Zerio-Plus EDA-Z5008 User manual

ZERIO PLUS
EDA-Z5008, Z5020 & Z5100
INSTALLATION & OPERATION MANUAL
ZPControlTechMan_r105
Revision 1.05

EDA-Z5008, Z5020 & Z5100 –Technical Manual ZPControlTechMan_r105
_____________________________________________________________________________________________________
2
0359
Electro Detectors Limited
Electro House
Edinburgh Way
Harlow, Essex
CM20 2EG, UK
14
0359 CPR 00226
DOP_EDA_Z5100 (covers all models)
EN54-2:1997+A1:2006
EN54-4:1997+A1:2002+A2:2006
EN54-25:2008
Control and indicating equipment for fire detection and fire alarm systems for buildings
Models: EDA-Z5008, EDA-Z5020, EDA-Z5100
Optional functions with requirements:
7.8 Output to fire alarm devices
7.9.1 Output to fire alarm routing equipment
7.11 Delays to outputs
7.12 Dependency on more than one alarm signal - Type C dependency
7.13 Alarm counter
8.3 Fault signals from points
9.5 Disablement of addressable points
10.0 Test condition

EDA-Z5008, Z5020 & Z5100 –Technical Manual ZPControlTechMan_r105
_____________________________________________________________________________________________________
3
Introduction
Electro Detectors has been manufacturing radio fire alarm systems since 1987 and with the
introduction of a harmonised specification for Europe has complemented its range of products to meet
EN54 Part 25. Based on the popular Zerio system, the Zerio Plus has been designed to be capable of
handling 240 devices in 100 zones. Typical installations would include small offices, private houses,
HMO’s, guesthouses and small hotels.
This manual contains information to enable an engineer to install, service and operate the Zerio Plus
control panel and the range of Zerio Plus devices. This product should be installed, commissioned and
maintained by qualified service personnel in accordance with codes of practice, statutory requirements
and IEE regulations for electrical equipment in buildings.
The system has been designed to allow very simple set up, with a user friendly menu structure and full-
text capability. There is no need to connect devices with a programming lead, as configuration is
achieved by radio. Text locations can be entered on the panel itself or by connecting a standard USB
keyboard to the panel.
Devices for the system are visually the same as the standard Millennium and Zerio devices. These
devices are not compatible with the Millennium or Zerio range of fire alarm equipment. A list of
devices available for use with this system can be found on the back page.
Prior to installation, the building where the system is to be installed must be surveyed to ensure that
each device to be fitted has a good radio communication path to the control or booster panel. This is
done with an EDA-Z5000 survey kit. When installing devices, they must be positioned as per the survey.
Installing a device even a few inches from the surveyed position can affect the signal strength
significantly, especially if any metalwork is contained in the ceiling above the new position (e.g. air-
conditioning ducting).
IMPORTANT
Failure to perform an accurate survey could result in the system being unreliable. These
errors can be costly to correct.
Position the panel where it is to be installed.
Ensure devices are surveyed for their exact positions touching the ceiling or wall.
A few inches either side may substantially affect the signal strength.
In order to have an accurate survey the batteries in the survey detector should be
changed at least once a year.

EDA-Z5008, Z5020 & Z5100 –Technical Manual ZPControlTechMan_r105
_____________________________________________________________________________________________________
4
Revision History
V0.10 27/08/2013 First draft release technical manual.
V0.11 01/10/2013 Draft release to test house.
V0.12 04/10/2013 Added access level descriptions.
V0.13 07/10/2013 Updated PCB layout.
V0.14 14/10/2013 Filename change, DOP updated.
V0.15 17/10/2013 EN54 approved functions added. Formatting changes.
V1.00 21/10/2013 First release.
V1.01 04/12/2013 Updated relay and delay information.
V1.02 14/01/2014 Updated text for type approval.
V1.03 11/02/2014 Updated control and indicating equipment options.
V1.04 06/03/2014 More information about panel relay settings and auto resound.
V1.05 29/04/2014 Added relay jumper positions and updated panel network.

