Zanussi ZF-1214DC User manual

12” METAL DESK FAN
ITEM NO. : ZF-1214DC/1214DW
Instruction Manual
Please keep for future reference
Thank you for purchasing 12” Metal Desk Fan
SAFETY GUIDELINES
1. Read the instructions carefully since they give important indications
concerning safety guidelines, assembly, operation, cleaning and care.
2. Check the condition of the appliance after removing from the packaging.
Ensure that all component parts of the fan are within the packaging and
have not been damaged.
3. Never leave any parts of the packing within reach of children.
4. This appliance must only be used for the purpose for which it was designed
i.e. for room ventilation. DO NOT USE IN BATHROOMS.
5. Never insert objects into the grille of the fan.
6. Never touch the appliance with wet or damp hands.
7. Never pull the cable or the appliance itself in order to disconnect the plug
from the socket.
8. Before carrying out any cleaning or servicing operation always remove the
plug from the socket.
9. In the event of appliance failing to operate, all repairing work must be
undertaken by a qualified engineer.
10. If the supply cord is damaged, it must be replaced by the manufacturer, its
service agent or similarly qualified persons in order to avoid a hazard.
11. Ensure that the fan is switched off from the supply mains before removing
the guard.
12. The appliance is not intended for use by persons (including children) with
reduced physical, sensory or mental capabilities, or lack of experience and
knowledge, unless they have been given supervision or instruction.
Warning : Never use without the guards in place!

ASSEMBLY
● Carefully unpack the appliance and remove all the packaging materials
attached to your Fan. Pick out the Motor housing (7), remove the Pole
fixing nut (13) out of the Supporting pole (11). Align and insert the
Supporting pole (11) into the hole of the Base (12), fasten it with the Pole
fixing nut (13).
● Remove the Blade locking cap (2) and Guard knob (4) from the Motor
shaft (6). Assemble the Rear grille (5) onto the Motor housing (7) to
match with the three fixing pins and make sure the carrying handle at
the top. Fixing it by the Guard knob(4).
● Assemble the Blade (3) on the Motor shaft (6) and secure it with Blade
locking cap (2).
● Put the Front grille (1) onto the Rear grille (5), settle it by the guard
fixing clip then fasten it with the Safety screw (14).
OPERATION
Unwind the power cable and Position the unit on a level, dry and flat
surface where the air outlet grilles cannot be obstructed. Position the
appliance at least 30 cm away from walls or obstacles.
Connect and ensure that the plug and the socket fit well.
Select the desired speed setting by rotating the Rotary switch. There are
3 speeds : 0 (Off), 1 (Low Speed), 2 (Medium Speed), 3 (High Speed)
Push the Oscillating knob (8) for oscillation and pull the Oscillating knob
(8) for fixed position.
The airflow can be adjusted upward or downward by simply moving the
Motor housing (7) up or down.
Warning : Never touch the Blade with your hand or any other objects
when the Fan is operating.
1. Front grille
2. Blade locking cap
3. Blade
4. Guard knob
5. Rear grille
6. Motor shaft
7. Motor housing
8. Oscillating knob
9. Rotary switch
10. Power cord & plug
11. Supporting pole
12. Base
13. Pole fixing nut
14. Safety screw

CLEANING AND CARE
Always disconnect the fan from mains socket before cleaning.
Avoid contact with moving fan parts.
Use only a soft damp cloth to clean the fan.
DO NOT immerse the fan in water and never allow water to drip into the
Motor Housing.
Never spray the appliance with liquids or submerge it in water or other
liquid.
DO NOT use harsh or abrasive chemicals to clean the fan. Never use
polish or any corrosive liquid that will damage the paint, metal or plastic.
Ensure that the fan is switched off from the mains socket before
removing.
Store the fan in its original box or cover the fan to protect it from dust in
a dry place if it will not be used for a long period of time.
TECHNICAL SPECIFICATIONS
Item No. : ZF-1214DC/1214DW
Voltage : AC 220-240V~ 50Hz
Wattage : 45W
Product size : 35 x 29 x 46 cm
N. W. : 3.0 kg
** Please keep and present purchase invoice for repair or inspection.
The guarantee does not cover the damage caused by accident,
alteration or repair by any unauthorized persons.
HONG KONG SERVICE CENTRE：
DAH CHONG HONG, LTD
Electrical Appliances Service Centre
Tel: [phone]
Note : If the cordset of this appliance becomes damaged,
discontinue use. Repairs should be undertaken
only by a qualified technician.
