ZHEJIANG XIANFENG MACHINERY DKC400 User manual

Sliding Gate Operator
User’s Manual
Model:DKC400(U) & DKC400(U)Y
WARNING!
ONLY QUALIFIED AND EXPERIENCED TECHNICIANS
SHOULD ATTEMPT INSTALLATION OR SERVICE TO
THIS UNIT, OTHERWISE, SERIOUS PERSONAL INJURY,
DEATH, OR PROPERTY DAMAGE MAY OCCUR.
PLEASE KEEP THESE INSTRUCTIONS FOR FURTHER
REFERENCE.
CONTENT
1. Important Safety Information …………………1
2. Main Technical Parameters……………………1
3. Main Features …………………………………2
4. Working Principle and Main Structure ………2
5. Installation and Adjustment ……………………2
6. Connecting - DKC400(U) ………………………10
7. Connecting - DKC400(U)Y ……………………11
8. Control …………………………………………20
9. Final Check ……………………………………25
10. Maintenance …………………………………26
11. Troubleshooting ………………………………27

DKC400(U) & DKC400(U)Y SLIDING GATE OPERATOR USER’S MANUAL
1. Important Safety Information
Carefully read and follow all safety precaution and warnings before attempting to install and
use this operator, incorrect installation can lead to severe injury.
The gate operator should be installed by a qualified technician; otherwise, serious
personal injury or property damage may occur.
The auto-reverse function must be checked during installation to ensure that the gate
can auto-reverse in the event of obstruction.
This auto-reverse function should be regularly inspected and adjusted, if necessary.
When opening or closing the gate, do not attempt to walk or drive through the gate.
Children should not be allowed to play near or operate automatic gates.
The automatic gate operator must be grounded.
Install the gate operator on the inside of the property, DO NOT install it on the outside of
the property where the public has access to it.
Be careful when in close proximity to moving parts where hands or fingers could be
pinched.
Do not allow control devices to be placed so that a person can access them by reaching
through the gate.
In the event of power failure, an emergency release key allows you to operate the gate
manually.
The operator should be switched off before repairing it or opening its cover.
Please erase and reprogram the code after installing the operator.
Our company reserves the right to change the design and specification without prior
notification.
2. Main Technical Parameters
Tab.1
Model DKC400 DKC400U DKC400Y DKC400UY
Power supply AC 220V, 50Hz AC110V, 60Hz AC 220V, 50Hz AC110V, 60Hz
Motor speed 1400 r/min 1680 r/min 1400 r/min 1680 r/min
Gate moving speed 14m/min (24 teeth) 11m/min (19 teeth) 17 m/min (24 teeth) 13m/min (19 teeth) 14m/min (24 teeth) 11m/min (19 teeth) 17 m/min (24 teeth) 13m/min (19 teeth)
Control unit Control box (optional) All-in-one gate operator, control board included
Output torque 14N·m
Working time 90 sec.
Limit switch Magnetic limit switch / spring limit switch (According to your order)
Remote control
operating range 30m
Frequency 433.92 MHz
Remote control mode Single-button
Auto-close time 0-44 sec.
Noise ≤60 dB
Ambient temperature -10ºC~+50ºC
1
DKC400(U) & DKC400 (U) Y SLIDING GATE OPERATOR USER’S MANUAL
3. Main Features
The device is used to drive sliding gate.
For your safety, the gate operator will stop and reverse if it was obstructed on closing
and stop when it was obstructed on opening.
User programmable and user erasable remote codes.
Infrared terminal (N.C) is supplied to use.
Auto-close feature is available for this operator.
Pedestrian mode.
Manual key release design for emergency purposes.
4. Working Principle and Main Structure
DKC400(U)Y all-in-one multifunctional sliding gate operator integrated the electric control
board into the operator, it is composed of a single-phase motor, worm and worm gear, the
main shaft of the motor rotates the worm with the clutch engaged, the worm rotates the worm
gear and output gear, which pushes the rack attached to the sliding gate, thus moving the
gate.
Control board not included in DKC400(U) main unit, it can be fitted with the XF24W(AC220V)
or XF24U(AC110V) control box according to your needs. The control box can be purchased
through your dealer.
5. Installation and Adjustment
The DKC400(U) & DKC400(U)Y rack-driven gate operator operates by forcing a drive rack
past a drive gear. The entire configuration is shown in Fig.1 - Fig.4. The gate operator must be
installed on the inside of the gate.
Gate preparation
Be sure the gate is properly installed and slides smoothly before installing the sliding gate
operator. The gate must be plumb, level, and move freely.
Fig.1 DKC400(U)Y Gate operator with magnetic limit switch
2

