ABB HiPerGuard MV UPS User manual

© Copyright 202
3
ABB, All rights reserved.
—
MEDIUM VOLTAGE UPS
HiPerGuard MV UPS
User Manual

HIPERGUARD SUPPORTS SUSTAINABILITY WITH THE HIGHEST LEVELS OF EFFICIENCY AVAILABLE ON
THE MARKET, AT 98 PERCENT – TRANSLATING TO A POTENTIAL CARBON EMISSION REDUCTION OF 1,360
TONS OVER A TYPICAL 15-YEAR LIFESPAN.
https://new.abb.com/ups/
2
/
104
—
ABB's HiPerGuard MV UPS is
an industry-first that provides
a continuous and reliable power
supply of up to 24 kV for mission
critical facilities to protect loads,
whilst reducing downtime.
HiPerGuard supports sustainability
with the highest levels of
efficiency available on the market,
at 98 percent – translating to a
potential carbon emission reduction
of 1,360 tons over a typical 15-year
lifespan.

ABOUT THIS DOCUMENT
https://new.abb.com/ups/
3
/
104
—
About this document
Document information
Copyright notice
The information in this manual is subject to change without notice.
This manual and parts thereof must notbe reproducedor copied,or disclosed to third parties, nor used
for anyunauthorized purposewithout written permission from ABB Ltd. The hardwareand software
described in thismanual areprovided under a licenseand may beused,copied, or disclosed onlyin
accordancewith thetermsof suchlicense.
Document identification
Document number: 2UCD400000E001
Ownership: ABB Ltd., Power Conditioning Products
Issue date: October, 2023
Revision: Rev C
Contact information
Address: ABB Ltd., Napier 4110, 111, Main North Road,New Zealand
Website: https://new.abb.com/ups
Equipment covered by the manual
This manual covers the HiPerGuardMV UPS product and provides general informationregarding:
– Generalfunctions of theMV UPS
– Operation
– Component enclosures
– Graphical DisplayModule (GDM)
– Control and adjustments
This manual does not claim tocover all variations and details of theHiPerGuard MV UPS, nor to consider
all eventualities thatmayarise during theoperation of theproduct. Installation,commissioning, and
maintenanceof the product arecovered in other documents, as listed in thefollowing section.
If the MV UPSis adaptedtospecific customerneeds or applications, andhandling,installation, and
operation of theproduct are affectedby these modifications,theextra information required will be
provided in separatedocumentation. Some productsmay differ from theconfiguration hereby
presented. Refer to the “as-built” documentation for details. If information is requiredbeyond the
instructions inthis manual, please referthe matter toABB.

ABOUT THIS DOCUMENT
https://new.abb.com/ups/
4
/
104
Target groups and required qualifications
The product presented in this manual is part of aCAT III/IV environment wherevoltages are present that
containa potentialhazard of electric shock and/or burn. For this reason, only personnel who have a
thorough knowledge of the MV UPS and the industrial environment and have obtainedthe required
qualification may handle, install, operate,or maintainthe product.
The manual addresses personnel who areresponsible for unpacking, transportation, installation,
operation, and maintenanceof the MVUPS. The personnel shall carry out thelistedtasks in amanner
that does not cause physical harm or danger,and thatensures the safe and reliable functioning of the
product.
Handling and Installation
Handling
The personnel shall be skilledand experienced in unpacking andtransporting heavy equipment.
Mechanical installation
The personnel shall be qualified to prepare the installation site accordingto the site and equipment
requirements andto perform the installation accordingly.
Commissioning of the HiPerGuard must only be performed by qualified and
certified ABB personnel.
Electrical installation
The personnel shall have a soundknowledgeof the relevant electrical codes andspecifications covering
low and medium voltage equipment, be experienced with electrical wiring principles, and knowthe
electrical symbols typically used in wiring diagrams.
Operation
The personnel include all persons whooperatethe HiPerGuardfrom the Graphic Display Module (GDM).
Those people mustknowthe functions of the GDM, be adequately trainedfor the MV UPS, and
understand its operation process.
Maintenance
The personnel include all persons who:
– Are qualifiedto carry out preventiveand corrective maintenance on MV UPS as described in this
manual.
– Are thoroughly familiar with theproduct.
– Have a sound knowledgeof therelevant electricalcodes and specifications covering lowand medium
voltage equipment.
– Are able toassessthe hazards associatedwith the energy sourcesof theMV UPS system and act
correspondingly.
– Knowthe safe shutdown andgrounding procedures for the MV UPSsystem.
– Are familiarand understand the instructions contained in the Service manual.

