Zennio ZDIDLIV2 Guide

© Zennio Avance y Tecnología S.L. Edition 5 Further information www.zennio.com Page 1/2
DALI-BOX Interface v2
Interface for one DALI bus with up to 64 devices and 64 lighting groups
ZDIDLIV2 TECHNICAL DOCUMENTATION
FEATURES
•Possibility of controlling up to 64 DALI ballasts and up to 64 lighting
groups (groups from number 17 to number 64 are only for one DALI
ballast)
•Compatibility with emergency lighting and colour ballasts (DT8).
•Scene sending and saving
•Error detection and monitoring
•Burn-in, Stand-by and Auto-off functions
•Manual control through buttons and status indication through display
•1.54” display (128 x 64 pixels) for settings and notifications
•External power supply of 110-240 VAC 50/60 Hz
•Total data saving on KNX bus failure
•Integrated KNX BCU (TP1-256)
•Size 67 x 90 x 79 mm (4.5 DIN units)
•DIN rail mounting according to IEC 60715 TH35, with fixing clamp
•DALI Standard certified
•Conformity with the CE, UKCA, RCM directives (marks on the right
side)
1. DALI bus channel
2. Control buttons
3. Display
4. Power supply indicator LED
5. External power supply
6. Programming LED
7. Programming button
8. KNX connector
9. Fixing clamp
Figure 1: DALI-BOX Interface v2
Programming button: short press to set programming mode. If this button is held while plugging the device into the KNX bus, it enters the safe mode.
Programming LED: programming mode indicator (red). When the device enters the safe mode, it blinks (red) every half second. During the start-up
(reset or after KNX bus failure) and if the device is not in safe mode, it emits a red flash.
GENERAL SPECIFICATIONS
CONCEPT
DESCRIPTION
Type of device
Electric operation control device
KNX supply
Voltage (typical)
29 VDC SELV
Voltage range
21-31 VDC
Maximum
consumption
Voltage
mA
mW
29 VDC (typical)
6
174
24 VDC¹
10
240
Connection type
Typical TP1 bus connector for 0.8 mm Ø rigid cable
External power supply
110-240 VAC 50/60 Hz
Operation temperature
-5 .. +45 °C
Storage temperature
-20 .. +55 °C
Operation humidity
5 .. 95%
Storage humidity
5 .. 95%
Complementary characteristics
Class B
Protection class
II
Operation type
Continuous operation
Device action type
Type 1
Electrical stress period
Long
Degree of protection
IP20, clean environment
Installation
Independent device to be mounted inside electrical panels with DIN rail (IEC
60715)
Minimum clearances
Not required
Response on KNX bus failure
Data saving according to parameterization
Response on KNX bus restart
Data recovery according to parameterization
Operation indicator
The programming LED indicates programming mode (red). The power
supply LED indicates external power (green). Display allows both
configuring the DALI system and supervising the current status.
Weight
186 g
PCB CTI index
175 V
Housing material
PC FR V0 halogen free
¹ Maximum consumption in the worst-case scenario (KNX Fan-In model).
1
3
2
7
5
4
6
8
9

© Zennio Avance y Tecnología S.L. Edition 5 Further information www.zennio.com Page 2/2
SAFETY INSTRUCTIONS AND ADDITIONAL NOTES
•Installation should only be performed by qualified professionals according to the laws and regulations applicable in each country.
•Do not connect the mains voltage nor any other external voltage to any point of the KNX bus; it would represent a risk for the entire
KNX system. The facility must have enough insulation between the mains (or auxiliary) voltage and the KNX bus or the wires of other
accessories, in case of being installed.
•The facility must be equipped with a device that ensures the omnipolar sectioning. Installation of a 10 A mini-circuit-breaker is
recommended. To prevent accidents, it must remain open in case of manipulation of the device.
•The device has a short-circuit protection fuse that, in case of activation, should only be rearmed or replaced by the Zennio technical
service.
•This device contains a security short-circuit proof transformer.
•Once the device is installed (in the panel or box), it must not be accessible from outside.
•For indoor use only.
•Keep the device away from water (condensation over the device included) and do not cover it with clothes, paper or any other material
while in use.
•This device contains a security short-circuit proof transformer.
•The WEEE logo means that this device contains electronic parts and it must be properly disposed of by following the instructions at
https://www.zennio.com/en/legal/weee-regulation.
•This device contains software subject to specific licences. For details, please refer to http://zennio.com/licenses.
DALI OUTPUT SPECIFICATIONS AND CONNECTIONS
CONCEPT
DESCRIPTION
Number of channels
1
Output type / Voltage
DALI bus / 17 VDC SELV
Guaranteed current per channel
128 mA
Maximum current per channel
250 mA
Maximum DALI ballasts per channel
64
Maximum length of cable
300 m (@ 1.5 mm²)
Short-circuit protection
YES
Overload protection
YES
Over-voltage protection
YES
Connection method
Screw terminal block (0.5 Nm max.)
Cable cross-section
1.5-4 mm² (IEC) / 26-10 AWG (UL)
EXTERNAL POWER SUPPLY SPECIFICATIONS AND CONNECTIONS
CONCEPT
DESCRIPTION
Power supply protection
fuse
Voltage
250 V
Current
4 A
Response type
F (Fast acting)
Connection method
Screw terminal block (0.5 Nm max.)
Cable cross-section
1.5-4 mm² (IEC) / 26-10 AWG (UL)
WIRINGDIAGRAMS
Figure 2: Mounting DALI-BOX Interface v2 on
DIN rail
Attaching DALI-BOX Interface v2 to DIN rail:
Removing DALI-BOX Interface v2 from DIN rail:
110-240 VAC
50/60 Hz
Ballast n
(n≤64)
Ballast 1
⚠NOTE:
In case of ballast replacement, please, pay
attention to the steps defined in the manual.
⚠NOTE:
In case of a DALI channel short circuit, the
device will monitor the DALI channel in order
to switch on the output at full current just as
the short circuit is removed.
