Zeiss TERRA ED 8 x 32 User manual

Gebrauchshinweise / Garantie
Instructions for use / Guarantee
Mode d’emploi / Garantie
Istruzioni d'impiego / Garanzia
Modo de empleo / Garantía
Bruksanvisning / Garanti
Kayttöohje / Takuu
Pokyny k používání / záruka
Informacje dotyczące użytkowania / Gwarancja
Használati utasítás / Jótállás
Инструкция по применению / Гарантия
使用提示 / 质保
使用上の注意 / 保証
ZEISS. INNOVATIVE SINCE 1846.
This product may be covered by one or
more of the following United States patents:
US6542302, US6816310, US6906862
000000-2113-044 / 10.2014
This applies to all countries except US and Canada!
ZEISS ZEISS

54
Technische Daten 8 x 32 10 x 32 8 x 42 10 x 42
Vergrößerung 810 810
Wirksamer Objektivdurchmesser (mm) 32 32 42 42 Austrittspupillen-Durchmesser (mm) 4.0 3.2 5.3 4.2
Dämmerungszahl 16.0 17.9 18.3 20.5 Sehfeld (ft/1000 yds)
(m/1000 m)
442 135
367 112
375 125
330 110
Subjektiver Sehwinkel (°) 60 63 56 60 Naheinstellgrenze (ft / m) 4.9 / 1.5 5.25 / 1.6 Dioptrienverstellbereich (dpt) +/– 4 Austrittspupillenabstand (mm) 16.5 18 14 Pupillendistanz (mm) 56 - 74 57.5 - 76
Objektivtyp ED Prismensystem Schmidt-Pechan Vergütung Hydrophobic Zeiss MC Stickstofffüllung Ja Wasserdicht (mbar) 100 Funktionstemperartur (°F / C°) –5° / +140° –15° / +60°
Länge (in / mm) 4.9 / 125 5.5 / 142
Breite bei einer Augenweite von 65 mm (in / mm) 4.37 / 111 4.7 / 120 Gewicht (oz / g) 17.98 / 510 24.5 / 695
Änderungen in Ausführung und Lieferumfang, die der technischen Weiterentwicklung dienen, sind vorbehalten.
INSTRUCTIONS FOR USE
Congratulations on purchasing your new ZEISS TERRA®ED binoculars. Enjoy the impressive
experience of undistorted image reproduction which is distinguished by perfect brilliance and
excellent colour accuracy.
ZEISS products are famous for outstanding optical performance, precision engineering and a
long service life. Please observe the following instructions for use in order to obtain the best
from your product and to ensure that it remains your constant companion for many years to
come.
Information for your safety
Environmental influences
� Do not under any circumstances look through the binoculars at the sun or laser light sources!
Serious eye injury may otherwise result.
� Never leave the binoculars in the sun for extended periods of time without the protective lens
cap. Extreme exposure to direct sunlight through the objective lens and eyepiece can function
as a burning glass and damage the interior components.
Danger of swallowing
Never leave the removable outer parts in reach of children (danger of swallowing).
Table of contents
Description of the components 6
Contents 6
Viewing with and without glasses 6
Adjustment of the interpupillary distance 6
Focusing 7
Mounting the carrying strap and the protective covers 7
Use of the eyepiece cap 7
Use of the protective lens cap 7
Mounting on a tripod 8
Care and maintenance 8
Replacement parts for ZEISS TERRA ED 8
Technical data 9
Guarantee 62