EDA-Z5008, Z5020 & Z5100 –Technical Manual ZPControlTechMan_r105
_____________________________________________________________________________________________________
5
Specification
Maximum Number of Zones EDA-Z5008 8
EDA-Z5020 20
EDA-Z5100 100
Maximum Number of Devices 240
Maximum Number of Repeater Panels 7
Maximum Total Number of Antennas 15
Dimensions (W x H x D) (not including antenna) 275x220x85mm
Weight (not including battery) 4kg
Operational Temperature -5oC to +40oC
IP Rating IP30
Alarm Indicators Twin flashing red LEDs
Red individual zone LEDs
Fire message on LCD with 40 characters of text
Fault Indicators Amber LEDs and LCD providing details and location of fault
with 40 characters of location text
Event Log Memory 1000 events maximum
Mains Supply 230V 50Hz 0.3A max
Mains Fuse 1 x 250V 3.15A
Battery 1 x 12V 7.0Ah sealed lead acid giving 72 hour standby
Battery Fuse 1 x 250V 3.15A
Relay Fuses 4 x 250V 500mA
RS485 Fuse 1 x 250V 500mA
Inputs 2 x wired monitored circuit. 4k7Ω(±5%) end of line (EOL)
resistor monitored for open and short circuit, 470Ω(±5%)
alarm load
Relays 4 x programmable
Relay Types Fire Relay Clean Contact
Fault Relay Clean Contact
Sounder Circuit 10-18V, 500mA, 4k7Ω (±5%) EOL
Fault Relay Safe Clean Contact
Fire Routing Relay 10-18V, 500mA, 4k7Ω (±5%) EOL
Operating Frequency 868MHz (868.025 to 868.575MHz)
Modulation 2-GFSK
Output Power (ERP) <25mW (<14dBm)
Channel Spacing 50KHz
Error Checking CRC
Error Correction Hamming
Number Of Channels Available 12
Compatible With Zerio Plus products only
Protocol ZPNet V1.00

EDA-Z5008, Z5020 & Z5100 –Technical Manual ZPControlTechMan_r105
_____________________________________________________________________________________________________
6
Contents
1.0 EN54 Approved Configuration
2.0 Installation
3.0 Front Panel Layout
4.0 User Operation
4.1 System Normal
4.2 Fault Conditions
4.3 Silence Buzzer
4.4 Reset a Fault
4.5 Alarm Conditions
4.6 Silence the Alarm
4.7 Re-sound the Sounders
4.8 Reset the Alarm
4.9 Access Levels
5.0 Menu Operation
5.1 Quick Menu
6.0 Setup Menu
6.1 Time and Date
6.2 Access Codes
6.3 Default Access Codes
6.4 Programming Agent Details
6.5 Panel Information
6.6 Set up a New System (Standard)
6.7 Set up a New System (HMO)
6.8 User Options
6.9 System Options
6.10 Fault Options
6.11 HMO Zones
6.12 HMO Options
6.13 User Tones
6.14 User Relays
6.15 Input Options
6.16 Input Text
6.17 Keyswitch Options
6.18 Panel Text
6.19 SIM Operations
6.20 Device Assignment
6.21 Panel Assignment
6.22 Add Antenna
6.23 Add Repeater/Booster Panel
6.24 Add Pager
6.25 Remove Hardware
6.26 Panel Network
6.27 Network Auto Configure
6.28 Device Information
6.29 Add Device
6.30 Remove Device
6.31 Remove All Devices
6.32 Edit Device
6.33 Device Text
6.34 Reprogram Device
6.35 System Test
7.0 Disable/Enable Menu
8.0 Test Mode
8.1 Test Zone
8.2 Clear Zone In Test
8.3 Lamp and Buzzer Test
8.4 System Test
8.5 Disable System Test
9.0 Event Log
9.1 Alarm Counter
9.2 View Event Log
9.3 Clear Event Log
9.4 Dump Event Log to USB
9.5 Save Event Log
9.6 View Saved Log
9.7 Shutdown Log
10.0 Verify Table
10.1 View Summary
10.2 View Detailed
10.3 Clear Verify Table
10.4 Dump Table to USB
10.5 View Panel Table
10.6 Clear Panel Table
11.0 View Airwaves
12.0 Battery Reset
13.0 Faults
13.1 Device Faults
13.2 Panel Faults
14.0 Delays
15.0 Common Problems & FAQ
16.0 Maintenance
17.0 Component Replacement
18.0 Zerio Plus Compatible Hardware

EDA-Z5008, Z5020 & Z5100 –Technical Manual ZPControlTechMan_r105
_____________________________________________________________________________________________________
7
1.0 - EN54 Approved Configuration
The Zerio Plus system has been approved by Intertek to meet EN54 parts 2 and 4. The panels were
tested and approved in their default configuration. This manual lists all available panel options and
settings, some of which can be set in a way that would result in a system that does not comply with
EN54. The EN54 approved settings are listed below:
Setup Type: Standard
Test Mode Type: By Zone
Test Mode Timeout: 0
Relay 1: Fire Routing Relay
Relay 2: Fault Relay safe
Relay 3: Sounder circuit
Relay 4: Sounder circuit
Relays: FIRE & SOUNDERS ON
Panel Buzzer: Enabled
Code Protect: ON
Device Verify Time: 390 seconds or less
Sounder Tone: Swept
Input Type: Latching
Input Relay Options: Relays Off
Fire & Sounders On
Heat Detector Type: A1S
Fault Relay: Enabled
Device Faults: Enabled
Panel Faults: Enabled