DKC400(U) & DKC400(U)Y SLIDING GATE OPERATOR USER’S MANUAL
Fig.2 DKC400(U)Y Gate operator with spring limit switch
Fig.3 DKC400(U) Gate operator with magnetic limit switch
3
DKC400(U) & DKC400(U)Y SLIDING GATE OPERATOR USER’S MANUAL
Fig.4 DKC400(U) Gate operator with spring limit switch
Conduit
In order to protect the wires, use PVC conduit for wires, conduit must be set into the concrete
when it is poured. Wires within the conduit shall be located or protected so that no damage
can result from contact with any rough or sharp part.
Concrete pad
The base unit of the gate operator requires a concrete pad in order to maintain proper stability.
The concrete pad should be approximately 300mm x 200mm x 200mm deep in order to
provide for adequate operation. The pad should be 70mm above finish grade. Be sure to
locate the pad so that it will not interfere with the gate.
Anchors
You can use the anchors, bolts, washers and nuts that are provided with the operator see Fig.5
and Fig.6. These anchors must be set into the concrete when it is poured, or you can use
wedge expansion bolts.
Operator base
Mount the gate operator base to the concrete pad see Fig.5.Verify that the operator is leveled
properly.
Operator
Mount the gate operator to the base using nuts and washers.
4

DKC400(U) & DKC400(U)Y SLIDING GATE OPERATOR USER’S MANUAL
Concretepad
170
263
203
110
Operator base
Plain washer
Spring washer
Nut
Fig.5
Nut
Wires
Bolt
Anchor
Nut
Spring washer
Plain washer
Gear
Gate operator
Operator base
Conduit
(Spring limit switch)
﹡you must use two conduits:
one for main power wire, another
one for low voltage wire, always
separate the power wire from
control wires.
Fig.6
Installing the rack (see Fig.7)
Weld the steel rack
Manually move the gate to its closing position.
Place the three threaded pawls (in the same package with rack) on the rack element.
Lay the first piece of rack on the gear and weld the first threaded pawl on the gate.
Move the gate manually, checking if the rack is resting on the gear, and weld the
second and third pawls.
5
DKC400(U) & DKC400(U)Y SLIDING GATE OPERATOR USER’S MANUAL
The space between rack and gear is about 1mm.
Bring another rack element near to the previous one. Move the gate manually and weld
the three pawls as the first rack, thus proceeding until the gate is fully covered.
When the rack has been installed, to ensure it meshes correctly with the gear.
If necessary, assemble the spacer between the rack and pawl to synchronise the teeth
of the two rack elements and keep racks in a straight line. See Fig.7
Screw the nylon rack
Manually move the gate to its closing position.
Lay the first piece of rack on the gear and mark the drilling point on the gate, drill a hole
and screw the bolt.
Move the gate manually, checking if the rack is resting on the gear, and repeat the
above operations.
Bring another rack element near to the previous one. Move the gate manually and carry
out the securing operations, thus proceeding until the gate is fully covered.
Fig.7
Magnets for limit switch
Install the magnet as shown in Fig.8 and Fig.9. The magnet and limit switch are used to control
the position of the gate. When the magnet is installed, release the gear clutch and push the
sliding gate manually to pre-determine the position. Weld or fit the magnet bracket to the rack
and then tighten the gear clutch. The lower bracket is for open position and higher bracket is
for close position. Finally adjust the magnet to the proper position by moving the gate with
the motor. The magnet should be 10-15mm away from the magnetic limit switch. If it is too
far away, the switch will fail to work. Adjust the position of the magnets until the positions of the
opening and closing meet the requirement.
Important Note: Please note the two magnet brackets (fixed plate) are different: one is
higher and another is lower. Verify and if necessary exchange the two brackets position.
Also if necessary exchange the limit switch wires CL (close) and OP (open). Another
common problem is there are two reed switches inside the magnetic limit switch: one is
6

DKC400(U) & DKC400(U)Y SLIDING GATE OPERATOR USER’S MANUAL
upper and another is lower. The magnet position can be installed in the middle so it
inducts both reed switches. Solution: adjust the magnet upper or lower.
10-15mm
Magnet
Gate
Pawl
Rack
Gear
Guide rail
Magnetic limit
switch inside
19 teeth: 122mm
24 teeth: 132mm
Magnet
bracket
Fig.8
It can be adjusted
Weld
Higher bracket
Magnet
Rack
Lower bracket
Magnet
Higher bracket
It can be adjusted
Style I: Weld the bracket on steel rack
Style II: Fit the bracket on steel rack or nylon rack
Lower bracket Rack
Fig.9
7
DKC400(U) & DKC400(U)Y SLIDING GATE OPERATOR USER’S MANUAL
Spring limit switch
Install the block as shown in Fig.10 and Fig.11. Release the gear clutch with the key and push
the sliding gate manually to pre-determine the position, screw the block to the rack and then
tighten the gear clutch with the key. Moving the gate electrically, adjust the block to the proper
position until the position of the opening and closing meet the requirement.
Block
Gate
Pawl
Rack
Gear
Guide rail
Spring limit switch
19 teeth: 122mm
24 teeth: 132mm
Fig.10
Right block
Left block Right block
Style III: screw the blocks on steel rack or nylon rack
Style IV: screw the blocks on steel rack or nylon rack
Rack
Left block
Fig.11
8