76
Description of the components
1Diopter compensation
2Eyecups
3 Focusing knob
4Carrying strap eyelets
Contents
ZEISS TERRA ED binoculars
Product Order number Scope of supply
8 x 32
8 x 42
52 32 05
52 42 05
Binocular
Eyepiece cap
Protective lens cap
Strap for fastening protective lens cap
Carrying strap
Bag
Lens cleaning cloth
User instructions
Warranty
10 x 32
10 x 42
52 32 06
52 42 06
Viewing with and without glasses
When viewing without glasses, fully extend both eyecups. To do this, turn the eyecup (Fig. 4) to
the left (counter clockwise) and upwards to the top click stop position (Illustration A).
The eyecups can be locked in four positions – at the bottom and top and in two middle posi-
tions. These adjustment options allow the distance of the eye from the exit pupil to be adjusted
according to the specific need of each user.
When viewing with glasses, turn the eyecup down to the right (clockwise) until it locks in the
bottom click stop position (Illustration B).
Adjusting of the interpupillary distance
Adjust the two barrels by pivoting them around the center hinge until you see one circular field
of vision when viewing with both eyes.
Focusing
The binoculars have a focusing knob (Fig. 1/3) and a diopter adjustment wheel (Fig. 1/1).
To adjust, close your right eye and focus the image in the left barrel using the center focusing
knob (Fig. 1/3). Then close your left eye and, if necessary, adjust the focus in the right barrel
using the diopter adjustment wheel (Fig. 1/1).
The diopter adjustment has a“+” and “–” an index point as a reference when setting
the diopter adjustment for different users.
Note: Always use the same object to focus both images!
Once adjusted, use only the focusing knob for varying distances. (Fig. 1/3).
Mounting the carrying strap and the protective covers
The carrying strap is supplied with the binoculars. Attach the carrying strap to the eyelets
provided on the binoculars, and mount the eyepiece cap on the strap as shown in Figs. 2, 3
and 5.
The strap for the protective lens cap is attached directly (either right or left) to the protective lens
cap. To fasten on the device, use either the carrying strap or one of the two carrying strap eyelets.
Note: Simply pass the carrying strap through the eyelets on the eyepiece cap. Before attaching
the carrying strap, as shown in Fig. 3, the strap length should be set at the desired length by
shortening or lengthening the strap.
Follow the same sequence for the opposite side. Some prefer to thread through the cap on both
sides, and some on only one.
Use of the eyepiece cap
The eyepiece cap is kept in the objectiv apertures. Remove the eyepiece cap with your index
fingers before using the binoculars.
Use of the protective lens cap
The protective lens cap is kept on the eyecups. Remove the protective lens cap with your index
fingers before using the binoculars.

98
Mounting on a tripod
Binoculars from the ZEISS TERRA ED series can be mounted on any commercial camera tripod
using the ZEISS universal tripod adapter for binoculars.
Care and maintenance
The binocular lenses come standard with a hydrophobic ZEISS MC coating. This protective coating
noticeably reduces contamination (such as water, dirt and debris) of the lenses with a special
smooth surface beading effect. Contaminants adhere less and can be quickly and easily removed,
smear-free. The hydrophobic ZEISS MC coating is also durable and abrasion resistant.
We recommend using the ZEISS lens cleaning cloth (included) to clean the surface of the lenses.
Even grease, fingerprints and dirt can be removed with little effort and without smears.
Do not wipe coarse dirt particles (e.g. sand) from the lenses; instead blow off or remove with a
fine brush. Other textiles, such as clothing, paper towels or handkerchiefs can scratch the lenses
and statically charge them.
We recommend routine cleaning of the lens surfaces. Contamination, especially grease or
fingerprints, can damage the lens surfaces after a while. Dry storage and keeping the outer lens
surfaces well ventilated, especially in humidity, helps to prevent a possible mold film forming
on the optics.
Replacement parts for ZEISS TERRA ED
If you need any replacement parts for your binoculars, e.g. protective lens caps, please contact
your local dealer, your country’s distributor or our customer service team.
Our customer service team is available from Monday to Friday from 8:00 am until 6:00 pm (CET)
should you have any questions.
Tel.: [phone]
Fax: [phone]
[email protected]
Technical Data 8 x 32 10 x 32 8 x 42 10 x 42
Magnification 810 810
Objective lens diameter (mm) 32 32 42 42 Exit pupil diameter (mm) 4.0 3.2 5.3 4.2
Twilight Factor 16.0 17.9 18.3 20.5 Field of view (ft/1000 yds)
(m/1000 m)
442 135
367 112
375 125
330 110
Subjective angle of view (°) 60 63 56 60 Close-up setting limit (ft / m) 4.9 / 1.5 5.25 / 1.6 Diopter Adjustment Range (dpt) +/– 4 Exit pupil distance (mm) 16.5 18 14 Pupil Distance (mm) 56 - 74 57.5 - 76
Lens type ED Prism system Schmidt-Pechan Coating Hydrophobic Zeiss MC Nitrogen Filled Yes Waterproof (mbar) 100 Operation Temperature (°F / C°) –5° / +140° –15° / +60°
Length (in / mm) 4.9 / 125 5.5 / 142
Width with an eye spacing of 65 mm (in / mm) 4.37 / 111 4.7 / 120 Weight (oz / g) 17.98 / 510 24.5 / 695
Subject to changes in design and scope of supply due to technical improvements.