ABOUT THIS DOCUMENT
https://new.abb.com/ups/
5
/
104
Responsibilities of the user
It is theresponsibility of those in charge of theHiPerGuard MV UPSto ensure thateachperson involved
in the installation, operation or maintenance of the product has received the appropriate training and
has thoroughlyread and clearlyunderstood the instructions in this manual andthe relevant safety
instructions.
Intended use of equipment
Those inchargeof the HiPerGuardMV UPSshall ensurethattheproduct is onlyused asspecified in the
contractualdocuments, operated under the conditions stipulated in the technicalspecifications andon
the rating plateof the product, and serviced in the intervals as specified by ABB.
Use of theHiPerGuard MV UPSoutside the scope of the specifications is not permitted and canleadto
malfunction or hazardous situations. Intended equipment usealso implies that only spare parts
recommended and approvedby ABB maybe used.Unauthorized modifications andconstructional
changes of theHiPerGuardMV UPS cancause malfunction and result in hazardous situations. Therefore,
such modifications are not permitted.
Quality certificates and applicable standards
The following certificatesand conformity declarations are availablefrom ABB:
– ISO 9001certificatesstating that ABB Ltd in Napier has implemented and maintains amanagement
systemthat fulfils the requirements of the normative standards.
– EC conformity declaration.
– List of the standards the MVUPS complieswith:
•IEC62040-3 VI SS 111.
• IEC62477-2.
•IEC61000-6-2.
•WEEE.
• IEC60076 (for themedium voltage magnetics).
Items covered by delivery
Deliverycomprises the following items:
– HiPerGuardMV UPSlow voltage Power Conversion Unit (PCU). This is a plinth with six enclosures
already installed and interwired.The sixenclosures are: DCT enclosure, APS enclosure, Utility
enclosure,3 x PE120 enclosures.
– HiPerGuard MV UPS Medium Voltage Magnetics (MVM) enclosure.
– Nuts, bolts, washers, brackets, plinth covers andothermetalwork partsrequiredto interconnect PCU
to MVM enclosure.
– Communicationsand fanpower cables tointerconnect PCU to MVM enclosure.
– Fiber cabletointerconnect HiPerGuard MV UPS to Medium Voltage Switchgear enclosure.
For information on items supplied, see the shipping note.
Identifying the delivery
The HiPerGuard and accessories are identified by the type code printed on the rating label. The label
provides information on the HiPerGuard MV UPS ratedvoltage,frequency, rated current and auxiliary
power supply.

ABBREVIATIONS & TERMS
https://new.abb.com/ups/
6
/
104
—
Abbreviations & Terms
The following table lists terms and abbreviations users shouldbe familiar with when usingthis manual.
Some of the terms andabbreviations used in the manual areunique to ABB andmight differ from the
common use.
Abbreviation/Term Meaning
APS AuxiliaryPower Supply. APS is an enclosure that contains the MVUPS
switched-mode power supplies, remote input/outputmodules, control
circuits and auxiliary transformers.
Bypass isolate state A statewherethe MV UPS is not operating, input and output breakersare
opened, and the automatic bypass breakeris closed.
Bypass mode The term isused todescribethesystem in bypass (not operating).When in
bypassmode, the bypass breaker is closed, and the input and output
breakers are opened.
CXF Coupling Transformer. CXF is a transformerthat couples themedium
voltagenetwork to thelow voltage power converters.
DCT Direct Current Termination. DCT is an enclosure wherethe energy storage
cables are terminated and connectedto theMV UPSPE120 cabinets.
EMC
ElectromagneticCompatibility. All measures to suppress electromagnetic
disturbancescaused bydifferent electrical equipmentin the same
electromagneticenvironment,and to strengthen the immunity of the
equipment to such disturbances.
EOA End of Autonomy. EOA refers to the end of the specified back-up autonomy
timeof the energy storage.
EOD End of Discharge. EODrefers to the state of energystorage when itis fully
depleted.
GDM Graphical DisplayModule.Has thelocal HumanMachine Interface(HMI)and
it is located in the PE120-1 enclosure.
HUB Two HUB controllers arelocated in PE120-2 and PE120-3 cabinets respectively. The main function is to transfer theinformation tothe system
controller.
ILR Isolating LineReactor. ILR is amedium voltageimpedance connected in
series, between the gridand the load.
IM IndependentMode. When operating on this mode, the MV UPS disconnects from the gridby openingthe input circuit breaker and supplies the load
through the energy storage.