EDA-Z5008, Z5020 & Z5100 –Technical Manual ZPControlTechMan_r105
_____________________________________________________________________________________________________
8
2.0 - Installation
The electronic components within the panel are vulnerable to electrostatic discharges. It is advisable
to wear a wrist strap designed to prevent the build-up of static charges within the body before
handing any electronic components. Do not remove or unplug any components while the panel is
powered up.
Mounting
The panel should be mounted on a wall in a suitable position as recommended by BS5839 Part 1. If
fitted, the antenna should be away from any solid objects, especially electronic equipment and metal
structures. The wall should be even, clean and dry and not prone to vibration. Should the wall not be
level, the panel should be mounted on a wooden board. The temperature should be in the range of -
5oC to +35oC and the humidity should not exceed 95%. Mount the panel using 3 x No. 10 screws of a
suitable length, and ensure washers (supplied) are used to meet the IP30 rating. The smaller washer
(25mm diameter) is to be used for the mounting hole next to the PSU.
Cabling
A 230V AC 50Hz supply capable of providing 500mA with a
minimum diameter of 7mm and a maximum diameter of 10.5mm
should be derived from a separate fused spur. This spur should not
incorporate a switch and should be labelled ‘Fire Alarm Equipment
–Do Not Switch Off’. A cable conforming to BS5839, with a core
cable size no greater than 2.5mm2should be used. Always ensure
that the mains supply is completely isolated before working on
any mains rated components.
Cables should only enter the panel housing through the knockouts provided. Do not remove more
knockouts than is needed to terminate the cables, as additional apertures in the panel will compromise
the ingress protection requirements of EN54-2/4. A nylon M20 IP66 cable gland should be used. The
cable should be connected to the terminal block as labelled from above with the Live (brown)
connected to the top terminal, the Earth (green/yellow) to the middle and the Neutral (blue) to the
bottom. Care should be taken to ensure no loose strands protrude from the terminal block and that the
wire insulation is trimmed to the correct length so that no exposed wire is left visible. Any earth cables
should not be removed.
Once the connection has been made, the panel fuse (3.15A ceramic T type) should be removed from
the panel by pulling on the fuse holder. The fused spur can then be energised. To power up the panel,
insert the fuse holder with the correct value of fuse fitted. As there is a high inrush current there is
likely to be a spark produced. This is normal. Mains power should always be applied prior to
connecting the standby battery. Once the mains supply has been applied, the green LED on the
bottom edge of the processor board should begin to flash once a second. The system normal screen
will be displayed.
Connections to the panel inputs should be made using fireproof 2 core cable with a core diameter of
1.0mm2. A nylon M20 IP66 cable gland should be used. The Fire Routing & Sounder circuits should be
connected using a fireproof 2 core cable conforming to BS5839. A suitable core diameter should be
used depending on the loading of the circuit. The Panel has been type approved to IP rating IP30.

EDA-Z5008, Z5020 & Z5100 –Technical Manual ZPControlTechMan_r105
_____________________________________________________________________________________________________
9
Battery
In order to meet EN54 Part 4, a Yuasa NP7-12 lead
acid battery should be fitted. This will give a 72
hour standby, assuming no external equipment (eg
wired antennas) has been added. If only 24 hours
standby is required and no external equipment has
been fitted then a 12V 2.8Ahr battery could be
fitted. Connect the battery using the supplied
terminal connections. The red wire is +12V and the
black wire is 0V. Do not confuse the colour of the
terminal connectors. Once connected, the Reset
button on the keypad can be pressed. If ‘Battery
Fault’ appears; check the connections and polarity. If the battery is connected incorrectly it is likely that
the fuse will blow. The wiring should be corrected and the fuse replaced.
The PSU will only charge batteries measuring 10.5V and above. This is a requirement of EN54-4 to cut
off charging at a point recommended by the battery manufacturer. Batteries measuring less than 10.5V
are regarded by the system as faulty and will not be charged. A ‘Battery Fault’ will be displayed on
screen. If the battery voltage is below 10.5V it will need to be removed from the panel to be charged
and reconditioned, or replaced. The battery voltage can be viewed on the PSU Info section of the 6.5 –
Panel Info menu.
When replacing the battery always do so with a product of equal specification. Always dispose of
batteries responsibly. Never dispose of batteries in general waste. If unsure contact your local
authority for guidance.
Antenna (if fitted)
The standard helical stub antenna
supplied with the panel should be
fitted to the antenna bracket
assembly before it is mounted into
the panel. Fit the antenna onto the
SMA connector as shown below.
This should be screwed hand tight.
Over tightening will cause the
antenna to break. The supplied
antenna retaining washer should
then be placed over the top of the
antenna. The antenna and bracket assembly should then be inserted through the antenna aperture
and mounted using the supplied M3 screw and an M3 serrated locking washer. Once mounted, the
antenna retaining washer prevents the stub antenna being unscrewed from outside the panel. Connect
the antenna assembly to the main processor board using the SMA connector. If a high gain remote
antenna is being used, the stub antenna and the antenna bracket assembly should be removed. The
new antenna should be fitted using a 50ΩSMA connector, suitable for use with RG58 c/u coaxial cable,
to the processor board. Cable runs should conform to the relevant sections of BS5839 and EN54. When
making off the cable, ensure that no stray shielding wires are shorting. Do not use non-radio
connectors as they will reduce the performance of the panel.

