ZANUSSI
P R O F E S S I O N A L
FULL MOD. FRY TOPS ON OVEN-THERMOSTATIC
N 900
Model 200224
SCRAPER FOR SMOOTH PLATE FRY TOP 1 1
SCRAPER FOR RIBBED PLATE FRY TOP 1 1
2/1 GN CHROME GRID 1 1
INCLUDED ACCESSORIES
Supply voltage 400 V, 3N, 50/60
Net weight - kg. 171 171
Thermostatic valve l l
Sloped cooking surface l l
height adjustment 50 50
height 850 850
depth 900 900
width 800 800
External dimensions - mm
Power supply Gas Electric
NRG8SMMO
200224
NRE8SMMO
200225
CHARACTERISTICS MODELS
TECHNICAL DATA
RANGE
COMPOSITION
N 900: a range of over 150 models for the
professional caterer designed to guarantee
the highest level of performance, reliability,
energy saving, safety standards and
ergonomic operation. These concepts are
reflected in the total modularity of the range
that ensures innumerable configurations,
either free-standing, bridged or cantilever.
N900 demonstrates how advanced
technology can satisfy the needs of the
professional caterer. The models detailed in
this sheet are two fry tops in gas and electric
version on static oven.
FUNCTIONAL AND
CONSTRUCTION
FEATURES
� Stainless steel burner with a
self-stabilizing flame. The burner has 4
branches with 8 flame lines (gas models).
� Incoloy heating elements positioned under
the cooking plate (electric models)
� Gas static oven (on model NRFG800) with
stainless steel burners, self-stabilizing flame
positioned beneath the base plate and a
thermostat adjustable from 120° to 280°C
� Electric static oven (on model NRFE800)
with separate thermostats for top and bottom
elements. Oven thermostat with temperature
markings in °C adjustable from 120° to
280°C and power of 6 KW.
� Safety thermostat on models with
thermostatic control (temperature markings in
°C). Piezo iginition.
� Deep drawn worktop in 20/10 stainless
steel. Front and side panels in stainless steel
with Scotch Brite finish.
� All models have right-angled side edges to
allow flush fitting joins between units
eliminating gaps and possible dirt traps. The
new built-in design (not valid for gas cock
models) avoids fat infiltration behind the
appliance improving hygienic condition.
� Cooking surface with rounded corners and
removable higher splashback, available in
mild steel (smooth or ribbed surface) or mild
steel coated with a layer of hard polished
chrome (only smooth) for optimum grilling
results.
� On the cooking surface there is a large
drain hole to drain fat into a 3-lt collector
placed under the cooking area.
� Main connections can be via the base of
the unit.
� All models provided with service duct to
facilitate installation.
� All gas appliances are supplied for use
with natural gas, with LPG conversion jets
supplied as standard.
� Very quick heat-up time to maximum
temperature.
� The special design of the control knob
system guarantees against water infiltration.
� Removable splashback in stainless steel
and scrapers with smooth/ribbed blades
included as standard.
� IPX5 water protection.
* In accordance with H regulations for gas models
belonging to Class B11 (power over 14 kW), it is
necessary to install a chimney (if installed under a
hood) or chimney and draft diverter if the waste gases
are vented directly outside.

BACK1 2009-09-29 The Company reserves the right to alter technical specifications without prior notice.
www.zanussiprofessional.com
ZANUSSI
P R O F E S S I O N A L
WATER DRAIN FOR FRY TOP HALF MODULE 206153 206153
WATER DRAIN FOR FRY TOP FULL MODULE 216153 216153
WATER COLUMN WITH SWIVEL ARM 206288 206288
WATER COLUMN EXTENSION FOR 900 LINE 206290 206290
SUPPORT FOR "BRIDGE" SYSTEM 800 MM 206137 206137
SUPPORT FOR "BRIDGE" SYSTEM 400 MM 206154 206154
SUPPORT FOR "BRIDGE" SYSTEM 1600 MM 206141 206141
SUPPORT FOR "BRIDGE" SYSTEM 1400 MM 206140 206140
SUPPORT FOR "BRIDGE" SYSTEM 1200 MM 206139 206139
SUPPORT FOR "BRIDGE" SYSTEM 1000 MM 206138 206138
SIDE HANDRAIL-RIGHT/LEFT HAND 206165 206165
SCRAPER FOR SMOOTH PLATE FRY TOP 164255 164255
REAR FLUE UPSTAND FOR SMALL CHIMNEY 206159
REAR FLUE UPSTAND FOR LARGE CHIMNEY 206160
PRESSURE REGULATOR FOR GAS UNITS 927225
PAIR OF COVERING STRIPS FOR END ELEMENTS 206234 206234
MATCHING RING FOR FLUE CONDENSER 150DIAM 206133 206133
LARGE HANDRAIL(PORTIONING SHELF)800 MM 206186 206186
LARGE HANDRAIL(PORTIONING SHELF)400 MM 206185 206185
JUNCTION SEALING KIT 206086 206086
FRONTAL KICKING STRIP 800 MM 206176 206176
FRONTAL KICKING STRIP 400 MM 206175 206175
FRONTAL KICKING STRIP 200 MM 206174 206174
FRONTAL KICKING STRIP 1600 MM 206179 206179
FRONTAL KICKING STRIP 1200 MM 206178 206178
FRONTAL KICKING STRIP 1000 MM 206177 206177
FRONTAL HANDRAIL 800 MM 206167 206167
FRONTAL HANDRAIL 400 MM 206166 206166
FRONTAL HANDRAIL 1600 MM 206192 206192
FRONTAL HANDRAIL 1200 MM 206191 206191
FRONT.KICK.STRIP F.CONCRETE INST.800 MM 206148 206148
FRONT.KICK.STRIP F.CONCRETE INST.400 MM 206147 206147
FRONT.KICK.STRIP F.CONCRETE INST.200 MM 206146 206146
FRONT.KICK.STRIP F.CONCRETE INST.1600 MM 206152 206152
FRONT.KICK.STRIP F.CONCRETE INST.1200 MM 206151 206151
FRONT.KICK.STRIP F.CONCRETE INST.1000 MM 206150 206150
FLUE CONDENSER FOR 1/2 MOD. DIAM.120MM 206155 206155
FLUE CONDENSER FOR 1 MODULE DIAM.150MM 206156 206156
FLANGED FEET KIT 206136 206136
DRAUGHT DIVERTER WITH 150 MM DIAMETER 206132 206132
DRAUGHT DIVERTER WITH 120 MM DIAMETER 206126 206126
4 WHEELS (2 WITH BRAKE) 206188 206188
4 FEET FOR CONCRETE INSTALLATION 206210 206210
2/1 GN CHROME GRID 164250 164250
2 SIDE KICKING STRIPS F.CONCRETE INSTAL. 206157 206157
2 SIDE KICKING STRIPS 206180 206180
2 SIDE COVERING PANELS H=700 D=900 206134 206134
2 SIDE COVERING PANELS FOR TOP-D=900MM 206278 206278
2 PANELS FOR SERVICE DUCT (SINGLE INST.) 206181 206181
2 PANELS FOR SERVICE DUCT (BACK TO BACK) 206202 206202
NRG8SMMO
200224
NRE8SMMO
200225
ACCESSORIES MODELS
OPTIONAL ACCESSORIES
G - Gas connection 1/2"
EI - Electrical connection 400 V, 3N, 50/60
NRG8SMMO
200224
NRE8SMMO
200225
LEGEND
200224 200225
