Youcan Robot BW Space User manual
用户手册
User Manual
ユーザーマニュアル
V1.1
BW Space
Contents
目录
目次
01-34
35-65
66-97
Contents
Product Overview
Introduction
Feature
Structure
Products List
Operating Manual
Charging
Quick Start
Start Reminder
Retrieval
Shut Down
Crash
Download Youcan Dive APP
Introduction of Youcan Dive APP
WiFi Repeater
Remote Controller
Instructions of Sealing Lubricant and Sealing Ring
Technical Specications
Battery Information
Important Safety Information
Contact Us
01
01
02
03
04
06
08
08
09
09
10
10
24
26
28
29
32
33
34
目录
产品概述
简介
特征
结构
物品清单
操作说明
设备充电
快速启动
开机提醒
回收机器
如何关机
出现死机情况
下载 Youcan Dive APP
Youcan Dive APP 功能介绍
WiFi 基站
遥控器
密封圈和密封润滑油的使用
规格参数
电池信息
重要安全信息
联系我们
35
35
36
37
38
40
42
42
43
43
44
44
56
57
59
60
63
64
65
目次
商品情報
製品リスト
使用説明
仕様
バッテリー情報
ご使用上の注意事項
お問い合わせ
01
Introduction
Type: BW Space
Youcan Robot's BW Space is the world's rst intelligent tracking underwater
drone. For the first time, Youcan Robot has applied image recognition and
intelligent tracking technology to underwater robot products. It uses powerful
motor algorithms, image recognition and interconnected information processing
technology to track and photograph underwater target person and automatically
adjust the lights according to the environment. Also, it supports underwater
live sharing and provides 4K high-denition camera shooting at the depth of
maximum 100 meters with 7-hour battery endurance. So it can be widely used
in elds including underwater entertainment, photography, exploitation, shing,
survey, marine environmental protection and so on.
Feature
I Product Overview
4K UHD
Camera
Auto Light
Adjust
Depth Maintenance
Shooting
Auto
Direction
Handheld
Design
1380lm ⅹ2 LED
Lights
Maximum
128G Storage
Maximum Speed
of 1.5 m/s
100 Meters
Dive
Stabilizer
7 Hours
Battery Life
Custom
backpack
1080P Real-time
Transmission
Underwater
Live Streaming
Remote
Controller
iOS/Android APP
Control
02
Structure
Portable handle
Horizontal
propeller
Vertical propeller
LED Light
LED Light
Horizontal
propeller
Protection wing
LED Light
LED Light
Horizontal
propeller
4K UHD Camera
Communication/
Charging interface
03
BW Space Underwater Drone
Backpack
Tether
Wire Spool
Remote Controller
WiFi Repeater
Charger
Sealing Lubricant and
Sealing Ring
II Products List
1
3
5
6
7
8
2
4
1
3
6
2
4
7 8
5
AB
C
D
04
III Operating Manual
Charging
1.BW Space is equipped with a special
adapter that can charge BW Space and WiFi
Repeater (unable to charge simultaneously).
2.BW Space charging: Open the host
protection cover, plug the charger with 4-pin
hole connector into the BW Space host
charge jack, with the other end connected to
the power supply.
3.WiFi Repeater charging: Plug one end of
the charger with 4-pin holes into the WiFi
Repeater four pin hole with the other end
connected to the power supply.
4.It takes 5 hours for a BW Space mainframe
to be charged full, and 1.5 hour for a WiFi
Repeater.
The BW Space charging
4-pin hole
Keep the connector dry.
Make sure that the 'pin
hole' at the front end of
the connector is aligned.
nut 4-pin hole
05
WiFi Repeater charging
The light is yellow when
charging and turns green
when the charging is
completed.
If the light is red, the device failed
to connect successfully. Please
tighten the connector.
The red light ashes continuously,
idicating that the device may be
faulty. Try to replace the device
(drone or WiFi Repeater) for
charging, or exchange the connector
of the cable.
If all of the above steps fail, please
contact our after-sales team：
1.Before installing the connector,
please apply the sealing lubricant to the
sealing ring and screw thread (see the
package and Page25 for how to use it).
2.When plugging the connector,
align the jack and turn the nut until
it is tightened; when unplugging the
connector, unscrew the nut until it can
be pulled off.
3.Please make sure that the jacks are
aligned with each other.
4.It is prohibited to touch the connector
front end with wet or sweaty hands;
water should be dried if there is water
on the connector.
5.It is not allowed to drag or pull the
Cautions: plugging and unplugging
of 4-pin connector
connector lest the connector or tether is
broken.