EDA-Z5008, Z5020 & Z5100 –Technical Manual ZPControlTechMan_r105
_____________________________________________________________________________________________________
10
PCB Layout
Monitored Inputs
The panel features two monitored inputs that can be programmed either as latching or non-latching. It
is important to note that before using these inputs they must be enabled by programming them in the
panel options menu. If the inputs are enabled then 4K7Ωend of line resistors must be fitted at the
termination. Applying a 470Ωresistor across the inputs will produce a ‘Fire’ message. The inputs are
labelled ‘INPUTS’ and ‘No1’ and ‘No2’. These inputs can be assigned a zone and text location, and then
cause and effects can be programmed for them. See 6.15 –Input Options for further information.
RS-485 Connections
The RS485 connectors are used for wiring hardware to the panel such as extra antennas or a secondary
display. A suitable data cable should be used with 2 sets of twisted pairs. Cat 5/5e/6 can be used but is
not fire rated. Wired antennas and displays have two RS485 connectors, making it possible to make a
chain of up to 4 units. On the last unit in any chain, a 100R resistor should be fitted across the D- and
D+ terminals of the unused RS485 connection. If one of the control/booster panel RS485 ports is
unused then a 100R should be fitted between D- and D+. If none of the panel RS485 ports are used
then there is no need to fit the 100R resistor. The RS485 ports are capable of supplying 500mA at 15V.
The use of this facility is not permitted for an EN54-2 compliant system.
FIRE ROUTING
RELAY
FAULT RELAY
FAILSAFE
INPUT 1
INPUT 2
RS-485
IN/OUT
RS-485
IN/OUT
Radio Transceiver
Buzzer
USB
Power LED
Memory Card
Display PCB
Header
PSU Connector
SOUNDER CIRCUIT RELAYS
Door LED
Header
O
O
Buzzer Link
Antenna
Connector
RS-485
Fuse
R S –4 8 5 O U T R S –4 8 5 I N I N P U T 2C 2NO 2NC 1C 1NO 1NC 0V D+ D- V+ 0V D+ D- V+ 2- 2+ 1- 1+ 2S-2S+ 2V+ 1S- 1S+ 1V+
O
O
O
O
O
O
O
O
O
O
O
O
O O O
O O O
O O O
O O O
4C 4NO 4NC 3C 3NO 3NC
4S-4S+ 4V+ 3S- 3S+ 3V+

EDA-Z5008, Z5020 & Z5100 –Technical Manual ZPControlTechMan_r105
_____________________________________________________________________________________________________
11
Panel Relays
The panel is equipped with four programmable relays, each capable of supplying 500mA. The total
current draw across all four relays must not exceed 1A. The default relay types are:
Relay 1: Fire Routing Relay - This activates on an alarm condition. It switches 12V onto the output and
is monitored for short and open circuit, with a 4K7ΩEOL. The circuit should be connected between the
C and the NO terminals. The fuse should be fitted and the links put in the lower position.
Relay 2: Fault Failsafe Relay - This energises on power-up and de-energises in fault. Consequently the
normally open and normally closed terminals are reversed. The fuse should be removed and the links
fitted in the upper position as shown on the PCB layout diagram.
Relays 3 & 4: Sounder Circuits - These are each capable of supplying 500mA at 12V. Both the sounder
circuit fuses should be fitted in the fuse holders and the links fitted in the left or lower positions as
shown on the PCB layout diagram. The circuit should be connected between the S+ and the S-
terminals. A 4K7Ωend of line resistor should be fitted to monitor the circuit.
The relays can be configured as sounder circuits, monitored outputs or volt free clean contact relays.
The relay type can be changed in 6.8 –User Options and by positioning the jumper links and fuses as
detailed below. When relays are configured as fire routing or as sounder circuits, the associated
terminal pin (V+) must not be used. Only the default relay types have been type approved.
Display Cable
A ribbon cable connects the two panel boards together. It should be connected to the system link/bus
connections on the boards. Do not remove or connect the ribbon cable while the panel is powered
up, as damage can occur to the processor board.
Buzzer Link
The buzzer can be disabled by removing the buzzer link (see page 6 –PCB Layout). Note that when the
buzzer is disabled, the system will not comply with EN54.
Memory Card
The memory card stores a complete set of the system settings including device/zone text and options.
The memory card should be fitted at all times unless instructed by the panel (i.e. when adding a
repeater panel).
USB Socket
The USB socket can be used for connecting a keyboard to program device text. It is also used to plug in
a memory stick to download the event log, device info and the verify table so a hardcopy can be
retained for records.
Relay Type Normal State Contacts in Alarm Fuse EOL Link Position
1. Fire Relay Not energised Clean contact None None Up/Right
2. Fault Relay Not energised Clean contact None None Up/Right
3. Sounder Circuit -4.5V 500mA +15V 500mA 500mA 4K7 Down/Left
4. Fault Relay Safe Energised Clean contact None None Up/Right
5. Fire Routing Relay -4.5V 500mA +15V 500mA 500mA 4K7 Down/Left

