304 AISI CENTRAL TYPE HOODS
BLOCK - BV line - 1800 mm
304 S/S LABYRINTH FILTER H=500 MM 4 8 8 10 12 12 14
304 S/S BLIND PANEL 400X500H MM 2 2 2 2
INCLUDED ACCESSORIES
Net weight - kg. 57 76 84 98 102 111 120
Air Capacity - mc/h 3800 7600 7600 7600 7600 7600 7600
height 500 500 500 500 500 500 500
depth 1800 1800 1800 1800 1800 1800 1800
width 1600 2000 2400 2800 3200 3600 4000
External dimensions - mm
BCV1816DT
642228
BCV1820DT
642229
BCV1824DT
642230
BCV1828DT
642231
BCV1832DT
642232
BCV1836DT
642233
BCV1840DT
642234
CHARACTERISTICS MODELS
TECHNICAL DATA
RANGE
COMPOSITION
A range of central hoods
guaranteeing a rational and versatile
solution to extraction problems over
most cooking appliances. The
sloped front gives them a neat
appearance while taking up less
space, making them particularly
suitable for small kitchens. The
range consists of hoods with 7
different lengths (1600, 2000, 2400,
2800, 3200, 3600 and 4000 mm)
and 1800 mm deep.
FUNCTIONAL AND
CONSTRUCTION
FEATURES

� Constructed entirely in 304 AISI
stainless steel.
� Labyrinth filters in 304 AISI
stainless steel easily removable for
cleaning. Labyrinth filters guarantee
constant filtration to avoid clogging
and protect against fire.
� Powerful internal fan(s) 550 W.
� Lead hole for electric cable on top.
� Perimetral gutter with drain hole to
transfer grease into a 304 AISI
container.
� External panels with upturned
edges to avoid injuries.
� Blind panels in 304 AISI stainless
steel for a correct exhaustion.
� The outlet holes are sized in order
to minimize drops in pressure.
� Pressure gauging for perfect
calibration.
� Condensate collection tray in 304
AISI stainless steel.
� Eyebolts and screw anchors for
ceiling installation.
� Prearranged for installation of
lighting.
