting guide please call your local YORK distributor for advice.
PROBLEM CAUSE CORRECTION
NO DISPLAY
No power Make sure power cord is plugged in
properly
System halted Unplug and re-plug the power cord to reset
the system
NO SPEED DISPLAY Wires are damaged or not connected properly Verify all wires are connected properly
Speed sensor is too far from magnet Contact your local YORK distributor
PARTIAL DISPLAY The PA board is not connected properly
Unplug and re-plug the power cord
Verify all wires are connected properly
Disconnect and re-connect all cables
Contact your local YORK distributor
NO PULSE SIGNAL
Wires are damaged or not connected
properly Verify all wires are connected properly
Too much hand movement Dry palms
Palms too wet Grip using moderate pressure
Hand Pulse Sensor is being gripped too tightly Remove all rings
User is wearing rings Contact your local YORK distributor
FOR YOUR OWN SAFETY, DO NOT OPEN PROTECTIVE CASING. IF ERROR PERSIST,
PLEASE CONTACT YOUR LOCAL YORK DISTRIBUTOR FOR ADVICE. KEEP THE
EQUIPMENT OUT OF USE UNTIL IT IS REPAIRED.
If you are having problems with your heart rate reading, please note that some fibres used in
clothes eg) polyester, create static electricity that may prevent a reliable heart rate reading. Mobile
phones, TV’s, microwaves and other electrical appliances that generate an electromagnetic field
may also interfere with heart rate measurement.
Troubleshooting

www.yorkfitness.com
14
Fitness guide
Starting and Finishing Your Workout
Begin and end each workout with a Warm Up / Down session - a few minutes of stretching to
help prevent strains, pulls and cramps.
Correct Cross-training form
To start using the cross trainer, simply stand on the foot pedals with the front of your shoes close
to the front edge of the pedal cap. Place your hands at a comfortable position on the handlebars.
Simply move your highest foot forward and follow the natural path of the machine.
Start on a load level that is comfortable to familiarize yourself with the machine. Once you are
comfortable, start adjusting the load level to achieve the workout desired.
Forward and Reverse: The cross trainer can be used in the forward and reverse direction to vary
the muscles that you workout. This will also vary your workout helping you to stay motivated. To
change directions, simply slow the pedals down until they stop and switch directions.
Load Level Adjustment: The load level of cross trainer can be changed at any time during your
workout. Adjusting your load level will allow you to increase or decrease your intensity level.
Suggested Stretches
The correct form for several basic stretches is shown at the right. Move slowly as you stretch—
never bounce.
1. Hamstring Stretch
Sit with one leg
extended. Bring the
sole of the opposite
foot toward you and
rest it against the inner
thigh of your extended
leg. Reach toward your
toes as far as possible.
Hold for 15 counts, then
relax. Repeat 3 times
for each leg. Stretches:
Hamstrings, lower back
and groin.
2. Calf/Achilles Stretch
With one leg in front of
the other, reach forward
and place your hands
against a wall. Keep your
back leg straight and
your back foot flat on the
floor. Bend your front leg,
lean forward and move
your hips toward the wall.
Hold for 15 counts, then
relax. Repeat 3 times for
each leg. To cause further
stretching of the achilles
tendons, bend your back
leg as well. Stretches:
Calves, achilles tendons
and ankles.
3. Quadriceps Stretch
With one hand against a
wall for balance, reach
back and grasp one foot
with your other hand. Bring
your heel as close to your
buttocks as possible. Hold
for 15 counts, then relax.
Repeat 3 times for each
leg. Stretches: Quadriceps
and hip muscles.
4. Inner Thigh Stretch
Sit with the soles of your
feet together and your
knees outward. Pull your
feet toward your groin
area as far as possible.
Hold for 15 counts, then
relax. Repeat 3 times.
Stretches: Quadriceps
and hip muscles.