DKC400(U) & DKC400(U)Y SLIDING GATE OPERATOR USER’S MANUAL
Tab. 2
Limit switch Rack Magnet bracket Block
Magnetic limit switch Steel Style I (see Fig.9) / Style II (see Fig.9) /
Nylon Style II (see Fig.9) /
Spring limit switch
Steel /Style III (see Fig.11)
/Style IV (see Fig.11)
Nylon /Style III (see Fig.11)
/Style IV (see Fig.11)
Note: the rack and magnet bracket / block came with your gate operator depends
on your order, select the proper installation method according to your needs.
Manual operation (see Fig.12)
In case of power failure use manual release key to open or close gate manually, use the
release key as follow:
Remove the cover.
Fit the supplied key in the hole.
Turn the key counterclockwise to release the clutch.
Open and close the gate manually.
After power-restored use the manual release key to engage the clutch by turning the
key clockwise and resume normal operation.
Insert the key Counterclockwise to release the clutch.
Clockwise to engage the clutch.
Release here
Fig.12
9
DKC400(U) & DKC400(U)Y SLIDING GATE OPERATOR USER’S MANUAL
6. Connecting ----
DKC400(U)
Make sure the control box power switch is OFF before connecting.
The DKC400(U) has a terminal block, Fig.13 shows the wiring of motor and limit switch, the
DKC400(U) is not equipped with control box, the control box (XF24W or XF24U) can be
purchased through your dealer.
Three different types of control boards (See Fig.14 KZB01 control board with SCR, Fig.15
KZB05 control board with relay, Fig.16 KZB13 control board with SCR & relay) can be used for
the control box, identify the type of your control board before connecting, select the proper
board diagram according to your order and connect the external button switch and safety
devices see Fig.14 - Fig.16 and wiring notes. Programming and adjusting refer to 8.CONTROL
section.
DKC400U GATE OPERATOR
DKC400 GATE OPERATOR
YELLOW
AND GREEN
BLACKBROWN
BLUE
WHITE RED
BLUE
POWER
AC220V
MOTOR
LIMIT SWITCH
WV
COM/UOPEN
COM
CLOSED
SWITCH
RELEASE
Terminal block inside
the gate operator
XF24W CONTROL BOX
Terminal block inside
the gate operator
YELLOW
AND GREEN
BLACK
WHITE RED
BLUE
XF24U CONTROL BOX
POWER
AC110V
MOTOR
LIMIT SWITCH
WVCOM/UOPEN
COM
CLOSED
SWITCH
RELEASE
WHITE RED
Fig.13
10

DKC400(U) & DKC400(U)Y SLIDING GATE OPERATOR USER’S MANUAL
7. Connecting ----DKC400(U)Y
Make sure that the power is OFF before making any electrical connections.
Control board included in the gate operator, there are three different types of control boards
can be used for the gate operator, select the proper board diagram according to your order.
Perform the wiring (See Fig.14 KZB01 control board with SCR, Fig.15 KZB05 control board
with relay or Fig.16 KZB13 control board with SCR & relay.)
Fig.14 KZB01 control board with silicon controlled rectifier
11
DKC400(U) & DKC400(U)Y SLIDING GATE OPERATOR USER’S MANUAL
Wiring notes for control board (KZB01)
1. Power switch: ON/OFF
2. Fuse: DKC400Y/XF24W: 5A, Ø5x20; DKC400UY/XF24U: 10A, Ø5x20
3. Antenna: ANT
4. Beeper: DC12V
5. Dip-switch
6. Memory Card: 93C66
7. MCU: PIC 16C57C
8. Three button switch / single button switch (keypad):
Three button switch (normally open, three-button mode): T (Stop), G (Close), K (Open),
COM (Common)
N.O.
Button switch Control board
terminal X10 No.8
T
G
K
COM
COMMON
STOP
CLOSE
OPEN
COM
T
G
K
Schematic diagram Wiring diagram
Single button switch / Keypad (normally open, single-button mode): T (Not used), G
(Open priority), K (Open/stop/close), COM (Common)
To install the keypad attach one lead of your keypad to ‘K’ of terminal X10 and the other
to the ‘COM’. The keypad will function in single channel mode.
Button switch
keypad
Not used
G
T
COM
K
Com
Signal
NO
com
K
Open
G
com
NO
Control board
terminal X10 No.8
Schematic diagram Wiring diagram
NOTE: Two modes (three-button mode or single-button mode) you can select according
to your order.
12