EDA-Z5008, Z5020 & Z5100 –Technical Manual ZPControlTechMan_r105
_____________________________________________________________________________________________________
12
3.0 - Front Panel Layout
①Fire LEDs In a fire condition, these LEDs will flash.
②Zone Alarm LEDs In a fire condition, the appropriate zone LED will illuminate. If the fire
condition exists across multiple zones, multiple zone LEDs will be
illuminated. *The EDA-Z5008 8 Zone panel is shown. The EDA-Z5020 panel
is equipped with 20 zone LEDs and the EDA-Z5100 is equipped with 100
zone LEDs
③Status LEDs
Supply This LED will be illuminated when mains power is present.
Delays Active Illuminated if delays are enabled.
Disablements Illuminated for any disablement.
Test Mode Illuminated if any test modes are operational.
More Info More information on the system condition is available in the event log.
Example image
①②
③④
⑤⑥

EDA-Z5008, Z5020 & Z5100 –Technical Manual ZPControlTechMan_r105
_____________________________________________________________________________________________________
13
④Fault LEDs
Common Fault Device or panel has a fault. See main display for details.
System Fault Fault that affects system performance. See main display for details.
Sounder Flt/Disable If the LED is flashing, there is a fault with one or more sounders. If the
LED is solid, the sounders have been disabled.
Routing Flt/Disable If the LED is flashing, there is a fault with the fire routing relay. If the LED
is solid, the fire routing relay has been disabled.
Routing Active Illuminated when the fire routing relay has been activated
⑤Keys
Menu/Info Press to initiate the menu system. If held down for longer than 2 seconds,
the LEDs will follow a test sequence (lamp test).
Function This button is disabled by default, though it can be programmed to do a
number of functions. See 6.8 –User Options.
Cancel Used to return to the main screen from a menu or to return to the menu
from a programming screen.
Enter This is used to accept information programmed into the panel.
Re-sound Alarm Following an alarm condition that has been silenced, this button will re-
sound the alarm.
Silence Alarm If the panel is in a fire condition this will silence the sounders.
Silence Buzzer Silences the panel buzzer for all currently displayed faults or alarms.
Reset Resets the panel from an alarm or fault condition. Note that the system
must be silenced before it can be reset from a fire condition.
⑥Navigation Keys
Use to navigate through the menu structure and programming/status screens. In a multiple
fault or alarm condition, the up and down arrow keys allow the user to scroll through all the
current events. The display will also scroll automatically every 4 seconds.
The navigation keys are numbered 1 to 4. This is to allow the user to enter a 4 digit access code
when prompted.

EDA-Z5008, Z5020 & Z5100 –Technical Manual ZPControlTechMan_r105
_____________________________________________________________________________________________________
14
4.0 - User Operation
4.1 - System Normal
In normal operation the screen will show either the date and time,
or the supplier/service contact details. The unit can also be
configured to alternate between the two. If configured this way, the
display will change every 4 seconds. See 6.4 –Programming Agent
Details. Also a single green ‘Supply’ LED will be illuminated.
4.2 - Fault Conditions
If a fault occurs, the internal buzzer will sound and a message will
be displayed. The first line details the current fault number, the
zone and the type of fault. The second line details the device type
and the device number. The third and fourth lines display the device
location text (if programmed). The description has a maximum
length of 40 characters across 2 lines. Appropriate action should be
taken to remedy the fault as this may affect the operation of the fire alarm system. If in doubt, the
system maintenance company should be contacted. If more than one fault exists on the system they
will scroll round every 5 seconds. Pressing the ↑ or ↓cursor key will display the next or previous fault.
4.3 - Silence Buzzer
If the panel buzzer is sounding following a fault or alarm, it can be silenced with the Silence Buzzer key.
Once the Silence Buzzer button has been pressed the panel assumes that the fault has been
acknowledged and does not re-sound the buzzer, unless a new fault occurs. The LED on the device will
continue to flash until the fault is reset –see below.
4.4 - Reset a Fault
A fault will be displayed on the panel until the system is reset, even
if the fault condition has been rectified. Assuming the fault has
been rectified; pressing Reset on the panel and entering an access
code using the navigation keys will reset the panel and the devices
on which the fault has occurred. The system normal screen will then
be displayed. If the fault is still present or re-occurs, it will be re-displayed. Where there are multiple
faults, all will be reset at the same time. It is not necessary to silence a fault before resetting it. The
particular device or devices in fault will also flash a green LED and beep. The system can be silenced
and reset without an access code by turning off ‘Code Protect’; see 6.9 –System Options.
4.5 - Alarm Conditions
In a fire condition, a screen similar to this will be displayed. The fire
LEDs will flash and the zones in alarm LED(s) will be illuminated.
Assuming the system is programmed to do so, the system sounders
will be activated and the routing active LED will illuminate. The first
line of the display shows the event number and the zone number.
The second line details the device type and its number. If the device location has been programmed
into the panel, it will be displayed on the third and fourth lines. Scroll through multiple alarms using
the ↑and ↓keys.
Tuesday
01-01-2013
12:04:36
001 Zn:001 VFY FAULT
SMOKE DET 001
Entrance Hall
Enter Access Code
----
001 Zone 001
SMOKE DET 001
Conference Room

