Zanussi KFRE400T User manual

ZANUSSI
P R O F E S S I O N A L
ELECTRIC FRYERS - 12 LT
N 700
178123
BASKET FOR 12 LT ELECTRIC FRYER
TOPS
1 1 2 2
INCLUDED ACCESSORIES
Supply voltage 400 V, 3N,
50/60
230 V, 3,
50/60
400 V, 3N,
50/60
230 V, 3,
50/60
Net weight - kg. 25 25 45 45
installed-electric 8.7 8.7 17.4 17.4
Power - kW
Maximum Well Capacity -lt 10, 12 10, 12 10, 12 10, 12
Temperature limiter l l l l
Thermostatic l l l l
height 235 235 235 235
depth 420 420 420 420
width 240 240 240 240
Usable well dimensions - mm
N° of wells 1 1 2 2
height 250 250 250 250
depth 700 700 700 700
width 400 400 800 800
External dimensions - mm
Power supply Electric Electric Electric Electric
KFRE400T
178122
KFRE400T2
178129
KFRE800T
178123
KFRE800T2
178130
CHARACTERISTICS MODELS
TECHNICAL DATA
RANGE
COMPOSITION
N 700: a range of over 100 models
for the professional caterer designed
to guarantee the highest level of
performance, reliability, energy
saving, safety standards and
ergonomic operation. These
concepts are reflected in the total
modularity of the range that ensures
numerous configurations, either
free-standing or bridged. N 700
demonstrates how advanced
technology can satisfy the needs of
the professional caterer.
The models detailed on this sheet
are 12 litres electric fryers with one
or two wells.
FUNCTIONAL AND
CONSTRUCTION
FEATURES
� Incoloy armoured high efficiency
heating elements.
� Working temperature from 105ºC
to 185ºC.
� Additional overheat safety
thermostat.
� Heating elements inside the well.
� All models have right-angled side
edges to allow flush-fitting joins
between units, eliminating gaps and
possible dirt traps.
� Worktop in 1,5mm stainless steel.
Front panel in stainless steel with
Scotch Brite finish.
� IPX4 water protection.
� Oil drainage via tap on front for
table-top models.
� Main connections can be via the
rear or the base of the unit.
� All models can easily be mounted
on open base cupboards or bridging
supports.
� All top models provided with
service duct to facilitate installation.

BABM3 2009-06-19 The Company reserves the right to alter technical specifications without prior notice.
www.zanussiprofessional.com
ZANUSSI
P R O F E S S I O N A L
SUPPORT FOR "BRIDGE" SYSTEM 800 MM 206137 206137 206137 206137
SUPPORT FOR "BRIDGE" SYSTEM 400 MM 206154 206154 206154 206154
SUPPORT FOR "BRIDGE" SYSTEM 1600 MM 206141 206141 206141 206141
SUPPORT FOR "BRIDGE" SYSTEM 1400 MM 206140 206140 206140 206140
SUPPORT FOR "BRIDGE" SYSTEM 1200 MM 206139 206139 206139 206139
SUPPORT FOR "BRIDGE" SYSTEM 1000 MM 206138 206138 206138 206138
RIGHT AND LEFT SIDE HANDRAILS 206240 206240 206240 206240
LARGE HANDRAIL(PORTIONING SHELF)800 MM 206186 206186 206186 206186
LARGE HANDRAIL(PORTIONING SHELF)400 MM 206185 206185 206185 206185
FRONTAL HANDRAIL 800 MM 206167 206167 206167 206167
FRONTAL HANDRAIL 400 MM 206166 206166 206166 206166
FRONTAL HANDRAIL 1600 MM 206192 206192 206192 206192
FRONTAL HANDRAIL 1200 MM 206191 206191 206191 206191
CHIMNEY UPSTAND 800MM 206304 206304
CHIMNEY UPSTAND 400MM 206303 206303
BASKET FOR 12 LT ELECTRIC FRYER TOPS 921629 921629 921629 921629
2 SIDE COVERING PANELS FOR TOP-D=700MM 206277 206277 206277 206277
KFRE400T
178122
KFRE400T2
178129
KFRE800T
178123
KFRE800T2
178130
ACCESSORIES MODELS
OPTIONAL ACCESSORIES
I - Electrical connection 400 V, 3N, 50/60 230 V, 3, 50/60 400 V, 3N, 50/60 230 V, 3, 50/60
KFRE400T
178122
KFRE400T2
178129
KFRE800T
178123
KFRE800T2
178130
LEGEND
178122, 178129
597829200
50
11
378
290
3575
25
250
700
147 450
102
400 795
200
178123, 178130
597829300
50
290
3575
25
250
700
147 450
102
795
200
800
778
11
200
