ZEN ROVE User manual

ROVE
Aroma Atomiser with Nano-mist technology
Create Zen on the Go®

Congratulations on purchasing your MADE BY ZEN® Rove Aroma
Atomiser. Please keep this manual to help you get the most out of your
Rove and for maintenance.
TABLE OF CONTENTS:
A. ABOUT THE ROVE
B. TECHNICAL SPECIFICATION
C. OPERATING INSTRUCTIONS
D. FEATURES
E. MAINTENANCE
F. TROUBLESHOOTING
G. WARRANTY

A - ABOUT THE ROVE
The Rove Aroma Atomiser instantly fills your surroundings with potent
scent direct from the oil bottle. Experience your favourite fragrances
and blends without water. Easy to use, super sleek and portable.
Perfect for any space that needs a powerful burst of scent and
aromatherapy. Rove is ideal for use with pure essential oils to achieve
the perfect wellbeing moment.
Rechargeable, up to
30 hours of use
Waterless technology
Intense scenting with
Nano-mist technology
Quiet operation
Compact size, ideal for
travel, gym, office, or home
Suitable for use with any
essential or fragrance oils,
5ml, 10ml & 15ml oil bottles
(MADE BY ZEN® oils
recommended)

B - TECHNICAL SPECIFICATIONS
Model Name: Rove Aroma Atomiser
Model No: EW10005A
Product Size: Φ69 x 120mm
Voltage: DC 5V (3.7V Lithium Ion Battery)
Power: 5W
Adaptor: 5V/1A USB
Oil Capacity: 5ml/10ml/15ml
Run Time: 15-30 hours dependant on
chosen scent intensity
01. Scent outlet
02. Type-C USB socket
03. External body
04. Timer button
05. Timer indication
06. Mist button
07. Mist intensity
08. Oil bottle release
09. Diffusion head
10. USB cable
11. Atomisation core
12. Anti-leakage ring
13. Oil pipettes
14. Atomisation core removal tool
08
09
10 11 12
13 14
Base
02
01
30 min
60 min
120 min
03
05
04
07
06
Top

1. The Rove must always be used with the USB cable provided (as other USB
cables are not compatible with this product). Insert only into a 5V/1A power
source. You can also use the cable provided with a 5V/1A USB adaptor, which
must be purchased separately.
2. The Rove Aroma Atomiser is not suitable to be charged in a vehicle. Please note
the Rove operates with a 3.7V lithium-ion rechargeable battery, many vehicles
operate at 12V, which will damage the product.
3. Place the Aroma Atomiser on a flat surface, at least 60cm away from the floor
and at least 10cm away from the wall. DO NOT place the Aroma Atomiser on
wooden or polished furniture that may be damaged by oil moisture.
4. Always unplug the Aroma Atomiser from the electrical supply when cleaning.
Ensure the cable is secure to avoid tripping or knocking over the Aroma Atomiser.
If the cable is damaged, it must be replaced with a suitable cable provided by the
manufacturer or its agent.
5. The Aroma Atomiser must be kept out of reach from children and pets to avoid
risk of injury. Children should be supervised at all times to ensure they do not play
with the appliance.
6. The Aroma Atomiser is not intended for use by persons (including children) with
reduced physical, sensory, or mental capabilities or lack of experience and
knowledge, unless they have been given supervision or instruction concerning use
of the appliance by a person responsible for their safety.
7. Keep the Aroma Atomiser in a clear space to allow the mist to freely spread and
away from appliances especially those sensitive to oil to avoid unnecessary
accidents.
IMPORTANT NOTES BEFORE

8. The Aroma Atomiser must be cleaned after each use and should always be kept
clean and dry when not in use. Remove the Atomiser diffusion head from the
body, if not in use for prolonged periods.
9. Never attempt to disassemble your Aroma Atomiser or repair the product, as
this will void your warranty and create a shock hazard. Contact your retailer if an
internal inspection is required.
10. In case of abnormal observations such as smoke, peculiar smells, or noise,
stop using the Aroma Atomiser immediately and contact the retailer from where
you purchased it. Never wrap the Aroma Atomiser with cloth or paper as blocking
ventilation could increase the risk of fire.
11. Always handle the Aroma Atomiser with care – accidental damage is not
covered under the warranty.
12. Never cover the scent outlet when the aroma atomiser is in operation.
13. Always plug the adaptor into the USB socket before plugging into the mains.
14. Do not touch, plug, or unplug the Aroma Atomiser with wet hands.
15. Do not immerse the unit in water or other liquids and do not attempt to clean
in a dishwasher.
16. Keep away from open flames, extended exposure may create risk of
explosion. Store at room temperature. Do not use this product when temperature
is too high or too low, <10˚C >40˚C.
17. Always check with your airline before travelling with Rove on an aircraft.