EDA-Z5008, Z5020 & Z5100 –Technical Manual ZPControlTechMan_r105
_____________________________________________________________________________________________________
15
4.6 - Silence the Alarm
When it is certain that it is safe to return to the building the Silence Alarm button should be pressed.
The user will then be prompted to enter a valid user access code using the navigation keys. Up to 30
seconds should then be allowed for all sounders to silence. If a device is still in an alarm condition the
sounders will not sound again unless another device goes into alarm. If an alarm is left unsilenced, the
sounders will turn off automatically after 30 minutes. The system can be silenced and reset without an
access code by turning off ‘Code Protect’; see 6.9 –System Options.
4.7 - Re-sound the Sounders
There may be times when the sounders have been mistakenly silenced –for example if the alarm was
genuine but someone pressed silence. The Re-Sound Alarm button followed by a valid access code will
activate the sounders again.
4.8 - Reset the Alarm
Assuming the reason for the alarm condition has been investigated; pressing Reset after silencing the
alarm will return the system to its normal operation screen and reset the devices that prompted the
alarm. The user will be prompted to enter a valid access code using the navigation keys. The system
can be silenced and reset without a code by turning off ‘Code Protect’; see 6.9 –System Options.
If a device has remained in alarm (i.e. the glass has not been replaced in a callpoint or a smoke detector
detects smoke is still inside the unit) after silencing the alarm and pressing Reset, the panel will
redisplay the alarm and the sounders will sound again.
4.9 - Access Levels
The panel is protected from misuse by means of four access levels. The access levels are as follows:
Level 1 Untrained user
Level 2A Basic user
Level 2B Advanced user
Level 3A Service and Maintenance Engineer
Level 3B Commissioning Engineer
Level 4 Manufacturer –Access tools required
A Level 1 untrained user can view the current system state including any faults, alarms, disablements
and tests. See 5.1 –Quick Menu.
A Level 2A basic user can view the current operational condition of the system, access the
disable/enable menu and may silence and reset alarms.
A Level 2B advanced user in addition has access to test mode and the event log.
A Level 3A engineer in addition has access to system and device information and the verify table.
A Level 3B commissioning engineer has access to all system options, including programming and
configuration of devices and hardware.
All menus, settings and options described in this manual show the required access level in the title. For
example: 8.4 - Enable System Test –service and commissioning users
Each access level (excluding level 1) requires a 4 digit code to access the menus. See 6.2 –View Access
Codes.
Enter Access Code
----

EDA-Z5008, Z5020 & Z5100 –Technical Manual ZPControlTechMan_r105
_____________________________________________________________________________________________________
16
5.0 - Menu Operation
To enter the menu system, press Menu. This will display an overview of any alarms, faults,
disablements or tests that are currently active, along with an option to access the Main Menu. The
options available on the main menu and sub-menus will be dependent on the access code entered and
its corresponding access level. To scroll through the menu the ↑and ↓keys should be pressed. In
order to select a menu option the →key should be pressed. To return to the previous menu screen
from a sub-menu the ←key should be pressed. Pressing Cancel will return to the system screen where
any faults or alarms will be displayed if present.
For every menu option listed in this manual, its place in the menu structure will be shown in grey text
underneath the heading. For example, the event log can be found by selecting the ‘Main Menu’,
followed by ‘View Events’ and selecting ‘View Event Log’.
1.Main Menu>>4.View Events>>2.View Event Log
If a non-menu screen is selected the Cancel button should be pressed to return to the menu without
making any changes. Subsequently, then pressing Cancel for a second time will return to the system
screen. If any changes are made to settings, these are generally saved using the Enter key as detailed
on the display. If an alarm occurs while in menu mode, the menu will be automatically cancelled, and
the alarm message displayed. If a fault occurs while in the menu mode, the fault LED will light but the
display will remain in the menu mode until cancelled in the usual way.
5.1 - Quick Menu –all access levels
Pressing Menu once will display the Quick Menu. Navigate using
the cursor keys. Any active alarms, faults, disablements or tests will
be displayed. No access code is needed to view the events listed.
You will only be prompted to enter an access code if you select ‘1-
Main Menu’.
When a category (e.g. Faults) is selected, the first screen will
display information such as the device number, zone, type of fault
and any text location.
Pressing the →key will display the time and date that the event
happened.
1>Main Menu
2 Alarms(000)
3 Faults(002)
4 Disablements(000)
001 Zn:001 SHORT CCT
CONTROL IP1
Time:12:00:08
Date:25/06/13