6.Tighten the screws or fasteners with your ngers. Do not tighten the screws
with pliers or other tools when installing lest the connector is damaged or
broken.
06
Quick Start
1.Open the host protection cover.
2.When installing communication tethers, plug the 4-pin hole connector at one
end of the communication tether into the BW Space host communication tether
socket, the other end into the WiFi Repeater, and then tighten the connector
clockwise.
Note: When connecting the communication tether to the BW Space, keep
in mind that the tether is hooked to the drone's pull-tab in case that the tether
connector comes off.
Tether
Tighten Clockwise
WiFi Repeater
Hook
Pull-tab
07
Important tips:
Control system upgrade: To continuously optimize the operative
performance of BW Space, we will upgrade the control system of BW Space
from time to time. When you open Youcan Dive APP, if the screen center slider
prompts display the progression of upgrading, this indicates that the device or
software is being upgraded, usually for a duration of about 1 minute. Do not
quit from the upgrading. In case of failed upgrading, please exit the Youcan
Dive, unplug the tether and reconnect and restart the upgrading.
Camera upgrade: Youcan Robot will upgrade the BW Space camera system
from time to time. If a prompt pops up and requires a camera to upgrade
when you enter Youcan Dive APP, BW Space will start downloading the latest
camera system and upgrade it upon the user's conrmation. This process may
take about 5 minutes. Please do not disconnect the device and keep Youcan
Dive under operation in the upgrade.
When you rst use the BW Space underwater drone, you will be prompted
for depth calibration and machine calibration.
Note: When you are performing depth calibration and machine calibration, the
drone's light will always blink, which is normal.
3.Open Youcan Dive App, select "Enter" or "Log in" (New users can register
and log in ), click "Connect the WiFi" (Search for and select the WiFi signal
starting with Youcan-xxxx and enter the initial password 12345678), after
successfully connected, please click "Connect", and just wait for the system to
automatically complete device search and sensor status check, then slide to the
right to unlock and BW Space is ready for operation and shooting.
08
If the system prompts that the device is not found, try the following:
（1）Tighten the connector until you hear a light and short sound of beep.
（2）Try to disconnect the tether and device (including the drone and WiFi
Repeater) multiple times, and reconnect the APP until the device is successfully
searched.
If all of the above steps fail, please contact our after-sales team：service@
youcanrobot.com
4.Put the BW Space into water.
Start Reminder
Open the Youcan Dive APP when the tether is connected to BW Space and
WiFi Repeater, and BW Space will flash three times, indicating the APP is
successfully connected, ready for operation.
In case of start failure, check the following things:
(1) If the device is appropriately powered;
(2) If the jack of the tether is connected to BW Space or WiFi Repeater jack
appropriately;
(3) Open the Youcan Dive APP and check to see if the device is connected. If
the connection fails, reconnect the WiFi Repeater.
Note: After the tether is successfully connected to the BW Space, it will
play a light and short music, which indicates that BW Space is started. It is
normal to nd that after the APP is connected, if BW Space is not put into the
water for a long time, BW Space will make a sound of tick, tick ...
Retrieval
After using, you can steer the BW Space back to the shore or to boat, pull back
the tether and drag the drone out of the water.
Note: Before BW Space is placed in the water, make sure the tether is
securely connected to facilitate the retrieval after using.
09
Shut Down
(1)Click the "Lock" button in the upper right corner of the Youcan Dive
APP, and BW Space will pause, unable to move or shoot through the APP.
(2)After the communication tether is unconnected to BW Space and WiFi
Repeater, the drone is shut down.
Note: Before unlocking the tether, make sure the peripheral area of the
interface is dry to avoid short circuit.
Crash
If the APP or Drone crashed or stuck , try the following steps or methods:
When the APP interface is stuck:
Exit the Youcan Dive APP completely and re-enter the APP to connect the
drone.
Crash:
(1) Click "Disconnect" in the main interface of the APP to disconnect the drone
and WiFi;
(2) Unplug the tether of the drone and the WiFi Repeater and reconnect the
tether;
(3) Return to the main interface and reconnect WiFi and the device.
Keep Dry
N
0
15
30
60
300
330
345
NE
NW
Depth：10M
Device
connected
High
10
Download Youcan Dive APP
•iOS：
Log in to the App Store to download or scan the QR code right to
download directly.
* Youcan Dive APP supports iOS10.3 and above systems.
•Android：
For Andriod 8.0 and above systems, please visit Google Play to
download.
For Andriod 6.0 and above systems, please visit www.
youcanrobot.com/support to download or scan the QR code right
to download directly.