ABBREVIATIONS & TERMS
https://new.abb.com/ups/
7
/
104
Abbreviation/Term Meaning
Island state A statewherethe MV UPS decided to go into independent modeby opening
the input circuit breaker and supplying the load through the energystorage.
Line voltage RMS lineto line voltageof the main power supplyof the MVUPS input.
LV Low Voltage. Voltage level up to 1000 Vac or 1500 Vdc.
MV Medium Voltage. Voltage level between 1 kVac and 35 kVac.
MVM Medium VoltageMagnetics. The MVM consists of thecouplingtransformer
and the isolating line reactor.
PCB Printed Circuit Board
PCC
Point of Common Coupling. The PCC isthe point in the electrical power
supply system wherethe responsibility of the utility changesto the
industrial customer. Theutility is responsible for providing clean voltage
and current with respect toharmonic distortion up to the PCC.
The industrial customer is responsiblenot to distort voltage and current by
its electrical systems
PCM PowerConditioning Mode. When operating on this mode, the MV UPS
continuously conditions theload voltage.
PCM_Active state A statewherethe gridinput voltageis out of thresholdand theMV UPSis
keeping the load voltage within specified limits while monitoring to decide
whether to disconnect from the grid.
PCM_Normal state A statewhere the gridinput voltageis within specified limits and the MV
UPS continuously conditions the loadvoltagetothe system nominal voltage
value while the utility is sup-plying the loadactivepower requirements.
PCS120 PowerConversion System 120. The PCS120 is the product platform for the
ABB power conditioning products.
PCU PowerConversion Unit. The PCU consists of theLV enclosures of the
HiPerGuard MV UPS unit.
PE120-N Platform Enclosure120. PE120 is the enclosurethatcontains several PCS120
modules. The product has three enclosures designatedas PE120-1, PE120-2
& PE120-3.
PEBB Power ElectronicBuilding Block
PE-E Protective Earth
PE-I Inverter Earth
Resynchronizing state A statewherethe MV UPS resynchronize to the grid inputvoltage and
commands the input circuit breaker to close when the grid voltage is back
and stable for reconnection.
RTD ResistanceTemperature Detector. The RTD is a temperature sensor where
the change in electrical resistance is used to measurethe temperature.

ABBREVIATIONS & TERMS
https://new.abb.com/ups/
8
/
104
Abbreviation/Term Meaning
Sabp
AutomaticBypass Switch. Represents the designation of the bypass circuit
breaker that bypasses the MV UPS system andconnects the grid directlyto
the load.This breakeris automaticallycontrolledby the MVUPS.
Sin Input Switch.Represents the designation of the input circuit breaker
connecting the MV UPSto the grid.
Smbp
Maintenance Bypass Switch. Represents the designation of the external
maintenance bypasscircuit breaker that bypasses the MV UPS system and
its automaticbypass switchgear and connects thegrid directly to the load.
This breakeris not controlled bythe MV UPS.
SC System Controller. Universal controllerlocated in the PE120-1 enclosure.
SOC Stateof Charge. SOC refers to the stateof chargeof the energystorage
connected to the MV UPS.
Sout Output Switch.Represents the designation of the output circuit breaker
connecting the MV UPSto the load.
Startingstate
A statewherethe MV UPS ramps its output voltagefrom zero to
input/output voltage magnitude, synchronizes to frequency andphase,
closesthe output and input circuit breakers and opens the automatic
bypass circuit breaker.
Stopping state A statewherethe MV UPS synchronizes the input tothe output voltage,
closesthe automaticbypass circuit breaker and opens theinput/output
circuit breakers.
UC Universal Controller
UPSS Uninterruptible Power Supply System. Refers to the HiPerGuard MV UPS unit (or multipleunits) in addition to the medium voltage switchgearand the
energystorage.
UPSU Uninterruptible Power Supply Unit.Refers toa singleHiPerGuardMV UPS
machine.
ZISC Impedance Isolated StaticConverter. ZISC refers to the architecture of the HiPerGuard MV UPS where the static power converters of the MV UPS are
isolated from the grid via an impedance.

