Z-Wave QUBINO FLUSH SHUTTER User manual

USER MANUAL EN.
QUBINO FLUSH SHUTTER
The Qubino Flush Shutter module is ideal for remotely controlling the motors of blinds, rollers,
shades, venetian blinds, etc.

EN.
2
Table of contents
About Qubino ................................................................................................................................................................3
Safety Information.........................................................................................................................................................5
Flush Shutter - Available Frequencies ...........................................................................................................................6
Where To Buy ................................................................................................................................................................7
1. Introduction...............................................................................................................................................................7
2. Use Cases ...................................................................................................................................................................9
2.1. Installation examples where Flush Shutter is installed behind a wall switch ....................................................9
2.4. Additional features of Flush Shutter which can make your life easier ............................................................11
3. Qubino Flush Shutter Advantages and Highlights ...................................................................................................12
4. Package Contents ....................................................................................................................................................16
5. Technical Terms for Switches ..................................................................................................................................17
6. Compatibility with Z-Wave Gateways (hubs) ..........................................................................................................19
7. Installation ...............................................................................................................................................................20
7.1. Installing the device behind a light switch.......................................................................................................21
7.2. Installing the Qubino Temperature Sensor......................................................................................................27
8. Device Information and Support .............................................................................................................................33
9. Electrical Diagram (110 - 230VAC, 24VDC) ..............................................................................................................34
10. Adding the device to a Z-Wave network (Inclusion)..............................................................................................35
11. Removing the device from a Z-Wave network (Exclusion) ....................................................................................36
12. Associations ...........................................................................................................................................................37
13. Flush Shutter Calibration .......................................................................................................................................39
14. Configuration Parameters .....................................................................................................................................42
15. Technical Specifications.........................................................................................................................................50
16. Z-Wave Command Classes.....................................................................................................................................52
17. Important Disclaimer.............................................................................................................................................55
18. Warning .................................................................................................................................................................55
19. Regulations ............................................................................................................................................................55

EN.
3
About Qubino
Qubino is a family of innovative Z-Wave devices, many of them the smallest of their kind.
Numerous breakthrough innovations, 100% quality control, and responsive customer service
make Qubino the number one choice for making your life more comfortable.
Qubino enables you to transform – inexpensively and invisibly – any traditional electric device
into a smart, connected one that you can control with your smart phone. Qubino devices are
simple to install and use, but also extremely versatile - they offer a wealth of additional features
and parameters for you to play with.
We love helping people who enjoy creating new ideas for their home and then using their hard
work and skill to turn those ideas into reality. We admire their passion and resourcefulness. We
do our best to supply you with products that will enable you to create a unique and special
home for yourself. We innovate so that you can be free to make the smartest home possible.
With just a touch of magic.
"Simple is smart." We believe it is smart to make complex things simple. But only when this
means simple for our customers, not for ourselves. We think a lot so that you won't have to
when it comes to installing or using our devices.
For more information visit: www.qubino.com

EN.
4
About Z-Wave:
The Z-Wave protocol is an interoperable, wireless, RF-based communications technology
designed specifically for control, monitoring, and status reading applications in residential and
light commercial environments. Mature, proven, and broadly deployed (with over 50 million
products sold worldwide), Z-Wave is by far the world market leader in wireless control, bringing
affordable, reliable, and easy-to-use 'smart' products to millions of people in every aspect of
daily life.
Source: www z-wavealliance.org

EN.
5
Safety Information
For Qubino, safety is first, so we have prepared lots of safety tips and information that can be
found throughout this manual.
To ensure your safety, please read this manual carefully before installing the device; follow
the instructions exactly.The manufacturer (GOAP d.o.o. Nova Gorica) shall not be legally
responsible for any equipment damage or personal injury caused by incorrect installation or
operation other than that covered in this manual.
ⓘPlease check the Technical Specifications and Electrical Diagram chapters, as well as fuse
requirements in the Installation chapter before installing the device.