DKC400(U) & DKC400(U)Y SLIDING GATE OPERATOR USER’S MANUAL
9. Limit switch: CL (Close limit), CO (Com), OP (Open limit)，DC12V (Output power supply)
CL
COM
OP
N.C. (For N.C. limit switch)
CL
COM
OP
N.O. (For N.O. limit switch)
Limit switch mode is adjustable by DIP-switch. (See table 3)
Schematic diagram
10. Output power supply: +12V (DC +12V), COM (CO)，DET (Loop detector), I.R. (Infrared
N.C)
COM
GND
+12V
Out COM
I.R
COM
+12V
Terminal
X8, No.10
Terminal
X8, No.10
I.R
COM
Out
COM
AC24V AC24V Terminal
X5,No.11
Infrared Control board Infrared Control board
Infrared with DC input Infrared with AC input
Loop detector with DC input
Control board
Loop detector
Terminal
X8, No.10
+12V
COM
DET
COM
Out
+12V
GND
COM
Loop detector with AC input
Control board
Loop detector
Terminal
X5,No.11
AC24VAC24V
COM Out COM
DET
Terminal
X8, No.10
Schematic diagram
11. Output power supply: AC24V
12. Power Indicator: LED
13. Learn button: AN
14. Force Adjustor (VR1): Clockwise +, Counterclockwise –
15. Power Transformer
16. Sampling Transformer: 110V/8.8V 4W
17. Alarm Lamp: DKC400Y/XF24W: AC220V; DKC400UY/XF24U: AC110V
18. Motor Capacitor
19. Motor: U (com), V (Positive direction), W (Opposite direction), E (grounding)
20. Power Input: E (Earth), L (Live), N (Neutral)
DKC400Y/XF24W: AC220V; DKC400UY/XF24U: AC110V
13
DKC400(U) & DKC400(U)Y SLIDING GATE OPERATOR USER’S MANUAL
Fig.15 KZB05 control board with relay
14

DKC400(U) & DKC400(U)Y SLIDING GATE OPERATOR USER’S MANUAL
Wiring notes for control board (KZB05)
1. Power switch: ON/OFF
2. Fuse: DKC400Y/XF24W: 5A, Ø5x20; DKC400UY/XF24U: 10A, Ø5x20
3. Antenna: ANT
4. Beeper: DC12V
5. Dip-switch
6. Memory Card: 93C66
7. MCU: PIC 16C57C
8. Three button switch / single button switch (keypad)
Three button switch (normally open, three-button mode): T (Stop), G (Close), K (Open),
COM (Common)
N.O.
Button switch
T
G
K
COM
COMMON
STOP
CLOSE
OPEN
COM
K
G
T
Control board
terminal X10 No.8
Schematic diagram Wiring diagram
Single button switch / Keypad (normally open, single-button mode): T (Not used), G
(Open priority), K (Open/stop/close), COM (Common)
To install the keypad attach one lead of your keypad to ‘K’ of terminal X10 and the other
to the ‘COM’. The keypad will function in single channel mode.
Button switch
keypad
Not used
G
T
COM
K
Com
Signal
NO
com
K
Open
G
com
NO
Control board
terminal X10 No.8
Schematic diagram Wiring diagram
NOTE: Two modes (three-button mode or single-button mode) you can select according
to your order.
15
DKC400(U) & DKC400(U)Y SLIDING GATE OPERATOR USER’S MANUAL
9. Limit switch: CL (Close limit), CO (Com), OP (Open limit)，DC12V (Output power supply)
CL
COM
OP
N.C. (For N.C. limit switch)
CL
COM
OP
N.O. (For N.O. limit switch)
Limit switch mode is adjustable by DIP-switch. (See table 3)
Schematic diagram
10. Output power supply: +12V (DC +12V), COM (CO)，DET (Loop detector), I.R. (Infrared
N.C)
COM
GND
+12V
Out COM
I.R
COM
+12V
Terminal
X8, No.10
Terminal
X8, No.10
I.R
COM
Out
COM
AC24V AC24V Terminal
X5,No.11
Infrared Control board Infrared Control board
Infrared with DC input Infrared with AC input
Loop detector with DC input
Control boardLoop detector
Terminal
X8, No.10
+12V
COM
DET
COM
Out
+12V
GND
COM
Loop detector with AC input
Control boardLoop detector
Terminal
X5,No.11
AC24VAC24V
COM Out COM
DET
Terminal
X8, No.10
Schematic diagram
11. Output power supply: AC24V
12. Power Indicator: LED
13. Learn button: AN
14. Force Adjustor (VR1): Clockwise +, Counterclockwise –
15. Power Transformer
16. Sampling Transformer: 110V/8.8V 4W
17. Alarm Lamp: DKC400Y/XF24W: AC220V; DKC400UY/XF24U: AC110V
18. Motor Capacitor
19. Motor: U (com), V (Positive direction), W (Opposite direction), E (grounding)
20. Power Input: E (Earth), L (Live), N (Neutral)
DKC400Y/XF24W: AC220V; DKC400UY/XF24U: AC110V
16