TRADEMARKS & RELATED DOCUMENTATION
https://new.abb.com/ups/
9
/
104
—
Trademarks
Names that are believedto be trademarks of other companies and organizations aredesignatedas
such. The absence or presenceof sucha designation should howevernot be regarded as an offenceof
the legalstatus of any trademark. The following registrations andtrademarks are usedin this manual:
Abbreviation/Term Meaning
Modbus® Registered trademark of Schneider Electric USA, Inc
HiPerGuard® Registered trademark of ABB NewZealand Ltd.
—
Related documentation
The following documents are available for furtherinformation:
Document title Document type Document number
HiPerGuard MV UPS Installation Manual Installation Manual 2UCD400000E003
HiPerGuard MV UPS Commissioning Manual Commissioning Manual 2UCD400000E004
Layout Drawings Drawings 2UCD400000E103
Service Manual Service 2UCD400000E411
HiPerGuard MVUPS Switchgear Interface Schematics 2UCD000500E3092
HiPerGuard MV UPS System Schematics Schematics 2UCD000505E302 and
2UCD000505E303

INTRODUCTION
https://new.abb.com/ups/
10
/
104
—
Introduction
Thank you for selecting ABB as your preferredsupplierof critical power equipment and congratulations
on your choiceof the HiPerGuard MVUPS toprotectyour installation.
The HiPerGuardMV UPSis themedium voltageUPS intendedfor multi-megawatt power protection.
Based onthe impedance isolated staticconverter (ZISC) architecture, the HiPerGuard MV UPS
introduces a flexible solution with high reliability and high efficiency for critical power installations.
Please carefully readthis User Manual,which containsall the necessary information and describes all
you needto knowaboutthe use of the HiPerGuard.
The UserManual describes the functionof theHiPerGuard, its operation, systemcomponents, the
meaning of thesystem events relatedto the user interface and provides procedures for starting and
stopping the equipment.
Please refer to the Installation Manual, which describes howto prepare the installation site,and
provides weight,dimensions andprocedures for moving, installing, andconnecting the HiPerGuard.
While every care hasbeen taken to ensurethe completeness and accuracy of this manual, ABB assumes
no responsibility or liability for anylosses or damages resulting from the use of the information
contained in this document.
Thank you for choosing ABB!

CONTENTS
https://new.abb.com/ups/
11
/
104
—
Contents
1. Safety .......................................................................................................................................................13
1.1. Safety notices ..............................................................................................................................................16
1.2. General safety information...................................................................................................................... 18
1.3. Possible residual risk................................................................................................................................. 18
2. Cyber Security Legal Disclaimer............................................................................................................19
2.1. Deployment guidelines..............................................................................................................................19
3. Product Description............................................................................................................................... 20
3.1. Single line diagram....................................................................................................................................20
3.2. Operating principle.....................................................................................................................................21
3.3. Major MV UPS components.....................................................................................................................32
3.4. Cooling system...........................................................................................................................................38
4. Model definition.....................................................................................................................................40
4.1. Platform code..............................................................................................................................................40
4.2. Product code...............................................................................................................................................40
4.3. System frequency.......................................................................................................................................40
4.4. Medium voltage magnetics design........................................................................................................40
4.5. Medium voltage cable entry.................................................................................................................... 41
4.6. System voltage........................................................................................................................................... 41
4.7. Energy storage code................................................................................................................................. 41
4.8. DC cables entry........................................................................................................................................... 41
4.9. System configuration................................................................................................................................ 41
4.10. Installation...................................................................................................................................................42
4.11. Layout...........................................................................................................................................................42
4.12. Power Exchanger interface......................................................................................................................42
4.13. Standbygenerator.....................................................................................................................................42
4.14. Standard.......................................................................................................................................................42
4.15. Options (Plus Codes).................................................................................................................................43
5. Technical specifications........................................................................................................................44
5.1. Utilityinput..................................................................................................................................................44
5.2. Loadoutput.................................................................................................................................................45
5.3. EnergyStorage...........................................................................................................................................45
5.4. MV Switchgear............................................................................................................................................46
5.5. Environmental conditions........................................................................................................................46
5.6. Interface.......................................................................................................................................................47
5.7. Dimensional data.......................................................................................................................................48
6. External power and control connections.............................................................................................49
6.1. Overview of external connections..........................................................................................................49