www.yorkfitness.com
www.yorkfitness.com
15
How Long Should I Exercise For?
That really depends on your current level of fitness. If you’re just starting out on a new exercise
program, you should start gradually and build up - do not try to do too much too quickly. 30
minutes, 3 times a week should be enough.
Don’t push yourself too hard - you should never feel exhausted during or following exercise.
Heart Rate Training
To get the most out of your new piece of fitness equipment and see the best results from your
training you should exercise at the right level of effort, and that means listening to your heart!
Working out to a target heart rate means you can direct your workout to achieve different goals:
Good health - For those wishing to improve quality of life and general well being. Your sessions
will need to be done at an intensity of between 50 - 60% of your estimated maximum heart rate,
should last about 30 minutes and can be done on most days of the week.
Weight loss - To see a significant reduction in body fat, your sessions must be a little more intense
- between 60 and 70% of your estimated maximum heart rate. These sessions can also be
performed on most days of the week for up to 30 minutes.
Improving fitness levels - These sessions should be performed at 70 - 80% of your estimated
maximum heart rate and can also involve bouts of interval training that would have your heart rate
peaking for short times near your maximum heart rate level. These are intense sessions and will
require at least a 48 hour rest between sessions.
Calculating Your Target Heart Rate
First, you need to find your estimated maximum heart rate using the formula “220 minus your age
in years”. So, if you are 35 years old your estimated maximum heart rate is:
220 - 35 = 185 beats per minute (bpm)
Next, to calculate your target heart rate, simply multiply your estimated maximum heart rate
(185bpm) by the applicable percentage. So, if your goal is better health:
185 x 60% = 111bpm
NOTE: The important issue to remember with all estimated calculations is that they are just
estimates - if you don’t feel comfortable exercising at your target then reduce it to a level
you are comfortable with.
Heart rate training requires you to monitor your heart rate throughout the workout. For this we
recommend using a chest strap (if your machine has a wireless receiver) or a heart rate monitor.
For more information please get in touch using the Contact Us details.
ALWAYS CONSULT YOUR DOCTOR BEFORE UNDERTAKING A NEW EXERCISE REGIME.
IF YOU EXPERIENCE NAUSEA, DIZZINESS OR OTHER ABNORMAL SYMPTOMS DURING
EXERCISE, STOP AT ONCE AND CONSULT YOUR DOCTOR.

www.yorkfitness.com
16
B-1
B
B-2
B-3
B-4 B-5
B-6
B-7
B-12
C-1
C-7
C-9
C-8
C-10
C-2
C-3
C-4
C-5
A
A-1
B-8
B-9
B-11
B-10 F-4
F-1
F-2 F-3
C-6
D
D-1
D-7
D-8
F-10
F-9
F-5
F-6
F-7
F-8
D-6
D-2
D-5
D-4
D-3
F-11
E
E-1 E-2
E-3
E-4
E-5
E-6
E-7
E-9
E-8
E-10
E-11
E-12
E-13
E-14
E-15
E-16
E-17
E-18
F-2
F-1
F-2
I-1
I-2
J-3
J-2
J-1
E-19
E-20
H-1
H-6
H-5
H-7
H-3 H-4
H-2
H-8
G
G-1
G-2
G-3
G-4
G-5
G-6
Exploded drawing