DKC400(U) & DKC400(U)Y SLIDING GATE OPERATOR USER’S MANUAL
Fig.16 KZB13 control board with silicon controlled rectifier & relay
17
DKC400(U) & DKC400(U)Y SLIDING GATE OPERATOR USER’S MANUAL
Wiring notes for control board (KZB13)
1. Fuse: DKC400Y/XF24W: 5A, Ø5x20; DKC400UY/XF24U: 10A, Ø5x20
2. Power Input: E (Earth), L (Live), N (Neutral)
DKC400Y/XF24W: AC220V; DKC400UY/XF24U: AC110V
3. Motor: U (com), V (Positive direction), W (Opposite direction), E (grounding)
4. Capacitor: DKC400Y/XF24W:14uf; DKC400UY/XF24U: 55 uF
5. Alarm lamp: DKC400Y/XF24W: AC220V; DKC400UY/XF24U: AC110V
6. Sampling transformer: 220V/12V 1W
7. Force Adjustor (VR): Clockwise +, Counterclockwise –
8. Power Transformer
9. MCU: PIC 16C57C
10. Power indicator: LED1
11. Output power supply: AC24V
12. Memory Card: 93C66
13. Limit switch: CL (Close limit), CO (Com), OP (Open limit)，DC12V (Output power supply)
CL
COM
OP
N.C. (For N.C. limit switch)
CL
COM
OP
N.O. (For N.O. limit switch)
Limit switch mode is adjustable by DIP-switch. (See table 3)
Schematic diagram
14. Three button switch / single button switch (keypad)
Three button switch (normally open, three-button mode): T (Stop), G (Close), K (Open), COM
(Common)
N.O.
Button switch
T
G
K
COM
COMMON
STOP
CLOSE
OPEN
COM
K
G
T
Control board
terminal X7 No.14
Schematic diagram Wiring diagram
Single button switch / Keypad (normally open, single-button mode): T (Not used), G (Open
priority), K (Open/stop/close), COM (Common)
To install the keypad attach one lead of your keypad to ‘K’ of terminal X7 and the other to the
‘COM’. The keypad will function in single channel mode.
18

DKC400(U) & DKC400(U)Y SLIDING GATE OPERATOR USER’S MANUAL
Button switch
keypad
Not used
G
T
COM
K
Com
Signal
NO
com
K
Open
G
com
NO
Control board
Schematic diagram Wiring diagram
NOTE: Two modes (three-button mode or single-button mode) you can select according
to your order.
15. Output power supply: +12V (DC +12V), COM (CO)，DET (Loop detector), I.R. (Infrared
N.C)
DET
COM
Out
COM
AC24V AC24V Terminal
X5,No.11
Loop detector Control board
Loop detector with AC input
COM
GND
+12V
Out COM
DET
COM
+12V
Loop detector Control board
Loop detector with DC input
Infrared with AC input
Infrared with DC input
Control board
Infrared
Control boardInfrared
Terminal
X5,No.11
AC24VAC24V
COM Out COM
I.R
+12V
COM
I.R
COM
Out
+12V
GND
COM
Terminal
X8, No.15
Terminal
X8, No.15
Terminal
X8, No.15
Terminal
X8, No.15
Schematic diagram
16. Beeper: DC12V
17. Learn button: AN
18. Dip-switch
19. Antenna: ANT
19
DKC400(U) & DKC400(U)Y SLIDING GATE OPERATOR USER’S MANUAL
8. Control
Below are all of the available remote controls for DKC400 series gate operators, the remote
control came with your operator depends on your order.
Additional remote controls can be purchased through your dealer.
Fig.17
You can select program / learn process (supporting up 100 remote controls or 25
remote controls) according to your order. If you have any problem, please contact the
dealer.
Adding extra remote controls (learn): Press the button ‘AN’ (See Fig.14, Fig.15 terminal
13 or Fig.16 terminal 17) on the control board, then the ‘LED2’ will be on and turn off,
the beeper will ring about 1 second, then press the remote control button which you
want to use, the beeper will ring about 2 seconds and the ‘LED2’ will turn on and then
turn off, The learning process is finished.
Up to 100 remote controls may be used.
Adding extra remote controls (learn): press the button “AN” (See Fig.14, Fig.15 terminal
13 or Fig.16 terminal 17) on the control board, then the beeper will ring about 1 second,
when you press the remote control button, the beeper will ring again, press the same
remote control button again, the beeper will ring at 1/2Hz frequency and then stop. The
learning process is finished.
Up to 25 remote controls may be used.
Erase remote controls: To erase all existing remote controls, press and hold ‘AN’
button until the beeper stops ringing. This indicates that all the remote controls have
been erased completely.
Warning: For safety and security, we recommend that the factory setting be
replaced with a personal code.
The remote control works in a single channel mode. It has four buttons. See Fig.17
The function of button 1, button 2 and button3 are the same. With each press of the
remote control button which has been programmed, the gate will close, stop, open or
20
YKF09YKF06
Button 4
Button 3
Button 2
Button 1
Button 3
Button 4
Button 2
Button 1