CONTENTS
https://new.abb.com/ups/
12
/
104
6.2. Medium voltageconnections to MVM enclosure................................................................................49
6.3. Energystorageconnections to DCT enclosure...................................................................................50
6.4. Power and I/O interfaces toAPS enclosure.........................................................................................50
6.5. Communication between MV UPS andMV Switchgear.....................................................................60
6.6. Modbus TCP/Web interfaces................................................................................................................... 61
6.7. Communication between MV UPSunits inparallelconfiguration..................................................62
7. User Interface......................................................................................................................................... 63
7.1. Graphic Display Module (GDM)...............................................................................................................63
7.2. Web Interface.............................................................................................................................................. 87
7.3. Ethernet Interface......................................................................................................................................87
8. Operation................................................................................................................................................88
8.1. Machine State Flowdiagram...................................................................................................................88
8.2. System Start................................................................................................................................................90
8.3. System Bypass............................................................................................................................................95
8.4. Independentmode....................................................................................................................................96
8.5. Resynchronizemode.................................................................................................................................98
8.6. System EPO (Emergency Power OFF)...................................................................................................98
8.7. Hard fault.....................................................................................................................................................99
8.8. Energystorage depleted........................................................................................................................100
9. Maintenance Schedule..........................................................................................................................101
9.1. Overview......................................................................................................................................................101

SAFETY
HIPERGUARD MV UPS
USER MANUAL
13
/
104
1. Safety
AR
! رﯾذﺣﺗ:دﮭﺟﻲﺋﺎﺑرﮭﻛرطﺧ
ﻊﺟارتﺎﻣﯾﻠﻌﺗلﯾﻐﺷﺗﻟا .
لﺻﻓاءﺎﺑرﮭﻛﻟامﻗوﺎﮭﻧﯾﻣﺄﺗﺑلﺑﻗلﻣﻌﻟاﻲﻓاذھزﺎﮭﺟﻟا
ﮫﯾﺑﻧﺗ!بﺟﯾمدﻋبﯾﻛرﺗﻟاﻻإنﻣلﻼﺧصﺧﺷﻰﻠﻋﺔﯾاردلﺎﺟﻣﺑﺔﯾﻧﻘﺗﻟاﺔﯾﺋﺎﺑرﮭﻛﻟا .
BG
Предупреждение: Опасно напрежение!
Вижте инструкциите за работа.
Изключете иблокирайте захранването преди да работите сустройството.
Внимание!Да се монтира само от експерт електротехник.
CS
Varování: Nebezpečné napětí!
Viz návod k obsluze.
Před zahájením pracína tomto zařízení odpojte a uzamkněte napájení.
Pozor!Toto zařízení smí instalovat pouze osoba s elektrotechnickou odborností.
DA Advarsel: Farlig elektrisk spænding!
Se betjeningsvejledningen.
Frakobl enheden, og afbryd strømforsyningen, før du arbejder med denne enhed.
Giv agt! Installation måkun foretagesaf personer medelektroteknisk ekspertise.
DE
Warnung:Gefährliche Spannung!
Siehe Bedienungsanleitung.
Vor dem ArbeitenGerät ausschaltenund von der Spannungsversorgung trennen.
Achtung! Installation nur durch elektrotechnische Fachkraft.
EL
Προειδοποίηση: Επικίνδυνη τάση!
Ανατρέξτε στις οδηγίες λειτουργίας.
Αποσυνδέστε και απομονώστε την παροχή ισχύος προτού ξε κινήσετε τις εργασίες σε
αυτήν τη συσκευή.
Προσοχή! Ηεγκατάσταση πρέπει να γίνεται μόνο από αδειούχο ηλεκτρολόγο
εγκαταστάτη.
EN
Warning: Hazardous voltage!
Refer to installation instructions.
Disconnect andlock out power beforeworking on this device.
Attention! Installation by person with electrotechnicalexpertise only.
ES
Advertencia: ¡Tensión peligrosa!
Consulte las instrucciones de funcionamiento.
Antes detrabajar con estedispositivo, desconectey bloquee la corriente.
¡Atención! Lainstalación debe ser realizadaúnicamente por un técnico electricista.
ET
Hoiatus: Elektrilöögioht!
Lisateavet vaadake kasutusjuhendist.
Enne selle seadmega töötamist ühendage lahti ja lukustage toide.
Tähelepanu! Seadet tohib paigaldada ainult elektrotehnilise kogemusega isik.
FI
Varoitus: Vaarallinen jännite!
Katso käyttöohje.
Katkaise virta ja estä virran kytkeminen lukituksellaennen töiden aloittamista.
Huomio!Asennuksen saasuorittaa vain henkilö,jolla on kokemusta sähkötekniikasta.

