ZNPPF1611B Revision 1.5
Operating Manual
ZNPPF1611B
16” PEDESTAL
FAN
REGISTER TODAY
FOR YOUR FREE
ADDITIONAL YEAR
GUARANTEE

ZNPPF1611B Revision 1.5
GUARANTEE
At Zanussi, we take all our customer feedback seriously.
Feel free to contact our Product Care Team, on 0330 123 0597 who will be more
than happy to assist you.
This product is guaranteed for 12 months from the date of the original purchase. If any
defect arises due to faulty materials or workmanship, the faulty product must be
returned to the place of purchase.
Refund or replacement is at the discretion of the retailer.
The following conditions apply:
•The product must be returned to the retailer with the original proof of purchase.
•The product must be installed and used in accordance with the instructions
contained in this instruction guide and any other instructions for use which are
supplied.
•It must be used for domestic purposes only and for its intended use.
•This guarantee does not cover wear and tear, damage, misuse or consumable
parts.
•This does not affect your statutory rights.
ZANUSSI CONTACT DETAILS
Website: https://www.zanussiheatingandcooling.uk
Telephone: [phone]
Address: Product Care, G2S, Green Bank Business
Park, Hindley Green, Wigan, WN2 4AY
Note your serial number below for future reference.
Image for
illustration
purposes only
REGISTER
ONLINE
Visit our website to register your full parts
and labour guarantee online.
www.zanussiheatingandcooling.uk
REGISTER
BY PHONE
Call our friendly Product Care team on the
number below.
0330 123 0597

ZNPPF1611B Revision 1.5
IMPORTANT SAFETY INSTRUCTIONS
•It is hazardous for anyone other than a competent person
to carry out any service or repair operation that involves
the removal of a cover which gives protection against
exposure to electrical parts.
•Do not use with a damaged cord or plug. If the supply
cord is damaged, it must be replaced by the
manufacturer, its service agent or similarly qualified
persons in order to avoid a hazard.
•This product is intended for household use only.
•Do not use outdoors.
•This appliance can be used by children aged from 8 years
and above and persons with reduced physical, sensory or
mental capabilities or lack of experience and knowledge
if they have been given supervision or instruction
concerning use of the appliance in a safe way and
understand the hazards involved. Children should not
play with the appliance. Cleaning and user maintenance
should not be made by children without supervision.
•Do not operate this appliance for anything other than its
intended use.
•Do not immerse whole unit in water or other liquids for
cleaning.
•Unplug from outlet when not in use. Do not leave
unattended while plugged in.
•Do not use if it has been dropped, damaged, left outdoors
or dropped into water.

ZNPPF1611B Revision 1.5
IMPORTANT SAFETY INSTRUCTIONS
•Keep the appliance away from water; do not allow it to
get wet. If unit is wet, do not plug unit into wall socket or
turn unit on.
•Do not handle the appliance with wet hands.
•Do not pull or carry by cord, use cord as a handle, close
door on cord, pull cord around sharp corners or edges, or
expose cord to heated surfaces. Do not unplug by pulling
on cord.
•To protect against electrical shock do not immerse cord,
plug, or appliance in water or other liquid.
•Unplug from the mains outlet when not in use, before
putting on and taking off parts, and before cleaning.
•Only use the unit when fully assembled.
•Never place your fingers or other objects into any part of
the appliance. Be aware that loose clothing or hair may
become trapped in the appliance if improperly used.
•Before use, ensure that all of the air vents of the
appliance are clear and there is no restriction of air flow.
•Caution: Appliance may disturb ashes in an open fire.
Always avoid directing the appliance toward naked
flames.

