York R51 User manual

ENGLISH
OWNER’S MANUAL
YDS-R51-0408
REMOTE CONTROLLER R51
Please read this installation manual carefully before installing your air conditioner.
Please keep this manual in a safe place for future reference.
This manual many be subject to change without notice for purpose of improvement.

CONTENTS
RemoteControllerSpecifications---------------------------------------
PerformanceFeatures-----------------------------------------------------
IntroductionofFunctionButtonsontheRemoteController---
NamesandFunctionsofindicatorsonRemoteController----
OperatingtheRemoteController---------------------------------------
Warning--------------------------------------------------------------------------
1
1
1
3
4
7

1
Model
R51,R51/BG,R51/E,R51/CE,R51/BGE,R51/CBGE
Environment
TemperatureRange
ReachingDistance
LowestVoltageofCPU
EmittingSignal
RatedVoltage
-5C60C
。。
8m(whenusing3.0voltage,itGets11m)
3.0V
2.0V
RemoteControllerSpecifications
PerformanceFeatures
IntroductionofFunctionButtonsontheRemoteController
1.OperatingMode:COOLHEATDRYFANandAUTO.
2.TimerSettingFunctionin24hours.
3.IndoorSettingTemperatureRange:17C~30C.
4.LCD(LiquidCrystalDisplay)ofallfunctions.
5.NightLightFunction(onlyR51/BGmodelavailable)
6.CompatiblewiththeformerR11.
、、、
。。
CANCEL
LOCK
1
Fig.1
SETTEMPERATURE
AUTO
COOL
DRY
HEAT
FAN
HIGH
MED
LOW
。
C
TEMP
MODE
SWING TIMER
RESET
ON/OFF FANSPEED
2
3
4
5
6
7
8
9
10
ECONOMICRUNNING
11
VENT
12
Note:Thisillustrationisforexplanationpurposesonly.Theactual
shapeorbuttonnamesoftheremotecontrollermaybeslightly
different.

2
TEMPButton: PushtheTEMPbuttontodecreasetheindoor
temperaturesettingortoadjusttheTIMERinacounter-clockwise
direction.
MODESelectButton: Eachtimeyoupushthebutton,amodeis
selectedinasequencethatgoesfromAUTOCOOLDRY
HEATandFANasthefollowingfigureindicates:
、、、
SWINGButton: Pushthisswitchbuttontochangethelouver
angle.
RESETButton: WhentheRESETbuttonispushed,allofthecurrent
settingsarecancelledandthecontrolwillreturntotheinitialsettings.
NOTE: HEATonlyforHeatPump
AUTO(COOL) COOL DRY HEAT FAN
LOCKButton: Pushthisbuttontolockinallthecurrentsettings.To
releasesettings,pushagain.
CANCELButton: PushthisbuttontocanceltheTIMERsettings.
TIMERButton: ThisbuttonisusedtopresetthetimeON(start
tooperate)andthetimeOFF(turnofftheoperation).
ON/OFFButton: Pushthisbuttontostarttheunitoperation.Push
thebuttonagaintostoptheunitoperation.
FANSPEEDButton: ThisbuttonisusedforsettingFanSpeedin
thesequencethatgoesfromAUTOLOWMEDtoHIGH,then
backtoAuto.
、、
TEMPButton: Pushthebuttontoincreasetheindoortemperature
settingortoadjusttheTIMERinaclockwisedirection.
VENTButton: Pushthisbuttontosettheventilatingmode.The
ventilatingmodewilloperateinthefollowingsequence:
Auto OffContinuous
VentilationFunctionisavailablefortheFreshStarSeries.
1
2
3
4
5
6
7
8
9
10
11
ECONOMICRUNNINGButton: Pushthisbuttontogointothe
Energy-Savingoperationmode.
12

3
NamesandFunctionsofindicatorsonRemoteController
TRANSMISSIONIndicator: Thisindicatorlightswhenremote
controllertransmitssignalstoindoorunit.
MODEDisplay: Showsthecurrentoperationmodes--AUTO,
COOL,DRYandHEAT.HEATonlyavailableforheatpumpmodel.
HEATPUMPONLY-LOCKdisplay isdisplayedbypushingtheLOCK
button.PushtheLOCKbuttonagaintocleardisplay.
TIMERDisplay: ThisdisplayareashowsthesettingsofTIMER.
Thatis,ifonlythestartingtimeofoperationisset,itwilldisplaythe
TIMERON.Ifonlytheturningofftimeofoperationisset,itwilldisplay
theTIMEROFF.Ifbothoperationsareset,itwillshowTIMERONOFF
whichindicatesyouhavechosentosetboththestartingtimeandoff
time.
FANDisplay: WhentheFANbuttonispushed,thissignalindicatorlights.
DigitalDisplayArea: Thisareawillshowthetemperatureand,ifinthe
TIMERmode,willshowtheONandOFFsettingsoftheTIMER.
NOTE: AllitemsareshownintheFig.2forthepurposeofclear
presentationButduringtheactualoperationonlythere-
lativefunctionalitemsareshownonthedisplaypanel.
DisplayPanel
Fig.2
AUTO
COOL
DRY
HEAT
1 6
2
1
2
3
4
5
6
3 4
5
FAN
HIGH
MED
LOW