C - OPERATING INSTRUCTIONS
2. Unscrew the empty oil bottle provided and replace with
a MADE BY ZEN® essential or fragrance oil bottle. The
dropper insert will need to be carefully removed from the
neck of the oil bottle, before screwing into the diffusion
head.
Alternatively, decant the essential or fragrance oil directly
into the empty oil bottle provided.
1. To release the diffusion head, firmly press the oil bottle
upwards from the base.
Note the Rove is compatible with 5ml, 10ml and 15ml oil
bottles, simply change the oil pipette to the correct length
depending on the bottle size. The oil pipette should
remain in a straight vertical position and not bend inside
the bottle (additional oil pipettes provided).
1
2

30min
60min
90min
4. Insert the diffusion head into the
main body, align the indication
arrows and push down ensuring the
diffusion head sits flush with the
external body.
3. Insert the diffusion head into the oil bottle and screw to
secure in place.
Once the oil bottle is installed do
not lean, move, or attempt to empty
or refill the Rove during operation. If
any oil is drained into the air pump
through incorrect use, this will
damage the air pump and cause
permanent damage to the product.
2
1
30min
60min
90min
30min
60min
90min

BUTTON FUNCTIONS
SCENT INTENSITY
> Press and hold to switch on the Rove, this will
activate the low-level scent intensity. (Recommended
for smaller spaces)
> Press again to activate mid-level scent intensity.
> Press again to activate high-level scent intensity.
> Press again to switch off.
Low scent intensity
10 sec. burst / 60 sec. pause
30 hours of use
Mid scent intensity
20 sec. burst / 60 sec. pause
20 hours of use
High scent intensity
30 sec. burst / 60 sec. pause
15 hours of use
TIMER CONTROL
Choose your run time - this feature will only operate
once the Rove is switched on.
> Press for 30 minute timer
> Press again for 60 minute timer
> Press again for 90 minute timer
> Press again to switch off the timer setting, the
Rove will continue to scent at the chosen intensity
level until switched off.
At any point during operation, you wish to turn off the
Rove, press and hold the or button.
Note: To avoid fast oil consumption, the Rove will
automatically shut off after 4 hours of continuous use.
Auto shut off after
30 minutes
Auto shut off after
60 minutes
Auto shut off after
90 minutes

CHARGING
The button will flash repeatedly to indicate the Rove needs to be charged.
Please note when using the timer setting, the button will not flash, the Rove will
simply switch off when the battery is fully discharged.
1. Plug the cable into the USB socket before connecting to the 5V/1A USB power
point or 5V/1A adaptor (not included).
2. Once connected properly the
button will flash to show the
Rove is being charged.
3.The button will stop flashing and
remain on, to show the Rove is fully
charged (time to full charge approx.
2-3hours).
30 min
60 min
120 min
30 min
60 min
120 min

D - FEATURES
The Rove Aroma Atomiser provides a revolutionary way to fragrance your
surroundings. Nano-mist technology releases potent particles of beautiful
scent direct from the oil bottle without the need for water or heat. Powerful
scenting for effortless aromatherapy and wellbeing.
- Rechargeable and compact, the ideal travel companion
- Sleek anodised aluminium material finish
- Compatible with 5ml, 10ml and 15ml oil bottles
- Soft touch button interface
- Quiet operation
- Auto-shut off after 4 hours of use
- Easy to clean and use

E - MAINTENANCE
2. Unscrew the oil bottle and decant any remaining oil from
the bottle.
Please ensure the Rove is switched off and not connected to the power source.
3. Fill the empty oil bottle half way with rubbing alcohol
under 75% concentration. Switch on for minimum of
10mins, maximum 1 hour. (Follow operating instructions to
switch on the Rove).
1
2
1. Release the diffusion head by firmly pressing the oil
bottle upwards from the base.
FILL BOTTLE
HALF WAY