SAFETY
HIPERGUARD MV UPS
USER MANUAL
14
/
103
FR
Avertissement: Tension dangereuse!
Consultez les consignes d’utilisation.
Débranchezet verrouillez l’alimentation électrique avant d’entreprendre des travaux sur
cet appareil.
Attention! L’installation doit être effectuée uniquement par une personne ayantune
expertise en électrotechnique.
HR
Upozorenje: Opasan napon!
Pogledajte upute za uporabu.
Odspojite i isključite struju prije radana ovomuređaju.
Pažnja! Ugradnja je dopuštena samo osobama stručnim u području elektrotehnike.
HU
Figyelmeztetés: Veszélyes feszültség!
Lásd a használati utasítást.
Válassza le és zárja ki az áramellátást, mielőtt a berendezésen dolgozni kezd.
Figyelem! Az üzembe helyezést csakelektrotechnikaiszakértelemmelrendelkezőszemély
végezheti el.
IT Attenzione: Tensione pericolosa!
Fare riferimento alle istruzioni per l’uso.
Prima diinterveniresu questo dispositivo, scollegare e isolare tutte lefonti di
alimentazione.
Attenzione! L’installazione deveessere eseguita esclusivamente da un installatore
qualificato.
LT
Įspėjimas: Pavojinga įtampa!
Žr. naudojimo instrukcijas.
Atjunkite ir laikinai užblokuokite maitinimąprieš dirbdami su šiuo įrenginiu.
Dėmesio! Įrengti gali tik asmuo, turintis elektrotechniko patirties.
LV
Brīdinājums: Bīstams spriegums!
Skatiet darba norādījumus.
Pirms sākat darbu ar šo ierīci, atvienojiet un bloķējiet strāvas padevi.
Uzmanību! Uzstādīšanu drīkst veikt tikai persona arzināšanām par elektrotehniku.
NL
Waarschuwing:Gevaarlijke spanning!
Raadpleeg de bedieningsinstructies.
Koppeldit apparaat los van de stroomvoorziening voordatu werkzaamheden uitvoert.
Let op! Installatie mag alleen worden uitgevoerd door een monteur met
elektrotechnische expertise.
NO
Advarsel: Farlig spenning!
Se i bruksanvisningen.
Koblefra og steng av strømmen før du arbeiderpå denne enheten.
Forsiktig!Montering skalkun utføres av kvalifisertepersoner med elektrokompetanse.
PL
Ostrzeżenie: Niebezpieczne napięcie!
Patrz: instrukcja obsługi.
Przed rozpoczęciem wykonywaniapracy z tymurządzeniem odłącz i zablokuj zasilanie.
Uwaga! Montażmoże wykonywaćwyłącznie osoba posiadająca doświadczenie
elektrotechniczne.

SAFETY
HIPERGUARD MV UPS
USER MANUAL
15
/
103
PT
Aviso: Tensão perigosa!
Consulte as instruções de operação.
Desconecte e desligue a energia elétrica antes detrabalharnesse dispositivo.
Atenção! A instalação deveser feitaapenas por umapessoa com especialidade
eletrotécnica.
RO
Avertisment: Tensiune electricăpericuloasă!
Consultați instrucțiunile de utilizare.
Deconectați și închidețisursa de energieînainte dea lucra cu acest dispozitiv.
Atenție! Instalare
RU
Внимание: Опасное электрическое напряжение!
Обратитесь кинструкциям по эксплуатации.
Отключите питание иобесточьте устройство перед началом работ.
Внимание! Установка должна выполняться только специалистом по
электротехническим работам.
SK
Výstraha: Nebezpečné napätie!
Pozrite si návod na použitie.
Pred začatím prácna tomto zariadení odpojtea zablokujte napájanie.
Pozor! Inštaláciu smie vykonávaťlen osobas odbornými znalosťami v oblasti
elektrotechniky.
SL
Opozorilo: Nevarna napetost!
Glejte navodila za uporabo.
Pred delom na tejnapravi izklopitein zakleniteelektrično napajanje.
Pozor! Namestitevsme izvesti samo elektrotehnični strokovnjak.
SV
Varning: Livsfarlig spänning!
Se i bruksanvisningen.
Frånkoppla och blockera anläggning eller en anläggningsdel innan arbeiteutförs.
Obs! Får endast installeras av behörig elektriker.
TR
Uyarı: Tehlikeli gerilim!
Çalışma talimatlarına bakın.
Bu cihaz üzerinde çalışmadan önce elektriği kesin ve kilitleyin.
Dikkat! Yalnızca elektroteknik uzmanlığa sahip kişiler tarafından kurulabilir.
ZH
警告：高压危险!
请参⻅操作手册
操作本设备前请断开并锁定电源。
注意！安装仅限专业电工人员。
Safetyinstructions are used to highlight a potential hazard when working on the equipment.
Safety instructions shall be strictly followed! Non-compliancecan jeopardize the safety of personnel, the
equipment andthe environment.
This manual contains important information regarding theoperation of theHiPerGuard and provides
technical and operational guidancefor operators. Thefollowingsafetyinstructions shall be observed.