ZNPPF1611B Revision 1.5
PARTS
ASSEMBLY
SETTINGS
OSCILLATION
Press the switch on the rear of the fan to engage the oscillation feature.
1. Fan Blade
2. Legs
3. Front Grille
4. Rear Grille
5. Fan Blade Fixing Point
6. Lower Pole
7. Rear Grille Securing Nut
8. Fan Blade Securing Nut
9. Legs Securing Joint
10.Extension Securing
Point
11.Screw & Nut
1. Thread the Lower Pole [6] through the Legs
Securing Joint [9]
2. Attach Extension Pole [10] onto Lower Pole [6]
and fit Legs [2] to Securing Joint [9]
3. Place Rear Grille [4] on Fan Blade Fixing Point
[5] aligning with rear posts, and secure with
Rear Grille Securing Nut [7]
4. Attach Fan Blade [1] onto Fixing Point [5] and
secure with Cap [8]
5. Clip Front Grille [3] onto Rear Grille [4] using
attached clips, and screw in Securing Screw
into Screw Hole on the Front Grille should be
at the top.
1
3
4
2
6
5
7
8
9
10
0
11

ZNPPF1611B Revision 1.5
PROBLEM SOLVING
The fan doesn’t
switch on
•Check the fan is plugged in
•Check the socket is switched on
•Check another appliance in the socket
•Unplug and check for any obvious signs of damage to cord or
plug
•If recently used, allow to cool for 1 hour then try again
The fan is rattling
•Check the grille is secured properly
•Check all screws are securely fastened
•Check there is nothing in contact with the fan
Fan will not
oscillate
•Check the oscillation switch is pressed down
•Check that nothing is interfering with the fan preventing
oscillation
Fan is making a
grinding sound
•Immediately switch off and contact Customer Services
The air is dusty
•Ensure fan is unplugged and set to 0
•Carefully remove grille
•Carefully remove blades from fan
•Using mild soapy water and a sponge, gently rinse the blades
•Allow to dry naturally for 24 hours then refit the blades
If you are still experiencing difficulties with the appliance please
contact us BEFORE returning the appliance to the retailer it was
purchased from:
Website: https://www.zanussiheatingandcooling.uk
Telephone: [phone]
Address: Product Care, G2S, Green Bank Business Park, Hindley
Green, Wigan, WN2 4AY

ZNPPF1611B Revision 1.5
IMPORTANT!
KEEP BLADES CLEAN
Wash the blades with cold water at least once every 3 months.
The blades may require more frequent washing if in a dusty environment.
Ensure that the fan is unplugged before removing the guard.
3
MONTHS
This product is guaranteed for 12 months from the date of the
original purchase. If any defect arises due to faulty materials or
workmanship, the faulty product must be returned to the place of
purchase.
By registering your product you will get an additional year
guarantee free of charge. Additional cover can be purchased
through the website.
www.zanussiheatingandcooling.co.uk
Product Care, G2S Ltd, Green Bank Business Park,
Swan Lane, Hindley Green, Wigan, WN2 4AY
REGISTER
ONLINE
Visit our website to
register your full parts
and labour guarantee online.
www.zanussiheatingandcooling.uk
REGISTER
BY PHONE
Call our friendly Product Care team on
the number below.
0330 123 0597

ZNPPF1611B Revision 1.5
The ‘wheelie bin’ symbol is known as the 'Crossed-out wheelie bin Symbol'. When this symbol is marked on a
product/batteries, it means that the product/batteries should not be disposed of with your general household
waste. Only discard electrical/electronic/battery items in separate collection schemes, which cater for the
recovery and recycling of materials contained within. Your co-operation is vital to ensure the success of these
schemes and for the protection of the environment. For your nearest disposal facility, visit
www.recycle-more.co.uk or ask in store for details.
SEDEX – Connecting businesses and their global suppliers to share ethical data and enabling improvement in
ethical performance. Visit www.sedex.org.uk for further information.
We reserve the right, due to possible changes to design, to alter the instruction manual without prior notice.
ZANUSSI is a registered trademark used under license from AB
Electrolux (publ). Made under license by G2S Limited, Wigan, WN2 4AY
Zanussi Support: call 0330 123 0597 or visit
www.zanussiheatingandcooling.uk