4
OperatingtheRemoteController
TheRemoteControllerusestwoalkalinedrybatteries(R03/Ir03X2).
WhentheAirConditionerisreadyforuse,switchonthepower
andtheOPERATIONindicatorlamponthedisplaypanelofthe
indoorunitstartsflashing.
1.UsetheMODEselectbuttontoselectAUTO.INthemultisystem,
toavoidmodeconflict,auto-modeistakenascoolmode.
2.PushtheTEMPbuttontosetthedesiredroomtemperature.
Themostcomfortabletemperaturesettingsarebetween21C
to28C.
3.PushtheON/OFFbuttontostarttheairconditioner.TheOPE-
RATIONlamponthedisplaypaneloftheindoorunitlights.The
operatingmodeofAUTOFANSPEEDisautomaticallysetand
therearenoindicatorsshownonthedisplaypaneloftheremote
controller.
4.PushtheON/OFFbuttonagaintostoptheunitoperation.
。
。
1.Toinstallbatteries,slidebackthecoverofthebatterycompartment
andinstallthebatteriesaccordingtothedirections(+and-)shown
ontheRemoteController.
2.Toreplacetheoldbatteries,usethesamemethodasmentioned
above.
1.Whenreplacingbatteries,donotuseoldbatteriesoradifferent
typebattery.Thismaycausetheremotecontrollerto
malfunction.
2.Ifyoudonotusetheremotecontrollerforseveralweeks
removethebatteries.Otherwisebatteryleakagemaydamage
theremotecontroller.
3.Theaveragebatterylifeundernormaluseisabout6months.
4.Replacethebatterieswhenthereisnoansweringbeepfromthe
indoorunitoriftheTransmissionIndicatorlightfailstoappear.
1.IntheAUTOmode,theairconditionercanlogicallychoose
themodeofCOOL,FAN,HEATandDRYbysensingthedif-
ferencebetweentheactualambientroomtemperatureand
thesettemperatureontheremotecontroller..
2.IftheAUTOmodeisnotcomfortableforyou,thedesiredmode
canbeselectedmanually.
Install/ReplaceBatteries
AUTOMATICOPERATION
NOTE
NOTE

5
1.IftheAUTOmodeisnotcomfortable,youmaymanuallyoverride
thesettingsbyusingCOOL,DRY,HEAT(HEATPUMPunitsonly),
orFANONLYmodes.
2.PushtheTEMPbuttontosetthedesiredroomtemperature.
WheninCOOLINGmode,themostcomfortablesettingsare21C
orabove.WheninHEATINGmode,themostcomfortablesettings
are28Corbelow.
3.PushtheFANSPEEDtoselecttheFANmodeofAUTO,HIGH,
MEDorLOW.
4.PushtheON/OFFbutton.Theoperationlamplightsandtheair
conditionerstartstooperateperyoursettings.PushtheON/OFF
buttonagaintostopthisunitoperation.
。
。
TheFANONLYmodecannotbeusedtocontrolthetemperature.While
inthismode,onlysteps13and4maybeperformed. 、
COOL,HEAT,andFANONLYOperation
NOTE
Duetothedifferenceofthesettemperatureoftheunitandthe
actualindoortemperature,theAirConditionerwheninDRYmode
willautomaticallyoperatemanytimeswithoutrunningtheCOOL
andFANmode.
1.PushtheMODEbuttontoselectDRY.
2.PushtheTEMPbuttontosetthedesiredtemperaturefrom
21Cto28C.
3.PushtheON/OFFbutton.Theoperationlamplightsandtheair
conditionerstartstooperateintheDRYmode.PushtheON/OFF
buttonagaintostopthisunitoperation.
。。
DRYOPERATION
NOTE
PUSHTIMERbuttontosettheonandofftimesoftheunit.
1.1PleasepushtheCANCELbuttontocancelanyformersettings.
1.2PushtheTIMERbutton.Theremotecontrollerwillshowthe
TIMERandthesignal"h"isshownonthedisplaypanel.The
controlisnowreadytoresettheTIMERONtostarttheoperation.
1.3PushtheTEMPbutton(or)tosetdesiredunitSTART
time.
1.4AftersettingtheTIMERtherewillbeaone-halfseconddelay
beforetheremotecontrollertransmitsthesignaltotheAir
Conditioner.Then,afterapproximatelyanother2seconds,the
settemperaturewillre-appearonthedigitaldisplay.
TIMEROPERATION
1.TosettheSTARTINGtime.