SAFETY
HIPERGUARD MV UPS
USER MANUAL
16
/
103
1.1. Safety notices
Symbol/sign Meaning
DANGER
This manual provides information for thesafe operation of the HiPerGuard. It does NOT
provide installation, commissioning,or service information. For such information,refer
to the appropriate document.
C A U T I O N – Trained operators
All operations on the HiPerGuard shall onlybe carriedout bya trained operator familiar
with the contents of this manual.Hazardous conditions could arise from incorrect
adjustment.
D A N G E R – Hazardous voltages
An Operator shallnot open doors or panels markedas containing hazardous voltages.
Manyparts in this product, including printedcircuit boards operate atlethal high
voltages. Stored energycomponentssuch as batteriesand capacitors can holdthis
voltageevenafter theopening of isolation switches.
DO NOT TOUCH components or connections that may have voltage present.
D A N G E R – High voltages
Lethal high voltages arepresentinside theMVM and MediumVoltage Switchgear
enclosures undernormaloperation or faultconditions.Do not remove anypanels or
guards. This mayonly be done bytrainedtechnical personnel after following the
stipulatedisolation, groundingand lock-out procedures.
DO NOT TOUCH components or connections that have voltage present.
D A N G E R – Stored charge
Storedcharge is present after the deviceis switched off. When the HiPerGuard is
powered down, lethal voltages will remainin the energy storage elements and the
completeHiPerGuardMV UPS should be considered live. To remove this hazard, energy
storage will needto be isolated and lockedoff, and filter capacitors discharged.
This mayonly bedone bytrained technical personnel while following the stipulated
isolation, grounding and lockout procedures.
D A N G E R – Protective covers
Normaloperation of this product requires all protective covers to be in place and all
doors closed and secured.
DA NG ER – Personal Protective Equipment
Ensuresafety glasses and other appropriate PPEare worn while working if any part of
the unit couldbe energized. Observe siterequirements for PPE while operating this
equipment.

SAFETY
HIPERGUARD MV UPS
USER MANUAL
17
/
103
Symbol/sign Meaning
D A N G E R – Arc flash
Arc flash isa dangerous phenomenon associated with operation at medium voltages.
It may be causedby switchgear failure, insulation breakdownor foreign object
intrusion. It may result in severe burns, severe eye injury, blindness or death.To
minimizethe risk,keepall doors closed and covers inplace whileoperating the
equipment.
Observe anyarcflash protection boundaries thatmay be in place around the MVM and
Medium Voltage Switchgear enclosures
DA NG ER – Potential material hazardof batteriesand capacitors
If a battery or capacitor isdamagedelectrically or physically, theresultingdebris could
representa material hazard.Refer to the appropriateMaterialSafety Data Sheetfor
information on safe handling and disposal.
Safetylabels areattached to the enclosures to alert personnel of potentialhazards when working on the
equipment.The instructions on thesafety labels mustalways be followed,and thelabels must be kept in
a perfectly legible condition.