EDA-Z5008, Z5020 & Z5100 –Technical Manual ZPControlTechMan_r105
_____________________________________________________________________________________________________
17
6.0 - Setup Menu
6.1 - Changing the system Time and Date –all access levels
1.Main Menu>>1.Setup>>1.Time & Date
To change the time and date settings use the ←and →keys to
navigate to the value, and the ↑or ↓keys to select the desired
value. Press Enter to accept or Cancel to exit. The Zerio Plus panel
automatically adjusts the clock for daylight savings. Should
complete power be lost the panel will revert the time back to the
default of 01/01/2013 12:00:00
6.2 - View Access Codes –advanced, service and commissioning users
1.Main Menu>>1.Setup>>2.Access Codes>>1.View Codes
The access code is a 4 digit number; with each digit ranging from 1
to 4. Selecting ‘1-View Codes’ will display the screen opposite. Only
access codes for the access level you have entered and those below
it will be displayed.
Changing Access Codes –advanced, service and commissioning users
1.Main Menu>>1.Setup>>2.Access Codes>>2.Change Codes
Using the cursor keys select the access level for which the access
code is to be changed. Users can only change the access code for
their level and below. Once selected, press the →key to continue.
Using the numbered keys enter the current access code. If correct,
you will be prompted to enter your chosen new access code, then
to re-enter it to confirm. Press Enter to save the new access code,
a message will be displayed that the access code is being saved.
Press Cancel to exit without saving at any time.
Set Access Codes to Default –commissioning users
1.Main Menu>>1.Setup>>2.Access Codes>>3.Set to Default
Use this option to reset the user access codes to their default settings. Press Enter to confirm.
6.3 - Default Access Codes
Basic User (AL2A): 1111
Advanced User (AL2B): 2222
Service Engineer (AL3A): 3333
Commissioning Engineer (AL3B): 4444
Time: 12:39:00
Date: 01-01-2013
ENTER to save
AL1 1111 AL2 2222
CANCEL to exit
Enter Current Code
----
CANCEL to exit
Enter New Code
----
CANCEL to exit
AL2A 1111 AL2B 2222
AL3A 3333 AL3B 4444
CANCEL to exit
Ensure that the access codes AL3A & AL3B are
changed from the default settings to ensure that only
authorised personnel can make changes to the system

EDA-Z5008, Z5020 & Z5100 –Technical Manual ZPControlTechMan_r105
_____________________________________________________________________________________________________
18
6.4 - Programming Agent Details –service and commissioning users
1.Main Menu>>1.Setup>>3.Panel Display
The system normal screen can be adjusted to display either the date and time, the agent’s name and
telephone number or alternating between the two every 4 seconds. In order to display the agent’s
details, they will need to be programmed into the panel. 20 characters per line can be programmed.
Text can be programmed into the control panel using a USB
keyboard or via the panel buttons. From the ‘Panel Display’ menu
select ‘1-Agent Name’.Enter text then press Enter to save. Select
‘2-Agent Phone’. Enter text then press Enter to save. If entering
text via the panel use the ↑key to display the characters. Browse
the characters using the ← → keys; select the highlighted character
using the ↓. Menu key is SPACE and Function is a BACKSPACE.
Once complete press ↑to hide the characters and press →.
Confirm the text is correct and press Enter to save. To return to the
menu press Cancel.
Change Display Options –service and commissioning users
1.Main Menu>>1.Setup>>3.Panel Display>>3.Display Options
Using the ↑or ↓keys, select ‘Time/Date’, ‘Agent Details’ or
‘Alternating’. Press →to select the option. Press Enter to save.
6.5 - Panel Information
1.Main Menu>>1.Setup>>4.System Setup>>1.Panel Info
It is possible to view information regarding the panel, such as the software version, system number and
the number of devices programmed onto the system.
Panel Status –service and commissioning users
1.Main Menu>>1.Setup>>4.System Setup>>1.Panel Info>>1.Status
Sys No: System number.
Devices: Number of devices added to the panel.
Panel No: Panel number and last panel number on system.
Antennas: Number of antennas assigned to the panel.
Ver: Software version.
Uptime: Operational time since panel was last powered down.
Tuesday
01-01-2013
12:04:36
A.N Other Fire
01234 567891
12:04:36
Alternating↕
Use ← → keys
Sys No:00699
Devices:001
Use → key
Panel No:01/01
Antennas:01
Use ← → keys
Ver:01.00 20Mar13
Uptime:0000d 03h 13m
Use ← key
TxRx
Version:01.02
Uptime:0000d03h13m45
Use ← key
Display
Version:01.01
Uptime:0000d04h16m33
Use ← key