CHANGING ATOMISATION CORE
Remove the diffusion head and oil bottle following maintenance steps 1 & 2.
2. Unscrew using the replacement tool to release the
atomisation core and oil pipette.
1. To release the atomisation core and oil pipette, align the
hexagonal shape of the replacement tool and atomisation
core (as highlighted in red).
4. Unscrew the oil bottle and pour out any remaining
alcohol. Wipe the diffusion head and oil pipette with a
clean, soft cloth and leave to dry.

3. Remove the anti-leakage ring and replace with new one
provided.
4. Replace with new atomisation core, using the
replacement tool.
We suggest you clean the Rove after using a full oil bottle or when changing to a new
scent as this will prevent scent contamination. If the oil bottle still contains oil, please
decant before adding the alcohol as per instructions in the maintenance section.
Never use alcohol above 75% concentration as it may damage the unit. Alcohol is
flammable, ensure the room is well ventilated to prevent risk of fire.
- Always keep the Rove clean and dry when not in use.
- Never leave stagnant oil inside the Rove for prolonged periods. If unused for a long
period of time, please remove the diffusion head from the main body and store
separately.
- When cleaning, always ensure no oil/alcohol enters the USB socket power port. Wipe
clean and allow the unit to dry thoroughly if any oil/alcohol accidentally enters the
electrical port. Do not plug in the cable if there is residue oil/alcohol in the USB socket.

F - TROUBLESHOOTING
Problem
Unit will not
switch on
Unable to
remove the
diffusion head
Oil leaking
Scent cross
over
There is no mist
visible, or the
mist visibility is
low
Possible Cause
The unit needs to be
charged
The power cable may not be
connected properly
The diffusion head has been
inserted into the main body
without an oil bottle
The diffusion head and main
body indication arrows are
not aligned
The oil bottle is not securely
fastened in the diffusion
head
The unit has been placed on
its side or upside down
The anti-leakage ring is
missing
There is residue of the
previous oil in the diffusion
head
Type of oil
Solution
Plug the USB cable into a 5V/1A power source
to charge the unit. Or use a 5V/1A power
adaptor to plug into mains power source. The
power button will flash to indicate the unit is
charging
Disconnect the cable and try connecting
properly. The power button will flash to
indicate the unit is charging
Gently press up on the oil pipette from the
base using a flat surface.
Firmly press the oil bottle upwards from the
base and realign the indication arrows
Ensure the oil bottle is screwed into the
diffusion head correctly
Follow the steps in the maintenance section
Ensure the anti-leakage ring is in place, see
maintenance section
Clean as advised in the maintenance section,
if cleaning isn’t successful change the
atomisation core as per instructions
Depending on the properties of the oil the
mist may not be visible. This is not unusual
and should not be considered as a fault. The
level of scent diffusion will not be affected

G - WARRANTY
IMPORTANT!
MADE BY ZEN®products comply with the WEEE Directive (Waste
from Electrical and Electronic Equipment Directive) 2012/19/EU.
This product carries a 12-month warranty for proper use in accordance with
this manual against any manufacturing defects. Accidental damage is not
covered under the warranty, including glass breakage. The warranty period
is 12 months from the date of purchase. In case of any problems arising
during the warranty period, please contact your retailer for maintenance or
claims. Proof of purchase will be required, so it is vital that you keep your
receipt of purchase with this manual safely.
Corrosive oils such as Citronella may cause damage to the unit. This type of
damage is not covered under the warranty. This Aroma Atomiser must be
cleaned after each use.
Electrical equipment is a large source of waste and if not properly recycled
could have damaging effects on the environment, whereas if it is recycled,
the resources could be used again. Electronic waste needs to be separated
from other waste to be recycled properly.
When the Rove Aroma Atomiser reaches the end of its working life, please
deposit at an appropriate collection point for recycling of electrical products.
You can also recycle used electronics at Household Waste Recycling Centres.
Caring for our planet is important to us, so please help us by disposing of the
Rove correctly. Thank You.