SAFETY
HIPERGUARD MV UPS
USER MANUAL
18
/
103
1.2. General safety information
1.2.1. Operator duties
The scope of work for anoperator of the HiPerGuardis to control and monitor theHiPerGuard from the
GDM, remotestart/stop controls, or from theweb page. An operator is not normally authorized to
undertake anymaintenance, service,or repair work. The operator maybe authorized to provide
assistance to a maintenance, service,or repairtechnician, by performing his or her duties under the
direction of a service team.If so, the operator must bewearing PPE tothe same level as those of the
service team.
1.2.2. Before energization
Beforethe HiPerGuard is energized, inspect to makesure:
– Any maintenance work beingdone on theHiPerGuard has been completedand all tools and
equipment are removed.
– All covers onthe MVUPS enclosures are securely fastened, and all doors areclosed,locked,and/or
bolted.
1.2.3. In case of fire
In caseof firein the electrical room:
– Observe theestablished rules and regulations for fireprotection.
– Only fireman with appropriate personal protective equipment is allowed to enter the electrical room.
1.3. Possible residual risk
The following risks can arisefrom a HiPerGuardsystem and pose a hazard to people. These risksmust
therefore be considered by the system integrator and/or the plant owner when assessing the risks of
the machinery.
The HiPerGuard is a high energypower conversion machine.Components may be dislodged, or
damaged while being transported, installed, commissioned,operatedor serviced, due to,for example:
–External influence on,or damage to the equipment
– Wrong parameter settings
–Operation of the equipment outsidethe scope of thespecifications
–Faulty hardware.
Any one of thesefaults may cause thenoisy ejection of high temperature materialsand gases.
Hazardous touchvoltages can bepresent on the HiPerGuard system components caused by, for
example:
–Operation of the equipment outsidethe scope of thespecifications
–External influence on,or damage to the equipment
– Induced voltages by external equipment
–Condensation on equipment components or pollution
–Faulty hardware.
For all the abovereasons, alwaysoperatewith all sidepanels in place and all doors shut and latched.

CYBER SECURITY LEGAL DISCLAIMER
HIPERGUARD MV UPS
USER MANUAL
19
/
103
2. Cyber Security Legal Disclaimer
Overview
This product is designed to be connected to and to communicate information and data vianetwork
interface.
It is thecustomer’s soleresponsibility to provide and continuouslyensurea secureconnection between
the product and customer network or anyother network (as thecase maybe). Customer shall establish
and maintain any appropriate measures (such as but not limited to the installation of firewalls,
application of authentication measures, encryption ofdata, installation of anti-virus programs,etc.)to
protect the product, thenetwork, its system and the interface against anykind of security breaches,
unauthorized access, interference, intrusion, leakage and/ or theft of data or information.
ABB andits affiliates arenot liable for damages and/or losses related tosuch security breaches,any
unauthorized access, interference, intrusion, leakage and/or theft ofdata or information.
2.1. Deployment guidelines
The recommended Cyber Security deployment for the HiPerGuard MV UPSis for it tobe only usedin a
trusted network with restricted access. The user is responsible for creating a defense-in-depth
protection by allocating firewall solutions toeach network.
For secureremoteaccess,use a VPNconnection – theHiPerGuard MVUPS is not approvedby ABB for
direct Internet connection.The user of theproduct should beaware that theunsecurenature of the
Modbus TCPprotocol exposes the communication betweenthe product and thecontrol system.
Authentication and integrity of transmittedinformation is notprovidedby the protocol. This enables
certain types of attacks, such as man-in-the-middle attacks, eavesdropping attacks andreplayattacks
for instance. The main security is providedthrough monitoring cybersecurity, topology (asset
management) and correct operation ofthe data networks usingthecybersecurity monitoring modules
and features of thefirewalls and managedswitches.

PRODUCT DESCRIPTION
HIPERGUARD MV UPS
USER MANUAL
20
/
103
3. Product Description
Overview
The ABB HiPerGuard MV UPS is a high-performance high-efficiency UPS system that ensures protection
from power quality events,enablingthe continuous conditioned power supply tosensitive and critical
loads.
Based on the ZISC (Impedance IsolatedStatic Converter) architecture, the HiPerGuard MVUPS uses a
special coupling reactor combined with PEBB120 inverter modulesto interfacefrom theutility to the
load. Thereactor acts as a barrier, preventing grid disturbances to reach the load and improves the
powerfactor seen from the gridside.
It is usedto protect sensitive loadsfrom thefull spectrum ofutility voltage events and combinedwith a
wide range of energystoragesolutionsABB’s ZISC provides autonomiesfromseconds to many minutes.
The equipment is connected to the medium-voltage network through theMV switchgear. Theinput
breaker connects the power supply to theMV UPS,which also has an active role in the normal operation.
The output breakerconnectsthe MV UPSto the load, and a bypass breaker is connected between the
whole MVUPS system, as shown in the singleline diagram.
3.1. Single line diagram
Figure3.1: HiPerGuard MVUPS Single Line Diagram