EDA-Z5008, Z5020 & Z5100 –Technical Manual ZPControlTechMan_r105
_____________________________________________________________________________________________________
19
Panel Readings –service and commissioning users
1.Main Menu>>1.Setup>>4.System Setup>>1.Panel Info>>2.Panel Readings
IP1: The resistance level on input 1.
IP2: The resistance level on input 2.
OP1: The resistance level on output 1.
OP2: The resistance level on output 2.
OP3: The resistance level on output 3.
OP4: The resistance level on output 4.
Vbus: The voltage of the PSU.
Light: Light sensor voltage.
View Antenna Information –service and commissioning users
1.Main Menu>>1.Setup>>4.System Setup>>1.Panel Info>>3.Antenna Info
Ant: The currently selected antenna.
Sys: The system number programmed at the antenna.
RSSI: Received signal strength indicator, from -20 to +20.
RF Chan: The channel the system is using.
Pan: The number of the panel programmed at the antenna.
Slot: Device protocol slot.
Squelch: RF interference filter. Non-user adjustable.
View Pager Information –service and commissioning users
1.Main Menu>>1.Setup>>4.System Setup>>1.Panel Info>>4.Pager Info
This menu displays information for any alert pagers that have been set up on the system.
View Power Supply Information –service and commissioning users
1.Main Menu>>1.Setup>>4.System Setup>>1.Panel Info>>5.PSU Info
Vin: Input Voltage.
Vbus: The voltage of the PSU.
Vbat: The voltage of the battery.
Ib: Battery current.
Io: PSU output current.
Status: PSU fault status.
State: PSU state.
PWM: Duty cycle.
Temp: PSU temperature (oC).
Version: The firmware version of the power supply PCB.
Uptime: Operational time since PSU was last powered down.
IP1:4535Ω IP2:4513Ω
OP1:4579Ω OP2:>10KΩ
OP3:4528Ω OP4:4671Ω
01314 01862
Vbus:14.9
Light:00.00V
Use ← key
Ant:01↕ Sys:00699
RSSI:20
RF Chan:09 Pan:01
Slot:195 Sqlch:100

EDA-Z5008, Z5020 & Z5100 –Technical Manual ZPControlTechMan_r105
_____________________________________________________________________________________________________
20
6.6 - Set up a New System (Standard) –commissioning users
1.Main Menu>>1.Setup>>4.System Setup>>2.New Setup>>1.Standard System
Devices are programmed via a radio link to the control panel. If
the system is known to have been used before then all the devices
that are logged on to the system must be removed first. To add or
remove devices on a system that is already set up; see 6.29 –Add
Device and 6.30 –Remove Device.
Press Enter to start. You will be asked if you would like to put the
system into test mode (see 8.0 –Test Mode). Select YES or NO and
press Enter. The control panel will now check the airwaves for any
radio interference and select a suitable channel for the system.
Press Enter to continue. Select the antenna type. At the Device
Programming screen, the device needs to be put into
programming mode. First remove the device from its base.
1. If a smoke detector, heat detector or combined sounder
detector is being programmed; hold both the reset button
and the unit removal button down while you place the
jumper link to the ON position.
2. If a sounder, beacon, callpoint, transmitter or I/O unit is
being programmed; hold down the unit removal button
while holding a magnet over the reed switch and place the
jumper link to the ON position. Some newer devices are
equipped with a log on button and do not require the
magnet to log on; simply hold down the button while the
jumper link is moved to the ON position.
Continue to hold the button(s) for approximately 5 seconds until a
confirmation of 3 beeps from the device is heard. The LED on the
device will now flash green. The device is now in its programming
mode. Press Enter on the panel to search for the device and follow
the prompts to set the device options. When complete press Enter
to program the device.
Once the device has restarted you will be asked to enter location text; see 6.33 –Device Text. Text can
be added at any time. Devices can be added at any time in the Device Setup menu.
If the system has booster panels or additional antennas fitted, an auto assignment for all devices
should be performed once all devices have been added. See 6.20 –Device Assignment.
System Setup
ENTER to continue
System will test
radio channel
ENTER to continue
Channel 09
RSSI -20
/
Please wait
Device Programming
ENTER to continue
Device Found
SMOKE DET
Use ← → keys