DKC400(U) & DKC400(U)Y SLIDING GATE OPERATOR USER’S MANUAL
stop cycle.
Button 1, button 2 and button 3 are used to open or close the gate. Button 4 is
available to set pedestrian mode. Note: if you canceled the pedestrian mode, the
function of button 4 is same as the other three buttons.
You can program/learn button 1, button 2, button 3 individually. You also can
program/learn two buttons or three buttons together, but you need repeat the
program/learn process if you want to use more than one button.
Warning: Notify the users that the gate is never to be operated unless it is in full view.
Verify open direction: If the gate does not move in the desired direction, then you will
need to reverse the motor operating direction, you can do this by exchanging wires ‘V’
and ‘W’, ‘OP’ and ‘CL’.
Tab. 3 DIP-switch
(See Fig.14 KZB01, Fig.15 KZB05 terminal 5)
Position DIP-switch Function
1ON Limit switch mode is NC.
OFF Limit switch mode is NO.
2ON Auto-close function and auto-close function of pedestrian
mode are available.
OFF Both Auto-close function and auto-close function of
pedestrian mode are shut off.
3ON Programming / In this position the control board is in
programming condition, NOT USE condition.
OFF Normal / In this position the control board can be normally
used.
(See Fig.16 KZB13 terminal 18)
Position DIP-switch Function
1ON Programming / In this position the control board is in
programming condition, NOT USE condition.
OFF Normal / In this position the control board can be normally
used.
2ON Auto-close function and auto-close function of pedestrian
mode are available.
OFF Both Auto-close function and auto-close function of
pedestrian mode are shut off.
3ON Limit switch mode is NC.
OFF Limit switch mode is NO.
DKC400(U) & DKC400(U)Y SLIDING GATE OPERATOR USER’S MANUAL
Set auto-close function (This feature can be selected to make the gate stay open for some
seconds before it automatically closes. The auto-close time can be adjusted to between 0 and
44 seconds.): for control board KZB01 or KZB05, please turn on the second and the third
DIP-switch to ON position (Note: for control board KZB13, please turn on the first and the
second DIP-switch to ON position). Press the remote control button (button 1, button 2 or
button 3) that has been programmed to open the gate (see Verify open direction section).
Stop the gate at any position by pressing the same button, wait for some seconds according to
your requirements (the range is 1~44 sec.), this period of time is regarded as ‘auto-close time’.
Close the gate by pressing the same button. Press the button again to stop the gate or the
gate will stop at its closed position automatically if the limit switch is reached. After this setup is
complete, return DIP-switch 3 to OFF position immediately (for control board KZB13, return
DIP-switch 1 to OFF). Thus the auto-close function has been set.
Cancel auto-close function: for control board KZB01 or KZB05, please turn on the second and
the third DIP-switch to ON position (Note: for control board KZB13, please turn on the first
and the second DIP-switch to ON position). Press the remote control button (button 1,
button 2 or button 3) that has been programmed to open the gate (see Verify open direction
section). Stop the gate at any position by pressing the same button, wait until the gate close
automatically (45 sec.). Press the same button to stop the gate or the gate will stop at its
closed position automatically if the limit switch is reached. After this setup is complete, return
DIP-switch 3 to OFF position immediately (for control board KZB13, return DIP-switch 1 to
OFF). Thus the auto-close function has been canceled.
Pedestrian mode: Pedestrian mode can be used to open gate about 1.5 meters for people
pass through.
﹡Set width of pedestrian mode: for control board KZB01 or KZB05, please turn on the second
and the third DIP-switch to ON position (Note: for control board KZB13, please turn on the
first and the second DIP-switch to ON position). Press button 4 to open the gate (see
Verify open direction section), Wait until the gate travels the distance according to your
requirements (the distance range is 0.3m~1.5m or wait for 3~10 sec.), it is regarded as ‘the
width of pedestrian mode’. Then press the same button/button 4 to stop the gate, wait for
some seconds (1~ 44 sec.). Close the gate by pressing the same button/button 4. Press the
same button again to stop the gate or the gate will stop at its closed position automatically if
the limit switch is reached. After this setup is complete, return DIP-switch 3 to OFF position
immediately (for control board KZB13, return DIP-switch 1 to OFF). Thus the width of
pedestrian mode has been set.
If you open the gate with button 4, the gate will stop at the expected position that you have set.
21
22

