Zafferano poldina XXL User manual

Rechargeable floor lamp
poldina XXL
1. Tips for use:
This product is exclusively for lighting purposes and:
A) It must not be exposed to heavy mechanical loads or contamination; B) It can be installed and used only after checking the state of the pro-
duct; check that is not dirty and has not been damaged during storage; C) Installation and maintenance must be carried out when the appliance
is switched off; D) Any alterations to the product, any tampering and any failure to comply with the instructions provided may make the appliance
hazardous; When completely assembled (head + structure), the lamp has IP54 protection, which
makes it ideal for outdoor use. The light fixture (head) alone has IP20 protection and is unsuitable for outdoor use on its own; F) All metal and plastic
surfaces should be cleaned with a soft dry cloth; G) The company Zafferano shall not be held liable for any damage caused due to its products being
assembled in any manner that does not comply with the instructions provided.
2. Technical data of the lamp:
- Power: 6,5 W
-Volt: DC 5 V
- Lumen lamp: 460-510 lm
- Lithium battery pack included (see section accessories included); for instructions about how to replace the battery pack, please consult the
website: www.zafferanoitalia.com. Use only original batteries for replacement.
- Charge: 20 h
- Battery life: 15 h
- Class: III
- Protection rating: IP54
- CRI>80
3. Battery charger technical data:
- Contact charging base: INPUT/OUTPUT 5Vdc - 1A; cavo USB 2 Mt.
- Charger: INPUT AC100-240V 50/60Hz; OUTPUT 5Vdc- 1A.
- The lamp works correctly even when connected to the charging base.
- It is advisable to use the original charger and charging base. Alternatively, you can use a certified 1A charger.
4. Important:
- The support surface for the lamp must not exceed a 15° tilt or it will fall.
- The battery has an overload protection function.
- To preserve the integrity of the battery, we recommend keeping the charge between minimum 20% and maximum 80%; if the lamp is not used for
long periods, it is advisable to regularly charge/discharge the product.
- Please refer to local laws for the proper disposal and recycling of the battery.
DESIGNED BY ZAFFERANO SRL IN ITALY, MADE IN PRC • Zafferano srl,Viale dell’Industria, 26-31055 Quinto di Treviso-TV-Italia • For more information
and updates visit our website • www.zafferanoitalia.com
3
LD0360B3 white
LD0360N3 dark grey
LD0360R3 corten
LED DIMMER
6,5W LED • 460-510lm • 2700-3000K
IP54 • 100-240V • 50-60Hz
CRI>80 • 5Vdc max 1A
Ø 28 x h 150 cm / Ø 11 x h 59 in
Base di ricarica a
contatto singola
LD0340RA
Multi-socket USB
charger (8xUSB)
BAT04703706701900
Replacement battery pack
Questo prodotto contiene una sorgente luminosa in classe F
KIT00015000000100
Replacement LED board
INCLUDED NOT INCLUDED

DESIGNED BY ZAFFERANO SRL IN ITALY, MADE IN PRC • Zafferano srl,Viale dell’Industria, 26-31055 Quinto di Treviso-TV-Italia • For more information
and updates visit our website • www.zafferanoitalia.com
INSTRUCTIONS FOR USE
4
SWITCHING ON / SWITCHING OFF / DIMMING
Quick taps to:
- turn on
- turn off the lamp
When the lamp is switched on, lightly press the touch sensor to
obtain the desired brightness. Every time you turn it on, the light
intensity returns to 100%
<1 sec <1 sec
CHARGE / INDICATOR LEDS
Charge the battery before initial use.
To correctly charge the lamp, we re-
commend that you:
1) Connect the USB cable to the adap-
tor;
2) Put the plug into the electrical
socket
3) Place the lamp on the charging
base;
4) When fully charged, disconnect the
plug from the electrical socket
1-2
1
3
2
RED LED
charging in progress
GREEN LED
the battery is charged, it is
advisable to disconnect it from
the power charger
Turn the lamp on and off 5 times in succession; the 5th time you
turn it on (10th touch), the colour temperature will be changed.
N.B. No more than 5 seconds must elapse between one touch and
the next.
COLOR TEMPERATURE CONFIGURATION
ASSEMBLING INSTRUCTIONS
on / off
x 5