6
2.TosettheSTOPPINGtime.
3.SettheSTARTING&STOPPINGtime
2.1PleasepresstheCANCELbuttontocancelanyformersettings.
2.3PushtheTEMPbuttontocanceltheTIMERONsetting.The
digitalareawillshow"00".
2.6AftersettingtheTIMERtherewillbeaone-halfseconddelaybefore
theremotecontrollertransmitsthesignalstotheAirConditioner.
Thenafterapproximatelyanother2seconds,thesettemperature
willre-appearonthedigitaldisplay.
3.1PleasepresstheCANCELbuttontocancelanyformersettings.
3.2PushtheTIMERbuttonandtheremotecontrollerwillshowthe
lastsettimeforSTARToperationandthesignal"h"will
beshownonthedisplaypanel.Youarenowreadytoreadjust
theTIMERONtostarttheoperation.
3.3PushtheTEMPbutton(or)tosetthetimeyouwantto
starttheoperation.
3.4PushtheTIMERbuttonandtheremotecontrollerwillshow
thelastsettimeforSTOPoperationandthesignal"h"willbe
shownonthedisplaypanel.Youarenowreadytoresetthe
timeoftheSTOPoperation.
3.5PushtheTEMPbutton(or)tosetthetimeyouwantto
stoptheoperation.
3.6AftersettingtheTIMERtherewillbeaone-halfseconddelay
beforetheremotecontrollertransmitsthesignaltotheAir
Conditioner.Then,afterapproximatelyanother2seconds,the
settemperaturewillre-appearonthedigitaldisplay.
2.5PushtheTEMPbutton(or)tosetthetimeyouwantto
stoptheoperation.
2.4PushtheTIMERbuttonandtheremotecontrollerwillshowthelast
settimefortheSTOPoperationandthesignal"h"willbeshown
onthedisplaypanel.Youarenowreadytoresetthetimeofthe
STOPoperation.
2.2PushtheTIMERbuttonandtheremotecontrollerwillshowthe
lastsettimefortheSTARToperationandthesignal"h"
willbeshownonthedisplaypanel.Youarenowreadytore-
adjusttheTIMEROFFtostoptheoperation.
NOTE
1.PleaseresettheTIMERaftercancellingtheformertime
settings.
2.Thesettingtimeisrelativetime.Thatisthetimesetisbasedon
thedelayofthecurrenttime.

1.Besuretherearenobarriersbetweentheremotecontrollerand
thereceiverofindoorunitotherwisetheairconditionerwillnot
work.
2.KeeptheRemoteControllerawayfromallliquids.
3.ProtecttheRemoteControllerfromhightemperaturesandexposure
toradiation.
4.KeeptheindoorreceiveroutofdirectsunlightortheAirConditioner
maymalfunction.
5.KeepcontrollerawayfromEMI(Electro-MagneticInterference)
suppliedbyotherhouseholdappliances.
Warning
7

DE - COMMISSIONING DISMANTLING & DISPOSAL
This product contains refrigerant under pressure, rotating parts, and electrical connections which
may be a danger and cause injury!
All work must only be carried out by competent persons using suitable protective clothing and safety precautions.
1. Isolate all sources of electrical supply to the unit including any control system supplies switched by the unit. Ensure that all points of electrical and gas
isolation are secured in the OFF position. The supply cables and gas pipework may then be disconnected and removed. For points of connection refer
to unit installation instructions.
2. Remove all refrigerant from each system of the unit into a suitable container using a refrigerant reclaim or recovery unit. This refrigerant may then be
re-used, if appropriate, or returned to the manufacturer for disposal.
Under No circumstances should refrigerant be vented to atmosphere. Where
appropriate, drain the refrigerant oil from each system into a suitable container and dispose of according to local laws and regulations governing
disposal of oily wastes.
3. Packaged unit can generally be removed in one piece after disconnection as above. Any fixing down bolts should be removed and then unit lifted from
position using the points provided and equipment of adequate lifting capacity. Reference MUST be made to the unit installation instructions for unit
weight and correct methods of lifting. Note that any residual or spilt refrigerant oil should be mopped up and disposed of as described above.
4. After removal from position the unit parts may be disposed of according to local laws and regulations.
dellortnocyletomersitinUkcohscirtcelefoksiRlaunaMehtdaeR
and may start without warning
