Dear Customer,
Thank you for purchasing the ZEB-U745
UPS. Please read the user manual carefully
before usage & save it for future reference.
Note:
Ÿ Avoid the usage of the product at high
temperature and high humidity environment.
Ÿ Avoid the self-disassembly of the products.
Warranty
To know more about terms and condition for
warranty policy, please visit
http://zebronics.com/pages/warranty-policy
Important Safety Instructions
Ÿ The voltages inside UPS may be
hazardous. Do not attempt to disassemble
the unit. The unit contains no user
serviceable parts. OnIy factory service
personnel may perform repairs.
Ÿ Internal battery voltage is 12VDC, 7Ah.
sealed, lead-acid, battery x1no.
Ÿ Connection to any other type of socket
other than a two-pole, three-wire grounded
socket may result in shock hazard as well as
violating to local electrical codes.
Ÿ In the event of an emergency, press the
OFF button and disconnect the power cord
from the AC power supply to properly disable

the UPS. Do not allow liquids or any external
objects to enter the UPS. Do not place
beverages or any other liquid-containing
vessels on or near the unit.
Ÿ This unit is designed for installation in a
controlled environment (temperature
controlled, indoor area free of conductive
contaminants). Avoid installing the UPS in
locations where there is static or flowing
water, or excessive humidity.
Ÿ Do not plug the UPS input into its own
output.
Ÿ Do not attach a power strip or surge
suppressor to the UPS.
Ÿ Do not connect non-computer-related
items, such as medical equipment, life-
support equipment, microwave ovens, or
vacuum cleaners to UPS.
Ÿ To reduce the risk of overheating the UPS,
do not cover the UPS cooling vents and avoid
exposing the unit to direct sunlight or
installing the unit near heat emitting
appliances such as air heaters or furnaces.
Ÿ Unplug the UPS prior to cleaning and do
not use liquid or spray detergent.
Ÿ Do not dispose the batteries into fire as
they may explode. Do not open or mutilate
the battery or batteries. Released electrolyte
is harmful to the skin and eyes.

It may be toxic.
Ÿ A battery can present a risk of electrical
shock and high short circuit current. The
following precautions should be observed
when working on batteries:
a) Remove watches, rings, or other metal
objects from the hands.
b) Use tools with insulated handles.
c) Wear rubber gloves and boots.
d) Do not lay tools or metal parts on top
of batteries.
Ÿ Disconnect charging source prior to
connecting or disconnecting batteries
terminals.
Ÿ Servicing of battery should be performed
or supervised by technical and authorized
personnel only.
Ÿ When replacing battery, replace with the
same type of sealed lead-acid battery. The
maximum ambient temperature rating is
40°C.
UPS Installation Procedure
Ÿ Your new UPS may be used immediately;
however recharging the battery for atleast
8hours (no load) is recommended to ensure
that the battery maximum charge capacity is
achieved. Charge loss may occur during
shipping and storage.

To recharge the battery, simply leave the unit
plugged into an AC outlet. The unit will
charge in both the on and off position.
Ÿ With the UPS unit off and unplugged,
connect the computer, monitor, and any
externally powered data storage device (Zip
drive, Jazz drive, Tape drive, etc.) into the
battery power supplied outlets. DO NOT plug
laser printer, copier, space heater, vacuum,
paper shredder or other large electrical
device into the battery power supplied
outlets. The power demands of these devices
will overload and possibly damage the unit.
Ÿ Plug the UPS into a 2 pole, 3 wire
grounded socket (wall outlet). Make sure the
wall branch outlet is protected by a fuse or
circuit breaker and does not service
equipment with large electrical demands (e.g.
air conditioner, refrigerator. copier, etc. Avoid
using extension cords.
Ÿ Press the power switch to turn the unit
ON. The power on indicator light will
illuminate and the unit will "beep".
Ÿ If an overload is detected, an audible
alarm will sound and the unit will emit beep
once every 0.5 seconds. To correct this turn
the UPS off and unplug atleast one piece of
equipment from the battery power supplied
outlets.

Wait 10 seconds Make sure the fuse is
normal and then turns the UPS on.
Ÿ To maintain optimal battery charge, leave
the UPS plugged into an AC outlet at all times.
Ÿ To store your UPS for an extended period,
cover it and store with the battery fully
charged. Recharge the battery every three
months to ensure battery life.
Product Description
Front Panel
1. Power Switch
2. LED Indicators
AC Mode : Green LED Glow
Battery Mode : Orange LED blinks
Fault Mode : Red LED Glow
Back Panel:
3. AC input
4. Output Sockets
5. Input Fuse
R-41213624
www.bis.gov.in
IS 16242 (Part 1) /
IEC 62040-1
3 4 5
1
2

Power On/Off (AC mode)
To turn on the UPS unit, press the power
switch lightly. To turn off the UPS unit, press
the power switch again
Power On/Off (Battery mode)
To start the UPS when AC utility power is
not available, simply press the power switch.
LED Indication and Alarm
Features
Line interactive UPS
Auto restart while AC is recovering
Automatic Voltage Regulation (AVR)
Wide Input Range
Microcontroller Based
Generator Compatible
Normal Green LED Glows
Battery Discharge Orange LED blinks Beep once
every 10 seconds
Battery Low Red LED Glow and
Orange LED flashing
Beep once
every 1 second
Overload Orange LED flashing Beep once
every 0.5 seconds
Fault Red LED Glow Continuous alarm
----
Condition Indication Alarm

Specifications(
(VA/W) 600VA/360W
220-240 VAC
140-300 VAC
50/60 Hz
3 Pin plug
Capacity
Input
Nominal voltage
Voltage range
Frequency
Plug type
Output
Voltage range (AC Mode)
Voltage range (Batt Mode)
Frequency range (Batt Mode)
Transfer time
Waveform
No. of output sockets
Battery type
Charging current
Recharge time
Protections
230VAC± 10%
230VAC±10%
50/60Hz±1%
4-8ms
Simulated Sine Wave
3
12V 7Ah x 1 nos
1A
6-8H to charge 90% (after
complete discharge)
3 LED
Green LED Glows
Orange LED blinks
Red LED Glow
Overload, Short Circuit,
Over Discharge &
Over Charge
Battery
Indicators
No. of LEDs
AC mode
Battery mode
Fault mode
Battery mode
Low battery
Overload
Fault
Beeping every 10 Secs.
Beeping every 1 Sec.
Beeping every 0.5 sec.
Continuous beeping
Dimension
Net. weight
Package dimension
10.1 x 28 x 14.2 cm
(W x D x H)
3.9 kg
32.6 x 14.2 x 21.3 cm
(WxDxH)
Operational temperature
Noise level
o
0-40 C
< 45dB
Alarm
Physical details
Environmental
factors
Internal FuseInput Protection

Troubleshooting
ISO 9001:2015 Certified Company
www.zebronics.com
Possible Cause Solution
Charge battery up to
8 hours
Press the power switch
again
Kindly Approach the service
center for product diagnostic
Problem
No LED
Indicator on
the front panel
Battery weak
Battery defect
Power switch is not
pressed
Alarm buzzer
beeps
continuously
when AC
supply is
normal
Overload of the UPS
Overload of the UPS
Battery voltage is too low
Battery defect due to
high temperature
operation environment,
or improper operation
to battery
Verify that the load
matches the UPS
capability specified
in the specs
Remove some non-critical
load
Charge battery 8 hours or
more
Kindly approach the
service center for
product diagnostic
When power
failure,
back-up
time is
shorten
Mains normal
but Battery
Mode indicator
orange LED is
flashing (for
LED model)
Power cord is loose Reconnect the
power cord properly
