With the Zone Status Screen, the thermostat Icon now unveils allof your zone
sensors' statuses.
Access the sensor status by pressing the thermostat icon.
Access the Zone Panel Status by pressing the
Accessories Icon.
Touch ICON for a detailed view
Log MenuRefresh Accessories
Exit Service Mode
Humidifier
ON
UV Lamps
ON
EAC
Not Installed
Heat Pump
OFF Thermostat
ON
Furnace
ON
11:07AM Thu 21 Jul
Back
LogRefresh Accessories
Touch ICON for a detailed view
Status
Humidifier
ON
UV Lamps
ON
EAC
Not Installed
Heat Pump
OFF Thermostat
ON
Furnace
ON
Select Zone 10:31AM Wed 04 Jan
BackRefresh
Touch ICON for a detailed view
Ventilator
ON
Dehumidifier
ON
BackRefresh
Accessories
Zone Panel
ON
Zone 5
ON Zone 6
ON
Because your system is optimized for airflow in every zone, the continuous
fan must be controlled differently than a non-zoned system.
The fan can be operated in three different modes:
Auto Mode: Only runs the fan when the zone
is calling for condition (heating or cooling).
Manual Mode: Will circulate air in the zone
when no other zone is calling for conditioning.
NOTE: Any percentage setting selected will
be automatically designated to all zones and
override all zone schedules. This is done to
ensure that there are no conflicting airflows at
a given time.
Schedule Mode: Runs the fan according to settings as defined in the programmed sched-
ule assigned for the current day part.
5% 100%
OK
Cancel
Master / Fan Adjust
Always
Run Fan
Auto ManualFunction:
23%
Show Fan on
Home
The Communicating Zone System allows for custom names tobe created and
displayed on Touch Screen Communicating Controls.
Selecting descriptive names for each zone allows for easier navigation when making
changes or settings from multiple locations in the home.
Access this feature through the menu settings
screen under "Zoning".
Once at the screen, you can view and change
each installed zone name.
Another feature available in the zone settings
screen is "Not Zoned" mode. This setting allows
you to have the system operate according to
the master zone's temperature and set point
while keeping all zone dampers open.
Zone Mode:
Living Room / Zoning Config
Bedroom 1
Not Zoned
Zoned
Edit
Kitchen Edit
Bedroom 2 Edit
Master Name:
Zone 2 Name:
Zone 3 Name:
Bedroom 3 Edit
Zone 4 Name:
The Communicating Zone System has the ability to control each zone's
humidity with separate set points. This allows you to customize your comfort
throughout your home.
When a Touch Screen Communicating Control is
installed in a zone as a sensor, it is constantly
tracking your humidity levels for the installed
zone.
The Master Touch Screen uses this information to
control equipment and airflow in that zone to the
settings desired.
Navigate to the humidity settings screen from the
menu or the short cut humidity icon in the zone (or
from the Master Touch Screen) to view or make
changes to this setting.
Schedule
Emergency
Heat
Close
Alert: Change Fi lter
StatusHumidityFan Settings
Dealer Tools Clean
Manage
Zones
Living Room
72°
Menu
Auto
ON
71°
72°
11:07AM Thu 21 Jul
55°
Alert: Change Fi lter
30%Humidity
In addition to having the ability to run a schedule as assigned per zone, the
Communicating Zone System can be easily set up to control every zone to
the same set point for a predetermined amount of time.
Vacation mode is accessed from the Advanced
Programmable View / Mode home screen. Select
the schedule button and press "Set Vacation".
This will bring up the vacation wizard which will
instruct you to set your "Leave" / "Return" date
and time, Temperature set points, Fan settings
and Humidity settings.
The thermostat will control all zones to these set-
tings without requiring setup at any other zone
sensors.
Menu
View Schedule...Set Vacation...
Day
8:00AM
78° 66°
Extend NOW or change to...
Return
5:00PM
73° 61°
10:00PM
Sleep
80° 57°
6:00AM
Awake
77° 55°
8:30AM Thu 05 Jan
NOW
OK
Vacation
Days
Leave
Return
2012
Jan5
2012
Jan10
AM10
AM
10
1
For how long?
NextCancel
8
8
6
5
Cancel
Tools / Wi-Fi
OK
Connect
11:07AM Thu 21 Jul
Home Network
Neighbors Network
Other Network
OK
Cancel
Connected
to:
Refresh
Wireless
Networks Keyboard
p
o
i
u
q
a
ABC
z
¦¢
§
xcvbnm , .
sdfghjkl
werty
123
Bksp
Space
Cancel OK
ALT
Steps to connect to wireless
1. Press select menu, select tools, select wireless.
2. Press refresh wireless network icon.
3. Select wireless network with Up/Down arrows.
4. Select connect.
5. If network is secure, type in password.
6. Connected to network
Touch Screen must be connected
to router before you can register the
device.
• For secured networks requiring a
password a lock will be present.
• Router signal strength will be shown once connected.
* For additional information
please reference the Non-Zoning
User’s Information Manual
* Download IntelliComfort from
iTunes or Google Play.
Connect Tab
Refresh Wireless
Network Icon
Unsecured
Network Secured
Network
Wireless Strength Icon
Up/Down Arrows
for Network Selection
Show Signal
Strength on Home