DKC400(U) & DKC400(U)Y SLIDING GATE OPERATOR USER’S MANUAL
﹡Set auto-close function of pedestrian mode: for control board KZB01 or KZB05, please turn
on the second and the third DIP-switch to ON position (Note: for control board KZB13,
please turn on the first and the second DIP-switch to ON position). Press button 4 to open
the gate (see Verify open direction section), wait some seconds (3~10 sec.). Then press the
same button/button 4 to stop the gate, wait some seconds according to your requirements
(1~44 sec.), this period of time is regarded as ‘auto-close time of pedestrian mode’. Close the
gate by pressing the same button/button 4. Press the same button again to stop the gate or
the gate will stop at its closed position automatically if the limit switch is reached. After this
setup is complete, return DIP-switch 3 to OFF position immediately (for control board KZB13,
return DIP-switch 1 to OFF). Thus the auto-close function of pedestrian mode has been
set.
Note: the new width of pedestrian mode has been re-programmed in the device and replaced
the original width you have set in Set width of pedestrian mode section.
If you open the gate with button 4, the gate will stop at the new expected position that you
have set, after some seconds as what you have set, the gate will close automatically.
Cancel width / auto-close function of pedestrian mode
﹡Cancel both width and auto-close function of pedestrian mode: for control board KZB01 or
KZB05, please turn on the second and the third DIP-switch to ON position (Note: for control
board KZB13, please turn on the first and the second DIP-switch to ON position). Press
button 4 to open the gate (see Verify open direction section). Wait for more than 15 sec..
Then press the same button/button 4 to stop the gate. Wait until the gate close automatically
(45 sec.). Press the same button/button 4 to stop the gate or the gate will stop at its closed
position automatically if the limit switch is reached. After this setup is complete, return
DIP-switch 3 to OFF position immediately (for control board KZB13, return DIP-switch 1 to
OFF). Thus the width and auto-close function of pedestrian mode have been canceled.
﹡Cancel width of pedestrian mode, keep auto-close function of pedestrian mode: for control
board KZB01 or KZB05, please turn on the second and the third DIP-switch to ON position
(Note: for control board KZB13, please turn on the first and the second DIP-switch to
ON position). Press button 4 to open the gate (see Verify open direction section). Wait for
more than 15 sec.. Then press the same button/button 4 to stop the gate. Wait some seconds
according to your requirements (1~44 sec.). Then press the same button/button 4 to close the
gate, press the same button again to stop the gate or the gate will stop at its closed position
automatically if the limit switch is reached. After this setup is complete, return DIP-switch 3 to
OFF position immediately (for control board KZB13, return DIP-switch 1 to OFF). Thus the
width of pedestrian mode has been canceled, the auto-close function of pedestrian mode has
been reserved.
Note: the new auto-close time of pedestrian mode has been re-programmed in the device and
replaced the original auto-close time of pedestrian mode that you have been set in Set
auto-close function of pedestrian mode section.
23
DKC400(U) & DKC400(U)Y SLIDING GATE OPERATOR USER’S MANUAL
﹡Keep width of pedestrian mode, cancel auto-close function of pedestrian mode: for control
board KZB01 or KZB05, please turn on the second and the third DIP-switch to ON position
(Note: for control board KZB13, please turn on the first and the second DIP-switch to
ON position). Press button 4 to open the gate (see Verify open direction section). Wait
some seconds (3~10 sec.), then press the same button/button 4 to stop the gate. Wait until the
gate close automatically (45 sec.). Press the same button again to stop the gate or the gate
will stop at its closed position automatically if the limit switch is reached. After this setup is
complete, return DIP-switch 3 to OFF position immediately (for control board KZB13, return
DIP-switch 1 to OFF). Thus the width of pedestrian mode has been reserved, the auto-close
function of pedestrian mode has been canceled.
Note: the new width of pedestrian mode has been re-programmed in the device and replaced
the original width.
If you open the gate with button 4, the gate will stop at the expected position that you have set,
but the gate will not close automatically.
Turn on the second DIP-switch to OFF position (Factory preset: OFF position), both auto close
function and auto-close function of pedestrian mode were shut off.
Note:
(1) You must follow the operating instruction as above, any wrong operation is not
allowed.
(2) If the gate cannot be moved, please check whether the gate is obstructed.
Adjustment of the auto-reverse function: rotate the ‘VR1’ (See Fig.14, Fig.15 terminal 14) or
‘VR’ knob (see Fig.16 terminal 7) with a screwdriver to adjust opening & closing force, the
resistance may be increased (or decreased) by rotating clockwise (or counterclockwise). If you
turn the variable resistor clockwise it will increase force. If you turn the variable resistor
counterclockwise, it will decrease force. Note: if the gate fails to reverse in the event of
obstruction, then the opening force or closing force should be checked for conformity with
requirements and adjusted accordingly. The gate will reverse if obstructed when closing, and
will stop if jammed when opening.
Please exchange two wires ‘V’ and ‘W’ if the auto-reverse direction is wrong. Exchange wires
‘OP’ and ‘CL’ if the limit direction is wrong.
WARNING: Do not attempt to tune the gate by placing your hand, arm or other body part in the
path of the gate, as serious injury could result. Damage to the gate operator motors may also
occur by placing a heavy immovable object in the path during the testing phase. Instead, place
a light object in the path (e.g., a chair or trash can) which can be pushed out of the way without
causing damage to gate motors. Once the tuning is complete you may replace the cover.
24