EN.
6
Flush Shutter - Available Frequencies
ORDERING CODE POWER SUPPLY FREQUENCY Z-WAVE FREQUENCY*
ZMNHCD1 50/60 Hz 868,4 MHz
ZMNHCD2 50/60 Hz 921,4 MHz
ZMNHCD3 50/60 Hz 908,4 MHz
ZMNHCD4 50/60 Hz 869,0 MHz
ZMNHCD5 50/60 Hz 916,0 MHz
ZMNHCD6 50/60 Hz 868,4 MHz
ZMNHCD7 50/60 Hz 919,8 MHz
ZMNHCD8 50/60 Hz 865,2 MHz
ZMNHCD9 50/60 Hz 922,5 MHz
ZMNHCDA 50/60 Hz 919,7 – 921,7 – 923,7 MHz
ZMNHCDB 50/60 Hz 868,1 MHz
ZMNHCDC 50/60 Hz 868,1 MHz
ZMNHCDD 50/60 Hz 919,8 MHz
ZMNHCDE 50/60 Hz 920,9 MHz
*You can check the Z-Wave frequency in your country here:
http://z-wave.sigmadesigns.com/wp-content/uploads/Z-Wave_Frequency_Coverage.pdf

EN.
7
Where To Buy
To find your nearest Qubino dealer visit: http://qubino.com/where-to-buy/
1. Introduction
The Flush Shutter controls the motors of blinds, rollers, shades, venetian blinds, etc. It
measures power consumption of the connected device, and can be paired with a digital
temperature sensor (sold separately). It supports push-button/momentary switches and toggle
switches (default).
The connection of a digital temperature sensor means you can create complex scenes and
control any device relative to a set temperature range. The Qubino Flush Shutter also acts as a
Z-Wave repeater to improve the range and stability of the Z-Wave network.

EN.
8
Flush Shutter supported functions:
Controls position of
blinds, rollers, shades,
venetian blinds, etc.
Controls angle of
blinds, venetian
blinds, vertical blinds
etc.
W
Measurement
kWh
Measurement
Temperature
Sensor
Associations
Z-Wave
Repeater
Auto-inclusion









EN.
9
2. Use Cases
The Flush Shutter can be used in many different scenes, which can help make your life more
comfortable. We have prepared a few of them for you so you can get an idea for your next
smart home project. Of course, there are countless of other options for how to use Qubino
Flush Shutter to remotely control devices via your smartphone.
2.1. Installation examples where Flush Shutter is installed behind a wall switch
•Remotely control outdoor venetian blinds
•Remotely control indoor venetian blinds
•Remotely control outdoor screens
•Remotely control indoor screens

EN.
10
•Remotely control rollers
•Remotely control curtains
•Remotely control vertical window blinds
•Remotely measure room temperature
(*The temperature sensor is sold
separately - for more info, check Qubino
catalogue. Product ordering code:
ZMNHEA1

EN.
11
2.4. Additional features of Flush Shutter which can make your life easier
•Do you know how much energy you
consume?
•The Flush Shutter
monitors and reports
energy consumption of connected devices in
real time to your smart
home app (your
gateway (hub) needs to support this feature).
Know how much power your light, domestic
water tank, iron, etc, is using.
•Want to control other devices in your
Z-Wave network with the Flush
Shutter?
•Connect the Flush Shutter
with other
devices in your network
to remotely
and automatically trigger another Z-
Wave device. And have other Z-Wave
devices trigger your Qubino Flush
Shutter.

EN.
12
3. Qubino Flush Shutter Advantages and Highlights
•The Qubino Flush Shutter allows the easiest and quickest installation possible. Because
of its small size, it fits smoothly in even the smallest, most shallow and most crowded
flush mounting boxes, which are stuffed with lots of electrical cables and where every
millimetre counts. All this is possible because the Qubino Flush Shutter is the smallest
Z-Wave switch in the world.
•The Qubino Flush Shutter has the option to connect a temperature sensor*, through
which users can monitor the ambient air or water temperature. It’s the only Z-Wave
switch in the worldwhich offers this option. With a connected sensor, the user can
monitor accurate measurements of the room temperature, pool water temperature,
etc., and remotely change conditions as desired. Qubino relay, along with the
temperature sensor, is connected directly to the power supply. Install it and forget it –
no need to worry about dying batteries, like with battery-powered sensors.
*The temperature sensor is sold separately - for more info, check Qubino catalogue.
Product ordering code: ZMNHEA1)

EN.
13
•Qubino guarantees 100% device quality. Such high quality can be delivered because
every Qubino goes through rigorous quality control standards throughout the
production process. Every device has a unique serial number and a part number, which
are assigned to the device only after it goes through a strict testing procedure.
•By scanning the QR code on the back of your Qubino device, the serial and part numbers
will be automatically copied on your mobile phone; they also provide direct access to
Qubino’s technical support team. The serial and part numbers of your device are given
automatically every time you open an inquiry with our support team: this instantly
shares the relevant device information we need to provide the best technical support
possible. For details, please see the Device Information and Support chapter.