www.yorkfitness.com
www.yorkfitness.com
17
Part list
YORK REF. REF. DESCRIPTION QTY.
52047-1 A CONSOLE 1
52047-2 A-1 SCREW (M5 X 10) 4
52047-3 B FRONT HANDELBAR 1
52047-4 B-1 SCREW (M3 X 20L) 2
52047-5 B-2 FOAM GRIP 2
52047-6 B-3 HAND PULSE SENSOR 2
52047-7 B-4 HAND PULSE SENSOR WIRE 1
52047-8 B-5 SENSOR WIRE, UPPER 1
52047-9 B-6 HEX HEAD SCREW (M8 X P1.25 X 16L) 3
52047-10 B-7 SEMI-CIRCULAR WASHER (Ø8 X Ø19 X 2T) 3
52047-11 B-8 END CAP 2
52047-12 B-9 UPPER HANDLEBAR SET 2
52047-13 B-10 FOAM GRIP 2
52047-14 B-11 UPPER HANDLEBAR 2
52047-15 B-12 END CAP 2
52047-16 C-1 HANDLEBAR POST 1
52047-17 C-2 TENSION CONTROLLER, UPPER 1
52047-18 C-3 CURVED WASHER (Ø17.5 X Ø25 X 0.3T) 2
52047-19 C-4 FLAT WASHER (Ø10 X Ø26 X 2T) 2
52047-20 C-5 NYLOC SCREW (M8 X P1.0 X 20L) 2
52047-21 C-6 LOWER HANDLEBAR 2
52047-22 C-7 SPRING WASHER(Ø8.1 X Ø12.9 X 2.4T) 4
52047-23 C-8 SEMI-CIRCULAR WASHER 4
52047-24 C-9 HEX HEAD SCREW (M8 X P1.25 X 16L) 4
52047-25 C-10 SENSOR WIRE, LOWER 1
52047-26 D-R PEDAL ARM, RIGHT 1
52047-27 D-L PEDAL ARM, LEFT 1
52047-28 D-1R/L PEDAL, PAIR 2
52047-29 D-2 NYLON NUT (9/16” X 6T) 1
52047-30 D-3 C-CLIP (Ø17) 4
52047-31 D-4 FLAT WASHER (Ø17.5 X Ø25 X 0.3T) 2
52047-32 D-5 CRANK PIN, LEFT 1
52047-33 D-6 CRANK PIN, RIGHT 1
52047-34 D-7 END CAP 2
52047-35 D-8 NYLON NUT (9/16” X 6T) 1
52047-36 E FRAME 1
52047-37 E-1 SENSOR HOLDER 1
52047-38 E-2 SCREW (M4 X 10L) 1
52047-39 E-3 C-CLIP (Ø20) 1
52047-40 E-4 CURVED WASHER (Ø20 X Ø30 X 0.3T) 1
52047-41 E-5 FLAT WASHER (Ø20.3 X Ø30 X 1T) 1
52047-42 E-6 BEARING (6004RS PLASTIC) 2
52047-43 E-7 DRIVE PULLEY 1
52047-44 E-8 BUSHING (Ø20.5 X Ø25 X 7.5MM) 1
52047-45 E-9 AXLE 1
YORK REF. REF. DESCRIPTION QTY.
52047-46 E-10 HEX SCREW (M8 X P1.25 X 12L X 5T) 3
52047-47 E-11 DRIVE BELT 1
52047-48 E-12 CRANK, RIGHT 1
52047-49 E-13 PATTERN NUT (M10 X P1.25 X 10T) 2
52047-50 E-14 SIDE COVER, RIGHT 1
52047-51 E-15 SCREW (3/16” X 3/4”) 6
52047-52 E-16 SIDE COVER, LEFT 1
52047-53 E-17 SCREW (M4 X 50L) 5
52047-54 E-18 CRANK, LEFT 1
52047-55 E-19 TENSION CONTROLLER, LOWER 1
52047-56 E-20 SPEED SENSOR 1
52047-57 F HARDWARE PACK (F-1~F-11) 1
52047-58 F-1 SEMI-CIRCULAR WASHER (Ø8 X Ø19 X 2T) 8
52047-59 F-2 ACRON NUT (M8) 10
52047-60 F-3 CARRIAGE BOLT (M8 X P1.25 X 35L) 4
52047-61 F-4 SCREW COVER 2
52047-62 F-5 HEX HEAD SCREW (M6 X P1.0 X 40L) 6
52047-63 F-6 FLAT WASHER (Ø6 X Ø16 X 2T) 6
52047-64 F-7 LOCKING KNOB 6
52047-65 F-8 SPRING WASHER (Ø6) 6
52047-66 F-9 FLAT WASHER (Ø8 X Ø16 X 1T) 2
52047-67 F-10 HEX HEAD SCREW (M8 X P1.25 X 45L) 2
52047-68 F-11 CARRIAGE BOLT (M8 X P1.25 X 75L) 4
52047-69 G MAGNET BRACKET (G-1~G-6) 1
52047-70 G-1 HEX SCREW (M6 X P1.0 X 16L) 2
52047-71 G-2 SPRING WASHER (Ø6) 2
52047-72 G-3 FLAT WASHER (Ø6 X Ø13 X 1T) 2
52047-73 G-4 C-CLIP (Ø12) 2
52047-74 G-5 CURVED WASHER (Ø12.5 X Ø18 X 0.3T) 2
52047-75 G-6 SPRING (Ø12 X Ø1.4 X 9T) 1
52047-76 H FLYWHEEL SET 1
52047-77 H-1 NUT (3/8” X -26 X 4.5T) 3
52047-78 H-2 PATTERN NUT (3/8” X -26 X 7T) 2
52047-79 H-3 FLYWHEEL AXLE 1
52047-80 H-4 FLAT WASHER (Ø10 X Ø14 X 1T) 1
52047-81 H-5 BEARING (6000RS PLASTIC) 1
52047-82 H-6 BEARING (6300RS PLASTIC) 1
52047-83 H-8 BUSHING (Ø10 X Ø14 X 6MM) 1
52047-84 I-1 REAR STABILIZER END CAP 2
52047-85 I-2 REAR STABILIZER 2
52047-86 J-1 END CAP W/ TRANSPORT WHEEL 2
52047-87 J-2 SCREW (M3 X 8) 2
52047-88 J-3 FRONT STABILIZER 1
52047-89 FIXING BLISTER PACK 1

www.yorkfitness.com