Introduction of Youcan Dive APP
Main Interface
Connecting Device
When the user uses the
device for the rst time,
click "Connect the device" to
search for and connect to the
WiFi Repeater signal. When
the user has connected the
WiFi Repeater signal, click
"Disconnect" to disconnect the
WiFi Repeater signal, and the
BW Space will not move and
shoot through APP control.
iOS
Android
11
Gallery
Browse or manage your photos
and video les.
Online mode: Browse photos and
videos on your device. You may
view and download or delete and
etc.
Local mode: Browse and manage
local pictures and videos that have
been downloaded to your phone or
tablet without connecting your BW
Space.
Personal Center
After the user registration or
login, personal information such
as user name, country, region,
and mailbox, as well as product
model, enterprise and other related
information will be displayed on
the screen.
12
WiFi: Display that BW Space has been successfully connected to the WiFi
Repeater signal.
WiFi: Display that BW Space doesn't turn on WiFi signal.
WiFi: Display that the other WiFi signals are connected, rather than the
WiFi Repeater signals of BW Space.
Temperature: Display underwater real-time temperature.
Device mode: displays the status of the on-hand device, divided into
controller mode and viewer mode.
BW Space supports multiple people to connect to the same WiFi Repeater,
using different mobile devices to watch real-time image taken by drone.
The controller mode only supports one mobile device to control. The viewer
mode suggests that up to 3 mobile devices.
Control Interface
N
0
15
30
60
300
330
345
NE
NW
Depth：10M
Device
connected
High
Machine 3D posture
Steel wheel
Brightness SpeedDepth index
Depth Maintenance Steel wheel
Gallery
Recording
WiFi
Temperature
Connection
Compass Device
Mode
Lock
Settings
BW Space
battery life
WiFi Repeater
battery life
13
BW Space battery life: Display the remaining battery capacity of BW
Space.
WiFi Repeater battery life: Display the remaining battery capacity of
WiFi Repeater.
Lock: Click the button and BW Space will enter into a lock status and
pause.
Settings: Enter the settings interface to configure the control mode and
camera.
Gallery: Click the button to browse and manage photos and videos.
Photographing: Click the Photo button to take photos.
Recording: Click the Video button to start the recording. Click the Video
button again to stop the recording.
Speed: Speed adjustment can be divided into low, medium and high, which
means low speed, medium speed and high speed respectively.
Depth maintenance: Click the button to turn on the Depth maintenance
shooting function. The BW Space is xed at a certain depth in the water,
aiming at the person and shooting. It can still move forward, backward,
left, right, but unable to up or down. Click the button again to turn off the
Depth maintenance shooting function, and the BW Space will return to free
motion.
Brightness adjustment:
•Auto-adjustment: Long press the button to become colorized, turn on the
Auto light adjustment function. The machine automatically adjusts the
light intensity according to the brightness of the surrounding environment.
At this point, you can still adjust the brightness temporarily by using the
adjustment lever, and the automatic adjustment will be performed again
later. Long press the button again, the button will turn black and white,
which will become manual adjustment.
•Manual adjustment: Touch the button to adjust the brightness of the light
by sliding the adjustment lever. There are 0~100 levels.The higher the value
is, the brighter the light. The 0 level is closed.
Machine 3D posture: display the machine front view, vertical view, side
view posture.
Compass: Shows the direction of the magnetic eld of the mobile device.
N
15
30
60
300
330
345
NE
NW
14
Control Settings
Control mode
Stick control: Control movement and shooting of drone with remote controller.
APP control: Control movement and shooting of drone with Youcan Dive APP.
Button settings: Set the direction of the left and right steer wheels.
Mode 1: The left steer wheel controls the drone to move forward, backward,
left and right, and the right steer wheel controls the drone to up and down.
Default mode is mode 1.
Mode 2: The left steer wheel controls the drone to up, down, turn left and right,
the right steer wheel controls the drone to move forward and backward.
Mode 3: The left steer wheel controls the drone to move forward and backward,
and the right steer wheel controls the drone to up, down, and turn left and right.
Mode 4: The left steer wheel controls the drone to up and down, and the right
steer wheel controls the drone to move forward, backward, left and right.
15
Control Settings
Steering sensitivity: Set the sensitivity of the machine's steering, from -5 to 5,
the higher the value, the more sensitive the steering and the faster the speed.
Depth calibration: Performs depth calibration based on the atmospheric
pressure of the current environment in which the drone is located.
Machine calibration: Calibrate the machine's gyroscope and magnetometer.
Setting sensitivity
Depth calibration
Machion calibration calibration
calibration
-5 -4 -3 -2 -1 1 2 3 4 50
Table of contents
Languages:
Other Youcan Robot Drone manuals