EN.
14
•The Qubino Flush Shutter is engineered and manufactured in the EU,and contains only
the highest quality components.
•The Qubino Flush 1D Relay is certified by an independent European Institute and has CE,
FCC, LVD and EMC certificates to ensure the highest safety standards.

EN.
15
FLUSH SHUTTER HIGHLIGHTS:
•Precise Z-Wave and manual control of motorized blinds, shades, shutters, and
sunscreens
•Allows control of venetian blinds and changing vertical position and angle of the shades
•Calibrates positioning automatically from your smart home UI and locally
•Works with push-button (momentary) and toggle switches
•Capable of measuring the power consumption of the connected device in real time via
smartphone, which allows you to save on electricity bills*
•Features one of the easiest and quickest installations of devices of this kind; fits in even
the smallest flush mounting boxes
•Saves and restores the last status after a power failure.
•Supports auto-inclusion mode for quick set up
•Supports additional parameters for expert users, which allows for advanced
configuration*
•Acts as a signal repeater which improves the range and stability of your Z-Wave network
•Can be used to remotely control and trigger other devices in your Z-Wave network
*Your gateway (hub) needs to support advanced configuration and parameter input if you wish
to use this feature

EN.
16
4. Package Contents
•Flush Shutter Device
•Installation Manual

EN.
17
5. Technical Terms for Switches
Symbol
Switch example images
Definition
EU
USA
Qubino
Other
names
Single pole,
single throw
(SPST) - One
switch
controlling one
light / circuit of
lights
One-way
switch
Two-way
switch
(regular
switch)
Toggle
switch
Switch;
Bi-stable
switch
Single pole,
double throw
(SPDT) - Two
switches
controlling the
same light /
circuit of lights
Two-way
switch
Three-way
switch
Two-way
switch
Used when you
have three or
more switches
controlling the
same light
Intermedi-
ate switch
Four-way
switch
Intermedi-
ate switch
Crossover
switch;
Cross
connection
After being
released, it goes
back to its
original state
Momentary switch Momentary
switch
Monostable
switch;
Push button

EN.
18
Qubino devices are installed into flush mounting boxes behind the switches. You can see some
examples below:
For more information on how to install your device, please refer to the Installation chapter.

EN.
19
6. Compatibility with Z-Wave Gateways (hubs)
Please check compatibility with your Z-Wave gateway (hub) before you purchase this device. If
you don’t see your gateway (hub) in the table below, please contact us at:
http://qubino.com/support/#email.
Flush shutter Tilt Q1 Q2 W kWh Temp Comments
Domoticz V3.5877
✓ ✓ ✓ ✓ ✕ ✓
Fibaro HC Lite v 4.100
✓ ✓ ✓ ✓ ✓ ✓
Vera edge v 1.7.2406
o
✓ ✓ ✓
T
✓
On UI is not
displayed
actual value
of tilts when
use stop level
change or
when
changed with
input
switches
zipato
✓ ✓ ✓ ✓
T
✓
Zwave me
✓ ✓ ✓ ✕ ✕ ✕
homeseer
✓ ✓ ✓ ✓
T
✓
open zwave
✓ ✓ ✓ ✓
T
✓
piper
✕ ✓ ✓ ✕ ✕ ✕
SmartThings
✓ ✓ ✓ ✓ ✓
O
Temperature
sensor
support
added in the
future
NETIChome
✓ ✓ ✓ ✓ ✓ ✓
homey
T
T
T
T
T
T
eedomus
✓ ✓ ✓ ✓ ✕ ✓
jeedom
✓ ✓ ✓ ✓ ✓ ✓
Symbol
Explanation
✓
Works fully
✕
Not working
O
See comment
T
Testing in progress

EN.
20
7. Installation
Before installing the device, please read the following carefully and follow the instructions
exactly:
ⓘDanger of electrocution!
Installation of this device requires a great degree of skill and may be performed only by a
licensed and qualified electrician. Please keep in mind that even when the device is turned off,
voltage may still be present in the device’s terminals.
ⓘNote!
Do not connect the device to loads exceeding the recommended values. Connect the device
exactly as shown in the provided diagrams. Improper wiring may be dangerous and result in
equipment damage.
Electrical installation must be protected by directly associated overcurrent protection fuse
4A, gG or Time lag T, rated breaking capacity 1500A (ESKA 522.723) must be used according to
wiring diagram to achieve appropriate overload protection of the device. The fuse must be
installed in fuse holder type: Adele contact 503Si/1 DS according to the standard IEC60669-2-
1. This standard is used in Europe only.