DKC400(U) & DKC400(U)Y SLIDING GATE OPERATOR USER’S MANUAL
Activities Covered in this section
Remote control: With each press of the button, the gate will close, stop, open or stop cycle.
(Single-button mode)
External button switch (not included): two different modes you can select according to
your order.
Three-button external button switch: press ‘OPEN’ button, the gate will open. Press ‘STOP’
button, the gate will stop. Press ‘CLOSE’ button, the gate will close.
Single-button/keypad: with each press of the button, the gate will close, stop, open or stop
cycle.
Auto-reverse function: After adjusting the opening force and closing force, the gate will
reverse and go open if obstructed when closing, and will stop if jammed when opening.
Auto-close function: This feature can be selected to make the gate stay open for some
seconds before it automatically closes. The auto-close time can be adjusted to between 0 and
44 seconds.
Pedestrian mode: This feature can be used to open gate about 1.5 meters for people pass
through.
Infrared photocell (not included): If infrared beam is interrupted during closing, the gate will
reverse and go open immediately. This feature will not function if the gate is in fully opened
and closed positions or during opening.
Open priority: The gate will return to open if press ‘OPEN’ button of external button switch
during closing.
Loop detector (not included): If loop detector detects vehicles during closing, the gate will
reopen immediately and stay open until the vehicles move out of the loop. After vehicles move
out of the loop, the gate will continue to close.
If loop detector detects vehicles when the gate stops, the gate will remain stop until vehicles
move out of the loop. After vehicles move out of the loop, the gate will close.
The gate will keep opening if loop detector detects vehicles during opening. After vehicles pass
through the loop, the gate will close.
Limit switch: The switch is used to accurately stop the gate in the opened and closed
positions.
If the gate stops at opened position when the limit switch is reached, the gate will not move if
you press ‘OPEN’ button.
If the gate stops at closed position when the limit switch is reached, the gate will not move if
you press ‘CLOSE’ button.
9. Final Check
Check the power supply, grounding and wiring before running the device.
Release the gear clutch with the release key to determine whether or not the gate can be
moved manually. If everything is in good working order, tighten the clutch with the key.
Switch on the power and run the device to ensure that the gate is sliding smoothly.
Adjust the magnet (block) position until the gate opened and closed properly at the limited
positions.
The gate operator is installed with a thermal protector, the motor is only designed to work for
25
DKC400(U) & DKC400(U)Y SLIDING GATE OPERATOR USER’S MANUAL
less than 5 minutes. If is runs continually for an extended period of time, the thermal protector
will switch off the motor automatically in case of the temperature is higher than 120°C and
switch on the motor when the temperature is lower than 85°C±5°C.
10. Maintenance
Keep operator clean at all times.
Ensure the operator is well earthed, and correctly terminated.
Regularly grease the wheels and axles to ensure the gate moves smoothly.
26

DKC400(U) & DKC400(U)Y SLIDING GATE OPERATOR USER’S MANUAL
11. Troubleshooting
Tab.4
Trouble Possible causes Solutions
Motor only runs in one direction.
The wire connector terminal block
becomes loose. Check wire connector terminal block.
The limit switch wire connector
terminal block becomes loose.
Check limit switch wire connector
terminal block.
Check the limit switch mode.
For control board KZB01 and KZB05,
the electric component on the control
board such as Q2, Q91 or Q92,
(KZB13: Q6) may
be damaged.
Replace the electric component Q2,
Q91, Q92 or (KZB13: Q6).
Replace the board.
By pressing button 1(button 2 or
button 3) which has been
programmed to open the gate, press
the same button again to stop the
gate in required position, but the gate
will auto-close immediately.
The auto-close time is too short. Reset the auto-close time. See Set
auto-close function section.
When you use button 4 of remote
control to open the gate, gate travels
too short. The width of pedestrian mode is too
narrow. Reset the width of pedestrian
mode. See Set width of
pedestrian mode section.
When you use button 4 of remote
control to open the gate, but the gate
will auto-close immediately. The auto-close time of pedestrian
mode is too short.
Reset the auto-close time of
pedestrian. See Set auto-close
function of pedestrian mode
section.
The gate will not open or close.
The limit switch wire connector
terminal block becomes loose. Check the limit switch mode (see table 3 DIP-switch).
Connecting wires or terminal blocks
are too loose. Check the connecting wires and terminal blocks.
For control board KZB01 and KZB05,
the electric component on the control
board such as Q2, Q91 or Q92,
(KZB13: Q6) may be damaged.
Replace the electric component Q2,
Q91, Q92 or (KZB13: Q6).
Replace the board.
Power switch is OFF. Make sure power switch is ON.
When you open the gate by using
button 1(button 2 or button 3) which
has been programmed, gate will stop
in mid-travel or reverse before
reaching the fully limit position.
The Force Adj. is adjusted too small. Check the Force Adj.
Adjust knob to increase force.
Gate is obstructed. Remove the obstruction.
Remote control does not work.
The indicator light of remote control
does not light. Check the batteries on your remote control.
Remote control is not suitable for
receiver.
E
rase remote controls
and
then
re-program the codes in the device.
See Adding extra remote
controls
(learn)
section.
Broken receive board. Replace receive board.
The remote control operating
distance is too short. Signals are shielded by the gate.
Link a new antenna (1~1.2m BVR
0.75mm2) to the old antenna. Then
fix the antenna on the wall
vertically, make sure the total height
from the top of antenna to the
ground is approx. 1.5m.
27
